roost&root 34721 User manual

Assembly
RVG Wildlife Covers
V1- Model 4 | Feb 2020
Copyright ® Endure Product, LLC... all rights reserved.
Cover Sheet
Feb 2020
V1-6
Copyright ® Endure Products, LLC... all rights reserved. This document is provided to you for your own personal limited use as a paying customer to assemble your product.
We consider these instructions company intellectual property and are granting you limited personal use only. Do not copy or distribute without written permission of Endure
Products, LLC. We claim all available Federal protection for our various trade names, our protected designs and trade dress as is allowed by any and all Federal intellectual
property protection laws. We invest heavily in your product and work very hard to do a good job and it is only fair that our workers benefit for their hard work.
SKU 34721
4x4 Wildlife Cover
SKU 32421
2x4 Wildlife Cover
SKU 32422
2x8 Wildlife Cover
SKU 34722
4x4 Wildlife Cover
Assembly Instructions
Raised Vegetable Gardens
Wildlife Covers
Help Text-line: 512-596-5200
EMAIL: [e-mail] re: RFB Assembly Support
VOICE: 877-741-COOP | Assembly Support ext 3
These written instructions, as
provided with your purchase, will
always be the latest iteration of the
instructions and match the product
shipped and provide the most
complete up-to-date information.
Note: Wildlife Covers are an
optional add-on product to a
Raised Vegetable Garden base...
which are sold seperately.
These instruction cover these models...

Assembly
RVG Wildlife Covers
V1- Model 4 | Feb 2020
Copyright ® Endure Product, LLC... all rights reserved.
Need to Know
+
+
Your Drill
Provided
Bit Holder
Provided
T-25 Bit
Provided T-25 3"
Ceramic Coated Wood Screws
+
Green arrows indicate
the placement of a brown
screw in the indicated
direction. Use of the provided
pilot bit is recommended
to make a pre-drilled hole.
Provided Exterior Grade
Hinge & Hasp Screws
Look For This
Note Symbol
Brown 3D imaged screws
are also used to indicate
a screw in a pre-drilled
hole...
+
Provided
Pre-Drill Bit
Provided
#2 Phillips Bit
Provided Safety Hasps
Provided Latching
Clips
Provided Hinges
And Screws
Before You Get Started...
Make all edges
flush during
assembly unless
otherwise noted.
Pan head screws are provided
if you ordered a tall cover.

Assembly
RVG Wildlife Covers
V1- Model 4 | Feb 2020
Copyright ® Endure Product, LLC... all rights reserved.
24" Single Section Standard
Height Wildlife Cover
Already Assembled RVG Base
(Sold Seperately)
Attach Assembled
Cover Using Brown
Screws making All
Edges Flush
Attach 2 hinges as shown
using Phillips screws in
pre-drilled holes.
Attach ends (with pre-drilled holes)
to sides as illustrated, using brown
T-25 Screws. Ends are same.
Wire side
facing inward
on all panels.
Top screws into
pre-drilled holes.
You will position bottom receiver
to where it works smoothly
with top hasp and attach using
provided screws. Use provided
spring clip or your padlock to secure.
Hinges On Back
Locking Hasps
On Front
Provided T-25 3"
Ceramic Coated Wood Screws
1
2
3
4

Assembly
RVG Wildlife Covers
V1- Model 4 | Feb 2020
Copyright ® Endure Product, LLC... all rights reserved.
24" Double Section Standard
Height Wildlife Cover
Attach Assembled
Cover Using Brown
Screws Making
All Edges Flush
Attach 4 hinges as shown
using Phillips screws in
pre-drilled holes.
Top screws into
pre-drilled holes.
You will position bottom receiver
to where it works smoothly
with top hasp and attach using
provided screws. Use provided
spring clip or your padlock to secure.
Provided T-25 3"
Ceramic Coated Wood Screws
Already Assembled
2 Section RVG Base
(Sold Seperately)
Attach ends (with pre-drilled holes)
to sides as illustrated, using brown
T-25 Screws. Ends are same.
Wire side
facing inward
on all panels.
Hinges On Back
Locking Hasps
On Front
1/16 Thick Black
Plastic Spacer
Between Side Panels
With Brown Screws
1
2
3
4
5

Assembly
RVG Wildlife Covers
V1- Model 4 | Feb 2020
Copyright ® Endure Product, LLC... all rights reserved.
47" Single Section Standard
Height Wildlife Cover
Attach Assembled
Cover Using Brown
Screws Making
All Edges Flush
Top screws into
pre-drilled holes.
You will position bottom receiver
to where it works smoothly
with top hasp and attach using
provided screws. Use provided
spring clip or your padlock to secure.
Provided T-25 3"
Ceramic Coated Wood Screws
Already Assembled RVG Base
(Sold Seperately)
Attach ends
(using pre-
drilled holes)
to sides as
illustrated
using brown
T-25 Screws.
Ends are
same.
Wire side
facing inward
on all panels.
Hinges On Top
Locking Hasps
On Outsides
Attach 4 hinges as shown
using Phillips screws in
pre-drilled holes.
Attach middle hinge
support board
as shown.
1
2
3
4
5

Assembly
RVG Wildlife Covers
V1- Model 4 | Feb 2020
Copyright ® Endure Product, LLC... all rights reserved.
47" Double Section Standard
Height Wildlife Cover
Top screws into
pre-drilled holes.
You will position bottom receiver
to where it works smoothly
with top hasp and attach using
provided screws. Use provided
spring clip or your padlock to secure.
Provided T-25 3"
Ceramic Coated Wood Screws
Attach 4 hinges as shown
using Phillips screws in
pre-drilled holes.
Attach middle hinge
support board
as shown.
1
3
4
5
6
Attach Assembled
Cover Using Brown
Screws Making All
Edges Flush.
Already Assembled RVG Base
(Sold Seperately)
Attach ends
(using pre-
drilled holes)
to sides as
illustrated
using brown
T-25 Screws.
Ends are
same.
Wire side
facing inward
on all panels.
Hinges On Top
Locking Hasps
On Outsides
Attach middle hinge
support board
as shown.
1/16 Thick Black
Plastic Spacer
Between Side Panels
With Brown Screws
2

Assembly
RVG Wildlife Covers
V1- Model 4 | Feb 2020
Copyright ® Endure Product, LLC... all rights reserved.
24" Single Section Tall Height
Wildlife Cover
Attach ends to
front and back sides.
Provided T-25 3"
Ceramic Coated Wood Screws
-
Wire side
faces inward
on all panels.
Attach 2 back panels together
2
Attach cover
to base.
3
Attach top making all
edges and corners
flush. Back edge has
holes entire length.
4
5
Door hinge screws on jamb side are pre-installed.
Position door in opening and install door side
hinge screws...
1st - put 1 screw in top hinge and tighten.
2nd- put 1 screw in bottom hinge, tighten.
3rd - align door in frame
4th - install all other screws.
Install door latch in position
as indicated using pre-drilled holes
using provided pan head screws.
1
6

Assembly
RVG Wildlife Covers
V1- Model 4 | Feb 2020
Copyright ® Endure Product, LLC... all rights reserved.
47" Single Section Tall Height
Wildlife Cover
Provided T-25 3"
Ceramic Coated Wood Screws
5
Door hinge screws on jamb side are pre-installed.
Position door in opening and install door side
hinge screws...
1st - put 1 screw in top hinge and tighten.
2nd- put 1 screw in bottom hinge, tighten.
3rd - align door in frame
4th - install all other screws.
Install door latch in position
as indicated using pre-drilled holes
using provided pan head screws.
Wire side
faces inward
on all panels.
Attach cover
to base.
3
Attach ends to
front and back sides.
-
2
Attach top making all
edges and corners
flush. Back edge has
holes entire length.
4
1
Attach side panels
together
6
