Roland VS-2400CD Operating and maintenance manual

SERVICE NOTES
Issued by RJA
Copyright © 2003 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission
of ROLAND CORPORATION.
Printed in Japan (0800) (AS)17058055E0
Jan.2003 VS-2400CD
SPECIFICATIONS....................................................................... 2
LOCATION OF CONTROLS PARTS LIST ............................. 4
LOCATION OF CONTROLS..................................................... 5
EXPLODED VIEW PARTS LIST ............................................... 6
EXPLODED VIEW ...................................................................... 7
WIRING DIAGRAM................................................................... 8
PARTS LIST................................................................................ 10
CHECKING THE VERSION NUMBER................................. 18
SAVING USER DATA & RELOADING SAVED DATA..... 18
TEST MODE............................................................................... 20
SYSTEM SOFTWARE UPDATE PROCEDURE.................... 23
FORMATTING THE HARD DISK ......................................... 23
BLOCK DIAGRAM 1................................................................ 26
BLOCK DIAGRAM 2................................................................ 28
CIRCUIT BOARD (MAIN)....................................................... 30
CIRCUIT BOARD (MAIN)....................................................... 32
CIRCUIT DIAGRAM (MAIN 1/8) ......................................... 34
CIRCUIT DIAGRAM (MAIN 2/8) ......................................... 36
CIRCUIT DIAGRAM (MAIN 3/8) ......................................... 38
CIRCUIT DIAGRAM (MAIN 4/8) ......................................... 40
CIRCUIT DIAGRAM (MAIN 5/8) ......................................... 42
CIRCUIT DIAGRAM (MAIN 6/8) ......................................... 44
CIRCUIT DIAGRAM (MAIN 7/8) ......................................... 46
CIRCUIT DIAGRAM (MAIN 8/8) ......................................... 48
CIRCUIT BOARD (ANALOG)................................................ 50
CIRCUIT BOARD (ANALOG)................................................ 52
CIRCUIT DIAGRAM (ANALOG 1/4)................................... 54
CIRCUIT DIAGRAM (ANALOG 2/4)................................... 56
CIRCUIT DIAGRAM (ANALOG 3/4)................................... 58
CIRCUIT DIAGRAM (ANALOG 4/4)................................... 60
CIRCUIT BOARD (PANEL/FADER) .................................... 62
CIRCUIT DIAGRAM (PANEL)............................................... 64
CIRCUIT DIAGRAM (FADER)............................................... 66
CIRCUIT BOARD (CONTRAST/CDRW) ............................. 68
CIRCUIT BOARD (CONTRAST/CDRW) ............................. 69
CIRCUIT DIAGRAM (CONTRAST) ...................................... 70
CIRCUIT DIAGRAM (CDRW)................................................ 72
TABLE OF CONTENT

2
Jan.2003
SPECIFICATIONS
VS-2400CD: 24Tr,24bit,96kHzSampling Digital
Studion Workstation
• Tracks
Tracks:24
V-Tracks:384 (16 V-Tracks per each Track)
• Sample Rate
96.0 / 88.2 / 64.0 / 48.0 / 44.1 / 32.0 kHz
* Adjustable range with vari-pitch function
22.00kHz-98.00kHz (at 96kHz)
22.00kHz-50.00kHz (at 48kHz)
• Recording Mode
Mastering 24-bit (M24)
Multitrack Pro (MTP)
CD Writing (CDR)
Mastering 16-bit (M16)
Multitrack 1 (MT1)
Multitrack 2 (MT2)
Live 1 (LIV)
Live 2 (LV2)
• Maximum Simultaneous Recording / Playback Tracks
Sample Rate 48/44.1/32kHz
16 tr. Rec / 16 tr. Play (M24,M16,CDR)
16 tr. Rec / 24 tr. Play (MTP,MT1/2,LIV,LV2)
Sample Rate 96/88.2/64kHz
8 tr. Rec / 8 tr. Play (M24,M16,CDR)
8 tr. Rec / 12 tr. Play (MTP,MT1/2,LIV,LV2)
* Depending on the organization of the song data or the disk drive performance
etc., the number of tracks which can be simultaneously recorded or played back
may be limited.
•Maximum Useful Capacity
40 GB
•Recording Time
(at 10GB Partition, conversion in 1 track, unit : minutes)
Recording Mode Sample Rate
96kHz 88.2kHz 64kHz 48kHz 44.1kHz 32kHz
M24 662 721 993 1,324 1,442 1,987
MTP 1,989 2,165 2,983 3,977 4,329 5,966
M16 994 1,082 1,491 1,989 2,165 2,983
CDR 994 1,082 1,491 1,989 2,165 2,983
MT1 1,989 2,165 2,983 3,977 4,329 5,966
MT2 2,651 2,885 3,976 5,302 5,771 7,953
LIV 3,181 3,462 4,772 6,362 6,925 9,543
LV2 3,977 4,329 5,966 7,955 8,658 11,932
* The above-listed recording times are approximate. Times may be slightly
depending on the specifications of the disk drive and on the number of songs that
were created.
In “CDR”recording mode, two tracks are always used in a pair (channel link is
on), so recording time is half the above-listed.
•Frequency Response
96.0kHz : 20Hz - 40kHz (+0dB/-2dB)
88.2kHz : 20Hz - 40kHz (+0dB/-2dB)
48.0kHz : 20Hz - 22kHz (+0dB/-2dB)
44.1kHz : 20Hz - 20kHz (+0dB/-2dB)
32.0kHz : 20Hz - 14kHz (+0dB/-2dB)
•Songs
200 songs
•Marker
1000 per project
•Locator
100 (10 x 10 banks) per project
•Scene
100 (10 x10 banks) per project
•Undo/Redo
999 Undo / 1 Redo
•Nominal Input Level (variable)
Input 1-8 :-64 - +14dBu (maximum +26dBu : balanced, maximum
+20dBu : unbalanced)
Guitar (Hi-Z) :-64 - +14dBu (maximum +20dBu)
•Input Impedance
Input 1-8 : 40k ohm (balanced)
Guitar (Hi-Z) : 1M ohm
•Nominal Output Level
Master Out : +4dBu (balanced)
AUX A (L, R) : +4dBu (balanced)
AUX B (L, R) : +4dBu (balanced)
Monitor Out : +4dBu (balanced)
•Output Impedance
Master Out : 600 ohm
AUX A (L, R) : 600 ohm
AUX B (L, R) : 600 ohm
Monitor Out : 600 ohm
Phones : 22 ohm
•Recommended Load Impedance
Master Out : 10k ohm or greater
AUX A (L, R) : 10k ohm or greater
AUX B (L, R) : 10k ohm or greater
Monitor Out : 10k ohm or greater
Phones : 8 - 600 ohm
•Residual Noise Level
(input terminated with 1k ohm, INPUT SENS : LINE, IHF-A, typ.)
Master Out : -86dBu or less
AUX A : -86dBu or less
AUX B : -86dBu or less
Monitor Out : -86dBu or less
•EQ
4-band (2 shelving + 2 peaking)
* Useful simultaneously at up to 32ch in both Input Mixer and Track Mixer.

3
VS-2400CD
•Dynamics Processor
Compressor, Expander
* Useful simultaneously at up to 32ch in both Input Mixer and Track Mixer.
•Effects
Maximum 4 stereo (One pre-installed + 1 more optional VS8F-2)
•Display
320 x 240 dots Graphic LCD (with backlit)
•Interface
SCSI : 25-pin D-sub
Digital I/O : Coaxial,Optical (conforms to S/P DIF)
VGA Out : 15-pin miniD-sub
PS/2 : MimiDIN 6pin
MIDI : DIN 5pin
•Connectors
MIDI Connectors(DIN 5pin type)
Input Jack 1--8(XLR type,balanced,pahntom power)
Input Jack 1--8(1/4inch phone type,balanced)
Guitar(Hi-Z)Jack(1/4inch phone type)
Digital In Connectors(Coaxial type,Optical type)
Digital Out Connectors(Coaxial type,Optical type)
Foot Switch Jack(1/4inch phone type)
PS/2 Mouse Connector(miniDIN 6pin type)
PS/2 Keyboard Connector(miniDIN 6pin type)
VGA Out Connector(MiniDB-15 type)
R-BUS Connectors(DB-25 type)
Master Out Jack L/R(1/4inch phone type,TRS balanced)
Monitor Out Jack L/R(1/4inch phone type,TRS balanced)
AUX A Send Jack L/R(1/4inch phone type,TRS balanced)
AUX B Send Jack L/R(1/4inch phone type,TRS balanced)
Headphones Jack(Stereo 1/4inch phone type)
•Power Supply
AC117V, AC230V or AC240V
•Power Consumption
60W
•Dimensions
480(W) x 481(D) x 136(H) mm
•Weight
10.5kg (Excluding internal hard disk)
23 lbs 3 oz
•Accessories
Owner’s Manual English (#72232856)
Leaflet Demo Performances English (#40561101)
AC Cord 120V (#00894378)
AC Cord 230V (#00894389)
AC Cord 240VA (#23495124)
AC Cord 240VE (#00907001)
PS/2 MOUSE (#02346478)
Demo CD-ROM (#03126745)
Blank CD-R Disk (#********)
Short Cut Seal (#40561067)
•Options
24-bit Effect Expansion Board : VS8F-2
Channel Edit Controller : VE-7000
Level Meter Bridge : MB-24
Bi-amp Monitor : DS-90A, DS-50A
Dynamic Microphone : DR-20
8CH A/D-D/A Converter : ADA-7000
AES/EBU Interface : AE-7000
R-BUS Cable : RBC-1 (1m), RBC-5 (5m)
Footswitch : FS-5U (BOSS)
Pedal Switch : DP-2
* 0dBu = 0.775Vrms
* In the interest of product development,the specifications for this product are
subject to change without prior notice.

4
Jan.2003
LOCATION OF CONTROLS PARTS LIST
[Parts]
No Part Code Part Name Description Q’ty
1 03121267 TOP COVER 1
2 03121278 SIDE PANEL L 1
3 03121289 SIDE PANEL R 1
4 03121334 REAR PANEL 1
5 03121323 DISPLAY ESCUTCHEON 1
6 03121290 DISPLAY COVER 1
7 01786012 SEESAW SWITCH JW-M11RKK 1
8 02563867 WIRING AC ASSY
9 02562956 DC FAN MOTOR 9A0812L403 1
10 13429825 MIDI CONNECTOR YKF51-5054 2PZ 1
11 01238856 CONNECTOR YKF42-8020 (TO PC DISPLAY OUT) 1
12 02455890 D-SUB CONNECTOR YKF42-8039 1
13 02565390 OPTICAL CONNECTOR TX GP1FA501TZ 1
14 02565401 OPTICAL CONNECTOR RX GP1FA501RZ 1
15 00458801 PIN JACK (ORG) PINx2 YKC21-3044 0/0 1
16 00569278 6.5MM JACK LGR4609-7100 10
17 03124956 DIN CONNECTOR YKF51-5399 2
18 02565389 U R-KNOB S1 LCG RED 1
03126412 9M/M ROTARY POT. RK09L1140 10KB L=25 1
19 02451189 VS KEYTOP SX PERPUL 1
02453834 PUSH SWITCH SPPH430100 1
20 01891834 U R-KNOB S1 LCG BLU 1
02901678 9M/M ROTARY POT. RK09L12D0 50KA L=25 1
21 01453123 XLR CONNECTOR NC3FAV2-0 8
22 01789234 6.5MM JACK JY-6353-01-250 9
23 01891801 U R-KNOB S1 LCG BLK 8
03124945 9M/M ROTARY POT. RK09L1140 50KRD L25 RR1 8
24 01904401 9M/M ROTARY POT. EVU F2A E25 B53 1
25 03121423 KEYTOP R 1
02891789 TACT SWITCH SKRGADD010 H=5.0 85
26 03121423 KEYTOP R 1
02891789 TACT SWITCH SKRGADD010 H=5.0 85
01239856 LED (ORANGE) SEL5921A TP15 54
27 03121412 KEYTOP L 1
02891789 TACT SWITCH SKRGADD010 H=5.0 85
03012001 LED SML72423C TP15 D RANK 12
28 22485303 D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
01231367 ROTARY ENCODER EC16B24204 (L=15) (W/N&W) 1
29 00901390 KEYTOP STOP(WHIT GREY) 1
00894645 TACT SWITCH SKECAF WITHOUT LED 3
30 00901401 KEYTOP PLAY(WHIT GREY) 1
00894645 TACT SWITCH SKECAF WITHOUT LED 3
31 00901412 KEYTOP REC(RED) 1
00894645 TACT SWITCH SKECAF WITHOUT LED 3
32 03121423 KEYTOP R 1
03011990 LED (RED) SEL5221S TP15 D RANK 2
33 03121423 KEYTOP R 1
00676423 LED (GREEN) SEL5421E TP-15 2
34 01349423 U S-KNOB M1 LCG DCG GRY/BLK 12
02901734 60M/M MOTOR FADER EVANSA CB1 B14 13
35 01349434 U S-KNOB M1 MRD LCG 1
02901734 60M/M MOTOR FADER EVANSA CB1 B14 13
36 03121412 KEYTOP L 1
02891789 TACT SWITCH SKRGADD010 H=5.0 85
01239856 LED (ORANGE) SEL5921A TP15 54
37 03121423 KEYTOP R 1
01239856 LED (ORANGE) SEL5921A TP15 54
38 03231878 CD-R/RW DRIVE UJDA 360RL-Z 1

5
VS-2400CD
LOCATION OF CONTROLS
fig.panel

6
Jan.2003
EXPLODED VIEW PARTS LIST
[Parts]
[Screws]
No Part Code Part Name Description Q’ty
1 03121389 BOTTOM COVER 1
2 03121456 HDD HOLDER 1
3 03230378 HDD UNIT 2F040J0 1
4 03232612 CUSHION HDD 1
5 03231878 CD-R/RW DRIVE UJDA 360RL-Z 1
6 03121489 CD HOLDER 1
7 72232056 CDRW BOARD ASSY 1
8 71019234 EFFECT EXPANSION BOARD 1
9 72232023 MAIN BOARD ASSY 1
10 03121467 SHIELD PANEL 1
11 03121401 ANGLE 2
12 03232590 CUSHION ANGLE 1
13 03121378 POWER SPLY COVER 1
14 02562889 SWITCHING REGULATOR SWP05 1
15 03121445 PWR SPLY HOLDER 1
16 72232078 FADER BOARD ASSY 1
17 72232089 PANEL BOARD ASSY 1
18 03121423 KEYTOP R 1
19 03121412 KEYTOP L 1
20 72232090 ANALOG BOARD ASSY 1
21 72232123 CONTRAST BOARD ASSY 1
23 03121267 TOP COVER 1
24 03121289 SIDE PANEL R 1
25 03121278 SIDE PANEL L 1
26 03121323 DISPLAY ESCUTCHEON 1
27 03121290 DISPLAY COVER 1
28 03121334 REAR PANEL 1
29 02562956 DC FAN MOTOR 9A0812L403 1
30 02563867 WIRING AC ASSY 1
31 01786012 SEESAW SWITCH JW-M11RKK 1
32 22485303 D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
33 02451189 VS KEYTOP SX PERPUL 1
34 01891801 U R-KNOB S1 LCG BLK 8
35 01349423 U S-KNOB M1 LCG DCG GRY/BLK 12
36 00901401 KEYTOP PLAY(WHIT GREY) 1
37 22355334 FOOT MKS 235-334 4
38 01455523 CORD BUSHING EDS-1717U 1
39 00902790 CORD BUSHING EDS-1208U 1
40 22175349 LEAF SPRING 217-349 1
41 01786045 SW HOLDER AT-217K 1
42 12189817 PCB SPACER RSPLS-10U 1
43 02908967 SHIELD CUSHION 1
No Part Code Part Name Description Q’ty
a 40013056 SCREW M3x6 PAN MACHINE W/SW+PW ZC 6
b 40011101 SCREW 3x8 BINDING TAPTITE B BZC 17
c 40012534 SCREW 3x6 BINDING TAPTITE S FE BZC 18
d 40013056 SCREW M3x6 PAN MACHINE W/SW+PW ZC 7
e 40458345 SCREW M4x8 PAN MACHINE W/SW+SMALL PW NI 1
f 40451412 SCREW 5x10 BINDING A BZC WOOD 4
g 40344134 SCREW M4-40x7.9 HEX SOCKET NI 4
h 40450367 SCREW 6-32UNC 1008SR/KM003 4
I 40239889 SCREW M3x6 BUTTON-TRUS TAPTITE S BZC 4
j 40342989 SCREW M4x8 PAN W/EX.TOOTH WASHER 1
k 40454956 SCREW M2x2.5 SPECIAL PAN ZNC 4
l 40011312 SCREW 3x8 BINDING TAPTITE P BZC 5
m 40459590 SCREW M4x20 HEX SOCKET HEAD NI 10
n 40011201 SCREW 3x8 PAN TAPTITE P BZC 16
o 40016412 JACK WASHER M9x13.5x0.45 9
p 40456923 NUT M9x11x2P.75 NI

7
VS-2400CD
EXPLODED VIEW
fig.bunkai
1
2
3
4
5
6
7
8
9
10
a
a
a
a
a
a
a
a
a
a
b
b
b
b
b
b
c
c
c
d
d
d
e
f
g
h
h
i
j
k
k
l
l
l
m
n
o
p
b
m
11
12
13
14
15
16
17
18
19
20 21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43

9
Jan.2003 VS-2400CD
WIRING DIAGRAM
fig.wiring
[Parts]
No Part Code Part Name Description Q'ty
W1 02563867 WIRING AC ASSY 1
W2 03126434 WIRING 2x360-P2.5-XHP-SCN 1
W3 03126423 WIRING 5x260-P2.5-XHP-SCN 1
W4 03126467 WIRING 4x170-P2.5-LCP-SCN 1
W5 03126445 WIRING 4x350-P2.5-XHP-SCN 1
W6 03126345 BAN CARD BNCD-P=1.25-K-12-120 1
W7 03126334 BAN CARD BNCD-P=1.25-K-26-120 1
W8 03126390 WIRING 11x200-P2.0-PHR-PHR 1
W9 03126456 WIRING 6x300-P2.5-XHP-SCN 1
W10 03128167 WIRING NIB3-10-005 1
W11 03126389 WIRING CDRW 1
W12 03126367 BAN CARD BNCD-P=1.25-K-24-500 1
W13 03126356 BAN CARD BNCD-P=1.25-K-26-240 1
W14 03126378 BAN CARD BNCD-S-P=1.25-K-16-260 1
PANEL BOARD
FADER BOARD
CDRW
BOARD
CD-RW
DRIVE
Hard Disk
Drive
CONTRAST
BOARD
LCD UNIT
MAIN BOARD
ANALOG BOARD
FAN
POWER SUPPLY
UNIT
CN15 CN18 CN16
CN9
CN8
CN801
CN802
CN2
CN6
CN3
CN1
CN101
CN1 CN2
CN3
CN5
CN7
CN12 CN3
CN4
CN3
CN2
CN1
CN1
CN4
CN3
CN2CN5
W1
W2
W3
W4
W5
W6 W7 W8
W9
W10
W11
W12
W13
W14

10
Jan.2003
PARTS LIST
fig.part1e
MB -> MAIN BOARD ASSY, AB -> ANALOG BOARD ASSY, PB -> PANEL BOARD ASSY, FB -> FADER BOARD ASSY, CB -> CONTRAST BOARD ASSY
CASING Q’ty
#03121389 BOTTOM COVER 1
# 03121290 DISPLAY COVER 1
# 03121323 DISPLAY ESCUTCHEON 1
# 03121378 POWER SPLY COVER 1
# 03121334 REAR PANEL 1
# 03121278 SIDE PANEL L 1
# 03121289 SIDE PANEL R 1
# 03121267 TOP COVER 1
CHASSIS
# 03121401 ANGLE 2
# 03121489 CD HOLDER 1
# 03121456 HDD HOLDER 1
01786045 SW HOLDER AT-217K 1
# 03121445 PWR SPLY HOLDER 1
KNOB, BUTTON
22485303 D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
# 03121412 KEYTOP L 1
# 03121423 KEYTOP R 1
00901401 KEYTOP PLAY(WHIT GREY) 1
00901412 KEYTOP REC(RED) 1
00901390 KEYTOP STOP(WHIT GREY) 1
02451189 VS KEYTOP SX PERPUL 1
01891801 U R-KNOB S1 LCG BLK 8
01891834 U R-KNOB S1 LCG BLU 1
02565389 U R-KNOB S1 LCG RED 1
01349423 U S-KNOB M1 LCG DCG GRY/BLK 12
01349434 U S-KNOB M1 MRD LCG 1
SWITCH
01786012 JW-M11RKK SEESAW SWITCH 1
00894656 SKQNAD TACT SWITCH SW1 on MB 1
00894645 SKECAF WITHOUT LED TACT SWITCH SW169,SW168,SW172 on PB 3
02891789 SKRGADD010 H=5.0 TACT SWITCH 85
02453834 SPPH430100 PUSH SWITCH SW1 on AB 1
JACK, EXT TERMINAL
01789234 JY-6353-01-250 6.5MM JACK JK15,JK3,JK6,JK12,JK18,JK22,JK24,JK26,JK9
on AB 9
00569278 LGR4609-7100 6.5MM JACK JK21,JK25,JK19,JK16,JK13,JK10,JK7,JK4,JK2
7,JK2 on AB 10
00458801 YKC21-3044 0/0 PIN JACK (ORG)PIN x2 JK2 on MB 1
13429825 YKF51-5054 2PZ MIDI CONNECTOR JK1 on MB 1
# 03124956 YKF51-5399 DIN CONNECTOR JK29,JK28 on AB 2
02455890 YKF42-8039 D-SUB CONNECTOR CN13 on MB 1
01238856
YKF42-8020 (TO PC DISPLAY OUT)
CONNECTOR CN4 on MB 1
01453123 NC3FAV2-0 XLR CONNECTOR JK23,JK1,JK5,JK8,JK11,JK14,JK20,JK17 on
AB 8
DISPLAY UNIT
# 72232112 LCD UNIT ASSY 1
NOTE: Replacement LCD UNIT ASSY should be made on a unit base.
DRIVE UNIT
#03230378 2F040J0 HDD UNIT 1
NOTE: Replacement HDD UNIT should be made on a unit base.
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CONSIDERATION ON PARTS ORDRING
When ordering any parts listed in the parts list, please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or even
undelivered replacement.
NOTE: The parts marked # are new. (initial parts)

11
VS-2400CD
# 03231878 UJDA360RL-Z CD-R/RW DRIVE UNIT 1
NOTE: Replacement CD-R/RW DRIVE UNIT should be made on a unit base.
POWER SUPPLY UNIT
02562889 SWP05 SWITCHING REGULATOR 1
NOTE: Replacement SWITCHING REGULATOR should be made on a unit base.
PCB ASSY
# 72232034 MAIN BOARD ASSY 1
NOTE: ‘MAIN BOARD ASSY’ includes the following parts.
# 03126467 WIRING 4x170-P2.5-LCP-SCN CN6 on MB 1
# 03126456 WIRING 6x300-P2.5-XHP-SCN CN7 on MB 1
00899890 PWB SPACER KGES-12 6
# 72232090 ANALOG BOARD ASSY 1
NOTE: ‘ANALOG BOARD ASSY’ includes the following parts.
# 03126434 WIRING 2x360-P2.5-XHP-SCN CN1 on AB 1
# 03126423 WIRING 5x260-P2.5-XHP-SCN CN2 on AB 1
# 03121478 JACK HOLDER 1
# 72232089 PANEL BOARD ASSY 1
# 72232078 FADER BOARD ASSY 1
NOTE: ‘FADER BOARD ASSY’ includes the following parts.
# 03126445 WIRING 4x350-P2.5-XHP-SCN CN3 on FB 1
# 72232123 CONTRAST BOARD ASSY 1
NOTE: ‘CONTRAST BOARD ASSY’ includes the following parts.
12189804 GROUNDING TERMINAL M1700 4
12199599 GRAND TERMINAL M3 2
# 72232056 CDRW BOARD ASSY 1
71019234 EFFECT EXPANSION BOARD 1
IC
01679156 HD6417014 RF28 IC (32BIT CPU) IC77 on MB 1
02454289 HD6417709AF133 IC (32BIT CPU) IC5 on MB 1
02129089 TMS320VC5402 IC (CPU DSP) IC48 on MB 1
01672867 M38881M2-069FP IC (CPU) IC27 on MB 1
02458978 XCB56364FU100 IC (DSP) IC53,IC54,IC56,IC57,IC58,IC55 on MB 6
00343823 M60205-0601FP IC (GATE ARRAY) IC83 on MB 1
******** MBM29F400BC-90PFTN IC (FLASH MEMORY/BLANK) IC78 on MB 1
******** TC58FVB321FT-10 IC (FLASH MEMORY/BLANK) IC4 on MB 1
02453878 AK4528VF IC (AD/DA) IC17,IC11,IC23,IC5 on AB 4
03018301 K4S641632F-TC75 IC (SDRAM) IC1,IC9 on MB 2
01902034 UPD43256BGU-70LL IC (SRAM) IC79 on MB 1
# 03125034 HY51V16164CSLTC-60 REC IC (DRAM) 1
15169550T0 TC74HC138AP IC (CMOS) IC105,IC104,IC101,IC103 on PB 4
15259865T0 TC74HC4053AF(TP2) IC (CMOS) IC80,IC82 on MB 2
15169556T0 TC74HC574AP IC (CMOS) IC107 on PB 1
# 03126767 TC74LCX245F(EL) IC (CMOS) IC3 on MB 1
00231878 TC74VHC00F(EL) IC (CMOS) 1
00231890 TC74VHC08F(EL) IC (CMOS) IC12 on MB 1
00670290 TC74VHC139F(EL) IC (CMOS) IC47 on MB 1
00893967 TC74VHC153F(EL) IC (CMOS) IC66,IC38 on MB 2
00236889 TC74VHC157F(EL) IC (CMOS) IC81,IC37,IC36,IC11 on MB 4
00893978 TC74VHC393F(EL) IC (CMOS) IC51 on MB 1
00564534 TC74VHC574F(EL) IC (CMOS) 4
00236878 TC74VHC74F-EL IC (CMOS) IC67 on MB 1
01458412 TC74VHCT04AF(EL) IC (CMOS) IC43,IC60 on MB 2
01670789 TC74VHCT08AF IC (CMOS) IC7,IC2 on MB. IC27 on AB 2
+1
00789689 TC74VHCT244AF(EL) IC (CMOS) IC40 on MB 1
01122267 TC74VHCT245F(EL) IC (CMOS) IC21 on MB 1
01901967 TC74VHCT74AF(EL) IC (CMOS) IC62 on MB 1
15249104 TC7S04F(TE85L) IC (CMOS) IC14,IC85 on MB 2
15259884 TC7S08F(TE85L) IC (CMOS) IC84 on MB 1
15259885 TC7S32F(TE85L) IC (CMOS) IC29 on MB 1
02563612 TC7SET00F(TE85L) IC (CMOS) IC69 on MB 1
01786690 TC7SET08F(TE85L) IC (CMOS) IC92 on MB 1
01348901 TC7SH04FU(TE85L) IC (CMOS) IC49 on MB 1
00564701 TC7SH08F(TE85L) IC (CMOS) IC65 on MB 1
# 02561367 TC7SL08F(TE85L) IC (CMOS) IC16 on MB 1
02015190 TC7SZ08F(TE85L) IC (CMOS) IC50 on MB 1
15249121 TC7W04F(TE12L) IC (CMOS) IC17 on MB 1
15249112 TC7W32F(TE12L) IC (CMOS) IC90 on MB 1
01455323 TC7W34FU(TE12L) IC (CMOS) IC26 on MB 1
02232356 TC7WH125FU(TE12L) IC (CMOS) IC76 on MB 1
DRIVE UNIT

12
Jan.2003
01907689 TC7WH157FU(TE12L) IC (CMOS) IC59,IC35 on MB 2
01455312 TC7WH74FU IC (CMOS) IC91,IC72 on MB 1
15249111 TC7WU04F(TE12L) IC (CMOS) IC25 on MB 1
# 03231678 TC7WZ74FU(TE12L) IC (CMOS) 1
02234234 TC74VHCT574AF(EL) IC (CMOS) IC20,IC22 on MB 2
01348101 TC7SET32FU(TE85L) IC (CMOS) IC23 on MB 1
01341567 TC74VHC163F(EL) IC (TTL COUNTER) IC68,IC71 on MB 2
01341578 TC74VHC14F(EL) IC (TTL SCHMITT TRIGGER INV.) IC73,IC70 on MB 2
01458390 TC74LVX244F(EL) IC (TTL) 1
15289128 BA10324AF IC (OP AMP) IC1 on CB 1
15289141 M5223AFP-600D IC (BIPOLAR OP AMP) IC13 on MB 1
15189266 NE-5532AN IC (BIPOLAR OP AMP) 5
15289105 UPC4570G2-E2 IC (BIPOLAR OP AMP) IC9,IC6,IC10,IC12,IC3,IC2,IC8,IC15,IC21,IC
16,IC4,IC18,IC19,IC26,IC24,IC22,IC14 on
AB
17
# 03120356 AK4114VQ IC (DIGITALAUDIO TRANSCEIVER) IC61 on MB 1
02563589 TC74LCX74F IC (EL) IC63 on MB 1
02344478 TC200G08AF-0028 IC (I/F) IC46 on MB 1
02019601 TC203G60AF-0014 IC (I/F) IC39 on MB 1
# 03120545 MD3306BP IC (IDE CONTROL) IC34 on MB 1
02454334 SED1356F0A IC (LCD-DRIVER) IC19 on MB 1
02901723 BA6218 IC (MOTOR DRIVER) IC3,IC5,IC2,IC4,IC11,IC1,IC6,IC12,IC10,IC9
,IC8,IC7,IC13 on FB 13
02565401 GP1FA501RZ RX IC (OPTICAL CONNECTOR) JK3 on MB 1
02565390 GP1FA501TZ TX IC (OPTICAL CONNECTOR) JK4 on MB 1
02900545 PC410LKNIP IC (PHOTO COUPLER) 1
02563534 ICS512MT IC (PLL) IC75 on MB 1
00564690 TC9246F(ELP) IC (PLL) IC44,IC64 on MB 2
15199286 AN78L05M-(E1) IC (REGULATOR) IC45 on MB 1
00458312 NJM2360M IC (REGULATOR) IC2 on CB 1
02230056 PQ07VZ5M2ZP IC (REGULATOR) IC18 on MB 1
02453967 PQ1R18 IC (REGULATOR) IC52 on MB 1
02783601 UPC2925T-T1 IC (REGULATOR) IC33 on MB 1
02454878 M62220FP-600C IC (REGULATOR) IC30 on MB 1
15199937 M51953BFP-600C IC (RESET) 1
01347489 RTC-4543 SA-A IC IC15 on MB 1
TRANSISTOR
01902012 2SA1244Y(TE16L) TRANSISTOR Q2 on MB 1
01121278 2SA1576A T106 QRS TRANSISTOR Q53 on AB 1
15309105 2SA1587-GR(TE85L) TRANSISTOR Q21,Q45,Q37,Q1,Q25,Q13,Q9,Q33 on AB 8
02454390 2SA1588-GR(TE85L) TRANSISTOR Q52 on AB 1
01121289 2SC4081 T106 QRS TRANSISTOR Q46,Q39,Q10,Q14,Q22,Q26,Q34,Q2 on AB 8
01239990 2SC4117-GR(TE85L) TRANSISTOR Q1,Q4,Q5,Q7,Q6 on MB.
Q47,Q42,Q41,Q23,Q29,Q12,Q30,Q35,Q24,Q
48,Q17,Q36,Q11,Q5,Q4,Q18 on AB. Q1 on
CB
5
+1
6
+1
15319115 2SC4213-A(TE85L) TRANSISTOR Q43,Q38,Q3,Q50,Q49,Q44,Q40,Q32,Q31,Q2
8,Q6,Q20,Q19,Q16,Q15,Q8,Q7,Q27 on AB 18
15329103T0 2SK880-GR(TE85R) FET Q51 on AB 1
00239812 DTC114EUT106 DIGITAL TRANSISTOR Q3 on MB. Q54 on AB 1
+1
00019112 TD62381P TRANSISTOR ARRAY IC108 on PB 1
15149134 TD62785P TRANSISTOR ARRAY IC106,IC102 on PB 2
DIODE
02454412 CRG02 (TE85L) RECTIFIER DIODE D2,D1 on AB 2
01780045 RB051L-40 SCHOTTKY DIODE D6 on MB 1
02454856 RB081L-20 TE25 SCHOTTKY DIODE D5 on MB 1
15019126 1SS133 T-77 SWITCHING DIODE D131,D123,D124,D125,D126,D127,D128,D1
30,D169,D132,D133,D134,D135,D136,D137,
D138,D139,D140,D141,D142,D129,D110,D1
43,D101,D102,D103,D104,D105,D106,D107,
D122,D109,D121,D111,D112,D113,D114,D1
15,D116,D117,D118,D119,D120,D108,D178,
D168,D170,D144,D172,D167,D174,D175,
88
D166,D177,D171,D179,D180,D181,D182,D1
83,D184,D185,D186,D187,D188,D176,D151,
D145,D146,D147,D148,D173,D150,D165,D1
52,D153,D154,D164,D156,D157,D158,D159,
D160,D161,D162,D163,D155,D149 on PB
01019534 1SS355 TE-17 SWITCHING DIODE D4,D3,D1,D2 on MB 4
00783034 1SS294(TE85L) DIODE D1 on CB 1
02908890 FTZ6.8E T148 ZENER DIODE D8,D9,D7 on MB 3
03011990 SEL5221S TP15 D RANK LED (RED) LED172,LED104,LED155 on PB 3
00676423 SEL5421E TP15 LED (GREEN) LED108,LED103,LED171 on PB 3
01239856 SEL5921A TP15 LED (ORANGE) LED135,LED143,LED142,LED140,LED138,L
ED144,LED136,LED148,LED134,LED133,LE
D132,LED137,LED145,LED147,LED129,LE
D149,LED150,LED151,LED152,LED153,
54
IC

13
VS-2400CD
LED154,LED156,LED157,LED158,LED146,L
ED116,LED101,LED102,LED105,LED106,LE
D107,LED109,LED110,LED111,LED112,LE
D113,LED131,LED115,LED130,LED117,LE
D118,LED119,LED120,LED121,LED122,LE
D123,LED124,LED125,LED126,LED127,
LED128,LED141,LED114,LED139 on PB
03012001 SML72423C TP15 D RANK LED LED160,LED161,LED162,LED163,LED164,L
ED165,LED166,LED167,LED168,LED169,LE
D170,LED159 on PB
12
01121323 DA204U T106 DIODE ARRAY DA4,DA3,DA5,DA6,DA7,DA1 on MB.
DA2,DA1 on AB 6 +2
01121334 DAN202U T106 DIODE ARRAY DA2 on MB 1
RESISTOR
01788256 RD16ST26A 100 J CARBON RESISTOR R109,R119,R118,R117,R116,R115,R114,R120
,R111,R112,R108,R107,R106,R105,R104,R10
3,R102,R101,R113,R110 on PB
20
15399750 MCR100 39 1W RESISTOR R49 on MB 1
01344723 MCR25 JZH J 220 OHM 1/4W MTL.FILM RESISTOR R326,R335 on AB 2
15399707 MCR25 JZH J 151 MTL.FILM RESISTOR R84,R32,R119,R41,R163,R196,R57,R31,R85,
R136,R135,R5,R104,R4,R118,R56,R276,R216,
R217,R244,R245,R265,R40,R275,R105,R299,
R300,R195,R185,R184,R164,R266 on AB
32
01451423 MCR25 JZH J 682 1/4W MTL.FILM RESISTOR R253,R173,R222,R254,R304,R305,R172,R221
,R141,R6,R140,R92,R91,R60,R59,R7 on AB 16
01011856 RPC05T 0R0 J MTL.FILM RESISTOR R97 on MB. R801 on CDRW Board 1
+1
# 03233201 RPC05T 3R3 J MTL.FILM RESISTOR 1
00566867 RPC05T 100 J MTL.FILM RESISTOR R3,R44 on MB. R353 on AB 2
+1
00566890 RPC05T 150 J MTL.FILM RESISTOR R17,R16,R15,R14,R13 on CB 5
00566912 RPC05T 220 J MTL.FILM RESISTOR R87,R72,R70,R69,R88,R90 on MB 6
00566934 RPC05T 330 J MTL.FILM RESISTOR R193,R184,R185,R186,R187,R188,R189,R190
,R192,R178,R194,R195,R196,R197,R198,R19
1,R93,R63,R74,R75,R76,R77,R78,R180,R92,R
183,R94,R95,R96,R107,R177,R201,R179,R18
1,R182,R81,R202,R203,R204,R205,R206,R20
7,R208,R200,R199 on MB
45
00566967 RPC05T 470 J MTL.FILM RESISTOR R160,R145,R146,R148,R156,R157,R144,R159
,R147,R161,R173,R158,R149 on MB 13
00567001 RPC05T 750 J MTL.FILM RESISTOR R137,R136 on MB 2
00567012 RPC05T 820 J MTL.FILM RESISTOR R86,R68,R73,R89,R91,R71 on MB 6
00567023 RPC05T 101 J MTL.FILM RESISTOR R110,R52,R45,R130,R142 on MB. R350 on
AB. R9 on CB 5 +1
+1
00567034 RPC05T 121 J MTL.FILM RESISTOR R56,R51 on MB 2
00567045 RPC05T 151 J MTL.FILM RESISTOR R42,R41,R40 on MB 3
00567056 RPC05T 181 J MTL.FILM RESISTOR R7 on CB 1
00567067 RPC05T 221 J MTL.FILM RESISTOR R60,R58,R164 on MB 3
00567112 RPC05T 471 J MTL.FILM RESISTOR R138 on MB 1
00567156 RPC05T 102 J MTL.FILM RESISTOR R119,R121,R122,R116,R113,R84,R65,R55,R5
3,R21,R115,R118,R112 on MB. R11 on CB 13 +1
00567178 RPC05T 152 J MTL.FILM RESISTOR R109,R140 on MB 2
00567190 RPC05T 222 J MTL.FILM RESISTOR R1,R5,R4,R2 on CB 4
00567212 RPC05T 332 J MTL.FILM RESISTOR R8 on CB 1
00567245 RPC05T 472 J MTL.FILM RESISTOR R19,R120,R117,R114,R111,R48,R174,R39,R1
6,R17,R15,R13,R12,R11,R10,R9,R8,R7,R47,R
14 on MB
20
00567256 RPC05T 562 J MTL.FILM RESISTOR R64,R83 on MB 2
00567289 RPC05T 103 J MTL.FILM RESISTOR R98,R101,R102,R103,R104,R123,R124,R125,
R82,R127,R79,R128,R129,R150,R151,R152,R
153,R154,R155,R163,R1,R165,R126,R28,R59,
R61,R66,R50,R43,R38,R32,R31,R85,R29,R57,
R26
70
,R175,R166,R25,R23,R22,R6,R5,R4,R2,R67,R
30,R226,R171,R169,R227,R225,R224,R223,R
222,R221,R220,R219,R218,R215,R214,R213,
R212,R211,R210,R209,R228,R172,R217,R170
on MB
00567312 RPC05T 183 J MTL.FILM RESISTOR R10 on CB 1
00567323 RPC05T 223 J MTL.FILM RESISTOR R3 on CB 1
00567456 RPC05T 224 J MTL.FILM RESISTOR R139,R108 on MB 2
00567556 RPC05T 105 J MTL.FILM RESISTOR R62,R46 on MB. R349 on AB 2
+1
00567645 RPC05T 475 J MTL.FILM RESISTOR R24,R27 on MB 2
15399405 RPC10T 222 J 1/10W MTL.FILM RESISTOR R131,R124,R168,R50,R260,R21,R98,R179,R2
02,R249,R284,R294,R12,R45,R212,R88onAB 16
15399421 RPC10T 103 J 1/10W MTL.FILM RESISTOR R355 on AB 1
15399437 RPC10T 473 J 1/10W MTL.FILM RESISTOR R356 on AB 1
15399453 RPC10T 224 J 1/10W MTL.FILM RESISTOR R354 on AB 1
15399457 RPC10T 334 J 1/10W MTL.FLIM RESISTOR R352 on AB 1
01013889 RR1220P-181-D 180 OHM (CHIP) MTL.FILM RESISTOR R33 on MB 1
01013890 RR1220P-221-D 220 OHM (CHIP) MTL.FILM RESISTOR R167 on MB 1
DIODE

14
Jan.2003
01018234 RR1220P-331-D 330 OHM (CHIP) MTL.FILM RESISTOR R34 on MB.
R225,R63,R73,R95,R113,R144,R154,R176,R1
0,R194,R29,R235,R317,R308,R278,R262 on
AB
1
+1
6
00348767 RR1220P-471-D 470 OHM (CHIP) MTL.FILM RESISTOR R257,R291 on AB 2
15419702 RR1220P-102-D 1K OHM (CHIP) MTL.FILM RESISTOR R36 on MB. R336,R327 on AB 1
+2
15419706 RR1220P-122-D 1.2K OHM (CHIP) MTL.FILM RESISTOR R26,R273,R314,R232,R191,R151,R70,R110
on AB 8
00564189 RR1220P-152-D 1.5K OHM (CHIP) MTL.FILM RESISTOR R35 on MB 1
00904701 RR1220P-302-D 3K OHM (CHIP) MTL.FILM RESISTOR R168 on MB 1
00897245 RR1220P-222-D 2.2K OHM (CHIP) MTL.FILM RESISTOR R256,R94,R8,R9,R338,R329,R306,R255,R224,
R223,R175,R174,R143,R61,R142,R62,R93,R3
07 on AB
18
00564212 RR1220P-332-D 3.3K OHM (CHIP) MTL.FILM RESISTOR R341 on AB 1
15419707 RR1220P-472-D 4.7K OHM (CHIP) MTL.FILM RESISTOR R146,R309,R268,R186,R102,R65,R16,R227,R
343 on AB 9
01788834 RR1220P-622-D 6.2K OHM (CHIP) MTL.FILM RESISTOR R23,R214,R14,R47,R52,R90,R101,R126,R133,
R171,R181,R204,R251,R263,R286,R296 on
AB
16
15419729 RR1220P-822-D 8.2K OHM (CHIP) MTL.FILM RESISTOR R283,R11,R30,R44,R55,R298,R103,R120,R26
4,R248,R215,R201,R183,R167,R134,R87 on
AB
16
15419701 RR1220P-103-D 10K OHM (CHIP) MTL.FILM RESISTOR R188,R129,R178,R177,R161,R157,R153,R130
,R123,R116,R112,R107,R97,R148,R242,R292,
R289,R281,R277,R270,R207,R258,R193,R238
,R234,R229,R211,R210,R96,R199,R259,
53
R340,R348,R347,R325,R344,R80,R331,R320,
R316,R311,R18,R72,R293,R19,R76,R67,R49,
R48,R39,R35,R28,R20 on AB
00897234 RR1220P-183-D 18K OHM (CHIP) MTL.FILM RESISTOR R141 on MB 1
15419717 RR1220P-273-D 27K OHM (CHIP) MTL.FILM RESISTOR R333,R322 on AB 2
15419726 RR1220P-393-D 39K OHM (CHIP) MTL.FILM RESISTOR R71,R152,R192,R233,R315,R27,R274,R111
on AB 8
00564234 RR1220P-473-D 47K OHM (CHIP) MTL.FILM RESISTOR R236,R33,R53,R74,R82,R114,R155,R1,R218,
R137,R246,R279,R301,R318,R330,R339,R197
,R165 on AB
18
00560890 RR1220P-823-D 82K OHM (CHIP) MTL.FILM RESISTOR R158,R321,R282,R200,R117,R77,R36,R239
on AB 8
00120289 RR1220P-104-D 100K OHM (CHIP) MTL.FILM RESISTOR R213,R247,R166,R240,R230,R160,R220,R250
,R205,R203,R189,R187,R180,R170,R334,R22
8,R302,R332,R324,R323,R312,R241,R303,R2
52,R295,R288,R287,R285,R271,R269,R261,
66
R310,R38,R169,R66,R58,R54,R78,R46,R79,R
37,R24,R22,R17,R13,R3,R2,R51,R122,R159,R
149,R147,R139,R138,R68,R125,R219,R121,R
108,R106,R99,R89,R86,R83,R132,R206 on AB
01013878 RR1220Q-100-D MTL.FILM RESISTOR R182,R345,R342,R297,R290,R267,R243,R226
,R209,R208,R43,R162,R145,R127,R100,R81,R
64,R42,R128,R15 on AB
20
01345990 RR1220Q-120-D MTL.FILM RESISTOR R25,R109,R190,R231,R272,R69,R313,R150
on AB 8
01455856 RR1220Q-680-D MTL.FILM RESISTOR R37 on MB 1
15419715 RR1220R-105-D MTL.FILM RESISTOR R346 on AB 1
15399953 MCR100-220J 1W RESISTOR (CHIP) R162 on MB 1
01896278 MCR18EZHJ 2R2 MTL.FILM RESISTOR R176 on MB 1
02564078 BPR28F 0.05 OHM K MTL.PLATE RESISTOR R54 on MB 1
01898345 ERY43SA125VA THERMISTOR RESISTOR R143 on MB. R351 on AB 1
+1
01903523 ERTJ1VR153J THERMISTOR RESISTOR R12 on CB 1
15399965 RCE9A103JAG7A (10K OHM x8) RESISTOR ARRAY RA2,RA1 on MB 2
15399968 RCE9A104JA (100K OHM x8) RESISTOR ARRAY RA15,RA6,RA12,RA9 on MB 4
# 03127101 RS4N-1000-J-2 RESISTOR ARRAY RA3,RA4 on MB 2
# 03127123 RS4N-1002-J-2 RESISTOR ARRAY RA19,RA18,RA20,RA21,RA35,RA22,RA36,
RA34,RA33,RA32,RA31,RA30,RA29,RA28,
RA27,RA26,RA11,RA25,RA24,RA23,RA10
on MB
21
POTENTIOMETER
02901734 EVANSA CB1 B14 60M/M MOTOR FADER VR10,VR11,VR1,VR6,VR9,VR12,VR8,VR7,V
R5,VR4,VR2,VR13,VR3 on FB 13
01904401 EVU F2A E25 B53 9M/M ROTARY POT. VR1 on CB 1
02901678 RK09L12D0 50KA L=25 9M/M ROTARY POT. VR9 on AB 1
# 03126412 RK09L1140 10KB L=25 9M/M ROTARY POT. VR10 on AB 1
# 03124945 RK09L1140 50KRD L=25 RR1 9M/M ROTARY POT. VR1,VR2,VR3,VR4,VR5,VR6,VR7,VR8 on
AB 8
CAPACITOR
01674612 ECJ1VB1H103K CERAMIC CAPACITOR C136,C204,C203,C163,C151,C150,C139,C13
7,C87,C138 on MB 18
00568456 ECJ1VF1C474Z CERAMIC CAPACITOR C164 on MB 1
RESISTOR

15
VS-2400CD
01674701 ECJ1VF1E104Z 0.1UF/16VK CERAMIC CAPACITOR C128,C167,C162,C160,C159,C158,C157,C15
6,C154,C153,C152,C226,C124,C127,C146,C1
34,C140,C141,C142,C126,C145,C133,C147,C
148,C132,C174,C131,C168,C129,C143,
132
+6
7
C188,C225,C206,C205,C202,C201,C200,C19
9,C198,C197,C196,C195,C171,C192,C169,C1
85,C183,C182,C181,C180,C179,C178,C177,C
176,C175,C121,C173,C122,C170,C194,
C46,C66,C34,C36,C37,C38,C31,C41,C30,C48
,C51,C52,C53,C56,C59,C123,C39,C17,C1,C3,
C4,C5,C6,C32,C14,C68,C18,C19,C20,C21,C2
3,C24,C27,C29,C9,C110,C99,C64,C102,
C103,C105,C186,C109,C98,C111,C112,C113,
C115,C116,C117,C118,C119,C106,C79,C69,
C70,C71,C73,C74,C100,C78,C97,C80,C82,C8
3,C84,C91,C92,C94,C95,C77,C184 on MB.
C191,C186,C187,C289,C188,C195,C305,C26
6,C263,C260,C259,C258,C267,C282,C283,C1
27,C290,C298,C300,C196,C306,C308,C312,C
320,C257,C255,C253,C246,C222,C216,C215,
C211,C210,C183,C61,C34,C181,C40,C117,C
46,C32,C60,C36,C66,C67,C71,C116,C72,C75
,C100,C107,C47,C149,C179,C114,C109,C44,
C173,C144,C118,C26,C128,C138,C139,C143,
C2,C111 on AB
02568812 ECJ2FB1C474K CERAMIC CAPACITOR C89,C165 on MB 2
01674167 ECUV1H100DCV CERAMIC CAPACITOR C50,C49,C187,C61,C62,C191 on MB 6
01674334 ECUV1H101JCV CERAMIC CAPACITOR C219,C214,C223,C222,C221,C220,C224,C21
8,C217,C215,C213,C212,C211,C210,C209,C2
08,C207,C216 on MB.
C315,C318,C319,C314,C310 on AB
18
+5
01674467 ECUV1H102JCV CERAMIC CAPACITOR C28 on MB 1
15359707 ECUV1H104KN 0.1 CERAMIC CAPACITOR C5 on CB 1
01674190 ECUV1H150JCV CERAMIC CAPACITOR C88,C161 on MB 2
01674212 ECUV1H220JCV CERAMIC CAPACITOR C217,C169,C240,C28,C105,C153,C146,C177,
C248,C225,C82,C4,C16,C39,C74,C98 on AB 16
01674423 ECUV1H471JCV CERAMIC CAPACITOR C193,C26,C25 on MB 3
01674434 ECUV1H561JCV CERAMIC CAPACITOR C311 on AB. C1 on CB 1
+1
00674423 ECA0JM102B 1000U/6.3V CHEMICAL CAPACITOR C35,C14 on FB 2
13639570 ECA1EM101B CHEMICAL CAPACITOR C28,C29,C30,C31,C32,C33,C34 on FB 7
01345956 ECEA1CPZ470B 47PF/16V CHEMICAL CAPACITOR C322,C92,C323,C18,C19,C59,C321,C93,C13
2,C133,C165,C204,C205,C236,C237,C275,C2
76,C164,C57 on AB
19
00568801 ECEA1EPZ470B CHEMICAL CAPACITOR C3,C77,C119,C150,C192,C223,C264,C45 on
AB 8
02562478 ECEA1HPZ101B CHEMICAL CAPACITOR C228,C247,C38,C152,C224,C185,C176,C251,
C159,C113,C104,C88,C42,C21,C15,C293,C2
80,C81 on AB
18
01346001 ECEA1HPZ220B 22UF/50V CHEMICAL CAPACITOR C212,C136,C140,C155,C160,C168,C175,C19
7,C126,C208,C232,C229,C241,C269,C284,C2
91,C294,C301,C7,C200,C49,C122,C249,C27,
C12,C53,C64,C68,C83,C86,C96,C102,C24 on
AB
33
# 15369186 ECEV1VA4R7SR CHEMICAL CAPACITOR C7,C8,C9,C10,C6 on CB 5
01900834 RA2-16V101M-T2 CHEMICAL CAPACITOR C193,C285,C304,C302,C288,C265,C262,C21
3,C190,C142,C141,C125,C120,C70,C69,C58,
C52,C214 on AB
18
01909690 RA2-16V471MC-T2 CHEMICAL CAPACITOR C131,C91,C163,C203,C235,C274,C316,C17,
C56 on AB 9
02230667 RA2-35V4R7MT2 CHEMICAL CAPACITOR C317 on AB 1
02453812 RA2-50V471M-T4 CHEMICAL CAPACITOR C307 on AB 1
01904690 RA2-63V100M-T2 CHEMICAL CAPACITOR C1,C261,C218,C189,C115,C145,C43,C73 on
AB 8
01902590 RA2-6V101MC-T2 CHEMICAL CAPACITOR C297 on AB 1
02121090 RA2-6V103M CHEMICAL CAPACITOR C54 on MB 1
02891756 RC2-6V331M-T2 CHEMICAL CAPACITOR C101,C102 on PB 2
02231223 RFS-16V152MK6ES CHEMICAL CAPACITOR C313,C309 on AB 2
02345145 RV2-16V101M-R CHEMICAL CAPACITOR C42,C93 on MB 2
02344978 RV2-50V2R2M-R CHEMICAL CAPACITOR C57 on MB 1
02345234 RV2-6V101M-R CHEMICAL CAPACITOR C47,C55,C60,C63,C65,C67,C33,C72,C40,C15
5,C149,C144,C135,C114,C125,C75,C120,C10
7,C104,C101,C96,C81,C76,C130,C22,C13,C1
2,C8,C7,C2 on MB. C2 on CB
30
+1
02564867 RV-35V470MG68-R CHEMICAL CAPACITOR C3,C4 on CB 2
# 02904923 RV3-6V331MF80-R CHEMICAL CAPACITOR C166,C58,C228,C190,C229,C230,C35,C172,
C90,C189,C227 on MB 11
02565545 RV-6V331MG68-R CHEMICAL CAPACITOR C801 on CDRW Board 1
13529132 RPE132-901F104Z50 MLT.LAY.CERAMIC CAPACITOR C109,C105,C107,C106,C108 on PB.
C15,C36,C25,C26,C16,C24,C23,C22,C21,C20
,C19,C18,C17,C27 on FB
5
+1
4
# 01458323 RPEF11H103Z2M1A01A MLT.LAY.CERAMIC CAPACITOR C6,C1,C2,C3,C4,C5,C7,C8,C9,C10,C11,C12,
C13 on FB 13
01784156 ECHU1C104JX5 POLYEST. CAPACITOR C299 on AB 1
02018178 ECHU1C223JX5 POLYEST. CAPACITOR C295,C286 on AB 2
01898434 ECHU1H101JX5 POLYEST. CAPACITOR C101,C292,C220,C303,C243,C279,C172,C14
8,C78,C30,C9 on AB 11
CAPACITOR

16
Jan.2003
01899345 ECHU1H121JX5 POLYEST. CAPACITOR C244,C54,C277,C281,C13,C272,C161,C22,C
25,C209,C206,C201,C166,C233,C238,C97,C1
29,C137,C134,C94,C89,C65,C62,C171 on AB
24
01784145 ECHU1H152JX5 POLYEST. CAPACITOR C51,C85,C124,C157,C271,C231,C10,C199 on
AB 8
01905534 ECHU1H221JX5 POLYEST. CAPACITOR C76,C250,C242,C227,C219,C184,C170,C158,
C147,C112,C87,C41,C20,C6,C99,C29 on AB 16
01896589 SK4-0J106MZ4-RA TANTALUM CAPACITOR C106,C252,C33,C35,C182,C108,C110,C178,
C256,C254,C180,C31 on AB 12
02562845 E2012C101 EMI FILTER C43,C45,C44 on MB 3
INDUCTOR, COIL, FILTER
01893634 LQH4N151K04 COIL L1 on CB 1
01904001 TSL1315S-101 CHOKE COIL L7 on MB 1
00907856 BLM21A601SPT FERRITE-BEAD L4,L5,L6,L2,L1,L8,L3 on MB.
L5,L4,L1,L2,L3 on AB 7 +5
01783601 BLM21B601SPT FERRITE-BEAD L10 on MB 1
CRYSTAL, RESONATOR
01126267 MA-406 7.056MHZ CRYSTAL X7 on MB 1
01124812 MA-406 10MHZ CRYSTAL X3 on MB 1
02562812 MA-406 14.31818MHZ CRYSTAL X2 on MB 1
01561956 SG-8002JC-50M-PHCL OSCILLATOR X5 on MB 1
02563556 SG-8002JC-66.6M-PHCL OSCILLATOR X6,X1 on MB 2
ENCODER
01231367 EC16B24204 (L=15) (W/N&W) ROTARY ENCODER EN101 on PB 1
CONNECTOR
01909601 12FE-BT-VK-N CONNECTOR CN12 on MB. CN3 on AB 1
+1
01908645 16FE-BT-VK-N CONNECTOR CN15 on MB 1
02010867 16FE-ST-VK-N CONNECTOR CN1 on FB 1
# 03121101 23FLZ-RSM1-TB CONNECTOR CN1 on CB 1
02120056 24FE-BT-VK-N CONNECTOR CN16 on MB 1
02122467 24FE-ST-VK-N CONNECTOR CN101 on PB 1
02019012 26FE-BT-VK-N CONNECTOR CN18,CN3 on MB 2
02018723 26FE-ST-VK-N CONNECTOR CN4 on AB. CN2 on FB 1
13369570 B2B-PH-K-S (2P) CONNECTOR CN5 on MB 1
13369565 B11B-PH-K-S JST CONNECTOR CN2 on MB. CN3 on CB 1
+1
02349545 P/N 75401-0X0-B CONNECTOR CN8 on MB 1
# 03124967 KX14-50KL7.9H1 CONNECTOR CN802 on CDRW Board 1
02237512 75501-0X0-B CONNECTOR P/N CN9,CN1,CN14 on MB. CN801 on CDRW
Board 3 +1
13379104 TX14-40R-6ST-MH1 B TO B CONNECTOR CN11,CN10 on MB 2
WIRING, CABLE
# 03126390 11x200-P2.0-PHR-PHR WIRING 1
02563867 AC ASSY WIRING 1
# 03126389 CDRW WIRING 1
# 03128167 NIB3-10-005 WIRING 1
# 03126345 BNCD-P=1.25-K-12-120 BAN CARD 1
# 03126334 BNCD-P=1.25-K-26-120 BAN CARD 1
# 03126356 BNCD-P=1.25-K-26-240 BAN CARD 1
# 03126367 BNCD-P=1.25-K-24-500 BAN CARD 1
# 03126378 BNCD-S-P=1.25-K-16-260 BAN CARD 1
TRANSFORMER
02019478 (7KQ5) 19832A PULSE TRANS L9 on MB 1
SCREW
40454956 SCREW M2x2.5 SPECIAL PAN ZNC 4
40011056 SCREW 3x6 BINDING TAPTITE B ZC 40
+2
40012534 SCREW 3x6 BINDING TAPTITE S FE BZC 18
40239889 SCREW M3x6 BUTTON-TRUS TAPTITE S BZC 4
40013056 SCREW M3x6 PAN MACHINE W/SW+PW ZC 13
40011101 SCREW 3x8 BINDING TAPTITE B BZC 17
40011312 SCREW 3x8 BINDING TAPTITE P BZC 5
40011201 SCREW 3x8 PAN TAPTITE P BZC 16
40458345 SCREW M4x8 PAN MACHINE W/SW+SMALL PW NI 1
40342989 SCREW M4x8 PAN W/EX.TOOTH WASHER 1
# 40459590 SCREW M4x20 HEX SOCKET HEAD NI 10
40344134 SCREW M4-40x7.9 HEX SOCKET NI 4
CAPACITOR

17
VS-2400CD
40451412 SCREW 5x10 BINDING A BZC WOOD 4
40450367 SCREW 6-32UNC 1008SR/KM003 4
40456923 NUT M9x11x2P.75 NI 9
40016412 JACK WASHER M9x13.5x0.45 9
PACKING
# 03121501 PAD L 1
# 03121512 PAD R 1
# 03121523 PAD UPPER 1
# 03121490 PACKING CASE 1
MISCELLANEOUS
40238545 CAUTION LABEL SHOCK HAZARD & ICES 1
01455523 CORD BUSHING EDS-1717U 1
00902790 CORD BUSHING EDS-1208U 1
# 03232590 CUSHION ANGLE 1
# 03232612 CUSHION HDD 1
02562956 DC FAN MOTOR 9A0812L403 1
40122434 DOUBLE-FACED TAPE #500 W7MM 20M 30P 1
22355334 FOOT MKS 235-334 4
40016512 INSULOK TIE 80M/M T-18S 2
# 40560801 LABEL PS2 1
# 40561078 LABEL POP SEAL 1
22175349 LEAF SPRING 217-349 1
00238990 LITHIUM BATTERY CR2032 220MAH/3V 1
12569420 LITHIUM BATTERY HOLDER(HL32-A2) for CR2032 BT1 on MB 1
12189817 PCB SPACER RSPLS-10U 1
# 03121467 SHIELD PANEL on MB 1
ACCESSORIES (STANDARD)
# 72231978 OWNER’S MANUAL JAPANESE 1
# 72232856 OWNER’S MANUAL ENGLISH 1
# 40561101 LEAFLET DEMO PERFORMANCES ENGLISH 1
02670401 AC CORD SET 100V YA-101/YP-3N/YC-13 1
00894378 AC CORD SET 120V SP301+IS14 SJT18/3 1
00894389 AC CORD SET 230V SP22+IS14 H05VV-F3G1.0 1
00907001 AC CORD SET 240VE KP-610 GTTBS-3 KS-31A 1
23495124 AC CORD SET 240VA SC-144-JO1 ES303-10HMA 1
02346478 PS/2 MOUSE LOGITECH SAW59A 1
# 03126745 DEMO CD-ROM 1
# ******** BLANK CD-R MEDIA CD-R SR74KC1 1
# 40561067 SHORT CUT SEAL 1
40232334 WARRANTY CARD (JAPAN ONLY) 1
SCREW

18
Jan.2003
CHECKING THE VERSION
NUMBER
While holding down the CH1 [CH EDIT] button and the [TRACK STATUS]
button, turn on the power of the VS-2400CD.
The display shown in “Fig-1”will appear.
fig.21
Boot : Version number and creation date of the program boot area.
System : Version number and creation date of the main program system area.
Sub System : Version number of the program system area.
Check sum : Check sum of each program area.
Total does not include the Sub System check sum.
The VS-2400CD has rewritable program areas for the sub-program that
performs panel-related operations, and for the sub-program that performs
non-panel operations.
You must update both programs to the latest version.
SAVING USER DATA &
RELOADING SAVED DATA
Saving data to CD-R/RW
(Saving the project)
Save the contents of the user’s HDD to CD-R/RW.
Backup can be performed only for an individual partition.
If the HDD contains more than one partition, you must back up each partition
to separate media.
1. From the normal screen, hold down the [SHIFT] button and press the
[PROJECT] button.
The Project Condition screen will appear.
(fig.8)
2. Move the cursor to the partition that you want to back up, and press the
[F6](LIST) button.
3. Move the cursor to the project that you want to back up, and press the
[ENTER/YES] button to mark that project.
If you want to back up more than one project, mark the other projects as
well.
4. Press the [PAGE] button to select Page 3, and press the [F3 (BACKUP)]
button.
The Project Backup screen will appear.
fig.9
•[F1 (Scrol Up)], [F2 (Scrol Down)]
If the list of projects to back up does not fit in one screen, you can use the
scroll buttons to scroll the screen and verify that the desired projects are
Version Information
Boot
Version : 1.001
Create Date : 12/13/2002
Create Time : 13:58:07
System
Version : 1.001
Create Date : 12/13/2002
Create Time : 13:58:07
Sub System
Version : 1.001
Check Sum
Total : 4A1Eh
Boot : 0DF7h
System : D987h
Parameter : 62A0h
Sub System : 6C88h
[ ENTER ]
[Fig-1]
[Fig.8]
[Fig.9]

19
VS-2400CD
selected.
•[F4 (SelDrv)]
Selects the backup-destination drive.
Use the TIME/VALUE dial to specify the copy-destination.
•[F5 (OK)]
Executes the backup.
•[F6 (CANCEL)]
Returns to the Project Condition without backing up.
The parameters that you set in Project Condition will be discarded.
•Verify
If this is “On,”the written data will be checked to verify that it is
readable.
•CD Speed
Selects the speed at which the CD-R disc will be written.
This parameter will be displayed only if the CD-R/RW drive is selected
as the writing-destination.
5. Select the backup destination.
Press the [F4 (SelDrv)] button to access the Drive Select screen.
Use the [TIME/VALUE] knob to move the cursor to the external SCSI
device that will be the backup destination, and press the [F5 (SELECT)]
button.
If the backup destination you select is a CD-RW disc to which data has already
been written, a message of “Finalized CD!!”or “Not Blank CD!”will appear.
If you press the [ENTER/YES] button, the contents that had been saved on the
CD-RW will be completely erased.
If you press the [EXIT/NO] button the disc will not be erased, but you will not
be able to back up to the specified CD-RW disc.
6. Press the [F5 (OK)] button.
If the “STORE Current?”(Store the current project?) dialog box appears,
press the [EXIT/NO] button.
7. If the data of the project(s) being saved is too large to fit on one disc, the
disc will be ejected and the display will indicate
“Please Insert Disk”
Insert the next disc, and press the [ENTER/YES] button.
At this time, the capacity of the saving media will be checked, so we
recommend that you label each disc with a number that indicates the
order in which it should be inserted.
8. When backup ends, the disc will be ejected, and you will return to the
Project Condition screen.
Loading data
(Restoring the project backup)
This procedure will recover a project that was backed up to CD-R/RW,
loading it back into the internal hard disk of the VS-2400CD in a form that
allows the project to be played or edited.
1. From a normal screen, hold down the [SHIFT] button and press the
[PROJECT] button. The Project Condition screen will appear.
fig.8
2. Move the cursor the CD-RW on which the project backup is saved.
3. Press the [PAGE] button to select Page3, and then press the [F2 (Recovr)]
button.
The Project Recover screen will appear.
fig.10
•[F1 (Scrol Up)], [F2 (Scrol Down)]
If the list of recoverable projects does not fit in the screen, use the scroll
buttons to scroll the screen.
•[F4 (SelDrv)]
Selects the recover-destination drive.
Use the [TIME/VALUE] knob to specify the recover-destination.
•[F5 (OK)]
Executes the recover operation.
•[F6 (CANCEL)]
Returns to Project Condition without recovering.
The parameters you set in Project Backup will be discarded.
•Erase All songs
If this is “On”the recover-destination drive will be initialized before
[Fig.8]
[Fig.10]

20
Jan.2003
recovery is performed.
Set this “Off”if you want to perform the recovery while leaving the
project(s) of the recover-destination drive as they are.
•CD Speed
Selects the speed at which the CD-R/RW disc will be read.
4. Select the recover-destination.
Press the [F4 (SelDrv)] button to access the Drive Select screen.
To exit Drive Select, press the [F6 (CANCEL)] button.
5. Press the [F5 (OK)] button.
The “STORE Current?”(Store the current project?) dialog box will
appear. Press the [EXIT/NO] button.
6. If the backup spanned more than one disc, the disc will be ejected and a
message of “Insert Disk #”(# is the disc number) will appear.
Insert the disc of the appropriate number and press the [ENTER/YES]
button.
When project recover is completed, you will return to Project Condition.
TEST MODE
Required equipment
•VS8F-2 (three pcs.)
•R-BUS device (recommended: ADA-7000)
•Foot switch
•Audio device (with digital output)
•A device that can output a SMPTE signal
•Cables (audio)
•Tester (a device that can measure voltages)
Starting test mode
To enter Test mode, hold down the [PAGE] and [F1] buttons located below the
LCD, turn on the power of the VS-2400CD.
Exiting test mode
Turn off the power of the VS-2400CD.
Basic operation
When the test program is started up as described above, the LCD screen of
“Fig.1”will appear.
The upper part of the LCD screen always shows the current version number.
The lower left of the LCD screen shows the test menu and the current audio
input/output checking mode.
The lower right of the screen shows the contents of the selected menu.
Use the [TIME/VALUE] knob to select a test item, and use the [F6] button to
execute it.
Explanation of items checked
when Test mode starts
Here we explain the checked items shown in the lower right of the screen
when Test mode is started.
fig.1
[SDRAM Checked]
Indicates the result of checking SDRAM.
If there is a problem with this, Test mode will not start up.
[VS8F2 Connect Test]
Checks the VS8F-2 connection.
1. The name of the connector on which the VS8F-2 is installed will be
displayed.
2. If all are installed, “A”and “B”will be displayed.
3. If the result is satisfactory, the display will indicate “OK.”If there is a
problem, or if none are installed, the display will indicate “NG.”
[DSP NET Checked]
Main board IC53, IC54, IC55, IC56, IC57, IC58, and VS8F-2 will be checked.
If satisfactory, the display will indicate “OK.”If a problem is found, the
display will indicate “NG.”
[GateArray Checked]
Main board IC38 and IC46 will be checked.
If satisfactory, the display will indicate “OK.”If a problem is found, the
display will indicate “NG.”
[Battery]
The lithium battery on the main board will be checked.
1. If satisfactory, the display will indicate “OK”and show the voltage of the
battery.
2. If unsatisfactory, the display will indicate “NG”and show the voltage of
the battery.
3. If no battery is installed, the display will indicate “<No Battery>”.
[Mouse Connected]
The mouse connection will be checked.
1. If a mouse is connected and is operating normally, the display will
indicate “OK.”
2. If a mouse is not connected, or if there is a problem, the display will
indicate “NG.”
[Fig.1]

21
VS-2400CD
[Keyboard Connected]
The keyboard connection will be checked.
1. If a keyboard is connected and is operating normally, the display will
indicate “OK.”
2. If a keyboard is not connected, or if there is a problem, the display will
indicate “NG.”
Explanation of test items
[01:LCD Check]
Checks the LCD screen display.
Each time you press the switch, three types of screen will alternate; white,
black, and text.
[02:Switch Check]
Checks panel board switch operation.
fig.2
1. Check ON/OFF for all switches on the panel.
2. If two or more switches are pressed simultaneously during this test, the
LED will blink to prompt you not to do so.
[03:LED Check]
Checks panel LED operation.
1. Check that all panel LEDs are lit.
2. Press the [PLAY] button to light the LEDs one at a time.
3. You can press the [STOP] button to go backward.
4. When you have checked all LEDs, they will all be lit.
[04:FS & MV Check]
Checks operation of the foot switch and monitor volume.
fig.3
1. The display will indicate “ON”when you press the foot switch, and
“OFF”when you release it.
2. Verify that the monitor volume causes the display value to change in a
range of “-90”to “+60”.
[05:Encoder Check]
Checks encoder operation.
Turn the [TIME/VALUE] knob at least three clicks to left and right.
[06:Digital Check]
Checks digital audio operation (Coaxial, Optical).
fig.4
1. Connect devices to Coaxial IN/OUT.
2. Press the [F3 (Coax)] button.
3. Verify that the Coaxial LOCK Status is “LOCK,”and that the audio from
Digital In is being output from Digital Out.
4. Connect devices to Optical IN/OUT.
5. Press the [F4 (Opt)] button.
6. Verify that the Optical LOCK Status is “LOCK,”and that the audio from
Digital In is being output from Digital Out.
[07:IDE Check]
Checks IDE hard disk drive operation.
[Fig.2]
[Fig.3]
[Fig.4]
