Roland JUNO-D User manual

1
MIDI Implementation
1. Receive data
■ Channel Voice Messages
* Not received in Performance mode when the Receive Switch parameter (PERFORM
PART) is OFF.
● Note off
Status 2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note off velocity: 00H - 7FH (0 - 127)
● Note on
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note on velocity: 01H - 7FH (1 - 127)
● Control Change
❍ Bank Select (Controller number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* Not received in Performance mode when the Receive Bank Select (PERFORM PART) is
OFF.
* The Performances, Patches, and Rhythms corresponding to each Bank Select are as
follows.
+—————+———————————+———————————+——————————————————————+———————————+
| BANK SELECT | PROGRAM | GROUP | NUMBER |
| MSB | LSB | NUMBER | | |
+—————+———————————+———————————+——————————————————————+———————————+
| 085 | 000 | 001 — 008 | User Performance | 001 — 008 |
| | 064 | 001 — 032 | Preset Performance | 001 — 032 |
| 086 | 000 | 001 — 002 | User Rhythm | 001 — 002 |
| | 064 | 001 — 020 | Preset Rhythm | 001 — 020 |
| 087 | 000 | 001 — 128 | User Patch | 001 — 128 |
| | 064 | 001 — 128 | Preset Patch | 001 — 128 |
| | : | | : | |
| | 068 | 001 — 128 | Preset Patch | 001 — 128 |
| 120 | 000 | 001 — 057 | GM Rhythm | 001 — 009 |
| 121 | 000 — | 001 — 128 | GM Patch | 001 — 256 |
+—————+———————————+———————————+——————————————————————+———————————+
❍ Modulation (Controller number 1)
Status 2nd byte 3rd byte
BnH 01H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Modulation depth: 00H - 7FH (0 - 127)
❍ Portamento Time (Controller number 5)
Status 2nd byte 3rd byte
BnH 05H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Portamento Time: 00H - 7FH (0 - 127)
* The Portamento Time parameter (PATCH TONE) will change.
❍ Data Entry (Controller number 6, 38)
Status 2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = the value of the parameter specified by RPN/NRPN
mm = MSB, ll = LSB
❍ Volume (Controller number 7)
Status 2nd byte 3rd byte
BnH 07H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Volume: 00H - 7FH (0 - 127)
* In Performance mode, the Part Level parameter (PERFORM PART) will change.
❍ Balance (Controller number 8)
Status 2nd byte 3rd byte
BnH 08H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Balance: 00H - 7FH (0 - 127)
* The Tone Balance parameter (PATCH COMMON) will change.
❍ Panpot (Controller number 10)
Status 2nd byte 3rd byte
BnH 0AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Panpot: 00H - 40H - 7FH (Left - Center - Right),
* In Performance mode, the Part Pan parameter (PERFORM PART) will change.
❍ Expression (Controller number 11)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Expression: 00H - 7FH (0 - 127)
❍ Effect Control 1 (Controller number 12)
Status 2nd byte 3rd byte
BnH 0CH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
❍ Effect Control 2 (Controller number 13)
Status 2nd byte 3rd byte
BnH 0DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
❍ Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON
❍ Portamento (Controller number 65)
Status 2nd byte 3rd byte
BnH 41H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* The Portamento Switch parameter (PATCH TONE) will change.
❍ Sostenuto (Controller number 66)
Status 2nd byte 3rd byte
BnH 42H vvH
n = MIDI channel number:0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍ Soft (Controller number 67)
Status 2nd byte 3rd byte
BnH 43H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍ Resonance (Controller number 71)
Status 2nd byte 3rd byte
BnH 47H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv= Resonance value (relative change): 00H - 40H - 7FH (-64 - 0 - +63),
* The Resonance parameter (PATCH TONE) will change.
❍ Release Time (Controller number 72)
Status 2nd byte 3rd byte
BnH 48H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Release Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63),
* The Release Time parameter (PATCH TONE) will change.
❍ Attack time (Controller number 73)
Status 2nd byte 3rd byte
BnH 49H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Attack time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63),
* The Attack Time parameter (PATCH TONE) will change.
Model: JUNO-D
Date: 2004.4.1
Version: 1.00
Copyright © 2004 ROLAND CORPORATION
No part of this publication may be reproduced in any form without the written permission of ROLAND CORPORATION.
1PS

2
❍ Cutoff (Controller number 74)
Status 2nd byte 3rd byte
BnH 4AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Cutoff value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* The Cutoff Frequency parameter (PATCH TONE) will change.
❍ Decay Time (Controller number 75)
Status 2nd byte 3rd byte
BnH 4BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Decay Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* The Decay Time parameter (PATCH TONE) will change.
❍ Vibrato Rate (Controller number 76)
Status 2nd byte 3rd byte
BnH 4CH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Rate value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* The LFO Rate parameter (PATCH TONE) will change.
❍ Vibrato Depth (Controller number 77)
Status 2nd byte 3rd byte
BnH 4DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Depth Value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* The LFO Depth parameter (PATCH TONE) will change.
❍ Vibrato Delay (Controller number 78)
Status 2nd byte 3rd byte
BnH 4EH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Delay value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* The LFO Delay parameter (PATCH TONE) will change.
❍ Portamento control (Controller number 84)
Status 2nd byte 3rd byte
BnH 54H kkH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = source note number: 00H - 7FH (0 - 127)
* A Note-on received immediately after a Portamento Control message will change
continuously in pitch, starting from the pitch of the Source Note Number.
* If a voice is already sounding for a note number identical to the Source Note Number,
this voice will continue sounding (i.e., legato) and will, when the next Note-on is
received, smoothly change to the pitch of that Note-on.
* The rate of the pitch change caused by Portamento Control is determined by the
Portamento Time value.
❍ Effect 1 (Reverb Send Level) (Controller number 91)
Status 2nd byte 3rd byte
BnH 5BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Reverb Send Level: 00H - 7FH (0 - 127)
* In Performance mode, the Part Reverb Send Level parameter (PERFORM PART) will
change.
❍ Effect 3 (Chorus Send Level) (Controller number 93)
Status 2nd byte 3rd byte
BnH 5DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Chorus Send Level: 00H - 7FH (0 - 127)
* In Performance mode, the Part Chorus Send Level parameter (PERFORM PART) will
change.
❍ RPN MSB/LSB (Controller number 100, 101)
Status 2nd byte 3rd byte
BnH 65H mmH
BnH 64H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = upper byte (MSB) of parameter number specified by RPN
ll = lower byte (LSB) of parameter number specified by RPN
<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers), which are extended.
When using RPNs, first RPN (Controller numbers 100 and 101; they can be sent in any
order) should be sent in order to select the parameter, then Data Entry (Controller numbers
6 and 38) should be sent to set the value. Once RPN messages are received, Data Entry
messages that is received at the same MIDI channel after that are recognized as changing
toward the value of the RPN messages. In order not to make any mistakes, transmitting
RPN Null is recommended after setting parameters you need.
This device receives the following RPNs.
RPN Data entry
MSB, LSB MSB, LSB Notes
00H, 00H mmH, llH Pitch Bend Sensitivity
mm: 00H - 18H (0 - 24 semitones)
ll: ignored (processed as 00H)
Up to 2 octave can be specified in semitone steps.
* The Pitch Bend Range parameter (PATCH TONE) will change.
00H, 01H mmH, llH Channel Fine Tuning
mm, ll: 20 00H - 40 00H - 60 00H
(-4096 x 100 / 8192 - 0 - +4096 x 100 / 8192 cent)
* The Fine Tune parameter (PATCH TONE) will change.
00H, 02H mmH, llH Channel Coarse Tuning
mm: 10H - 40H - 70H (-48 - 0 - +48 semitones)
ll: ignored (processed as 00H)
* The Coarse Tune parameter (PATCH TONE) will change.
00H, 05H mmH, llH Modularion Depth Range
mm: 00 00H - 06 00H
(0 - 16384 x 600 / 16384 cent)
* Not received in Patch mode.
7FH, 7FH ---, --- RPN null
RPN and NRPN will be set as “unspecified.”
Once this setting has been made, subsequent
Parameter values that were previously set will
not change.
mm, ll: ignored
● Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H - FH (ch.1 - 16)
pp = Program number: 00H - 7FH (prog.1 - prog.128)
* Not received in Performance mode when the Receive Program Change parameter
(PERFORM PART) is OFF.
● Channel Pressure
Status 2nd byte
DnH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Channel Pressure: 00H - 7FH (0 - 127)
● Pitch Bend Change
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)

3
■ Channel Mode Messages
* Not received in Performance mode when the Receive Switch parameter (PERFORM
PART) is OFF.
● All Sounds Off (Controller number 120)
Status 2nd byte 3rd byte
BnH 78H 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When this message is received, all notes currently sounding on the corresponding
channel will be turned off.
● Reset All Controllers (Controller number 121)
Status 2nd byte 3rd byte
BnH 79H 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When this message is received, the following controllers will be set to their reset values.
Controller Reset value
Pitch Bend Change +/-0 (center)
Polyphonic Key Pressure 0 (off)
Channel Pressure 0 (off)
Modulation 0 (off)
Expression 127 (max)
Hold 1 0 (off)
Sostenuto 0 (off)
Soft 0 (off)
RPN unset; previously set data will not change
NRPN unset; previously set data will not change
● All Notes Off (Controller number 123)
Status 2nd byte 3rd byte
BnH 7BH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When All Notes Off is received, all notes on the corresponding channel will be turned
off. However, if Hold 1 or Sostenuto is ON, the sound will be continued until these are
turned off.
● OMNI OFF (Controller number 124)
Status 2nd byte 3rd byte
BnH 7CH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes Off is received.
● OMNI ON (Controller number 125)
Status 2nd byte 3rd byte
BnH 7DH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes Off is received. OMNI ON
will not be turned on.
● MONO (Controller number 126)
Status 2nd byte 3rd byte
BnH 7EH mmH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = mono number: 00H - 10H (0 - 16)
* The same processing will be carried out as when All Notes Off is received.
* The Solo Switch parameter (PATCH COMMON) will change.
● POLY (Controller number 127)
Status 2nd byte 3rd byte
BnH 7FH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes Off is received.
* The Solo Switch parameter (PATCH COMMON) will change.
■ System Realtime Message
● Active Sensing
Status
FEH
* When Active Sensing is received, the unit will begin monitoring the intervals of all
further messages. While monitoring, if the interval between messages exceeds 420 ms,
the same processing will be carried out as when All Sounds Off, All Notes Off and Reset
All Controllers are received, and message interval monitoring will be halted.
■ System Exclusive Message
Status Data byte Status
F0H iiH, ddH, ......,eeH F7H
F0H: System Exclusive Message status
ii = ID number: an ID number (manufacturer ID) to indicate the manufacturer whose
Exclusive message this is. Roland’s manufacturer ID is 41H.
ID numbers 7EH and 7FH are extensions of the MIDI standard;
Universal Non-realtime Messages (7EH) and Universal Realtime
Messages (7FH).
dd,...,ee = data: 00H - 7FH (0 - 127)
F7H: EOX (End Of Exclusive)
Of the System Exclusive messages received by this device, the Universal Non-realtime
messages and the Universal Realtime messages and the Global Parameter Control and the
Data Request (RQ1) messages and the Data Set (DT1) messages will be set automatically.
● Universal Non-realtime System Exclusive Messages
❍ Identity Request Message
Status Data byte Status
F0H 7EH, dev, 06H, 01H F7H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
dev Device ID (dev: 10H - 1FH, 7FH)
06H Sub ID#1 (General Information)
01H Sub ID#2 (Identity Request)
F7H EOX (End Of Exclusive)
* When this message is received, Identity Reply message (p. 8) will be transmitted.
❍ GM1 System On
Status Data byte Status
F0H 7EH, 7FH, 09H, 01H F7H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
09H Sub ID#1 (General MIDI Message)
01H Sub ID#2 (General MIDI 1 On)
F7H EOX (End Of Exclusive)
* When this messages is received, this instrument will turn to the Performance mode.
❍ GM2 System On
Status Data byte Status
F0H 7EH 7FH 09H 03H F7H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
09H Sub ID#1 (General MIDI Message)
03H Sub ID#2 (General MIDI 2 On)
F7H EOX (End Of Exclusive)
* When this messages is received, this instrument will turn to the Performance mode.

4
❍ GM System Off
Status Data byte Status
F0H 7EH, 7F, 09H, 02H F7H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
09H Sub ID#1 (General MIDI Message)
02H Sub ID#2 (General MIDI Off)
F7H EOX (End Of Exclusive)
* When this messages is received, this instrument will return to the Performance mode.
● Universal Realtime System Exclusive Messages
❍ Master Volume
Status Data byte Status
F0H 7FH, 7FH, 04H, 01H, llH, mmH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
01H Sub ID#2 (Master Volume)
llH Master Volume lower byte
mmH Master Volume upper byte
F7H EOX (End Of Exclusive)
* The lower byte (llH) of Master Volume will be handled as 00H.
* The Master Level parameter (SYSTEM GENERAL) will change.
❍ Master Fine Tuning
Status Data byte Status
F0H 7FH, 7FH, 04H, 03H, llH, mmH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
03H Sub ID#2 (Master Fine Tuning)
llH Master Fine Tuning LSB
mmH Master Fine Tuning MSB
F7H EOX (End Of Exclusive)
mm, ll: 00 00H - 40 00H - 7F 7FH (-100 - 0 - +99.9 [cents])
* The Master Tune parameter (SYSTEM GENERAL) will change.
❍ Master Coarse Tuning
Status Data byte Status
F0H 7FH, 7FH, 04H, 04H, llH, mmH F7
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
04H Sub ID#2 (Master Coarse Tuning)
llH Master Coarse Tuning LSB
mmH Master Coarse Tuning MSB
F7H EOX (End Of Exclusive)
llH: ignored (processed as 00H)
mmH: 28H - 40H - 58H (-24 - 0 - +24 [semitones])
* The Master Key Shift parameter (SYSTEM GENERAL) will change.
● Global Parameter Control
* Not received in Patch mode.
❍ Reverb Parameters
Status Data byte Status
F0H 7FH, 7FH, 04H, 05H, 01H, 01H, F7H
01H, 01H, 01H, ppH, vvH
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
05H Sub ID#2 (Global Parameter Control)
01H Slot path length
01H Parameter ID width
01H Value width
01H Slot path MSB
01H Slot path LSB (Effect 0101: Reverb)
ppH Parameter to be controlled.
vvH Value for the parameter.
pp=0 Reverb Type
vv = 00H Small Room
vv = 01H Medium Room
vv = 02H Large Room
vv = 03H Medium Hall
vv = 04H Large Hall
vv = 08H Plate
pp=1 Reverb Time
vv = 00H - 7FH 0 - 127
F7H EOX (End Of Exclusive)
❍ Chorus Parameters
Status Data byte Status
F0H 7FH, 7FH, 04H, 05H, 01H, 01H, F7H
01H, 01H, 02H, ppH, vvH
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
05H Sub ID#2 (Global Parameter Control)
01H Slot path length
01H Parameter ID width
01H Value width
01H Slot path MSB
02H Slot path LSB (Effect 0102: Chorus)
ppH Parameter to be controlled.
vvH Value for the parameter.
pp=0 Chorus Type
vv=0 Chorus1
vv=1 Chorus2
vv=2 Chorus3
vv=3 Chorus4
vv=4 FB Chorus
vv=5 Flanger
pp=1 Mod Rate
vv= 00H - 7FH 0 - 127
pp=2 Mod Depth
vv = 00H - 7FH 0 - 127
pp=3 Feedback
vv = 00H - 7FH 0 - 127
pp=4 Send To Reverb
vv = 00H - 7FH 0 - 127
F7H EOX (End Of Exclusive)

5
❍ Channel Pressure
Status Data byte Status
F0H 7FH, 7FH, 09H, 01H, 0nH, ppH, rrH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
09H Sub ID#1 (Controller Destination Setting)
01H Sub ID#2 (Channel Pressure)
0nH MIDI Channel (00 - 0F)
ppH Controlled parameter
rrH Controlled range
pp=0 Pitch Control
rr = 28H - 58H -24 - +24 [semitones]
pp=1 Filter Cutoff Control
rr = 00H - 7FH -9600 - +9450 [cents]
pp=2 Amplitude Control
rr = 00H - 7FH 0 - 200%
pp=3 LFO Pitch Depth
rr = 00H - 7FH 0 - 600 [cents]
pp=4 LFO Filter Depth
rr = 00H - 7FH 0 - 2400 [cents]
pp=5 LFO Amplitude Depth
rr = 00H - 7FH 0 - 100%
F7H EOX (End Of Exclusive)
❍ Controller
Status Data byte Status
F0H 7FH, 7FH, 09H, 03H, 0nH, ccH, ppH, rrH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
09H Sub ID#1 (Controller Destination Setting)
03H Sub ID#2 (Control Change)
0nH MIDI Channel (00 - 0F)
ccH Controller number (01 - 1F, 40 - 5F)
ppH Controlled parameter
rrH Controlled range
pp=0 Pitch Control
rr = 28H - 58H -24 - +24 [semitones]
pp=1 Filter Cutoff Control
rr = 00H - 7FH -9600 - +9450 [cents]
pp=2 Amplitude Control
rr = 00H - 7FH 0 - 200%
pp=3 LFO Pitch Depth
rr = 00H - 7FH 0 - 600 [cents]
pp=4 LFO Filter Depth
rr = 00H - 7FH 0 - 2400 [cents]
pp=5 LFO Amplitude Depth
rr = 00H - 7FH 0 - 100%
F7H EOX (End Of Exclusive)
❍ Scale/Octave Tuning Adjust
Status Data byte Status
F0H 7EH, 7FH, 08H, 08H, ffH, ggH, hhH, ssH... F7
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
08H Sub ID#1 (MIDI Tuning Standard)
08H Sub ID#2 (scale/octave tuning 1-byte form)
ffH Channel/Option byte 1
bits 0 to 1 = channel 15 to 16
bit 2 to 6 = Undefined
ggH Channel byte 2
bits 0 to 6 = channel 8 to 14
hhH Channel byte 3
bits 0 to 6 = channel 1 to 7
ssH 12 byte tuning offset of 12 semitones from C to B
00H = -64 [cents]
40H = 0 [cents] (equal temperament)
7FH = +63 [cents]
F7H EOX (End Of Exclusive)
❍ Key-based Instrument Controllers
Status Data byte Status
F0H 7FH, 7FH, 0AH, 01H, 0nH, kkH, nnH, vvH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
0AH Sub ID#1 (Key-Based Instrument Control)
01H Sub ID#2 (Controller)
0nH MIDI Channel (00 - 0FH)
kkH Key Number
nnH Control Number
vvH Value
nn=07H Level
vv = 00H - 7FH 0 - 200% (Relative)
nn=0AH Pan
vv = 00H - 7FH Left - Right (Absolute)
nn=5BH Reverb Send
vv = 00H - 7FH 0 - 127 (Absolute)
nn=5D Chorus Send
vv = 00H - 7FH 0 - 127 (Absolute)
: :
F7 EOX (End Of Exclusive)
* This parameter affects drum instruments only.
● Data Transmission
This instrument can use exclusive messages to exchange many varieties of internal settings
with other devices.
The model ID of the exclusive messages used by this instrument is 00H 64H.
❍ Data Request 1 RQ1 (11H)
This message requests the other device to transmit data. The address and size indicate the
type and amount of data that is requested.
When a Data Request message is received, if the device is in a state in which it is able to
transmit data, and if the address and size are appropriate, the requested data is transmitted
as a Data Set 1 (DT1) message. If the conditions are not met, nothing is transmitted.
Status data byte status
F0H 41H, dev, 00H, 64H, 11H, aaH, bbH, ccH, F7H
ddH, ssH, ttH, uuH, vvH, sum
Byte Remarks
F0H Exclusive status
41H ID number (Roland)
dev device ID (dev: 10H - 1FH, 7FH)
00H model ID #1 (JUNO-D)
64H model ID #2 (JUNO-D)
11H command ID (RQ1)
aaH address MSB
bbH address
ccH address
ddH address LSB
ssH size MSB
ttH size
uuH size
vvH size LSB
sum checksum
F7H EOX (End Of Exclusive)
* The size of data that can be transmitted at one time is fixed for each type of data. And
data requests must be made with a fixed starting address and size. Refer to the address
and size given in “Parameter Address Map” (p. 9).
* For the checksum, refer to p. 24.
* Not received when the Receive Exclusive parameter (SYSTEM MIDI) is OFF.

6
❍ Data set 1 DT1 (12H)
Status Data byte Status
F0H 41H, dev, 00H, 64H, 12H, aaH, bbH, F7H
ccH, ddH, eeH, ... ffH, sum
Byte Explanation
F0H Exclusive status
41H ID number (Roland)
dev Device ID (dev: 00H - 1FH, 7FH)
00H Model ID #1 (JUNO-D)
64H Model ID #2 (JUNO-D)
12H Command ID (DT1)
aaH Address MSB: upper byte of the starting address of the data to be sent
bbH Address: upper middle byte of the starting address of the data to be sent
ccH Address: lower middle byte of the starting address of the data to be sent
ddH Address LSB: lower byte of the starting address of the data to be sent.
eeH Data: the actual data to be sent. Multiple bytes of data are transmitted in order
starting from the address.
: :
ffH Data
sum Checksum
F7H EOX (End Of Exclusive)
* The amount of data that can be transmitted at one time depends on the type of data, and
data will be transmitted from the specified starting address and size. Refer to the address
and size given in “Parameter Address Map” (p. 9).
* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and each
packet will be sent at an interval of about 20 ms.
* Regarding the checksum, please refer to p. 24.
* Not received when the Receive Exclusive parameter (SYSTEM MIDI) is OFF.
Status Data byte Status
F0H 41H, dev, 42H, 12H, aaH, bbH, ccH, F7H
ddH, ... eeH, sum
Byte Explanation
F0H Exclusive status
41H ID number (Roland)
dev Device ID (dev: 10H - 1FH, 7FH)
42H Model ID (GS)
12H Command ID (DT1)
aaH Address MSB: upper byte of the starting address of the transmitted data
bbH Address: middle byte of the starting address of the transmitted data
ccH Address LSB: lower byte of the starting address of the transmitted data
ddH Data: the actual data to be transmitted. Multiple bytes of data are transmitted
starting from the address.
: :
eeH Data
sum Checksum
F7H EOX (End Of Exclusive)
* The amount of data that can be transmitted at one time depends on the type of data, and
data will be transmitted from the specified starting address and size. Refer to the address
and size given in “Parameter Address Map” (p. 9).
* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and each
packet will be sent at an interval of about 20 ms.
* Regarding the checksum, please refer to p. 24.
* Not received when the Receive Exclusive parameter (SYSTEM MIDI) is OFF.
2. Data Transmission
■ Channel Voice Messages
● Note off
Status 2nd byte 3rd byte
8nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note off velocity: 00H - 7FH (0 - 127)
● Note on
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note on velocity: 01H - 7FH (1 - 127)
● Control Change
❍ Bank Select (Controller number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* These messages are transmitted when Patch, Rhythm Set or Performance is selected. But
not transmitted when Transmit Program Change or Transmit Bank Select parameter
(SYSTEM MIDI) is OFF.
❍ Modulation (Controller number 1)
Status 2nd byte 3rd byte
BnH 01H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Modulation depth: 00H - 7FH (0 - 127)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to MODULATION.
❍ Portamento Time (Controller number 5)
Status 2nd byte 3rd byte
BnH 05H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Portamento Time: 00H - 7FH (0 - 127)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to PORTA TIME.
❍ Volume (Controller number 7)
Status 2nd byte 3rd byte
BnH 07H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Volume: 00H - 7FH (0 - 127)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to VOLUME.
❍ Balance (Controller number 8)
Status 2nd byte 3rd byte
BnH 08H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Balance: 00H - 7FH (0 - 127)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to BALANCE.
❍ Panpot (Controller number 10)
Status 2nd byte 3rd byte
BnH 0AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Panpot: 00H - 40H - 7FH (Left - Center - Right),
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to PAN.

7
❍ Expression (Controller number 11)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Expression: 00H - 7FH (0 - 127)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to EXPRESSION.
❍ Effect Control 1 (Controller number 12)
Status 2nd byte 3rd byte
BnH 0CH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value (relative change): 0H - 40H - 7FH (-64 - 0 - +63)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to MFX PARAMETER1.
❍ Effect Control 2 (Controller number 13)
Status 2nd byte 3rd byte
BnH 0DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to MFX PARAMETER2.
❍ Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON
❍ Portamento (Controller number 65)
Status 2nd byte 3rd byte
BnH 41H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to PORTAMENTO.
❍ Sostenuto (Controller number 66)
Status 2nd byte 3rd byte
BnH 42H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to SOSTENUTO.
❍ Soft (Controller number 67)
Status 2nd byte 3rd byte
BnH 43H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to SOFT.
❍ Resonance (Controller number 71)
Status 2nd byte 3rd byte
BnH 47H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv= Resonance value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to RESONANCE.
❍ Release Time (Controller number 72)
Status 2nd byte 3rd byte
BnH 48H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Release Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to RELEASE TIME.
❍ Attack time (Controller number 73)
Status 2nd byte 3rd byte
BnH 49H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Attack time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to ATTACK TIME.
❍ Cutoff (Controller number 74)
Status 2nd byte 3rd byte
BnH 4AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Cutoff value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to CUTOFF.
❍ Decay Time (Controller number 75)
Status 2nd byte 3rd byte
BnH 4BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Decay Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to DECAY TIME.
❍ Vibrato Rate (Controller number 76)
Status 2nd byte 3rd byte
BnH 4CH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Rate value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to LFO RATE.
❍ Vibrato Depth (Controller number 77)
Status 2nd byte 3rd byte
BnH 4DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Depth Value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to LFO DEPTH.
❍ Vibrato Delay (Controller number 78)
Status 2nd byte 3rd byte
BnH 4EH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Delay value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to LFO DELAY.
❍ Effect 1 (Reverb Send Level) (Controller number 91)
Status 2nd byte 3rd byte
BnH 5BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Reverb Send Level: 00H - 7FH (0 - 127)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to REV SEND LEVEL.
❍ Effect 3 (Chorus Send Level) (Controller number 93)
Status 2nd byte 3rd byte
BnH 5DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Chorus Send Level: 00H - 7FH (0 - 127)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to CHO SEND LEVEL.

8
● Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H - FH (ch.1 - 16)
pp = Program number: 00H - 7FH (prog.1 - prog.128)
* These messages are transmitted when Patch, Rhythm Set or Performance is selected. But
not transmitted when Transmit Program Change parameter (SYSTEM MIDI) is OFF.
● Channel Pressure
Status 2nd byte
DnH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Channel Pressure: 00H - 7FH (0 - 127)
* Sent when the Modulation/Pedal/C1-C3 Assign parameter (SYSTEM CONTROLLER) is
set to AFTERTOUCH.
● Pitch Bend Change
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
■ System Realtime Messages
●Active Sensing
Status
FEH
* This message is transmitted at intervals of approximately 250 msec.
* This message is not sent when Transmit Active Sensing parameter (SYSTEM MIDI) is
OFF.
■System Exclusive Messages
Universal Non-realtime System Exclusive Message” and Data Set 1 (DT1) are the only
System Exclusive messages transmitted by the JUNO-D.
●Universal Non-realtime System Exclusive Message
❍Identity Reply Message
Receiving Identity Request Message (p. 3), the JUNO-D send this message.
Status Data byte Status
F0H 7EH, dev, 06H, 02H, 41H, 64H, 01H, F7H
01H, 00H, 00H, 01H, 00H, 01H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
dev Device ID (dev: 10H - 1FH)
06H Sub ID#1 (General Information)
02H Sub ID#2 (Identity Reply)
41H ID number (Roland)
64H 01H Device family code
01H 00H Device family number code
00H 01H 00H 01H Software revision level
F7H EOX (End of Exclusive)
●Data Transmission
❍Data set 1 DT1 (12H)
Status Data byte Status
F0H 41H, dev, 00H, 64H, 12H, aaH, bbH, F7H
ccH, ddH, eeH, ... ffH, sum
Byte Explanation
F0H Exclusive status
41H ID number (Roland)
dev Device ID (dev: 00H - 1FH, 7FH)
00H Model ID #1 (JUNO-D)
64H Model ID #2 (JUNO-D)
12H Command ID (DT1)
aaH Address MSB: upper byte of the starting address of the data to be sent
bbH Address: upper middle byte of the starting address of the data to be sent
ccH Address: lower middle byte of the starting address of the data to be sent
ddH Address LSB: lower byte of the starting address of the data to be sent.
eeH Data: the actual data to be sent. Multiple bytes of data are transmitted in order
starting from the address.
: :
ffH Data
sum Checksum
F7H EOX (End Of Exclusive)
* The amount of data that can be transmitted at one time depends on the type of data, and
data will be transmitted from the specified starting address and size. Refer to the address
and size given in “Parameter Address Map” (p. 9).
* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and each
packet will be sent at an interval of about 20 ms.

9
3. Parameter Address Map
* Transmission of “#” marked address is divided to some packets. For example, ABH in hexadecimal notation will be divided to 0AH and 0BH, and is sent/received in this order.
■JUNO-D (MODEL ID = 00H 64H)
+——————————————————————————————————————————————————————————————————————————————+
| Start | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 00 | Setup |
|—————————————+————————————————————————————————————————————————————————————————|
| 01 00 00 00 | System |
|—————————————+————————————————————————————————————————————————————————————————|
| 10 00 00 00 | Temporary Performance |
| 11 00 00 00 | Temporary Patch/Rhythm (Performance Mode Part 1) |
| 11 02 00 00 | Temporary Patch/Rhythm (Performance Mode Part 2) |
| : | |
| 11 1E 00 00 | Temporary Patch/Rhythm (Performance Mode Part 16) |
| 18 00 00 00 | Temporary Patch/Rhythm (Patch Mode) |
| 1A 00 00 00 | Temporary Arpeggio |
| 1C 00 00 00 | Temporary Chord |
|—————————————+————————————————————————————————————————————————————————————————|
| 20 00 00 00 | User Performance (001) |
| 20 01 00 00 | User Performance (002) |
| : | |
| 20 07 00 00 | User Performance (008) |
|—————————————+————————————————————————————————————————————————————————————————|
| 30 00 00 00 | User Patch (001) |
| 30 01 00 00 | User Patch (002) |
| : | |
| 30 7F 00 00 | User Patch (128) |
|—————————————+————————————————————————————————————————————————————————————————|
| 40 00 00 00 | User Rhythm (01) |
| 40 01 00 00 | User Rhythm (02) |
|—————————————+————————————————————————————————————————————————————————————————|
| 50 00 00 00 | User Arpeggio (1) |
| 50 01 00 00 | User Arpeggio (2) |
| : | |
| 50 07 00 00 | User Arpeggio (8) |
|—————————————+————————————————————————————————————————————————————————————————|
| 60 00 00 00 | User Chord (1) |
| 60 01 00 00 | User Chord (2) |
| : | |
| 60 07 00 00 | User Chord (8) |
+——————————————————————————————————————————————————————————————————————————————+
* Temporary Patch/Rhythm
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Temporary Patch |
| 01 00 00 | Temporary Rhythm |
+——————————————————————————————————————————————————————————————————————————————+
* Performance
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Performance Common |
| 00 02 00 | Performance MFX |
| 00 04 00 | Performance Chorus |
| 00 06 00 | Performance Reverb |
| 00 10 00 | Performance Part (Part 1) |
| 00 11 00 | Performance Part (Part 2) |
| : | |
| 00 1F 00 | Performance Part (Part 16) |
+——————————————————————————————————————————————————————————————————————————————+
* Patch
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Patch Common |
| 00 02 00 | Patch MFX |
| 00 04 00 | Patch Chorus |
| 00 06 00 | Patch Reverb |
| 00 10 00 | Patch Tone (1) |
| 00 11 00 | Patch Tone (2) |
+——————————————————————————————————————————————————————————————————————————————+
* Rhythm
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Rhythm Common |
| 00 02 00 | Rhythm MFX |
| 00 04 00 | Rhythm Chorus |
| 00 06 00 | Rhythm Reverb |
| 00 10 00 | Rhythm Tone (Key # 21) |
| 00 11 00 | Rhythm Tone (Key # 22) |
| : | |
| 00 67 00 | Rhythm Tone (Key # 108) |
+——————————————————————————————————————————————————————————————————————————————+
* Arpeggio
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Arpeggio Setup |
| 00 10 00 | (reserved) |
+——————————————————————————————————————————————————————————————————————————————+

10
* Chord
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Chord Pattern |
| 00 01 00 | Chord Pattern |
| : | |
| 00 0B 00 | Chord Pattern |
| 00 10 00 | (reserved) |
+——————————————————————————————————————————————————————————————————————————————+
* Setup
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 0aaa | Mode Select (0 — 4) |
| | | PERFORMANCE, PATCH, GM1, GM2, GS |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 01 | 0aaa aaaa | Performance Bank Select MSB (CC# 0) (0 — 127) |
| 00 02 | 0aaa aaaa | Performance Bank Select LSB (CC# 32) (0 — 127) |
| 00 03 | 0aaa aaaa | Performance Program Number (PC) (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 04 | 0aaa aaaa | Patch Bank Select MSB (CC# 0) (0 — 127) |
| 00 05 | 0aaa aaaa | Patch Bank Select LSB (CC# 32) (0 — 127) |
| 00 06 | 0aaa aaaa | Patch Program Number (PC) (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 07 | 0000 000a | MFX Switch (0 — 1) |
| | | BYPASS, ON |
| 00 08 | 0000 000a | Chorus Switch (0 — 1) |
| | | OFF, ON |
| 00 09 | 0000 000a | Reverb Switch (0 — 1) |
| | | OFF, ON |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0A | 0000 000a | Arpeggio Switch (0 — 1) |
| | | OFF, ON |
| 00 0B | 0000 000a | Arpeggio Group (0 — 1) |
| | | USER, PRESET |
| 00 0C | 0000 aaaa | Arpeggio Number (0 — 8) |
| | | 1 — 9 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0D | 0000 000a | Chord Switch (0 — 1) |
| | | OFF, ON |
| 00 0E | 0000 000a | Chord Group (0 — 1) |
| | | USER, PRESET |
| 00 0F | 0000 aaaa | Chord Number (0 — 15) |
| | | 1 — 16 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 10 | 000a aaaa | D Beam Assign (0 — 26) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH, BEND UP, BEND DOWN, |
| | | SEQ START/STOP, SOLO SYNTH, ACTIVE EXP |
| 00 11 | 0000 aaaa | D Beam Sens (1 — 10) |
| 00 12 | 0000 000a | D Beam Polarity (0 — 1) |
| | | NORMAL, REVERSE |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 13 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* System Common
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
|# 00 00 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Master Tune (24 — 2024) |
| | | —100.0 — 100.0 [cent] |
| 00 04 | 00aa aaaa | Master Key Shift (40 — 88) |
| | | —24 — +24 |
| 00 05 | 0aaa aaaa | Master Level (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 06 | 0000 000a | Hold Pedal Polarity (0 — 1) |
| | | STANDARD, REVERSE |
| 00 07 | 000a aaaa | Control Pedal Assign (0 — 23) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH, PUNCH IN/OUT, TAP TEMPO |
| 00 08 | 000a aaaa | Modulation Assign (0 — 21) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH |
| 00 09 | 000a aaaa | C1 Knob Assign (0 — 22) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH, PATCH MODIFY |
| 00 0A | 000a aaaa | C2 Knob Assign (0 — 22) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH, PATCH MODIFY |

11
| 00 0B | 000a aaaa | C3 Knob Assign (0 — 22) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH, PATCH MODIFY |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0C | 0000 0aaa | Patch Scale Tune Type (0 — 3) |
| | | EQUAL, JUST(MAJOR) in C, JUST(MINOR) in C, ARABIC |
| 00 0D | 0aaa aaaa | Patch Scale Tune for C (0 — 127) |
| | | —64 — +63 |
| 00 0E | 0aaa aaaa | Patch Scale Tune for C# (0 — 127) |
| | | —64 — +63 |
| 00 0F | 0aaa aaaa | Patch Scale Tune for D (0 — 127) |
| | | —64 — +63 |
| 00 10 | 0aaa aaaa | Patch Scale Tune for D# (0 — 127) |
| | | —64 — +63 |
| 00 11 | 0aaa aaaa | Patch Scale Tune for E (0 — 127) |
| | | —64 — +63 |
| 00 12 | 0aaa aaaa | Patch Scale Tune for F (0 — 127) |
| | | —64 — +63 |
| 00 13 | 0aaa aaaa | Patch Scale Tune for F# (0 — 127) |
| | | —64 — +63 |
| 00 14 | 0aaa aaaa | Patch Scale Tune for G (0 — 127) |
| | | —64 — +63 |
| 00 15 | 0aaa aaaa | Patch Scale Tune for G# (0 — 127) |
| | | —64 — +63 |
| 00 16 | 0aaa aaaa | Patch Scale Tune for A (0 — 127) |
| | | —64 — +63 |
| 00 17 | 0aaa aaaa | Patch Scale Tune for A# (0 — 127) |
| | | —64 — +63 |
| 00 18 | 0aaa aaaa | Patch Scale Tune for B (0 — 127) |
| | | —64 — +63 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 19 | 0000 000a | Receive Program Change (0 — 1) |
| | | OFF, ON |
| 00 1A | 0000 000a | Receive Bank Select (0 — 1) |
| | | OFF, ON |
| 00 1B | 0000 000a | Transmit Program Change (0 — 1) |
| | | OFF, ON |
| 00 1C | 0000 000a | Transmit Bank Select (0 — 1) |
| | | OFF, ON |
| 00 1D | 0000 aaaa | Patch Receive Channel (0 — 15) |
| | | 1 — 16 |
| 00 1E | 000a aaaa | Patch Transmit Channel (0 — 17) |
| | | 1 — 16, RxCH, OFF |
| 00 1F | 000a aaaa | Performance Control Channel (0 — 16) |
| | | 1 — 16, OFF |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 20 | 0000 000a | System Clock Source (0 — 1) |
| | | INT, MIDI |
|# 00 21 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | System Tempo (5 — 300) |
| | | 5 — 300 [BPM] |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 24 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Performance Common
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Performance Name 1 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 01 | 0aaa aaaa | Performance Name 2 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 02 | 0aaa aaaa | Performance Name 3 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 03 | 0aaa aaaa | Performance Name 4 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 04 | 0aaa aaaa | Performance Name 5 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 05 | 0aaa aaaa | Performance Name 6 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 06 | 0aaa aaaa | Performance Name 7 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 07 | 0aaa aaaa | Performance Name 8 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 08 | 0aaa aaaa | Performance Name 9 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 09 | 0aaa aaaa | Performance Name 10 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 0A | 0aaa aaaa | Performance Name 11 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 0B | 0aaa aaaa | Performance Name 12 (32 — 127) |
| | | 32 — 127 [ASCII] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0C | 00aa aaaa | Voice Reserve 1 (0 — 32) |
| 00 0D | 00aa aaaa | Voice Reserve 2 (0 — 32) |
| 00 0E | 00aa aaaa | Voice Reserve 3 (0 — 32) |
| 00 0F | 00aa aaaa | Voice Reserve 4 (0 — 32) |
| 00 10 | 00aa aaaa | Voice Reserve 5 (0 — 32) |
| 00 11 | 00aa aaaa | Voice Reserve 6 (0 — 32) |
| 00 12 | 00aa aaaa | Voice Reserve 7 (0 — 32) |
| 00 13 | 00aa aaaa | Voice Reserve 8 (0 — 32) |
| 00 14 | 00aa aaaa | Voice Reserve 9 (0 — 32) |
| 00 15 | 00aa aaaa | Voice Reserve 10 (0 — 32) |
| 00 16 | 00aa aaaa | Voice Reserve 11 (0 — 32) |
| 00 17 | 00aa aaaa | Voice Reserve 12 (0 — 32) |
| 00 18 | 00aa aaaa | Voice Reserve 13 (0 — 32) |
| 00 19 | 00aa aaaa | Voice Reserve 14 (0 — 32) |
| 00 1A | 00aa aaaa | Voice Reserve 15 (0 — 32) |
| 00 1B | 00aa aaaa | Voice Reserve 16 (0 — 32) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 1C | 0aaa aaaa | Performance Level (0 — 127) |
| 00 1D | 000a aaaa | MFX Source (0 — 16) |
| | | PERFORM, PART1 — PART16 |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 1E | Total Size |
+——————————————————————————————————————————————————————————————————————————————+

12
* Performance MFX
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 00aa aaaa | MFX Type (0 — 47) |
| | | 00 THROUGH, 01 STEREO EQ, 02 OVERDRIVE, |
| | | 03 DISTORTION, 04 PHASER, 05 SPECTRUM, |
| | | 06 ENHANCER, 07 AUTO WAH, 08 ROTARY, |
| | | 09 COMPRESSOR, 10 LIMITER, 11 HEXA—CHORUS, |
| | | 12 TREMOLO CHO, 13 SPACE—D, 14 St CHORUS, |
| | | 15 St FLANGER, 16 STEP FLANGER, 17 St DELAY, |
| | | 18 LONG DELAY, 19 MOD DELAY, 20 3 TAP DELAY, |
| | | 21 4 TAP DELAY, 22 TM CTRL DLY, 23 2V PCH SHIFT, |
| | | 24 FB PCH SHIFT, 25 REVERB, 26 GATED REVERB, |
| | | 27 OD>CHORUS, 28 OD>FLANGER, 29 OD>DELAY, |
| | | 30 DIST>CHORUS, 31 DIST>FLANGER, 32 DIST>DELAY, |
| | | 33 ENH>CHORUS, 34 ENH>FLANGER, 35 ENH>DELAY, |
| | | 36 CHORUS>DELAY, 37 FLG>DELAY, 38 CHO>FLANGER, |
| | | 39 CHORUS/DELAY, 40 FLG/DELAY, 41 CHO/FLANGER, |
| | | 42 LOFI, 43 SLICER, 44 TREMOLO, |
| | | 45 AUTO PAN, 46 TUMBLING DELAY, |
| | | 47 FEEDBACK RIPPER |
| 00 01 | 0aaa aaaa | MFX Chorus Send Level (0 — 127) |
| 00 02 | 0aaa aaaa | MFX Reverb Send Level (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 03 | 0000 aaaa | MFX Control Assign 1 (0 — 2) |
| | | OFF, 1 — 2 |
| 00 04 | 0000 aaaa | MFX Control Assign 2 (0 — 2) |
| | | OFF, 1 — 2 |
|# 00 05 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 1 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 09 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 2 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 0D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 3 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 4 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 15 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 5 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 19 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 6 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 1D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 7 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 21 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 8 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 25 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 9 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 29 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 10 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 2D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 11 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 31 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 12 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 35 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 13 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 39 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 14 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 3D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 15 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 41 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 16 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 45 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 17 (12768 — 52768) |
| | | —20000 — +20000 |

13
|# 00 49 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 18 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 4D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 19 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 51 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 20 (12768 — 52768) |
| | | —20000 — +20000 |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 55 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Performance Chorus
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 0aaa | Chorus Type (0 — 7) |
| | | CHORUS1, CHORUS2, CHORUS3, CHORUS4, |
| | | FEEDBACK CHORUS, FLANGER, |
| | | SHORT DELAY, SHORT DELAY(FB) |
| 00 01 | 0000 0aaa | Chorus Pre—LPF (0 — 7) |
| 00 02 | 0aaa aaaa | Chorus Level (0 — 127) |
| 00 03 | 0aaa aaaa | Chorus Feedback (0 — 127) |
| 00 04 | 0aaa aaaa | Chorus Delay (0 — 127) |
| 00 05 | 0aaa aaaa | Chorus Rate (0 — 127) |
| 00 06 | 0aaa aaaa | Chorus Depth (0 — 127) |
| 00 07 | 0aaa aaaa | Chorus Send Level to Reverb (0 — 127) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 08 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Performance Reverb
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 0aaa | Reverb Type (0 — 7) |
| | | ROOM1, ROOM2, ROOM3, |
| | | HALL1, HALL2, PLATE, |
| | | DELAY, PANNING DELAY |
| 00 01 | 0000 0aaa | Reverb Character (0 — 7) |
| 00 02 | 0000 0aaa | Reverb Pre—LPF (0 — 7) |
| 00 03 | 0aaa aaaa | Reverb Level (0 — 127) |
| 00 04 | 0aaa aaaa | Reverb Time (0 — 127) |
| 00 05 | 0aaa aaaa | Reverb Delay Feedback (0 — 127) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 06 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Performance Part
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Patch Bank Select MSB (CC# 0) (0 — 127) |
| 00 01 | 0aaa aaaa | Patch Bank Select LSB (CC# 32) (0 — 127) |
| 00 02 | 0aaa aaaa | Patch Program Number (PC) (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 03 | 0aaa aaaa | Part Level (CC# 7) (0 — 127) |
| 00 04 | 0aaa aaaa | Part Pan (CC# 10) (0 — 127) |
| | | RANDOM, L63 — 63R |
| 00 05 | 0000 000a | Part MFX Switch (0 — 1) |
| | | BYPASS, ON |
| 00 06 | 0aaa aaaa | Part Chorus Send Level (CC# 93) (0 — 127) |
| 00 07 | 0aaa aaaa | Part Reverb Send Level (CC# 91) (0 — 127) |
| 00 08 | 0000 aaaa | Receive Channel (0 — 15) |
| | | 1 — 16 |
| 00 09 | 0000 000a | Receive Switch (0 — 1) |
| | | OFF, ON |
| 00 0A | 0000 000a | Receive Program Change (0 — 1) |
| | | OFF, ON |
| 00 0B | 0000 000a | Receive Bank Select (0 — 1) |
| | | OFF, ON |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0C | 0000 0aaa | Part Scale Tune Type (0 — 3) |
| | | EQUAL, JUST(MAJOR) in C, JUST(MINOR) in C, ARABIC |
| 00 0D | 0aaa aaaa | Part Scale Tune for C (0 — 127) |
| | | —64 — +63 |
| 00 0E | 0aaa aaaa | Part Scale Tune for C# (0 — 127) |
| | | —64 — +63 |
| 00 0F | 0aaa aaaa | Part Scale Tune for D (0 — 127) |
| | | —64 — +63 |
| 00 10 | 0aaa aaaa | Part Scale Tune for D# (0 — 127) |
| | | —64 — +63 |
| 00 11 | 0aaa aaaa | Part Scale Tune for E (0 — 127) |
| | | —64 — +63 |
| 00 12 | 0aaa aaaa | Part Scale Tune for F (0 — 127) |
| | | —64 — +63 |
| 00 13 | 0aaa aaaa | Part Scale Tune for F# (0 — 127) |
| | | —64 — +63 |
| 00 14 | 0aaa aaaa | Part Scale Tune for G (0 — 127) |
| | | —64 — +63 |
| 00 15 | 0aaa aaaa | Part Scale Tune for G# (0 — 127) |
| | | —64 — +63 |
| 00 16 | 0aaa aaaa | Part Scale Tune for A (0 — 127) |
| | | —64 — +63 |
| 00 17 | 0aaa aaaa | Part Scale Tune for A# (0 — 127) |
| | | —64 — +63 |
| 00 18 | 0aaa aaaa | Part Scale Tune for B (0 — 127) |
| | | —64 — +63 |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 19 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+

14
* Patch Common
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Patch Name 1 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 01 | 0aaa aaaa | Patch Name 2 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 02 | 0aaa aaaa | Patch Name 3 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 03 | 0aaa aaaa | Patch Name 4 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 04 | 0aaa aaaa | Patch Name 5 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 05 | 0aaa aaaa | Patch Name 6 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 06 | 0aaa aaaa | Patch Name 7 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 07 | 0aaa aaaa | Patch Name 8 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 08 | 0aaa aaaa | Patch Name 9 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 09 | 0aaa aaaa | Patch Name 10 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 0A | 0aaa aaaa | Patch Name 11 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 0B | 0aaa aaaa | Patch Name 12 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 0C | 0aaa aaaa | Patch Category (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0D | 0000 00aa | Keyboard Mode (0 — 2) |
| | | SINGLE, SPLIT, DUAL |
| 00 0E | 0aaa aaaa | Patch Level (0 — 127) |
| 00 0F | 0aaa aaaa | Tone Balance (CC# 8) (0 — 127) |
| | | —64(LOWER) — +63(UPPER) |
| 00 10 | 0aaa aaaa | Split Point (21 — 108) |
| | | A0 — C8 |
| 00 11 | 0000 00aa | Split Arpeggio (0 — 2) |
| | | UPPER, LOWER, BOTH |
| 00 12 | 0000 00aa | Solo Switch (MONO ON/POLY ON) (0 — 3) |
| | | OFF, ON, UPPER, LOWER |
| 00 13 | 0000 00aa | Modulation Destination (0 — 2) |
| | | UPPER, LOWER, BOTH |
| 00 14 | 0000 00aa | Pitch Bend Destination (0 — 2) |
| | | UPPER, LOWER, BOTH |
| 00 15 | 0000 00aa | Modify Destination (0 — 2) |
| | | UPPER, LOWER, BOTH |
| 00 16 | 0000 00aa | Expression Destination (0 — 2) |
| | | UPPER, LOWER, BOTH |
| 00 17 | 0000 000a | Active Expression Switch (0 — 1) |
| | | OFF, ON |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 18 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Patch MFX
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 00aa aaaa | MFX Type (0 — 47) |
| | | 00 THROUGH, 01 STEREO EQ, 02 OVERDRIVE, |
| | | 03 DISTORTION, 04 PHASER, 05 SPECTRUM, |
| | | 06 ENHANCER, 07 AUTO WAH, 08 ROTARY, |
| | | 09 COMPRESSOR, 10 LIMITER, 11 HEXA—CHORUS, |
| | | 12 TREMOLO CHO, 13 SPACE—D, 14 St CHORUS, |
| | | 15 St FLANGER, 16 STEP FLANGER, 17 St DELAY, |
| | | 18 LONG DELAY, 19 MOD DELAY, 20 3 TAP DELAY, |
| | | 21 4 TAP DELAY, 22 TM CTRL DLY, 23 2V PCH SHIFT, |
| | | 24 FB PCH SHIFT, 25 REVERB, 26 GATED REVERB, |
| | | 27 OD>CHORUS, 28 OD>FLANGER, 29 OD>DELAY, |
| | | 30 DIST>CHORUS, 31 DIST>FLANGER, 32 DIST>DELAY, |
| | | 33 ENH>CHORUS, 34 ENH>FLANGER, 35 ENH>DELAY, |
| | | 36 CHORUS>DELAY, 37 FLG>DELAY, 38 CHO>FLANGER, |
| | | 39 CHORUS/DELAY, 40 FLG/DELAY, 41 CHO/FLANGER, |
| | | 42 LOFI, 43 SLICER, 44 TREMOLO, |
| | | 45 AUTO PAN, 46 TUMBLING DELAY, |
| | | 47 FEEDBACK RIPPER |
| 00 01 | 0aaa aaaa | MFX Send Level to Chorus (0 — 127) |
| 00 02 | 0aaa aaaa | MFX Send Level to Reverb (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 03 | 0000 aaaa | MFX Control Assign 1 (0 — 2) |
| | | OFF, 1 — 2 |
| 00 04 | 0000 aaaa | MFX Control Assign 2 (0 — 2) |
| | | OFF, 1 — 2 |
|# 00 05 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 1 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 09 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 2 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 0D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 3 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 4 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 15 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 5 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 19 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |

15
| | 0000 dddd | MFX Parameter 6 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 1D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 7 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 21 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 8 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 25 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 9 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 29 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 10 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 2D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 11 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 31 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 12 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 35 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 13 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 39 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 14 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 3D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 15 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 41 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 16 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 45 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 17 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 49 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 18 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 4D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 19 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 51 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 20 (12768 — 52768) |
| | | —20000 — +20000 |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 55 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Patch Chorus
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 0aaa | Chorus Type (0 — 7) |
| | | CHORUS1, CHORUS2, CHORUS3, CHORUS4, |
| | | FEEDBACK CHORUS, FLANGER, |
| | | SHORT DELAY, SHORT DELAY(FB) |
| 00 01 | 0000 0aaa | Chorus Pre—LPF (0 — 7) |
| 00 02 | 0aaa aaaa | Chorus Level (0 — 127) |
| 00 03 | 0aaa aaaa | Chorus Feedback (0 — 127) |
| 00 04 | 0aaa aaaa | Chorus Delay (0 — 127) |
| 00 05 | 0aaa aaaa | Chorus Rate (0 — 127) |
| 00 06 | 0aaa aaaa | Chorus Depth (0 — 127) |
| 00 07 | 0aaa aaaa | Chorus Send Level to Reverb (0 — 127) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 08 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Patch Reverb
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 0aaa | Reverb Type (0 — 7) |
| | | ROOM1, ROOM2, ROOM3, |
| | | HALL1, HALL2, PLATE, |
| | | DELAY, PANNING DELAY |
| 00 01 | 0000 0aaa | Reverb Character (0 — 7) |
| 00 02 | 0000 0aaa | Reverb Pre—LPF (0 — 7) |
| 00 03 | 0aaa aaaa | Reverb Level (0 — 127) |
| 00 04 | 0aaa aaaa | Reverb Time (0 — 127) |
| 00 05 | 0aaa aaaa | Reverb Delay Feedback (0 — 127) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 06 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+

16
* Patch Tone
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
|# 00 00 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | Original Tone Number (0 — 639) |
| | | 0 — 639 |
| 00 03 | 0aaa aaaa | Tone Pan (0 — 127) |
| | | L64 — 63R |
| 00 04 | 0000 000a | Tone MFX Switch (0 — 1) |
| | | BYPASS, ON |
| 00 05 | 0aaa aaaa | Tone Chorus Send Level (0 — 127) |
| 00 06 | 0aaa aaaa | Tone Reverb Send Level (0 — 127) |
| 00 07 | 0aaa aaaa | Coarse Tune (RPN# 2) (16 — 112) |
| | | —48 — +48 |
| 00 08 | 0aaa aaaa | Fine Tune (RPN# 1) (14 — 114) |
| | | —50 — +50 |
| 00 09 | 0aaa aaaa | LFO Rate (CC# 76) (0 — 127) |
| | | —64 — +63 |
| 00 0A | 0aaa aaaa | LFO Depth (CC# 77) (0 — 127) |
| | | —64 — +63 |
| 00 0B | 0aaa aaaa | LFO Delay (CC# 78) (0 — 127) |
| | | —64 — +63 |
| 00 0C | 0000 000a | LFO Filter Switch (0 — 1) |
| | | OFF, ON |
| 00 0D | 0aaa aaaa | Cutoff Frequency (CC# 74) (0 — 127) |
| | | —64 — +63 |
| 00 0E | 0aaa aaaa | Resonance (CC# 71) (0 — 127) |
| | | —64 — +63 |
| 00 0F | 0aaa aaaa | Attack Time (CC# 73) (0 — 127) |
| | | —64 — +63 |
| 00 10 | 0aaa aaaa | Decay Time (CC# 75) (0 — 127) |
| | | —64 — +63 |
| 00 11 | 0aaa aaaa | Release Time (CC# 72) (0 — 127) |
| | | —64 — +63 |
| 00 12 | 0000 000a | Portamento Switch (CC# 65) (0 — 1) |
| | | OFF, ON |
| 00 13 | 0aaa aaaa | Portamento Time (CC# 5) (0 — 127) |
| 00 14 | 0aaa aaaa | Velocity Sens Depth (0 — 127) |
| | | —64 — +63 |
| 00 15 | 0aaa aaaa | Velocity Sens Offset (0 — 127) |
| | | —64 — +63 |
| 00 16 | 000a aaaa | Pitch Bend Range (RPN# 0) (0 — 24) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 17 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Rhythm Common
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Rhythm Name 1 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 01 | 0aaa aaaa | Rhythm Name 2 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 02 | 0aaa aaaa | Rhythm Name 3 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 03 | 0aaa aaaa | Rhythm Name 4 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 04 | 0aaa aaaa | Rhythm Name 5 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 05 | 0aaa aaaa | Rhythm Name 6 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 06 | 0aaa aaaa | Rhythm Name 7 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 07 | 0aaa aaaa | Rhythm Name 8 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 08 | 0aaa aaaa | Rhythm Name 9 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 09 | 0aaa aaaa | Rhythm Name 10 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 0A | 0aaa aaaa | Rhythm Name 11 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 0B | 0aaa aaaa | Rhythm Name 12 (32 — 127) |
| | | 32 — 127 [ASCII] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0C | 000a aaaa | Original Rhythm Number (0 — 19) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 0D | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Rhythm MFX
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 00aa aaaa | MFX Type (0 — 47) |
| | | 00 THROUGH, 01 STEREO EQ, 02 OVERDRIVE, |
| | | 03 DISTORTION, 04 PHASER, 05 SPECTRUM, |
| | | 06 ENHANCER, 07 AUTO WAH, 08 ROTARY, |
| | | 09 COMPRESSOR, 10 LIMITER, 11 HEXA—CHORUS, |
| | | 12 TREMOLO CHO, 13 SPACE—D, 14 St CHORUS, |
| | | 15 St FLANGER, 16 STEP FLANGER, 17 St DELAY, |
| | | 18 LONG DELAY, 19 MOD DELAY, 20 3 TAP DELAY, |
| | | 21 4 TAP DELAY, 22 TM CTRL DLY, 23 2V PCH SHIFT, |
| | | 24 FB PCH SHIFT, 25 REVERB, 26 GATED REVERB, |
| | | 27 OD>CHORUS, 28 OD>FLANGER, 29 OD>DELAY, |
| | | 30 DIST>CHORUS, 31 DIST>FLANGER, 32 DIST>DELAY, |
| | | 33 ENH>CHORUS, 34 ENH>FLANGER, 35 ENH>DELAY, |
| | | 36 CHORUS>DELAY, 37 FLG>DELAY, 38 CHO>FLANGER, |
| | | 39 CHORUS/DELAY, 40 FLG/DELAY, 41 CHO/FLANGER, |
| | | 42 LOFI, 43 SLICER, 44 TREMOLO, |
| | | 45 AUTO PAN, 46 TUMBLING DELAY, |
| | | 47 FEEDBACK RIPPER |
| 00 01 | 0aaa aaaa | MFX Chorus Send Level (0 — 127) |
| 00 02 | 0aaa aaaa | MFX Reverb Send Level (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 03 | 0000 aaaa | MFX Control Assign 1 (0 — 2) |
| | | OFF, 1 — 2 |
| 00 04 | 0000 aaaa | MFX Control Assign 2 (0 — 2) |
| | | OFF, 1 — 2 |

17
|# 00 05 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 1 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 09 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 2 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 0D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 3 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 4 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 15 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 5 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 19 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 6 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 1D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 7 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 21 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 8 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 25 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 9 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 29 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 10 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 2D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 11 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 31 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 12 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 35 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 13 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 39 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 14 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 3D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 15 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 41 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 16 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 45 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 17 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 49 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 18 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 4D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 19 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 51 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 20 (12768 — 52768) |
| | | —20000 — +20000 |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 55 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+

18
* Rhythm Chorus
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 0aaa | Chorus Type (0 — 7) |
| | | CHORUS1, CHORUS2, CHORUS3, CHORUS4, |
| | | FEEDBACK CHORUS, FLANGER, |
| | | SHORT DELAY, SHORT DELAY(FB) |
| 00 01 | 0000 0aaa | Chorus Pre—LPF (0 — 7) |
| 00 02 | 0aaa aaaa | Chorus Level (0 — 127) |
| 00 03 | 0aaa aaaa | Chorus Feedback (0 — 127) |
| 00 04 | 0aaa aaaa | Chorus Delay (0 — 127) |
| 00 05 | 0aaa aaaa | Chorus Rate (0 — 127) |
| 00 06 | 0aaa aaaa | Chorus Depth (0 — 127) |
| 00 07 | 0aaa aaaa | Chorus Send Level to Reverb (0 — 127) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 08 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Rhythm Reverb
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 0aaa | Reverb Type (0 — 7) |
| | | ROOM1, ROOM2, ROOM3, |
| | | HALL1, HALL2, PLATE, |
| | | DELAY, PANNING DELAY |
| 00 01 | 0000 0aaa | Reverb Character (0 — 7) |
| 00 02 | 0000 0aaa | Reverb Pre—LPF (0 — 7) |
| 00 03 | 0aaa aaaa | Reverb Level (0 — 127) |
| 00 04 | 0aaa aaaa | Reverb Time (0 — 127) |
| 00 05 | 0aaa aaaa | Reverb Delay Feedback (0 — 127) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 06 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Rhythm Tone
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Rhythm Tone Pitch (0 — 127) |
| | | —60 — +67 |
| 00 01 | 0aaa aaaa | Rhythm Tone Level (0 — 127) |
| 00 02 | 0aaa aaaa | Rhythm Tone Pan (0 — 127) |
| | | RANDOM, L63 — 63R |
| 00 03 | 0aaa aaaa | Reverb Send Level (0 — 127) |
| 00 04 | 0aaa aaaa | Chorus Send Level (0 — 127) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 05 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Arpeggio Setup
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 000a | Arpeggio Hold (0 — 1) |
| | | OFF, ON |
| 00 01 | 0000 000a | Arpeggio Style Group (0 — 1) |
| | | USER, PRESET |
| 00 02 | 0aaa aaaa | Arpeggio Style Number (0 — 127) |
| | | 1 — 128 |
| 00 03 | 0aaa aaaa | Arpeggio Variation (0 — 127) |
| | | 1 — 128 |
| 00 04 | 00aa aaaa | Arpeggio Motif (0 — 9) |
| | | UP, DOWN, UP&DOWN, RANDOM, |
| | | NOTE—ORDER, GLISSANDO, CHORD, |
| | | AUTO1, AUTO2, PHRASE |
| 00 05 | 0aaa aaaa | Arpeggio Accent Rate (0 — 100) |
| 00 06 | 0aaa aaaa | Arpeggio Shuffle Rate (0 — 100) |
| 00 07 | 0000 000a | Arpeggio Shuffle Resolution (0 — 1) |
| | | 16TH, 8TH |
| 00 08 | 0aaa aaaa | Arpeggio Keyboard Velocity (0 — 127) |
| | | REAL, 1 — 127 |
| 00 09 | 0000 0aaa | Arpeggio Octave Range (61 — 67) |
| | | —3 — +3 |
| 00 0A | 0000 000a | Arpeggio Key Trigger (0 — 1) |
| | | OFF, ON |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 0B | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Chord Pattern
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Chord Pattern Assign 1 (20 — 108) |
| | | OFF, A0 — C8 |
| 00 01 | 0aaa aaaa | Chord Pattern Assign 2 (20 — 108) |
| | | OFF, A0 — C8 |
| 00 02 | 0aaa aaaa | Chord Pattern Assign 3 (20 — 108) |
| | | OFF, A0 — C8 |
| 00 03 | 0aaa aaaa | Chord Pattern Assign 4 (20 — 108) |
| | | OFF, A0 — C8 |
| 00 04 | 0aaa aaaa | Chord Pattern Assign 5 (20 — 108) |
| | | OFF, A0 — C8 |
| 00 05 | 0aaa aaaa | Chord Pattern Assign 6 (20 — 108) |
| | | OFF, A0 — C8 |
| 00 06 | 0aaa aaaa | Chord Pattern Assign 7 (20 — 108) |
| | | OFF, A0 — C8 |
| 00 07 | 0aaa aaaa | Chord Pattern Assign 8 (20 — 108) |
| | | OFF, A0 — C8 |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 08 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+

19
Type 1: STEREO EQ
MFX Parameter Value Display
1 Low Freq 0 - 1 200, 400 [Hz]
2 Low Gain 0 - 30 -15 - +15 [dB]
3 High Freq 0 - 2 2000, 4000, 8000 [Hz]
4 High Gain 0 - 30 -15 - +15 [dB]
5 P1 Freq 0 - 16 200, 250, 315, 400, 500, 630, 800, 1000,
1250, 1600, 2000, 2500, 3150, 4000, 5000,
6300, 8000 [Hz]
6 P1 Q 0 - 4 0.5, 1.0, 2.0, 4.0, 8.0
7 P1 Gain 0 - 30 -15 - +15 [dB]
8 P2 Freq 0 - 16 200, 250, 315, 400, 500, 630, 800, 1000,
1250, 1600, 2000, 2500, 3150, 4000, 5000,
6300, 8000 [Hz]
9 P2 Q 0 - 4 0.5, 1.0, 2.0, 4.0, 8.0
10 P2 Gain 0 - 30 -15 - +15 [dB]
11 Level 0 - 127 0 - 127
Type 2: OVERDRIVE
MFX Parameter Value Display
1 Drive 0 - 127 0 - 127
2 Pan 0 - 127 L64 - 63R
3 Amp Type 0 - 3 SMALL, BUILT-IN, 2-STACK, 3-
STACK
4 Low Gain 0 - 30 -15 - +15 [dB]
5 High Gain 0 - 30 -15 - +15 [dB]
6 Level 0 - 127 0 - 127
Type 3: DISTORTION
MFX Parameter Value Display
1 Drive 0 - 127 0 - 127
2 Pan 0 - 127 L64 - 63R
3 Amp Type 0 - 3 SMALL, BUILT-IN, 2-STACK, 3-
STACK
4 Low Gain 0 - 30 -15 - +15 [dB]
5 High Gain 0 - 30 -15 - +15 [dB]
6 Level 0 - 127 0 - 127
Type 4: PHASER
MFX Parameter Value Display
1 Manual 0 - 125 100 - 8000 [Hz]
2 Rate 1 - 200 0.05 - 10.00 [Hz]
3 Depth 0 - 127 0 - 127
4 Resonance 0 - 127 0 - 127
5 Mix 0 - 127 0 - 127
6 Pan 0 - 127 L64 - 63R
7 Level 0 - 127 0 - 127
Type 5: SPECTRUM
MFX Parameter Value Display
1 Band1 0 - 30 -15 - +15 [dB]
2 Band2 0 - 30 -15 - +15 [dB]
3 Band3 0 - 30 -15 - +15 [dB]
4 Band4 0 - 30 -15 - +15 [dB]
5 Band5 0 - 30 -15 - +15 [dB]
6 Band6 0 - 30 -15 - +15 [dB]
7 Band7 0 - 30 -15 - +15 [dB]
8 Band8 0 - 30 -15 - +15 [dB]
9 Q 0 - 4 0.5, 1.0, 2.0, 4.0, 8.0
10 Pan 0 - 127 L64 - 63R
11 Level 0 - 127 0 - 127
Type 6: ENHANCER
MFX Parameter Value Display
1 Sens 0 - 127 0 - 127
2 Mix 0 - 127 0 - 127
3 Low Gain 0 - 30 -15 - +15 [dB]
4 High Gain 0 - 30 -15 - +15 [dB]
5 Level 0 - 127 0 - 127
Type 7: AUTO WAH
MFX Parameter Value Display
1 Filter Type 0 - 1 LPF, BPF
2 Rate 1 - 200 0.05 - 10.00 [Hz]
3 Depth 0 - 127 0 - 127
4 Sens 0 - 127 0 - 127
5 Manual 0 - 127 0 - 127
6 Peak 0 - 127 0 - 127
7 Level 0 - 127 0 - 127
Type 8: ROTARY
MFX Parameter Value Display
1 High Slow Rate 1 - 200 0.05 - 10.00 [Hz]
2 Low Slow Rate 1 - 200 0.05 - 10.00 [Hz]
3 High Fast Rate 1 - 200 0.05 - 10.00 [Hz]
4 Low Fast Rate 1 - 200 0.05 - 10.00 [Hz]
5 Speed 0 - 1 SLOW, FAST
6 High Acceleration 0 - 15 0 - 15
7 Low Acceleration 0 - 15 0 - 15
8 High Level 0 - 127 0 - 127
9 Low Level 0 - 127 0 - 127
10 Separation 0 - 127 0 - 127
11 Level 0 - 127 0 - 127
Type 9: COMPRESSOR
MFX Parameter Value Display
1 Sustain 0 - 127 0 - 127
2 Attack 0 - 127 0 - 127
3 Pan 0 - 127 L64 - 63R
4 Post Gain 0 - 3 0, +6, +12, +18 [dB]
5 Low Gain 0 - 30 -15 - +15 [dB]
6 High Gain 0 - 30 -15 - +15 [dB]
7 Level 0 - 127 0 - 127
Type 10: LIMITER
MFX Parameter Value Display
1 Threshold 0 - 127 0 - 127
2 Release 0 - 127 0 - 127
3 Ratio 0 - 3 1.5:1, 2:1, 4:1, 100:1
4 Pan 0 - 127 L64 - 63R
5 Post Gain 0 - 3 0, +6, +12, +18 [dB]
6 Low Gain 0 - 30 -15 - +15 [dB]
7 High Gain 0 - 30 -15 - +15 [dB]
8 Level 0 - 127 0 - 127
Type 11: HEXA-CHORUS
MFX Parameter Value Display
1 Pre Delay 0 - 125 0.0 - 100 [ms]
2 Rate 1 - 200 0.05 - 10.00 [Hz]
3 Depth 0 - 127 0 - 127
4Pre Delay Deviation 0 - 20 0 - 20
5 Depth Deviation 0 - 40 -20 - +20
6 Pan Deviation 0 - 20 0 - 20
7 Balance 0 - 100 D100:0W - D0:100W
8 Level 0 - 127 0 - 127
Type 12: TREMOLO CHORUS
MFX Parameter Value Display
1 Pre Delay 0 - 125 0.0 - 100 [ms]
2 Chorus Rate 1 - 200 0.05 - 10.00 [Hz]
3 Chorus Depth 0 - 127 0 - 127
4 Tremolo Rate 1 - 200 0.05 - 10.00 [Hz]
5Tremolo Separation
0 - 127
0 - 127
6 Tremolo Phase 0 - 90 0 - 180 [deg]
7 Balance 0 - 100 D100:0W - D0:100W
8 Level 0 - 127 0 - 127
Type 13: SPACE-D
MFX Parameter Value Display
1 Pre Delay 0 - 125 0.0 - 100 [ms]
2 Rate 1 - 200 0.05 - 10.00 [Hz]
3 Depth 0 - 127 0 - 127
4 Phase 0 - 90 0 - 180 [deg]
5 Low Gain 0 - 30 -15 - +15 [dB]
6 High Gain 0 - 30 -15 - +15 [dB]
7 Balance 0 - 100 D100:0W - D0:100W
8 Level 0 - 127 0 - 127

20
Type 14: STEREO CHORUS
MFX Parameter Value Display
1 Filter Type 0 - 2 OFF, LPF, HPF
2 Cutoff Freq 0 - 16 200, 250, 315, 400, 500, 630, 800, 1000,
1250, 1600, 2000, 2500, 3150, 4000, 5000,
6300, 8000 [Hz]
3 Pre Delay 0 - 125 0.0 - 100 [ms]
4 Rate 1 - 200 0.05 - 10.00 [Hz]
5 Depth 0 - 127 0 - 127
6 Phase 0 - 90 0 - 180 [deg]
7 Low Gain 0 - 30 -15 - +15 [dB]
8 High Gain 0 - 30 -15 - +15 [dB]
9 Balance 0 - 100 D100:0W - D0:100W
10 Level 0 - 127 0 - 127
Type 15: STEREO FLANGER
MFX Parameter Value Display
1 Filter Type 0 - 2 OFF, LPF, HPF
2 Cutoff Freq 0 - 16 200, 250, 315, 400, 500, 630, 800, 1000,
1250, 1600, 2000, 2500, 3150, 4000, 5000,
6300, 8000 [Hz]
3 Pre Delay 0 - 125 0.0 - 100 [ms]
4 Rate 1 - 200 0.05 - 10.00 [Hz]
5 Depth 0 - 127 0 - 127
6 Phase 0 - 90 0 - 180 [deg]
7 Feedback 0 - 98 -98 - +98 [%]
8 Low Gain 0 - 30 -15 - +15 [dB]
9 High Gain 0 - 30 -15 - +15 [dB]
10 Balance 0 - 100 D100:0W - D0:100W
11 Level 0 - 127 0 - 127
Type 16: STEP FLANGER
MFX Parameter Value Display
1 Pre Delay 0 - 125 0.0 - 100 [ms]
2 Rate 1 - 200 0.05 - 10.00 [Hz]
3 Depth 0 - 127 0 - 127
4 Feedback 0 - 98 -98 - +98 [%]
5 Step Rate 1 - 222 0.1 - 20.00 [Hz] MUSICAL-NOTES
6 Phase 0 - 90 0 - 180 [deg]
7 Balance 0 - 100 D100:0W - D0:100W
8 Reset 0 - 1 OFF, ON
9 Level 0 - 127 0 - 127
Type 17: STEREO DELAY
MFX Parameter Value Display
1 Feedback mode 0 - 1 NORMAL, CROSS
2 Delay Left 0 - 430 0 - 420 [ms] MUSICAL-NOTES
3 Delay Right 0 - 430 0 - 420 [ms] MUSICAL-NOTES
4 Phase Left 0 - 1 NORMAL, INVERT
5 Phase Right 0 - 1 NORMAL, INVERT
6 Feedback 0 - 98 -98 - +98 [%]
7 HF Damp 0 - 17 200, 250, 315, 400, 500, 630, 800, 1000,
1250, 1600, 2000, 2500, 3150, 4000, 5000,
6300, 8000, BYPASS [Hz]
8 Low Gain 0 - 30 -15 - +15 [dB]
9 High Gain 0 - 30 -15 - +15 [dB]
10 Balance 0 - 100 D100:0W - D0:100W
11 Level 0 - 127 0 - 127
Type 18: LONG DELAY
MFX Parameter Value Display
1 Delay 0 - 850 0 - 840 [ms] MUSICAL-NOTES
2 Feedback 0 - 98 -98 - +98 [%]
3 HF Damp 0 - 17 200, 250, 315, 400, 500, 630, 800, 1000,
1250, 1600, 2000, 2500, 3150, 4000, 5000,
6300, 8000, BYPASS [Hz]
4 Low Gain 0 - 30 -15 - +15 [dB]
5 High Gain 0 - 30 -15 - +15 [dB]
6 Balance 0 - 100 D100:0W - D0:100W
7 Level 0 - 127 0 - 127
Type 19: MODULATION DELAY
MFX Parameter Value Display
1 Feedback mode 0 - 1 NORMAL, CROSS
2 Delay Left 0 - 370 0 - 370 [ms]
3 Delay Right 0 - 370 0 - 370 [ms]
4 Feedback 0 - 98 -98 - +98 [%]
5 HF Damp 0 - 17 200, 250, 315, 400, 500, 630, 800, 1000,
1250, 1600, 2000, 2500, 3150, 4000, 5000,
6300, 8000, BYPASS [Hz]
6 Rate 1 - 200 0.05 - 10.00 [Hz]
7 Depth 0 - 127 0 - 127
8 Phase 0 - 90 0 - 180 [deg]
9 Low Gain 0 - 30 -15 - +15 [dB]
10 High Gain 0 - 30 -15 - +15 [dB]
11 Balance 0 - 100 D100:0W - D0:100W
12 Level 0 - 127 0 - 127
Type 20: TRIPLE TAP DELAY
MFX Parameter Value Display
1 Delay Left 0 - 850 0 - 840 [ms] MUSICAL-NOTES
2 Delay Right 0 - 850 0 - 840 [ms] MUSICAL-NOTES
3 Delay Center 0 - 850 0 - 840 [ms] MUSICAL-NOTES
4 Feedback 0 - 98 -98 - +98 [%]
5 HF Damp 0 - 17 200, 250, 315, 400, 500, 630, 800, 1000,
1250, 1600, 2000, 2500, 3150, 4000, 5000,
6300, 8000, BYPASS [Hz]
6 Left Level 0 - 127 0 - 127
7 Right Level 0 - 127 0 - 127
8 Center Level 0 - 127 0 - 127
9 Low Gain 0 - 30 -15 - +15 [dB]
10 High Gain 0 - 30 -15 - +15 [dB]
11 Balance 0 - 100 D100:0W - D0:100W
12 Level 0 - 127 0 - 127
Type 21: QUADRUPLE TAP DELAY
MFX Parameter Value Display
1 Delay 1 0 - 850 0 - 840 [ms] MUSICAL-NOTES
2 Delay 2 0 - 850 0 - 840 [ms] MUSICAL-NOTES
3 Delay 3 0 - 850 0 - 840 [ms] MUSICAL-NOTES
4 Delay 4 0 - 850 0 - 840 [ms] MUSICAL-NOTES
5 Level 1 0 - 127 0 - 127
6 Level 2 0 - 127 0 - 127
7 Level 3 0 - 127 0 - 127
8 Level 4 0 - 127 0 - 127
9 Feedback 0 - 98 -98 - +98 [%]
10 HF Damp 0 - 17 200, 250, 315, 400, 500, 630, 800, 1000,
1250, 1600, 2000, 2500, 3150, 4000, 5000,
6300, 8000, BYPASS [Hz]
11 Balance 0 - 100 D100:0W - D0:100W
12 Level 0 - 127 0 - 127
Type 22: TIME CONTROL DELAY
MFX Parameter Value Display
1 Delay 0 - 840 0 - 840 [ms]
2 Feedback 0 - 98 -98 - +98 [%]
3 Acceleration 0 - 15 0 - 15
4 HF Damp 0 - 17 200, 250, 315, 400, 500, 630, 800, 1000,
1250, 1600, 2000, 2500, 3150, 4000, 5000,
6300, 8000, BYPASS [Hz]
5 Pan 0 - 127 L64 - 63R
6 Low Gain 0 - 30 -15 - +15 [dB]
7 High Gain 0 - 30 -15 - +15 [dB]
8 Balance 0 - 100 D100:0W - D0:100W
9 Level 0 - 127 0 - 127
Type 23: 2VOICE PITCH SHIFTER
MFX Parameter Value Display
1 Mode 0 - 4 1, 2, 3, 4, 5
2 Coarse A 0 - 36 -24 - +12 [semi]
3 Coarse B 0 - 36 -24 - +12 [semi]
4 Fine A 0 - 100 -100 - +100 [cent]
5 Fine B 0 - 100 -100 - +100 [cent]
6 Pre Delay A 0 - 500 0.0 - 500 [ms]
7 Pre Delay B 0 - 500 0.0 - 500 [ms]
8 Pan A 0 - 127 L64 - 63R
9 Pan B 0 - 127 L64 - 63R
10 Level Balance 0 - 100 A100:0B - A0:100B
11 Balance 0 - 100 D100:0W - D0:100W
12 Level 0 - 127 0 - 127
