ROHS Performance Series User manual

User’s Manual
Performance Series Real-Time DVR
▪H.264 Stand-Alone DVR
▪Independent Dual Display
▪Triple Streaming
▪Auto IP Detection
▪iPhone, Android Phone Support

1
Preface
Thank you for being a user of the world's best digital video recorder (DVR), and the leading
Digital Video Surveillance System. For effective usage, please read this manual carefully. For
future reference, please keep this manual handy.
Copyright/Authentication/Trademark/Limited Warranty
Copyright
This manual is produced under copyright law. None of its contents may be copied or duplicated
without prior approval.
Copyright 2009~
Authentication
CE, FCC, KCC
Trademark
Ethernet(TM) is the trademark of Xerox Corporation.
Microsoft(TM), MS-DOS(TM), Windows(TM logo), Windows(TM) and Windows NT(TM) are the
trademarks of Microsoft Corporation, used in the United States and elsewhere.
Limited Warranty
•The manufacturer, importer and agent shall not be responsible for accidental damage (including
injury) and other damage caused by inappropriate use or operation of this product.
•The information in this manual is prepared based on the current specifications for the product.
The manufacturer is currently adding new functions and will continue to upgrade the product
with new technology. All specifications may be changed without notice to individual users.
Cautions
We strongly recommend that users read all safety cautions carefully before operating the product
in order to operate the product appropriately.
Since the indicated cautions contain critical safety information, they must be fully complied with.
The cautions are categorized into Danger, Warning, Caution and Important.
Risk of death or serious injury.
This is the highest priority danger warning.
Risk of serious or lesser degree of injury.
May also cause damage to the product or to property.
Risk of minor injury or damage.
Requirements or limitations regarding operation. Users are
recommended to read the relevant details carefully so as to
operate the product properly and without harm.
The above cautions indicate the degree of damage that may occur due to inappropriate use of
the system.

2
Risk of death or serious injury.
This is the highest priority danger warning.
•RISK OF EXPLOSION IF BATTERY IS REPLACED BY INCORRECT TYPE. DISPOSE OF USED
BATTERY ACCORDING TO THE INSTRCTIONS.
•THIS EQUIPMENT IS FOR INDOOR USE AND ALL WIRINGS AND CABLINGS SHOULD BE
LIMITED TO INSIDE OF THE BUILDING.
•Please connect the power cord only to the type of AC outlet indicated in the manual or product
specification. If connected to other types of power outlet, fire or electric shock may occur.
•Do not expose the product to moisture or dampness. Doing so may result fire or electric shock.
•Do not place heavy objects on top of the power cord. Damage to the power cord may result in
fire or electric shock.
•Do not place containers with liquid or small metal objects on top of the product. Liquid or small
metal objects getting into the unit may lead to fire or electric shock.
•Do not score, bend, twist, pull or heat the power cord. Damage to the power cord may lead to
fire or electric shock.
•Do not remove the top casing of the product. Doing so may result in electric shock. If internal
examination and maintenance are deemed necessary, contact the authorized system vendors
or installers.
•Do not modify the product in any way. Doing so may lead to fire or electric shock.
•In case of lightning, immediately turn off the power switch and remove the power cord from
the power outlet. Failure to do so may result in fire or electric shock.
•Please use only the power cord supplied with the product. Use of other power cords may result
in fire or electric shock.
•In case of smoke, smell or noise, immediately turn off the power switch and remove the power
cord from the power outlet. Continued operation of the product may result in fire or electric
shock. Request a maintenance service from the authorized system vendors or installers.
•If the product is dropped or damaged, turn off the power switch and remove the power cord
from the power outlet. Continued operation of the product may result in fire or electric shock.
Users should request a maintenance service from the authorized system vendors or installers.
•Do not touch the product with wet hands. Doing so may result in electric shock.
Risk of serious or lesser degree of injury.
May also cause damage to the product or to property.
•Do not leave the power cord or other cables in passageways. Passers-by may trip and fall.
•Avoid contact with water or beverages. It may result in damage that cannot be repaired.
•In case of lightning, immediately turn off the power switch and remove the power cord from
the power outlet. The product may otherwise be damaged.
• Excessive current from the product and the camera may result in an electric shock. Connect the
power cord only to an appropriate power source when the product is disconnected from its
own power supply.

3
Risk of minor injury or damage.
• If a foreign substance is stuck to the product, remove it using a soft cloth or tissue. Do not use
chemical agents (thinner, solvent, etc.) to remove the substance.
• Do not operate or store the product in the following places.
- An area that is either too cold or too hot
- An area of high humidity, in front of an air-conditioner, or in places subject to sudden
temperature changes
- An area with excessive dust
- Areas where heat from the product cannot be dissipated through both of the product's
side ventilation openings
• Do not place credit cards/telephone cards/bank account books/tickets and other objects with
magnetic properties near the product.
• Static electricity may cause damage to the internal parts of the product. Please remove static
electricity from your body before touching the rear panel and internal electronic parts of the
product.
• If this product is damaged beyond repair or reaches its maximum service life, dispose of it in
compliance with local laws and regulations regarding to the disposal of lead and plastic waste.
Requirements or limitations regarding operation. Users are
recommended to read the relevant details carefully so as to
operate the product properly without any injury or damage.
• The product may not work properly if the power source is unstable or if an electric shock occurs.
Make sure to use the correctly rated power.
• The product is designed to be safe against electric power failures; however, damage may occur
at a power failure. Current data may be damaged or not be recorded properly. Make sure to
use an Uninterruptible Power Supply (UPS).
• Since the product is designed to record video data on a hard disk, an error in the hard disk or
other miscellaneous errors might prevent the product from recording properly. Periodic
maintenance is required for proper operation of the product.
• The product is designed for users to configure their own interface. However, a user
configuration error could lead to an operation failure. This product should be set up by certified
installers only.
• Since the product is connected - and tightly coupled - to exterior accessories (camera, sensor,
LAN, Hard Disk, etc.), there is a risk of malfunction from external causes. Make sure to have
certified installers do regular maintenance on all devices in the system.
• Use the rack mounting handle provided with the product for installation.
• In this product, 1 Kbyte equals 1,024 bytes, 1 Mbyte equals 1,048,576 bytes and 1 Gbyte
equals 1,073,700,000 bytes.

4
Contents
Preface ............................................................................................... 1
Contents............................................................................................. 4
Chapter 1. Introduction ..................................................................... 7
1. The System ......................................................................................................... 7
2. General Features ................................................................................................ 7
3. Specification ....................................................................................................... 8
Chapter 2. System Installation ........................................................ 10
1. Package Contents............................................................................................. 10
2. Connecting Devices .......................................................................................... 11
2-1. 4 Channel Premium DVR................................................................................... 11
2-2. 8/16 Channel Premium DVR.............................................................................. 14
3. Cautions............................................................................................................ 16
Chapter 3. Using DVR....................................................................... 17
1. Basic Operation ................................................................................................ 17
1-1. Front Panel & IR Remote Controller................................................................... 17
1-2. Turning on the System...................................................................................... 17
1-3. Menu Bar......................................................................................................... 18
1-4. Display Icons ................................................................................................... 18
1-5. User or Admin Login......................................................................................... 20
1-6. The Main Menu ................................................................................................ 21
1-7. Contextual Menu .............................................................................................. 22
2. DVR Configuration............................................................................................ 23
2-1. SYSTEM........................................................................................................... 23
2-1-1. MENU > SYSTEM > Information .............................................................. 23
2-1-2. MENU > SYSTEM > Date & Time............................................................. 24
2-1-3. MENU > SYSTEM > User......................................................................... 24
2-1-4. MENU > SYSTEM > Quick Setup.............................................................. 26
2-1-5. MENU > SYSTEM > System Log .............................................................. 26
2-2. DEVICE............................................................................................................ 27
2-2-1. MENU > DEVICE > Camera..................................................................... 27
2-2-2. MENU > DEVICE > Audio........................................................................ 28
2-2-3. MENU > DEVICE > Alarm........................................................................ 28
2-2-4. MENU > DEVICE > Keyboard .................................................................. 29
2-2-5. MENU > DEVICE > RS232 & RS485 ......................................................... 29
2-3. DISPLAY .......................................................................................................... 30
2-3-1. MENU > DISPLAY > Display .................................................................... 30
2-3-2. MENU > DISPLAY > VGA ........................................................................ 30
2-3-3. MENU > DISPLAY > CVBS....................................................................... 31
2-3-4. MENU > DISPLAY > Digital Signage......................................................... 32
2-4. RECORD .......................................................................................................... 33
2-4-1. MENU > RECORD > Storage ................................................................... 33
2-4-2. MENU > RECORD > Record..................................................................... 33
2-4-3. MENU > RECORD > Utilities .................................................................... 35
2-5. NETWORK ....................................................................................................... 36
2-5-1. MENU > NETWORK > Address ................................................................ 36
2-5-2. MENU > NETWORK > DDNS ................................................................... 37
2-5-3. MENU > NETWORK > Notification ........................................................... 37

5
2-5-4. MENU > NETWORK > Transmission ......................................................... 38
2-6. EVENT............................................................................................................. 39
2-6-1. MENU > EVENT > Sensor ....................................................................... 39
2-6-2. MENU > EVENT > Motion ....................................................................... 40
2-6-3. MENU > EVENT > Video Loss.................................................................. 43
2-6-4. MENU > EVENT > Text-In ....................................................................... 44
2-6-5. MENU > EVENT > System....................................................................... 46
3. Playback ........................................................................................................... 47
3-1. Go to Time....................................................................................................... 49
3-2. Calendar Search ............................................................................................... 49
3-3. Event Search.................................................................................................... 49
3-4. Text-In Search.................................................................................................. 50
3-5. Backup Data Playback ...................................................................................... 51
3-6. Playback Control .............................................................................................. 52
4. Backup.............................................................................................................. 53
4-1. Backup ............................................................................................................ 53
4-2. Instant Backup................................................................................................. 54
4-3. Clip Maker........................................................................................................ 54
Chapter 4. Remote Software ........................................................... 55
1. Using Remote Software.................................................................................... 55
1-1. Starting the Software........................................................................................ 55
1-2. Site Set Up ...................................................................................................... 57
1-3. Favorite Set Up ................................................................................................ 60
1-3. Site List Panel .................................................................................................. 62
1-4. Tool Panel ........................................................................................................ 63
1-4-1. DVR Status............................................................................................. 63
1-4-2. PTZ ....................................................................................................... 63
1-4-3. TEXT-IN ................................................................................................. 64
1-4-4. GPS ....................................................................................................... 64
2. Remote Playback.............................................................................................. 65
2-1. Calendar Search ............................................................................................... 65
2-2. Event Search.................................................................................................... 66
2-3. Text-In Search.................................................................................................. 67
2-4. Saving the recorded data.................................................................................. 68
2-5. Play Backup Data ............................................................................................. 69
2-6. Play Independent HDD Data on PC.................................................................... 70
3. Setup ................................................................................................................ 71
3-1. Remote Software Setup .................................................................................... 71
3-2. Remote DVR Setup........................................................................................... 75
3-3. Remote Upgrade .............................................................................................. 76
4. Callback ............................................................................................................ 77
Appendix A. Remote Access Using I.E. ............................................ 79
Appendix B. How to set DDNS using router..................................... 83
Appendix C. Digital Signage Maker.................................................. 89
1. How to use Digital Signage Maker ........................................................................ 90
Appendix D. PFRM Instructions ....................................................... 92
1. Outline ............................................................................................................... 92
2. How to connect................................................................................................... 93
Appendix E. NEMON Network Archiver Instructions ....................... 95
1. Outline ............................................................................................................... 95

6
2. Feature............................................................................................................... 95
3. How to use Network Archiver ............................................................................... 96
4. Set Up .............................................................................................................. 100
5. Reference ......................................................................................................... 106
COMPLIANCE NOTICE OF FCC: ........................................................................... 107
WEEE (Waste Electrical & Electronic Equipment)............................................... 107
ROHS Compliance............................................................................................... 107

7
Chapter 1. Introduction
1. The System
This product is targeted towards the expanding DVR market. As the market is expanding from
Professional to Consumer and into wider sectors, both price and feature oriented products are
highly on demand across different market sectors. This product is designed to fulfill these various
aspects of different market needs. This highly affordable, reliable, and usable DVR series is to
fulfill basic DVR requirements and the most satisfactions.
2. General Features
• True H.264 Standard Video Compression
• Embedded Linux System to give you the Ultimate Reliability
• Dedicated DB Structure for Stability
• Various Recording Resolution D1/Half D1/CIF
• CMS (Central Monitoring System)
• Easy Setup same like DVR GUI in CMS
• Web Monitoring, Searching and Setup
• Own Media Player for Backup Playback
• Two USB Port for Mouse operation, Multi USB Hub and Backup
• Up to Two SATA HDD and No Limitation of Capacity
• Two- Way Audio
• Multiple DVRs can be operated with One Keyboard Controller
• Text-In & Relay Output Support
• Real Time Recording and Multi Ch. Playback
•Triple Streaming / Digital Zoom
•iPhone, Android Phone Support
• Independent Dual Display
Dual Display allows user to use both VGA and CVBS outputs at the same time with different
display options. Two different individual display modes can be set on each monitor output. Two
different display mode (Live Monitoring on one monitor and Playback on the other) can be
displayed and controlled at the same time. This function will provide high flexibility and efficiency
for monitoring options for the users.
Note : This manual covers the 4-channel, 8-channel and 16-channel DVRs. The DVRs are
identical except for the number of cameras, audio inputs and alarms. The GUI illustrations and
descriptions in this manual are based on the 4 channel model.

8
3. Specification
Model
4 Channel Performance DVR
Video
In
4 BNC (without Loop-out)
Out
1 VGA, 1 CVBS (Dual Display)
Audio
In
4 RCA (Line-In)
Out
1 RCA (Line-Out)
Device
Sensor In
4 TTL (3+Emergency)
Alarm Out
2 Open Collector Output
I/O Interface
RS232, RS485, USB x 2
Display
Speed
Real Time
Resolution
720 x 480 (NTSC)
Split Screen
1, 4, PIP, Digital Zoom
Recording
Compression
H.264 Codec
Speed /
Resolution
120fps@CIF(NTSC)
120fps@Half D1(NTSC)
60fps@D1(NTSC)
Picture Quality
Very High, High, Standard, Low
Mode
Time-lapse, Event, Time & Event, Emergency (Panic)
Playback
Display
1, 4, Digital Zoom
Search Mode
Calendar Search, Event Search, Text-In Search, Go to Time
Playback Mode
Multi Channel Normal & Reverse Play,
RW & FF ( x2, x4, x8, x16, x32), Frame to Frame, Pause
Network
Interface
Ethernet (10/100 Base)
Protocol
TCP/IP, HTTP, DHCP, ADSL(PPPoE), RTP/RTSP
Application
Live, Playback, Setup, Notification (Callback, E-Mail)
Web Browse
Internet Explorer 7 or higher
Mobile Support
iPhone, Android Phone (Real Streaming)
Storage
2 x SATA HDD
Backup
External HDD(USB), External USB Memory
Control
Front Panel Button, USB Mouse port,
IR Remote Controller, Joystick Controller port
OSD
Graphic User Interface (Multilingual)
Approval
FCC, CE, KCC
ROHS
ROHS Compliance
Power Consumption
DC12V, 3.33A (40W)
Operating Temperature
41°F~104°F
Operating Humidity
0%~80% / non-condensing
Dimension
13.39(W)x2.64(H)x10.43(D)inch
Weight
4.4lbs (without HDD)

9
Model
8 Channel Performance DVR
16 Channel Performance DVR
Video
In
8 BNC (Loop-out option*)
16 BNC (Loop-out option*)
Out
1 VGA, 1 CVBS (Dual Display)
Audio
In
8 RCA (Line in) –Option*
Out
1 RCA (Line Out)
Device
Sensor In
4 TTL (3+Emergency)
Alarm Out
2 Open Collector Output
I/O Interface
RS232, RS485, USB x 2
Display
Speed
Real Time
Resolution
720 x 480 (NTSC)
Split Screen
1,4,6,9,PIP,Digital Zoom
1,4,6,8,9,13,16,PIP,
Digital Zoom
Recording
Compression
H.264 Codec
Speed /
Resolution
240fps@CIF(NTSC)
240fps@Half D1(NTSC)
120fps@D1(NTSC)
480fps@CIF(NTSC)
240fps@Half D1(NTSC)
120fps@D1(NTSC)
Picture Quality
Very High, High, Standard, Low
Mode
Time-lapse, Event, Time & Event, Emergency (Panic)
Playback
Display
1, 4, 6, 9, Digital Zoom
1,4,6,8,9,13,16,Digital Zoom
Search Mode
Calendar Search, Event Search, Text-In Search, Go to Time
Playback Mode
Multi Channel Normal & Reverse Play,
RW & FF ( x2, x4, x8, x16, x32), Frame to Frame, Pause
Network
Interface
Ethernet (10/100 Base)
Protocol
TCP/IP, HTTP, DHCP, ADSL(PPPoE), RTP/RTSP
Application
Live, Playback, Setup, Notification (Callback, E-Mail)
Web Browse
Internet Explorer 7 or higher
Mobile Support
iPhone, Android Phone (Real Streaming)
Storage
2 x SATA HDD
Backup
External HDD(USB), External USB Memory
Control
Front Panel Button, USB Mouse port,
IR Remote Controller, Joystick Controller port
OSD
Graphic User Interface (Multilingual)
Approval
FCC, CE, KCC
ROHS
ROHS Compliance
Power Consumption
DC12V, 3.33 (40W)
Operating Temperature
41°F~104°F
Operating Humidity
0%~80% / non-condensing
Dimension
13.39(W)x2.64(H)x10.43(D)inch
Weight
4.4lb (without HDD)
* Requires optional accessory connector(s). Please ask about this to your supplier.
