Roland PM-01 User manual

Thank you for purchasing the PERSONAL DRUM MONITOR PM-01.
The PM-01 is a slim and compact powered monitor that matches the
design of the Roland HD-1 V-Drums.
202
Copyright © 2007 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in
any form without the written permission of ROLAND CORPORATION.
201b
Before using this unit, carefully read the sections entitled:
“IMPORTANT SAFETY INSTRUCTIONS” (p. 2), “USING THE UNIT
SAFELY” (p. 3), and “IMPORTANT NOTES” (p. 5). These sections
provide important information concerning the proper operation of
the unit. Additionally, in order to feel assured that you have gained
a good grasp of every feature provided by your new unit, Owner’s
manual should be read in its entirety. The manual should be saved
and kept on hand as a convenient reference.
Owner’s Manual
04671623 1J
PM-01_e.fm 1 ページ ２００７年２月２０日 火曜日 午後１時３１分

2
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION: RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING - When using electric products, basic precautions should always be followed, including the following:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in
accordance with the manufacturers instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Unplug this apparatus during lightning storms or when
unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
IMPORTANT: THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE.
BLUE:
BROWN:
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.
Under no circumstances must either of the above wires be connected to the earth terminal of a three pin plug.
NEUTRAL
LIVE
For the U.K.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
PM-01_e.fm 2 ページ ２００７年２月２０日 火曜日 午後１時３１分

3
USING THE UNIT SAFELY
001
• Before using this unit, make sure to
read the instructions below, and the
Owner’s Manual.
..................................................................................................
002a
• Do not open or perform any internal
modifications on the unit.
..................................................................................................
003
• Do not attempt to repair the unit, or
replace parts within it (except when
this manual provides specific instruc-
tions directing you to do so). Refer all
servicing to your retailer, the nearest
Roland Service Center, or an autho-
rized Roland distributor, as listed on
the “Information” page.
..................................................................................................
004
• Never use or store the unit in places
that are:
• Subject to temperature extremes
(e.g., direct sunlight in an enclosed
vehicle, near a heating duct, on top
of heat-generating equipment); or
are
• Damp (e.g., baths, washrooms, on
wet floors); or are
• Humid; or are
• Exposed to rain; or are
• Dusty; or are
• Subject to high levels of vibration.
007
• Make sure you always have the unit
placed so it is level and sure to remain
stable. Never place it on stands that
could wobble, or on inclined surfaces.
..................................................................................................
008a
• The unit should be connected to a
power supply only of the type
described in the operating instructions,
or as marked on the rear side of unit.
..................................................................................................
008e
• Use only the attached power-supply
cord. Also, the supplied power cord
must not be used with any other
device.
..................................................................................................
009
• Do not excessively twist or bend the
power cord, nor place heavy objects on
it. Doing so can damage the cord,
producing severed elements and short
circuits. Damaged cords are fire and
shock hazards!
Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic
animals or pets.
Used for instructions intended to alert
the user to the risk of death or severe
injury should the unit be used
improperly.
The ●symbol alerts the user to things that must be
carried out. The specific thing that must be done is
indicated by the design contained within the circle. In
the case of the symbol at left, it means that the power-
cord plug must be unplugged from the outlet.
The symbol alerts the user to important instructions
or warnings.The specific meaning of the symbol is
determined by the design contained within the
triangle. In the case of the symbol at left, it is used for
general cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never
be carried out (are forbidden). The specific thing that
must not be done is indicated by the design contained
within the circle. In the case of the symbol at left, it
means that the unit must never be disassembled.
PM-01_e.fm 3 ページ ２００７年２月２０日 火曜日 午後１時３１分

4
010
• This unit, either alone or in combi-
nation with an amplifier and
headphones or speakers, may be
capable of producing sound levels that
could cause permanent hearing loss.
Do not operate for a long period of
time at a high volume level, or at a
level that is uncomfortable. If you
experience any hearing loss or ringing
in the ears, you should immediately
stop using the unit, and consult an
audiologist.
..................................................................................................
011
• Do not allow any objects (e.g.,
flammable material, coins, pins); or
liquids of any kind (water, soft drinks,
etc.) to penetrate the unit.
..................................................................................................
012a (modified)
• Immediately turn the STANDBY
switch off, remove the power cord
from the outlet, and request servicing
by your retailer, the nearest Roland
Service Center, or an authorized
Roland distributor, as listed on the
“Information” page when:
• The power-supply cord or the plug
has been damaged; or
• If smoke or unusual odor occurs
• Objects have fallen into, or liquid
has been spilled onto the unit; or
• The unit has been exposed to rain
(or otherwise has become wet); or
• The unit does not appear to operate
normally or exhibits a marked
change in performance.
..................................................................................................
015
• Do not force the unit’s power-supply
cord to share an outlet with an unrea-
sonable number of other devices. Be
especially careful when using
extension cords—the total power used
by all devices you have connected to
the extension cord’s outlet must never
exceed the power rating (watts/
amperes) for the extension cord.
Excessive loads can cause the
insulation on the cord to heat up and
eventually melt through.
013
• In households with small children, an
adult should provide supervision until
the child is capable of following all the
rules essential for the safe operation of
the unit.
..................................................................................................
014
• Protect the unit from strong impact.
(Do not drop it!)
..................................................................................................
016
• Before using the unit in a foreign
country, consult with your retailer, the
nearest Roland Service Center, or an
authorized Roland distributor, as
listed on the “Information” page.
..................................................................................................
026
• Do not put anything that contains
water (e.g., flower vases) on this unit.
Also, avoid the use of insecticides,
perfumes, alcohol, nail polish, spray
cans, etc., near the unit. Swiftly wipe
away any liquid that spills on the unit
using a dry, soft cloth.
101a
• The unit should be located so that its
location or position does not interfere
with its proper ventilation.
..................................................................................................
102b
• Always grasp only the plug on the
power-supply cord when plugging
into, or unplugging from, an outlet or
this unit.
..................................................................................................
103a
• At regular intervals, you should
unplug the power plug and clean it by
using a dry cloth to wipe all dust and
other accumulations away from its
prongs. Also, disconnect the power
plug from the power outlet whenever
the unit is to remain unused for an
extended period of time. Any accumu-
lation of dust between the power plug
and the power outlet can result in poor
insulation and lead to fire.
PM-01_e.fm 4 ページ ２００７年２月２０日 火曜日 午後１時３１分

5
104
• Try to prevent cords and cables from
becoming entangled. Also, all cords
and cables should be placed so they
are out of the reach of children.
..................................................................................................
106
• Never climb on top of, nor place heavy
objects on the unit.
..................................................................................................
107b
• Never handle the power cord or its
plugs with wet hands when plugging
into, or unplugging from, an outlet or
this unit.
..................................................................................................
108a
• Before moving the unit, disconnect the
power plug from the outlet, and pull
out all cords from external devices.
..................................................................................................
109a (modified)
• Before cleaning the unit, unplug the
power cord from the outlet.
110a
• Whenever you suspect the possibility
of lightning in your area, pull the plug
on the power cord out of the outlet.
..................................................................................................
bass
• Be sure to avoid
inserting your
fingers in the bass
reflex ports when
transporting or
moving the
speakers, as your
fingers may
become wedged
and stuck in the
ports.
IMPORTANT NOTES
291b
In addition to the items listed under “IMPORTANT SAFETY INSTRUCTIONS” and “USING
THE UNIT SAFELY” on pages 2–5, please read and observe the following:
Power Supply
301
• Do not connect this unit to same electrical
outlet that is being used by an electrical
appliance that is controlled by an inverter
(such as a refrigerator, washing machine,
microwave oven, or air conditioner), or that
contains a motor. Depending on the way in
which the electrical appliance is used, power
supply noise may cause this unit to
malfunction or may produce audible noise. If
it is not practical to use a separate electrical
outlet, connect a power supply noise filter
between this unit and the electrical outlet.
307
• Before connecting this unit to other devices,
turn off the power to all units. This will help
prevent malfunctions and/or damage to
speakers or other devices.
308 (modified)
• Although the LED is switched off when the
STANDBY switch is switched off, this does
not mean that the unit has been completely
disconnected from the source of power. If you
need to turn off the power completely, first
turn off the STANDBY switch, then unplug
the power cord from the power outlet. For this
reason, the outlet into which you choose to
connect the power cord’s plug should be one
that is within easy reach and readily acces-
sible.
PM-01_e.fm 5 ページ ２００７年２月２０日 火曜日 午後１時３１分

6
Placement
351
• Using the unit near power amplifiers (or other
equipment containing large power trans-
formers) may induce hum. To alleviate the
problem, change the orientation of this unit;
or move it farther away from the source of
interference.
352a
• This device may interfere with radio and
television reception. Do not use this device in
the vicinity of such receivers.
352b
• Noise may be produced if wireless communi-
cations devices, such as cell phones, are
operated in the vicinity of this unit. Such noise
could occur when receiving or initiating a call,
or while conversing. Should you experience
such problems, you should relocate such
wireless devices so they are at a greater
distance from this unit, or switch them off.
354a
• Do not expose the unit to direct sunlight,
place it near devices that radiate heat, leave it
inside an enclosed vehicle, or otherwise
subject it to temperature extremes. Excessive
heat can deform or discolor the unit.
355b
• When moved from one location to another
where the temperature and/or humidity is
very different, water droplets (condensation)
may form inside the unit. Damage or
malfunction may result if you attempt to use
the unit in this condition. Therefore, before
using the unit, you must allow it to stand for
several hours, until the condensation has
completely evaporated.
360
• Depending on the material and temperature
of the surface on which you place the unit, its
rubber feet may discolor or mar the surface.
You can place a piece of felt or cloth under the
rubber feet to prevent this from happening. If
you do so, please make sure that the unit will
not slip or move accidentally.
Maintenance
401a
• For everyday cleaning wipe the unit with a
soft, dry cloth or one that has been slightly
dampened with water. To remove stubborn
dirt, use a cloth impregnated with a mild,
non-abrasive detergent. Afterwards, be sure
to wipe the unit thoroughly with a soft, dry
cloth.
402
• Never use benzine, thinners, alcohol or
solvents of any kind, to avoid the possibility
of discoloration and/or deformation.
Additional Precautions
553
• Use a reasonable amount of care when using
the unit’s buttons, sliders, or other controls;
and when using its jacks and connectors.
Rough handling can lead to malfunctions.
556
• When connecting / disconnecting all cables,
grasp the connector itself—never pull on the
cable. This way you will avoid causing shorts,
or damage to the cable’s internal elements.
557
• A small amount of heat will radiate from the
unit during normal operation.
558b
• To avoid disturbing your neighbors, try to
keep the unit’s volume at reasonable levels
(especially when it is late at night).
559a
• When you need to transport the unit, package
it in the box (including padding) that it came
in, if possible. Otherwise, you will need to use
equivalent packaging materials.
562
• Some connection cables contain resistors. Do
not use cables that incorporate resistors for
connecting to this unit. The use of such cables
can cause the sound level to be extremely low,
or impossible to hear. For information on
cable specifications, contact the manufacturer
of the cable.
PM-01_e.fm 6 ページ ２００７年２月２０日 火曜日 午後１時３１分

7
Panel Descriptions
fig.Panel.eps
STANDBY Switch
Turn this toward the right to turn on.
When this is on, an amber indicator will light.
945 (modified)
* If you need to turn off the power completely, first turn off the STANDBY switch, then unplug the
power cord from the power outlet. Refer to Power Supply (p. 5).
LINE VOLUME Knob
This adjusts the volume of the device connected to the LINE IN jack.
LINE IN Jack
Connect the percussion sound module to this jack.
* Use the cable included with the PM-01 to connect it to the Roland HD-1 V-Drums.
* If you connect a sound module with a high output level (such as the TD series), distortion may occur
if you turn the volume level up too much. If this occurs, lower the volume of the drum sound module.
AC INLET
Connect the included Power cord here. Plug it firmly in, so that the cable does not
accidentally become disconnected.
Front
Rear
Front Rear
1
23
4
1
2
3
This instrument is equipped with stereo miniature phone type jacks, and accepts both mono and stereo.
Make connections after first checking the wiring diagrams of other equipment you intend to connect.
This accepts stereo miniature phone plug. However, the speaker is mono.
4
PM-01_e.fm 7 ページ ２００７年２月２０日 火曜日 午後１時３１分

8
Connections/Turning On the Power
fig.Panel2.eps
941 (modified)
Once the connections have been properly completed, be sure to
use the steps described below to turn on the STANDBY switch.
Turning on STANDBY in the wrong order risks malfunction
and/or damage to speakers and other devices (reverse the
procedure when turning off the STANDBY switch).
< Connected device → PM-01>
943 (modified)
* Always make sure to have the volume level turned down before turning
on the STANDBY switch. Even with the volume all the way down, you
may still hear some sound when the STANDBY switch is turned on,
but this is normal, and does not indicate a malfunction.
945 (modified)
* If you need to turn off the power completely, first turn off the
STANDBY switch, then unplug the power cord from the power outlet.
Refer to Power Supply (p. 5).
Connections
Precautions Concerning Initial Use
921
To prevent malfunction
and/or damage to
speakers or other
devices, always turn
down the volume, and
turn off the power on all
devices before making
any connections.
926a
When connection cables
with resistors are used,
the volume level of
equipment connected to
the input (LINE IN) may
be low. If this happens,
use connection cables
that do not contain
resistors.
Percussion Sound Module
Rear
942 (modified)
This unit is equipped
with a circuitry
protection feature. A few
moments are required
after the STANDBY
switch is turned on
before the unit is ready
for normal operation.
PM-01_e.fm 8 ページ ２００７年２月２０日 火曜日 午後１時３１分

9
Appendix
Do not place the monitor on its side or upside down.
* Please also refer to Placement (p. 6) in IMPORTANT NOTES .
If you’re connecting the PM-01 to the Roland HD-1
V-Drums, set up your equipment as shown at right.
Rated Power Output
15 W
Nominal Input Level / Input Impedance
LINE IN: -6 dBu/20 k ohms or greater
Speaker
4" (10 cm) Full Range
Enclosure
Bass-reflex type
Controls
LINE VOLUME knob
STANDBY switch
Indicator
STANDBY
Connector
LINE IN jack
(Stereo miniature phone type)
Power Supply
AC 117 V, AC 220 V, AC 230 V, AC 240 V
(50/60 Hz)
Power Consumption
14 W
Dimensions
202 (W) x 186 (D) x 450 (H) mm
8 (W) x 7-3/8 (D) x 17-3/4 (H) inches
Weight
3.4 kg / 7 lbs 8 oz
Accessories
Owner’s Manual
Power Cord
Audio Cable
* 0 dBu = 0.775 Vrms
962a
* In the interest of product improvement, the
specifications and/or appearance of this unit are
subject to change without prior notice.
Important Notes on Placement
Example Setup
Specifications
PM-01_e.fm 9 ページ ２００７年２月２０日 火曜日 午後１時３１分

For EU Countries
GR
SK
CZ
SI
LV
LT
EE
PL
HU
FI
SE
NO
DK
NL
PT
ES
IT
DE
FR
UK
This product complies with the requirements of European Directives EMC 89/336/EEC and LVD 73/23/EEC.
For EU Countries
PM-01_e.fm 10 ページ ２００７年２月２０日 火曜日 午後１時３１分
