Roland MV-8000 User manual

This manual explains how to use an MV-8000 in which “System Program Version 2.00”
(included with the MV8-VGA) is installed.
The main contents of this manual are:
• Items shown in the external display
• Operations using the mouse
• New functionality and changes added to the MV-8000 owner's manual
Please read this manual in conjunction with the original MV-8000 owner's manual.
● About the Symbols and icons in this manual
• Text in square brackets [ ] refers to buttons on the panel of the MV-8000.
Buttons indicated as [F1 (Sample)] refer to the F1 (function 1) button when the F1 function
shown in the LCD is “Sample.”
• Where a range of values is shown, the default value is printed in bold type.
For example, an indication of
Range: 60 , 67, 72, 75 (Hz)
means that 60 Hz is the default value.
Indicates information that you should be aware of when using the MV-8000.
Indicates a convenient operation or useful music production technique.
Indicates supplementary information about an operation.
Indicates a reference page.
Indicates an explanation of a term.
Indicates operation from the MV-8000’s top panel.
Indicates operation from the Mouse and the external VGA display.
© 2004 Roland Corporation
All rights reserved. No part of this publication may be reproduced in any form without the
written permission of ROLAND CORPORATION.
Roland Web Site http://www.roland.com/
• Before using this unit, carefully read the sections entitled: “IMPORTANT SAFETY
INSTRUCTIONS” (Owner’s Manual p. 2), “USING THE UNIT SAFELY” (Owner’s Manual p. 3),
and “IMPORTANT NOTES” (Owner’s Manual p. 5). These sections provide important information
concerning the proper operation of the unit. Additionally, in order to feel assured that you have
gained a good grasp of every feature provided by your new unit, Quick Start and Owner’s Manual
should be read in its entirety. The manual should be saved and kept on hand as a convenient
reference.
• The explanations in this manual include illustrations that depict what should typically
be shown by the display. Note, however, that your unit may incorporate a newer,
enhanced version of the system (e.g., includes newer sounds), so what you actually see
in the display may not always match what appears in the manual.
Version 2.0
Owner’s Manual
MV-8000v200_e.book 1 ページ ２００５年５月４日 水曜日 午後４時２０分

2
Contents
Using an external display and mouse to operate the MV-8000 ..........4
The newly added VGA/MOUSE screen................................................................................................. 4
Using the two operating modes, the display, and the mouse.............................................................. 5
Switching between the two operating modes............................................................................. 5
Mouse........................................................................................................................................................... 6
About the mouse ............................................................................................................................. 6
Basic operation ................................................................................................................................ 6
Mouse operations............................................................................................................................ 8
Screen Section............................................................................................................................................ 10
SEQUENCE screen........................................................................................................................ 10
Operation section...................................................................................................................................... 22
Quick Tour ..................................................................................................................................... 22
Using the mouse to edit sequence data...................................................................................... 25
Using the mouse to edit a MIDI track (PIANO ROLL EDIT screen)..................................... 26
Step Recording............................................................................................................................... 28
Changes in Sampling and Importing ..................................................29
Sampling .................................................................................................................................................... 29
Importing................................................................................................................................................... 32
Importing the WAV or AIFF files ............................................................................................... 32
Importing the Standard MIDI Files ............................................................................................ 37
Importing from various CD-ROM libraries .............................................................................. 38
Check multiple samples you have captured............................................................................. 40
Quick Assign ............................................................................................................................................. 41
Assigning a sampled sound a patch (partial) ........................................................................... 41
Assigning a sampled sound an audio phrase ........................................................................... 41
Assigning a patch (partial) by chopping a sample................................................................... 42
Assign multiple samples as partials........................................................................................... 43
Assign multiple samples as audio phrases ............................................................................... 44
Changes in Sample Edit .......................................................................45
Truncating ................................................................................................................................................. 45
Truncating a sample used by a partial’s SMT........................................................................... 45
Truncating a sample used by an audio phrase......................................................................... 46
Added the AUDIO PHRASE SAMPLE EDIT screen .......................................................................... 49
Deleting the sample along with the partial (Delete Partial)............................................................... 50
Deleting the sample along with the audio phrase (Delete Audio Phrase)....................................... 51
Deleting the sample along with the patch (Delete Patch) .................................................................. 52
Assigning a partial to pads in a pitched scale (Set Chromatic) ......................................................... 53
Changes in recording and editing sequences ...................................55
Selecting a region quickly (Quick Region)............................................................................................ 55
The selected region in the SEQUENCE EDIT screen............................................................... 55
the selected region in the PIANO ROLL EDIT screen............................................................. 55
Initiate recording when a note message is received............................................................................ 56
Step-recording for the length of an audio phrase................................................................................56
Combining multiple MIDI tracks into one (Merge Tracks)................................................................ 57
Extracting specific note events (Split Notes) ........................................................................................ 58
Inserting blank measures at the specified time (Insert Measure)...................................................... 60
Using shortcuts to execute editing commands .................................................................................... 61
Using shortcuts to switch the step time ................................................................................................ 61
Changes in Mixdown and Mastering...................................................62
Mixdown.................................................................................................................................................... 62
Mastering................................................................................................................................................... 63
MV-8000v200_e.book 2 ページ ２００５年５月４日 水曜日 午後４時２０分

3
Using the MV-8000 with external devices...........................................65
Using the MV-8000 in Multitimbre Sampler Mode............................................................................. 65
Playing the MV-8000 from an externally-connected sequencer............................................. 65
Recording your velocity pad performance on an externally-connected sequencer ....................... 66
Synchronized operation with external devices (Slave)....................................................................... 69
Additional parameters in the SYNC screen .............................................................................. 69
Added the R-BUS screen.............................................................................................................. 70
Receive and synchronize to MIDI Clock ................................................................................... 71
Receive and synchronize to MTC ............................................................................................... 72
Use the MIDI IN connector of the DIF-AT24 .......................................................................................73
Changes in the others ..........................................................................74
Directly selecting a pad bank ([PAD BANKS]+Pad 1–16).................................................................. 74
Using the velocity pads to switch Track Mute and Solo .................................................................... 74
Starting a new song with your favorite settings (User Track Template) ......................................... 75
Saving a User Track Template..................................................................................................... 75
Using a user track template to create a song............................................................................. 76
Saving a song in SMF format (Save As SMF) .......................................................................................76
Note regarding saving to SMF ....................................................................................................77
Viewing the PATCH LIBRARY popup in the INSTRUMENTS screen............................................ 77
Copy or move entire folders ................................................................................................................... 77
Changes in MIDI Filter parameter......................................................................................................... 78
Changes in GLOBAL screen ................................................................................................................... 78
Prevent the hard disk from being formatted (HD Format Protect parameter).................... 78
Adjusting the volume of the entire sampler ............................................................................. 78
Memo......................................................................................................79
MV-8000v200_e.book 3 ページ ２００５年５月４日 水曜日 午後４時２０分

4
Using an external display and mouse to
operate the MV-8000
If the MV8-VGA is installed in the MV-8000, you can connect an external display
(VGA) and the included mouse, and perform operations from the external display.
Even when you are using an external display to operate the MV-8000, you can also
view information on the MV-8000’s built-in LCD screen.
This screen lets you make settings for the external display and mouse if the MV8-VGA
(sold separately) is installed.
fig.vga-mouse-screen
1. Color Theme
You can select the combination of colors used in the external display. Select your
favorite color scheme from the following choices.
2. Refresh Rate
Sets the rate at which the monitor re-draws it image.
Range: 60 , 67, 72, 75 (Hz)
3. H Position and V Position
Adjust the H Position (Horizontal Position) and the V Position (Vertical Position)
parameters if you’d like to shift the image on your VGA monitor.
4. Pointer Speed
Sets how fast the mouse’s cursor moves.
Range: 1 (Slow)– 5 –9 (Quick)
The newly added VGA/MOUSE screen
Range
Default
Chocolate Magenta
Mint Slate Moss Green
Purple Orchid Copper
Grass Tan
Violet Gray
Refresh Rate H Position V Position
60 -3–
0 –4 -14– 0 –14
67 -5– 0 –5 -21– 0 –22
72 -5– 0 –5 -18– 0 –19
75 -5– 0 –5 -8– 0 –9
In order to operate the MV-
8000 using an external display,
the MV-8000’s system program
version must be 2.00 or higher.
If you select a value the
monitor doesn’t support,
image quality may be poor,
and damage to the monitor
may result.
Depending on the H Position
or V Position settings, the
image shown in the external
display may be distorted. If the
external display you're using
has settings for adjusting the
image position, make
adjustments first on the
external display.
MV-8000v200_e.book 4 ページ ２００５年５月４日 水曜日 午後４時２０分

5
Using an external display and mouse to operate the MV-8000
Here’s how to tell whether the current screen for operations is the external display or
the built-in LCD.
● When the external display shows the “MV-8000 logo”
In this state you use the MV-8000’s panel and its own built-in LCD to perform
operations. The external display and mouse cannot be used for operations.
● When the MV-8000’s LCD indicates “VGA MODE”
A 640 x 480 pixel color screen will appear on the external display, and you can operate
the MV-8000 from the external display (VGA mode). You can use the front panel to
perform the same operations as before, and also operate the MV-8000 using the
included mouse. The MV-8000’s LCD will indicate the status of the tracks and the
samples assigned to the velocity pads.
Here’s how to select either the external display or the built-in LCD as the screen in
which you will operate the MV-8000.
1
Press
The SYSTEM MENU screen will appear.
2
With the cursor located in the lower row of icons, press (VGA/Mouse).
Alternatively, you can select the VGA/MOUSE icon and press .
The VGA/MOUSE screen will appear.
3
Press (VGA-LCD).
1
From the menu bar, click “SYSTEM” ➔ “VGA/Mouse.”
The VGA/MOUSE screen will appear.
2
Click .
You will be able to operate in the built-in LCD.
Using the two operating modes, the display, and the
mouse
Switching between the two operating modes
You can press the [SHIFT] +
[EXIT] buttons to switch the
operating mode from the
external display to the internal
LCD. You can’t use this
method to switch from the
internal LCD to the external
display.
MV-8000v200_e.book 5 ページ ２００５年５月４日 水曜日 午後４時２０分

6
Using an external display and mouse to operate the MV-8000
You can use the included mouse to operate the on-screen knobs and buttons, or the
sequence data in the play list.
When you move the mouse, the mouse pointer (the arrow symbol) will move in the
screen. By placing the mouse pointer on a button or knob and pressing (clicking) the
mouse button you can perform various operations depending on the selected item.
The included mouse is a wheel mouse.
Basic mouse operations are:
• Use the mouse pointer to indicate a button or knob in the screen (“point”)
• Press the mouse button (“click”)
• Turn the mouse wheel
● Point
Move the tip of the mouse pointer to a button or knob shown in the
screen. This is called “pointing” at the button or knob.
● Click
Point to a button or knob in the screen; then press and
release the mouse button once.
In some cases you will be specifically told to “right-click,”
which means to click using the right mouse button.
● Double-click
Point to an on-screen button or knob, and rapidly press
the mouse button twice.
● Operating the wheel
Turn the wheel toward or away from yourself.
After clicking on a numerical parameter, you can turn the wheel to
raise or lower the value. The wheel can be used only for numerical
parameters; it cannot be used to operate buttons or knobs.
Mouse
About the mouse
Basic operation
In order to use the mouse, the
MV-8000’s system program
must be version 2.00 or higher.
Mouse operations can be used
only in the external display.
The included mouse is an
optical mouse. It may not
function correctly on some
surfaces, so be sure to use it on
the included mouse pad.
Wheel
Right-button
Left-button
The wheel can also be clicked
j
ust like the left or right
b
uttons, but the MV-8000 does
not use this action.
MV-8000v200_e.book 6 ページ ２００５年５月４日 水曜日 午後４時２０分

7
Using an external display and mouse to operate the MV-8000
● Drag
Move the mouse while holding down the
mouse button.
For example by dragging an event shown
in a play list, you can change the starting
time or the track of that event. By dragging
a knob you can change its setting.
● Drag&Drop
Drag, and then release the mouse button at
the desired location.
The sequence data or knob you dragged
will move to the position at which you
released the button.
2
1
Press
Move while holding down
2
3
1
Press
Release your finger
from the button
Move while holding down
MV-8000v200_e.book 7 ページ ２００５年５月４日 水曜日 午後４時２０分

8
Using an external display and mouse to operate the MV-8000
Here’s how to operate the buttons and knobs shown in the screen.
● Menu Bar
Click an item in the menu bar, and a list showing the contents of that item will appear.
In the list, click the desired item.
● Buttons
You can click on “buttons” shown in the screen to execute various operations or to
select parameters.
● Sliders
Sliders are used to continuously vary a value. Point to the knob of a slider, and drag it
up or down.
● Knobs
Knobs are used to continuously vary a value. Point to a knob, and drag it horizontally.
● Numerical boxes
Numerical boxes are used to make detailed changes in the value of a parameter. Click
a numerical value to highlight it, and turn the wheel forward or backward to change
the value.
Mouse operations
MV-8000v200_e.book 8 ページ ２００５年５月４日 水曜日 午後４時２０分

9
Using an external display and mouse to operate the MV-8000
● Name editor
This is a popup window used to input names in various screens. Input the desired
name by using the mouse to click the buttons.
Explanation
Name This is the area in which you will input the name.
Keyboard Use these buttons to select the characters you want to input.
Insert
button
This button switches between Insert input mode and Overwrite input mode.
Insert input mode is selected when the button is in the inward position; the
characters you select will be input at the cursor position, and any subsequent
characters will be moved toward the right. In Overwrite input mode, any
previously-input characters will be overwritten by the characters you input.
CapitalLock
button
This button switches between uppercase (Caps) and lowercase characters.
Uppercase (Caps) input is selected when the button is in the inward position;
only uppercase characters will be input from the keyboard.
Shift button
This button temporarily switches the type of characters that will be input
from the keyboard. Clicking the keyboard when the Shift button is in the
inward position will defeat the Shift button.
Cursor
button
These buttons change the position at which characters from the keyboard will
be input.
Name
Insert button
Capital Lock button
Cursor button
Shift button
Keyboard
MV-8000v200_e.book 9 ページ ２００５年５月４日 水曜日 午後４時２０分

10
Screen Section
● Transport Block
fig.transport-block1
Screen Section
SEQUENCE screen
Explanation
Step Time This indicates the range of movement that will occur when you press the step buttons (Rewind/For-
ward). You can click this area to see a list of the available movement ranges.
Marker button The MARKER popup will appear.
Locator button The LOCATOR popup will appear.
Step button
(Rewind/Forward) These buttons return or advance the current time location by the range specified in Step Time.
Marker button
(Previous/Next) These buttons move the current time location to the next or previous recorded marker.
Preview button
(To/From)
These buttons audition a several-second portion (specified by Preview Length) before or after the cur-
rent time location.
Event button
(Previous/Next) These buttons move the current time location to the next or previous recorded event.
Top button Return to the start of the current song (0001-01-000).
Meas button
(Rewind/Forward) These buttons move the current time location forward or backward in one-measure steps.
Stop button To stop the sequencer.
Play button To play the sequencer.
REC button The RECORD PARAMETER popup will appear. Here you can make preparations for recording data
into the sequencer.
Step REC button The STEP REC popup will appear. Starts the step recording.
Menu Bar
Transport Block
Function Button Block
Launcher Block
Playlist Area
Inspector Area
Tools Area Ruler Area
Tracklist Area
MV-8000v200_e.book 10 ページ ２００５年５月４日 水曜日 午後４時２０分

11
fig.transport-block2
fig.transport-block3
● Launcher Block
fig.launcher-block1
REC Parameter
button The RECORD PARAMETER popup will appear.
Song Position Bar
The entire length of this bar corresponds to the length of the current song, and the scrollbar handle
indicates the current time location. You can move the current time location by dragging or clicking the
scrollbar handle.
Explanation
Mixdown Mode
button This switches the mixdown mode. If you record while this is on, the current song will be mixed down.
Sync Mode button Here you can switch the synchronization mode.
Current Time
Location
This area indicates the current time location in “measures - beats - ticks.” You can click a numerical
field and change the time.
Current Time
Location This area indicates the current time location in “hours : minutes : seconds . frames.”
Explanation
BPM (Tempo) This indicates the tempo at the current time location. If the tempo track is off, you can click this value
and change the tempo.
Tempo Track Switch You can click this area to switch the Tempo Track On ( )/Off ( ).
Time Signature Display the time signature of the current song.
Auto Punch button This button switch the Auto Punch function On/Off.
Auto Punch
In/Out
This area indicates the auto punch-in time (at left) and auto punch-out time (at right). You can click a
numerical field and change the time.
Loop button This button switch the Loop function On/Off.
Loop Start/End This area indicates the loop-start time (at left) and loop-end time (at right). You can click a numerical
field and change the time.
Metronome Mode Specifies when the metronome signal will be output.
Loop Quick Set
button
This button makes the playback loop from the beginning of the current beat for the length specified
by the Loop Quick Set Length setting.
Loop Quick Set
Length
This indicates the loop length that will be used when you press the Loop Quick Set button. You can
click this to see a list of the available loop lengths.
Explanation
Sampling button The SAMPLING popup will appear. Here you can make settings and execute sampling.
Import button The IMPORT popup will appear. Here you can import data from the hard disk or a CD.
Instruments button The INSTRUMENTS popup will appear. Here you can edit or make settings for instruments.
Audio Phrases
button The AUDIO PHRASES popup will appear. Here you can edit or make settings for audio phrases.
Quick Edit button Here you can edit the audio phrases or the partials of the current track.
Pad Banks button The PAD BANKS popup will appear. Here you can switch the pad bank of the velocity pads.
Explanation
MV-8000v200_e.book 11 ページ ２００５年５月４日 水曜日 午後４時２０分

12
fig.launcher-block2
● Playlist Block
Inspector Area (When the current track is MIDI track)
Pad Bank
Number/Name
Display the current pad bank and pad name. If the tempo track is off, you can click this value and
change the tempo.
Explanation
Effects button The EFFECTS popup will appear. Here you can make settings for the built-in MFX, Delay/Chorus and
Reverb.
Effect Section
Selector This selects the effect module (MFX, delay/chorus, reverb) that will be controlled by the C1–C3 knobs.
Mixer button The MIXER popup will appear. Here you can adjust the volume and panning of the audio tracks and
instrument parts.
Mixer Section
Selector
This displays mixer sections which can be controlled by the eight sliders on the MV-8000’s panel. A
list of the available mixer sections will appear when you click this.
The available mixer sections are:
• Audio Track 1–8
• Instrument Part 1–8
• Instrument Part 9–16
• AUX1–4/Effect Return/Audio Phrase/Input
• Assignable sliders
Region In/Out
button
This button specifies the current time location as region-in (beginning of the selected region) or region-
out (end of the selected region).
Region In/Out point This area indicates the region-in time (at left) and region-out time (at right). You can click a numerical
field and change the time.
Explanation
Current Track
Number/Name Display the current track number and current track name.
Output Assign
(Instrument)
This indicates the instrument part played by the current track. If you click this area, show the list of
the instrument part.
Output Assign
(MIDI) Specifies the MIDI connector and channel used for MIDI output of the data from the MIDI track.
Quantize Type Display the setting of quantization of the current track.
Strength Display the strength of quantization. You can click the numerical value to edit the strength. (This is
displayed when the Quantize Type is set to Grid or Shuffle.)
Resolution Display the quantization timing. You can click the numerical value to edit the resolution. (This is
displayed when the Quantize Type is set to Grid or Shuffle.)
Rate This indicates the amount of “swing” that will be applied when the Quantize Type is set to Shuffle.
You can click the numerical value to edit the rate.
Template This indicates the template name that will be applied when the Quantize Type is set to Template. You
can click the template name to show the template list and select the other template.
Velocity This indicates the strength of the velocity correction that will be applied when the Quantize Type is
set to Template. You can click the numerical value to edit the velocity.
Explanation
Quantize Type=
Off
Grid
Shuffle
Template
MV-8000v200_e.book 12 ページ ２００５年５月４日 水曜日 午後４時２０分

13
Inspector Area (When the current track is Audio Track)
Tools Area
Ruler Area
fig.ruler-
Explanation
Current Track Num-
ber/Name Display the current track number and current track name.
Output Assign Specifies the output connector from which the audio recorded on the track will be output.
Explanation
View Filter
This indicates the type of events that will be displayed in the SEQUENCE screen or in the EVENT LIST
popup window. By clicking an icon you can specify whether that type of event will be displayed
(white) or will be hidden (black).
Expand Track List
Area button This expands the track list area display.
Piano Roll button The PIANO ROLL EDIT popup will appear. This is available when the current track is a MIDI track.
Event List button The EVENT LIST popup will appear. This is available when the current track is a MIDI track.
Snap button
If this is on, clicking in the play list or ruler will automatically select a suitable location (such as the
beginning of a measure). Since the interval of this division is specified by the Grid Resolution setting,
you can use this feature to “snap” your selection to precise units of beats or measures.
Grid Resolution
This indicates the unit (the level of detail) that can be selected with the mouse pointer when using the
Snap function. By clicking the numerical value you can specify whether that list of resolution will be
displayed.
Arrow button
This switches the mouse pointer to Arrow mode. Use this when you want to select a range of events
in the play list. All events included in the mouse selection will be selected even if they extend beyond
the range.
Range button This switches the mouse pointer to Range mode. Use this when you want to select a range of events
in the play list. The range selected by the mouse will be the actual selected range.
Eraser button This switches the mouse pointer to Eraser mode. In Eraser mode, you can click an event in the play list
to delete it.
Undo/Redo
button
You can click this button to cancel (UNDO) the results of an editing command in sequencer section. If
you then click the button again, you can cancel the UNDO (i.e., REDO).
Explanation
Tempo Change
Event This indicates the location of a change in tempo and time signature.
Current Time The current time is indicated by a red line.
Region of Auto
Punch In/Out This indicates the region (red) in which Record mode will be enabled automatically.
Locator These are locators placed in the song. You can place up to 10 locators in a song. The desired time
location can be stored in any Locator number.
Marker These are markers placed in the song. You can place up to 99 markers in a song. Markers are
automatically numbered in ascending order according to their time location.
Selected Region This indicates the region of time you selected by dragging the mouse, etc.
Region of Loop The enclosed region (blue) will loop.
MV-8000v200_e.book 13 ページ ２００５年５月４日 水曜日 午後４時２０分

14
Right-click on the Ruler Area
fig.ruler-area2
Tracklist Area
Explanation
Track Number Display the Track number. You can click here to make that number the current track.
Track Type Icon This indicates the type of track. You can click here to select or de-select that track.
Track Name Display the name of the track. When you double-click here, the EDIT TRACK NAME popup window
will appear, allowing you to edit the name of the track.
Track Move Up/
Down button You can click these to move the current track upward or downward (i.e., change their order).
All Track Select but-
ton Click this to select or de-select all tracks.
Output Assign
(Instrument) This indicates the instrument part played by the current track.
Output Assign
(MIDI) Specifies the MIDI connector and channel used for MIDI output of the data from the MIDI track.
Output Assign (Au-
dio) Specifies the output connector from which the audio recorded on the track will be output.
Mute button Click this to turn Mute on (yellow) or off.
Solo button Click this to turn Solo on (light blue) or off.
Record button Click this to switch the current track.
All Track Mute Off
button Click this to defeat Mute for all tracks.
All Track Solo Off
button Click this to defeat Solo for all tracks.
Track Parameter
button Click this to display the TRACK PARAMETER popup window for the corresponding track.
1 Locator
9 Set Selected Region to Auto Punch
2 Tempo Track
3 Add Marker
4 Add Tempo Change Event...
5 Clear Marker
6 Clear Locator
7 Clear Tempo Change Event
8 Set Selected Region to Loop
The LOCATOR popup will appear.
You can specify a locator number and register a time locationi for it.
The TEMPO TRACK popup will appear.
The tempo track lets you specify the tempo and time signature.
This adds a marker at the current time location.
The ADD TEMPO CHANGE EVENT popup will appear.
Here you can input or edit tempo events.
This sets the selected region as the Loop region.
Erase Marker in place which carried out the right-click.
Erase Locator in place which carried out the right-click.
Erase Tempo Change Event in place which carried out the right-click.
This sets the selected region as the Auto Punch region.
MV-8000v200_e.book 14 ページ ２００５年５月４日 水曜日 午後４時２０分

15
Right-click on the Tracklist Area
fig.tracklist-area2
Playlist Area
Explanation
MIDI Event
These boxes indicate MIDI events. They are color-coded according to the assigned instrument part.
When you double-click a MIDI event, the PIANO ROLL EDIT popup window will appear.
When you holding down [JUMP] and double-click a MIDI event, the EVENT LIST popup will
appear.
Audio Event These boxes indicate audio events. When you double-click an audio event, the AUDIO EVENT PA-
RAMETER popup window will appear.
Zoom button These buttons expand (+) or shrink (-) the time axis of the playlist.
Scroll button/bar
Here you can move the displayed portion of the play list along the time axis. Click to move to-
ward the beginning of the song, or click to move toward the end of the song. You can drag the
scroll bar to move the current time location accordingly.
The ADD MIDI TRACKS popup will appear. Add one or
more MIDI tracks for recording data in your current song.
The ADD AUDIO TRACKS popup will appear.
Add one or more Audio tracks for recording data in your current song.
The DELETE TRACKS popup will appear. Here you can delete the tracks.
Deletes the all events of current track.
A confirmation message will appear before the data is erased.
The EDIT TRACK NAME popup will appear.
You can change the name of the track.
The MERGE TRACKS popup will appear.
Here you can combine multiple MIDI tracks into a single track.
Defeat Mute for all tracks.
Select or de-select all tracks.
Defeat Solo for all tracks.
1 Add MIDI Tracks...
2 Add Audio Tracks...
3 Delete Tracks...
4 Merge Tracks...
6 Erase All Events
7 Track Name...
The TRACK PARAMETER popup will appear.
8 Track Parameter
9 Select All Tracks
10 All Mute Off
11 All Solo Off
5 Insert Measure...
The INSERT MEASURE popup will appear.
Here you can insert blank measures at the specified measure location.
MV-8000v200_e.book 15 ページ ２００５年５月４日 水曜日 午後４時２０分

16
Right-click on the Playlist Area
● Function Block
Explanation
Function buttons The [F1]–[F5] buttons correspond to functions displayed at the bottom of the LCD.
Wave Memory
meter
If it is in the state which can do the direct recording, the remaining recordable time and the remaining
amount of memory are displayed.
Sequence Memory
meter
In the state which can do the sequence recording, green meter is displayed. This indicates the amount
of sequence data that has been recorded. The numerical value shows the proportion of free area avail-
able for recording events into the sequencer.
1 Move...
2 Copy&Paste...
3 Copy&Insert...
4 Erase
5 Cut
6 Quantize...
7 Change Velocity...
8 Change Duration...
9 Shift Timing...
10 Data Thin...
11 Transpose...
12 Split notes...
15 Copy As Audio Phrase...
13 Copy As MIDI Clip...
14 Paste MIDI Clip...
16 Audio Event Parameter
The MOVE popup will appear.
Moves the data of the selected region to the specified location.
The COPY&PASTE popup will appear.
Copies the data of the selected region to the specified location.
The COPY&INSERT popup will appear.
Inserts the data of the selected region to the specified location.
Deletes the data. The deleted region will be blank.
Deletes the data. Subsequent data will be moved forward.
The QUANTIZE popup will appear.
Adjust the timing of MIDI note events in the way you specify.
The CHANGE VELOCITY popup will appear.
Changes the velocity of MIDI note events.
The CHANGE DURATION popup will appear.
Changes the duration (note length) of MIDI note events.
The SHIFT TIMING popup will appear. Moves the events of the selected
region forward or backward in units of one tick (1/480th of a quarter note).
The DATA THIN popup will appear.
Thins-out events of the selected region to reduce the amount of data.
The TRANSPOSE popup will appear.
Transposes the pitch of note events in the selected region, in units of a semitone.
The SPLIT NOTE popup will appear.
This lets you extract only specific note events from a track,
and move them to a specified other track.
The COPY AS AUDIO PHRASE popup will appear.
Here you can copy the selected data to the velocity pads.
The COPY AS MIDI CLIP popup will appear.
Add the specified data to the MIDI clip library.
The PASTE MIDI CLIP popup will appear.
Paste the MIDI clip from the MIDI clip library into the current song.
The COPY AS MIDI CLIP popup will appear.
Adjust the parameters of the event of an selected audio track.
MV-8000v200_e.book 16 ページ ２００５年５月４日 水曜日 午後４時２０分

17
● Menu Bar
PROJECT
Manage the project and make project setting.
SONG
Manage the song and make various settings for the current song.
1 Rename Project...
2 Set Project Protection...
3 Load Project...
9 Backup To CD...
10 Recover From CD...
11 Shutdown
4 Save Project
5 Save As New Project...
6 Create New Project...
7 Delete Project...
8 Optimize Project
The EDIT PROJECT NAME popup will appear. Assign a name to the project.
The SET PROJECT PROTECTION popup will appear.
Protect a project saved on disk from being overwritten or deleted.
The LOAD PROJECT popup will appear. Load a project, making it the current project.
"Save Current Project?" message will appear. Save the current project.
The SAVE AS NEW PROJECT popup will appear.
Here you can save the current project under a different name, and then make it the current project.
The CREATE NEW PROJECT popup will appear. Create a new project.
The DELETE PROJECT popup will appear. Delete an unwanted project.
"Optimize Project?" message will appear.
This will reorganize the samples used by the current project
in order to make the most efficient use of memory.
The BACKUP PROJECT TO CD popup will appear.
Backup the current project to a CD-R/RW disc.
The RECOVER PROJECT FROM CD popup will appear.
Recover (restore) a backed-up project from CD into the MV-8000 with the name you specify.
"SHUTDOWN Are you sure?" message will appear.
You must execute this operation before powering-off the MV-8000.
2 Song Parameter
1 Song Name...
3 Sync
4 Create New Song...
5 Select Song...
6 Delete Song...
7 Copy As New Song...
8 Save As User Template
9 Save As SMF...
The SONG PARAMETER popup will appear. Make settings for the current song.
The EDIT SONG NAME popup will appear. You can change the name of the current song.
The SYNC popup will appear. Make synchronization settings.
The CREATE NEW SONG popup will appear. Create a new song within the current project.
The SELECT SONG popup will appear. Change the current song by recalling the desired song.
The DELETE SONG popup will appear. Delete an unwanted song.
The COPY AS NEW SONG popup will appear.
Copy the current song, and switch the current song to be the resulting copy.
Save the current song in SMF (Standard MIDI File) format 1.
Save a track structure or loop settings to a song template.
MV-8000v200_e.book 17 ページ ２００５年５月４日 水曜日 午後４時２０分

18
SEQUENCE
Perform sequencer-related operations.
1 Tempo Track
2 Add MIDI Track...
3 Add Audio Track...
4 Delete Tracks...
5 Merge Tracks...
6 Current Track Edit >
1 Name...
2 Erase All Events
7 Insert Measure...
8 Marker
9 View Filter
10 Step Time
11 Metronome
12 Loop
13 MIDI Clip Library
The TEMPO TRACK popup will appear.
The tempo track lets you specify the tempo and time signature.
The ADD MIDI TRACKS popup will appear.
Add one or more MIDI tracks for recording data in your current song.
The ADD AUDIO TRACKS popup will appear.
Add one or more Audio tracks for recording data in your current song.
The DELETE TRACKS popup will appear. Here you can delete the tracks.
Deletes the all events of current track. A confirmation message will appear before the data is erased.
The MERGE TRACKS popup will appear. Here you can combine multiple MIDI tracks into a single track.
The INSERT MEASURE popup will appear.
Here you can insert blank measures at the specified measure location.
The EDIT TRACK NAME popup will appear. Here you can change the name of the track.
The MARKER popup will appear. Here you can add or delete markers.
The VIEW FILTER popup will appear.
Here you can select the MIDI events that can be viewed
and edited in the SEQUENCE screen and EVENT LIST screen.
The STEP TIME popup will appear.
Here you can specify the interval by which the STEP buttons will change the time location.
The METRONOME popup will appear. Here you can make metronome settings.
The LOOP popup will appear. Here you can make loop settings for loop play.
The MIDI CLIP LIBRARY popup will appear. Here you can rename or delete items in the MIDI clip library.
MV-8000v200_e.book 18 ページ ２００５年５月４日 水曜日 午後４時２０分

19
EDIT
You can edit the track.
1 Move...
2 Copy&Paste...
3 Copy&Insert...
4 Erase
5 Cut
6 Quantize...
7 Change Velocity...
8 Change Duration...
9 Shift Timing...
10 Data Thin...
11 Transpose...
12 Split notes...
15 Copy As Audio Phrase...
13 Copy As MIDI Clip...
14 Paste MIDI Clip...
16 Audio Event Parameter
17 Select All Tracks
The MOVE popup will appear.
Moves the data of the selected region to the specified location.
The COPY&PASTE popup will appear.
Copies the data of the selected region to the specified location.
Deletes the data. The deleted region will be blank.
The COPY&INSERT popup will appear.
Inserts the data of the selected region to the specified location.
Deletes the data. Subsequent data will be moved forward.
The QUANTIZE popup will appear.
Adjust the timing of MIDI note events in the way you specify.
The CHANGE VELOCITY popup will appear.
Changes the velocity of MIDI note events.
The CHANGE DURATION popup will appear.
Changes the duration (note length) of MIDI note events.
The SHIFT TIMING popup will appear.
Moves the events of the selected region forward or backward in units
of one tick (1/480th of a quarter note).
The DATA THIN popup will appear.
Thins-out events of the selected region to reduce the amount of data.
The TRANSPOSE popup will appear.
Transposes the pitch of note events in the selected region, in units of a semitone.
The SPLIT NOTE popup will appear.
This lets you extract only specific note events from a track,
and move them to a specified other track.
The COPY AS AUDIO PHRASE popup will appear.
Here you can copy the selected data to the velocity pads.
The COPY AS MIDI CLIP popup will appear.
Add the specified data to the MIDI clip library.
The PASTE MIDI CLIP popup will appear.
Paste the MIDI clip from the MIDI clip library into the current song.
The AUDIO EVENT PARAMETER popup will appear.
Adjust the parameters of the event of an selected audio track.
Select or de-select all tracks.
MV-8000v200_e.book 19 ページ ２００５年５月４日 水曜日 午後４時２０分

20
SAMPLER
Here you can sample or import of audio sources, and make sampler setting.
MIXER/EFFECTS
Here you can make mixer or effect setting.
SYSTEM
Here you can make system setting for the MV-8000.
1 Sampling
2 Import
3 Audio Phrases
4 Instruments
5 Pad Banks
6 Quick Edit >
The SAMPLING popup will appear. Here you can make sampling setting and perform sampling.
The IMPORT popup will appear. Here you can import of music data from hard disk or CD.
The AUDIO PHRASES popup will appear. Here you can edit the audio phrases.
The INSTRUMENTS popup will appear. Here you can edit the instruments.
The PAD BANKS popup will appear. The PAD BANKS popup will appear.
Here you can switch the pad bank of the velocity pads.
This lets you edit an audio phrase or partial assigned to a velocity pad.
Use the sub-menu to select the number of the velocity pad.
1 Mixer
2 Effects
The MIXER popup will appear.
Here you can adjust the volume and panning of the audio tracks and instrument parts.
The EFFECTS popup will appear.
Here you can make settings for the built-in MFX, Delay/Chorus and Reverb.
1 Global
2 Pad/Panel
3 MIDI
4 V-Link
5 System Info
6 Slider
7 R-BUS
8 VGA/Mouse
The GLOBAL popup will appear.
Here you can make settings for the overall system of the MV-8000.
The SYSTEM PAD popup will appear.
Here you can make settings for the velocity pads, top panel buttons, knobs, and sliders.
The MIDI popup will appear. Here you can make MIDI settings.
The V-LINK popup will appear. Here you can make V-LINK settings.
The SYSTEM INFORMATION popup will appear.
Here you can view information about memory usage and the status of the installed options.
The SYSTEM ASSIGNABLE SLIDER popup will appear.
Here you can specify the functions assigned to the sliders.
The R-BUS popup will appear. Here you can make R-BUS settings.
The VGA/MOUSE popup will appear.
Here you can specify the signal that will be sent to the external display,
and adjust the sensitivity of the mouse.
MV-8000v200_e.book 20 ページ ２００５年５月４日 水曜日 午後４時２０分
