How to Assemble the RG-7
■Check the Parts
fig.00-01¬
Before you begin assembling the stand, check that all the following parts were supplied.
■Assemble Procedure
Attach the legs to the piano
1. Position the legs in place beneath the piano.
2. Use the hex wrench to fasten the leg to the
piano (at two points) with the bolts .
3. Fasten the two other legs to the piano in the
same fashion.
Attach the lyre assembly
4. Using the screws , fasten the lyre assembly
to the piano (at four points).
5. Using the screws , fasten the lyre support sticks
to the lyre box (at two points).
6. Using the screws , fasten the lyre support sticks
to the piano (at two points).
7. Place the caster cups beneath the casters of the
legs.
Connecting the Pedal Cord and the Power Cord
The customer can also connect the pedal cord and the power cord.
1. Connect the supplied power cord to the AC inlet.
2. Connect the pedal cord to the Pedal connector.
3. Cramp the power cord and pedal cord with Cord
Cramp and screw at A, B and C (see the
picture).
4. Plug the power cord into an AC outlet.
Legs 3 Screws (M8 x 30) 4
Lyre assembly 1 Screws (M4 x 16) 5
Lyre support sticks 2 Screw (4 x 10) 3
Caster Cups 3 Hex wrench (Large) 1
Hex socket head cap bolts (W 1/2) 6 Cord Cramp (Small) 4
Spring washers 6 Cord Cramp (Large) 4
Plain washers 6
a
b
c
d
e
f
g
A
A
D
D
A
D
C
B
A b
Bc
Cd
De
a
f
g
1
2
a
a
eA
a
A
6
7
D
5
c
c
4
4
b
b
b B
c
C
c
C
D
f d
40568789 3PD
Leaflet For a Dealer or a Qualified Professional Installer
This leaflet is for a dealer or a qualified professional installer. The customer should not attempt to assemble the instrument.
Roland cannot warrant the safety of the assemble operation, if this operation is carried out by the customer.
The assemble operation may cause serious personal injury and serious damage to the properties.
*40568789- 03*
