ROLEC OCPP0410 User manual

Installation & Operation Manual
EVQROCM-01-V03-R0 January 2022
QUANTUM:EV
EV OPENCHARGE
Single and Three Phase
Socketed EV Chargers
(GPRS/Ethernet Communication)
INSTALLATION
& OPERATION
MANUAL
MODELS:
SINGLE PHASE
OCPP0410 1 X 3.6kW
OCPP0411 1 X 7.2kW
OCPP0420 2 X 3.6kW
OCPP0421 2 X 7.2kW
OCPP0425 4 X 7.2kW
3 PHASE
OCPP0412 1 X 11kW
OCPP0413 1 X 22kW
OCPP0422 2 X 11kW
OCPP0423 2 X 22kW

Product Support
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 1of 25 January 2022
Amendments
Amendment
Number Details Date
Ver 1, Rev 0 New Document. September
2020
Ver 2, Rev 0 Amended to include VendElectric details. December
2020
Ver 2, Rev 1
Amendment to Host and Installer Guides
Amendment to Specification Wording
Addition of Connector Type Label
April 2021
Ver 2, Rev 2 Correction to Compliances Table August
2021
Ver 3 Rev 0 Addition of 4-Way Charger
Addition of maintenance information
January
2022
Product: Quantum:EV OpenCharge
Applicable Models:
Single Phase Three Phase Superfast
OCPP0410 OCPP0412
OCPP0411 OCPP0413
OCPP0420 OCPP0422
OCPP0421 OCPP0423
OCPP0425
Document Type: Installation and Operation Manual
Document Code: EVQROCM-01-V03-R0
Language: UK English (Original)
Date Published: January 2022
Rolec Services Ltd are the publishers of this document and own the rights to use the text, images and all technical
content contained within. Content supplied by third parties / partner organisations remains the property of that
organisation and is used by agreement with the supplier.
Rolec Services Ltd exercise care to ensure content is as accurate as possible at the time of publication. However, no
guarantee of accuracy should be inferred.
Rolec Services Ltd, Ralphs Lane, Boston, Lincolnshire PE20 1QU. United Kingdom.
[phone]
[e-mail]

Product Support
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 1of 25 January 2022
Amendments
Amendment
Number Details Date
Ver 1, Rev 0 New Document. September
2020
Ver 2, Rev 0 Amended to include VendElectric details. December
2020
Ver 2, Rev 1
Amendment to Host and Installer Guides
Amendment to Specification Wording
Addition of Connector Type Label
April 2021
Ver 2, Rev 2 Correction to Compliances Table August
2021
Ver 3 Rev 0 Addition of 4-Way Charger
Addition of maintenance information
January
2022
Product: Quantum:EV OpenCharge
Applicable Models:
Single Phase Three Phase Superfast
OCPP0410 OCPP0412
OCPP0411 OCPP0413
OCPP0420 OCPP0422
OCPP0421 OCPP0423
OCPP0425
Document Type: Installation and Operation Manual
Document Code: EVQROCM-01-V03-R0
Language: UK English (Original)
Date Published: January 2022
Rolec Services Ltd are the publishers of this document and own the rights to use the text, images and all technical
content contained within. Content supplied by third parties / partner organisations remains the property of that
organisation and is used by agreement with the supplier.
Rolec Services Ltd exercise care to ensure content is as accurate as possible at the time of publication. However, no
guarantee of accuracy should be inferred.
Rolec Services Ltd, Ralphs Lane, Boston, Lincolnshire PE20 1QU. United Kingdom.
[phone]
[e-mail]
Product Support
EVQROCM-01-V03-R0 Installation and Operation Manual Quantum:EV OpenCharge
January 2022 Page 2of 25
Contents
Product Support 2
Safety 3
Safety Advice within this Manual 3
Product Overview 4
Product Features 4
Product Specification 5
Physical Specification 5
Electrical Specification 6
Certifications and Compliances 7
Options and Accessories 7
Unpacking 7
Typical Contents 7
Labelling 8
Information Labels 8
Installation 9
Schematics 10
Before Installation 15
Installation Procedure 15
Base Installation – If Supplied: 15
If a Base is Not Supplied: 15
Install the Pedestal 16
Commissioning 18
Commissioning with VendElectric 18
LED Illumination 18
After Installation 18
Operation 19
VendElectric EV Driver Application 19
Status Indicator Guide 19
To End a Charging Session 20
Charging Cables and Sockets 20
Maintenance 21
External Cleaning and Inspection 21
Suggested Inspection and Testing 22
VendElectric Host’s Guide 23
VendElectric Installer’s Guide 24
Installers Notes 25
Product Support
xPlease go to www.rolecserv.com and refer to the product support area.
xFor installation assistance and advice, contact your preferred electrical
installer.

Safety
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 3of 25 January 2022
Safety
This manual is specifically applicable to the Quantum:EV OpenCharge electric vehicle
charging product and is provided as a guide to its installation and operation.
IMPORTANT: Installers and End Users must read and understand the content
of this manual before installation and/or use of the product.
Installation must only be performed by someone who is properly qualified and
competent to do so in accordance with the current legislation applicable in the
geographical region of the installation.
xRolec Services Ltd cannot accept any responsibility for improper installation or any
problems arising from improper installation.
NOTE: Damage to the equipment, connected systems or to property caused by
improper installation are the responsibility of the installer.
xThe information provided in this manual must ONLY be used with the model(s) listed on
page 1 of this manual.
xThe information provided in this manual must NOT be used with any other product.
xThe content of this manual may be updated by the manufacturer as required.
xDo NOT use the equipment for anything other than its intended purpose.
xDo NOT modify the equipment unless specifically instructed to do so by the
manufacturer.
xDo NOT attempt to repair the equipment unless specifically instructed to do so by the
manufacturer.
xTo maintain electrical safety, the body enclosure of the product (access covers) must
be secured in their correct location using the supplied fasteners and the seal must be
sufficient to maintain the IP rating of the enclosure.
xFasteners used to mount the product in its working location must be sufficient for the
task and the specific mounting point.
xIf required, fasteners used to mount the product in its working location should be
sealed to maintain the IP rating of the enclosure.
xDamage to the product may render it unsafe. The product must be electrically
isolated and NOT used until appropriate remedial action has been performed.
Safety Advice within this Manual
Rolec manuals use a system of warnings, cautions and notes.
xWARNINGS concern the safety of installers/end user and will be given before the
detail/instructions in the manual.
xCAUTIONS concern the potential for damage to the equipment and will be given
before the detail/instructions in the manual.
xNOTES are given to provide additional information and/or to highlight information of
importance. They will be given either before or after the detail/instructions as
appropriate and may use different wording (such as IMPORTANT) where emphasis is
required.
Warnings, Cautions and Notes may be repeated several times as appropriate and may
be preceded by a hazard symbol where appropriate.

Product Overview
EVQROCM-01-V03-R0 Installation and Operation Manual Quantum:EV OpenCharge
January 2022 Page 4of 25
Product Overview
The Quantum:EV OpenCharge is an OCPP compliant, smart charging unit which has been
designed to provide the Host with full visibility and control of its use and, for the driver, a
simple to use EV charging solution activated via an RFID card/fob or an online web or
phone application which allows control of the unit and views of their charging activity.
The Quantum:EV OpenCharge is available with the following power options:
Model Number Specification
OCPP0410 Quantum:EV OpenCharge OCPP - 1x 3.6kW (16A) Type 2 socket
OCPP0411 Quantum:EV OpenCharge OCPP - 1x 7.2kW (32A) Type 2 socket
OCPP0420 Quantum:EV OpenCharge OCPP - 2x 3.6kW (16A) Type 2 sockets
OCPP0421 Quantum:EV OpenCharge OCPP - 2x 7.2kW (32A) Type 2 sockets
OCPP0425 Quantum:EV OpenCharge OCPP - 4x 7.2kW (32A) Type 2 sockets
OCPP0412 Quantum:EV OpenCharge OCPP - 1x 11kW (16A) Type 2 socket
OCPP0413 Quantum:EV OpenCharge OCPP - 1x 22kW (32A) Type 2 socket
OCPP0422 Quantum:EV OpenCharge OCPP - 2x 11kW (16A) Type 2 sockets
OCPP0423 Quantum:EV OpenCharge OCPP - 2x 22kW (32A) Type 2 sockets
Refer to the Product Specification on page 5 for further details.
Product Features
xMode 3 (IEC 61851-1) charging
xType 2 (IEC 62196) charging socket(s) c/w
security hatchlock(s)
xBuilt-in RFID reader(s)
xPhotocell controlled LED amenity lighting
head
xSurface or root mountable
xBuilt-in AC overload protection (MCB)
xBuilt-in AC & DC fault protection (RCD)
xBuilt-in LED charging status indicator socket
halo(s)
xBuilt-in class 1 MID compliant kWh meter(s)
xIP Rated, UV stabilised, fire retardant, IK10
impact & corrosion resistant
xOCPP 1.6 compliant (Can integrate with
any back office)
xRemote firmware updates
xEV driver Pay-to-Charge smartphone
integration
xSmart charging control via mobile phone
and/or RFID
xCan integrate with any chosen OCPP
back office management system
xOn board GPRS modem with antenna
xEthernet connection

Product Specification
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 5of 25 January 2022
Product Specification
Physical Specification
Dimensions 1440 x 375 x 275mm (HxWxD)
Materials xChassis – 2.5mmH[WUXGHGDOXPLQLXPZLWKǍP
anodised finish
xPanels – 3.2mm Aluminium composite
xLED lens – Impact resistant 3mm Polycarbonate
xBase – Impact resistant, 5mm Polycarbonate
Mass < 32 kg
Operating Temperature -30°C to +50°C
Operating Humidity Range 5% to 95%
Figure 1 General Arrangement and Dimensions
NOTE: Depending on the model, a GPRS antenna(s) is mounted either above the socket(s)
on the side of the pedestal, or on the back panel of the pedestal.
3 6 0mm 2 6 0m m
12 5 0m m
1440mm
375mm 275mm
LED
Illumination
Charging
Socket(s)
Up to 2
each side
LED ‘Halo’
Status
Indicator
User
Instructions
Light Sensor
RFID Sensor
1 each side
on
OCPP0425
QR Code
Socket ID
Label

Product Specification
EVQROCM-01-V03-R0 Installation and Operation Manual Quantum:EV OpenCharge
January 2022 Page 6of 25
Electrical Specification
Product Code OCPP0410 OCPP0411 OCPP0420 OCPP0421 OCPP0425
C
C
h
h
a
a
r
r
g
g
i
i
n
n
g
g
S
S
o
o
c
c
k
k
e
e
t
t
(
(
s
s
)
)
1x Type 2
(IEC 62196)
2x Type 2
(IEC 62196)
4x Type 2
(IEC 62196)
AC Charging Output 1 x 3.6kW
(16A)
1 x 7.2kW
(32A)
2 x 3.6kW
(16A)
2 x 7.2kW
(32A)
4 x 7.2kW
(32A)
Charge Protocol Mode 3
AC Overload Protection 1x C20A MCB 1x C40A MCB 2x C20A MCBs 2x C40A MCBs 4x C40A MCBs
A
A
C
C
&
&
D
D
C
C
F
F
a
a
u
u
l
l
t
t
P
P
r
r
o
o
t
t
e
e
c
c
t
t
i
i
o
o
n
n
1x Type B RCD 2x Type B RCDs 4x Type B RCDs
Input Supply
1x 16A 230V
AC/50Hz
(Single Phase)
1x 32A 230V
AC/50Hz
(Single Phase)
1x 32A 230V
AC/50Hz
(Single Phase)
1x 63A 230V
AC/50Hz
(Single Phase)
2x 63A 230V
AC/50Hz
(Single Phase)
Cable Terminals 3x 50 mm (2x) 3x 50 mm*
Communications
GPRS (Recommended signal strength of 14 CSQ or better), or
RJ45 ethernet connection
2x RJ45
ethernet
connections
Operating Temperature -30°C to +50°C
*Alternative cable terminal options available upon request
Product Code OCPP0412 OCPP0410 OCPP0422 OCPP0423
C
C
h
h
a
a
r
r
g
g
i
i
n
n
g
g
S
S
o
o
c
c
k
k
e
e
t
t
(
(
s
s
)
)
1x Type 2 (IEC 62196) 2x Type 2 (IEC 62196)
AC Charging Output 1 x 11kW
(16A)
1 x 22kW
(32A)
2 x 11kW
(16A)
2 x 22kW
(32A)
Charge Protocol Mode 3
AC Overload Protection 1x C20A MCB 1x C40A MCB 2x C20A MCBs 2x C40A MCBs
AC & DC Fault Protection 1x Type B RCD 2x Type B RCDs
Input Supply 1x 16A 400VAC
50Hz (3 Phase)
1x 32A 400VAC
50Hz (3 Phase)
1x 32A 400VAC
50Hz (3 Phase)
1x 63A 400VAC
50Hz (3 Phase)
Cable Terminals 5x 50 mm
Communications GPRS (Recommended signal strength of 14 CSQ or better)
RJ45 ethernet connection
Operating Temperature -30°C to +50°C

Options and Accessories
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 7of 25 January 2022
Certifications and Compliances
This product has been designed and built in accordance with the following standards and legislation:
OCPP Version 1.6 J.
Charging Compliance EN 61851-1:2011,
Wiring Regulations BS 7671.
EMC Compliance EN 301 489-01 V2.2.0,
EN 301 489-03 V2.1.1, EN 301 489-52 V1.1.0,
EN 50470-1:2006 (1x Skt) or EN 55032:2012 (2x & 4x Skts),
(2014/30/EU).
Safety Compliance (LVD) 2014/35/EU.
Product Safety EN 62368-1:2014.
Radio Equipment Directive
Spectrum/ Telecom (Art. 3(2)):
EN 301 511 V9.0.2, EN 300 330 v2.1.1,
EN 62311:2008,
2014/53/EU.
Environmental Protection BS EN 60529:1992+A2:2013,
xEnclosure IP66,
xSocket IP54.
BS EN62262:2008,
xEnclosure IK10 impact rating.
Plug(s)/Socket(s) BS EN 62196-1:2014, BS EN 62196-2:2017.
Fire Rating UL94 Flame Rating at V2 for 1.5 mm and 3.0 mm.
RoHS / REACH 1907/2006,
2011/65/EU,
Options and Accessories
xRFID card/fobs
xLoad Manager system (electrical
distribution management)
xCorporate branding (colours, logo badge,
etc.)
xGalvanised steel ground mounting base
xProtection barriers
xCharge point signage
xEV charging cables (Type 1 to Type 2 or
Type 2 to Type 2)
Unpacking
The content of the package depends on the model ordered and any options or
accessories.
IMPORTANT: Make sure all packaging is disposed of responsibly and in accordance with
the current regulations in your region.
Typical Contents
xEV Charger
xRubber Splash Mat
xInstallation and Operators Manual +
VendElectric instructions

Labelling
EVQROCM-01-V03-R0 Installation and Operation Manual Quantum:EV OpenCharge
January 2022 Page 8of 25
Labelling
Installers must observe any/all warning labels displayed on the equipment or inside the
equipment enclosure.
Labels may be in the form of adhesive ‘stickers’, plates, and/or moulded into the surface
of components.
Information Labels
Figure 2 Typical Product /
Rating Labels
Figure 3 Typical Fascia Label
Figure 4 RFID and Socket
Selection Label
(4-Way Only)
Figure 5 Socket QR Code Label Example Figure 6 Electricity Warning Label (as appropriate)
Figure 7 Power Rating Label (as appropriate)
NOTES:
xBranding on labels may be different to that shown above.

Installation
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 9of 25 January 2022
Installation
IMPORTANT: Installers and End Users must read and understand the content
of this manual before installation and/or use of the product.
Installation must only be performed by someone who is properly qualified and
competent to do so in accordance with the current legislation in force in the
geographical location of the installation.
xAdvice provided in this manual does NOT override any legislation.
xRolec Services Ltd cannot accept any responsibility for improper installation or any
problems arising from improper installation.
NOTE: Damage to the equipment, connected systems or to property caused by
improper installation are the responsibility of the installer.

Installation
EVQROCM-01-V03-R0 Installation and Operation Manual Quantum:EV OpenCharge
January 2022 Page 10 of 25
Schematics
Applicable to Single Phase, Single Socket Models:
xOCPP0410
xOCPP0411
Figure 8 Single Phase Single Socket Quantum:EV OpenCharge – Schematic
ACEQ0040
C6
2N
N1
N N
T
A2
A1
14
11
12
WHITE
J602 X1
X603
X601
X602
X600
1
7
6
24513
46
WH ITE
1
2
3
14
11
25-
ACEQ0040
C6
2N
N1
N N
T
LN
SW/L
PHOTOCELL
E
CP PP
N
L3 L2
L1
3 2
1
0V
3 2
1
1
7
6
2
LNE
LIVE 1
NEUTRAL
EARTH
INCOMING SUPPLY
10.8-13.8VMax.2A Max.24Watt
OUTPUT: 12V-2A
+V
N
INPUT: 100-240VAC
0.88A 50/60Hz
L
-V
4
2T1 4 T2 6 T3 14 NO
A2
1 L1 3 L2 5 L3 13 NO
A2A1
SNUBBER
ACEN0095
C20
1
2
O-OFF
ACEO0200
63A I n 0.03A
230V/240V~
N1 N2
T
Test Regularly
50/60Hz
Im= I m= 1000A
Inc=I c= 10000A IEC/EN 61008-1 IEC/EN 62423
-25
~
4
kWh
B
NN
2425 23 23+
24 G
SDA SCL M OSI MISO IQR GND RS T 3.3V
BROWN
GREEN
YELLOW
GREY
PINK
BLUE
REDSDA - 8 PIN 4
SCK - 7 PIN 3
PIN 2MOSI - 6
MISO - 5 PIN 1
IQR - 4 PIN 8
GND - 3 PIN 7
RST - 2 PIN 6
3.3V - 1 PIN 5
A1
A2
10x 1W LED LIGHTS (WHITE)
AC-L (Brown) DCV+ (Red)
AC-N(BLUE) DCV- (Rlack)
LED Driver
Model:LD010H-CU03536-51
Input:100-240Vac ~ 0.25A 50/60Hz
Output:25-36Vdc 350mA
Watt:12.6W Max.
ta=60°C tc=90°C
ConstantCurrent Class 2 PowerSupply
IP67
WHITE CABLE
LED DRIVER
EARTH IN ACCORDANCE WITH CURRENT REGULATIONS

Installation
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 11 of 25 January 2022
Applicable to Single Phase, Double Socket Models:
xOCPP0420
xOCPP0421
Figure 9 Single Phase Double Socket Quantum:EV OpenCharge – Schematic
ACEQ0040
C6
2N
N1
N N
TACEN0095
6000
C20
230V~
IEC60898-1 EN60898-1
I
O
1
2
ACEN0095
6000
C20
230V~
IEC60898-1 EN60898-1
I
O
1
2
16 15 13
NE
CP PP
L1
L2L3
12 24
11 23
10 22
9
21
8
20
7
19
6
18
5
17
4231
14
Relais Control
(1)(2)
Socket Control (2) Socket Control (1)
Cardreader(1) Cardreader(2)
12 24
1
13
np-+
rs485 / power
SIM
GPRS
LAN
status
GREENFLUX SMART
CHARGING CONTROLLER
(FRONT VIEW)
A2
A1 14
11
12
3
GREENFLUX SMART
CHARGING CONTROLLER
(RHS VIEW)
GREENFLUX SMART CHARGING
CONTROLLER (LHS VIEW)
2
1
10.8-13.8VMax.2AMax.24Watt
OUTPUT: 12V-2A
E
CP PP
N
L3 L2
L1
+V
N
INPUT: 100-240VAC 0.88A 50/60Hz
A1
L
-V
11
A2
12 14
3 2
1
SOCKET 1 SOCKET 2
12V0V
4
WHITE CABLE
4
12
11
10 10
9 8 7 6 5 2
1
ACEO0200
63AI n 0 .03A
230V/240V~
N1 N2
T
TestRegularly
50/60Hz
Im= I m = 1000A Inc= I c = 10000A
IEC/EN61008-1 IEC/EN62423
-25
~
kWh
1000
imp/kWh
230V0.25- 5(100)A
B
NN
2425 23
2T1 4 T2 6 T3 14 N O
A2
1 L1 3 L2 5 L3 13 NO
A2A1
SNUBBER
ACEO0200
63AI n 0.03A
230V/240V~
N1 N2
T
TestRegularly
50/60Hz
Im= I m = 1000A Inc= I c = 10000A IEC/EN61008-1 IEC/EN62423
-25
~
kWh
1000
imp/kWh
230V0.25- 5(100)A
B
NN
2425 23
2T1 4 T2 6 T3 14 N O
A2
1 L1 3 L2 5 L3 13 NO
A2A1
SNUBBER
WHITE CABLE
LNE
LIVE
NEUTRAL
EARTH
INCOMING SUPPLY
23+
25-
24 G
24 G
23+
25-
SDA SCL MOSIMISOIQR GN D RST 3.3V
A1
A2
A1
A2
ACEQ0040
C6
2N
N1
N N
T
LN
SW/L
PHOTOCELL
10x 1W LED LIGHTS (WHITE)
AC-L(Brown) DCV+ (Red)
AC-N(BLUE) DCV-(Rlack)
LED Driver
Model:LD010H-CU03536-51
Input:100-240Vac~ 0.25A50/60Hz
Output:25-36Vdc350mA
Watt:12.6WMax.
ta=60°C tc=90°C
ConstantCurrent C lass 2 Power Supply
IP67
WHITE CABLE
EARTH IN ACCORDANCE WITH CURRENT REGULATIONS

Installation
EVQROCM-01-V03-R0 Installation and Operation Manual Quantum:EV OpenCharge
January 2022 Page 12 of 25
Applicable to Single Phase, Four Socket Model:
xOCPP0425
Figure 10 Single Phase Four Socket Quantum:EV OpenCharge – Schematic
EARTH IN ACCORDANCE WITH CURRENT REGULATIONS
NOTE: The 4x Socket Quantum is, effectively, two 2x socket Quantums in one pedestal enclosure. With the exception of the components highlighted above, which are only fitted to ONE of the circuits, both charging circuits are the same and have individual power input terminals and ethernet connections.
Attached to
one circuit only.

Installation
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 13 of 25 January 2022
Applicable to Three Phase Single Socket models:
xOCPP0412
xOCPP0413
Figure 11 Three Phase Single Socket Quantum:EV OpenCharge – Schematic
ACEQ0040
C6
2N
N1
N N
T
D20
400V
6000
IEC60898
ACEN0098
I
O
A2
A1 14
11
12
SNUBBER
10.8-13.8VMax.2A Max.24Watt
OUTPUT: 12V-2A
+V
N
INPUT: 100-240VAC
0.88A 50/60Hz
L
-V
AB
1000imp/kWh
DTS353F-2 EN50470-1/3
kWh
-25°C to 55°C
3X230/400V
0,25-5(80)A
50Hz
135 7
24 23 21 20
2468
ACEQ0040
C6
2N
N1
N N
T
LN
SW/L
PHOTOCELL ACEO0240
63A 30mA
400/415V 50/60/Hz
N1 3 5 N24 6
LIVE 1
LIVE 2
LIVE 3
NEUTRAL
EARTH
A1
A2
WHITE
J602 X1
X603
X601
X602
X600
1
7
6
245
13
46
WH ITE
1
2
3
E
CP PP
N
L3 L2
L1
3 2
1
0V
3
2
1
1
7
6
2
4
4
SDA SCL MOSIMISO IQR GND RST 3.3V
BROWN
GREEN
YELLOW
GREY
PINK
BLUE
REDSDA - 8 PIN 4
SCK - 7 PIN 3
PIN 2MOSI - 6
MISO - 5 PIN 1
IQR - 4 PIN 8
GND - 3 PIN 7
RST - 2 PIN 6
3.3V - 1 PIN 5
INCOMING SUPPLY
ACSE0320
A1
135
7(13)
246
8(14)
A2
A1 1 3 5 7(13)
426
8(14)
A2
240V~
Ie(AC-7a) Ue:400V
AC-7a AC-7b
IEC/EN 61095 IEC/EN 60947-4-1
20A
Ui:500V
16kW/3~400V
4kW/3~400V
10x 1W LED LIGHTS (WHITE)
AC-L (Brown) DCV+ (Red)
AC-N(BLUE) DCV- (Rlack)
LED Driver
Model:LD010H-CU03536-51
Input:100-240Vac ~ 0.25A 50/60Hz
Output:25-36Vdc 350mA
Watt:12.6W Max.
ta=60°C tc=90°C
Constant Curre nt Class2PowerSupply
IP67
WHITE CABLE
LED DRIVER
EARTH IN ACCORDANCE WITH CURRENT REGULATIONS

Installation
EVQROCM-01-V03-R0 Installation and Operation Manual Quantum:EV OpenCharge
January 2022 Page 14 of 25
Applicable to Three Phase, Double Socket models:
xOCPP0422
xOCPP0423
Figure 12 Three Phase Double Socket Quantum:EV OpenCharge – Schematic
D20
400V
6000
IEC60898
ACEN0098
I
O
D20
400V
6000
IEC60898
ACEN0098
I
O
16 15 13
NE
CP PP
L1
L2L3
12 24
11
23
10
22
9
21
8
20
7
19
6
18
5
17
4231
14
Relais Control
(1)(2)
Socket Control (2) Socket Control (1)
Cardreader(1)Card reader(2)
12 24
1
13
np-+
rs485 / power
SIM
GPRS
LAN
status
GREENFLUX SMART
CHARGING CONTROLLER
(FRONT VIEW )
A2
A1
14
11
12
LIVE 1
INCOMING SUPPLY
3
GREENFLUX SMART
CHARGING CONTROLLER
(RHS VIEW)
GREENFLUX SMART CHARGING
CONTROLLER (LHS VIEW)
2
1
SNUBBER
10.8-13.8VMax.2AMax.24Watt
OUTPUT: 12V-2A
E
CP PP
N
L3 L2
L1
+V
N
INPUT: 100-240VAC
0.88A 50/60Hz
A1
L
-V
11
A2 12 14
3
2 1
SNUBBER
SOCKET 1 SOCKET 2
AB
1000imp/kWh
DTS353F-2 EN50470-1/3
kWh
-25°Cto 55°C
3X230/400V
0,25-5(80)A
50Hz
1 35 7
24 23 21 20
2468
AB
1000imp/kWh
DTS353F-2 EN50470-1/3
kWh
-25°Cto 55°C
3X230/400V
0,25-5(80)A
50Hz
1 35 7
24 23 21 20
2468
12V0V
LIVE 2
LIVE 3
NEUTRAL
EARTH
ACEQ0040
C6
2N
N1
N N
T
4
4 - WHITE CABLE
4
ACEO0240 63A 30mA
400/415V 50/60/Hz
N13 5 N246
ACEO0240
63A 30mA
400/415V 50/60/Hz
N1 3 5
N24 6
12
11
10 10
9 8 7 6 5 2
1
SDASCL MOSIMISOIQR GN D RST 3.3V
A1
A2
ACSE0320
A1
135
7(13)
246
8(14)
A2
A1 1 35 7(13)
426
8(14)
A2
240V~
Ie(AC-7a) Ue:400V
AC-7a AC-7b
IEC/EN61095 IEC/EN60947-4-1
20A
Ui:500V
16kW/3~400V
4kW/3~400V
ACSE0320
A1
135
7(13)
246
8(14)
A2
A1 1 35 7(13)
426
8(14)
A2
240V~
Ie(AC-7a) Ue:400V
AC-7a AC-7b
IEC/EN61095 IEC/EN60947-4-1
20A
Ui:500V
16kW/3~400V
4kW/3~400V
A1
A2
ACEQ0040
C6
2N
N1
N N
T
LN
SW/L PHOTOCELL
10x 1W LED LIGHTS (WHITE)
AC-L(Brown ) DCV+ (Red)
AC-N(BLUE) DCV- (Rla ck)
LED Driver
Model:LD010H-CU03536-51
Input:100-240Vac~ 0.25A50/60Hz
Output:25-36Vdc350mA
Watt:12.6WMax.
ta=60°C tc=90°C
ConstantCurrent C lass 2 Power Su pply
IP67
WHITE CABLE
EARTH IN ACCORDANCE WITH CURRENT REGULATIONS

Installation
EVQROCM-01-V03-R0 Installation and Operation Manual Quantum:EV OpenCharge
January 2022 Page 16 of 25
Install the Pedestal
IMPORTANT: All electrical work must be performed in accordance with the current
Electrical Wiring Regulations applicable in the geographical region of the installation.
CAUTION: Equipment Damage
Do NOT use power tools to remove/install panel fixings.
Power tools can damage the fixings, making the panel difficult to remove.
Use hand tools ONLY and do not overtighten fasteners.
CAUTION: Equipment Damage
During the next steps the charger front panel will be removed. Take care to not
damage cables or components.
1. Remove and retain the fixings securing the front panel to the pedestal chassis.
2. Carefully ease the front panel away from the unit to gain access to the interior.
CAUTION: Equipment Damage
Fascia panels may be connected to the main assembly by electrical cables. Take
care not to damage, strain, or disconnect the cables. Make sure all connections are
secure before refitting the panel.
3. If required, cut ‘X’ shaped slits in the rubber splash mat to match the mounting
points of the base and to allow entry of the power and ethernet cable (if required).
4. Fit the mat over the cables and onto the ground mounting base or the securing
points if a base was not supplied.
5. Carefully lift the pedestal then lower the chassis over the cables and onto either:
xthe ground mounting base (align the four holes in the chassis with the four studs
of the base).
xthe prepared surface.
6. Route the cables to the appropriate length to be able to connect to the terminals
within the chassis.
7. Secure the chassis to the ground with the correct fixings for the location.
8. Trim around the pedestal base to remove any excess rubber from the splash mat (if
required).
NOTE: All electrical work must be performed in accordance with the current
legislation applicable in the geographical region of the installation.
CAUTION; Equipment Damage – Sensitive Equipment
If you will be performing insulation resistance tests on the power supply cables, it is
advised to be done BEFORE connecting the cable to the charger. The high voltages
applied during the test may damage sensitive components if tested after the cable is
connected.
9. Terminate the supply cable in the appropriate manner and connect to the
pedestal in accordance with the appropriate schematic.
10. If required, connect the Ethernet cable to the Communications unit.
Installation
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 15 of 25 January 2022
Before Installation
IMPORTANT: Signal Strength
Units using GPRS to communicate with a cloud-based back office contain a roaming
SIM card which connects to the strongest signal available.
It is assumed that a suitable GPRS signal has already been verified by the end
user/installer prior to installation.
xUnits using GPRS require a suitable GPRS signal of 14 CSQ or better.
xRolec cannot be held responsible or accountable in the event a GPRS unit is
installed in a location without adequate network signal.
1. Establish a suitable site location for the unit that is both secure and environmentally
safe.
2. Make sure the location meets current legislation (if applicable).
3. Make sure the unit and any accessories have not been damaged in transit.
NOTE: Items damaged in transit must first be reported to the courier and then to the
supplier.
Where possible, photographic evidence of package and/or item damage should be
provided.
4. Make sure the unit model is correct and matches the order.
NOTE: Incorrect or damaged units must NOT be installed. Contact your supplier to
discuss rectification.
Installation Procedure
If protective bollards or barriers will be used, consider installing them at the point of site
preparation.
Base Installation – If Supplied:
1. Prepare the ground and set the ground mounting base in the desired location.
xMake sure the power supply cable and ethernet cable (if required) is fed
upward through the middle of the base.
2. Concrete the base into place and allow time for it to set.
xThe lip of the base should be 2 – 3 mm above the surrounding ground level.
If a Base is Not Supplied:
1. Prepare a suitable area of firm, flat ground.
xIt must be possible to secure the charger to the ground with bolts or similar
fixings that are appropriate to the type of prepared ground.
xTypically, into concrete, M8 x 100 mm Anchor Bolts should be used but installers
must assess the site and choose the most appropriate fixing for their needs.
xMake sure the power supply cable and ethernet cable (if required) is fed
upward through the middle of the pedestal mounting location.

Installation
EVQROCM-01-V03-R0 Installation and Operation Manual Quantum:EV OpenCharge
January 2022 Page 16 of 25
Install the Pedestal
IMPORTANT: All electrical work must be performed in accordance with the current
Electrical Wiring Regulations applicable in the geographical region of the installation.
CAUTION: Equipment Damage
Do NOT use power tools to remove/install panel fixings.
Power tools can damage the fixings, making the panel difficult to remove.
Use hand tools ONLY and do not overtighten fasteners.
CAUTION: Equipment Damage
During the next steps the charger front panel will be removed. Take care to not
damage cables or components.
1. Remove and retain the fixings securing the front panel to the pedestal chassis.
2. Carefully ease the front panel away from the unit to gain access to the interior.
CAUTION: Equipment Damage
Fascia panels may be connected to the main assembly by electrical cables. Take
care not to damage, strain, or disconnect the cables. Make sure all connections are
secure before refitting the panel.
3. If required, cut ‘X’ shaped slits in the rubber splash mat to match the mounting
points of the base and to allow entry of the power and ethernet cable (if required).
4. Fit the mat over the cables and onto the ground mounting base or the securing
points if a base was not supplied.
5. Carefully lift the pedestal then lower the chassis over the cables and onto either:
xthe ground mounting base (align the four holes in the chassis with the four studs
of the base).
xthe prepared surface.
6. Route the cables to the appropriate length to be able to connect to the terminals
within the chassis.
7. Secure the chassis to the ground with the correct fixings for the location.
8. Trim around the pedestal base to remove any excess rubber from the splash mat (if
required).
NOTE: All electrical work must be performed in accordance with the current
legislation applicable in the geographical region of the installation.
CAUTION; Equipment Damage – Sensitive Equipment
If you will be performing insulation resistance tests on the power supply cables, it is
advised to be done BEFORE connecting the cable to the charger. The high voltages
applied during the test may damage sensitive components if tested after the cable is
connected.
9. Terminate the supply cable in the appropriate manner and connect to the
pedestal in accordance with the appropriate schematic.
10. If required, connect the Ethernet cable to the Communications unit.

Installation
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 17 of 25 January 2022
11. Make sure all cable connections are secure and have not become loose or
damaged in transit or during installation.
12. Make sure ALL debris is removed from the front and rear halves of the enclosure
and that no debris is present on any of the components.
NOTE: Debris and similar pollutants can adversely affect the performance and
working life expectancy of components and will invalidate the product/component
warranty.
IMPORTANT NOTE:
It is the responsibility of the installing engineer to satisfy themselves, that all cable
terminations throughout this product are secure and tight and have not become
loose, strained, or disconnected during transit and/or installation.
13. Switch ON the power to the unit and test in accordance with the current legislation
applicable in the geographical region of the installation.
xMake sure this product has been installed in compliance with the current
Electrical Wiring Regulations (including recommended earthing arrangements).
14. Make sure you are satisfied that the installation is complete and is in a safe
condition.
CAUTION: Equipment Damage
Do NOT use power tools to remove/install panel fixings.
Use hand tools ONLY and do not overtighten fasteners.
15. Refit the front Fascia panel, taking care not to trap any electrical cables. Secure
the panel with the fixings removed earlier in the procedure.
xMake sure the rubber washer on the fixing is in
good condition and is correctly placed between
the fascia and the washer.
xSlight compression of the rubber washer helps to
maintain the water resistance of the pedestal.
xDo NOT over tighten the fixings.
Rubber
Steel
r

Commissioning
EVQROCM-01-V03-R0 Installation and Operation Manual Quantum:EV OpenCharge
January 2022 Page 18 of 25
Commissioning
If the VendElectric service is NOT being used, another service provider will be required to
administer smart services and commissioning will need to be performed in accordance
with the alternative service provider’s instructions.
Commissioning with VendElectric
NOTE: A Smartphone or similar web enabled device with a working internet connection
is required for the next steps.
1. All preliminary tasks listed in the Host’s Guide (shown at the end of this manual) must
have been performed by the customer (Host) before commissioning can proceed.
2. To complete commissioning, refer to the Installer’s Guide (shown at the end of this
manual).
3. Once commissioning is complete, the Host will receive an invitation from
VendElectric to set up their Back Office.
4. Engage with the customer to install the VendElectric application to their
smartphone or similar device from either the App Store for Apple devices or from
Google Play for Android devices.
xThe application is also accessible on almost any device with a web browser.
https://app.vendelectric.com
LED Illumination
The pedestal incorporates an amenity LED illumination lamp which activates in response
to changing light levels.
1. Cover the light sensor, located on the side of the pedestal, the lamp should
illuminate.
2. Uncover the light sensor and the lamp should switch OFF.
NOTE: To prevent flickering in frequently changing light conditions such as headlights or
shade from passing vehicles, the lamp has a built-in delay before it switches on / off.
After Installation
Make sure this manual is given to the Host.

Operation
Quantum:EV OpenCharge EVQROCM-01-V03-R0 Installation and Operation Manual
Page 19 of 25 January 2022
Operation
NOTE: At the end of a charging session, always disconnect the cable from the vehicle
before disconnecting from the charger.
Operating instructions for this charger are shown on the unit fascia. For more detail, refer
to the EV Driver App User Guide included within the charger packaging.
VendElectric EV Driver Application
The VendElectric EV Driver Application is a free download for use with smartphones
running Google Android or Apple IOS. The application may be downloaded from Google
Play or the Apple App Store.
Alternatively, the application can be used via a web browser.
xhttps://app.vendelectric.com
For operation of the system using the online application, please refer to the EV Driver App
User Guide included within the charger packaging.
Status Indicator Guide
Flashing blue light Socket Available.
Flashing green light Socket Available for ‘Plug and Go’ charging
(optional feature to be activated by the Host).
Fixed blue light Cable plugged in but not charging.
Fixed green light Charge in progress.
Fixed red light Potential earth leak fault detected by the 6mA DC device.
Flashing red light Potential Communications Fault.
No light No power to the unit or the breaker within the unit has
tripped and needs to be reset.
1. Make sure the status indicator shows that the unit is ready to charge.
2. Connect the charging cable to the charger.
3. Connect the other end of the cable to the vehicle
4. Use the mobile application to start the charge session.
5. Alternatively use an RFID card/fob to start the charge session.
xThe charger will issue a ‘beep’ sound to indicate the card has been recognised
and accepted.
6. Make sure the status indicator changes to a fixed green light.
