Rotel RSP-1069 Installation manual

RSP 1069
RS232 Controller Command List
Table: RSP 1069 Waveform format expected:
Baud Rate Parity Valid Data Bits Stop Bit Value Handshaking Data Type
38400 N 8 1 None String
Table: RSP 1069 expected format of a request by RS 232 controller:
Start Count Device ID Type Key Checksum
0xFE 0x03 0xA2 0x10 0xXX 0xXX
Table 1: Type 10 Primary Command List
NOTE: The values in the table below show the exact byte sequence of all requests. The device
will expect the bytes only - no spaces, no delimiter, etc. The controlling device may implement its
own method to download each command sequence. The numerical values in the first column are
Hexadecimal.
RSP 1069 HEX Command Command Description
FE 03 A2 10 00 B5 RMC Vol+ Remote Volume Up
FE 03 A2 10 01 B6 RMC Vol- Remote Volume Down
FE 03 A2 10 02 B7 CD Source CD
FE 03 A2 10 03 B8 Tuner Source Tuner
FE 03 A2 10 04 B9 Tape Source Tape
FE 03 A2 10 05 BA Video 1 Source Video 1
FE 03 A2 10 06 BB Video 2 Source Video 2
FE 03 A2 10 07 BC Video 3 Source Video 3
FE 03 A2 10 08 BD Video 4 Source Video 4
FE 03 A2 10 09 BE Video 5 Source Video 5
FE 03 A2 10 0A BF Power Power Toggle
FE 03 A2 10 0B C0 Vol+ Volume Up
FE 03 A2 10 0C C1 Vol- Volume Down
FE 03 A2 10 0D C2 Treble+ Treble Up
FE 03 A2 10 0E C3 Treble- Treble Down
FE 03 A2 10 0F C4 Bass+ Bass Up
FE 03 A2 10 10 C5 Bass- Bass Down
FE 03 A2 10 11 C6 Stereo DSP Stereo
FE 03 A2 10 12 C7 3 Stereo DSP Dolby 3 Stereo
FE 03 A2 10 13 C8 Pro Logic DSP Pro Logic
FE 03 A2 10 14 C9 DSP DSP Music
FE 03 A2 10 15 CA Multi Multi Input
FE 03 A2 10 16 CB Dynamic Dynamic Range
FE 03 A2 10 17 CC Rec Record
FE 03 A2 10 18 CD OSD Menu OSD Menu
FE 03 A2 10 19 CE OSD Enter OSD Enter
FE 03 A2 10 1A CF OSD Right (+) OSD Right
FE 03 A2 10 1B D0 OSD Left (-) OSD Left
FE 03 A2 10 1C D1 OSD Up OSD Up

RSP 1069 HEX Command Command Description
FE 03 A2 10 1D D2 OSD Down / Dynamic OSD Down / Dynamic
FE 03 A2 10 1E D3 Mute Mute
FE 03 A2 10 1F D4 Digital In Select Digital Input Select
FE 03 A2 10 22 D7 Surround+ Next Surround Mode
FE 03 A2 10 23 D8 Zone 2 / Main Zone
FE 03 A2 10 4A FF Power Off Power Off
FE 03 A2 10 4B 00 Power On Power On
FE 03 A2 10 4C 01 C Center
FE 03 A2 10 4D 02 S Subwoofer
FE 03 A2 10 4E 03 R Surround
FE 03 A2 10 4F 04 Filter (EQ) Cinema EQ
FE 03 A2 10 52 07 FL On / Off FL Display Toggle
FE 03 A2 10 53 08 Pro Logic / 3 Stereo Dolby 3 Stereo
FE 03 A2 10 54 09 dts Neo:6 dts Neo:6
FE 03 A2 10 57 0C Music 1 Music 1
FE 03 A2 10 58 0D Music 2 Music 2
FE 03 A2 10 59 0E Music 3 Music 3
FE 03 A2 10 5A 0F Music 4 Music 4
FE 03 A2 10 5B 10 5Ch Stereo 5Ch Stereo
FE 03 A2 10 5C 11 7Ch Stereo 7Ch Stereo
FE 03 A2 10 5D 12 PLII Cinema PLII Cinema
FE 03 A2 10 5E 13 PLII Music PLII Music
FE 03 A2 10 5F 14 PLII Emulation PLII Emulation
FE 03 A2 10 60 15 dts Neo:6 Music dts Neo:6 Music
FE 03 A2 10 61 16 dts Neo:6 Cinema dts Neo:6 Cinema
FE 03 A2 10 62 17 PLII Panorama PLII Panorama
FE 03 A2 10 63 18 PLII Dimension Up PLII Dimension Up
FE 03 A2 10 64 19 PLII Dimension Down PLII Dimension Down
FE 03 A2 10 65 1A PLII Center Width Up PLII Center Width Up
FE 03 A2 10 66 1B PLII Center Width Down PLII Center Width Down
FE 03 A2 10 67 1C Shift (Treble Bass) Tone Controls
FE 03 A2 10 68 1D DD EX On/Off DD EX On/Off
FE 03 A2 10 6E 23 Party Mode Party Mode Toggle
FE 03 A2 10 71 26 All Zones Off Power Off All Zones
FE 03 A2 10 74 29 PLII Game Dolby PLII Game
FE 03 A2 10 75 2A Output Resolution Output Resolution
FE 03 A2 10 FF B4 Display Refresh Display Refresh
Table 2: Type 14 Main Zone Command List
NOTE: These commands are duplicate functions of the primary commands in the table above
bearing the same name.
RSP 1069 HEX Command Command Description
FE 03 A2 14 00 B9 RMC Vol+ Remote Volume Up
FE 03 A2 14 01 BA RMC Vol- Remote Volume Down
FE 03 A2 14 02 BB Main CD Main Zone Source CD
FE 03 A2 14 03 BC Main Tuner Main Zone Source Tuner

FE 03 A2 14 04 BD Main Tape Main Zone Source Tape
FE 03 A2 14 05 BE Main Video 1 Main Zone Source Video 1
FE 03 A2 14 06 BF Main Video 2 Main Zone Source Video 2
FE 03 A2 14 07 C0 Main Video 3 Main Zone Source Video 3
FE 03 A2 14 08 C1 Main Video 4 Main Zone Source Video 4
FE 03 A2 14 09 C2 Main Video 5 Main Zone Source Video 5
FE 03 A2 14 0A C3 Main Power Main Zone Power Toggle
FE 03 A2 14 1E D7 Main Mute Main Zone Mute
FE 03 A2 14 6C 25 Main Mute On Main Zone Mute On
FE 03 A2 14 6D 26 Main Mute Off Main Zone Mute Off
Table 3: Type 15 Record Source Command List
RSP 1069 HEX Command Command Description
FE 03 A2 15 02 BC Record CD Record Source CD
FE 03 A2 15 03 BD Record Tuner Record Source Tuner
FE 03 A2 15 04 BE Record Tape Record Source Tape
FE 03 A2 15 05 BF Record Video 1 Record Source Video 1
FE 03 A2 15 06 C0 Record Video 2 Record Source Video 2
FE 03 A2 15 07 C1 Record Video 3 Record Source Video 3
FE 03 A2 15 08 C2 Record Video 4 Record Source Video 4
FE 03 A2 15 09 C3 Record Video 5 Record Source Video 5
FE 03 A2 15 6B 25 Record Source Record Source
Table 4: Type 16 Zone 2 Command List
RSP 1069 HEX Command Command Description
FE 03 A2 16 00 BB Vol+ Zone 2 Volume Up
FE 03 A2 16 01 BC Vol- Zone 2 Volume Down
FE 03 A2 16 02 BD Zone 2 CD Zone 2 Source CD
FE 03 A2 16 03 BE Zone 2 Tuner Zone 2 Source Tuner
FE 03 A2 16 04 BF Zone 2 Tape Zone 2 Source Tape
FE 03 A2 16 05 C0 Zone 2 Video 1 Zone 2 Source Video 1
FE 03 A2 16 06 C1 Zone 2 Video 2 Zone 2 Source Video 2
FE 03 A2 16 07 C2 Zone 2 Video 3 Zone 2 Source Video 3
FE 03 A2 16 08 C3 Zone 2 Video 4 Zone 2 Source Video 4
FE 03 A2 16 09 C4 Zone 2 Video 5 Zone 2 Source Video 5
FE 03 A2 16 0A C5 Zone 2 Power Zone 2 Power Toggle
FE 03 A2 16 1E D9 Zone 2 Mute Zone 2 Mute Toggle
FE 03 A2 16 4A 05 Zone 2 Power Off Zone 2 Power Off
FE 03 A2 16 4B 06 Zone 2 Power On Zone 2 Power On
FE 03 A2 16 6B 26 Zone 2 Source Zone 2 Source
FE 03 A2 16 6C 27 Zone 2 Mute On Zone 2 Mute On
FE 03 A2 16 6D 28 Zone 2 Mute Off Zone 2 Mute Off
FE 03 A2 16 6E 29 Party Mode Party Mode Toggle
FE 03 A2 16 71 2C All Zones Off Power Off All Zones

Table 5: Type 17 Zone 3 Command List
RSP 1069 HEX Command Command Description
FE 03 A2 17 00 BC Vol+ Zone 3 Volume Up
FE 03 A2 17 01 BD Vol- Zone 3 Volume Down
FE 03 A2 17 02 BE Zone 3 CD Zone 3 Source CD
FE 03 A2 17 03 BF Zone 3 Tuner Zone 3 Source Tuner
FE 03 A2 17 04 C0 Zone 3 Tape Zone 3 Source Tape
FE 03 A2 17 05 C1 Zone 3 Video 1 Zone 3 Source Video 1
FE 03 A2 17 06 C2 Zone 3 Video 2 Zone 3 Source Video 2
FE 03 A2 17 07 C3 Zone 3 Video 3 Zone 3 Source Video 3
FE 03 A2 17 08 C4 Zone 3 Video 4 Zone 3 Source Video 4
FE 03 A2 17 09 C5 Zone 3 Video 5 Zone 3 Source Video 5
FE 03 A2 17 0A C6 Zone 3 Power Zone 3 Power Toggle
FE 03 A2 17 1E DA Zone 3 Mute Zone 3 Mute Toggle
FE 03 A2 17 4A 06 Zone 3 Power Off Zone 3 Power Off
FE 03 A2 17 4B 07 Zone 3 Power On Zone 3 Power On
FE 03 A2 17 6B 27 Zone 3 Source Zone 3 Source
FE 03 A2 17 6C 28 Zone 3 Mute On Zone 3 Mute On
FE 03 A2 17 6D 29 Zone 3 Mute Off Zone 3 Mute Off
FE 03 A2 17 6E 2A Party Mode Party Mode Toggle
FE 03 A2 17 71 2D All Zones Off Power Off All Zones
Table 6: Type 18 Zone 4 Command List
RSP 1069 HEX Command Command Description
FE 03 A2 18 00 BD Vol+ Zone 4 Volume Up
FE 03 A2 18 01 BE Vol- Zone 4 Volume Down
FE 03 A2 18 02 BF Zone 4 CD Zone 4 Source CD
FE 03 A2 18 03 C0 Zone 4 Tuner Zone 4 Source Tuner
FE 03 A2 18 04 C1 Zone 4 Tape Zone 4 Source Tape
FE 03 A2 18 05 C2 Zone 4 Video 1 Zone 4 Source Video 1
FE 03 A2 18 06 C3 Zone 4 Video 2 Zone 4 Source Video 2
FE 03 A2 18 07 C4 Zone 4 Video 3 Zone 4 Source Video 3
FE 03 A2 18 08 C5 Zone 4 Video 4 Zone 4 Source Video 4
FE 03 A2 18 09 C6 Zone 4 Video 5 Zone 4 Source Video 5
FE 03 A2 18 0A C7 Zone 4 Power Zone 4 Power Toggle
FE 03 A2 18 1E DB Zone 4 Mute Zone 4 Mute Toggle
FE 03 A2 18 4A 07 Zone 4 Power Off Zone 4 Power Off
FE 03 A2 18 4B 08 Zone 4 Power On Zone 4 Power On
FE 03 A2 18 6B 28 Zone 4 Source Zone 4 Source
FE 03 A2 18 6C 29 Zone 4 Mute On Zone 4 Mute On
FE 03 A2 18 6D 2A Zone 4 Mute Off Zone 4 Mute Off
FE 03 A2 18 6E 2B Party Mode Party Mode Toggle
FE 03 A2 18 71 2E All Zones Off Power Off All Zones

Table 7: Type 30 Volume Direct Command List
RSP 1069 HEX Command Command Description
FE 03 A2 30 00 D5 Volume Min Volume Min
FE 03 A2 30 01 D6 Volume 1 Volume 1
FE 03 A2 30 02 D7 Volume 2 Volume 2
FE 03 A2 30 03 D8 Volume 3 Volume 3
FE 03 A2 30 04 D9 Volume 4 Volume 4
FE 03 A2 30 05 DA Volume 5 Volume 5
FE 03 A2 30 06 DB Volume 6 Volume 6
FE 03 A2 30 07 DC Volume 7 Volume 7
FE 03 A2 30 08 DD Volume 8 Volume 8
FE 03 A2 30 09 DE Volume 9 Volume 9
FE 03 A2 30 0A DF Volume 10 Volume 10
FE 03 A2 30 0B E0 Volume 11 Volume 11
FE 03 A2 30 0C E1 Volume 12 Volume 12
FE 03 A2 30 0D E2 Volume 13 Volume 13
FE 03 A2 30 0E E3 Volume 14 Volume 14
FE 03 A2 30 0F E4 Volume 15 Volume 15
FE 03 A2 30 10 E5 Volume 16 Volume 16
FE 03 A2 30 20 F5 Volume 32 Volume 32
FE 03 A2 30 30 05 Volume 48 Volume 48
FE 03 A2 30 40 15 Volume 64 Volume 64
FE 03 A2 30 50 25 Volume 80 Volume 80
FE 03 A2 30 5F 34 Volume 95 Volume 95
FE 03 A2 30 60 35 Volume Max Volume Max
Table 8: Commands Sent with exceptions or modifications required
RSP 1069 HEX Command Expected Command
FE 03 A2 30 28 FD FE 03 A2 30 28 FD 00 Volume 40
FE 03 A2 30 29 FE FE 03 A2 30 29 FD 01 Volume 41
The table above list commands with exceptions. To keep the RSP 1069 from encountering the
start byte FE in any position other than as the start byte, any occurrence of the bytes FE or FD in
the command string must be converted to either FD 00 (for FD) or FD 01 (for FE). This will allow
the string to pass while masking any occurrence of the byte FE except as the start byte.
Table 9: Type 32 Zone 2 Volume Direct Command List
RSP 1069 HEX Command Command Description
FE 03 A2 32 00 D7 Zone 2 Volume Min Zone 2 Volume Min
FE 03 A2 32 01 D8 Zone 2 Volume 1 Zone 2 Volume 1
FE 03 A2 32 02 D9 Zone 2 Volume 2 Zone 2 Volume 2
FE 03 A2 32 03 DA Zone 2 Volume 3 Zone 2 Volume 3
FE 03 A2 32 04 DB Zone 2 Volume 4 Zone 2 Volume 4
FE 03 A2 32 05 DC Zone 2 Volume 5 Zone 2 Volume 5
FE 03 A2 32 06 DD Zone 2 Volume 6 Zone 2 Volume 6
FE 03 A2 32 07 DE Zone 2 Volume 7 Zone 2 Volume 7
FE 03 A2 32 08 DF Zone 2 Volume 8 Zone 2 Volume 8

FE 03 A2 32 09 E0 Zone 2 Volume 9 Zone 2 Volume 9
FE 03 A2 32 0A E1 Zone 2 Volume 10 Zone 2 Volume 10
FE 03 A2 32 0B E2 Zone 2 Volume 11 Zone 2 Volume 11
FE 03 A2 32 0C E3 Zone 2 Volume 12 Zone 2 Volume 12
FE 03 A2 32 0D E4 Zone 2 Volume 13 Zone 2 Volume 13
FE 03 A2 32 0E E5 Zone 2 Volume 14 Zone 2 Volume 14
FE 03 A2 32 0F E6 Zone 2 Volume 15 Zone 2 Volume 15
FE 03 A2 32 10 E7 Zone 2 Volume 16 Zone 2 Volume 16
FE 03 A2 32 20 F7 Zone 2 Volume 32 Zone 2 Volume 32
FE 03 A2 32 30 07 Zone 2 Volume 48 Zone 2 Volume 48
FE 03 A2 32 40 17 Zone 2 Volume 64 Zone 2 Volume 64
FE 03 A2 32 50 27 Zone 2 Volume 80 Zone 2 Volume 80
FE 03 A2 32 5F 36 Zone 2 Volume 95 Zone 2 Volume 95
FE 03 A2 32 60 37 Zone 2 Volume Max Zone 2 Volume Max
Table 10: Commands Sent with exceptions or modifications required
RSP 1069 HEX Command Expected Command
FE 03 A2 32 26 FD FE 03 A2 32 26 FD 00 Zone 2 Volume 38
FE 03 A2 32 27 FE FE 03 A2 32 27 FD 01 Zone 2 Volume 39
The table above list commands with exceptions. To keep the RSP 1069 from encountering the
start byte FE in any position other than as the start byte, any occurrence of the bytes FE or FD in
the command string must be converted to either FD 00 (for FD) or FD 01 (for FE). This will allow
the string to pass while masking any occurrence of the byte FE except as the start byte.
Table 11: Type 33 Zone 3 Volume Direct Command List
RSP 1069 HEX Command Command Description
FE 03 A2 33 00 D8 Zone 3 Volume Min Zone 3 Volume Min
FE 03 A2 33 01 D9 Zone 3 Volume 1 Zone 3 Volume 1
FE 03 A2 33 02 DA Zone 3 Volume 2 Zone 3 Volume 2
FE 03 A2 33 03 DB Zone 3 Volume 3 Zone 3 Volume 3
FE 03 A2 33 04 DC Zone 3 Volume 4 Zone 3 Volume 4
FE 03 A2 33 05 DD Zone 3 Volume 5 Zone 3 Volume 5
FE 03 A2 33 06 DE Zone 3 Volume 6 Zone 3 Volume 6
FE 03 A2 33 07 DF Zone 3 Volume 7 Zone 3 Volume 7
FE 03 A2 33 08 E0 Zone 3 Volume 8 Zone 3 Volume 8
FE 03 A2 33 09 E1 Zone 3 Volume 9 Zone 3 Volume 9
FE 03 A2 33 0A E2 Zone 3 Volume 10 Zone 3 Volume 10
FE 03 A2 33 0B E3 Zone 3 Volume 11 Zone 3 Volume 11
FE 03 A2 33 0C E4 Zone 3 Volume 12 Zone 3 Volume 12
FE 03 A2 33 0D E5 Zone 3 Volume 13 Zone 3 Volume 13
FE 03 A2 33 0E E6 Zone 3 Volume 14 Zone 3 Volume 14
FE 03 A2 33 0F E7 Zone 3 Volume 15 Zone 3 Volume 15
FE 03 A2 33 10 E8 Zone 3 Volume 16 Zone 3 Volume 16
FE 03 A2 33 20 F8 Zone 3 Volume 32 Zone 3 Volume 32
FE 03 A2 33 30 08 Zone 3 Volume 48 Zone 3 Volume 48
FE 03 A2 33 40 18 Zone 3 Volume 64 Zone 3 Volume 64
FE 03 A2 33 50 28 Zone 3 Volume 80 Zone 3 Volume 80

RSP 1069 HEX Command Expected Command
FE 03 A2 33 5F 37 Zone 3 Volume 95 Zone 3 Volume 95
FE 03 A2 33 60 38 Zone 3 Volume Max Zone 3 Volume Max
Table 12: Commands Sent with exceptions or modifications required
RSP 1069 HEX Command Expected Command
FE 03 A2 33 25 FD FE 03 A2 33 25 FD 00 Zone 3 Volume 37
FE 03 A2 33 26 FE FE 03 A2 33 26 FD 01 Zone 3 Volume 38
The table above list commands with exceptions. To keep the RSP 1069 from encountering the
start byte FE in any position other than as the start byte, any occurrence of the bytes FE or FD in
the command string must be converted to either FD 00 (for FD) or FD 01 (for FE). This will allow
the string to pass while masking any occurrence of the byte FE except as the start byte.
Table 13: Type 34 Zone 4 Volume Direct Command List
RSP 1069 HEX Command Command Description
FE 03 A2 34 00 D9 Zone 4 Volume Min Zone 4 Volume Min
FE 03 A2 34 01 DA Zone 4 Volume 1 Zone 4 Volume 1
FE 03 A2 34 02 DB Zone 4 Volume 2 Zone 4 Volume 2
FE 03 A2 34 03 DC Zone 4 Volume 3 Zone 4 Volume 3
FE 03 A2 34 04 DD Zone 4 Volume 4 Zone 4 Volume 4
FE 03 A2 34 05 DE Zone 4 Volume 5 Zone 4 Volume 5
FE 03 A2 34 06 DF Zone 4 Volume 6 Zone 4 Volume 6
FE 03 A2 34 07 E0 Zone 4 Volume 7 Zone 4 Volume 7
FE 03 A2 34 08 E1 Zone 4 Volume 8 Zone 4 Volume 8
FE 03 A2 34 09 E2 Zone 4 Volume 9 Zone 4 Volume 9
FE 03 A2 34 0A E3 Zone 4 Volume 10 Zone 4 Volume 10
FE 03 A2 34 0B E4 Zone 4 Volume 11 Zone 4 Volume 11
FE 03 A2 34 0C E5 Zone 4 Volume 12 Zone 4 Volume 12
FE 03 A2 34 0D E6 Zone 4 Volume 13 Zone 4 Volume 13
FE 03 A2 34 0E E7 Zone 4 Volume 14 Zone 4 Volume 14
FE 03 A2 34 0F E8 Zone 4 Volume 15 Zone 4 Volume 15
FE 03 A2 34 10 E9 Zone 4 Volume 16 Zone 4 Volume 16
FE 03 A2 34 20 F9 Zone 4 Volume 32 Zone 4 Volume 32
FE 03 A2 34 30 09 Zone 4 Volume 48 Zone 4 Volume 48
FE 03 A2 34 40 19 Zone 4 Volume 64 Zone 4 Volume 64
FE 03 A2 34 50 29 Zone 4 Volume 80 Zone 4 Volume 80
FE 03 A2 34 50 38 Zone 4 Volume 95 Zone 4 Volume 95
FE 03 A2 34 50 39 Zone 4 Volume Max Zone 4 Volume Max
