Multi-Media Navigation System Installation Guide DS-VW0714 Rev A
Installation Guide
NOTICE OF INTENDED INSTALLATION AND USE E
THE ROSEN MULTI-MEDIA NAVIGATION SYSTEMS CONTAIN AN INTERNAL VIDEO PLAYER, WHICH IS
NOT INTENDED FOR VIEWING BY THE DRIVER. THE VIDEO PLAYER IS DISABLED WHEN THE
VEHICLE IS IN MOTION THROUGH A CONNECTION TO THE PARKING BRAKE. THE INSTALLER OF
THIS PRODUCT MUST INSURE THE VIDEO DISABLE CONNECTION IS WORKING PROPERLY PRIOR TO
DELIVERY OF THE VEHICLE. IMPROPER INSTALLATION COULD DISTRACT THE DRIVER OR
INTERFERE WITH SAFE OPERATION OF THE VEHICLE, WHICH COULD RESULT IN SERIOUS INJURY
OR DEATH, AND COULD ALSO VIOLATE STATE AND/OR FEDERAL LAW.
ROSEN ENTERTAINMENT SYSTEMS DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY OR
PROPERTY DAMAGE THAT MAY RESULT FROM ANY IMPROPER OR UNINTENDED INSTALLATION
AND/OR USE.
BEFORE YOU START THE INSTALLATION, READ THIS GUIDE!
Rosen Multi-Media systems are the easiest-to-install OEM Radio replacement systems available today.
However, we strongly recommend reading this guide before starting the installation!
For additional technical tips, please visit
www.Rosendealercentral.com
1 - Make sure you have the tools you will need
These common items are needed to complete this installation:
·Digital multi-meter (DMM) ·#2 Phillips screwdriver ·Panel removing tools
·1/4” drive sockets are often needed for dashboard and trim disassembly
·Torx or Allen-drive wrenches if they are used on any panels you will be removing
·A DVD or CD in good condition for testing the system
Standard installation parts you may need include wire, wire ties, wire crimp connectors or solder, electrical
insulating tape, and foam tape. Installation of aftermarket automotive electronics also often requires access to
special parts. It is a good idea to have a source for these common installation parts.
DS-VW0710 Volkswagen Series

Installation Guide VW Series
Rosen Entertainment Systems Copyright 2008 all rights reserved
Installation Guide DP-VW0714 Rev A
Page 2
2 - Inspect the vehicle and plan your work
CHECK THE BATTERY
Test the battery voltage to make sure it’s fully charged and inspect battery terminals for tightness and any corrosion. This
only takes seconds and can save hours of troubleshooting later.
3 – Turn the Vehicle OFF or Disconnect the Battery
TURN THE VEHICLE OFF BEFORE STARTING
Be sure to turn the vehicle OFF before starting, and keep the vehicle OFF until the installation is fully completed BEFORE
the vehicle is turned on.
Note: Failure to follow these instructions may cause the AIRBAG FAULT SENSOR to become enabled. Fault
Sensors which have been enabled will require the Dealer Service Department to reset them. Dealerships often
charge a significant fee to reset the Fault Sensor.
4 – Remove the Interior Trim Components
You will need to remove the interior trim components prior to removing the factory radio. The following steps will help
guide you through this process.
Note: When removing the Interior Trim Components, use caution to prevent damage to the components. If you are
unsure about the removal process, consult the OEM Service Manual for additional instructions.
Note: Once the Interior Trim Components have been removed, be sure to inspect the clips for any damage.
Damaged part must be replaced before re-installation.
Step 1: Remove the Upper
Trim Components
Step 2: Remove the Inner Trim
Components
Step 3: Remove the Vent Trim
Component
Step 4: Unplug the Electrical
Connection
New Vehicles RARELY have a fully charged battery. This can cause many system malfunctions.
Keep the Vehicle OFF while the Radio is disconnected to avoid a potential Airbag Sensor Fault
Use Caution. See the OEM Service Manual for additional information on the removal process

Installation Guide VW Series
Rosen Entertainment Systems Copyright 2008 all rights reserved
Installation Guide DP-VW0714 Rev A
Page 3
5 - Remove the Factory Radio
You will need to remove the Factory Radio and prepare the Rosen Multi-Media unit for installation. The following steps
will help guide you through this process.
Note: Be sure to inspect all brackets and clips to ensure they were not damaged during the removal process. If any
brackets or clips were damaged, replace them prior to installation of the Rosen unit.
Step 1: Remove the OEM Radio
Trim
Step 2: Remove Radio Mounting
Screws
Step 3: Remove Radio Mounting
Screws
Step 4: Remove OEM Radio from
Dash. Unplug Factory
Harness
6 – Locate the GPS Antenna, Optional XM Antenna and iPod Interface
You will need to mount the GPS and Optional XM Antennas on the exterior of the vehicle. And mount the iPod Interface
Connector in the vehicle. The following steps will help guide you through this process.
Note: Please route the GPS harness away from other power harnesses in the vehicle. This will help to ensure
optimum performance of the GPS system.
Note: Please locate the iPod interface module in an area which can be serviced in the future. The iPod cable is
intended to be a serviceable item, which plugs into the iPod/XM Interface Module.
Step 1: Mount the GPS and XM
antenna in a location on
the exterior of the Vehicle
Step 2: Connect the Optional XM
Tuner as shown below.
Mount the tuner inside the
vehicle
Step 3: Mount the iPod/XM
Interface module where it
can be serviced in the
future
Step 4: Locate the iPod interface
connector for use by the
end-consumer
It is the installer’s responsibility to ensure that the safety equipment in the vehicle is NOT
adversely affected by installation of this system. Ensure that the routing of the harnesses does
NOT obstruct airbags, SRS or other safety devices.
Use Caution. See the OEM Service Manual for additional information on the removal process

Installation Guide VW Series
Rosen Entertainment Systems Copyright 2008 all rights reserved
Installation Guide DP-VW0714 Rev A
Page 4
7 – Connect and Install the Rosen Unit
You will need to make the Electrical Connections and install the Rosen Unit. The following steps will help guide you
through this process.
Note: Connect BRAKE WIRE (blue w/ white) to Emergency brake switch wire (ground when E-brake is
engaged). This insures video is disabled while vehicle is in motion.
Note: Use caution when locating the wire harnesses to be sure they will not be damaged when the Rosen unit is
installed.
Note: For vehicles with Dual Diversity Antenna, connect the White Antenna lead only, and protect the second
antenna lead from damage. For improved Radio performance, use an aftermarket dual diversity antenna adaptor.
Step 1: Remove transport
screws
Step 2: Connect the GPS,
Steering Wheel Control
and Power Connections
Step 3: Connect the iPod and
optional XM, Camera and
Backing Sensors
Step 4: Prepare the Vehicle side
connection harnesses
8 – Re-Install Interior Trim Components
You will need to re-install the interior trim components. The following steps will help guide you through this process.
Note: When Installing the Interior Trim Components, use caution to prevent damage to the components. If you are
unsure about the removal process, consult the OEM Service Manual for additional instructions.
Step 1: Attach the Electrical,
Install Radio Trim, then
Upper Vent Trim
Step 2: Install the Inner/Upper Trim
Components
Step 3: Dash Trim Components
Installed
Step 4: Verify unit operation
Use Caution. See the OEM Service Manual for additional information on the installation process
Insure that the video disable connection is connected as intended and working as designed!!!
Be sure to fully engage all connectors and prevent them from causing vibrating noises

Installation Guide VW Series
Rosen Entertainment Systems Copyright 2008 all rights reserved
Installation Guide DP-VW0714 Rev A
Page 5
9 – Touch Screen Calibration and Installer Settings
The system was calibrated at the factory, however re-calibrate the system if the touch screen positions do not appear to
align with the buttons or icons.
Calibrate the Primary Touch Screen –
Note: There are TWO Calibrations for the Touch Screen in the Rosen unit. To Calibrate the Primary Touch Screen
Operation of the unit (Radio, DVD, BT etc) follow these steps:
Step 1: Select Main from any
Screen
Step 2: Select SETUP on the Main
Screen
Step 3: Select CONTROL SETUP
on the Setup Screen
Step 4: Select TOUCH SCREEN
and follow the on-
screen instructions
Navigation Touch Screen Calibration –
Note: The Navigation Calibration Screen is only available for a short time, after the vehicle is switched ON… To
access the Navigation Calibration Screen, Select NAV as soon as the System Self Test has Finished.
Step 1: Start the Rosen Unit, and
wait for the Self Test to
completed
Step 2: Select NAV after the Self
Test has completed
Step 3: Touch the Screen quickly,
before it “Times Out.” If
needed, repeat Step 1.
Step 4: Follow the On-Screen
instruction to adjust the
calibration.
Installer Settings Screen –
The Installer can enable and disable several option features of the Rosen Unit. To access the Installer Settings
screen, follow the steps below.
Step 1: Select Main from any
Screen
Step 2: Select the AUX Icon Step 3: Touch the UPPER RIGHT
CORNER of the Screen
Enter “7253” and “OK”
Step 4: Enable or Disable the
desired functions
Note: The following settings can be changed from this screen:
1. Enable the Power Antenna
2. Enable/Disable the Video Disable tied to the Parking Brake (Use for testing only)
3. Adjust the limit settings on the display backlight
4. Enable/Disable XM Radio Interface
5. Reset the Factory Settings
Touch the Screen to
Calibrate

Installation Guide VW Series
Rosen Entertainment Systems Copyright 2008 all rights reserved
Installation Guide DP-VW0714 Rev A
Page 6
10 – Pre-Delivery Test
You will need to fully test the system to ensure it is working and connected to the vehicle properly. The following steps will
guide you through this process.
Step 1: Initial Test
a. Reconnect the vehicle battery if needed
b. Start the vehicle (ensure that it is safe to do so)
c. Perform the following steps on the Multi-Media Systems to ensure proper operation:
•Turn the unit ON
•Select all available sources
oSelect the Radio and test several stations
oSelect the DVD and test playback of a disc
oSelect the iPod and test music playback
oSelect the XM tuner if equipped, and wait for XM Preview to start
•Test the Steering Wheel Controls
oIf the vehicle is equipped, test all steering wheel controls
•Test the Backup Sensors
oIf installed, test the sensors by placing a stationary object behind the vehicle (never test
the sensors by backing the vehicle into an object)
oRepeat this for each of the sensors
•Test the Navigation
oSelect the Navigation and wait for the satellites to be located
oConfirm the location reported is your current location
•Eject the test disc
•Turn the vehicle off and wait for the unit to turn off
d. If the system does not function properly, reset the system by pressing and holding the reset
button located near the eject button
Step 3: Pre-Delivery Preparation
a. Start the vehicle (ensure that it is safe to do so)
b. Perform the following steps
•Calibrate the Navigation Touch Screen, if not already performed
•Calibrate the Primary Touch Screen, if not already performed
•Retest the Radio and general audio performance of the system
•Remove the protective films and clean the unit as needed
c. Place the Owner’s Information package in the glove compartment
Service and Optional Parts List
Part Number Description Part Number Description
DP-VW0711 Quick Reference Guide DP-VW0712 Harness, Main Interconnect
DP-VW0714 Installation Guide DP-VW0713 Harness, Steering Wheel Ctrl.
DP-1001 Manual, Owner’s DP-1008 Harness, AUX Out
DP-1003 Manual, Navigation DP-1009 Harness, AUX IN
DP-1004 Remote Control DP-1010 Harness, Sensors/Camera
DP-1023 Pin, Stylus DP-1011 Harness, Dolby 5.1/Amp
DP-1020 Card, SD without maps DP-1013 Harness, iPod/Interface Box
DP-1022 Antenna, GPS DP-1014 Harness, XM Radio Interface
DP-1025 Tuner, XMD1000 Kit DP-1015 Harness, iPod Replacement
DP-1035 Camera, Cylinder W/Mount DP-1007 Harness, USB Adaptor
DP-1036 Camera, License Plate

Installation Guide VW Series
Rosen Entertainment Systems Copyright 2008 all rights reserved
Installation Guide DP-VW0714 Rev A
Page 7
Wiring diagram
