ROSE DISPLAYS ANOFRAME WITH TOP AND BOTTOM WALL MOUNTS User manual

Parts
35 Congress Street, Salem MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
split rails
solid rail
Figure 2
Instructions For Hanging
Instruction Sheet
AnoFrame™
Figure 1
Figure 3
Figure 5
Figure 4
Step 1
Locate the two split rails and the solid rail that is the
same length as the split rails.
Insert corner brackets into side AnoFrame rails.
Insert two corner brackets into each end of the solid
side Ano rail. Insert one corner bracket into each
end of each split side Ano rail. Fig. 1 & Fig. 2
Note: Tension tabs on corner brackets face
towards outside of frame.
Step 2
Finish assembling frame by following sequence in
Fig. 3.
Step 3
Install 2 wall mounting hangers using a Phillips head
screwdriver. Make sure that the wall mounting
hangers are level. A plastic expansion anchor is
suggested for drywall installations.
Fig. 4
Step 4
Slide AnoFrame onto wall mounting hangers. Fig 5
Step 5
Install 2 bottom wall hangers. This secures
frame in place. Fig 6
Step 6
Insert poster. Fig 7
Note: The AnoFrame shown here is a round
profile. It is available in either square or round
profile. Assembly is the same for top and side load.
solid rail
solid rail
split rails
Figure 6 Figure 7
Incept-2.11.04
The AnoFrame is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSAnoFrame4Hangers
Wall Mounting
Hangers
06-6067
AnoFrame Rails
12AF-100 AnoFrame
Split Rails
Corner
Brackets
Bottom Wall
Hangers
06-6069
