ROHO SOFFLEX 2 User manual

SUPPLIER: This manual must be kept with this product.
CAREGIVER: Before using this product, read these instructions and save for future reference.
shape fitting technology®
ROHO®Non-Powered Mattress Overlays & Accessories
Operation Manual

3
TABLE OF CONTENTS
Warnings 4-5
Cautions 5
Intended Use 6
CPR 6
Parts Detail 7
Product Specifications 7-8
Product Use Instructions:
ROHO® DRY FLOATATION®Mattress Overlay System 8-10
ROHO® DRY FLOATATION®Bariatric Mattress Overlay System 8-10
ROHO® DRY FLOATATION®Operating Room Pad 8-10
ROHO® SOFFLEX®2 Mattress Overlay System 8-10
ROHO® PRODIGY®Mattress Overlay System 8-10
Attachment and Removal of Covers 11
ROHO® DRY FLOATATION®Isolette 12
ROHO®DRY FLOATATION® Nesting Pad 12
ROHO®Thyroid Pillow 12
ROHO®DRY FLOATATION® Head/Neck Pillow 12
Cleaning & Disinfecting 12-13
Disposal, Troubleshooting, Repair Program, & Contact Information 13-14
Return Policy & Limited Warranty 15
ESPAÑOL 16
FRANÇAIS 29
DEUTSCH 42
ITALIANO 55
NEDERLANDS 68
DANSK 81
SVENSKA 94
NORSK 107
SUOMI 120
PORTUGUÊS 133
ROHO, Inc. has a policy of continual product improvement and reserves the right to
amend this document. The current version of this document is available at www.roho.com.
Manufactured by ROHO, Inc.
100 North Florida Avenue, Belleville, Illinois 62221-5429
U.S.A.: 800-851-3449 • Fax [phone] • e-mail: [email protected]
Outside the U.S.A.: 618-277-9150 • Fax [phone] • e-mail: [email protected]
© 2008, 2013 ROHO, Inc.
The following are registered trademarks of ROHO, Inc.:
ROHO®, DRY FLOATATION®, PRODIGY®, SOFFLEX®and shape fitting technology®.
Products in this manual may be covered by one or more U.S. and foreign patents and
trademarks. For further details please refer to www.roho.com.

4
Mattress Overlay - Entrapment and Fall Risks: Medical experts and governmental entities
in various countries have determined that the use of side rails on beds may present a
life-threatening entrapment danger to the individual. Bed frame side rail usage is not a
requirement for the functional operation of any ROHO product; however, the use of side rails
may be clinically indicated for certain individuals. The decision whether to use side rails
should be based upon applicable laws, regulations, the individual’s condition and needs, and
a case-by-case assessment by clinicians and / or healthcare providers actively involved in
the individual’s care. Such an assessment may include, but not be limited to: the individual’s
physique, overall condition, level of confusion or cognitive impairment (with or without
medication), mobility (or lack thereof), history of falls, combativeness, attempts to get out of
bed, uncontrolled body movement, and frustration when confined.
Knowledgeable and properly trained caregivers should:
• In the event a decision is made to use side rails, ensure that any risks associated with
the individual becoming entrapped in the side rails are identified and steps are taken to
minimize such risks.
• In the event a decision is made not to use side rails, ensure that any risks associated
with the individual falling out of bed are identified and steps are taken to minimize
such risks.
• Determine whether to use pads, bolsters, alarms, high-low beds, or other positioning
aids and safety devices that are available on the market to reduce the risk of
entrapment or falls.
• Suffocation Risk: The ROHO SOFFLEX 2 Mattress Overlay (SOFFLEX 2) and ROHO PRODIGY
Mattress Overlay (PRODIGY) should not be used by infants or other individuals who are at
risk of suffocation.
• Skin/soft tissue breakdown can occur due to a number of factors, which vary by
individual. Check skin daily. Redness, bruising, or darker areas (when compared to normal
skin) may indicate the beginning of soft tissue breakdown and needs to be addressed. STOP
USE if any discoloration does NOT disappear within 30 minutes after transferring from the
product. Consult a healthcare professional immediately.
• Check inflation and adjustment frequently, at least once a day!
• Ensure that product sections are snapped together before and during use.
• Weight Limit: The mattress overlay should be correctly sized to the individual and the bed
mattress. If it is NOT, the product’s benefits may be reduced or eliminated, increasing risk
to skin and other soft tissue.
• DO NOT use ROHO® Mattress Overlay Enclosure Cover (Overlay Enclosure Cover) handles
to lift or slide the individual, as it may result in injury.
• While properly adjusted mattress overlays will protect the individual from tissue trauma,
they do not eliminate the need for periodic individual turning.
• It is important that the product be set up by knowledgeable caregivers who are properly
trained in the use of this product.
WARNINGS

5
• PROPER INFLATION: Refer to the Adjustment Instructions for proper inflation guidelines.
Proper inflation offers the maximum therapeutic benefit to the individual. Please note that
a product that has been properly adjusted for the specific individual may appear under-
inflated when unoccupied; this is because the individual’s body mass is no longer loading
the product. The use of any inflation device other than the supplied hand pump may
damage the product and void the warranty.
•DO NOT use an under-inflated or over-inflated product. Doing so reduces or eliminates the
product’s benefits, increasing risk to the skin and other soft tissue.
If your product does not appear to be holding air, see TROUBLESHOOTING. If your
product is still not holding air, contact your clinical caregiver, distributor, or ROHO, Inc.
immediately.
• The cushioning products featured in this operation manual are NOT recommended for use
with x-rays due to potential radiopacities, which may interfere with diagnoses or surgical
procedures that require radiographic images.
• Placing too many linens or other materials between the product and the individual will
reduce the product’s effectiveness.
• DO NOT use the product as a water flotation device (e.g., a Life Preserver). It will NOT
support you in water.
• Changes in altitude may require adjustment to your product.
• Keep the product away from sharp objects, which may puncture the air cells and cause
deflation.
• DO NOT expose the product to high heat, open flames or hot ashes.
• If a product has been in temperatures less than 32°F / 0°C and exhibits unusual stiffness,
allow the product to warm to room temperature, then open air valve(s). Roll and unroll the
product until the material is soft and pliable again. Repeat adjustment instructions before
using.
• DO NOT use any valve or air cell as a handle for carrying or pulling the product. Grasp
mattress overlay sections by the base or the outside edges. DO NOT use the product as a
transfer surface. DO NOT re-position the product while it is in use.
• DO NOT allow oil-based lotions or lanolin to come in contact with the product as they may
degrade the material.
• Prolonged exposure to ozone will degrade the product and may affect the performance of the
product and invalidate the product warranty.
• Straps must be attached for use with the SOFFLEX 2 and the PRODIGY unless used with the
Overlay Enclosure Cover. The Overlay Enclosure Cover straps must be secured to the bed
mattress when the cover is in use.
WARNINGS, Continued
CAUTIONS

6
PRODUCT INTENDED USE
The products in this manual are intended to be part of an overall care regimen. ROHO, Inc.
recommends that a clinician make product recommendations based upon an evaluation of
the individual’s medical and therapeutic needs.
• The ROHO®DRY FLOATATION®Mattress Overlay System (Standard Overlay) and the ROHO
DRY FLOATATION Bariatric Mattress Overlay System (Bariatric Overlay) are non-powered,
air-filled, adjustable, zoned, reactive, full support surfaces that are intended to conform to
an individual’s shape to provide skin/soft tissue and deep tissue injury protection and an
environment to facilitate wound healing. ROHO mattress overlays must be used on top of
standard hospital, nursing home, home care or consumer mattresses. There is no weight
limit for the Standard Overlay or Bariatric Overlay when properly sized to the individual
and the bed mattress.
• The ROHO®DRY FLOATATION®Isolette (Isolette) and ROHO®DRY FLOATATION®Nesting Pad
(Nesting Pad) are designed for infants who may require skin/soft tissue protection as part
of their medical care, and fit standard hospital isolettes and home isolettes.
• The ROHO®DRY FLOATATION®Operating Room Pad (O.R. Pad) is a non-powered, air-
filled, adjustable, zoned, reactive, full support surface that is intended to conform to an
individual’s shape to provide skin/soft tissue and deep tissue injury protection. The O.R.
Pad must be used on top of an operating room table on the flat surface, without additional
positioning devices between the table and O.R. Pad. There is no weight limit for the O.R.
Pad when properly sized to the individual and table.
• The ROHO®DRY FLOATATION®Head / Neck Pillow (Head / Neck Pillow) is designed to
provide cushioning and support to the head and neck for individuals who may require
skin/soft tissue protection.
• The ROHO®Thyroid Pillow (Thyroid Pillow) is designed for individuals who are undergoing
surgical procedures that require hyperextension of the neck.
• The ROHO®SOFFLEX®2 Mattress Overlay System (SOFFLEX 2) is a non-powered, air-
filled, adjustable, zoned, reactive, full support surface that is intended to conform to
an individual’s shape to provide skin/soft tissue and deep tissue injury protection and
an environment to facilitate wound healing. The SOFFLEX 2 must be used on top of a
standard hospital, nursing home, home care, or consumer mattress. There is a weight
limit of 330 pounds (150 kg) when properly sized to the individual and bed mattress.
• The ROHO®PRODIGY®Mattress Overlay System (PRODIGY) is a non-powered, air-filled,
adjustable, zoned, reactive, full support surface that is intended to conform to an
individual’s shape to provide skin/soft tissue and deep tissue injury protection. The
PRODIGY Mattress Overlay System must be used on top of a standard hospital, nursing
home, home care, or consumer mattress. There is a weight limit of 300 pounds (136 kg)
when properly sized to the individual and bed mattress.
• The ROHO®Mattress Overlay Foam Insert Pad (Insert Pad) or ROHO®Leveling Pad
(Leveling Pad) may be used in place of mattress overlay sections for areas that that do not
require skin/soft tissue protection. Consult with a clinician.
CPR
CPR may be performed without deflating the product. A cardiac board is not necessary.

7
To order replacement parts, from the U.S.A., contact the ROHO Customer Service Department, call your
product provider, or visit The ROHO Store at www.therohostore.com. Outside the U.S.A., contact your
country’s ROHO distributor.
PARTS DETAIL (Standard Overlay Section shown)
Mattress Overlay System
Cover
ROHO Hand Pump
Cells
Repair Kit
Snaps
Product Registration Card
Product
Registration Card
Operation Manual
Inflation
Valve
PRODUCT SPECIFICATIONS
MATERIALS:
• ROHO® DRY FLOATATION®products featured in this manual are made of neoprene rubber with nickel
plated brass valve(s).
• SOFFLEX 2 is made of polyether polyurethane with a nickel plated brass valve and nylon straps
• PRODIGY is made of Flame Retardant Polyvinyl Chloride (PVC) Film (DEHP Free) with nickel plated
brass valve and nylon straps.
• ROHO® Reusable Mattress Overlay System Cover (Reusable Overlay Cover) and Overlay Enclosure Cover
are made of two-way stretch, moisture-resistant fabric with a zipper, straps and carrying handle.
Refer to the care label attached to your cover for material content.
The Reusable Overlay Cover and the Overlay Enclosure Cover are designed to fit the Standard
Overlay system, SOFFLEX 2 system, and PRODIGY system. Covers are not available for all sizes.

8
PRODUCT SPECIFICATIONS, Continued
Width x Length x
Height (in.) Width x Length x Height (cm) Weight (lb.) Weight (kg)
Standard Overlay Section 33.75 x 19.25 x 3.25 86 x 49 x 8.5 8.0 3.6
Standard Overlay System
(4 Sections) 33.75 x 75 x 3.25 86 x 190.5 x 8.5 32.0 14.4
Bariatric Overlay System
(8 Sections)
39.5 x 75 x 3.25
41.5 x 75 x 3.25
54.5 x 75 x 3.25
60 x 75 x 3.25
100.5 x 190.5 x 8.5
105.5 x 190.5 x 8.5
138.5 x 190.5 x 8.5
152.5 x 190.5 x 8.5
36.5
38.5
47.5
50.5
16.5
17.4
21.5
22.9
Bariatric Overlay System
(12 Sections) 48.5 x 75 x 3.25 123 x 190.5 x 8.5 45.0 20.4
Standard SOFFLEX 2 Section 36 x 27.5 x 3.5 91.5 x 70 x 9 2.25 1.0
Standard SOFFLEX 2 System
(3 Sections) 36 x 81.75 x 3.5 91.5 x 207.5 x 9 6.5 2.9
PRODIGY Section 36 x 27.5 x 3.5 91.5 x 70 x 9 3.25 1.4
PRODIGY System
(3 Sections) 36 x 81.75 x 3.5 91.5 x 207.5 x 9 9.6 4.3
NOTE: All measurements are approximate.
ADJUSTMENT INSTRUCTIONS FOR:
• Standard Overlay • SOFFLEX 2 • O.R. Pad
• Bariatric Overlay • PRODIGY
1: For mattress overlays: Remove all bed
linens except the support mattress pad or
sheet from existing bed mattress. Place the
mattress overlay sections cell side up, on
top of the bed mattress. Align the mattress
overlay sections and snap together.
For the O.R. Pad: Place the section or system
on the operating table, cells facing up.
2: Turn the valve counter-clockwise to open.
NOTE: If there is more than one valve per
section, only open one.
NOTE: SOFFLEX 2 and PRODIGY, valves are
located on the bottom surface.

9
6: For mattress overlays and O.R. Pad: To adjust for the proper immersion level of each
product section, slide your hand between the product surface and the individual’s lowest bony
prominence. Turn the valve counter-clockwise to open, and release air until the area of high
risk is within the suggested Inflation Guidelines (see the next page). Turn the valve clockwise
to close. Repeat Step 6 for the remaining product sections.
NOTE: The adjustment sequence noted in the image is ROHO's recommendation; the
sequence for adjusting the product may vary for each individual.
NOTE: Confirm proper adjustment after transferring the individual back onto the product.
3: Slide the pump’s rubber nozzle over the
valve and inflate until the product arches
slightly upward.
4: Turn the valve clockwise to close.
Remove the pump. Repeat steps 2 and 3 for
remaining sections.
5: For mattress overlays only: Reapply bed linens (maximum one sheet, one draw sheet, or one
incontinent pad). Place the individual on the mattress overlay in their normal lying position.
Linens not shown.
ADJUSTMENT INSTRUCTIONS, Continued

10
NOTE: Inflation Guidelines should be followed to ensure adequate air between all
parts of the individual and all sections of the mattress overlay or O.R. Pad. See WARNINGS.
Inflation Guidelines:
Product Distance From Base
Standard Overlay, Bariatric Overlay, O.R. Pad, and SOFFLEX 2 ½in. to 1 in. (1.5 cm to 2.5 cm)
PRODIGY 1in. to 1.5 in. (2.5 cm to 4 cm)
NOTE: Insert Pads or Leveling Pads may be used as replacement of Standard Overlay
sections ONLY. DO NOT use them as replacement solutions where the individual is at risk of
tissue breakdown. Replace the pad(s) with Standard Overlay section(s) at the first indication
of tissue trauma. Ensure that the pad(s) and sections(s) are properly snapped together
before use.
LINENS
Too many linens between the product and the individual will compromise skin protection
performance, prevent the individual from sinking in, and reduce pressure distribution.
It is recommended that a maximum of:
• One flat or contoured sheet, arranged loosely over the mattress overlay.
• If needed, a draw sheet for moving and transferring can be used.
• If needed, one incontinent pad can be used.
• Water-resistant Reusable Overlay Covers and Overlay Enclosure Covers are available
from ROHO, Inc.
PILLOW POSITIONING
ADJUSTMENT INSTRUCTIONS, Continued
Special Positioning: For an individual with special positioning needs while lying on their side
or back, a pillow can be placed beneath the mattress overlay. Consult with your clinician or
healthcare provider for proper pillow positioning.
ATTACHMENT OF OVERLAY STRAPS
NOTE: Four (4) Overlay Straps are included to aid in securing the SOFFLEX 2 and PRODIGY to
the bed mattress.
1. Attach one strap to each corner of the mattress overlay.
2. Stretch the straps around the corners of the bed mattress to secure the mattress overlay to
the bed mattress.
NOTE: Straps are provided with SOFFLEX 2 and PRODIGY Systems only.

11
Reusable Overlay Cover Attachment and Removal:
1. Attachment: Remove all bed linens, except the support mattress pad or sheet, from the
existing bed mattress. Unfold. Place the “feet graphic” at the foot of the bed. Stretch each
corner of the cover over the mattress overlay and bed mattress.
2. Removal: Pull each corner up and over the bed mattress and mattress overlay.
Overlay Enclosure Cover Attachment:
1. Remove all bed linens, except the support mattress pad or sheet, from the existing bed
mattress.
2. Referring to the directional labels, place the cover on top of the bed mattress, unzip one
side fully, and fold the cover top to one side. Wrap the straps under the bed mattress and
buckle to secure the cover to the bed mattress. NOTE: Overlay straps cannot be used with
the Overlay Enclosure Cover
3. Place the mattress overlay, cell side
up, inside the cover. Align the mattress
overlay sections and snap together.
4. Follow the inflation steps in the
Adjustment Instructions for the mattress
overlay, and continue with step 5 of these
instructions.
5. Reapply the bed linens (maximum one
sheet, one draw sheet, or one incontinent
pad).
6. Unfold the cover top.
7. Place the individual on the mattress
overlay in their normal lying position.
8. Follow the immersion steps in the
Adjustment Instructions to properly
immerse the individual.
9. Once the proper immersion is achieved,
zip the cover closed.
Overlay Enclosure Cover Removal:
To Remove the Mattress Overlay and Overlay Enclosure Cover TOGETHER:
1. Transfer the individual to a different surface.
2. Unbuckle and remove the cover from the bed with the mattress overlay still enclosed.
NOTE: If placing the individual back on the mattress overlay, ensure the sections are snapped
together and lying flat. Continue with step 4 of the Overlay Enclosure Cover Attachment
instructions.
To Remove the Mattress Overlay and Overlay Enclosure Cover SEPARATELY:
1. Transfer the individual to a different surface.
2. Unzip one side of the cover.
3. Unsnap and remove the mattress overlay sections from the cover.
4. Unbuckle the cover from the bed mattress and remove the cover from the bed mattress.
ADJUSTMENT INSTRUCTIONS, Continued

12
Adjustment Instructions for Isolette and Nesting Pad
1. Turn the valve counter-clockwise to open. Slide the pump’s rubber nozzle over the valve
and inflate until the product arches slightly upward. Turn the valve clockwise to close.
Remove the pump.
2. Place the infant on the mattress overlay. To properly immerse the infant, adjust the
Isolette or Nesting Pad by placing your open hand under the infant’s lowest bony
prominences, and then release air until there is no more than 1 in. (2.5 cm) and no less
than ½ in. (1.5 cm) between the areas of high risk and the base of the Isolette or Nesting
Pad.
3. Turn the valve clockwise to close.
Adjustment Instructions for Thyroid Pillow
1. Turn the valve counter-clockwise to open. Slide the pump’s rubber nozzle over the valve
and inflate the pillow to the level needed for hyperextension of the neck.
2. Turn the valve clockwise to close and remove the pump.
Adjustment Instructions for Head / Neck Pillow
1. Turn valve counter-clockwise to open. Slide the pump’s rubber nozzle over the inner
valve and inflate the pillow until it begins to slightly arch upward.
2. Turn valve clockwise to close and remove pump.
3. Repeat for the outside valve.
4. Place the individual's head / neck on the pillow. To properly immerse the individual's
head / neck, adjust the pillow by placing your open hand under the individual's head /
neck, and then release air until there is no more than 1 in. (2.5 cm) and no less than ½
in. (1.5 cm) between areas of high risk and the base of the Head / Neck Pillow.
5. Turn each valve clockwise to close.
CLEANING & DISINFECTING
Cleaning and disinfecting are two separate processes. Cleaning must precede disinfection.
NOTE: Before use by a different individual, clean, disinfect, and check product for proper
functioning.
To clean the Reusable Overlay Cover and Overlay Enclosure Cover:
Remove cover from mattress overlay. Machine wash, gentle cycle, in cold
water (30˚C) with a mild detergent. May also wipe clean with neutral
detergent and water. Rinse thoroughly. Tumble dry low.
NOTE: DO NOT dry clean the Reusable Overlay Cover.
To disinfect the Reusable Overlay Cover and Overlay Enclosure Cover:
Hand wash, using a dilution of one part household bleach to nine parts water.
Quaternary-type disinfectants may also be used in concentrations recommended
by the manufacturer. Rinse thoroughly. NOTE: The cover may be machine washed
occasionally in hot water (60˚C) for disinfection. However, ROHO, Inc.
recommends against repeated washings at high temperatures, as this
can accelerate degradation of the cover. Tumble dry low.
NOTE: Follow guidelines on bleach or disinfectant container.
ADJUSTMENT INSTRUCTIONS, Continued

13
CLEANING & DISINFECTING, Continued
To clean the air-filled products featured in this manual:
Remove all linens and/or straps. Turn valve(s) clockwise to close and place product in large
sink. Use mild liquid hand soap, hand dishwashing liquid, laundry detergent, or multipurpose
detergent that is used for general cleaning. Dilute, following product label directions for surface
cleaning. Use a soft plastic bristle brush, sponge, or wash
cloth to gently scrub all surfaces. Rinse thoroughly with clean
water and air dry.
To disinfect the air-filled products featured in this manual:
Repeat cleaning instructions. Use a solution of 1 part household liquid bleach per 9 parts of
warm water. Follow safety guidelines on bleach product label. Keep the clean product wet with
bleach solution for 10 minutes. Rinse thoroughly with clean water and air dry. NOTE: Most
germicidal disinfectants are safe if used
following the disinfectant manufacturer’s
dilution directions.
Note on Sterilization: ROHO products are not packaged in a sterile condition, nor are they
intended or required to be sterilized prior to usage. High temperatures accelerate aging and
may cause damage to the product assembly. If institution protocol demands sterilization,
open the valve(s) and use the lowest temperature possible for the shortest time possible.
Gas sterilization is preferable to steam autoclave, but neither is recommended. In any
process using pressure, ensure all valves are open to prevent damage to the product. ROHO,
Inc. highly discourages sterilization methods using temperatures greater than 200° F (93°
C) for DRY FLOATATION products or the Thyroid Pillow and 160° F (71°C) for Air Floatation
Mattress Overlays.
DISPOSAL
When properly used and disposed of, the components of the products in this manual are
associated with no known environmental hazards. Dispose of the product and/or components
in accordance with the applicable regulations in your jurisdiction. DO NOT INCINERATE.
+
DO NOT:
• machine wash or machine dry ROHO DRY FLOATATION products, PRODIGY, SOFFLEX 2,
or Thyroid Pillow.
• use abrasives such as steel wool or scouring pads.
• use caustic, automatic dishwasher detergents.
• use cleaning products containing petroleum or organic solvents including acetone,
toluene, Methyl Ethyl Ketone (MEK), naphtha, dry cleaning fluids, adhesive removers,
etc.
• allow water or cleaning solution to enter the product.
• expose to direct sunlight, ultraviolet light or ozone gas cleaning methods.
• use oil-based lotions, lanolin, or phenolic-based disinfectants on ROHO DRY
FLOATATION products or Thyroid Pillow because they may compromise the integrity of
the material.

14
TROUBLESHOOTING
Not Holding Air: Inflate the product. Then confirm that all valves are completely closed
(turn valves clockwise). Look for holes. If large holes or leaks are found, see REPAIR
PROGRAM. If very small holes or no holes are visible, follow the instructions in the Repair
Kit provided with your product.
Uncomfortable/Unstable: Make sure the product is not over-inflated or under-inflated (see
Adjustment Instructions). Make sure air cells are facing individual. Make sure the product
is not too big or too small for the bed. Allow individual to lie on the product for at least one
hour to adjust to the texture of the product and immersion into the air cells.
Mattress Overlay Slides on Bed: Make sure mattress overlay sections are snapped together.
If mattress overlay sections are on slick sheet, remove slick sheet. If using the Overlay
Enclosure Cover, check to make sure that the straps are secured to bed mattress. If using
SOFFLEX 2 or PRODIGY without the Overlay Enclosure Cover, check to make sure that the
mattress overlay straps are secure.
REPAIR PROGRAM
If you require a repair, you may return the product for assessment. Before returning the product
to ROHO, Inc., contact our Warranty Service Department in the U.S.A ([email protected]).
Outside the U.S.A., contact the nearest ROHO distributor.
Be advised that a charge will be assessed for any service provided for product that does not
qualify under the product’s warranty.
LOANER PROGRAM (U.S.A. ONLY)
ROHO, Inc. offers a loaner Standard Overlay section (Bariatric extensions are not included)
while your Standard Overlay section is being repaired. Loaner Standard Overlay sections
require a deposit. Contact our Warranty Service Department. The Loaner Program is only
available for the Standard Overlay.
CONTACT INFORMATION
In the U.S.A:
ROHO Warranty Service and Customer Care:
Phone: [phone] • Fax: [phone]
Warranty Service: [email protected]
Customer Care: [email protected]
Note: If directed to return any items, please send to:
ROHO, Inc.
1501 South 74th Street
Belleville, IL 62223
Outside the U.S.A.:
ROHO International:
[email protected] • Phone: [phone] • Fax: [phone]
Or visit www.roho.com for a list of ROHO International distributors.

15
RETURN POLICY
All products returned must be new and unused, require prior authorization from ROHO, Inc.,
and are subject to a restocking charge. Before returning your product: In the U.S.A., contact our
Warranty Service Department; outside of the U.S.A., contact your country’s ROHO distributor.
LIMITED WARRANTY
What is covered?
ROHO, Inc. covers any defects in materials or workmanship of the product.
For how long?
DRY FLOATATION Products and Thyroid Pillow (24 months), SOFFLEX 2 (18 months), and
PRODIGY (12 Months), from the date the product was originally purchased, with the exception
of covers, which have a 6-Month Limited Warranty.
What is not covered?
A product that has been misused, damaged by an accident, or damaged from "an act of Nature,"
e.g., flood, tornado, earthquake, fire. Any substitutions of supplied product accessories or
modification to the product will void the warranty.
What we will do.
Within a reasonable amount of time after you return the product to us, we will repair or
replace at our option any defect in material and workmanship and ship it back to you, all free
of charge.
What the customer must do.
Within the U.S.A., the customer must contact ROHO, Inc. Warranty Service Department. Note:
Any items sent to ROHO, Inc. without prior authorization will not be returned to the customer.
Outside the U.S.A., contact your country's ROHO distributor.
Questions?
See CONTACT INFORMATION.
Disclaimer.
Any implied warranties, including the MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE are limited to the same time period of the product types referenced above in
the "For how long" section and any action for a breach of such warranties or any express
warranties herein must be commenced within that time. ROHO, Inc. shall not be responsible
for any incidental or consequential damages with respect to economic loss to property,
whether as a result of a breach of express or implied warranties or otherwise.
Your rights and the effect of this warranty upon them.
This warranty restricts the duration of all implied warranties as noted above and limits or
excludes recovery for incidental or consequential damages. Some jurisdictions do not allow
limitations on how long implied warranties will last and some jurisdictions do not allow the
exclusion or limitation of consequential or incidental damages, so those provisions may not
apply to you. While this warranty gives you specific legal rights, you may also have other
rights which vary from jurisdiction to jurisdiction.

16
TABLA DE CONTENIDOS
Advertencias 17-18
Precauciones 18
Uso Previsto 19
RCP 19
Detalle de las Piezas 20
Especificaciones del Producto 20-21
Instrucciones de Uso del Producto:
Sistema de Cubierta de Colchón ROHO®DRY FLOATATION®21-23
Sistema de Cubierta de Colchón Bariátrico ROHO®DRY FLOATATION®21-23
Cojín para Quirófano ROHO®DRY FLOATATION®21-23
Sistema de Cubierta de Colchón ROHO®SOFFLEX®2 21-23
Sistema de Cubierta de Colchón ROHO® PRODIGY®21-23
Colocación y Extracción de Fundas 24
Isolette ROHO®DRY FLOATATION®25
Cojín para Bebés ROHO®DRY FLOATATION®25
Almohada para Tiroides ROHO®25
Almohada para Cabeza/Cuello ROHO®DRY FLOATATION®25
Limpieza y Desinfección 25-26
Desechado, Solución de Problemas, Programa de Reparación e Información de Contacto 26-27
Política de Devolución y Garantía Limitada 28
ROHO, Inc. tiene una política de mejora continua del producto y se reserva el derecho de modificar el
presente documento. La versión actual de este documento está disponible en www.roho.com.
Fabricado por ROHO, Inc.
100 North Florida Avenue, Belleville, Illinois 62221-5429
EE.UU.: 800-851-3449 • Fax [phone] • e-mail: [email protected]
Fuera de los EE.UU.: 618-277-9150 • Fax [phone] • e-mail: [email protected]
2008, 2013 ROHO, Inc.
Las siguientes son marcas registradas de ROHO, Inc.:
ROHO®, DRY FLOATATION®, PRODIGY®, SOFFLEX®y shape fitting technology®.
Los productos de este manual pueden estar cubiertos por una o más patentes y marcas de Estados Unidos y
en el extranjero. Para más detalles, consulte www.roho.com.
ESPAÑOL
Accesorios y Cubiertas de Colchones No Eléctricos
Manual de Operación
PROVEEDOR: Debe guardar este manual con este producto.
CUIDADOR: Antes de usar este producto, lea estas instrucciones y guárdelas para referencia futura.
shape fitting technology®

17
• Cubierta de Colchón - Riesgos de Atrapamiento y Caídas: Los expertos médicos y
entidades gubernamentales de varios países han determinado que el uso de barandas en
las camas puede presentar un peligro de atrapamiento letal para la persona. El uso de
barandas en el marco de la cama no es un requisito para la operación funcional de ningún
producto ROHO, sin embargo, su uso puede ser indicado clínicamente para ciertas personas.
La decisión de utilizar las barandas se debe basar en las leyes, reglamentos aplicables, en
las condiciones y necesidades de la persona, y en una evaluación del caso de los clínicos
y/o profesionales de la salud que participan activamente en el cuidado de la persona. Esta
evaluación puede incluir, pero no se limita a: el físico de la persona, su estado general, nivel
de confusión o deterioro cognitivo (con o sin medicación), movilidad (o falta de la misma),
historial de caídas, agresividad, intentos de salir de la cama, movimiento corporal sin
control y frustración en caso de confinamiento.
Los cuidadores informados y debidamente capacitados deben:
• En caso de que se tome la decisión de utilizar barandas, asegurar que se identifiquen los
riesgos asociados con la persona quedándose atrapada en las barandas y se tomen las
medidas para minimizar estos riesgos.
• En caso de que se tome la decisión de utilizar barandas, asegurar que se identifiquen
los riesgos asociados con la persona cayéndose de la cama y se tomen las medidas para
minimizar estos riesgos.
• Determinar si utilizarán cojines, almohadones, alarmas, camas ortopédicas, u otras
ayudas de posicionamiento y dispositivos de seguridad que están disponibles en el
mercado para reducir el riesgo de atrapamiento o caídas.
• Riesgo de Asfixia: No se debe utilizar la Cubierta de Colchón ROHO SOFFLEX 2 (SOFFLEX 2)
y la Cubierta de Colchón ROHO PRODIGY (PRODIGY) para niños u otras personas que tienen
riesgo de asfixia.
• Puede ocurrir degradación del tejido blando/piel debido a una serie de factores, que
varían según la persona. Revise la piel cada día. El enrojecimiento, moretones, o áreas más
oscuras (comparadas con la piel normal) pueden indicar el inicio de degradación del tejido
blando y se debe ser tratado. DETENGA SU USO si cualquier decoloración NO desaparece
dentro de 30 minutos después de no utilizar el producto. Consulte a un profesional de la
salud inmediatamente.
• ¡Revise el inflado y ajuste frecuentemente, por lo menos una vez al día!
• Asegúrese que las secciones del producto estén abrochadas, antes y durante su uso.
• Límite de Peso: La cubierta de colchón debe ser del tamaño correcto para la persona y
el colchón de la cama. Si NO lo es, los beneficios del producto pueden ser reducidos o
eliminados, lo que aumenta el riesgo para la piel y otros tejidos blandos.
• NO use las agarraderas de la Funda de la Cubierta de Colchón ROHO® (Funda de la
Cubierta) para levantar o deslizar a la persona, ya que puede provocar lesiones.
• Si bien las cubiertas de colchones bien ajustadas protegerán a la persona contra el
trauma del tejido, no eliminan la necesidad de girar a la persona periódicamente.
• Es importante que el producto sea colocado por cuidadores expertos que están
debidamente capacitados en el uso de este producto.
ADVERTENCIAS
ESPAÑOL

18
• INFLADO ADECUADO: Consulte las Instrucciones de Ajuste para conocer las directrices del
inflado adecuado. El inflado adecuado ofrece el máximo beneficio terapéutico a la persona.
Tenga en cuenta que un producto que ha sido ajustado correctamente para el persona
específica puede aparecer inflado en exceso cuando esté desocupado; esto se debe a que
la masa corporal de la persona ya no está poniendo carga sobre el producto. El uso de
cualquier dispositivo de inflado distinto a la bomba manual suministrada puede dañar el
producto y anular la garantía.
• NO use un producto inflado en exceso o no lo suficiente. Hacerlo reduce o elimina los
beneficios del producto, aumentando el riesgo para la piel y otros tejidos blandos.
Si su producto no parece sostener el aire, consulte la SOLUCIÓN DE PROBLEMAS. Si
su producto aún no está sosteniendo el aire, contacte a su cuidador clínico, a su
distribuidor o a ROHO, Inc. inmediatamente.
• Los productos de acolchamiento que aparecen en este manual de operación NO se
recomiendan para su uso con rayos X debido a las radiopacidades potenciales que
pueden interferir con el diagnóstico o procedimientos quirúrgicos que requieren
imágenes radiográficas.
• Colocar demasiada ropa de cama u otros materiales entre el producto y la persona
reducirá la eficacia del producto.
• NO use el producto como un dispositivo de flotación en el agua (por ejemplo, un chaleco
salvavidas). NO le dará soporte en el agua.
• Los cambios de altitud pueden requerir un ajuste de su producto.
• Mantenga el producto lejos de objetos afilados, éstos pueden perforar las celdas de aire y
desinflar el producto.
• NO exponga el producto al calor intenso, llamas vivas o cenizas calientes.
• Si un producto ha estado en temperaturas menores a 32°F/0°C y presenta rigidez inusual,
permita que el producto se caliente a temperatura ambiente, luego abra la(s) válvula(s) de
aire. Enrolle y desenrolle el producto hasta que el material esté suave y plegable de nuevo.
Repita las instrucciones de ajuste antes de usarlo.
• NO utilice ninguna válvula o celda de aire como agarradera para llevar o jalar del producto.
Sujete las secciones de la cubierta de colchón por la base o de los bordes exteriores.
NO utilice el producto como una superficie de transferencia. NO cambie la posición del
producto mientras está en uso.
• NO permita que lociones a base de aceite o lanolina entren en contacto con el producto, ya
que pueden degradar el material.
• La exposición prolongada a ozono degradará el producto y puede afectar el funcionamiento
del mismo e invalidar la garantía del producto.
• Se debe adjuntar las correas para su uso con el SOFFLEX 2 y PRODIGY a menos que se use
con la Funda de la Cubierta. Las correas de la Funda de la Cubierta deben fijarse al colchón
de la cama cuando se use la funda.
ADVERTENCIAS, Continuación
PRECAUCIONES
ESPAÑOL

19
USO PREVISTO DEL PRODUCTO
Los productos que aparecen en este manual tienen el propósito de ser parte de un régimen de
cuidado general. ROHO, Inc. recomienda que un clínico recete los productos en base a una evaluación
de las necesidades médicas y terapéuticas de la persona.
• La (Cubierta Estándar) Sistema de Cubierta de Colchón ROHO®DRY FLOATATION®y la (Cubierta
Bariátrica) Sistema de Cubierta de Colchón Bariátrico ROHO DRY FLOATATION son superficies sin
fuente eléctrica, llenas de aire, ajustables, zonales, reactivas, de apoyo completo que se amoldan
a la forma de una persona para proporcionar protección contra lesiones de la piel/tejido blando
y tejido profundo y un entorno para facilitar la cicatrización de heridas. Las cubiertas de colchón
ROHO se deben utilizar sobre los colchones de hospital, de hogares de ancianos, de cuidado en
casa o de consumo estándares. No hay límite de peso para la Cubierta Estándar o la Cubierta
Bariátrica cuando se ajusta el tamaño adecuadamente para la persona y al colchón de la cama.
• El Isolette (Isolette) ROHO®DRY FLOATATION®y el Cojín para Bebés (Cojín para Bebés) ROHO®
DRY FLOATATION®están diseñados para niños que pueden necesitar protección para la piel/tejidos
blandos como parte de su atención médica, y se ajustan a los isolettes estándares de hospital e
isolettes de casa.
• El Cojín para Quirófano (Cojín para Q.) ROHO®DRY FLOATATION®es una superficie sin fuente
eléctrica, llena de aire, ajustable, zonal, reactiva, de apoyo completo que se amolda a la forma
de una persona para proporcionar protección contra lesiones de la piel/tejido blando y tejido
profundo. Se debe utilizar el Cojín para Q. sobre una mesa de operaciones sobre la superficie
plana, sin dispositivos adicionales de posicionamiento entre la mesa y el Cojín para Q. No hay
límite de peso para el Cojín para Q. cuando se ajusta adecuadamente al tamaño de la persona y
de la mesa.
• La Almohada para Cabeza/Cuello (Almohada para Cabeza/Cuello) ROHO®DRY FLOATATION®está
diseñada para proporcionar amortiguación y apoyo a la cabeza y el cuello para las personas que
pueden requerir protección para la piel/tejidos blandos.
• La Almohada para Tiroides (Almohada para Tiroides) ROHO®está diseñada para las personas que
se someten a procedimientos quirúrgicos que requieren hiperextensión del cuello.
• El Sistema de Cubierta de Colchón ROHO®SOFFLEX®2 (SOFFLEX 2) es una superficie sin fuente
eléctrica, llena de aire, ajustable, zonal, reactiva, de apoyo completo que se amolda a la forma de
una persona para proporcionar protección contra lesiones de la piel/tejido blando y tejido profundo
y un entorno para facilitar la cicatrización de heridas. Se debe utilizar el SOFFLEX 2 sobre los
colchones de hospital, de hogares de ancianos, de cuidado en casa o de consumo estándares.
Hay un límite de peso de 330 libras (150 kg) cuando se ajusta el tamaño adecuadamente para la
persona y al colchón de la cama.
• El Sistema de Cubierta de Colchón ROHO®PRODIGY®(PRODIGY) es una superficie sin fuente
eléctrica, llena de aire, ajustable, zonal, reactiva, de apoyo completo que se amolda a la forma
de una persona para proporcionar protección contra lesiones de la piel/tejido blando y tejido
profundo. Se debe utilizar el Sistema de Cubierta de Colchón PRODIGY sobre los colchones de
hospital, de hogares de ancianos, de cuidado en casa o de consumo estándares. Hay un límite
de peso de 300 libras (136 kg) cuando se ajusta el tamaño adecuadamente para la persona y al
colchón de la cama.
• Se pueden utilizar las Almohadillas de Inserción de Espuma de la Cubierta de Colchón
(Almohadillas de Inserción) ROHO®o la Almohadilla de Nivelación (Almohadilla de Nivelación)
ROHO®en lugar de las secciones de la cubierta de colchón para las áreas que no requieren
protección para la piel/tejidos blandos. Consulte a un clínico.
RCP
Se puede proporcionar RCP sin desinflar el producto. No es necesaria una tabla de parada.
ESPAÑOL

20
Para pedir piezas de repuesto, de los EE.UU., contacte al Departamento de Servicio al Cliente ROHO,
llame a su proveedor del producto, o visite la Tienda ROHO en www.therohostore.com. Fuera de los
EE.UU., contacte al distribuidor ROHO de su país.
DETALLE DE LAS PIEZAS (Se muestra la Sección de la Cubierta Estándar)
Sistema de Cubierta del Colchón
Funda
Bomba Manual ROHO
Celdas
Kit de Reparación
Broches
Tarjeta de Registro del Producto
Product
Registration Card
Manual de Operación
Válvula de
Inflado
ESPECIFICACIONES DEL PRODUCTO
MATERIALES:
• Los productos ROHO®DRY FLOATATION®que se exhiben en este manual son hechos con goma de
neopreno con válvula(s) de latón chapado en níquel.
• SOFFLEX 2 está hecho de poliuretano polieter con una válvula de latón chapado en níquel y correas
de nylon
• PRODIGY está hecho de una Película de Cloruro de Polivinilo Retardador de Llamas (PVC) (Libre de
DEHP) con válvula de latón chapada en níquel y correas de nylon
• La Funda del Sistema de Cubierta de Colchón Reutilizable (Funda de Cubierta Reutilizable) ROHO®
y la Funda de la Cubierta están hechas de tela bioelástica, resistente a la humedad con una
cremallera, correas y agarradera de transporte. Consulte la etiqueta de cuidado adjunta a su funda
para ver el contenido del material.
La Funda de la Cubierta Reutilizable y la Funda de la Cubierta están diseñadas para ajustarse al
sistema de la Cubierta Estándar, al sistema SOFFLEX 2 y al sistema PRODIGY. Las fundas no están
disponibles para todos los tamaños.
ESPAÑOL
