Quick Installation Guide
8 port Giga Switch RC-410X

Quick Installation Guide
8 port Giga Switch RC-410X
2
Thank you for purchasing RC-410X, a 8-port 10/100/1000 Gigabit desktop switch which is
suited for SOHO and enterprise users seeking pain-free, plug-and-play Ethernet connectivity.
The RC-410X delivers rich features, high performance, and extreme reliability in a cost-effective,
space-saving design. The plastic housing provides a light-weight and user-friendly touch
compared to metal casing, and the sleek and compact design of the RC-410X saves space
while serving thermal needs. This is a perfect solution for high-speed connectivity.
Step Label Description
1 LAN Ports (1 – 8) Use an Ethernet cable to connect each port to a computer on your
Local Area Network (LAN).
2 DC Connector Use the power cable and connect the adapter to the power socket
on the wall, and the DC inlet into the DC connector.
Connection LED This LED will light up once an Ethernet cable is connected to one
of the LAN ports or the WAN port.
Activity LED This LED will light up once an Ethernet cable is connected to one
of the LAN / WAN ports and the network is generating traffic.
Power LED This LED will light up once the power cable is connected to the DC
connector.
Thank you for purchasing a quality Rosewill Product.
Please register your product at : www.rosewill.com for complete warranty information and future support for your
product.
