ROHRBACK COSASCO SYSTEMS Microcor MWT-3905-MDL User manual

Quick Start Guide and Safety Manual
P/N 702195-QUICKSTART – Rev (-) Quick Start Guide and Safety Manual
P/N 702195-QUICKSTART – Rev (-)
8
PRODUCT CERTIFICATIONS: PLEASE REFER TO MWT-3905 Microcor®Data-Logger, MWT-3905-MDL
NOTES:
Rohrback Cosasco Systems, Inc.

Quick Start Guide and Safety Manual
P/N 702195-QUICKSTART – Rev (-)
2
© 2011 Rohrback Cosasco Systems, Inc. All rights reserved.
Microcor®is a registered trademark of Rohrback Cosasco Systems, Inc.
No part of this manual may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose, without the express written
permission of Rohrback Cosasco Systems, Inc.
Rohrback Cosasco Systems, Inc.
11841 East Smith Avenue,
Santa Fe Springs, CA 90670
USA
Phone: [phone]
Phone: [phone]
Fax: [phone]
Website: www.Cosasco.com
Sales Email: [email protected]
General Email: [email protected]
Quick Start Guide and Safety Manual
P/N 702195-QUICKSTART – Rev (-)
7
STEP 4: VERIFY OPERATION
Operation can be verified with the handheld device, or through the computer software.
Handheld Device
Check the Status of the connection with the handheld device. Refer to the handheld device
documentation for more details.
Computer Software
Check the status of the connection through the software interface. Refer to the computer
software documentation for more details.
Troubleshooting
If the device is not operating properly, refer to the troubleshooting section of the MWT-
3905-MDL Reference Manual.

Quick Start Guide and Safety Manual
P/N 702195-QUICKSTART – Rev (-)
6
Quick Start Guide and Safety Manual
P/N 702195-QUICKSTART – Rev (-)
3
STEP 2: CONNECT THE POWER MODULE STEP 1: MOUNT THE DATA-LOGGER
Power Module (RCS P/N 748400) is intrinsically safe and may be connected/disconnected
in a hazardous location. The Microcor®Data-Logger can be installed on the top, side or bottom of the line according
to the probe installation. Choose the best installation configuration that corresponds to the
location of the probe.
Grounding
*INTRINSICALLY SAFE
BATTERY PACK
A 8 to 14 AWG grounding wire can be attached to the data-logger at the grounding lug.
Connect the ground wire to earth ground per local electrical code.
COVER
Direct Probe Mounting
PROBE
CONNECTOR
*BATTERY CAN ONLY
BE INSTALLED IN
ONE DIRECTION
Top of the Line
1. Attach connector and tighten connector nut to mount the data-logger to the probe
adapter.
MAIN HOUSING
PROBE ASSEMBLY
PROBE ADAPTER
DATA PORT DATA PORT
DAT
A
-LOGGER MOUNTED ON A
COSASCO ACCESS FITTING WITH
RETRIEVABLE PROBE
PROBE ASSEMBLY
COSASCO ACCESS
FITTING WITH PLUG
ASSEMBLY ACCESS VALVE
RETRACTABLE PROBE
ASSEMBLY WITH
SAFETY CLAMP
DAT
A
-LOGGER WITH A
RETRACTABLE PROBE
ASSEMBLY
STEP 3: CONFIGURE THE DATA-LOGGER
To configure the data-logger, connect the handheld device to the data-logger through the
data port. Refer to the MWT-3905-MDL Reference Manual to set Data-Logger
configurations. Alternatively, the computer software may be used to configure the Data-
Logger.
PROBE ASSEMBLY
Configuration for hazardous/non-hazardous locations
(computer software may only be used in a non-hazardous location).

Quick Start Guide and Safety Manual
P/N 702195-QUICKSTART – R
ev (-)
4
Side of the Line
1. Attach connector and tighten connector nut to mount the data-logger to the probe
adapter.
Bottom of the Line
1. Attach connector and tighten connector nut to mount the data-logger to the probe
adapter.
DATA-LOGGER MOUNTED ON THE SIDE OF THE PIPE
PROBE ASSEMBLY
DATA PORT
DATA-LOGGER MOUNTED ON UNDERSIDE OF PIPE
Quick Start Guide and Safety Manual
P/N 702195-QUICKSTART – Rev (-)
5
Optional Remote Mounting
(Bottom of the Line shown)
1. Secure the data-logger to the remote mounting post using appropriate accessories.
2. Attach connector and tighten connector nut of the optional flexible cable to the probe
adapter and attach the other end to the data-logger.
DATA PORT
RCS Mounting Accessories
FLEXIBLE CABLE
(OPTIONAL)
MOUNTING POST
PROBE ASSEMBLY
MOUNTED ON THE
UNDERSIDE OF THE
PIPE
MOUNTING
BRACKET
DATA-LOGGER MOUNTED IN REMOTE LOCATION
2” DIA. MOUNTING POST
(NOT SUPPLIED)
MOUNTING PLATE
LOCK WASHER
AND HEX NUT “U” BOLT
