FR-2/FR-2
Accessory Guide
Attaching the straps
Proceed as follows to attach the straps to your FR-2/FR-2b:
(1) Unpack the straps.
(2) Put the FR-2/FR-2b on a stable surface.
The connection panel must face down.
(3) Slide the upper end of one strap through the
holder ring (see the illustration).
The upper end is the part with the Velcro portions
and the clip.
(4) Fasten the strap’s upper part to the Velcro layer
below it.
(5) Close the security clip to ensure that the strap
cannot come loose.
(6) Repeat steps (3)~(5) for the other strap.
The upper strap ends should look as follows:
(7) Turn the FR-2/FR-2b around (with the connection
panel on the left side, see below).
(8) Slide the lower end of one strap through the
holder ring as shown.
(9) Slide the strap end through the upper eyelet of its
plastic buckle (see the illustration).
(10) Turn the strap end around and insert it into the
lower eyelet, then pull it tight.
602.00.0272 RES 630-07 Accessory Guide E

(11) Slide the plastic clip over the loose and long
lower strap ends to secure the strap.
Note: You may want to adjust the length first to suit your
preference.
(12) Repeat steps (8)~(11) for the other lower strap
end.
Strap holder precaution
Never unscrew the strap holder rings to avoid dam-
aging the FR-2/FR-2b’s plastic housing, which
eventually compromises overall stability and safety.
Securing the adapter and/or a MIDI cable
Proceed as follows to ensure that the adapter cable –or a MIDI cable– doesn’t come loose while you are playing.
Your FR-2/FR-2b comes with an adapter and an
attachment strip that allows you to secure the
adapter cable and an optional MIDI cable to the right
strap.
(1) Prepare the adapter cable and the attachment
strip as follows:
Be sure to attach the strip before the ferrite core on
the adapter cable. If you like, you can also add the
MIDI cable to this assembly.
(2) Secure the attachment strip as shown in the
illustration, making sure that the ferrite core
cannot slide out of the loop.
(3) Hold the adapter cable close to the right strap
and wind the attachment strip around it as
shown.
The strip is fitted with a Velcro layer that holds it in
place.
(4) Keep winding the attachment strip around the
strap until your assembly looks as follows:
(5) Reverse these steps to remove and disconnect
the adapter and/or MIDI cable when you want to
stop playing.
