Roland VS-640i Operating and maintenance manual

SERVICE NOTES
70240-02
Copyright © 2013 ROLAND DG CORPORATION
Condential
TERMS OF USE
Users of this Service Note shall be deemed to agree with the following Terms of Use.
1. USERS
This Service Note is only for authorized persons with user ID and password issued by Roland DG Corporation.
2. PURPOSE
Authorized persons can use this Service Note only for the purposes of selling and providing to the customers
maintenance service of VS-640i/540i/300i.
3. REUSE
Authorized persons shall not disclose, transfer, rent or distribute this Service Note to, or allow this Service Note
to be used in any manner by, any third party other than authorized persons.
4. REPRODUCTION
Authorized persons shall not copy, change or alter this Service Note without permission of Roland DG
Corporation.
5. EFFECT OF VIOLATION
Regardless of circumstances, we will vigorously respond to any violation hereof, through legal action.

Contents
1 Structure & Spare Parts
OVERVIEW......................................................................1-1
1-1 COVER ............................................................................1-2
1-2 PANEL..............................................................................1-3
1-3 FRAME.............................................................................1-4
1-4 LEVER..............................................................................1-5
1-5 BED .................................................................................1-6
1-6 RAIL .................................................................................1-8
RAIL-VS-640i-...................................................................1-9
RAIL-VS-540i-.................................................................1-10
RAIL-VS-300i-.................................................................1-11
1-7 CHASSIS .......................................................................1-12
1-8 SCAN MOTOR ..............................................................1-13
1-9 FEED MOTOR ...............................................................1-14
1-10 HEAD CARRIAGE .......................................................1-15
1-11 TOOL CARRIAGE ........................................................1-16
1-12 WIPER .........................................................................1-17
1-13 CAP..............................................................................1-18
1-14 PUMP...........................................................................1-19
1-15 INK CARTRIDGE .........................................................1-20
1-16 CHOKE VALVE.............................................................1-21
1-17 CIRCULATION PUMP..................................................1-22
1-18 INK TUBE WIRING.......................................................1-23
1-19 PINCH ROLLER...........................................................1-24
1-20 STAND..........................................................................1-25
1-21 ACCESSORY 1 ............................................................1-26
1-22 ACCESSORY 2 ............................................................1-27
2 Electrical Section
2-1 WIRING MAP ..................................................................2-1
2-2 MAIN BOARD ..................................................................2-3
2-3 SERVO BOARD ............................................................2-18
2-4 CARRAGE BOARD .......................................................2-24
2-5 SUB BOARD ..................................................................2-27
3 Replacement of Main Parts
3-1 HEAD REPLACEMENT ...................................................3-5
3-2 DAMPER REPLACEMENT ...........................................3-12
3-3 WIPER REPLACEMENT ...............................................3-20
3-4 FELT WIPER REPLACEMENT .....................................3-23
3-5 WIPER SCRAPER REPLACEMENT .............................3-26
3-6 CAP TOP REPLACEMENT ...........................................3-28
3-7 TOOL CARRIAGE REPLACEMENT .............................3-33
3-8 CARRIAGE MOTOR REPLACEMENT ..........................3-38
3-9 FEED MOTOR REPLACEMENT ...................................3-44
3-10 PUMP REPLACEMENT ..............................................3-55
3-11 BOARD REPLACEMENT (MAIN BOARD)...................3-60
3-12 SW POWER SUPPLY REPLACEMENT......................3-67
3-13 BATTERY REPLACEMENT ........................................3-70
3-14 CARRIAGE BELT REPLACEMENT ...........................3-73
3-15 ENCODER SCALE REPLACEMENT ..........................3-79
3-16 GRIT ENCODER REPLACEMENT ............................3-81
3-17 PINCH ROLLER REPLACEMENT ..............................3-85
3-18 CUTTER PROTECTION REPLACEMENT .................3-86
3-19 CUT RIBBON CABLE REPLACEMENT ......................3-87
3-20 LINEAR ENCODER BOARD REPLACEMENT ...........3-93
3-21 HOW TO FOLD RIBBON CABLE TO THE HEAD .......3-98
3-22 RIBBON CABLE (MAIN BOARD TO CARRIAGE BOARD)
REPLACEMENT ........................................................3-101
4 Adjustment
4-1 SERVICE MODE ..............................................................4-2
4-2 HOW TO UPGRADE/INSTALL FIRMWARE...................4-13
4-3 HEAD ALIGNMENT ........................................................4-20
4-4 LIMIT POSITION & CUT DOWN POSITION
INITIALIZE .....................................................................4-24
4-5 LINEAR ENCODER SETUP ..........................................4-26
4-6 FLUSHING POSITION ADJUSTMENT...........................4-28
4-7 CROP MARK SENSOR ADJUSTMENT .......................4-30
4-8 CROP-CUTADJUSTMENT ...........................................4-33
4-9 PRINT/CUT POSITION ADJUSTMENT .........................4-36
4-10 CALIBRATION(FEEDING DIRECTION) ......................4-39
4-11 TOOL HEIGHTADJUSTMENT ....................................4-41
4-12 TOOL PRESSURE ADJUSTMENT ..............................4-43
4-13 BELT TENSION ADJUSTMENT ...................................4-47
4-14 BELT POSITION ADJUSTMENT .................................4-50
4-15 TAKE-UP UNIT OPERATION CHECK .........................4-57
5 Supplemental Information
5-1 SPECIAL TOOLS..............................................................5-1
5-2 SENSOR MAP..................................................................5-
2
5-3 MOTOR ERROR...............................................................5-
6
5-4 SERVICE CALL................................................................5-
7
6 Service Activities
6-1 INSTALLATION CHECK LIST ..........................................6-1
6-2 MAINTENANCE CHECK LIST........................................6-15
6-3 SPECIFICATION.............................................................6-16

Revision Record
Revision
No. Date Description of Changes Approval Issued
0 2013.9.20 First Edition Onoda Yamane
1 2013.12.9 5-3 MOTOR ERROR, 5-4 SERVICE CALL has been added. Onoda Eiko
2 2014.6.12 1-22 ACCESSORY 2 has been added. Onoda Ito

About and Notices.
Used for instructions intended to alert the operator to the risk of death
or severe injury should the unit be used improperly.
Used for instructions intended to alert the operator to the risk of injury
or material damage should the unit be used improperly.
* material damage refers to damage or other adverse effects caused
with respect to the home and all its furnishings, as well to domestic
animals or pets.
The symbol alerts the user to items that must never be carried out (are
forbidden). The specific thing that must not be done is indicated by the design
contained within the circle.
The symbol at left means not to touch.
The symbol alerts the user to things that must be carried out. The specific
thing that must be done is indicated by the design contained within the circle. The
symbol at left means the power-cord plug must be unplugged from the outlet.
The symbol alerts the user to important instructions or warnings. The specific
meaning of the symbol is determined by the design contained within the triangle.
The symbol at left means “danger of electrocution”.
In addition to the and symbols, the symbols shown below are also used.
: Tips and advise before the adjustment.
To Ensure Safe Work

About the Labels Affixed to the Unit
These labels are affixed to the body of this product.
The following figure describes the location.
Caution: Moving Print Heads
The print heads inside the cover move
at high speed and pose a hazard. Never
insert the hand or fingers into the gap.
Caution: Pinching Hazard
Be careful not to allow the fingers to
become pinched when loading media or
closing covers.
Caution: Moving Print Heads
The print heads inside the front cover
move at high speed and pose a hazard.
Never insert the hand or fingers into the
gap.
Flammable
Ink and discharged fluid are flammable.
Keep away from open flame.
Ink Is Toxic
Ink and discharged fluid are toxic.
Avoid contact with the body. Use only in
a well ventilated area.
Flammable
Ink and discharged fluid are flam-
mable.Keep away from open flame.
Caution: High Temperature
The platen and dryer become hot.
Exercise caution to avoid fire or
burns.
Ink Is Toxic
Ink and discharged fluid are toxic.
Avoid contact with the body. Use
only in a well ventilated area.
Caution: High Voltage
Cover removal may pose hazard
of shock or electrocution due to
high voltage.

WARNING - FOR CONTINUED
PROTECTION AGAINST RISK OF FIRE,
REPLACE ONLY WITH FUSE OF THE
SPECIFIED TYPE AND CURRENT RATING.
F80L HS

1 Structure & Spare Parts
Overview
1-20 STAND
1-1 COVER
1-2 PANEL
1-9 FEED MOTOR
1-19 PINCH ROLLER
1-4 LEVER
1-3 FRAME
1-17 CIRCULATION PUMP
1-16 CHOKE VALVE
1-7 CHASSIS
1-5 BED
1-10 HEAD CARRIAGE
1-11 TOOL CARRIAGE
1-12 WIPER
1-13 CAP
1-14 PUMP
1-8 SCAN MOTOR
1-6 RAIL1-15 INK CARTRIDGE
1-18
INK TUBE WIRING
1-1

1-1 COVER
PARTS LIST -Main Parts- PARTS LIST -Main Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
1000010652 ASSY,COVER FRONT VS-300I 1 20 1000010705 LABEL,SET INK VS-640I#LA1487 1
1000010635 ASSY,COVER FRONT VS-540I 1 21 1000009754 LABEL,USE ECO-SOL MAX2#LA1407 1
1000010623 ASSY,COVER FRONT VS-640I 1 1000007288 PLATE,COVER F VS-300 (VS-300i) 1
2 1000010597 COVER,BACK L VS-640I 1 1000007282 PLATE,COVER F VS-540 (VS-540i) 1
3 1000010593 COVER,CHASSIS VS-640I 1 1000007013 PLATE,COVER F VS-640 (VS-640i) 1
4 1000010596 COVER,EX UNIT VS-640I 1 1000007290 PLATE,NUT COVER F VS-300 (VS-300i) 1
5 1000006793 COVER,MAINTENANCE INKHEAD VS-640 1 1000007283 PLATE,NUT COVER F VS-540 (VS-540i) 1
1000010650 COVER,RAIL B VS-300I 1 1000007015 PLATE,NUT COVER F VS-640 (VS-640i) 1
1000010633 COVER,RAIL B VS-540I 1 24 1000004198 SHAFT,COVER F VP-540 2
1000010595 COVER,RAIL B VS-640I 1 25 1000003089 SHEET,FRAME SUPPORT RAIL VP-540 1
7 1000010594 COVER,RAIL B-RIGHT VS-640I 1 21425110 WASHER,COVER FJ-50 (VS-300i) 8
1000010651 COVER,RAIL F VS-300I 1 21425110 WASHER,COVER FJ-50 (VS-540i) 12
1000010634 COVER,RAIL F VS-540I 1 21425110 WASHER,COVER FJ-50 (VS-640i) 14
1000010617 COVER,RAIL F VS-640I 1
9 1000010702 COVER,SIDE L VS-640I 1
10 1000010703 COVER,SIDE R VS-640I 1
PARTS LIST -Supplemental Parts-
11 12239406 CUSHION,TM-96-6 2 Parts No. Parts Name qt.
1000011682 FRAME,COVER F VS-300I 1 S1 31019703 SCREW,BINDING P-TIGHT M3*8 3C 100P 2
1000011681 FRAME,COVER F VS-540I 1 31289112AS CUPSCREW SET,M3*10 NI 100 PCS. (VS-300i) 3
1000011680 FRAME,COVER F VS-640I 1 31289112AS CUPSCREW SET,M3*10 NI 100 PCS. (VS-540i) 5
13 1000010373 GASKET,STGZ 15-13 L45 5 31289112AS CUPSCREW SET,M3*10 NI 100 PCS. (VS-640i) 6
14 1000007014 HOOK,INT SW R VS-640 1 S3 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 32
15 1000007284 KNOB,COVER FRONT VS-540 1 S4 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. 6
16 1000004160 LABEL, REFLECTION XC-540#LA1041 1 3000000225AS CUP-SCREW,3*4 NI MEKKU 20PICS (VS-300i) 5
17 1000009387 LABEL, WARNING CARRIAGE#LA1365 1 3000000225AS
CUP-SCREW,3*4 NI MEKKU 20PICS (VS-540i/VS-640i)
7
18 1000006358 LABEL,CAUTION LEC-330#LA1149 1 S6 31139103 PLAPOINT,FE4*6 WH 4
19 1000001099 LABEL,HARMFUL FIRE #LA915 1 S7 31049107AS SCREW SET,CAP M3*12 3CBC 20 PCS 1
1
22
S5
S2
6
8
12
23
26
6
5
3
8
9
10
11
11
12
13
34
15
16
17
18
4
19
20
21
22
123
24
24 13 25
26
S1
S2
7
S3
S3
S6
S6
S3 S3
S5
S5
S3
2S3
S3
S4
S4
S4
S7
1-2

1-2 PANEL
PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
W701406010 ASSY,PANEL BOARD VS-640 1 S1 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 8
W702406010 ASSY,PANEL BOARD VS-640I 1 S2 31019149 SCREW SET,BINDING M2.3*8 3CBC 100PCS 2
2 1000010552 CABLE-ASSY,MAINT-COVER SW VS-640I 1
3 23475212 CABLE-CARD,24P1 600L BB 1
4 22495102 KEY TOP,CLEAR GX-24 2
5 22495101 KEY TOP,WHITE GX-24 7
6 1000003029 SHEET,LCD VP-540 1
7 1000010704 SHEET,PANEL VS-640I 1
8 1000006790 STAY,PANEL VS-640 1
1
7
8
2
6
4
5
S2
S1
1
S1
4
3
1-3

1-3 FRAME
PARTS LIST -Main Parts- PARTS LIST -Main Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
1 7520501000 ASSY,CAP BOTTLE 2 FJ-52 1 27 1000006788 STAY,FRAME SIDE R VS-640 1
W701406040 ASSY,FAN JUNCTION BOARD VS-640 1 28 1000002554 STAY,SUPPORT RAIL L VP-540 1
W702406040 ASSY,FAN JUNCTION BOARD VS-640I 1 29 1000006807 SUPPORT,CABLE VS-640 1
3 21985140 BRACKET,INK CATCH TANK SP-540V 1 30 1000010572 SUPPORT,FRAME L VS-640I 1
4 12159508 BUSH,SHAFT OILES 80F-1206 2 31 1000010571 SUPPORT,FRAME R VS-640I 1
5 1000002168 CABLE-ASSY,FAN VP-540 1
6 1000010560 CABLE-ASSY,F-COVER R VS-640I 1
7 1000006695 CABLE-ASSY,M-COVER L VS-640 1
8 1000006785 COVER,INT SW L VS-640 1
PARTS LIST -Supplemental Parts-
9 1000006786 COVER,INT SW R VS-640 1 Parts No. Parts Name qt.
10 1000010590 COVER,L BOTTOM VS-640I 1 S1 31029101 BUSH,NB-19 1
11 1000006792 COVER,UNDER L VS-640 1 S2 31029106 BUSH,SQUARE SB-6025 1
12 1000006756 COVER,UNDER R VS-640 1 S3 31329501AS CLAMP SET,PUSH MOUNT RT30SSF5 20P 3
13 1000010600 FRAME,AUTOCUTTER VS-640I 1 S4 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 20
14 1000010570 FRAME,MIDDLE L VS-640I 1 S5 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. 6
15 1000010569 FRAME,MIDDLE R VS-640I 1 S6 31279121 LABEL,FLASH-LIGHTING NO.E-582 1
16 1000010602 FRAME,RAIL STAY VS-640I 1 S7 31129101 PIPE SET,POLYCA 3*6*8 20PCS 4
17 1000010587 FRAME,SIDE L VS-640I 1 S8 31139103 PLAPOINT,FE4*6 WH 1
18 1000010586 FRAME,SIDE R VS-640I 1 S9 31409702 SADDLE SET,LOCKING WIRE LES-1010 20P 3
19 1000006410 HOLDER,PUMP TUBE SP-300I 1 S10 31409811AS SADDLE SET,LOCKING WIRE LWS-1211Z 20P 2
20 1000003489 LABEL,MARK ECO#LA1014 1 S11 31409801AS SADDLE,LOCKING WIRE LWS-0711Z 20P 14
21 22535444 LABEL,READ MANUAL #LA637 1 S12 31019149 SCREW SET,BINDING M2.3*8 3CBC 100PCS 4
22 22155763 OILES BUSH 80F-0806 1 S13 31049171AS SCREW SET,CAP M3*12 NI 50 PCS. 4
23 1000003088 PAD,BASE BOTTOM VP-540 1 S14 31049170AS SCREW SET,CAP M3*8 NI 50 PCS. 2
24 22055474 PLATE,INK CATCH TANK FJ-52 1 S15 31049169AS SCREW SET,CAP M4*8 3CBC+PW 20PCS 15
25 1000010622 STAY,COVER UNDER VS-640I 1 S16 31239125AS SCREW SET,W-SEMS M3*8 SUS 50 PCS. 2
26 1000010601 STAY,FRAME AC VS-640I 1 S17 31069104 SCREW,CAP M4*6+FL NI 9
2
S10
S3
S11 S10
12
S11
S17
16
S15
S15
28
17
1
24
S16
11
S16 27 18
29
S4
S10
22
3
19
S5
S17
S2
S15 31
4
S9
S15
S3
S15
S14 96S12
23
S7
S13
S11
15
S17
14
30
S15
4
S3
S13
S7
2
5
7
8
S3
S14
S15
S15
S4
10
13
25
26
21
20
S5
S4
S5
S4
S5
S4
S6
S1
S7
S7 S9
S9
S8
S13
S11
S12
S13
S15
S17
1-4

1-4 LEVER
PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
1 21905192 ADAPTER,CLAMP MEDIA SP-540V 2 S1 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 1
2 12159573 BUSH,80F-0603 2 S2 31129101
PIPE SET,POLYCA 3*6*8 20PCS (VS-540i/VS-640i)
1
3 12159563 BUSH,80F-1006 3 S3 31149705 RING SET,E-RING ETW-7 SUS 50PCS 3
4 1000006701 CABLE-ASSY,PINCH UD SENS VS-640 1 S4 31149706AS RING SET,E-RING ETW-10 SUS 20 PCS 1
5 21745109 COLLAR,LEVER FJ-540 2 S5 31049142AS SCREW SET,CAP M3*6 NI MEC 20 PCS 2
6 22305101 GUIDE,LEVER SP-300 1 S6 31049169AS SCREW SET,CAP M4*8 3CBC+PW 20PCS 5
7 1000001601 KNOB,XC-540 1 S7 31049173AS SCREW SET,CAP M4*10 NI 50 PCS. 1
8 1000006809 LEVER,CAM PINCH VS-640 1 S8 31049137AS SCREW SET,CAP M4*25 3CBC 20 PCS 3
9 22175105 PINCH ROLL SPRING 1 S9 31049171AS
SCREW SET,CAP M3*12 NI 50 PCS. (VS-540i/VS-640i)
1
10 1000002609 PLATE,LEVER LINK VP-540 1
11 1000006689 SENSOR-INTERRUPTER,EE-SX4009-P1 1
12 22145393 SHAFT,JOINT PNC-960 1
22295270 SHAFT,SQUARE SP-300 (VS-300i) 1
1000002526 SHAFT,SQUARE VP-540 (VS-540i) 1
1000004767 SHAFT,SQUARE RS-640 (VS-640i) 1
14 22035196 STAND,LEVER SP-300 1
15 1000002555 STAY,LEVER SENSOR VP-540 1
16 1000009349 STAY,PINCH LEVER ADJUST RE-640 1
17 1000009348 STAY,PINCH LEVER RE-640 1
13
13
1
2
3
3
3
4
1
5
6
7
8
10
11
12
9
14
15
16
17
S8
S8
S5
S7
S6
S6
S6
S6
S1
S3
S3
S3
S4
S2
S9
1-5

1-5 BED
1
2
3
4
4
5
6
7
7
8
8
9
9
10
10
11
12
13
13
14
14
15
16
18
19
17
17
20
20
S1
S1
S2
S2
S2
S2
S3
S4
S5
S5
S5
S5
S6
S6
S7
S7
S8
S8
S9
S9
S9
S9
S10
S11
S11
S12
S13
S13
S12
S14
S14
S16
S15
S15
S15
S15
S15
S15
S15
S15
S15
S15
S6
S15
5
S5
S5
S5
S5
S5
S5
S5
S5
S14
S14
S14
S3
1-6

1-5 BED
PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
1000010649 APRON,B VS-300I 1 S1 31029101 BUSH,NB-19 2
1000010632 APRON,B VS-540I 1 S2 31329601AS CLAMP SET,INSULOK T-18S 100 PCS. 4
1000010598 APRON,B VS-640I 1 31329501AS CLAMP SET,PUSH MOUNT RT30SSF5 20P (VS-300i) 8
1000011688 APRON,F AL VS-300I 1 31329501AS CLAMP SET,PUSH MOUNT RT30SSF5 20P (VS-540i) 11
1000011686 APRON,F AL VS-540I 1 31329501AS CLAMP SET,PUSH MOUNT RT30SSF5 20P (VS-640i) 12
1000011684 APRON,F AL VS-640I 1 31289112AS CUPSCREW SET,M3*10 NI 100 PCS. (VS-300i) 10
1000007244 APRON,F UNDER VS-300 (VS-300i) 1 31289112AS CUPSCREW SET,M3*10 NI 100 PCS. (VS-540i) 16
1000007199 APRON,F UNDER VS-540 (VS-540i) 1 31289112AS CUPSCREW SET,M3*10 NI 100 PCS. (VS-640i) 18
1000006802 APRON,F UNDER VS-640 (VS-640i) 1 S5 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 22
1000002166 ASSY,CORD HEATER VP-300 (VS-300i) 2 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. (VS-300i) 7
1000002165 ASSY,CORD HEATER VP-540 (VS-540i) 2 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. (VS-540i/VS-640i) 10
1000004792 ASSY,CORD HEATER RS-640 (VS-640i) 2 S7 31279106 LABEL,CAUTION HOT SURF NO.778 2
W701406060 ASSY,THERMISTOR BOARD VS-640 2 S8 31299102AS RIVET SET,NYLON P2655B 20 PCS. 4
W702406060 ASSY,THERMISTOR BOARD VS-640I 2 S9 31409702 SADDLE SET,LOCKING WIRE LES-1010 20P 6
6700469060 ASSY,THERMISTOR BOARD SERVICE 2 S10 31409801AS SADDLE,LOCKING WIRE LWS-0711Z 20P 2
1000002183 CABLE-ASSY,HEATER VP-540 (VS-300i) 4 31019124 SCREW SET,BINDING M3*35 NI 50 PCS (VS-300i) 3
1000004791 CABLE-ASSY,HEATER RS-640 (VS-540i) 4 31019124 SCREW SET,BINDING M3*35 NI 50 PCS (VS-540i/VS-640i) 6
1000010556 CABLE-ASSY,HEATER VS-640I (VS-640i) 4 S12 31019142AS SCREW SET,BINDING M3*4 NI 100PCS. 4
7 1000010553 CABLE-ASSY,PAPER SENSOR VS-640I 1 S13 31049170AS SCREW SET,CAP M3*8 NI 50 PCS. 2
8 1000002181 CABLE-ASSY,THERMISTOR VP-540 2 31049169AS SCREW SET,CAP M4*8 3CBC+PW 20PCS (VS-300i) 10
9 1000010554 CABLE-ASSY,THERMOSTAT VS-640I 2 31049169AS SCREW SET,CAP M4*8 3CBC+PW 20PCS (VS-540i/VS-640i) 18
1000000764 FAN,A35577-55ROL (VS-300i) 1 31019703 SCREW,BINDING P-TIGHT M3*8 3C 100P (VS-300i) 18
1000000764 FAN,A35577-55ROL (VS-540i/VS-640i) 2 31019703 SCREW,BINDING P-TIGHT M3*8 3C 100P (VS-540i/VS-640i) 30
11 1000006794 FRAME,SIDE BED L VS-640 1 31179106 SCREW,JACK UP SP-540V (VS-300i) 2
1000002656 PAD,CUTTER VP-300 (VS-300i) 1 31179106 SCREW,JACK UP SP-540V (VS-540i/VS-640i) 6
1000002598 PAD,CUTTER VP-540 (VS-540i) 1
1000006713 PAD,CUTTER VS-640 (VS-640i) 1
13 15099124 SENSOR,US-602SXTLAS 65OFF 50ON 2
14 15099115 SENSOR-INTERRUPTER GP2A25NJ 2
15 1000002600 SHUTTER,BED L VP-540 1
16 1000002599 SHUTTER,BED R VP-540 1
17 21625103 SHUTTER,HEATER CORD SP-300 2
1000011689 STAY,DRY HEATER 2 VS-300I 1
1000011687 STAY,DRY HEATER 2 VS-540I 1
1000011685 STAY,DRY HEATER 2 VS-640I 1
1000002669 STAY,DRY HEATER VP-300 (VS-300i) 1
1000002606 STAY,DRY HEATER VP-540 (VS-540i) 1
1000009778 STAY,DRY HEATER RS-640_01 (VS-640i) 1
20 1000002585 STAY,PAPER SENSOR VP-540 2
2
3
4
19
S3
S4
S6
S11
S14
1
5
18
S15
S16
6
10
12
1-7

1-6 RAIL
30
29
1
1
1
2
S5
S10
S5
4
14
16
S1
48
S20
21
S5
S5
S5
S5
55
53
S10
19
S2
S3
S18
S7
S18
S7
S22
S22
6
6
52
S27
S6 S19
S18
5
41
41
38
43
S9
S9
7
S4
15
S17
S17
S8
S8
3S10
S1
S10
20
20
33
25
18
11
11
46
23
39
34
42
8
S5 S16
S5
12
32
10
S5
13
28
S5
26
35
36
37
40
9
44
S5
S5
47
49
S4
50
S5
51
S14
S10
S10
S10
S15
S12
S21
31
S13
S11
S5
S5
54
S5
24
17
45
22
S5
S5
1-8

1-6 RAIL - VS-640i -
PARTS LIST -Main Parts- PARTS LIST -Main Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
W701406090 ASSY,FLEX 1 VS-640 3 47 1000003665 SHEET,LINEAR SCALE XJ-540 1
W702406090 ASSY,FLEX 1 VS-640I 3 48 1000010580 SHEET,TUBE GUIDE VS-640I 1
W7014060A0 ASSY,FLEX 2 VS-640 1 49 22175122 SPRING,BACK UP PNC-960 1
W7024060A0 ASSY,FLEX 2 VS-640I 1 50 22715469 STAY,HOLD SHAFT SQUARE SP-540V 1
W7014060B0 ASSY,FLEX 3 VS-640 1 51 1000002597 STAY,RAILGUIDE L VP-540 1
W7024060B0 ASSY,FLEX 3 VS-640I 1 52 22135441 STOPPER,LINEAR SCALE FJ-540 1
W701406080 ASSY,JUNCTION BOARD VS-640 1 53 1000010579 SUPPORT,CUT CABLE VS-640I 1
W702406080 ASSY,JUNCTION BOARD VS-640I 1 54 1000002617 SUPPORT,GUIDE CABLE VP-540 1
5 6700469030 ASSY,PULLEY VP-540 1 55 1000010577 SUPPORT,GUIDE CABLE VS-640I 1
6 1000002589 BASE,RAIL VP-540 2
7 1000010581 BELT,150S2M2428LW-C 1
8 1000010558 CABLE-ASSY,CUT-CAR ORG VS-640I 1
9 1000006822 CABLE-CARD,15P1 2850L BB HIGH-V 1
10 1000010566 CABLE-CARD,26P1 2440L BB HIGH-V 1
11 1000010565 CABLE-CARD,36P1 3100L BB HIGH-V 3 PARTS LIST -Supplemental Parts-
12 1000006704 CABLE-CARD,40P1 400L BB HIGH-V 1 Parts No. Parts Name qt.
13 1000006757 COVER,INNER VS-640 1 S1 31029106 BUSH,SQUARE SB-6025 2
14 1000006801 COVER,JUNCTION BOARD VS-640 1 S2 3000000033 CLAMP,WIRE PLESS RFC-45VO 6
15 1000010625 COVER,RAIL SIDE L VS-640I 1 S3 3000000030 CLAMP,WIRE PRESS RFC-33V0 5
16 1000010576 COVER,RAIL SIDE VS-640I 1 S4 31289111AS CUPSCREW SET, M4*6 NI 100 PCS. 20
17 1000010620 CUSHION,TUBE GUIDE VS-640I 2 S5 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 31
18 1000011050 FILTER(E),FRCN40-12-1.7-K 3 S6 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. 4
19 1000010575 FRAME,SUPPORT RAIL VS-640I 1 S7 31119904 PIN,SPRING 2.5*8 SUS STRAIGHT 50 PCS 4
20 1000006711 GUIDE,CABLE FLEX-CUT VS-640 2 S8 31129102 PIPE SET,POLYCA 4*8*10 20PCS 2
21 1000010578 GUIDE,CUT CABLE VS-640I 1 S9 31149704AS RING SET,E-RING ETW-6 SUS 100 PCS 2
22 1000006514 GUIDE,TUBE 10 VS-640 1 S10 31299102AS RIVET SET,NYLON P2655B 20 PCS. 24
23 1000010114 GUIDE,TUBE XF-640 26 S11 31409702 SADDLE SET,LOCKING WIRE LES-1010 20P 1
24 1000009392 HOLDER,BACKUP SHAFTSQUARE RE-640 1 S12 31409811AS SADDLE SET,LOCKING WIRE LWS-1211Z 20P 6
25 1000010607 HOLDER,CABLE F VS-640I 1 S13 31409801AS SADDLE,LOCKING WIRE LWS-0711Z 20P 1
26 1000010606 HOLDER,CABLE VS-640I 1 S14 3000000081 SADDLE,LOCKING WIRE RLWT-0.5V0 20pcs. 5
27 1000001555 HOLDER,IDLE PULLEY XC-540 1 S15 31049155AS SCREW SET,CAP M3*12 BC+PW 20 PCS. 20
28 21655131 HOLDER,LINEAR SCALE CJ-70 1 S16 31049173AS SCREW SET,CAP M4*10 NI 50 PCS. 1
29 1000002971 LABEL,G-ROLLER 170 VP-540 #LA978 1 S17 31049174AS SCREW SET,CAP M4*15 NI 20 PCS. 2
30 1000002970 LABEL,G-ROLLER 50 VP-540 #LA977 7 S18 31049137AS SCREW SET,CAP M4*25 3CBC 20 PCS 7
31 1000002685 LABEL,PINCH ROLL VP-540#LA968 1 S19 31049169AS SCREW SET,CAP M4*8 3CBC+PW 20PCS 2
32 1000010667 L-BEARING,SSR15XW1GGE/W2GE+2320L(B) 1 S20 31089110AS SCREW SET,PAN M3*4 NI+PW 100 PCS 5
33 1000006516 PLATE,CABLE CUT VS-640 1 S21 31239103AS SCREW SET,W-SEMS M3*8 NI+PW 50 PCS 9
34 1000002581 PLATE,CUT ORIGIN VP-540 1 S22 31069104 SCREW,CAP M4*6+FL NI 4
35 1000010605 PLATE,HOLDER CABLE VS-640I 1
36 22055316 PLATE,LINEAR SCALE CJ-70 1
37 1000010574 PLATE,RAIL REAR VS-640I 1
38 1000001904 PULLEY,T55P2S16(B21C26) 1
39 1000010573 RAIL,GUIDE VS-640I 1
40 1000006789 RAIL,LINEAR SCALE VS-640 1
41 22175815 BEARING F8-16ZZ 2
42 1000006689 SENSOR-INTERRUPTER,EE-SX4009-P1 1
43 1000001479 SHAFT,IDLE PULLEY XC-540 1
44 1000010619 SHEET,CHOKE CABLE VS-640I 1
45 1000003089 SHEET,FRAME SUPPORT RAIL VP-540 5
46 1000010608 SHEET,HOLDER CABLE VS-640I 2
1
2
3
4
1-9

1-6 RAIL - VS-540i -
PARTS LIST -Main Parts- PARTS LIST -Main Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
W701406090 ASSY,FLEX 1 VS-640 3 47 1000002544 SHEET,LINEAR SCALE VP-540 1
W702406090 ASSY,FLEX 1 VS-640I 3 48 1000010637 SHEET,TUBE GUIDE VS-540I 1
W7014060A0 ASSY,FLEX 2 VS-640 1 49 22175122 SPRING,BACK UP PNC-960 1
W7024060A0 ASSY,FLEX 2 VS-640I 1 50 22715469 STAY,HOLD SHAFT SQUARE SP-540V 1
W7014060B0 ASSY,FLEX 3 VS-640 1 51 1000002597 STAY,RAILGUIDE L VP-540 1
W7024060B0 ASSY,FLEX 3 VS-640I 1 52 22135441 STOPPER,LINEAR SCALE FJ-540 1
W701406080 ASSY,JUNCTION BOARD VS-640 1 53 1000010579 SUPPORT,CUT CABLE VS-640I 1
W702406080 ASSY,JUNCTION BOARD VS-640I 1 54 1000002617 SUPPORT,GUIDE CABLE VP-540 1
5 6700469030 ASSY,PULLEY VP-540 1 55 1000010577 SUPPORT,GUIDE CABLE VS-640I 1
6 1000002589 BASE,RAIL VP-540 2
7 1000010628 BELT,150S2M2168LW-C 1
8 1000010558 CABLE-ASSY,CUT-CAR ORG VS-640I 1
9 1000006822 CABLE-CARD,15P1 2850L BB HIGH-V 1
10 1000006821 CABLE-CARD,26P1 2330L BB HIGH-V 1
11 1000004962 CABLE-CARD,36P1 2930L BB HIGH-V 3 PARTS LIST -Supplemental Parts-
12 1000006704 CABLE-CARD,40P1 400L BB HIGH-V 1 Parts No. Parts Name qt.
13 1000006757 COVER,INNER VS-640 1 S1 31029106 BUSH,SQUARE SB-6025 2
14 1000006801 COVER,JUNCTION BOARD VS-640 1 S2 3000000033 CLAMP,WIRE PLESS RFC-45VO 6
15 1000010625 COVER,RAIL SIDE L VS-640I 1 S3 3000000030 CLAMP,WIRE PRESS RFC-33V0 5
16 1000010576 COVER,RAIL SIDE VS-640I 1 S4 31289111AS CUPSCREW SET, M4*6 NI 100 PCS. 18
17 1000010620 CUSHION,TUBE GUIDE VS-640I 2 S5 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 30
18 1000011050 FILTER(E),FRCN40-12-1.7-K 3 S6 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. 4
19 1000010639 FRAME,SUPORT RAIL VS-540I 1 S7 31119904 PIN,SPRING 2.5*8 SUS STRAIGHT 50 PCS 4
20 1000002591 GUIDE,CABLE FLEX-CUT VP-540 2 S8 31129102 PIPE SET,POLYCA 4*8*10 20PCS 2
21 1000010640 GUIDE,CUT CABLE VS-540I 1 S9 31149704AS RING SET,E-RING ETW-6 SUS 100 PCS 2
22 1000006514 GUIDE,TUBE 10 VS-640 1 S10 31299102AS RIVET SET,NYLON P2655B 20 PCS. 24
23 1000010114 GUIDE,TUBE XF-640 24 S11 31409702 SADDLE SET,LOCKING WIRE LES-1010 20P 1
24 1000009392 HOLDER,BACKUP SHAFTSQUARE RE-640 1 S12 31409811AS SADDLE SET,LOCKING WIRE LWS-1211Z 20P 6
25 1000010643 HOLDER,CABLE F VS-540I 1 S13 31409801AS SADDLE,LOCKING WIRE LWS-0711Z 20P 1
26 1000010642 HOLDER,CABLE VS-540I 1 S14 3000000081 SADDLE,LOCKING WIRE RLWT-0.5V0 20pcs. 5
27 1000001555 HOLDER,IDLE PULLEY XC-540 1 S15 31049155AS SCREW SET,CAP M3*12 BC+PW 20 PCS. 18
28 21655131 HOLDER,LINEAR SCALE CJ-70 1 S16 31049173AS SCREW SET,CAP M4*10 NI 50 PCS. 1
29 1000002971 LABEL,G-ROLLER 170 VP-540 #LA978 1 S17 31049174AS SCREW SET,CAP M4*15 NI 20 PCS. 2
30 1000002970 LABEL,G-ROLLER 50 VP-540 #LA977 6 S18 31049137AS SCREW SET,CAP M4*25 3CBC 20 PCS 7
31 1000002685 LABEL,PINCH ROLL VP-540#LA968 1 S19 31049169AS SCREW SET,CAP M4*8 3CBC+PW 20PCS 4
32 1000010668 L-BEARING,SSR15XW1GGE/W2GE+2050L(B) 1 S20 31089110AS SCREW SET,PAN M3*4 NI+PW 100 PCS 5
33 1000002613 PLATE,CABLE CUT VP-540 1 S21 31239103AS SCREW SET,W-SEMS M3*8 NI+PW 50 PCS 8
34 1000002581 PLATE,CUT ORIGIN VP-540 1 S22 31069104 SCREW,CAP M4*6+FL NI 4
35 1000010641 PLATE,HOLDER CABLE VS-540I 1
36 22055316 PLATE,LINEAR SCALE CJ-70 1
37 1000010638 PLATE,RAIL REAR VS-540I 1
38 1000001904 PULLEY,T55P2S16(B21C26) 1
39 1000010636 RAIL,GUIDE VS-540I 1
40 1000007203 RAIL,LINEAR SCALE VS-540 1
41 22175815 BEARING F8-16ZZ 2
42 1000006689 SENSOR-INTERRUPTER,EE-SX4009-P1 1
43 1000001479 SHAFT,IDLE PULLEY XC-540 1
44 1000010644 SHEET,CHOKE CABLE VS-540I 1
45 1000003089 SHEET,FRAME SUPPORT RAIL VP-540 4
46 1000006798 SHEET,HOLDER CABLE VS-640 2
1
2
3
4
1-10

1-6 RAIL - VS-300i -
PARTS LIST -Main Parts- PARTS LIST -Main Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
W701406090 ASSY,FLEX 1 VS-640 2 47 1000002665 SHEET,LINEAR SCALE VP-300 1
W702406090 ASSY,FLEX 1 VS-640I 2 48 1000010654 SHEET,TUBE GUIDE VS-300I 1
W7014060A0 ASSY,FLEX 2 VS-640 1 49 22175122 SPRING,BACK UP PNC-960 1
W7024060A0 ASSY,FLEX 2 VS-640I 1 50 22715469 STAY,HOLD SHAFT SQUARE SP-540V 1
W7014060B0 ASSY,FLEX 3 VS-640 1 51 1000002597 STAY,RAILGUIDE L VP-540 1
W7024060B0 ASSY,FLEX 3 VS-640I 1 52 22135441 STOPPER,LINEAR SCALE FJ-540 1
W701406080 ASSY,JUNCTION BOARD VS-640 1 53 1000010659 SUPPORT,CUT CABLE VS-300I 1
W702406080 ASSY,JUNCTION BOARD VS-640I 1 54 1000002617 SUPPORT,GUIDE CABLE VP-540 1
5 6700469030 ASSY,PULLEY VP-540 1 55 1000010658 SUPPORT,GUIDE CABLE VS-300I 1
6 1000002589 BASE,RAIL VP-540 2
7 1000010645 BELT,100S2M1554LW-C 1
8 1000010558 CABLE-ASSY,CUT-CAR ORG VS-640I 1
9 1000007175 CABLE-CARD,15P1 2240L BB HIGH-V 1
10 1000007176 CABLE-CARD,26P1 1770L BB HIGH-V 1
11 1000007177 CABLE-CARD,36P1 2370L BB HIGH-V 3
PARTS LIST -Supplemental Parts-
12 1000006704 CABLE-CARD,40P1 400L BB HIGH-V 1 Parts No. Parts Name qt.
13 1000006757 COVER,INNER VS-640 1 S1 31029106 BUSH,SQUARE SB-6025 2
14 1000006801 COVER,JUNCTION BOARD VS-640 1 S2 3000000033 CLAMP,WIRE PLESS RFC-45VO 4
15 1000010625 COVER,RAIL SIDE L VS-640I 1 S3 3000000030 CLAMP,WIRE PRESS RFC-33V0 3
16 1000010576 COVER,RAIL SIDE VS-640I 1 S4 31289111AS CUPSCREW SET, M4*6 NI 100 PCS. 16
17 1000010620 CUSHION,TUBE GUIDE VS-640I 2 S5 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 29
18 1000011050 FILTER(E),FRCN40-12-1.7-K 3 S6 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. 4
19 1000010656 FRAME,SUPORT RAIL VS-300I 1 S7 31119904 PIN,SPRING 2.5*8 SUS STRAIGHT 50 PCS 4
20 1000002667 GUIDE,CABLE FLEX-CUT VP-300 2 S8 31129102 PIPE SET,POLYCA 4*8*10 20PCS 2
21 1000010657 GUIDE,CUT CABLE VS-300I 1 S9 31149704AS RING SET,E-RING ETW-6 SUS 100 PCS 2
22 1000006514 GUIDE,TUBE 10 VS-640 1 S10 31299102AS RIVET SET,NYLON P2655B 20 PCS. 22
23 1000010114 GUIDE,TUBE XF-640 18 S11 31409702 SADDLE SET,LOCKING WIRE LES-1010 20P 1
25 1000010662 HOLDER,CABLE VS-300I 1 S12 31409811AS SADDLE SET,LOCKING WIRE LWS-1211Z 20P 4
26 1000010663 HOLDER,CABLE F VS-300I 1 S13 31409801AS SADDLE,LOCKING WIRE LWS-0711Z 20P 1
27 1000001555 HOLDER,IDLE PULLEY XC-540 1 S14 3000000081 SADDLE,LOCKING WIRE RLWT-0.5V0 20pcs. 5
28 21655131 HOLDER,LINEAR SCALE CJ-70 1 S15 31049155AS SCREW SET,CAP M3*12 BC+PW 20 PCS. 13
29 1000002971 LABEL,G-ROLLER 170 VP-540 #LA978 1 S16 31049173AS SCREW SET,CAP M4*10 NI 50 PCS. 1
30 1000002970 LABEL,G-ROLLER 50 VP-540 #LA977 3 S17 31049174AS SCREW SET,CAP M4*15 NI 20 PCS. 2
31 1000002685 LABEL,PINCH ROLL VP-540#LA968 1 S18 31049137AS SCREW SET,CAP M4*25 3CBC 20 PCS 7
32 1000010669 L-BEARING,SSR15XW1GGE/W2GE+1440L(B) 1 S19 31049169AS SCREW SET,CAP M4*8 3CBC+PW 20PCS 4
33 1000002674 PLATE,CABLE CUT VP-300 1 S20 31089110AS SCREW SET,PAN M3*4 NI+PW 100 PCS 5
34 1000002581 PLATE,CUT ORIGIN VP-540 1 S21 31239103AS SCREW SET,W-SEMS M3*8 NI+PW 50 PCS 6
35 1000007221 PLATE,HOLDER CABLE VS-420 1 S22 31069104 SCREW,CAP M4*6+FL NI 4
36 22055316 PLATE,LINEAR SCALE CJ-70 1
37 1000010655 PLATE,RAIL REAR VS-300I 1
38 1000001904 PULLEY,T55P2S16(B21C26) 1
39 1000010653 RAIL,GUIDE VS-300I 1
40 1000007248 RAIL,LINEAR SCALE VS-300 1
41 22175815 BEARING F8-16ZZ 2
42 1000006689 SENSOR-INTERRUPTER,EE-SX4009-P1 1
43 1000001479 SHAFT,IDLE PULLEY XC-540 1
44 1000010660 SHEET,CHOKE CABLE VS-300I 1
45 1000003089 SHEET,FRAME SUPPORT RAIL VP-540 3
46 1000010664 SHEET,HOLDER CABLE VS-300I 2
1
2
3
4
1-11

1-7 CHASSIS
PARTS LIST -Main Parts- PARTS LIST -Main Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
1 6702419000 ASSY,MAIN BOARD VS-640I 1 21 12559105 FUSE,5X20 021706.3MXP 6.3A/250V 2
W701406020 ASSY,POWER BOARD VS-640 1 22 13429702 INLET AC P01CF01 15A250V 1
W702406020 ASSY,POWER BOARD VS-640I 1 23 1000002682 LABEL,LAN VP-540#LA964 1
3 1000010546 ASSY,SERVO BOARD VS-640I 1 24 22535117 LABEL,POWER CM-500 NO.893 1
4 15009101 BATTERY CR2032 1 25 13129170 POWER SW AJ7201B 1
1000002044 CABLE-ASSY,117V SELECTOR XC-540 2 26 1000006130 POWER UNIT,LEB150F-0536-XRLD A 1
1000002043 CABLE-ASSY,230V SELECTOR XC-540 2 27 1000010592 STAY,CABLE VS-640I 1
6 1000002189 CABLE-ASSY,JUNBI A VP-540 1 28 1000002566 STAY,CHASSIS FAN VP-540 1
7 1000002190 CABLE-ASSY,JUNBI B VP-540 1
8 23415268 CABLE-ASSY AC GROUND GREEN SP-540 1
9 23415116 CABLE ASSY,JUNBI D SP-300 1
10 1000002173 CABLE-ASSY,JUNBI E VP-540 1
11 23415117 CABLE ASSY,POWER MAIN SP-300 1
12 1000004961 CABLE-ASSY,POWER SERVO RS-540 1
PARTS LIST -Supplemental Parts-
13 1000002180 CABLE-ASSY,RELAY JUNCTION VP-540 1 Parts No. Parts Name qt.
14 23475197 CABLE CARD 25P1 105L BB FJ-540 1 S1 31029106 BUSH,SQUARE SB-6025 3
1000007177 CABLE-CARD,36P1 2370L BB HIGH-V (VS-300i) 3 S2 31289111AS CUPSCREW SET, M4*6 NI 100 PCS. 1
1000004962 CABLE-CARD,36P1 2930L BB HIGH-V (VS-540i) 3 S3 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 20
1000010565 CABLE-CARD,36P1 3100L BB HIGH-V (VS-640i) 3 S4 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. 2
16 1000010591 CHASSIS,VS-640I 1 S5 31279191 LABEL,WARNING FUSE REPLACE #347 1
17 11769118 CLAMP,FCM2-S6-14 1 S6 31409702 SADDLE SET,LOCKING WIRE LES-1010 20P 1
18 1000006174 FAN,9A0624H414 1 S7 31409801AS SADDLE,LOCKING WIRE LWS-0711Z 20P 6
19 1000004149 FILTER(E),FRC-40-12-1.7-013 1 S8 31019124 SCREW SET,BINDING M3*35 NI 50 PCS 2
20 12399353 FILTER(E) TFT-081813N F-540 1 S9 31369102 SPACER,PCB SUPPORT PCB-8S 2
5
15
2
8
76
1
2
3
4
9
10
11
12
13
14
16
15
18
19
20
21
22
23
24
25
26
27
28
17
S1
S1
S1
S2
S3
S3
S3
S3
S3
S3
S4
S5
S6
S7
S7
S8
S9
5
1-12

1-8 SCAN MOTOR
PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
1 6700469030 ASSY,PULLEY VP-540 1 S1 31329501AS CLAMP SET,PUSH MOUNT RT30SSF5 20P 1
2 6701979020 ASSY,SCAN MOTOR RE-640 1 S2 31289111AS CUPSCREW SET, M4*6 NI 100 PCS. 1
3 11869103 BALL,4MM 1 S3 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 2
4 1000010582 BASE,SCAN DRIVE VS-640I 1 S4 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. 5
5 22175815 BEARING F8-16ZZ 2 S5 31149704AS RING SET,E-RING ETW-6 SUS 100 PCS 1
6 1000010557 CABLE-ASSY,PRI-CAR ORG VS-640I 1 S6 31049171AS SCREW SET,CAP M3*12 NI 50 PCS. 4
7 1000010555 CABLE-ASSY,SCAN MOTOR VS-640I 1 S7 31049173AS SCREW SET,CAP M4*10 NI 50 PCS. 1
8 21365103 CASE,LOCK CJ-70 1 S8 31049137AS SCREW SET,CAP M4*25 3CBC 20 PCS 1
9 1000010585 FLANGE,MOTOR SCAN VS-640I 1 S9 31049169AS SCREW SET,CAP M4*8 3CBC+PW 20PCS 7
10 1000001905 GEAR,H187S20(B8) 1
11 1000009284 LOCK,STAY RE-640 1
12 1000001904 PULLEY,T55P2S16(B21C26) 1
13 1000006689 SENSOR-INTERRUPTER,EE-SX4009-P1 1
14 1000001480 SHAFT,DRIVE PULLEY XC-540 1
15 22295117 SHAFT,LOCK CJ-70 1
16 22185101 SLIDER,LOCK CJ-70 1
17 22175134 SPRING,A CJ-70 2
18 22175157 SPRING,C P-ROLLER CM-500 1
19 1000010583 STAY,OIL GUARD VS-640I 1
20 1000010584 STAY,SHAFT DRIVE PULLEY VS-640I 1
2
3
1
5
5
6
8
9
10
11
12
13
14
15
16
17
17
18
19
20
S1
4
S2
S3
S4
S4
S5
S6
S7
S8
S9
S9
S9
S9
S9
7
1-13

1-9 FEED MOTOR
PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts-
Parts No. Parts Name qt. Parts No. Parts Name qt.
1 6701409040 ASSY,FEED MOTOR VS-640 1 S1 31289111AS CUPSCREW SET, M4*6 NI 100 PCS. 2
W701407040 ASSY,GRIT ENCODER BOARD VS-640 1 S2 31289109AS CUPSCREW SET,M3*4 NI 100 PCS. 1
W702407040 ASSY,GRIT ENCODER VS-640I 1 S3 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. 5
3 1000010551 CABLE-ASSY,FEED MOTOR VS-640I 1 S4 31299102AS RIVET SET,NYLON P2655B 20 PCS. 3
4 1000010559 CABLE-ASSY,GRIT ENC VS-640I 1 S5 31049170AS SCREW SET,CAP M3*8 NI 50 PCS. 3
5 1000009413 COVER,FEED GEAR RE-640 1 S6 31049169AS SCREW SET,CAP M4*8 3CBC+PW 20PCS 3
6 1000006765 COVER,SCAN MOTOR VS-640 1 S7 31199701AS SCREW SET,SET WP M3*3 NI 20 PCS 4
7 1000002593 FLANGE,GRIT-ENCORDER VP-540 1 S8 31229103AS SCREW SET,TRUSS M2*6 NI 100 PCS 2
8 1000010626 FLANGE,MOTOR FEED VS-640I 1
9 1000008039 FRAME,SCAN MOTOR VS-640_01 1
10 21685128 GEAR H300 S10(B6C16POM) 1
11 1000006709 R-BEARING,6000ZZNR*NS7S 1
12 1000002162 SHEET,ROTARY DISK SLIT 360LPI 1
13 22175157 SPRING,C P-ROLLER CM-500 1
14 1000002596 STAY,G-ENCODER SENSOR VP-540 1
15 1000002594 STOPPER,GRIT-ENCORDER VP-540 1
2
1
2
3
4
5
8
6
9
10
11
12
15
14 13
7
S7
S7
S2
S5
S4
S4
S3
S3
S3
S6
S8 S1
1-14
