Linuo LN-1621 User manual

1
8 Lipo laser+40Khz CAVITATION +VACUUM+MULTIPOLE RF Slimming Machine
LN-1621 Manual

2
Warning
Thanks for using our company's products, in order to fully make
use of the products, we sincerely suggests follow:
◆◆Please read the instruction in detail and keep it well for further
reading and consulting.
◆◆Please follow the instruction to fit and operate the machine.
◆◆Please do not remove and change any accessories of the
machine.
◆◆It forbids others to open and remove the mainframe except the
authorized people in the company.
◆◆It forbids others to change and maintain the machine except
the professional people.
◆◆Please contact us if there is any trouble during operation.
Working principal
wave fat system
With collective strong sound wave head, strong sound wave of 40KHZ may be emitted to vibrate
fat cells at top speed and produce numerous vacuum air pockets inside and outside the fat cells, robustly impact fat
cells to generate introverted blast and disintegrate triglyceride into glycerol and free fatty acids. Then RF
waves at frequency of 1M HZ is used for exhausting the integrated glycerol and free fatty acids through
hepatoenteral circulation. Finally, vacuum RF and energy electrode are used for positioning and tightening fat. In
physics, it is known as "cavitation". Micropore introverted blast inside and outside cell may lead to enhanced molecular
motion and a higher energy level and this will finally cause fat cell rupture and thereby achieve the effects of body
building and losing weight.
Theory
laser for fat reduction,use the 650nm soft laser to destroy the deep fat cells,
broke the cell membrane,change the fat to triglyceride,
then leave out the body thanks to metabolism.
The laser heat can Stimulate the subcutaneous dermal tissue collagen
and elastic fibers hyperplasia,make the treated area skin tighten and elasticity

3
Function
1.Replacing and sumouning the surgery of attracting the fat;
2.Tightening the flaccid skin;
3.Promoting the speed of organism metabolism and accelerating the waste and the moisture extraction of the body;
4.Reparing striae gravidarum;
5.Relaxing themuscies,relieving the muscle spasm and alleviating the ache symptomof muscles;
6.Losing weight of the whole body.
Specification:
Functions (13 handles) Technical specifications
6polar RF
1.Out :ACV14V
2.Intensity:0-20
3.Frequency: 5MHZ
4.Working time:0-60min
Ultrasonic Cavitation
slimming
1.Out:ACV32V
2.Intensity:0-20
3.Frequency: 40KHZ
4.Working time:0-60min
tripolar RF for face
1.Out Voltage:ACV32V
2.Intensity:0-20
3.Frequency:5MHZ
4.Working time:0-60min
4polar RF
1.OUT:ACV32V
2.Intensity:0-20
3.Frequency: 5MHZ
4.Working time:0-60min
Vacuum Biopolar RF
1> Vacuum specifications:
1:VOLTAGE:ACV110-220V /50-60HZ
2.Vacuum:0-0.08MPa
3.Frequency:50-60HZ
4.Working time:0-60min
2> RF Specifications 1.OUT:ACV32V
2.Intensity:0-20
3.Frequnecy: 75KHZ
4.Working time:0-60min
8 Lipo Laser Pads (6 big+2
small)
1.Laser wavelength:630-650nm
2. Numbers of treatment probe:8 Pads(6 big+2
small)
3. Numbers of diode laser:50 diodes
4.Time:30-60 minutes
5. Working temperature: 10-40 degree
6. Maximum output power: 400W
7. Single output: 50mW adjustable
8.Laser frequency:1-1000Hz
Packing Size 56*60*40cm
Gross Weight 30Kg
Voltage ACV110-220V /50-60HZ

4
Click on the picture of the corresponding the handle enter the operration interface
Instrument Function and Treatment Principles
1.laser lipolisis handle
The Laser-lipolysis emits low levels of laser energy, which creates a chemical signal in the fat cells,
breaking down the stored triglycerides into free fatty acids and glycerol and releasing them though channels in the cell
membranes. The fatty acids and glycerol are then transported around the body to the tissues that will use them during
metabolism to create energy. This process of fatty acid release is a natural response of the body when the body needs to used
stored energy reserves, thus Laser-lipolysis is not creating any unnatural reaction in the body nor does it affect or damage any
surrounding structures such as skin, blood vessels and peripheral nerves. A period of exercise post treatment will ensure the
complete metabolism and thus elimination from the body of the freed fatty acids.

5
2.Vacuum Bipolar RF handle
Dissolve fat, lymphatic drainage, firm skin and enhance skin elasticity
Body-shaping Equipment adopts the most advanced high-speed turbine negative
pressure technology, and innovative three-dimensional conversion
technology,combining with microcomputer chip controlled patent roller axis,and has an anti-geocentric
attract effect on the skin.
Attracting and outspreading the fibrillar connective tissue of different cortexes , through the rhythmic massage and effectively
break down subcutaneous fat and reduce cellular tissue accumulation of fat , use of the patents to massage deeply roller
different parts of thebody ,bring up fat layer in dermis, curium and subcutaneous ,and release micro-vascular lymphatic vessels
at the same time, promoting metabolism and to make fat cells in a passive movement to fat acids, even within the cells of toxins,
also to be eliminated from lymphatic system in vitro, the detoxitication enhance the fuction of as many as four times. Can be
done manually or any other instruments can not achieve the perfect results. At the same time, skin is more elastic and luster.It
is the "healthy body sculpture management" expert
3.Sextupole RF handle
Being integrated with the most advanced RF technology and radio
frequency, the instrument may directly reach the deep-seated fat body and have the excellence of targeted positioning RF. In
the fast-active state, fat cell tissue may generate friction heat, increase local temperature and remove excess fat and toxin from
the body through sweat gland, enterohepatic circulation and lymph and ultimately achieve the effect of dissolving fat.With
controlled depth technology, inlaid diamond particles of different sizes may rub skin alongits pattern, adjust suction
strength by means of vacuum draw and rub with negative pressure strongforce to directly explode thick fat. Thus, the effects
are very obvious: Enhance blood circulation, accelerate the decomposition of fat, take away wastes, enhance
the effect of removing cellulite, effectively improve the state of areolar tissue, remove stubborn fat and
improve the sufficient absorption condition of diet products.

6
4. 40Khz Ultrasonic handle
Strong sound wave explosion fat head
With collective strong sound wave head, strong sound wave of 40KHZ may be emitted to human
body for impacting fat cells fiercely and causing friction motion between fat cells. This may cause
effective consumption of calories and moisture in fat cells and reduce the size of fat cells. What's more, sound
wave
vibration Vmay cause fierce impact of fat cells to make them be exploded instantaneously, reduce the
amount of fat cells and thereby achieve the effects of removing fat.
5.Quadrupole RF handle --Facial wrinkle elimination, tightening and lifting
A capacitive coupling electrode is used for transmitting radio-wave energy and generating an
electric field for entering into subcutaneous tissue through the skin surface. In the high-frequency
of 450khz, this electric field changes its polarity for 450,000 times per second. To reply to the rapid
change in electrode, directions of electrical particles the skin are also changed. By this time, natural
electric resistance in thesubcutaneous tissue moves and generates heat energy. As thepapillary dermis collagen may
immediately shrink when the temperature is within the range from 60 to 70 Celcius degree, after wrinkle treatment, client may
immediately sense the skin tightening effects as it is being lifted and firmed. When collagen is produced
continuously, thickness and density of the skin papillary dermis may be increased to remove wrinkles, eliminate scars,
restore skin elasticity and gloss and make it be blonde and smooth. While collagen is increased, fresh skin is generated in
the position of operation and wrinkles are removed by large amount of cells. In addition, when cortex
without elasticity or that with thick horny layer in the area with wrinkles is separated, surrounding skin will also be renewed.

7
6.Tripolar facial handle
Stick to enhance rejuvenation: use of positive and negative micro-current activation
energy release skin cells, so that rapid synthesis of fibroblasts Collagen, elastic skin revert to the original compact, the skin
causing t the skin to stimulate the muscle tension is increased, thereby gradually eliminate wrinkles, prevent skin aging,
restoring skin elasticity, facial improvement.
Caution for using RF
1.Beautician should wear insulated gloves during operation.
2.Do not wear any aglet, both for the beautician and the users.
3.The electrode probe must be fully in contact with skin.
4.Do not make the RF electrode stay on any part without moving. Keep it
moving on skin slowly.
5.Skin around eyes and forehead is very thin, the RF output intensity
should be relatively weakened.
6.Do not contact skin with unipolar when using of bipolar, tripolar,
hexpolar RF work head otherwise it will produce pulse discharge, gel
paste etc. Products like gel maybe evaporated into a mist.

8
System Features
Real-time power monitor
Automatic Power calibration
Automatic fiber identification
Immediate Results
Completely Safe
No Starvation Diets
Long last & natural results.
Pain free treatment.
No consumables or disposals.
No need professional operator
No beautician operate in whole process
The newest technology. the simple unmanned operation treatment way.
Non-invasive treatment without anaesthesia or wound, easily remove the hard fat Cell.
Are the results permanent?
LipoLaser is a very effective treatment, however, like any weight loss program a sensible diet and lifestyle is necessary
to maintain condition and efficacy.
Using Guidance
1. Operation schematic drawing of 40K cavitation explode work head
Massage the fat of thigh in circles
2. Operation schematic drawing of sextupole RF laser work head for
body
Waist and abdomen care（25minutes，2-3 days/time）
1Massage to navel as center and gradually expanding the range

9
②Massage chest nest, both sides of former abdomen and below the
navel(into diamond) from inside to outside in circles.
③Concentrated the fat from 4 directions to navel as center.
④Massage from end of pelvis to groin in circles.
⑤Massage from inner rib to outer edge in circles.
⑥Massage back and forth from inner rib to outer edge in straight line
⑦LiftiHip and he lower part of the body care（30minutes，2-3days/time）used the
ΦD50mm probe
Concentrated the fat to groin in circles or straight line.ng from inner rib to outer edge after
massage.

10
3. Operation schematic drawing of laser lipolisis
4. Operation schematic drawing of Tripolar RF work head for face
①Massage the mandible center in circles to produce deep heat.
2Massage lower jaw in lines.
③Massage the triangle zone of both sides of the face in circles.
3Massage from jaw to angulus oris to ear in lines.
④Massage from jaw to angulus oris to ear in lines.
ADVERTION
1. Pregnant women or women during in menses.
2. Epileptic
3. Patients with malignancy.
4. Patient whose wound after operation has not healed up.

11
5. Acute inflammation or epidemical patients.
6. Whom with heart diseases or with heart pacemaker..
7. Whom with kidney (gall-stone ) disease.
8. Who was embedded metal object or silica gel.
9. Who in menses, birth control period, emiction incontinence period, or accepting the belly operation.
10. Whose body always take much inner hot.
11. Who has the genetic hypersensitivity.
Package Listing
Main Machine 1 unit
40K cavitation head 1 unit
Tripolar RF head 1 unit
Quadrupole RF head 1 unit
Sixpolar RF handle 1 unit
Lipo Laser Pads 8 unit (6 large,2 small)
Power supply wire 1 unit
Manual 1 unit
Rated input voltage: AC220V-240V 50HZ /AC110V-120V 60Hz
NOTICE
1. Be sure to use the special ultrasonic gel.
2. Avoid knocking the us head.
3. For avoiding burning the head, during operation, please prepare enough ultrasoinc gel.
4. Don’t stay in one place, avoid treating on the bone.
5. Don’t use disinfectant product to disinfect the us head. We suggest the wet cotton or dry towel
enough.
6. Check the machine power cord if it is connected well.
7. If the machine will not use for a loing time, please switch off it, and power off.
8. Please take off all metal decoration from the operator and patient’s body.
9. If continuous using 1 hour, please pause the machine about 10 minutes, then using again.
10.During the operation, be sure not to accept other treatment.
