Roland VS-1680 V-XPANDED Operating and maintenance manual
Sep, 1998
VS-1680
TABLE OF CONTENTS Page
SPECIFICATIONS •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••1~2
LOCATION OF CONTROLS ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••3
EXPLODED VIEW•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••4
BLOCK DIAGRAM ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••5
PARTS LIST•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••6~7
IDENTIFYING VERSION NUMBER ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••7~10
TEST MODE•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••7~10
SETTING THE INTERNAL CLOCK ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••10
VS-840 SYSTEM SOFTWARE UPDATE
USING THE SMF ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••10
SAVING DATA OF INTERNAL HDD•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••11~13
EXCHANGE THE MAIN BOARD •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••14
CIRCUIT DIAGRAM & BOARD ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••15~24
IC DATA••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••25
SPECIFICATIONS (VS8F-2)•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••26
INSTALLING THE (VS8F-2) •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••26
PARTS LIST (VS8F-2) ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••27
CIRCUIT DIAGRAM & BOARD (VS8F-2)••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••28~29
Printed in Japan (AD00) (CR) 1
17059910
Copyright c1998 by ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission of
ROLAND CORPORATION.
SPECIFICATIONS
VS-1680: 24 bit Digital Studio Workstation
'Tracks :Tracks :16
:V-Tracks :256(16V-Tracks per each Track)
Note :Up to 8 tracks can be recorded simultaneously, and up to 16 tracks
can be played back simultaneously.
'
Maximum Useful Capacity
:128Gbytes :2Gbytes(capacity)
x8 (Partition)
x8 (Disk Drive)
'Internal Memory :Songs :200(each pertition)
'Equalizer :HI, MID, LOW (16 channels)
HI, LOW (26 channels)
'Recording Mode :Multitrack Pro (MTP)
Mastering (MAS)
Multitrack 1 (MT1)
Multitrack 2 (MT2)
Live 1 (LIV1)
Live 2 (LIV2)
'Signal Processing :AD Conversion :20bits,64times oversampling
:DA Conversion :20bits,128times oversampling
Internal Processing
:24 bits (mixer section)
'Sample Rate :48.0 kHz, 44.1 kHz, 32.0 kHz
Note :Sample rate can be adjusted around 22.00--50.48 kHz (maximum)
by using vari-pitch function.
'Frequency Response :Sample Rate
:48.0 kHz:20 Hz--22 kHz (+0.2 dB/-0.2 dB)
:44.1 kHz:20 Hz--20 kHz (+0.2 dB/-0.2 dB)
:32.0 kHz:20 Hz--14 kHz (+0.2 dB/-0.2 dB)
'Total Harmonic Distortion
(INPUT SENS: 0 dBu, 1 kHz at nominal output level)
:0.005 % or less (recording mode: MTP)
:0.003 % or less (recording mode: MAS)
'Recording Time (at 2 G bytes, 1 track)
Recording Mode Sample Rate
48.0 kHz 44.1 kHz 32.0 kHz
MTP 742 minutes 808 minutes 1114 minutes
MAS 370 minutes 404 minutes 556 minutes
MT1 742 minutes 808 minutes 1114 minutes
MT2 990 minutes 1078 minutes 1484 minutes
LIV1 1188 minutes 1292 minutes 1782 minutes
LIV2 1484 minutes 1616 minutes 2228 minutes
Note :The above-listed recording times are approximate. Times may be
slightly depending on the specifications of the disk drive and on the
number of songs that were created.
'Nominal Input Level (variable)
Input1--2 :-50--+4 dBu (maximum +26 dBu:Balanced,
maximum +20 dBu:Unbalanced)
Input3--8 :-50--+4 dBu (maximum +26 dBu:Balanced,
maximum +20 dBu:Unbalanced)
Guitar(Hi-Z) :-50--+4 dBu (maximum +26 dBu:Balanced,
maximum +20 dBu:Unbalanced)
'Input Impedance :Input1–2 :30 k ohms
:Input3–8 :30 k ohms
:Guitar (Hi-Z) :500 k ohms
'Nominal Output Level :Master Out :0 dBu
AUX A (L, R) :0 dBu
AUX B (L, R) :0 dBu
Monitor Out :0 dBu
'Output Impedance :Master Out :1 k ohm
AUX A (L, R) :1 k ohm
AUX B (L, R) :1 k ohm
Monitor Out :1 k ohm
Headphones :22 ohms
VS-1680
24bit digital studio workstation
Issued by RJA
2
VS-1680
Sep, 1998
'
Recommended load Impedance
:Master Out :10 k ohms or greater
AUX A (L, R) :10 k ohms or greater
AUX B (L, R) :10 k ohms or greater
Monitor Out :10 k ohms or greater
Headphones :8--50 ohms
'Residual Noise Level
( input terminated with 1 k ohms,INPUT SENS = LINE, IHF-A, typ.)
:Master Out :-82 dBu or less
AUX A (L, R) :-82 dBu or less
AUX B (L, R) :-82 dBu or less
Monitor Out :-82 dBu or less
'Interface Connectors :SCSI :DB-25 type
Digital I/O :Coaxial, Optical
(conforms to S/P DIF)
'Display :320 x 240 dots, Graphic LCD (with backlit)
'Connectors :SCSI Connector (DB-25 type)
MIDI Connector (IN, OUT/THRU)
Input Jack 1--2 (XLR type, balanced, phantom power)
Input Jack 3--8 (1/4 inch phone type, TRS balanced)
Guitar (Hi-Z) Jack (1/4 inch phone type)
Digital In Connector (Coaxial type, Optical type)
Digital Out Connector (Coaxial type, Optical type)
Foot Switch Jack (1/4 inch phone type)
Headphones Jack (Stereo 1/4 inch phone type)
AUX A Send Jack L/R (RCA phono type)
AUX B Send Jack L/R (RCA phono type)
Master Out Jack L/R (RCA phono type)
Monitor Out Jack L/R (RCA phono type)
'Power Supply :AC 117 V, AC 230 V or AC 240 V
'Power Consumption :33 W (Including internal hard disk)
'Dimension :554 (W) x 336 (D) x 109 (H) mm
21-13/16 (W) x 13-1/4 (D) x 4-5/16 (H) inches
'Weight :
6.3 kg (Excluding internal hard disk) 13 lbs 15 oz
'Accessories :Owner's Manual (ENGLISH) :#71017189
AC Cord 120V :#00894378
AC Cord 230V :#00894389
AC Cord 240VE :#00907001
AC Cord 240VA :#23495124
'Options :Internal Hard Disk Drive Unit :HDP88 Series
Effect Expansion Board :VS8F-2
Foot Switch :FS-5U (BOSS)
Pedal Switch :DP-2
Headphone :RH-120
(0 dBu = 0.775 V rms)
* In the interest of product improvement, the specifications and/or
appearance of this unit are subject to change without prior notice.
3
CANNON NC3FAH2-0
(01239890)
6.5MM JACK
LGR4609-7000
(00569278) 6.5MM JACK
HLJ4306-01-3010
(01345934)
PIN JACK
YKC21-3492
(01345989)
PIN JACK
YKC21-3044
(00458801)
MIDI JACK
YKF51-5054
(13429825)
AC INLET
NC-176-1.0
(01347623)
DC FAN MOTOR
D04X-05TL 05(V)
(01010301)
F S-BUTTON MX BLK
(22495565)
SWITCHING POWER SUPPLY
A1KW1AA261
(01347645)
D-SUB CONNECTER 25PIN
DBLC-J25SAF-20L9F
(13429314)
TOS LINK(RX)
TORX178A
(01343001)
TOS LINK(TX)
TOTX178
(01239078)
SLIDE SW
SSSU142-S09N1
(01239989)
P R-KNOB SF-A MWG/LCG
(01347301)
ROTARY POT. (INPUT) EVU JF8 FL3 54D (50KRD)
(01347678)
ROTARY POT. (MONITOR) EVU JF8 FL3 B54 (50KB)
(01347856)
ROTARY POT. (PHONES) EVJ Y95 F03 A14 (10KA)
(01345978)
TACT SW SKQNAD
(00894656)
LED (RED) SEL5221S
(00560756)
LED (GREEN) SEL5421E
(00676423)
LED (ORANGE) SEL5921A
(01239856)
LED (RED/GREEN) SML72423C
(01239867)
U S-KNOB M1 LCG DCG
(01349423)
SLID POT.
EWA Q1A C10 B54
(01342934)
U S-KNOB M1 MRD LCG
(01349434) HD COVER
(01450167)
SLID POT.
EWA Q1A C10 B54
(01342934)
TACT SWITCH SKECAF
(00894645)
KEYTOP FWD/RWD
(00901423)
KEYTOP PLAY
(00901401)
KEYTOP REC
(00901412)
KEYTOP RESET
(00901445)
KEYTOP STOP
(00901390)
ROTARY ENCODER
EC16B24104 L=15
(01124478)
D R-KNOB L MCG
(00677223)
ROTARY POT.
EVU F2A E20 B53
(01344123)
LCD LM320191
(01124234)
DISPLAY COVER
(01347878)
TOP PANEL B
(01347890)
TOP PANEL A
(01347889)
TOP CASE
(01347867)
LOCATION OF CONTROLS
VS-1680
Sep, 1998
4
EXPLODED VIEW
Sep, 1998
[PARTS]
No. PART No. PART NAME
q01452289 EXP COVER
w01347901 BOTTOM COVER
e01450167 HD COVER
r01347712 PWB HOLDER
t01349878 HD HOLDER
y70905967 CONNECTER BOARD
u00897812 ANGLE HD-R
i00897823 ANGLE HD-L
o01561334 AIR GUIDE
!0 70906756 MIDI BOARD
!1 71011289 DIGITAL I/O BOARD
!2 01458312 SHIELD PANEL
!3 01347645 SWITCHING REGULATOR A1KW1AA261
!4 71015356 MAIN BOARD
!5 01348090 SUB CHASSIS
!6 70897023 PANEL BOARD
!7 01451445 SWB HOLDER
!8 01459201 VOLUME HOLDER
!9 71015967 LCD CONTRAST BOARD
@0 01451434 LCD HOLDER
@1 01124234 DISPLAY UNIT LCD LM320191
@2 01450112 REAR PANEL
@3 01347867 TOP CASE
@4 01347878 DISPLAY COVER
@5 01347889 TOP PANEL A
@6 01347890 TOP PANEL B
@7 00677223 D R-KNOB L MCG
@8 00901423 KEYTOP FWD/RWD
00901401 KEYTOP PLAY
00901412 KEYTOP REC
00901445 KEYTOP RESET
00901390 KEYTOP STOP
@9 01347301 P R-KNOB SF-A MWG/LCG
#0 01349423 U S-KNOB M1 LCG DCG
01349434 U S-KNOB M1 MRD LCG
#1 01455523 CORD BUSHING EDS-1717U
#2 01010301 DC FAN MOTOR D04X-05TL 05(V)
#3 01455745 WIRING POWER WITH INLET
#4 22495565 F S-BUTTON MX BLK
#5 00899890 PWB SPACER KGES-12
#6 17048413 STATUS KEY SEAL
#7 17048412 AUTMIX KEY SEAL
#8 22355160 FOOT D25
#9 01347912 WIRING HDD
[SCREW]
A40011145 FLAT TAPTIGHT B M3x6mm BZC
B40011101 BINDING TAPTIGHT B M3x8mm BZC
C40011501 PAN MACHINE SCREW SEMS P 3x8mm BZC
D40019990 PAN MACHINE SCREW SEMS 4x20mm BZC
E******** M4FLANGE NUT
F******** M4x8mm LO2 BZC
G40012534 BINDING TAPTIGHT S M3x6mm BZC
H******** BOSS NUT M2.6/M7.3L5.2
I40012945 PAN MACHINE SCREW W/SW+PW M3x6mm BZC
J40011156 FLAT TAPTIGHT B M3x8mm BZC
K******** PAN MACHINE SCREW W/SW+SMOLE PW M3x6mm BZC
VS-1680
1 2 3 4 5 6 7 8 9 10111213141516171819202122232425262728
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U5
Out/Thru Input
MIDI
IC1
CPU
SH7042
IC8
Flash
16Mbit
IC9,10
D-RAM
32Mbit
IC16
SPC
53CF96
IC28
DSP GA
IDE I/F
BUFFERS
BUSS
IC17 IDE
Conecter
IC35
ESP2
IC5
CPU GA
Terminater
IC311
A/D/A
SENS Input8
Master Out L
Master Out R
Aux Out BR
Moniter Out L
PCM & CONTROL
IC21
Digital In
IC22
Digital Out
Digital Input COX
Digital Output COX
CN13
to VS8F-2
CN700
fromVS-1680
IC700
CPU
H8 IC702
S-RAM
IC703
ESP2 IC705
D-RAM
512Kbit 4Mbit
VS8F-2(OPTION BOARD)
FOOT SW
IC19
PLL1
IC30
PLL2
256to1280fs
512fs
MASTER CLOCK
FEDER IC7,8
MPX
BF<
BF&DEC
DEC
SW & LED
Panel Board
LCD UNIT
320x240dot IC34
ESP2
CN12
to VS8F-2
CN700
fromVS-1680
VS8F-2
(OPTION)
IC27
TI DSP
Aux Out AR
Aux Out BL
Moniter Out R
Digital Input OPT
Aux Out AL
Digital Output OPT
Guitar In
SENS Input7
SENS Input6
SENS Input5
SENS Input4
SENS Input3
SENS Input2
SENS Input1
Phones
IC315
IC303
IC307
BLOCK DIAGRAM
VS-1680
Sep, 1998
!
PARTS LIST BATTERY
00238990 CR2032 210MAH/3V LITHIUM BATTERY
IC
01342423 HD6437042AE11F CPU IC1 on MB
# 01450201 TMS320C541PZ1-40 CFM IC27 on MB
# 01347490 NCR53CF96-2 SIO IC16 on MB
# 01349745 UPD65806GD-100-LML CUSTOM IC IC28 on MB
00892556 TC170C140AF-003 (ESP2) CUSTOM IC IC34.IC34 on MB
00343823 M60205-0601FP CUSTOM IC IC5 on MB
# 01450845 UPD431016LE-15-E2 SRAM IC29.IC62 on MB
01122412 TC551001B(C)FL-70L SRAM IC12 on MB
# 01347689 TMS417809A-60DZR DRAM IC9.IC10 on MB
01127578 LH28F016SUT-70 FLASH MEMORY IC8 on MB
01238101 AK4520AVF-E2 AD/DA IC303.IC307.IC311.IC315 on MB
15169596 TC74HC4051AP CMOS IC7.IC8 on PB
15169627 TC74HC154AP CMOS IC1 on PB
15169556T0 TC74HC574AP CMOS IC5 on PB
15169515 TC74HC00AP CMOS IC300 on PB
15169512 TC74HCU04AP CMOS IC400 on PB
01349590 TC7WU04FU(TE12L) CMOS IC44 on MB
# 01349578 TC7W08FU(TE12L) CMOS IC45 on MB
# 01450178 TC7W14FU(TE12L) CMOS IC48 on MB
00893967 TC74VHC153F(EL) CMOS IC7.IC20 on MB
01121834 TC7W74FU TE12L CMOS IC43.IC64 on MB
# 01121845 TC7W04FU TE12L CMOS IC49.IC57 on MB
# 01348890 TC7SHU04FU(TE85L) CMOS IC53 on MB
# 01348956 TC7SH00FU(TE85L) CMOS IC58 on MB
# 01348901 TC7SH04FU(TE85L) CMOS IC50.IC51 on MB
# 01348912 TC7SH08FU(TE85L) CMOS IC54.IC66 on MB
# 01348945 TC7SH32FU(TE85L) CMOS IC55.IC56.IC61 on MB
00231878 TC74VHC00F(EL) CMOS IC36 on MB
# 01346067 TC74VHC595F(EL) CMOS IC23 on MB
00670290 TC74VHC139F(EL) CMOS IC6 on MB
# 00236889 TC74VHC157F(EL) CMOS IC31-33.IC63 on MB
00236845 TC74VHC245F(EL) CMOS IC13 to IC15 on MB
00893978 TC74VHC393F(EL) CMOS IC18.IC24.IC25.IC52.IC60 on MB
00564534 TC74VHC574F(EL) CMOS IC26 on MB
00236878 TC74VHC74F-EL CMOS IC59.IC65 on MB
15289110 UPC4062G2-T2 SO OP AMP IC3 on MB
15189266 NE-5532AN BIPOLAR OP AMP IC300.IC304.IC308.IC312 on MB
15289109 M5216FP-600D BIPOLAR OP AMP IC321 on MB
15289105 UPC4570G2-T2 BIPOLAR OP AMP IC322 on MB
15199286 AN78L05M-(E1) REGULATOR IC302.IC306.IC310.IC314 on MB
15199944 SED1335F0B DRIVER IC11 on MB
00893990 BH9595FP SCSI ACTIVE TERMINATOR IC17 on MB
01124367 TLC2933IPW PLL IC30 on MB
00564690 TC9246F(ELP) PLL IC19 on MB
00121078 TC9271F(ELP) DIF/TRANSMITTER IC22 on MB
# 01124378 LC8905V-TLM DIF/RECEIVER IC21 on MB
# 01347489 RTC-4543 SA-A TIMER IC2 on MB
15289123 M51953AFP-600C RESET IC IC4 on MB
15199928 NJM2360D CONTROL IC IC700 on CB
00900901 CXA-M10A-L CFL INVERTER MODULE IC701 on CB
TRANSISTOR
00019112 TD62381P IC6 on PB
15149150 TD62787AP IC3.IC4 on PB
15309101 2SA1037KR T146 Q328 on MB
# 01239990 2SC4117-GR(TE85L) Q300 to Q315 on MB
15129151 2SC1815-GR(TPE2) Q700 on CB
15319603 2SD1664R T101 Q2 on MB
15119141 DTA114ESATP Q300 on PB
15129164 DTC114ESTP Q400 on PB
15329516 DTC114EKT146 Q1.Q326.Q327 on MB
15329505 DTC314TKT146 Q316 to Q325 on MB
DIODE
15019126 1SS133 T-77 SWITCHING DIODE D1 to D85.D300 on MB
00128045 S2S6M-4001P12.5 SCHOTTKY DIODE D3 on MB
15339105 DAN202K T146 ARRAY DIODE D1 on MB
15339112 DA119 T146 ARRAY DIODE D4.D5.D300 on MB
15339108 DA204K T146 ARRAY DIODE D2 on MB
# 01349556 AK06 SCHOTTKY DIODE D700 on CB
RESISTOR
00120823 MNR35J5J103 RESISTOR ARRAY RA1-8.RA17.RA18.RA24.RA25 on MB
00128189 MNR35J5J102 RESISTOR ARRAY RA9.RA10 on MB
00126490 MNR34J5ABJ470 RESISTOR ARRAY RA11 to RA16 on MB
# 01458689 SRPX2 L15 0.1 J FILM RESISTOR R95 on MB
POTENTIOMETER
# 01347678 EVU JF8 FL3 54D (50KRD) 9M/M ROTARY POT. VR300 to VR307 on MB
# 01347856 EVU JF8 FL3 B54 (50KB) 9M/M ROTARY POT. VR1 on MB
# 01345978 EVJ Y95 F03 A14(10KA) 12M/M ROTARY POT. VR308 on MB
# 01344123 EVU F2A E20 B53 9M/M ROTARY POT. VR14 on PB
# 01342934 EWA Q1A C10 B54 60M/M SLIDE POT. VR1 to VR13 PB
CAPACITOR
00239490 AMZV0050J103 0200 POLYESTER. C404 on PB
# 01345845 EEUFC1J221S CHEMICAL C409 on PB
# 01346012 ECHU1H121JB5 POLYESTER. C304.C317.C332.C333.C334.C345-C347.C362-C364.C375-C377.C392-C394.
C406-C408 on MB
01015912 ECHU1H222JB5 POLYESTER. C312.C325.C342.C355.C372.C385.C402.C416 on MB
# 01454878 ROS-16V222M CHEMICAL C509.C510 on MB
# 01345956 ECEA1CPZ470B CHEMICAL C511 to C520 on MB
00908201 ECEA1EPZ101B CHEMICAL C474.C477.C480.C483.C486.C489.C492.C494.C497.C499 on MB
00568801 ECEA1EPZ470B CHEMICAL C308.C311.C321.C324.C338.C341.C351.C354.C368.C371.C381.C384.C398.C401.
C412.C415 on MB
# 01346001 ECEA1HPZ220B CHEMICAL C300.C301.C313.C314.C330.C331.C343.C344.C360.C361.C373.C374.C390.C391.
C404.C405 on MB
# 13639535J0 SME10VB470TP CHEMICAL C329.C359.C389.C420 on MB
# 13639549J0 SME16VB47TP CHEMICAL C307.C320.C337.C350.C367.C380.C397.C411 on MB
# 13649646 SME16VB470TP CHEMICAL C530 on MB
# 13639610J0 SME50VB22TP CHEMICAL C457.C458.C461.C462.C465.C466.C469.C470 on MB
# 13639512J0 SME6.3VB100TP CHEMICAL C421.C425.C428.C430.C434.C437.C439.C443.C446.C448.C452.C455.C460.C464.
C468.C472 on MB
# 01454889 RA2-16V470MT2 CHEMICAL C521-C529 on MB
# 13639552J0 SME16VB330TP CHEMICAL C326.C356.C386.C417 on MB
13649101M0 ECEA1HN010SB CHEMICAL-BP C531 on MB
# 01450189 ECEA1VKS470B CHEMICAL C705 on MB
13529162 A055F104ZB2 MLT.LAY.CERA C401.C402.C403.C406.C408 on PB
13639698 ECEA0JKS101B CHEMICAL C300 on PB
# 01458690 6.3MV10000HC CHEMICAL C108 on MB
INDUCTOR, COIL, FILTER
00891689 SBT-0260TF EMI FILTER FL300-FL303 on PB
12449449 RCH875-151K COIL L700 on CB
# 01233345 N2012Z121T02 FERRITE-BEAD FL1-FL5 on MB
12449268 BL02RN2-R62T2 FERRITE-BEAD FL400 on PB
CRYSTAL, RESONATOR
01124812 MA-406 10MHZ X'TAL X1 on MB
# 01454856 SG-8002JC-56M-PHCL OSCILLATOR X3 on MB
# 01454867 SG-8002JC-60M-PHCL OSCILLATOR X4 on MB
ROTARY ENCODER
# 01124478 EC16B24104 L=15 ROTARY ENCODER EN2 on PB
OPTICAL DEVICE
15229706S0 PC910X PHOTO COUPLER IC301 on PB
00560756 SEL5221S TP15 LED (RED) D165-D172.D116.D175 on PB
00676423 SEL5421E TP15 LED (GREEN) D115.D174 on PB
# 01239856 SEL5921A TP15 LED (ORANGE) D113.D114.D117-D156.D158-D161D163.D164.D173 on PB
# 01239867 SML72423C TP15 LED (RED/GREEN) D100-D112 on PB
# 01343001 TORX178A JK400 on PB
01239078 TOTX178 JK401 on PB
6
NOTE:The parts marked # are new (initial parts)
MB => MAIN BOARD PB => PANEL BOARD CB => LCD CONTRAST BOARD
CASING
# 01347867 TOP CASE
NOTE: Changed the TOP CASE when used the following seals.
# 17048412 AUTMIX KEY SEAL 04458-202
# 17048413 STATUS KEY SEAL 04458-203
# 01347889 TOP PANEL A
# 01347890 TOP PANEL B
# 01450112 REAR PANEL
# 01347878 DISPLAY COVER
# 71016289 BOTTOM ASSY
NOTE: Replacement BOTTOM ASSY includes the following parts.
# 01347901 BOTTOM COVER
# 01452289 EXP COVER
22355160 FOOT D25
# 17048441 HDD HOLDER ASSY without CONNECTOR BOARD
NOTE: Replacement HDD HOLDER ASSY without CONNECTOR BOARD includes the following parts.
00897823 ANGLE HD-L
00897812 ANGLE HD-R
# 01349878 HD HOLDER
CHASSIS
# 01348090 SUB CHASSIS
# 01451434 LCD HOLDER
# 01451445 SWB HOLDER
# 01347712 PWB HOLDER
# 01459201 VOLUME HOLDER
# 01450167 HD COVER
12569420 BATTERY HOLDER CR2032 (HL32-A2)
# 01458312 SHIELD PANEL
# 01561334 AIR GUIDE
# 17048428 CE-012 L=27 EDGING on SUB CHASSIS
01455523 EDS-1717U CORD BUSHING on SUB CHASSIS
KNOB BUTTON
00901423 KEYTOP FWD/RWD
00901401 KEYTOP PLAY
00901412 KEYTOP REC
00901445 KEYTOP RESET
00901390 KEYTOP STOP
00677223 D R-KNOB L MCG VALUE
# 01347301 P R-KNOB SF-A MWG/LCG INPUT
# 01349423 U S-KNOB M1 LCG/DCG TRACK
# 01349434 U S-KNOB M1 MRD/LCG MASTER
22495565 F S-BUTTON MX BLK
SWITCH
00894645 SKECAF TACT SWITCH SW80 to SW85 on PB
00894656 SKQNAD PTR TACT SWITCH SW1to SW79 on PB
# 01239989 SSSU142-S09N1 SLIDE SWITCH SW200 on PB
JACK SOCKET
00458801 YKC21-3044 PIN O/O JK402 on PB
00569278 LGR4609-7000 6.5MM JK403 on PBJK302 to JK307-310 on MB
# 01345934 HLJ4306-01-3010 6.5MM JK308
# 01239890 NC3FAH2-0 CANNON JK300.JK301 on MB
# 01345989 YKC 21-3492 RCA(PIN) JK309
13429314 DBLC-J25SAF-20L9F D-SUB JK1
13429825 YKF51-5054 MIDI on MIDI BOARD
01347623 NC-176-1.0 AC INLET
DISPLAY UNIT
# 01124234 LCD LM320191
NOTE :Replacement DISPLAY UNIT should be made on a unit basis.
No replacements available for individual parts. Replacement only by a unit.
NOTE: The DISPLAY UNIT does not include the following seal.
Please order them separately, if necessary.
# 17048425 LCD SEAL on DISPLAY UNIT
PCB ASSY
#‰71015356 MAIN BOARD
# 70897023 PANEL BOARD
# 70905967 CONNECTOR BOARD
# 71011289 DIGITAL I/O BOARD
# 71015967 LCD CONTRAST BOARD
# 70906756 MIDI BOARD
POWER SUPPLY UNIT
# 01347645 A1KW1AA261 SWITCHING REGULATOR
NOTE: Replacement POWER SUPPLY UNIT should be made on a unit basis.
No replacements available for individual parts. Replacement only by a unit.
Warning! : There is the possibility that you will burn your hands when you touch Power Supply parts soon after the power supply is turned off.
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics.
Use only listed parts for
replacement.
!
CONSIDERATIONS ON PARTS ORDERING
When ordering any parts listed in the parts list, please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or
even undelivered replacement.
VS-1680
Sep, 1998
Note: Consider about the natural environment carefully before through the old lithium battery away when you exchange to the new one.
Sep, 1998
VS-1680
7
CONNECTOR
00894567 FX2C2-52P-1.27DSAL CONNECTOR CN601 on CB
13429825 YKF51-5054 (DUAL) MIDI CONNECTOR JK300 on PB
13369503 B7B-PH-K-S JST CONNECTOR CN7 on MB
13379104 TX14-40R-6ST-MH1 B TO B CONNECTOR CN12.CN13 on MB
# 01341990 52045-1245 FFC/FPC CONNECTOR CN701 on CB
# 01349645 S2(4-2.3)B-XH-A CONNECTOR CN703 on CB
13369851 PS-50PE-D4T1-B1-K CONNECTOR CN7-CN9 on MB CN600 on CB
13369567 B4B-PH-K-S JST CONNECTOR CN201 on PB
13369564 B12B-PH-K-S JST CONNECTOR CN6 on MB
13369582 B13B-PH-K-S JST CONNECTOR CN11 on MB
13369563 B14B-PH-K-S JST CONNECTOR CN4 on MB
13369562 B15B-PH-K-S JST CONNECTOR CN5 on MB
13439474 B2B-XH-A CONNECTOR CN14 on MB
13369594 B4B-XH-A JST CONNECTOR CN3 on MB
13369566 B6B-PH-K-S JST CONNECTOR CN1 on MB
13369541 B10B-PH-K-S JST CONNECTOR CN15 on MB
13369568 B3B-PH-K-S JST CONNECTOR CN702 on CB
WIRING CABLE
# 01347912 WIRING HDD Between MB(CN8) to CB(CN600)
# 01344134 WIRING PANEL 3S Between CB(CN702) to PB(CN4)
# 01344145 WIRING PANEL 13S Between MB(CN11) to PB(CN3)
# 01344156 WIRING PANEL 14S Between MB(CN4) to PB(CN2)
# 01344167 WIRING PANEL 15S Between MB(CN5) to PB(CN1)
# 01344212 WIRING MIDI BOARD 6S Between MB(CN1) to PB(CN300)
# 01344178 WIRING DIGITAL I/O BOARD 3 Between PS Assy(CN3) to PB(CN200)
# 01344190 WIRING DIGITAL I/O BOARD 7S Between MB(CN10) to PB(CN400)
# 01347512 WIRING MAIN 8 Between MB(CN2) to PS Assy(CN2)
# 01344189 WIRING DIGITAL I/O BOARD 4 Between MB(CN300) to PS Assy(CN201)
# 01347634 WIRING LCD CONT BOARD 12S Between MB(CN6) to CB(CN700)
# 01455745 WIRING POWER WITH INLET
TRANSFORMER
12449615 PT-10244-615 Pulse Trans. T400 on PB
FAN MOTOR
# 01010301 D04X-05TL 05(V) DC FAN MOTOR
SCREW
40012534 3X6mm Binding Taptight S BZC
******** 3X6mm Pan Machine Screw W/SW+Smole PW BZC
40012945 3X6mm Pan Machine Screw W/SW+PW BZC
40011145 3X6mm Flat Taptight B BZC
40011101 3X8mm Binding Taptight B BZC
40011501 3X8mm Pan Machine Screw SEMS BZC
40011156 3X8mm Flat Tap-Tight B BZC
******** 4X8mm LO2 BZC
# 40019990 4X20mm Pan Machine Screw SEMS BZC
******** M4 FLANGE NUT
******** BOSS NUT M2.6/M7.3L5.2
PACKING
# 01124089 PACKING CASE
# 01124123 PAD for PACKING CASE
MISCELLANEOUS
00899890 KGES-12 PWB SPACER on MB
01455512 UC-300287 L=15 EMI GASKET
# 40238545 CAUTION LABEL SHOCK HAZARD & ICES
# 40126812 CAUTION LABEL BARRIER
ACCESSORIES(Standard)
# 70896967 OWNER'S MANUAL SET JAPANESE
# 71017189 OWNER'S MANUAL SET ENGLISH
00894367 AC CORD SET 100V SP18A+IS14 VCTF2X0.75
00894378 AC CORD SET 120V SP301+IS14 SJT18/3
00894389 AC CORD SET 230V SP22+IS14 H05VV-F3G1.0
00907001 AC CORD SET 240VE KP-610,GTBS-3,KS-31A
23495124 AC CORD SET 240VA SC-114-J01 ES303-10HMA
# 40232334 (JAPAN ONLY)
!
!
!
!
!
!
TEST MODE
Equipment
:VS-1680
:VS8F-2
:Audio devices (CD PLAYER, DAT, AUDIO SIGNAL
GENERATOR, AMPLIFER, SPEAKER, HEADPHONES)
:MIDI devices (MIDI KEYBOARD, MIDI MODULE)
:SCSI devices (ZIP DRIVE)
:Cable (AUDIO, MIDI, SCSI)
1.Entering test mode
While pressing [TRACK SELECT] and [STATUS]button on the
CH5, turn the power on.
The unit is now in the test mode.
2.Exiting test mode
Turning the power off is the only one way to exit the test mode.
3.Selecting of the test from a menu
The test menu is shown on the display after starting up the test
mode program.
The information of the current version is shown on the upper
part of the display all the time.
The menu items are shown on the left-lower part of the
display.
The contents of the selected menu is shown on the right-lower
part of the display.
4. Executing commands
There are 17 kinds of the check menus. Each check menu
has several commands.
To select the desired menu, use [F1] and [F2] button.
When the desired menu is selected by [F1] or [F2] button, that
function on a display is shown on the [F3], [F4], [F5] and [F6].
5. Test Options
[01:LCD check]
This is a test for the LCD in order to find any defect such as LCD
lighting problems,cracks, wrong connections, or etc.
[F3:LCD Black] Turn on all LCD dots simultaneously.
[F4:LCD White] Turn off all LCD dots simultaneously.
[F5:LCD check1] Turn on LCD in a check pattern.
[ Roland VS-1680 TEST Mode ( Version 1.xxx ) ]
Upper Software Version Number: VS-1680Ver.x.xxx
Upper Software Create Date: Dec 11 97' xx:xx
BOOTROM Version Number: VS-1680BtVerx.xx
[TEST MENU]
>01:LCD Chk
02:LED Chk
03:SW Chk
[ [ LCD Check ] ]
(fig-1)
FUNCTION
F1 (pageUp) F2 (PageDown)
(fig-2)
FUNCTION
F3 F4 F5 F6
(fig-3)
8
[F6:LCD check2] Display all ASCII character codes one by
one on the LCD.
[02:LED check]
This is a test for the LED in order to find any defect such as LED
lighting problems,short circuit, wrong connections, or etc.
[F3:LED Scan] Turn on and off LED one by one.
[F4:LED Blink] Flash all LED simultaneously.
[F5:LED All On] Turn all LED simultaneously.
[F6:LED ManuScan]
Turn on LED one by one as [FF] or
[REW] button is pressed or TIME/VALUE
Dial is turned.
[03:SW check]
Check the SW contact fault or other problems and confirm SW
functions on Panel board.
[F3:SW] Except power switch press all switches
on the panel one by one.
The LEDs will flash and warn of error
when more than two Switches are
pressed at the same time during the test.
To finish this test turn TIME/VALUE dial.
"Err" message and the number of
switches which not tested yet will be
appeared on the display at the end of
the test.
(If there is any untested switch is
remained.)
When all switches are tested completely,
"OK" message is appeared on the
display and finish the test.
[04:Fader check]
Check the Fader and the capacity of back up battery on Panel
board.
[xx:Fader Check] Check the Faders.
The LCD draws bar graphs representing
settings of the faders.
Each channel LED lights green when the
fader is at the bottom,red at the top
position (127) and orange at the middle
of the stroke (64).
In the test, confirm the bottom and top
position.
[xx:Battery Check] Battery voltage and OK/NG are shown
on the display.
[05:FootSW check]
Check the status of foot switch function.
[xx:FootSW Check]
Check the foot switch.
Plug the foot switch in FOOT SWITCH
socket.
The LCD indicates each status when
switch is turned on and off and confirm
the LCD correspond it correctly.
[06:Encoder check]
Check the status of Encoder function.
[xx:Encoder Check]
Check the encoder function.
The display shows the numbers that
increase or decrease depending on the
TIME/VALUE dial turning direction.
Confirm increase or decrease numbers
correspond to the dial direction.
Turn TIME/VALUE dial clockwise:
increase the numbers.
Turn TIME/VALUE dial counterclockwise:
decrease the numbers.
The numbers are indicated -25 to 25
extreme.
[07:MIDI check]
Check the status of MIDI IN/OUT/THRU function.
[F3:MIDI IN/OUT] Feed MIDI signal to MIDI IN.
The display indicate the data which input
into MIDI IN and output the data from
MIDI OUT.
Confirm the data which output from MIDI
OUT is as same as the input data.
[F4:MIDI THRU] Feed MIDI signal to MIDI IN.
The display indicate the data which input
into MIDI IN and output the data from
MIDI OUT by hardware through from
MIDI IN.
Confirm the data which output from MIDI
OUT is as same as the input data.
[08:A/D D/A check]
Test A/D and D/A in order to find wrong connection or etc.
[F3:FS Select] 48,44.1,32KHz
Select the sampling rate at A/D and D/A
stages
[F4:Peak ModeSel]
Clip(0dB), Peak(-3dB), Sence(-20dB),
0(---dB)
Set the LED lighting conditions at the
peak point.
[F5:R-DAC Mode] MASTER, MT-PRO, MT-1, MT-2, Liv1,
Liv2
R-DAC processed sound is output to all
OUT.
[F6:MUTE] Off, ON
Mute all of output signals.
Analogue input 1-8 send signals to analogue output 1-8
respectively.
The signals from analogue input 7 and 8 are also sent to
DIGITAL OUT.
[09:Digital IN check]
Test Digital IN in order to find wrong connection or etc.
[F3:Input Sel] 1ch(Cx), 2ch(Op)
Select the output of Cox and Opt.
[[F5:R-DAC Mode] MASTER, MT-PRO, MT-1, MT-2, Liv1,
Liv2
R-DAC processed sound is output to all
OUT
Test DIGITAL IN.
Connect DIGITAL IN socket to DIGITAL OUT of your CD player
or etc. and play song.
When the signal is received correctly and locked, the display will
show "Lock" message, current FS, Emphasis(EMP), Copy
graph(CPY) and Category(xxH). If the signal isn't received
correctly and unlocked,"Unlock" message will be appeared on
the display.
The input signals from DIGITAL IN are sent to all of analogue
output and also sent to DIGITAL OUT with the same flags (FS,
CPY, EMP) as they received.
[10:Digital OUT check]
Test Digital OUT in order to find wrong connection or etc.
[F3:FS Select] 48,44.1,32KHz
Select the sampling rate at Digital OUT.
Sep, 1998
VS-1680
9
[F4:Emphasis] Off, On
Set the Emphasis flag of DIGITAL OUT.
[F5:Copy] Off, On
Set the Copy flag of DIGITAL OUT.
[F6:MUTE] Off, ON
Mute all of output signals.
Test DIGITAL OUT.
Send the signals that are input to analogue 7 and 8 to DIGITAL
OUT (1ch, 2ch) and also send to analogue output(7ch, 8ch).
[11:Sin Wave check]
( FACTORY ONLY TEST.NOT USE SERVICE. )
Test the analogue D/A by SIN wave from DSP in order to find
wrong connection or etc.
[F3:FS Select] 48,44.1,32KHz
Select the sampling rate at Sin wave
output stages.
[F4:Sin Freq] 100-900(100HzStep) 1K-10K(1KHzStep)
Select the Sin wave frequency.
[F5:Sin Level] 0Fh-7Fh
Set the output level of Sin wave.
[F6:MUTE] Off, ON
Mute the output from Sin wave.
Output Sin wave.
Sin wave is sent to all analogue output and DIGITAL OUT.
[12:SCSI check]
This is a test for SCSI in order to find wrong connection, chip
defect or etc.
[F3:Check Start] Test SCSI (External, Internal).
Connect a disk drive unit to SCSI socket.
When this test is selected, perform
initialization of SCSI chip and read/write
the date from/into the connected SCSI
device.
The drive unit must have been formatted
on VS-1680.
The display will show "OK!" message
when the test is successful, if not "Err"
message will be appeared on the
display.
[13:IDE check]
Test IDE in order to find wrong connection or etc.
[F3:Check Start] Test IDE.
Install a disk drive unit into front panel
expansion slot (if not installed).
Execute read/write procedure from/into
the connected IDE. The drive unit must
have been formatted on VS-1680.
The display will show "OK!" message
when the test is successful, if not "Err"
message will be appeared on the
display.
[14:RTC check]
Set the internal clock.
[F3:TIME Edit] Set the time of the internal clock.
[F4] and [F5] buttons function as (Left)
and (Right) cursor in the edit menu.
Move the cursor and edit the values by
TIME/VALUE dial.
To select the value press [F6](Store).
To cancel the performance press [F3]
(Cancel).
[F6:Get MIDI] Set the internal clock by the data from
MIDI.
[15:FAN check]
This is a test for FAN control to see whether it functions
correctly.
[F3:FAN ON/OFF] Off, On
FAN is switched ON/OFF alternatively
whenever it selected.
The display shows FAN condition.
[16:DSP GA check]
( FACTORY ONLY TEST.NOT USE SERVICE. )
This is a test for DSP GA function and memory in order to find
any wrong connection or etc.
[F3:FS Select] 48,44.1,32KHz
Select the sampling rate at the test.
[F4:Peak ModeSel]
Clip(0dB), Peak(-3dB), Sence(-20dB),
0(---dB)
Set the LED lighting conditions at the
peak point.
[F6:Memory Check]
Test the memory of the high speed S-
RAM which used in DSP GA.
[17:VS8F-2 check]
This is a test for the option board (VS8F-2), ESP and DSP in
order to find any wrong connection, chip defect or other
problems.
[F3:VS8F-2] Test the connection between VS-1680
and VS8F-2 and also test the VS8F-2
internal functions.
To start the test install VS8F-2 to the
option connector A and B on VS-1680
then select the test menu.
The display will show "OK!" messages
from both of connector A and B when
the test is successful, if not "Err"
message will be appeared on the
display.
[F4:ESP Check] Test the connection of ESP and ESP
internal functions.
To start the test select this item.
The display will show "OK!" message
when the test is successful,if not "Err"
message will be appeared.
[F5:DSP Check] Test the connection of DSP.
To start the test select this item.
The display will show "OK!" message
when the test is successful, if not "Err"
message will be appeared.
■ESP check error codes
01 ESP busy error ESP 2 chip may be defective
02 ESP program RAM error ESP 2 chip may be defective
04 ESP internal RAM error ESP 2 chip may be defective
08
ESP communications RAM error
ESP 2 chip may be defective
10 ESP flag error ESP 2 chip may be defective
40 ESP wiring error ESP 2 may be loosely connected
(poor soldering, etc.)
These error codes are expressed in hexadecimal.
Two or more errors may occur at a time and corresponding
error code will appear.
Examples: 11: Busy error and flag error
06: Program RAM error and internal RAM error
0c:
Internal RAM error and communications RAM error
■VS8F-2 check error codes
01 SRAM wiring error Loose connection of SRAM
(poor soldering, etc.)
02 ESP wiring error Loose connection of ESP 2
(poor soldering, etc.)
TEST MODE ERROR CODE
VS-1680
Sep, 1998
10
04 ESP program RAM error ESP 2 chip may be defective
08 ESP internal RAM error ESP 2 chip may be defective
10
ESP communications RAM error
ESP 2 chip may be defective
20 ESP external RAM error Loose connection of DRAM
(poor soldering, etc.)
40 ESP flag error ESP 2 chip may be defective
These error codes are expressed in hexadecimal.
Two or more errors may occur at a time and corresponding
error code will appear.
Examples: 11:
SRAM wiring error and ESP communications RAM error
06:
ESP wiring error and ESP communications RAM error
0c:
ESP program RAM error and ESP internal RAM error
The VS-1680 features an internal clock. The internal clock is
battery-powered.
Re-setting of time and date will be required when the battery is
changed.
1. Press [PLAY (DISPLAY)].
2. Hold down [SHIFT] and press [F5(SYSTEM)]. The System
menu icon is displayed.
If the system menu icon does not appear press [F6(EXIT)].
3. Press [F2(DATE)]. If "DATE" does not appear in [F2], first
press [PAGE] until "DATE" is displayed then press
[F2(DATE)]
4. To move cursor and set the each value press [
^
], [v], [<] or
[>].
Refer to the displayed calendar shown on the display.
Date Edit
Set year, month and date by the Christian era.
Date Format
Select the way of indicating year, month and date.
mm/dd/yyyy: month/date/year
dd/mm/yyyy: date/month/year
yyyy/mm/dd: year/month/date
mmm.dd,'yy: month/date/year
dd mmm 'yy: date/month/year
Time Edit
Set the current time by 24 hours.
5. When year, month, date and time are set, press [F4(Set)]
with the time signal.
From that moment, the clock start counting time.
6. Press [PLAY(DISPLAY)] to back to the initial display.
The latest system software of the VS-1680 is stored to the floppy
disks named "VS-1680 System Ver.1.xx SMF" as the standard
MIDI file format (SMF format).
Check the following SMF's included to the floppy disks.
VS-1680 System Ver.1.xx SMF disk 1 VS-1680 System Ver. 1.xx SMF disk 2
VS168001. MID VS168005. MID
VS168002. MID VS168006. MID
VS168003. MID VS168007. MID
VS168004. MID VS168008. MID
VS-1680 System Ver. 1.xx SMF disk 3 VS-1680 System Ver. 1.xx SMF disk 4
VS168009. MID VS168013. MID
VS168010. MID VS168014. MID
VS168011. MID VS168015. MID
VS168012. MID VS168016. MID
Update VS-1680 system software by following the procedure
described below.
1. Connect a MIDI cable between two connectors; MIDI OUT
connector of the MIDI Sequencer that can play back SMF
data and MIDI IN connector of VS-1680. It is convenient to
use the MIDI Sequencer such as an SB-55 sound brush
that can play back some SMF's continuously.
2. While holding down [TRACK SELECT] and [STATUS] on
the CH7, turn on the VS-1680's power.
3. A message "SYSTEM Update?" will be displayed. Press
[YES].
4. Check a message "Waiting MIDI-EX" is displayed, play
back all SMF data from "VS-168001. MID" to "VS-168016.
MID" in order.
5. After finish playing back all SMF's, a message "Update
SysPRG?" will be displayed.
Press [YES].
6. A message "Please Reboot OK" will be displayed. The
system software of your VS-1680 was already updated.
Restart the VS-1680.
To update the VS-1680 using the disk, follow the procedure
described below.
Note that if the version of the disk is identical to that of the VS-
1680, no updating is possible. Rather, the unit simply operates in
the play conditions.
1. Connect a zip drive to VS-1680 through the SCSI cable.
Turn on Zip drive.
2. Insert the disk into the zip drive.
3. Turn on VS-1680.
4. The message "System Prog Load Now working ..."
appears indicating the start of updating.
5. [Fig.1] is displayed. When the updated data is correct,
press YES button.
SETTING THE INTERNAL CLOCK
VS-1680 SYSTEM SOFTWARE UPDATE USING THE SMF
SYSTEM SOFTWARE UPDATE USING ZIP DISK
Sep, 1998
VS-1680
" -- Updete System Program ? -- "
" Ver.1.xxx ( Btver1.00 ) "
[ YES ] / [ NO ]
Fig.1
" -- Keep User Setting ? -- "
" [ EZ ROUTING User Routing ] "
" [ EFFECT User Patch ] "
" [ ARARM User Data ] "
" [ NO ] is Init User Seeting "
[ YES ] / [ NO ]
" -- Init User Setting Sure ? -- "
" [ EZ ROUTING User Routing ] "
" [ EFFECT User Patch ] "
" [ ARARM User Data ] "
[ YES ] / [ NO ]
Fig.2 Fig.3
11
6. [Fig.2] is displayed. If the user date is required to be
saved,press [YES] button.
If [NO] button is pressed, [Fig.3] is displayed.
If it is OK, press [YES] button.
7. The message "Now Working ..**" appears indicating the
start of count down.
When the message ""Please Reboot OK" appears and
LEDs on the VS-1860 are flashing, the updating procedure
is completed. Turn off VS-1680.
8. Remove the zip disk and turn off the zip drive. Remove the
SISI cable.
If it is necessary to replace a PCB on the user VS-1680, save
the user system parameters and Effect user patches onto a
sequencer or equivalent storage.
Load back the data onto the VS-1680 after it has been fixed.
■Send the parameters through MIDI OUT
1. Pressing CH7 "TRACK SELECT" and STATUS and F5
SYSTEM button simultaneously, turn on POWER switch on
VS-1680.
2. The message "Send SysPrmMIDI?" is displayed. Press
"YES" button and the system parameters are sent in MIDI
exclusive format.
■Restore the system parameters
To receive the system parameters & write it to Flash, refer to the
chapter [VS-1680 SYSTEM SOFTWARE UPDATE USING THE
SMF] in this service note.
Depending on the receiving method, the displays will look
different on the LCD.
For example, when "-P-" and prompt "Update SysPRM/" are
displayed, press [YES] button to write only the system
parameters into the flash memory.
A Zip drive (ZIP-EXT-S2) can be connected to the SCSI connector
of the VS-1680 and save song data which created on VS-1680.
Equipment: VS-1680
Zip disk
Zip drive (ZIP-EXT-2S)
SCSI connector
Connecting the Zip Drive
Connect the Zip drive to the VS-1680 as below.
About connector:
●VS-1680 uses SCSI connector; D-sub type, pin25 (female). To
connect the cable correctly, please confirm the form of the
SCSI connector of the disk drive to be connected.
●Keep SCSI cable as short as possible, and use only cables
which have an impedance (110 ohms +/- 10%) that is
compatible with the SCSI standard, and are completely shield.
●Do not allow the total length of all SCSI cables connecting the
chain of disk drives to exceed 6.5 meters.
●Do not connect or disconnect SCSI cables when the power of
any device is turned on.
Turning power on.
1. Turn on the power to the Zip drive.
2. Turn on the power to the VS-1680 with the POWER switch
on the rear panel.
A new disk just purchased at your computer store or a disk that
was used by another device cannot be used on the VS-1680 as is.
You must initialize the disk by VS-1680 so that it can be used by
the VS-1680.
When a disk is initialized, the entire contents are irretrievably
lost.
Check any such disk you plan to initialize to make sure that it
does not contain anything that you don't want deleted.
If you are using a drive or disk that has been partitioned, please
note that you will not be able to choose a particular partition that
you wish to initialize.
When you carry out a drive initialization, the whole drive and all
its partitions will be initialized at once.
■Initializing new Zip disks.
1. Confirm that power to the Zip drive and the VS-1680 is
turned on.
2. Insert a disk into the Zip drive.
3. Press [PLAY (DISPLAY)]
4. Hold down [SHIFT] and press [F6 (UTILITY)].
The Utility menu icon appears in the display.
5. Press [F6 (DrIni)]. If "DrIni" does not appear in [F6], first
press [PAGE] until "DrIni" is displayed, then press [F6
(DrIni)].
6. Use [
^
], [v], [<], and [>] to move the cursor. Rotate the
TIME/VALUE dial to make each of the values settings.
■Init Drive (Initialize Drive):
Select the disk drive (IDE, SCSI0~SCSI7). "IDE" indicators
internal hard disks, and "SCSI0~SCSI7" (these are SCSI ID
numbers) indicate external hard disks.
For example, select "SCSI5" when selecting the Zip drive
connection.
■Partition:
Select the partition size (500 MB, 1000 MB, or 2000 MB).
In normal circumstances, select "2000 MB."
■Physical Format:
Select whether or not to use physical formatting. For new disks
or disks that have been used by another device, select "On.
"For new hard disks or when formatting disks for Windows or
Macintosh platforms, select "Off."
■Surface Scan:
This confirms that the read and write functions in all of the disk
drive's partitions
are operating correctly when the drive is initialized.
In normal circumstances, set this to "Off.
"When you particularly want to conduct a test of the read/write
functions, the set this to "On."
At this time, the function buttons work as shown below.
[F1 (DrSel)]: This displays a directory of the currently
connected drives.
Use [
^
], [v], [<], and [>] to select the drive that you want to
initialize.
[F3 (Info)]: Displays the drive information.
[F4 (Exec)]: Executes initialization of the selected drive.
[F6 (EXIT)]: Exits the screen.
7. When the settings are made, press [F4 (Exec)].
"Init. *****, OK?" appears in the display. "*****" refers to the
drive's SCSI ID number.
For example, "SCSI5" indicates a Zip drive.
8. Press [YES].
"Init *****, Sure?" (Really initialize the disk?) appears in the display.
9. Press [YES].
"STORE Current?" (Store the current song?) appears in
the display.
SAVING AND LOADING DATA OF INTERNAL HDD
VS-1680
Sep, 1998
SAVING SYTEM PARAMETERS
SCSI cableSCSI cable
VS-1680 Zip drive
INITIALIZING THE DISK (DRIVE LNITIALIZE)
12
10. If you wish to save the current song, press [YES]; if not,
then press [NO].
If you have selected a demo song, then press [NO].
11. After the initialization is completed correctly, the VS-1680
restarts automatically, and you are returned to Play
condition.
* Be aware that initializing a drive requires some time. This is
not a malfunction.
For example, when physical formatting is turned on, the time
required to format one Zip disk is approximately 10 minutes.
The progress of initialization will be shown in the display.
Be sure not to turn the power off until initialization is complete.
There are two ways to carry out the Song Copy procedure.
Select the method you will use based on the amount of free
space on the destination disk (100 MB for Zip disks).
The amount of memory used on the disk is shown in the display.
Playable: Use this method to copy songs that use
relatively little data onto disks with sufficient
memory to hold them.
If the destination drive or disk already has song
data saved on it, then you can copy additional
songs that will fit within the remaining free
space.
Archive: Use this method to copy songs that are too large
to be saved on a single disk.
The song data is converted into a data format
specifically for saving (archive format), and is
copied onto multiple disks according to the free
space on the disks.
This means that it will not be possible to directly
play back the song data.
If you wish to play back song data copied in
archive format, you will need to reload the
archive data into the current drive using the
appropriate procedure.
Furthermore, song data cannot be copied onto
disks that already have songs recorded on them.
■Saving a Song to a Single Disk (Playable)
Save a playable copy of a song on the VS-1680's internal hard
disk to a Zip drive which is set to SCSI ID Number 5.
1. Select the disk containing the source song you want to
copy as the current drive.
2. Press [PLAY(DISPLAY)]
3. Hold down [SHIFT] and press [F1 (SONG)]
The Song menu icon appears in the display.
4. Press [F1 (CP PL)]. If "CP PL" does not appear in [F1],
first press [PAGE] until "CP PL" is displayed, then press
[F1 (CP PL)].
5. Press [<] and [>] to move the cursor to "Source Song."
6. Use the TIME/VALUE dial to move the cursor to the song
you want to copy and press [F3 (MARK)]. By pressing [F2
(ALL)], you can place and remove Markers from all of the
songs.
In addition, you can press [F1 (SelSg)] to display a
directory of the songs.
At this point, after you have placed a Marker at the song
you want, press [F1 (Back)].
7. Press [>] to move the cursor to "Destination Drive."
8. Use the TIME/VALUE dial to select the destination drive
and partition.
You can press [F5 (SelDr)] to display a directory of drives.
At this point, use [
^
], [v], [<], and [>] to select the
destination drive, and select the destination partition with
the TIME/VALUE dial.
Once you have selected the destination drive, press [F1
(Back)].
9. If the source and destination drives are different, press [v].
Move the cursor to "Erase All Songs" with the
TIME/VALUE dial.
* Erase All Songs
When this is set to "On," the copy procedure is carried
out after the destination drive is initialized.
If you want to perform the copy procedure leaving songs
already saved in the destination drive as they are, then
set this to "Off."
10. Press [F4 (Exec)].
A message asking if you want to continue appears in the
display.
11. Press [YES].
"STORE Current?" (Store the current song?) appears in
the display.
12. If you wish to save the current song, press [YES]; if not,
then press [NO].
If you have selected a demo song, then press [NO].
13. When copy is completed, the Song menu icon appears in
the display.
Press [PLAY (DISPLAY)].
Return to Play condition.
NOTE: If "Disk Memory Full" Appears in the Display
This indicates that the destination disk has insufficient
free space, or that the number of songs on the disk
has exceeded the maximum number (200 songs) that
can be stored on the disk, and that the copy
procedure was canceled.
However, you can still use the song data copied up to
that point.
■To Load Data from Disks
Use the following procedure to take playable songs that have
been copied to Zip disks and load them onto the VS-1680's
hard disk.
Switch the current drive to Zip drive (Drive Select).
Then perform playable copy from Zip drive to the internal hard
disk drive.
* The original song is not overwritten by performing these
procedures if the original song that copied from the internal
hard disk to Zip disk is not erased from the internal hard disk.
In that case, a new song which has the same name as the
original one will be create in an available earliest song
number.
1. Confirm both power of Zip drive and VS-1680 are turned
on.
2. Insert the disk containing the song you want to load into
the Zip drive.
3. Press [PLAY (DISPLAY)].
4. While pressing [SHIFT] press [F6 (UTILITY)]. The utility
menu icon is appeared on the display.
5. Press [F4 (DrSel)]. If "DrSel" does not appear on [F4], first
press [PAGE] to show "DrSel" then press [F4 (DrSel)].
Table of the current connected drive will be shown on the
display.
6. To move cursor, press [
^
], [v], [<] or [>]. Select the drive
you wish to switch.
To select the partition which you wish to switch, rotate the
TIME/VALUE dial.
At this time, the function buttons works as described below.
[F3 (Info)] : Indicate the drive information.
[F4 (Exec)] : Execute drive select.
[F6 (EXIT)] : Exit from the menu.
7. After select drive/partition press [F4 (Exec)].
8. A confirming message is appeared on the display. Press
[YES].
9. "STORE Current?" (Save the current song?) message is
appeared on the display.
If you wish to save the current song press [YES], if not
press [NO].
When the demo song is selected press [NO].
10. When the current drive is switched song menu icon is
displayed.
Press [PLAY (DISPLAY)].
Return to play condition.
11. Make a playable copy of the song from the Zip disk onto
the VS-1680's hard disk, as described in "Saving a Song to
a Single Disk."
Sep, 1998
VS-1680
SAVING PERFORMANCE DATA TO A ZIP DRIVE (Song Copy)
13
12. When playable copy is completed, repeat the procedures 3
to 10 and select the internal hard disk as a current drive.
■When You Cannot Save a Song to a Single Disk
Handling of Archive Copy Disks
To save songs in archive format, the destination disk must be
initialized.
This initialization procedure differs from the usual Drive
Initialize formatting.
This procedure lets you carry out Archive Copy with newly
purchased disks, disks which previously have been used with
a personal computer or other device, or other disks which have
not been formatted with Drive Initialize.
However, any song data saved to the disk is lost once the
Archive Copy procedure is performed.
Additionally, you cannot designate a disk containing archive
format songs as the current drive.
If you try to do this, the disk is identified as being an
{uninitialized disk}.
■Saving to Disks (Store)
1. Make the drive containing the song you want to load the
current drive.
2. Press [PLAY (DISPLAY)]
3. Hold down [SHIFT] and press [F1 (SONG)].
The Song menu icon appears in the display.
4. Press [F2 (AC Str)]. If "AC Str" does not appear in [F2],
first press [PAGE] until "AC Str" is displayed, then press
[F2 (AC Str)].
5. Press [<] to move the cursor to "Source Song."
6. Songs that are marked are copied.
Use the TIME/VALUE dial to move the cursor to the song
you want to copy and press [F3 (MARK)].
By pressing [F2 (ALL)], you can place and remove Markers
from all of the songs.
In addition, you can press [F1 (SelSg)] to display a
directory of the songs.
At this point, after you have placed a Marker at the song
you want, press [F1 (Back)].
7. Press [>] to move the cursor to "Destination Drive."
8. Use the TIME/VALUE dial to select the destination drive
and partition.
Press [F5 (SelDr)] to display a directory of drives.
At this point, use [
^
], [v], [<], and [>] to select the
destination drive, and press [F1 (Back)].
9. Press [F4 (Exec)].
A message asking if you want to continue appears in the
display.
10. Press [YES].
"STORE Current?" (Store the current song?) appears in
the display.
11. If you wish to save the current song, press [YES]; if not,
then press [NO].
If you have selected a demo song, then press [NO].
* All data saved on the Zip disk will be deleted.
Do not use any Zip disk containing song data that you need.
12. If the song holds a large amount of data, and cannot be
contained on a single Zip disk, the disk is ejected, and the
message "Please Insert Disk" appears in the display.
Insert the next disk and press [YES].
At this time, be sure to write the disk numbers on the labels
so that you can keep track of the order in which the disks
were inserted into the drive.
13. When copying over multiple Zip disks, "Insert Disk #" (#
indicates the number in the order of insertion) appears in
the display.
Insert each of the disks once more in the proper order and
press [YES].
14. When the Archive Store procedure is finished, the Song
menu icon appears in the display.
Press [PLAY (DISPLAY)].
Return to Play condition.
■Loading Data From Disks (Extract)
1. Make the drive containing the song you want to copy the
current drive.
2. Press [PLAY (DISPLAY)]
3. Hold down [SHIFT] and press [F1 (SONG)].
The Song menu icon appears in the display.
4. Press [F3 (AC Ext)]. If "AC Ext" does not appear in [F3],
first press [PAGE] until "AC Ext" is displayed, then press
[F3 (AC Ext)].
5. Press [
^
] to move the cursor to "Source Drive."
6. Use the TIME/VALUE dial to select the drive containing the
source you want to load.
By pressing [F1 (SelDr)], you can display a directory of
drives.
At this point, use [
^
],[v],[<], and [>] to select the source
drive,and press [F1(Back)].
7. Songs that are marked are copied.
Use the TIME/VALUE dial to move the cursor to the song
you want to restore and press [F4 (MARK)].
By pressing [F3 (ALL)], you can place and remove Markers
from all of the songs.
In addition, you can press [F2 (SelSg)] to display a
directory of the songs.
At this point, after you have placed a Marker at the song
you want, press [F1 (Back)].
8. Press [F5 (Exec)].
A message asking if you want to continue appears in the
display.
9. Press [YES].
"STORE Current?" (Store the current song?) appears in
the display.
10. If you wish to save the current song, press [YES]; if not,
then press [NO].
If you have selected a demo song, then press [NO].
11. A confirmation message is displayed asking if you want to
perform the Drive Initialize procedure on the disk to which
the data will be loaded.
If you want the song data to loaded after the drive is
initialized, press [YES].
If you do not wish to initialize the drive, the press [NO].
* If you press [YES] at this point, any data stored on the
destination drive is lost.
In normal circumstances, press [NO].
If there is insufficient free space on the drive, then after first
backing up the data on the disk to which you will load the
data, press [YES].
12. Execute the load.
When copying over multiple disks, "Insert Disk #" (#
indicates the number in the order of insertion) appears in
the display.
Insert the next disk and press [YES].
13. When the Archive Store procedure is finished, the Song
menu icon appears in the display.
Press [PLAY (DISPLAY)].
Return to Play condition.
■Turning power off
1. Turn the power of VS-1680 off.
2. Take Zip disk from Zip drive.
3. Turn the power of Zip drive off.
4. Disconnect SCSI connector.
VS-1680
Sep, 1998
14
1.Remove the knobs from the front panel: (a), (b) (13 slider
knobs and 10 round knobs).
Remove the top panel A(c): slide in a flat blade tool e.g. tip
of a screwdriver below the top panel and then carefully lift
the panel.
Notes: 1) Main board cannot be removed before the top
panel A(c) is removed.
2) Once the panel is removed, keep adhesive
surfaces away from dusts.
3) Replacement top panel A(c) available from
Roland service representative.
2.Turn over the body (d) and remove the bottom cover (f) by
removing 16 screws.
3.Remove CN2 and CN3 and MIDI board by removing
corresponding 4 screws.
4.Remove screws: 2 from main board, 6 from rear panel, 2 (g
and h) from switching regulator. Remove the rear panel (i)
together with the switching regulator, fan, main board,
digital I/O board. To do this, slightly shift the main board to
disengage it from notches (marked * in the figure).
5.Remove screws (j) and (l) and then the air guide (k) and
MIDI board (m) from the rear panel.
6.Remove screws (n), (o) and (p) and then main board (q)
from the rear panel (r).
7.Install the repaired or new main board by first engage it
with notches (*). Repeat steps 1 to 6 in the reverse order.
After attaching the top panel A(c), evenly depress the
surface using soft cloth for tight adhesion.
Sep, 1998
VS-1680
EXCHANGE THE MAIN BOARD
1 2 3 4 5 6 7 8 9 10111213141516171819202122232425262728
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U15
CIRCUIT BOARD
MAIN BOARD ASSY (71015356)
View from component side.
VS-1680
Sep, 1998
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
16
MAIN BOARD ASSY (71015356)
View from foil side.
VS-1680
Sep, 1998
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
Sep, 1998
17
VS-1680
PANEL BOARD ASSY (70897023)/DIGITAL I/O BOARD ASSY (71011289)
/MIDI BOARD ASSY (70906756)
DIGITAL I/O BOARD ASSY
(71011289) MIDI BOARD ASSY
(70906756)
PANEL BOARD ASSY (70897023)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
VS-1680
Sep, 1998
18
LCD CONTRAST BOARD ASSY (71015967)
/CONNECTOR BOARD ASSY (70905967)
View from component side. View from foil side.
LCD CONTRAST BOARD
ASSY (71015967)
CONNECTOR BOARD
ASSY (70905967) LCD CONTRAST BOARD
ASSY (71015967) CONNECTOR BOARD
ASSY (70905967)
Sep, 1998
VS-1680
19
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
29 30 31 32 33 34 35 36 37 38 39 40 41 42
V
W
X
Y
Z
10000/6.3V
C108
+
R95
0.1(2W)
B4B-XH-A
CN3
4
3
2
1
after 2Lot.
This Circuit is
VCC
10K
R69
C10
100/6.3V(ECEV)
+
-15V
C107
0.1
R89
22K
0.1
C106
FL5 N2012Z-121
FL4 N2012Z-121
N2012Z-121FL3
FL2 N2012Z-121
C11 100/6.3V(ECEV)
+
C12
220/16V(HW)
+
22KR85
22KR86
R87 22K
22KR88
R76 0
IC12
TC551001BFL-70L
NC1
A15
A14
A13
VSS
OE
CS2
A4
A2
A0
A3
A5
A6
A7
A8
A9
A10
A11
A1 D0
D1
D2
D3
D4
D5
D6
CS1
D7
WE A16
VCCA12
432
229
21
22
20
19
18
17
15
14
13
11
25
23
26
27
5
6
7
9
12
10
8
30
24
16
28
3
31
1
IC10
TMS417809-60DZ
D7
A9
A0
A1
A2
A3
A4
A5
A6
A7
A8
D0
D1
D2
D3
D4
D5
D6
VCC_1
VCC_2
VSS_1
VSS_2
CAS
OE
RAS
WE
A10 NC
27
21
10
11
12
13
16
17
18
19
20
2
3
4
5
24
25
26
1
14
15
28
23
22
7
6
98
IC43
TC7W74FU
S
RQ
QD
C
1
25
3
67
IC44
TC7WU04FU
35
IC44
TC7WU04FU
71
TC7W08FUIC45
6
53
TC7W08FUIC45 7
1
2
IC48
TC7W14FU
53
IC48
TC7W14FU
62
TC7W14FU
IC48 71
R71 22K
0.001
C104
0.1
C94
TC7SH32FU
IC61 4
2
1
VHC393
IC60
CK
QD
QC
QB
QA
CLR
12
11
10
9
8
13
VHC393
IC60
CK
QD
QC
QB
QA
CLR
1
6
5
4
3
2
TC7SH32FU
IC55 1
2
4
IC18
VHC393
CK
QD
QC
QB
QA
CLR
12
11
10
9
8
13
TC7SH00FU
IC58 1
2
4
VHC393
IC52
CK
QD
QC
QB
QA
CLR
13
8
9
10
11
12
TC7SH04FU
IC51 42
TC7SH04FU
IC50
24
VCC
GND
+5V
X1
MA-406(10MHZ)
14
VCC
C51
100/6.3V(ECEV)
+
C25
100/6.3V(ECEV)
+
C14
100/6.3V(ECEV)
+
100/6.3V(ECEV)
C6
+
4
8
IC3
UPC4062
+
-
3
21
ID1
ID10
ID10
ID0
ID15
ID14
ID1
ID13
ID2
ID12
ID3
ID11
ID4
ID7
ID[0:15]
ID8
ID6
ID9
ID5
ID15
ID12
ID11
ID9
ID8
ID0
ID3
ID7
ID6
ID5
ID4
ID13
ID14
ID2
BOARD_IN8
CN2
8
7
6
5
4
3
2
1
S
CP1
CP2
DISP
D0
D1
D2
D3
IC3
UPC4062
+
-7
6
5
0.1
C1
IC4
M51953AFP
NC
NC
NC
NC
RESET
CD
VCC
G
8
3
2
1
4
7
56
0.001
C15
TO MIDI
VCC
VR1
EVUJF8FL3B54(50KB)
1
2
3
SS0
SS1
SS2
SS3
SSEN
LLCK
LS0
LS1
LS2
LS3
ADSC0
ADSC1
ADSC2
AN0
AN1
SELECT
MIDIOUT
GND
RESET
+5V
B6B-PH-K-S
CN1
1
2
3
4
5
6
MIDIIN
-15V
GND
+12V
+5V
GND
+5V
GND
+12V 12P
C40
A3
A2
A1
A21
A20
A19
A18
A17
A16
A15
A14
A13
A12
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A1
A0
A4
A3
A2
A1
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A20
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A1
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A1
A19
A18
A17
A16
A15
A14
A13
A12
A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A21
A21
A20
A19
A5
A4
A3
A2
A1
A0
A20
A0
A[0:21]
VDD
GND
C16
0.001
C17
0.001
0.001
C19
0.001
C18
0.001
C23
0.001
C24
C22
0.001
C21
0.001
C20
0.001
TO PANEL
VCC
GND
GND
+5V
+5V
C38
0.001
C37
0.001
0.001
C36
C34
0.001
VCC
10KX8
RA8
6
10
9
8
7
5
4
3
2
1
C35
0.001
0.001
C33
0.001
C32
0.001
C31
C30
0.001
TO PANEL +5V
VCC
GND
PD0
PD1
PD2
PD3
PD4
PD5
PD6
PD7
CN5
B15B-PH-K-S
1
10
11
12
13
14
15
2
3
4
5
6
7
8
9
C26
0.001 C27
0.001
0.001
C28
0.001
C29
RA12
47X4
8
7
6
54
3
2
1
47X4
RA11
1
2
3
45
6
7
8
IC9
TMS417809-60DZ
D7
A9
A0
A1
A2
A3
A4
A5
A6
A7
A8
D0
D1
D2
D3
D4
D5
D6
VCC_1
VCC_2
VSS_1
VSS_2
CAS
OE
RAS
WE
A10 NC 89
6
7
22
23
28
15
14
1
26
25
24
5
4
3
2
20
19
18
17
16
13
12
11
10
21
27
C54
0.1
IC16
NCR53CF96-2
CLK
WR
SELO
SELI
SDOP
SDO7
SDO6
SDO5
SDO4
SDO3
SDO2
SDO1
SDO0
SDIP
SDI7
SDI6
SDI5
SDI4
SDI3
SDI2
SDI1
SDI0
RSTO
RSTI
REQO
REQI
RD
MSGIO
INT
I/OIO
DIFFM
DBWR
DACK
CS
C/DIO
BSYO
BSYI
ATNIO
ACKO
ACKI
VSS_9
VSS_8
VSS_7
VSS_6
VSS_5
VSS_4
VSS_3
VSS_2
VSS_16
VSS_15
VSS_14
VSS_13
VSS_12
VSS_11
VSS_10
VSS_1
VDD_2
VDD_1
TGS
RESET
PAD7
PAD6
PAD5
PAD4
PAD3
PAD2
PAD1
PAD0
NC_6
NC_5
NC_4
NC_3
NC_2
NC_1
MODE1
MODE0 IGS
DREQ
DBP1
DBP0
DB9
DB8
DB7
DB6
DB5
DB4
DB3
DB2
DB15
DB14
DB13
DB12
DB11
DB10
DB1
DB0
A3
A2
A1
A0
53
78
89
39
28
3
87 6
4
75 72
71
69
70
73
29
30
31
32
33
34
35
36
37
27
19
20
21
22
23
24
25
26
60
61
67
68
94
95
79
52
51
50
49
48
45
44
43
42
80
62
76
64
2
1
81
63
65
54
47
46
41
40
18
17
7
55
5
88
38
77
99
98
97
96
93
92
91
90
100
16
15
14
13
12
11
10
9
8
85
84
83
82
66
57
56
58
59
74
86
0.1
C7
GND
GND
GND
+5V
IC6
VHC139
A
B
GY3
Y2
Y1
Y0 12
11
10
9
15
13
14
TO TOOL
VCC
CLK6.75MHZ
CLK27MHZ
VCC IC11
SED1335F0B
VCS
YSCL
XECL
XSCL
LP
WF
YDIS
XD3
XD2
XD1
NC_3
NC_2
SEL1
VWR
VD6
VD5
VD4
VD3
VD2
VD1
VA14
VA13
VA12
VA11
VA10
VA9
VA8
VA7
VA6
VA5
VA4
VA3
VA2
VA1
D0
D1
D2
D3
D4
D5
D6
D7
RD
WR
VA0
VA15
VD7
VRD
XG
XD
SEL2
VDD
NC_1
VD0
XD0
YD
CS
A0
RES
VSS
36
10
20
19
40
33
49
11
21
15
18
17
9
42
50
6
14
13
29
28
27
26
25
24
23
22
5
4
3
2
1
59
58
57
56
55
54
53
52
51
48
47
46
45
44
43
7
16
12
60
32
31
30
39
38
37
35
34
41
8
VCC
C46
0.1
VCC
0.1
C44
LH28F016SUT-70
IC8
NC_3
NC_2
NC_1
3/5
RY/BY
VCC_1
VCC_2
GND_3 CE0
A0
A1
A10
A11
A12
A13
A14
A15
A16
A17
A2
A3
A4
A5
A6
A7
A8
A9
D0
D1
D10
D11
D12
D13
D14
D2
D3
D4
D5
D6
D7
D8
D9
GND_1
VPP
BYTE RP
WE
WP
CE1
A18
GND_2
VCC_3 OE
A19
D15
A20 30
29
3
1
53
9
37
48 14
32
28
18
17
13
12
11
10
8
7
27
26
25
24
23
22
20
19
33
35
39
41
45
47
50
38
40
44
46
49
51
34
36
21
1531 16
55
56
2
6
42
43 54
5
52
4
VCC
VCC
VCC
DA0
DA1
CS1
P-XRESET
PORT-BUSS
CS-BUSS
CTRL-BUSS
ADRS-BUSS
DATA-BUSS
VCC
VCC
C50 0.1
VCC
C43
0.1
CN8
PS-50PE-D4T1-B1
40
39
38
37
36
35
32
25
24
23
22
21
19
17
13
11
9
8
7
6
5
4
3
2
1
10
12
14
15
16
18
20
26
27
28
29
30
31
33
34
41
42
43
44
45
46
47
48
49
50
+5VL
XRESET
BT_SEL
CS_BROM
A19
A18
A17
A16
A15
A14
A13
A12
A11
A10
A9
A8
A7
A6
A5
A4
A2
A1
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
D12
D13
D14
D15
A3
RDB
WRL
A0
A20
A21
VCC
FROM POWER
VHC245
IC14
A3
GND
A7
A6
A5
A4
A2
A1
A0
VCC
OE
DIR
B7
B6
B5
B4
B3
B2
B1
B0
5
10
9
8
7
6
4
3
2
20
19
1
11
12
13
14
15
16
17
18
VHC153
IC7
2G
1G
VCC
GND
B
A
2Y
2C3
2C2
2C1
2C0
1Y
1C3
1C2
1C1
1C0
6
5
4
3
7
10
11
12
13
9
14
2
8
16
1
15
VHC245
IC13
A3
GND
A7
A6
A5
A4
A2
A1
A0
VCC
OE
DIR
B7
B6
B5
B4
B3
B2
B1
B0 18
17
16
15
14
13
12
11
1
19
20
2
3
4
6
7
8
9
10
5
47X4
RA15
1
2
3
45
6
7
8
GND
VCC VCC
VCC
RA9 1KX8
6
10
9
8
7
5
4
3
2
1
VCC
VCC
GND
C90
0.1
VCC
C42
0.1
VCC
-DASP
-CS1
-CS0
DA2
DA0
-PDIAG
DA1
-IOCS16
INTRQ
-DMACK
CSEL
IORDY
-DIOR
-DIOW
GND
GND
DMARQ
(KEY)
GND
DD15
DD14
DD13
DD12
DD11
DD10
DD09
DD08
DD00
DD01
DD02
DD03
DD04
DD05
DD06
DD07
-RESET
C4
2.2/50V(ECEV)
+
VCC
0.1
C5
VCC
0.1
C89
VCC
10KX8
RA3
6
10
9
8
7
5
4
3
2
1
VCC VCC
RA2 10KX8
6
10
9
8
7
5
4
3
2
1
VCCVCC
VCC
10KX8
RA4
1
2
3
4
5
7
8
9
10
6
VCC
C48 0.1
C49 0.1
10KX8
RA1
1
2
3
4
5
7
8
9
10
6
RA7 10KX8
6
10
9
8
7
5
4
3
2
1
GND
GND
C91
0.1 C92
0.1
VCC
RA16
47X4
8
7
6
54
3
2
1
VCC
TO IDE
1KX8
RA10
6
10
9
8
7
5
4
3
2
1
VCC
VCC
VCC
+5V
+5V
+5V
GND
GND
GND
OPEN
+5VM
GND
XRESET
VCC
VCC
VCC
470P
C9
CS0
DA2
DIOR
DIOW
XRESET
VCC
VCC
C52
0.1
TO HDD
REQ
I/O
C/D
SEL
MSG
RST
ACK
BSY
GND
GND
GND
GND
GND
GND
GND
GND
GND
ATN
GND
GND
GND
GND
TERMPWR
N.C
GND
GND
GND
GND
GND
GND
GND
DBP
GND
DB6
DB4
DB3
DB2
DB1
DB0
GND
GND
GND
GND
GND
DB5
DB7
GND
GND
GND
GND
DBLC-J25SAF-20L9F JK1
1325
1224
1123
1022
921
820
719
618
517
416
315
214
1
C53
47/16V(ECEV)
+
D3
S2S6M
21
C55
47/16V(ECEV)
+
BH9595FP-Y
IC17
EN
NC
TSD
GND3
VDD1
GND1 T7
T8
T9
T10
T14
T13
T12
T11
T15
T16
T17
T18
T6
T5
T4
T3
T1
T2
GND2
VM
VDD2
2
1
25
27
13
716
17
18
19
23
22
21
20
3
4
5
6
15
12
11
10
8
9
26
24
14
VCC
DATA-BUSS
ADDRESS-BUSS
CONTROL-BUSS
P-XRESET
PORT-BUSS
CS-BUSS
XRESET
VCC
0.1
C41
VCC
C45
0.1
VCC
CN7
PS-50PE-D4T1-B1
40
39
38
37
36
35
32
25
24
23
22
21
19
17
13
11
9
8
7
6
5
4
3
2
1
10
12
14
15
16
18
20
26
27
28
29
30
31
33
34
41
42
50
49
43
44
45
46
47
48
+5V
GND
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
D7
D6
D5
D4
D3
D2
D1
D0
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
D15
D0
D1
D2
D3
D4
D5
D6
D7
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
D0
D7
D8
D9
D10
D11
D12
D13
D14
D15
D7
D8
D9
D10
D11
D12
D13
D14
D15
D6
D5
D4
D3
D2
D1
D0
D6
D5
D4
D3
D2
D1
D[0:15]
VD6
VD5
VD3
VD1
VD0
VD1
VD2
VD3
VD4
VD5
VD6
VD7
VD2
VD4
VD7
VD0
VD[0:7]
CLK27MHZ
VCC
GND 7
14
VCC
GND 8
16
RA13
47X4
1
2
3
45
6
7
8
RA14
47X4
8
7
6
54
3
2
1
I/O
REQ
C/D
SEL
MSG
RST
ACK
BSY
ATN
SDP
SD7
SD6
SD5
SD4
SD3
SD2
SD1
SD0
SD[0:7],SDP,RST,BSY,SEL,I/O,C/D,MSG,REQ,ACK,ATN
SD3
SD1
SD0
MSG
C/D
I/O
ATN
SEL
BSY
REQ
ACK
RST
SDP
SD7
SD6
SD5
BSY
ATN
REQ
MSG
C/D
I/O
SEL
RST
SDP
SD7
SD6
SD5
SD4
SD3
SD2
SD1
SD0
SD0
SD1
SD2
SD3
SD4
SD5
SD6
SD7
SDP
BSY
ACK
RST
SEL
REQ
ACK
SD4
SD2
SD6
SD5
SD4
SD3
SD2
SD1
SD0
SDP
SEL
BSY
ACK
ATN
RST
I/O
C/D
MSG
REQ
SD7
CS_EXT
B14B-PH-K-S
CN4
14
12
10
1
2
3
4
5
6
7
8
9
11
13
M60205-0601FP
IC5
PWM1
A0
A1
A19
A2
A20
A21
A3
A4
A5
CKIN
CKOUT
D0
D1
D2
D3
D4
D5
D6
D7
ENCA
ENCB
LD0
LD1
LD2
LD3
LD4
LD5
LD6
LD7
LE
LLCK
LS0
LS1
LS2
LS3
MIDIIN
PD0
PD1
PD2
PD3
PD4
PD5
PD6
PD7
PORT0
PORT1
PORT2
PORT3
PORT4
PORT5
PORT6
PORT7
RS
RXW
SS0
SS1
SS2
SS3
SSEN
VDD_1
VDD_2
VDD_3
VDD_4
VSS_1
VSS_2
VSS_3
VSS_4
VSS_5
VSS_6
CS2
CS4
CS6
EC0
EC1
EC10
EC11
EC2
EC3
EC4
EC5
EC6
EC7
EC8
EC9
EXINT0
EXINT1
EXINT2
RD
RESET
WAITIN
WAITOUT
WRHO
WRLO
XIREQ
XWRH
XWRL
XDACK
XLCDREQ
PWM2 3
31
32
36
35
24
5
4
37
25
26
34
58
57
56
51
50
49
48
47
46
45
44
55
54
43
42
41
39
38
80
53
40
33
28
1
79
52
29
2
70
74
73
72
71
91
90
66
65
64
63
62
61
60
59
89
88
87
86
85
84
83
82
6
78
77
76
75
81
92
100
99
98
97
96
95
94
93
69
68 14
13
12
11
10
9
8
7
30
27
20
19
18
23
22
17
21
16
15
67
GND
VDD
PS-50PE-D4T1-B1 CN9
50
49
48
47
46
45
44
43
42
41
34
33
31
30
29
28
27
26
20
18
16
15
14
12
10
1
2
3
4
5
6
7
8
9
11
13
17
19
21
22
23
24
25
32
35
36
37
38
39
40
SCSI
CONECTOR
TO DRIVE
POWER
CLK6.75MHz
RA6 10KX8
1
2
3
4
5
7
8
9
10
6
RA5 10KX8
6
10
9
8
7
5
4
3
2
1
0.1
C13
12P
C39
+15V
GND
VCC
0.001
C2
CS-BUSS
PORT-BUSS
CONTROL-BUSS
ADDRESS-BUSS
DATA-BUSS
VCC
C88
0.1
D1
DAN202K
3
2
1
VCC
CR2032CASE
BT1
21
DA204K
D2
23
1
VCC
VCC
MONITOR LEVEL
P-XRESET
+15V
-15V
RTC-4543SA
IC2
CE
CLK
DATA
FOE
FOUT
FSEL
GND
NC_1
NC_2
NC_3
NC_4
NC_5
VDD
WR 3
10
11
6
14
4
1
2
7
8
12
13
9
5
R1
10K
R2
4.7M R3
1K
R4
100
22KR6
R7
220
10K
R9
R10 0
R14 22K
22KR15 22KR16
R17
22K
22K
R18
22K
R19
22K
R20
22K
R21
R22
22K
R24
22K
R25
22K
22K
R26
IC6
VHC139
A
B
GY3
Y2
Y1
Y0
2
3
17
6
5
4
22KR5
+15V
AG
VCC
VCC
CLK6_75MHZ
VCC
VHC74
IC59
S
RQ
QD
C
3
25
6
14
VHC74
IC59
S
RQ
QD
C
1013
8
912
11
VCC
VCC
C93
0.1
R8
3K
0.1
C8
XRESET
22KR11
R70 22K
VCC
TC7WU04FU
IC44
62
TC7W04FU
IC57
53
IC49
TC7W04FU
17
TC7W04FU
IC49 26
TC7W04FU
IC49
35
IC1
HD6437042AE11F
DREQ0
PE15
WRL
WRH
WDTOVF
RES
RDWR
RD
RAS
IRQ3
IRQ2
IRQ1
IRQ0
CS3
CS2
CS1
CS0
CASL
CASH
XTAL
VSS_9
VSS_8
VSS_7
VSS_6
VSS_5
VSS_4
VSS_3
VSS_2
VSS_11
VSS_10
VSS_1
VCC_5
VCC_4
VCC_3
VCC_2
VCC_1
TXD1
TXD0
TIOC0D
RXD1
RXD0
PLLVSS
PLLVCC
PLLCAP
PE9
PE8
PE7
PE6
PE5
PE4
PE12
PE11
PE10
NMI
MD3
MD2
MD1
MD0
EXTAL DACK0
CK
AVSS
AVCC
AN7
AN6
AN5
AN4
AN3
AN2
AN1
AN0
AD9
AD8
AD7
AD6
AD5
AD4
AD3
AD2
AD15
AD14
AD13
AD12
AD11
AD10
AD1
AD0
A9
A8
A7
A6
A5
A4
A3
A21
A20
A2
A19
A18
A17
A16
A15
A14
A13
A12
A11
A10
A1
A0
DRAK0
PE13
DREQ1 87
112
86
4
5
14
15
16
17
18
19
20
22
29
30
6
31
32
7
8
9
10
11
12
13
70
69
58
57
56
54
53
52
68
67
66
64
63
62
60
59
91
92
93
94
95
96
98
99
100
97
83
1
74
79
78
75
73
76
108
110
111
89
102
104
105
106
107
81
80
82
51
48
88
50
47
21
37
65
77
103
3
101
109
23
27
33
39
55
61
71
90
72
26
25
41
40
45
44
49
46
43
42
24
34
28
84
35
36
38
2
85
100/6.3V(ECEV)
C3
+
DA119
D4 13
1MR13
R75 (0)
R12 22K
VCC
VCC
CS_SPC
CS_IDE1
CS_IDE0
CS_EXT
BT_SEL
CS_BROM
CS_LCD
CS_BOOT
CS_IDE0
CS_IDE1
CS_IDE
CS_SPC
CS_GA
CS_EXT
CS_LCD
CS_ESPA
CS_ESPB
BT_SEL
CS_BOOT
CS_BROM
CS_PORT0
CS_IDE,CS_IDE[0:1],CS_ESPA,CS_ESPB,CS_LCD,CS_EXT,CS_PORT0,CS_SPC,CS_GA,CS_BROM,CS_BOOT,BT_SEL
CS_IDE
N2012Z-121FL1
VCC VCC
LCD BOARD
TO
IC6
IDE DACK
IDE DREQ
SCSI DREQ
SCSI DACK
PL3
XMUTE
TIOC0D
PE[5:8],PE[10:11],PG[0:7],PL[3:7],XMUTE,TIOC0D,PWM2,RXD1,TXD1,ENCA,ENCB,AN4
PL7
PWM2
PG0
PG1
PG2
PG3
PG4
PG5
PG6
PG7
ENCA
ENCB
PL5
PL6
PL7
RXD1
TXD1
PE5
PG4
PG5
AN4
PE6
PE7
PE8
PE10
PE11
PL4
PL3
VHC245
IC15
A3
GND
A7
A6
A5
A4
A2
A1
A0
VCC
OE
DIR
B7
B6
B5
B4
B3
B2
B1
B0 18
17
16
15
14
13
12
11
1
19
20
2
3
4
6
7
8
9
10
5
VHC157
IC63
3Y
2Y
1Y
VCC
ST
SEL
4B
4A
3B
3A
2A
1B
1A
2B
4Y
GND 8
12
6
2
3
5
11
10
14
13
1
15
16
4
7
9
DACK0
DRAK0
EXINT2
DREQ1
DRAK0
DACK0
DREQ0
IRQ3
IRQ1
IRQ0
RDWR
CASH
CASL
RAS
WRH
WRL
RD
RD
WRL
RDWR
CASH
RAS
RDWR
CASL
RAS
WRL
RD
RD
IRQ3
RD
WRL
IRQ1
RD
WRL
RD
WRL
DREQ1
RD,WRL,WRH,RAS,CASL,CASH,RDWR,IRQ[0:1],IRQ3,DREQ[0:1],DACK0,DRAK0,EXINT[0:2]
RD
WRH
EXINT0
EXINT1
EXINT2
WRL
DREQ0
DACK0
C103
0.1
IC18,24,25,36,52,59,60,65
B12B-PH-K-SCN6
11
9
8
7
6
5
4
3
2
1
10
12
CIRCUIT DIAGRAM
MAIN BOARD 1/3 (71015356)
20
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
29 30 31 32 33 34 35 36 37 38 39 40 41 42
V
W
X
Y
Z
IC66
TC7SH04FU
42
ADD11
ADD10
ADD9
ADD8
512FS
1FS
DAD11
DAD10
DAD9
DAD8
64FS
256FS
1FS
64FS
256FS
512FS
1FS,64FS,256FS,512FS,ADD[1:5],ADD[8:11],DAD[1:6],DAD[8:11]
ADD5
512FS
1FS
64FS
DAD6
DAD5
DAD8
DAD6
DAD5
DAD4
DAD3
ADD11
ADD10
ADD9
ADD8
ADD1
ADD2
ADD3
ADD4
ADD5
DAD1
DAD2
DAD9
DAD10
DAD11
1FS
256FS
512FS
1FS
10K
R93
10K
R94
10K
R92
512FS
DAD8
ADD8
VCC
TRR0
TRS0
CN13
TX14-40R-6ST-MH1
40
34
33
31
30
29
28
27
26
20
18
16
15
14
12
10
1
2
3
4
5
6
7
8
9
11
13
17
19
21
22
23
24
25
32
35
36
37
38
39
ESPBS0
ESPBS[0:5]
ESPBS5
ESPBS4
ESPBS3
ESPBS2
ESPBS1
ESPBS0
ESPBS4
ESPBS3
ESPBS2
ESPBS0
ESPBS1
ESPBS5
ESPBS4
ESPBS1
ESPBS2
ESPBS3
ESPBS5
EFFBS0
EFFBS1
EFFBS2
EFFBS3
EFFBS4
EFFBS5
EFFBS[0:5]
EFFBS4
EFFBS3
EFFBS2
EFFBS1
EFFBS0
EFFBS5
TRR0
TRS0
CN12
TX14-40R-6ST-MH1
39
38
37
36
35
32
25
24
23
22
21
19
17
13
11
9
8
7
6
5
4
3
2
1
10
12
14
15
16
18
20
26
27
28
29
30
31
33
34
40
EFFAS0
EFFAS2
EFFAS3
EFFAS4
EFFAS5
EFFAS1
EFFAS[0:5]
EFFAS5
EFFAS0
EFFAS1
EFFAS2
EFFAS3
EFFAS4
ESPAS0
ESPAS5
ESPAS4
ESPAS3
ESPAS2
ESPAS1
ESPAS[0:5]
ESPAS5
ESPAS4
ESPAS3
ESPAS2
ESPAS1
ESPAS0
ESPAS5
ESPAS4
ESPAS2
ESPAS0
ESPAS1
ESPAS3
IC65
VHC74
S
RQ
QD
C
1013
8
912
11
VCC
VCC
VCC
R90
22
R30
22
VCC
TC7W74FU
IC64
S
RQ
QD
C
1
2 5
3
6 7
SG-8002JC(60MHZ)
X4
VDD OUT
OEGND
4 3
12
SG-8002JC(56MHZ)
X3
VDD OUT
OEGND
2 1
34
BOARD
ESPBI[0:5],ESPBICK
ESPBI5
ESPBI2
ESPBI3
ESPBI4
ESPBI0
ESPBI0
ESPBI1
ESPBI2
ESPBI3
ESPBI4
ESPBI5
ESPBICK
ESPBI1
ESPBICK
IC62
UPD431016
WE
UB
OE
LB
CS
VSS_2
VSS_1
VCC_2
VCC_1
NC3
NC2
NC1
D9
D8
D7
D6
D5
D4
D3
D2
D15
D14
D13
D12
D11
D10
D1
D0
A9
A8
A7
A6
A5
A4
A3
A2
A15
A14
A13
A12
A11
A10
A1
A0
5
4
25
24
21
20
19
18
3
2
1
44
43
42
27
26
7
8
31
32
35
36
37
38
9
10
13
14
15
16
29
30
22
23
28
11
33
12
34
6
39
41
40
17
MD[0:23]
MD5
MD0
MD1
MD2
MD3
MD4
MD8
MD9
MD10
MD11
MD12
MD13
MD14
MD15
MD23
MD22
MD21
MD20
MD19
MD18
MD17
MD16
MD7
MD6
MD23
MD22
MD21
MD19
MD16
MD15
MD12
MD10
MD5
MD4
MD3
MD2
MD0
MD1
MD6
MD7
MD8
MD9
MD11
MD13
MD14
MD17
MD18
MD20
R77 10K
100R53
R58 100
R56 100
R55 100
100R54
MA[0:15]
MA12
MA13
MA14
MA11
MA10
MA9
MA7
MA6
MA4
MA0
MA1
MA2
MA3
MA5
MA8
MA15
MA14
MA13
MA11
MA8
MA9
MA10
MA12
MA7
MA4
MA5
MA6
MA2
MA3
MA1
MA15
MA12
MA13
MA14
MA10
MA11
MA9
MA6
MA7
MA5
MA3
MA0
MA1
MA2
MA4
MA8
MA0
MA15
ESPAI4
ESPAI0
ESPAI3
ESPAI0
ESPAI1
ESPAI2
ESPAI1
ESPAI2
ESPAI3
ESPAI4
ESPAI5
ESPAICK
ESPAICK
ESPAI[0:5],ESPAICK
ESPAI5
ESPAOCK
ESPAO5
ESPAO4
ESPAO3
ESPAO2
ESPAO1
ESPAO0
ESPAO[0:5],ESPAOCK
ESPAOCK
ESPAO5
ESPAO4
ESPAO3
ESPAO2
ESPAO1
ESPAO0
IC29
UPD431016
WE
UB
OE
LB
CS
VSS_2
VSS_1
VCC_2
VCC_1
NC3
NC2
NC1
D9
D8
D7
D6
D5
D4
D3
D2
D15
D14
D13
D12
D11
D10
D1
D0
A9
A8
A7
A6
A5
A4
A3
A2
A15
A14
A13
A12
A11
A10
A1
A0
17
40
41
39
6
34
12
33
11
28
23
22
30
29
16
15
14
13
10
9
38
37
36
35
32
31
8
7
26
27
42
43
44
1
2
3
18
19
20
21
24
25
4
5
VCC
VCC
75R72
R65 100
100R66
R67 100
R68 100
R61 100
100R62
R63 100
R64 100
100R57
100R59 100R60
BOARD
TO PANEL RA24 10KX8
1
2
3
4
5
7
8
9
10
6
RA25 10KX8
6
10
9
8
7
5
4
3
2
1
VCC
10KX8
RA17
1
2
3
4
5
7
8
9
10
6
R52 22K
IRQ0
EXINT1
EXINT0
RD,WRL,IRQ0,EXINT[0:1]
RD
WRL WRL
RD
WRL
WRL
RD
A6
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A1
A0
A1
A13
A12
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A0
A[0:21]
A2
A1
A3
A4
A5
CS_GA
CS_ESPA,CS_ESPB,CS_PORT0,CS_GA
CS_PORT0
CS_ESPA CS_ESPB
VCC
C77
0.1
100/6.3V(ECEV)
C87
+
C69
100/6.3V(ECEV)
+
100/6.3V(ECEV)
C66
+
100/6.3V(ECEV)
C57
+
10KX8
RA18
6
10
9
8
7
5
4
3
2
1
CLK6_75MHZ
PEAK1
PEAK2
PEAK3
PEAK4
PEAK5
PEAK6
PEAK7
PEAK8
CN11
B13B-PH-K-S
12
10
1
2
3
4
5
6
7
8
9
11
13
BOARD
IN/OUT
TO DIGITAL
0.1
C78
VCC
VCC
VCC
0.1
C81
VCC
C83 0.1
VCC 0.1
C82
VHC393
IC24
CK
QD
QC
QB
QA
CLR
2
3
4
5
6
1
VCC
EDAA[0:3]
EDAA1
EDAA0
EDAA2
EDAA3
EDAA0
EDAA1
EDAA2
EDAA3
XRESET
(D.OUT LH)
(D.OUT CK)
(D.OUT DATA)
(BLOCK)
(32/192)
(PLL_DATA)
VHC00
IC36 11
13
12
C76
0.1
VCC
P-XRESET
CS-BUSS
CTRL-BUSS
ADRS-BUSS
DATA-BUSS
XRESET
PORT-BUSS
XRESET
CS-BUSS
P-XRESET
CONTROL-BUSS
ADDRESS-BUSS
DATA-BUSS
AUDIO-BUSS
GND
VCC
VCC
GND
GND
VCC
LRCK0
MCK0
TX1
RX1
XRST
D/A7
D/A6
D/A5
D/A4
A/D3
A/D2
A/D1
A/D0
D/A3
D/A2
D/A1
D/A0
TRCKO
TRR5
TRR4
TRR3
TRR2
TRR1
TRCKIN
TRS1
TRS2
TRS3
TRS4
TRS5
LRCKI
CLKI
GND
VCC
VCC
0.1
C85
VCC
VCC
AUDIO-BUSS
DATA-BUSS
P-XRESET
CS-BUSS
XRESET
VCC
C80
0.1
VCC
0.1
C79
XRESET
CS-BUSS
PORT-BUSS
P-XRESET
CONTROL-BUSS
ADDRESS-BUSS
DATA-BUSS
XRESET
DATA-BUSS
ADRS-BUSS
CTRL-BUSS
CS-BUSS
PORT-BUSS
P-XRESET
CLK6.75MHZ
IC24
VHC393
CK
QD
QC
QB
QA
CLR
13
8
9
10
11
12
VHC393
IC25
CK
QD
QC
QB
QA
CLR
2
3
4
5
6
1
C64
0.1
0.01
C65
VCC
C68
0.1
(PLL_CK)
0.1
C62
15P
C61
VCC
VCC
VCC
VCC
0.47
C60
C59 0.01 C58
0.1
512FS
VHC393
IC25
CK
QD
QC
QB
QA
CLR
13
8
9
10
11
12
C67
47P
PORT-BUSS PORT-BUSS
AUDIO-BUSS
C63
0.1
ADDRESS-BUSS
CONTROL-BUSS
CLK27MHZ CLK6.75MHz
CLK27MHz
VCC
GND
CLKI
LRCKI
TRS4
TRS3
TRS2
TRS1
TRCKIN
TRR1
TRR2
TRR3
TRR4
TRR5
TRCKO
D/A0
D/A1
D/A2
D/A3
A/D0
A/D1
A/D2
A/D3
D/A4
D/A5
D/A6
D/A7
XRST
RX1
TX1
MCK0
LRCK0
VCC
GND
GND
VCC
VCC
GND
VCC
0.1
C84
C75 0.1
VCCVCC
VCC
VHC393
IC18
CK
QD
QC
QB
QA
CLR
1
6
5
4
3
2
VCC
EADA3
EADA2
EADA1
EADA3
EADA2
EADA1
EADA0
EADA0
EADA[0:3]
EADB2
EADB1
EADB0
EADB3
EADB0
EADB1
EADB2
EADB3
EADB[0:3]
VHC157
IC32
3Y
2Y
1Y
VCC
ST
SEL
4B
4A
3B
3A
2A
1B
1A
2B
4Y
GND
9
7
4
16
15
1
13
14
10
11
5
3
2
6
12
8
VHC157
IC31
3Y
2Y
1Y
VCC
ST
SEL
4B
4A
3B
3A
2A
1B
1A
2B
4Y
GND 8
12
6
2
3
5
11
10
14
13
1
15
16
4
7
9
IC33
VHC157
3Y
2Y
1Y
VCC
ST
SEL
4B
4A
3B
3A
2A
1B
1A
2B
4Y
GND 8
12
6
2
3
5
11
10
14
13
1
15
16
4
7
9
VCC
VCC
VCC
VCC
CN10
B7B-PH-K-S
7
6
5
4
3
2
1
VCC
0.1
C74
VCC
VCC
VCC VCC
C72
0.01
C73
0.01
220P
C70 220P
C71
GND
+5V
ENC_GND
ENC_B
ENC_A
+5V
GND
FOOT SW
D.OUT1
D.IN1
D.IN2
D.OUT2
VCC
ESPBOCK
ESPBO1
ESPBO2
ESPBO3
ESPBO4
ESPBO5
ESPBOCK
ESPBO[0:5],ESPBOCK
ESPBO0
ESPBO5
ESPBO4
ESPBO3
ESPBO2
ESPBO1
ESPBO0
D0
D1
D2
D3
D4
D5
D7
D6
D0 D0
D6
D7
D5
D4
D3
D2
D1
D[0:15]
D1
D2
D3
D4
D5
D6
D7
D15
D1
D0
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
D14
R29
1.5K
5.6KR34
R36 150
5.6KR35
220
R37
10K
R38 10K
R39
R40 10K
10KR41
R44
330 4.7K
R45
TLC2933
IC30
VCOO
VCOINH
VCOIN
SELECT
RBIAS
PFDO
PFDINH
NC
FINB
FINA
DVDD
DGND
AVDD
AGND
3
10
12
2
13
6
9
8
5
4
1
7
14
11
15K
R46
0
R47
22K
R48 22K
R49
R50
22K
TC9246F
IC19
XO
XI
VSSA
VSS
VDDA
VDD
S2
S1
REF
PD
M2
M1
LOCK CKO
AMPO
AMPI
10
14
11
12
7
16
9
3
6
8
2
4
5
15
13
1
VHC153
IC20
2G
1G
VCC
GND
B
A
2Y
2C3
2C2
2C1
2C0
1Y
1C3
1C2
1C1
1C0
15
1
16
8
2
14
9
13
12
11
10
7
3
4
5
6
IC23
VHC595
SI
SCK
QH
QD
GND
QG
QF
QE
QC
QB
QA
VCC
G
QHX
RCK
SCLR 10
12
913
16
15
1
2
4
5
6
8
3
7
11
14
IC35
TC170C140AF-003(ESP2)
WR
WE
RST2
RST1
RD
RAS
CS
CAS
VSS_9
VSS_8
VSS_7
VSS_6
VSS_5
VSS_4
VSS_3
VSS_20
VSS_2
VSS_19
VSS_18
VSS_17
VSS_16
VSS_15
VSS_14
VSS_13
VSS_12
VSS_11
VSS_10
VSS_1
VPOUT
VDD_8
VDD_7
VDD_6
VDD_5
VDD_4
VDD_3
VDD_2
VDD_13
VDD_12
VDD_11
VDD_10
VDD_9
VDD_1
TYPE
TRS5
TRS4
TRS3
TRS2
TRS1
TRS0
TRR5
TRR4
TRR3
TRR2
TRR1
TRR0
TRCKO
TRCKIN
SYO
SYI PSEA16
PSEA15
PSEA14
PSEA13
PSEA12
PSEA11
PSEA10
OSC
MCK1
MCK0
LRCK1
LRCK0
INT1
INT0
ED9
ED8
ED7
ED6
ED5
ED4
ED3
ED23
ED22
ED21
ED20
ED2
ED19
ED18
ED17
ED16
ED15
ED14
ED13
ED12
ED11
ED10
ED1
ED0
EA9
EA8
EA7
EA6
EA5
EA4
EA3
EA2
EA1
EA0
DIRECT
DA7
DA6
DA5
DA4
DA3
DA2
DA1
DA0
CD7
CD6
CD5
CD4
CD3
CD2
CD1
CD0
CA9
CA8
CA7
CA6
CA5
CA4
CA3
CA2
CA13
CA12
CA11
CA10
CA1
CA0
BCK1
BCK0
AD3
AD2
AD1
AD0
64
65
51
66
114
113
112
111
116
117
121
122
124
129
128
131
136
137
138
139
140
141
27
143
144
134
68
13
69
70
14
90
72
54
41
30
18
12
109
108
1
101
102
103
104
105
106
62
61
60
59
58
57
107
56
132
133
63
55
50
40
31
28
19
11
127
119
110
100
91
89
80
73
71
2
33
32
10
9
8
7
6
49
48
47
46
5
45
44
43
42
39
38
37
36
35
34
4
3
25
24
23
22
21
20
17
16
29
92
93
94
95
96
97
98
99
78
79
81
82
83
84
85
86
74
75
76
77
87
88 126
135
26
142
15
125
120
118
115
123
67
52
130
53
IC34
TC170C140AF-003(ESP2)
WR
WE
RST2
RST1
RD
RAS
CS
CAS
VSS_9
VSS_8
VSS_7
VSS_6
VSS_5
VSS_4
VSS_3
VSS_20
VSS_2
VSS_19
VSS_18
VSS_17
VSS_16
VSS_15
VSS_14
VSS_13
VSS_12
VSS_11
VSS_10
VSS_1
VPOUT
VDD_8
VDD_7
VDD_6
VDD_5
VDD_4
VDD_3
VDD_2
VDD_13
VDD_12
VDD_11
VDD_10
VDD_9
VDD_1
TYPE
TRS5
TRS4
TRS3
TRS2
TRS1
TRS0
TRR5
TRR4
TRR3
TRR2
TRR1
TRR0
TRCKO
TRCKIN
SYO
SYI PSEA16
PSEA15
PSEA14
PSEA13
PSEA12
PSEA11
PSEA10
OSC
MCK1
MCK0
LRCK1
LRCK0
INT1
INT0
ED9
ED8
ED7
ED6
ED5
ED4
ED3
ED23
ED22
ED21
ED20
ED2
ED19
ED18
ED17
ED16
ED15
ED14
ED13
ED12
ED11
ED10
ED1
ED0
EA9
EA8
EA7
EA6
EA5
EA4
EA3
EA2
EA1
EA0
DIRECT
DA7
DA6
DA5
DA4
DA3
DA2
DA1
DA0
CD7
CD6
CD5
CD4
CD3
CD2
CD1
CD0
CA9
CA8
CA7
CA6
CA5
CA4
CA3
CA2
CA13
CA12
CA11
CA10
CA1
CA0
BCK1
BCK0
AD3
AD2
AD1
AD0
53
130
52
67
123
115
118
120
125
15
142
26
135
126
88
87
77
76
75
74
86
85
84
83
82
81
79
78
99
98
97
96
95
94
93
92
29
16
17
20
21
22
23
24
25
3
4
34
35
36
37
38
39
42
43
44
45
5
46
47
48
49
6
7
8
9
10
32
33
2
71
73
80
89
91
100
110
119
127
11
19
28
31
40
50
55
63
133
132
56
107
57
58
59
60
61
62
106
105
104
103
102
101
1
108
109
12
18
30
41
54
72
90
14
70
69
13
68
134
144
143
27
141
140
139
138
137
136
131
128
129
124
122
121
117
116
111
112
113
114
66
51
65
64
IC36
VHC00
65
4
VHC00
IC36 9
10
8
VHC00
IC36
32
1
TMS320C541
IC27
TRST
RS
R/W
PS
NMI
MSTRB
MSC
MP/MC
IS
IOSTRB
INT3
INT2
INT1
INT0
IAQ
IACK
HOLDA
HOLD
DS
BIO
XF
X1
VSS_9
VSS_8
VSS_7
VSS_6
VSS_5
VSS_4
VSS_3
VSS_2
VSS_11
VSS_10
VSS_1
VDD_9
VDD_8
VDD_7
VDD_6
VDD_5
VDD_4
VDD_3
VDD_2
VDD_1
TOUT
TMS
TDO
TDI
TCK
READY
FSX1
FSX0
FSR1
FSR0
EMU1
EMU0
DX1
DX0
DR1
DR0
D9
D8
D7
D6
D5
D4
D3
D2
D15
D14
D13
D12
D11
D10
D1
D0
CNT
CLKX1
CLKX0
CLKR1
CLKR0
CLKOUT
CLKMD3
CLKMD2
CLKMD1
CLKIN
A9
A8
A7
A6
A5
A4
A3
A2
A15
A14
A13
A12
A11
A10
A1
A0
60
69
16
13
44
17
19
25
15
18
48
47
46
45
22
43
21
23
14
24
20
67
65
63
50
40
35
26
10
9
89
88
1
90
87
76
64
49
39
36
11
8
55
62
58
59
61
12
38
37
30
29
57
56
42
41
32
31
80
79
78
77
75
74
73
72
86
85
84
83
82
81
71
70
54
34
33
28
27
66
51
52
53
68
100
99
98
97
96
95
94
93
7
6
5
4
3
2
92
91
IC22
TC9271F
XI
VSS
VLDY VDD
UBDA
M2
M1
LRS
LRCK
LBIT
IS2
IS1
FS2
FS1
FR32
EMPH
DO2
DO1
DATA
CTG3
CTG2
CTG1
COPY
CKS
CKA2
CKA1
BLOCK
BCK
13
14
728
2
18
17
3
4
25
20
19
11
10
24
8
16
15
6
23
22
21
9
12
27
26
1
5
VHC574
IC26
Q3
GND
Q7
Q6
Q5
Q4
Q2
Q1
Q0
VCC
OE
CK
D7
D6
D5
D4
D3
D2
D1
D0
16
10
12
13
14
15
17
18
19
20
1
11
9
8
7
6
5
4
3
2
C56
0.1
R27
100
220K
R28
R51 22K
22
R31
VHC393
IC52
CK
QD
QC
QB
QA
CLR
1
6
5
4
3
2
TC7SHU04FU
IC53
24
TC7SH32FU
IC56
42
1
IC57
TC7W04FU
2 6 75
R32
10K
R42
VCC
330K
R73
LC8905V
IC21
XMODE
VIN
VDD
VCOTST2
TST1
R
LRCK
LD
GND
ERROR
E/DOUT
DO
DIN2
DIN1
DATO
DI
CL
CKSEL
CKOUT
CE
BCK
AVOCK
128FS
20
10
6
713
12
5
22
24
3
17
2
1
23
16
14
19
15
21 4
8
9
18
11
R33 24K
VCC
(D.IN DO)
(D.IN DI)
(D.IN CE)
(D.IN CL)
R74
10K
VCC
0.1
C105
10KR78
R79 10K
10KR80
R81 10K
10KR82
R83 10K
R84 10K
UPD65806GD-100-LML
IC28
1FS
512FS
CA1
CA2
CA3
CA4
CA5
CA6
CD0
CD1
CD10
CD11
CD12
CD13
CD14
CD15
CD2
CD3
CD4
CD5
CD6
CD7
CD8
CD9
CLK
DA0
DA1
DA13
DA14
DA15
DA2
DA3
DA4
DD0
DD1
DD10
DD11
DD12
DD13
DD14
DD15
DD2
DD3
DD4
DD5
DD6
DD7
DD8
DD9
ESAI0
ESAI1
ESAI2
ESAI3
ESAI4
ESAI5
ESAICLK
ESAO0
ESAO1
ESAO2
ESAO3
ESAO4
ESAO5
ESAOCLK
ESASL
ESBI0
ESBI1
ESBI2
ESBI3
ESBI4
ESBI5
ESBICLK
ESBO0
ESBO1
ESBO2
ESBO3
ESBO4
ESBO5
ESBOCLK
ESBSL
MA0
MA1
MA10
MA11
MA12
MA13
MA14
MA15
MA2
MA3
MA4
MA5
MA6
MA7
MA8
MA9
MD0
MD1
MD10
MD11
MD12
MD13
MD14
MD15
MD16
MD17
MD18
MD19
MD2
MD20
MD21
MD22
MD23
MD3
MD4
MD5
MD6
MD7
MD8
MD9
PKDT
PKLD
SCAN0
SCAN1
SCAN2
SI0
SI1
SI10
SI11
SI2
SI3
SI4
SI5
SI6
SI7
SI8
SI9
SO0
SO1
SO10
SO11
SO2
SO3
SO4
SO5
SO6
SO7
SO8
SO9
SYCI
SYCO
TEST1
TEST2 VDD_1
VDD_10
VDD_11
VDD_12
VDD_13
VDD_14
VDD_15
VDD_16
VDD_17
VDD_2
VDD_3
VDD_4
VDD_5
VDD_6
VDD_7
VDD_8
VDD_9
VSS_1
VSS_10
VSS_11
VSS_12
VSS_13
VSS_14
VSS_15
VSS_16
VSS_17
VSS_18
VSS_19
VSS_2
VSS_20
VSS_21
VSS_22
VSS_23
VSS_24
VSS_25
VSS_26
VSS_3
VSS_4
VSS_5
VSS_6
VSS_7
VSS_8
VSS_9
CINT
CRD
CS
CWR
DCS
DINT
DR/W
DSTRB
MCE0
MCE1
MOE
MWE
RESET
132
154
112
113
114
115
116
117
100
99
89
87
86
85
84
83
98
97
96
95
93
92
91
90
107
61
60
56
55
54
59
58
57
81
80
68
67
66
65
64
63
77
76
75
74
73
72
70
69
174
173
172
171
170
169
160
167
166
165
164
163
162
158
168
191
190
189
188
187
186
184
181
180
179
178
177
176
193
194
13
14
44
46
45
43
41
39
10
8
3
4
9
11
40
42
200
201
20
21
22
23
24
25
28
29
30
31
202
32
33
34
35
203
204
205
206
207
18
19
120
119
5
6
7
139
138
123
122
137
136
135
134
127
126
125
124
152
151
142
141
150
149
148
147
146
145
144
143
195
196
109
128 27
130
133
153
157
175
183
192
208
36
38
53
62
78
82
101
104
1
88
94
105
106
108
118
121
131
140
155
2
156
159
161
182
185
197
199
15
17
26
51
52
71
79
103
102
111
110
49
50
47
48
16
198
12
37
129
VS8F2
BOARD
EDAB[0:3]
EDAB2
EDAB0
EDAB1
EDAB3
EDAB1
EDAB2
EDAB3
EDAB0
VCC
2SD1664
Q2
3
2
1
C86
100/6.3V(ECEV)
+
DA119
D5
3 1
VCC
TRS5
ON/OFF
VS8F2
DTC114EK
Q1 1
3
2
IC54
TC7SH08FU
4
2
1
IC65
VHC74
S
RQ
QD
C
3
2 5
6
1 4
IC57
TC7W04FU
1 7
CLK27MHZ
PG0
PE[5:8],PE[10:11],PG[0:7],PL[4:7],TIOC0D,PWM2,RXD1,TXD1,ENCA,ENCB,AN4
ENCA
PG7
PL6
PG6
PG5
PG4
PE11
PE7
PG3
PG2
PG1
PWM2
PE10
PE8
PL5
PL4
TIOC0D
TXD1
RXD1
PE6 PE5
ENCB
AN4
B2B-XH-A
CN14
2
1+5V
ADD9
ADD10
ADD11
DAD9
DAD10
DAD11
1FS
B10B-PH-K-S
CN15
2
10
3
4
5
6
7
8
9
1
10K
R43
10K
R91
TO FANTO TOOL
P-XRESET
VS-1680
Sep, 1998
MAIN BOARD 2/3 (71015356)
Other manuals for VS-1680 V-XPANDED
6
Table of contents
Other Roland Musical Instrument manuals
Roland
Roland C-80 Operating and maintenance manual
Roland
Roland F701 User manual
Roland
Roland V-ACCORDION FR-5 User manual
Roland
Roland AEROPHONE AE-20 User manual
Roland
Roland HP 337 User manual
Roland
Roland FP-7F User manual
Roland
Roland AT-20R User manual
Roland
Roland Classic Keyboard C-230 User manual
Roland
Roland HP 535 User manual
Roland
Roland KF-7 User manual
Roland
Roland f-20 User manual
Roland
Roland V-Accordion FR-1x User manual
Roland
Roland VK-8 User manual
Roland
Roland E-X30 Operating and maintenance manual
Roland
Roland Atelier AT-90R User manual
Roland
Roland KR-105 User manual
Roland
Roland RD-700NX User manual
Roland
Roland Atelier AT90 User manual
Roland
Roland E-X50 User manual
Roland
Roland HP 5700 User manual
