Rotel RSP-1069 User manual

Technical
Manual
SURROUND SOUND PROCESSOR
RSP-1069
Table of Contents
Specification......................................1
Parts List...........................................2~13
Upgrade Procedure..........................14~20
Wiring................................................21
PCB Assembly..................................22~27
Schematic Diagram .........................28~44
SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU,
TOKYO 150-0045, JAPAN Serial. NO.
Beginning
®
Quality Uncompromised
Y-407A-0709/pdf
THE ROTEL CO., LTD.
Specifications
Audio
Total Harmonic Distortion
<0.008%
Intermodulation Distortion (60 Hz:7 kHz)
<0.008%
Frequency Response
10 Hz – 120 kHz, ±3dB (analog bypass)
10 Hz – 95 kHz, ±3dB (digital input)
Signal to Noise Ratio (IHF A-weighted)
95dB (analog bypass)
92dB (Dolby Digital, dts) 0dBFs
Input Sensitivity/Impedance
Line Level: 200 mV/100K ohms
Preamp Output Level/Output Impedance
1.0 V / 1K ohms
Contour (LF/HF)
±6dB at 50 Hz/15 kHz
Decodable Digital Input Signals
Dolby Digital, Dolby Digital EX, DTS, DTS-ES,
DTS 96/24, DTS ES 96/24, LPCM (up to 192K),
HDCD, DVD-A (HDMI HD ONLY)
Video
Input Resolutions
480i/576i
480p/576p
720p
1080i
1080p (HDMI only)
Output Resolutions
480i/576i (Composite, S-Video only)
480p/576p
720p
1080i
1080p (HDMI only)
HDMI Input/Output:
Version 1.1
Signal to Noise Ratio
45dB
Input Impedance
75 ohms
Output Impedance
75 ohms
Output Level
1.0 volt
General
Power Consumption:
80 watts
4.7 watts (standby)
Power Requirements (AC)
120 volts, 60Hz (USA version)
230 volts, 50Hz (CE version)
Weight
9.0 Kg/19.8 lb.
Dimensions (W x H x D)
432 x 122 x 341 mm
17.01” x 4.8” x 13.43”
Front Panel Height
(feet removed for rack mount)
109 mm / 4.29”

SURROUND SOUND PROCESSOR RSP-1069
LF
HF
CD TUNER TAPE VIDEO1 VIDEO2 VIDEO3 VIDEO4 VIDEO5
2CH DSP
MULTI
INPUT MUTE SELZONE
DTS
Neo 6
STANDBY
PL x
MODE
Appearance RSP-1069
AC120V~60Hz
NP-791
ON
OFF
2

Parts List 1/10 RSP-1069
SYMBOL PARTS NO. DESCRIPTION
501 X-1396-B PCB ASSY (ENCODER)
C131,132 043 TC50V101-A CERAMIC CAPACITOR 100pF
C133-136 043 TC50V821-A CERAMIC CAPACITOR 820pF
R131-136 053 CR14-103J-A CARBON RESISTOR 1/4W 10K
E131 056 C-4678A01 ROTARY ENCODER EC16B243040F (D25) (VOLUME)
E132,133 056 C-4678A03 ROTARY ENCODER EC16B242040A (D20) (TONE)
SW131 061 C-4172A13 PUSH SWITCH SPUN12XT131
CP105 068 B2B-PH-KS CONNECTOR WAFER 2P
501 E-1486-B PCB ASSY (AUDIO)
IC301 031 KIA7809AF-RTF/P IC SMD (REG.+9VDC)
IC312,325 031 MM1631XJBE IC SMD (AUDIO SWITCH)
IC304-311,316-320,322-324,326-344 031 NJM2068M IC SMD (OPE DUAL)
IC302 031 TC9162CFG IC SMD (SWITCH ALLEY)
IC321 031 TC9163CFG IC SMD (SWITCH ALLEY)
IC303,313-315 031 TC9482BFG IC SMD (VOLUME)
Q309,311,313,322 032 KRA107S TRANSISTOR CHIP KRA107S
Q310,312,314 032 KRC107S TRANSISTOR CHIP KRC107S
Q301-308,315-321 032 KRC231S TRANSISTOR CHIP KRC231S
C353,422 041 TUTES1C101-7TF ELECTROLYTIC CAPACITOR 16V100uF
C331,423 041 TUTES1E220-7TF ELECTROLYTIC CAPACITOR 25V22uF
C301-305,307,308,311,312,314,333,334,337 041 TUTES1E470-7TF ELECTROLYTIC CAPACITOR 25V47uF
C338,341,342,348,372-375,383,384,387,388 041 TUTES1E470-7TF ELECTROLYTIC CAPACITOR 25V47uF
C390,392,393,396,397,399,400,415,420,421 041 TUTES1E470-7TF ELECTROLYTIC CAPACITOR 25V47uF
C425,426,437-444,456,457,459-470,489,490 041 TUTES1E470-7TF ELECTROLYTIC CAPACITOR 25V47uF
C306,309,310,313,315,316,317,318,321,322 041 TUTES1H100-7TF ELECTROLYTIC CAPACITOR 50V10uF
C332,335,336,339,340,343,360-367 041 TUTES1H100-7TF ELECTROLYTIC CAPACITOR 50V10uF
C377,378,380-382,385,386,389,391,394,395 041 TUTES1H100-7TF ELECTROLYTIC CAPACITOR 50V10uF
C398,424,427-435,445,446,448-455,458 041 TUTES1H100-7TF ELECTROLYTIC CAPACITOR 50V10uF
C479-488,491-504,511,512,515,516,519,520 041 TUTES1H100-7TF ELECTROLYTIC CAPACITOR 50V10uF
C523,524,544-571,728,729,732,733 041 TUTES1H100-7TF ELECTROLYTIC CAPACITOR 50V10uF
C535 047 ECJ2VB1H333K CERAMIC CAPACITOR CHIP 0.033uF
C622-707,716-723,730,731 047 ECJ2VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C447,509 047 ECJ2VF1H224Z CERAMIC CAPACITOR CHIP 0.22uF
C708-715 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
C326,330,347,352,478,525,534,536-543 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
C586-593,608-621 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
C323-325,327-329,356-359 047 ECJ2VG1H220J CERAMIC CAPACITOR CHIP 22pF
C403-410,471-477,526-533 047 ECJ2VG1H220J CERAMIC CAPACITOR CHIP 22pF
C354,355,436 047 ECJ2VG1H222J CERAMIC CAPACITOR CHIP 0.0022uF
C319,320,344-346,349-351,368-371,376,379 047 ECJ2VG1H470J CERAMIC CAPACITOR CHIP 47pF
C401,402,411-414,416-419,505-508,510 047 ECJ2VG1H470J CERAMIC CAPACITOR CHIP 47pF
C513,514,517,518,521,522,572-585,594-607 047 ECJ2VG1H470J CERAMIC CAPACITOR CHIP 47pF
C724,725,726,727 047 ECJ2VG1H470J CERAMIC CAPACITOR CHIP 47pF
R307-311,313,314,317,318,321,336-338,355 055 ERJ6ENF1000V RESISTOR CHIP 100
R356,359,360,372,392,393,396,397 055 ERJ6ENF1000V RESISTOR CHIP 100
R400,401,404,405,414-416,418,419,425,431 055 ERJ6ENF1000V RESISTOR CHIP 100
R432,435,436,439,440,443,444,448,473,478 055 ERJ6ENF1000V RESISTOR CHIP 100
R487-490,492,493,496,497,499,501,502,505 055 ERJ6ENF1000V RESISTOR CHIP 100
R506,508,509,512-519,524-536,545-554,563 055 ERJ6ENF1000V RESISTOR CHIP 100
R566-568,577,578,611,614,615,618,619,622 055 ERJ6ENF1000V RESISTOR CHIP 100
R623,626,627,630,631,634,635,638,677,680 055 ERJ6ENF1000V RESISTOR CHIP 100
R681,684,685,688,689,692,693,696,697 055 ERJ6ENF1000V RESISTOR CHIP 100
R700,701,704,754-757 055 ERJ6ENF1000V RESISTOR CHIP 100
R301-306,312,315,316,319,320,323,324,327 055 ERJ6ENF1001V RESISTOR CHIP 1K
016 X-1396A01-03 PCB ASSY
016 E-1486C00 PCB ASSY
3

Parts List 2/10 RSP-1069
SYMBOL PARTS NO. DESCRIPTION
R328,330-332,335,352,354,357,358,361,370 055 ERJ6ENF1001V RESISTOR CHIP 1K
R371,411-413,426,429,438,441,442,445-447 055 ERJ6ENF1001V RESISTOR CHIP 1K
R469-472,474,475,537-544,587-590,639,641 055 ERJ6ENF1001V RESISTOR CHIP 1K
R643,645,647,649,651,653,655-660 055 ERJ6ENF1001V RESISTOR CHIP 1K
R705-721,731-738,746,748,749 055 ERJ6ENF1001V RESISTOR CHIP 1K
R739-745 055 ERJ6ENF1002V RESISTOR CHIP 10K
R351,353,363,364,366-369,373-376,391,394 055 ERJ6ENF1003V RESISTOR CHIP 100K
R395,398,399,402,403,406-410,417,420,449 055 ERJ6ENF1003V RESISTOR CHIP 100K
R452,476,477,479-486,491,494,495,498,500 055 ERJ6ENF1003V RESISTOR CHIP 100K
R503,504,507,520,521,564,565,569-576 055 ERJ6ENF1003V RESISTOR CHIP 100K
R603-610,612,613,616,617,620,621,624,625 055 ERJ6ENF1003V RESISTOR CHIP 100K
R628,629,632,633,636,637,640,642,644,646 055 ERJ6ENF1003V RESISTOR CHIP 100K
R648,650,652,654,661,664,665,668,669,672 055 ERJ6ENF1003V RESISTOR CHIP 100K
R673,676,678,679,682,683,686,687,690,691 055 ERJ6ENF1003V RESISTOR CHIP 100K
R694,695,698,699,702,703,722-730,747 055 ERJ6ENF1003V RESISTOR CHIP 100K
R750-753 055 ERJ6ENF1003V RESISTOR CHIP 100K
R377,378 055 ERJ6ENF10R0V RESISTOR CHIP 10
R600,602 055 ERJ6ENF1202V RESISTOR CHIP 12K
R599 055 ERJ6ENF1801V RESISTOR CHIP 1.8K
R340,341,344,346,379,382,384,385,388,389 055 ERJ6ENF2001V RESISTOR CHIP 2K
R322,325,326,329,461,464,465,468 055 ERJ6ENF2201V RESISTOR CHIP 2.2K
R591,593,595,597,601,663,667,671,675 055 ERJ6ENF2702V RESISTOR CHIP 27K
R362,365 055 ERJ6ENF3300V RESISTOR CHIP 330
R421-424,430,433,434,437,510,522,555-562 055 ERJ6ENF3301V RESISTOR CHIP 3.3K
R339,342,343,383,386,387,390 055 ERJ6ENF4701 RESISTOR CHIP 4.7K
R450,451,453-460,511,523,592,594,596 055 ERJ6ENF4701 RESISTOR CHIP 4.7K
R598,662,666,670,674 055 ERJ6ENF4701 RESISTOR CHIP 4.7K
R333,334,427,428 055 ERJ6ENF4703V RESISTOR CHIP 470K
R347-350,462,463,466,467 055 ERJ6ENF5601V RESISTOR CHIP 5.6K
R579-586 055 ERJ6ENF5602V RESISTOR CHIP 56K
R345,380,381 055 ERJ6ENF7501V RESISTOR CHIP 7.5K
JAK308 066 C-4764A01 2P PIN JACK (W/R)
JAK307 066 C-4784A02 4P PIN JACK (B)
JAK301-304,306 066 C-4792A01 6P PIN JACK (W/R)
JAK305 066 C-4832A01 4P PIN JACK (W/R/B)
CN303 068 B12B-PH-KS CONNECTOR WAFER 12P
CP402 068 B3B-PH-KS CONNECTOR WAFER 3P
CP306 068 B4B-PH-KS CONNECTOR WAFER 4P
501 E-1488-B PCB ASSY (HDMI SWITCH)
L601-616 021 ACM2012D EMC FILTER COIL ACM2012D-900-2P
L617-620 021 ACM2012H EMC FILTER COIL ACM2012H-900-2P
IC631 023 CXOSMD-004 CRYSTAL SMD 27.000MHZ
XT605 023 HC49USMD-013 CRYSTAL SMD 13.500MHz
XT601 023 HC49USMD-014 CRYSTAL SMD 28.322MHz
XT604 023 HC49USMD-015 CRYSTAL SMD 5.000MHz
L652 025 BK2125HS102 BEAD COIL CHIP BK2125HS102-T
L623,624,626,628,640-642,645-648,667-669 025 BK2125HS102 BEAD COIL CHIP BK2125HS102-T
L661-665 025 BK2125HS601 BEAD COIL CHIP BK2125HS601-T
L621,622,625,627,629,633-636,638,639 025 BK2125HS601 BEAD COIL CHIP BK2125HS601-T
L643,644,649-651,666 025 BK2125HS601 BEAD COIL CHIP BK2125HS601-T
L630-632 025 CM2012F100K INDUCTOR CHIP 10uH
ZD601 031 AD1580BRTZ IC (VOLTAGE REFERENCE)
IC629 031 ADV7322KSTZ IC SMD (VIDEO ENCODER)
IC623 031 ADV7401BSTZ-110 IC SMD (VIDEO DECODER)
IC610,617 031 AME1117ACGT IC SMD (REGULATOR) ABE AME1117ACGTZ
016 E-1488E00 PCB ASSY
4

Parts List 3/10 RSP-1069
SYMBOL PARTS NO. DESCRIPTION
IC640 031 AME1117BCGT IC SMD (REGULATOR) AKE AME1117BCGTZ
IC621,624,638 031 AME1117CCGT IC SMD (REGULATOR) ABF AME1117CCGTZ
IC625,641 031 AME1117ECGT IC SMD (REGULATOR) AXH AME1117ECGTZ
IC611 031 AME8801SEEV IC SMD (REGULATOR) AME8801SEEVZ
IC602,604,606,608,642 031 BR24L08F-W IC SMD (EEPROM)
IC628 031 FLI2300-LF-CF IC SMD (CONVERTER)
IC620 031 K4S643232H-UC60 IC SMD (SDRAM)
IC615,650 031 NC7SZ08M5-NL IC SMD (AND GATE)
IC633,634,637,648 031 NC7SZ125M5-NL IC SMD (TRISTATE BUFFER)
IC614 031 NJW1320FP1 IC SMD (VIDEO SWITCH)
IC644-646 031 PI6CV304LE IC SMD (CLOCK BUFFER)
IC616 031 SII9030CTU-7 IC SMD (TRANSMITTER)
IC622 031 SII9031CTU-7 IC SMD (RECEIVER)
IC635,643 031 SN74ALVC244PWR IC SMD (BUFFEDRIVER)
IC647 031 SN74ALVCH162827GR IC SMD (BUFFEDRIVER)
IC630 031 SN74ALVCH162827GR IC SMD (BUFFEDRIVER)
IC649 031 SN74CB3Q3305 IC SMD (BUS SWITCH) SN74CB3Q3305PER
IC636 031 SN74LVC257APWR IC SMD (MULTIPLEXER)
IC613,618 031 THS7353PW IC SMD (VIDEO BUFFER)
IC612 031 TMDS341 IC SMD (SWITCH)
IC601,603,605,607 031 TS5A23157DGSR IC SMD (ANALOG SWITCH)
IC639 031 UPD70F03701GB-X58 IC SMD (SOFT WRITING) Scalar CPU and Flash
Q613-615,617,621-624 032 KRC107S TRANSISTOR CHIP KRC107S
Q608-610,625,639,640 032 KRC107S TRANSISTOR CHIP KRC107S
Q632,634,636,638 032 KRC231S TRANSISTOR CHIP KTA1504S
Q631,633,635,637 032 KRC231S TRANSISTORANSISTOR CHIP
Q616,618-620 032 KTA1504S TRANSISTOR CHIP UPA672T
Q611,612,641 032 NDC7002N DUAL FET SMD
Q626-630 032 UPA672T DUAL FET SMD
CV601-610 034 AVRL101 VARISTOR DIODE
ZD602,603,608-611 034 KDZ6.2V ZENER DIODE KDZ6.2V
D605-614 034 RCLAMP0514M DIODE RCLAMP0514M.TBT
D616 034 T1N4004-TB DIODE 1N4004-F (AMMO)
D621 037 KDS184RTK DIODE CHIP KDS184RTK
ZD604-607 037 KDS226RTK DIODE CHIP KDS226RTK
D615 037 KDS226RTK DIODE CHIP KDS226RTK
C635,643,673,686,721,736,741 047 ECFS1A221M ELECTROLYTIC CAPACITOR SMD 10V220uF
C617-619,735,737 047 ECFS1A471M ELECTROLYTIC CAPACITOR SMD 10V470uF
C608-616,622,626,628,630,632-634,637 047 ECFS1C100M ELECTROLYTIC CAPACITOR SMD 16V10uF
C641,646-648,664,671,683,691 047 ECFS1C100M ELECTROLYTIC CAPACITOR SMD 16V10uF
C705,716,717,719,720 047 ECFS1C100M ELECTROLYTIC CAPACITOR SMD 16V10uF
C623,667,672,678,680,687,690 047 ECFS1C101M ELECTROLYTIC CAPACITOR SMD 16V100uF
C715,722,728,730,743,749 047 ECFS1C101M ELECTROLYTIC CAPACITOR SMD 16V100uF
C621,624,642,644,645,665,676,677,694 047 ECFS1C470M ELECTROLYTIC CAPACITOR SMD 16V47uF
C701-703,718 047 ECFS1C470M ELECTROLYTIC CAPACITOR SMD 16V47uF
C620,625,627,629 047 ECFS1E470M ELECTROLYTIC CAPACITOR SMD 25V47uF
C711,724,943,944,955 047 ECFS1E4R7M ELECTROLYTIC CAPACITOR SMD 25V4.7uF
C631 047 ECFS1H010M ELECTROLYTIC CAPACITOR SMD 50V1uF
C689,750,791,810,821,884,885,895,898,899 047 ECJ1VB1H103K CERAMIC CAPACITOR CHIP 0.01uF
C904,905,908,909,911,912,916,922-925 047 ECJ1VB1H103K CERAMIC CAPACITOR CHIP 0.01uF
C929,930,936-940,942,948-950,962 047 ECJ1VB1H103K CERAMIC CAPACITOR CHIP 0.01uF
C606,607,675,679,692,695,696,699 047 ECJ1VB1H103K CERAMIC CAPACITOR CHIP 0.01uF
C700,704,708,709,739,748,956,963-969 047 ECJ1VB1H103K CERAMIC CAPACITOR CHIP 0.01uF
C682 047 ECJ1VB1H392K CERAMIC CAPACITOR CHIP 3900pF
C809 047 ECJ1VB1H822K CERAMIC CAPACITOR CHIP 8200pF
C808 047 ECJ1VB1H823K CERAMIC CAPACITOR CHIP 0.082pF
C945-947 047 ECJ1VC1H020C CERAMIC CAPACITOR CHIP 2pF
5

Parts List 4/10 RSP-1069
SYMBOL PARTS NO. DESCRIPTION
C830,831,840,970 047 ECJ1VC1H050C CERAMIC CAPACITOR CHIP 5pF
C933-935 047 ECJ1VC1H100D CERAMIC CAPACITOR CHIP 10pF
C957 047 ECJ1VC1H100D CERAMIC CAPACITOR CHIP 10pF
C807,822 047 ECJ1VC1H180J CERAMIC CAPACITOR CHIP 18pF
C755,756,841-843 047 ECJ1VC1H220J CERAMIC CAPACITOR CHIP 22pF
C753,754 047 ECJ1VC1H330J CERAMIC CAPACITOR CHIP 33pF
C681 047 ECJ1VC1H821J CERAMIC CAPACITOR CHIP 820pF
C824,880,881 047 ECJ1VF1C105Z CERAMIC CAPACITOR CHIP 16V1uF
C650,655-660,668-670 047 ECJ1VF1C105Z CERAMIC CAPACITOR CHIP 16V1uF
C601,604,605,697,707 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C688,751,752,757-783,785-790,792,793 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C795-805,811-820,823,826,829,833-836 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C839,844,847-879,882,883,887-892,897 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C900-903,910,913-915,917-921,926-928,932 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C602,603,636,639,649,651,661-663 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C666,684,685,693,698 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C706,710,714,725-727,729,731-734 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C738,740,742,744-747,941,961 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C806,825,832,906,931 047 ECJ1VG1H102J CERAMIC CAPACITOR CHIP 1000pF
C674,886 047 ECJ1VG1H102J CERAMIC CAPACITOR CHIP 1000pF
R713,727 054 1WS4.7JF MOF RESISTOR 1W 4.7
R976 054 1WS6.8JF MOF RESISTOR 1W 6.8
R623,624,640,647,652,655-658,664,666 055 CN43-220 NETWORK RESISTOR CHIP 22
R668,670,679,682,686-690,706,707 055 CN43-220 NETWORK RESISTOR CHIP 22
R748-751,756,780,815,820,830,940,941,975 055 ERJ3EKF1000V RESISTOR CHIP 100
R626,628,631,680,703,704,716,717 055 ERJ3EKF1000V RESISTOR CHIP 100
R720-725,732,734,735,737,739,741,743,745 055 ERJ3EKF1000V RESISTOR CHIP 100
R938,939,942,948,949 055 ERJ3EKF1000V RESISTOR CHIP 100
R757,821,828,918-921 055 ERJ3EKF1001V RESISTOR CHIP 1K
R777 055 ERJ3EKF1001V RESISTOR CHIP 1K
R619,810,827,834-837,852,864,865 055 ERJ3EKF1002V RESISTOR CHIP 10K
R868,871,880,904,952 055 ERJ3EKF1002V RESISTOR CHIP 10K
R683,685,691,693,695,698,700,701 055 ERJ3EKF1002V RESISTOR CHIP 10K
R925,982-984 055 ERJ3EKF1002V RESISTOR CHIP 10K
R784 055 ERJ3EKF1004V RESISTOR CHIP 1M
R603-605,764 055 ERJ3EKF10R0V RESISTOR CHIP 10
R601,602 055 ERJ3EKF10R0V RESISTOR CHIP 10
R822,909 055 ERJ3EKF1200V RESISTOR CHIP 120
R798-800 055 ERJ3EKF1500V RESISTOR CHIP 150
R824,831-833,842,862 055 ERJ3EKF1501V RESISTOR CHIP 1.5K
R781 055 ERJ3EKF1691V RESISTOR CHIP 1.69K
R761 055 ERJ3EKF1820V RESISTOR CHIP 182
R786 055 ERJ3EKF2000V RESISTOR CHIP 200
R845,872,874,875 055 ERJ3EKF2001V RESISTOR CHIP 2K
R907,912 055 ERJ3EKF2001V RESISTOR CHIP 2K
R606,917 055 ERJ3EKF2002V RESISTOR CHIP 20K
R607,608 055 ERJ3EKF2002V RESISTOR CHIP 20K
R891-893 055 ERJ3EKF2202V RESISTOR CHIP 22K
R654,767-769,771,774,776 055 ERJ3EKF22R1V RESISTOR CHIP 22.1
R620,625,630,634,641,650,651,653 055 ERJ3EKF22R1V RESISTOR CHIP 22.1
R659-663,671-677,684,696,697,699,702,779 055 ERJ3EKF22R1V RESISTOR CHIP 22.1
R927,950,951,953 055 ERJ3EKF22R1V RESISTOR CHIP 22.1
R789,790 055 ERJ3EKF2701V RESISTOR CHIP 2.7K
R635-637 055 ERJ3EKF3000V RESISTOR CHIP 300
R638,642 055 ERJ3EKF3001V RESISTOR CHIP 3K
R846,873 055 ERJ3EKF3301V RESISTOR CHIP 3.3K
R669 055 ERJ3EKF3303V RESISTOR CHIP 330K
6

Parts List 5/10 RSP-1069
SYMBOL PARTS NO. DESCRIPTION
R840 055 ERJ3EKF4641V RESISTOR CHIP 4.64K
R807 055 ERJ3EKF4700V RESISTOR CHIP 470
R752-755,763,782,783,787,829,847 055 ERJ3EKF4701V RESISTOR CHIP 4.7K
R853-855,857,863,869,958,978,979 055 ERJ3EKF4701V RESISTOR CHIP 4.7K
R648,649,708-712,715,718,719,729-731 055 ERJ3EKF4701V RESISTOR CHIP 4.7K
R733,736,738,740,742,744,908,911,926 055 ERJ3EKF4701V RESISTOR CHIP 4.7K
R946,947,955-957,980,981 055 ERJ3EKF4701V RESISTOR CHIP 4.7K
R895,896,898,899,901,902,905,906 055 ERJ3EKF4702V RESISTOR CHIP 47K
R616,617,928-935 055 ERJ3EKF4702V RESISTOR CHIP 47K
R758 055 ERJ3EKF4703V RESISTOR CHIP 470K
R856 055 ERJ3EKF4750V RESISTOR CHIP 475
R646,778 055 ERJ3EKF47R0V RESISTOR CHIP 47
R794-797,801,805 055 ERJ3EKF6040V RESISTOR CHIP 604
R639 055 ERJ3EKF6800V RESISTOR CHIP 680
R841 055 ERJ3EKF6802V RESISTOR CHIP 68K
R823,910,922-924 055 ERJ3EKF7500V RESISTOR CHIP 750
R759,760,762,882-890 055 ERJ3EKF75R0V RESISTOR CHIP 75
R610,870,876 055 ERJ3EKF75R0V RESISTOR CHIP 75
R765,766,775,785,788,791-793 055 ERJ3GEY0R00V RESISTOR CHIP 0
R806,808,894,897,900,903,943-945 055 ERJ3GEY0R00V RESISTOR CHIP 0
R962,966,970,974 055 ERJ3GEY0R00V RESISTOR CHIP 0
R618,627,629,633,643-645,678,681 055 ERJ3GEY0R00V RESISTOR CHIP 0
R714,726,728,746,937,959,963,967,971 055 ERJ3GEY0R00V RESISTOR CHIP 0
R632 055 ERJ3RQF2R2V RESISTOR CHIP 2.2
L658-660 055 ERJ6GEYJ2R2V RESISTOR CHIP 2.2
JK601,602 066 C-4833A01 PIN JACK 6P (G .BLU.R)
J601-605 066 C-4963A01 HDMI SOCKTE
501 E-1489-B PCB ASSY (VIDEO)
L501-503 021 TLAL02TB100K MICRO INDUCTOR 10uH
L504,506,509,512 021 TLAL02TB4R7K MICRO INDUCTOR 4.7uH
L505,507,508 021 TLAL02TB6R8K MICRO INDUCTOR 6.8uH
XT501 023 HC49U-001WR CRYSTAL 14.31818MHz
L510,511 025 BK2125HS601 BEAD COIL CHIP BK2125HS601-T
IC516,517,521 031 AD8063ART IC SMD (AMP) ADV8063ARTZ-R2
IC524 031 MB90050PF-G-001 IC SMD (OSD)
IC522 031 MM1108XFFE IC SMD (SYNC SEPARATOR)
IC504,505,515 031 MM1227XFBE IC SMD (VIDEO SWITCH)
IC506-514,518-520 031 MM1508XNRE IC SMD (VIDEO SWITCH)
IC525 031 NJM7805FA IC (REG. +5VDC)KIA7805API
IC523 031 NJM7808FA IC (REG.+8VDC)KIA7808API
IC501-503 031 TEA6425D IC SMD (VIDEO SWITCH)
Q503 032 KRC107S TRANSISTOR CHIP KRC107S
Q501,502,504,505 032 KTC3875S-Y TRANSISTOR KTC3875S-Y-RTK
D501-503 037 KDS226RTK DIODE CHIP KDS226RTK
C503,505,507-515,522-524,528,529 041 TUTES1A101-7TF ELECTROLYTIC CAPACITOR 10V100uF
C541-550,560,567-569 041 TUTES1A101-7TF ELECTROLYTIC CAPACITOR 10V100uF
C502,504,506,519-521,572-574 041 TUTES1A471-7TF ELECTROLYTIC CAPACITOR 10V470uF
C583,587 041 TUTES1E470-7TF ELECTROLYTIC CAPACITOR 25V47uF
C552 041 TUTES1H010-7TF ELECTROLYTIC CAPACITOR 50V1uF
C501,530-540,551,553-555,557-559 041 TUTES1H100-7TF ELECTROLYTIC CAPACITOR 50V10uF
C561,562,566,570,575,582,584-586 041 TUTES1H100-7TF ELECTROLYTIC CAPACITOR 50V10uF
C580 041 TUTES1H3R3-7TF ELECTROLYTIC CAPACITOR 50V3.3uF
C589-632,634,639,643-646,648-651 047 3535104122 CERAMIC CAPACITOR CHIP 0.1uF
C581 047 3535104122 CERAMIC CAPACITOR CHIP 0.1uF
C647,652,653 047 3535200122 CERAMIC CAPACITOR CHIP 20pF
016 E-1489B00 PCB ASSY
7

Parts List 6/10 RSP-1069
SYMBOL PARTS NO. DESCRIPTION
C516-518,525-527 047 3535224122 CERAMIC CAPACITOR CHIP 0.22uF
C578 047 3535392122 CERAMIC CAPACITOR CHIP 3900pF
C633 047 ECJ1VC1H100D CERAMIC CAPACITOR CHIP 10pF
C564,571 047 ECJ1VC1H100D CERAMIC CAPACITOR CHIP 10pF
C642 047 ECJ1VC1H101J CERAMIC CAPACITOR CHIP 100pF
C577 047 ECJ1VC1H102J CERAMIC CAPACITOR CHIP 1000pF
C637,638,641 047 ECJ1VC1H220J CERAMIC CAPACITOR CHIP 22pF
C556,579 047 ECJ1VC1H561J CERAMIC CAPACITOR CHIP 560pF
C635,636,640 047 ECJ1VC1H820J CERAMIC CAPACITOR CHIP 82pF
R602,605 054 1WS10J MOF RESISTOR 1W 10
R620 055 ERJ3EKF1000V RESISTOR CHIP 100
R544-547,561,566,576,591 055 ERJ3EKF1000V RESISTOR CHIP 100
R521,523,594,612-614 055 ERJ3EKF1001V RESISTOR CHIP 1K
R578-581,586,593,616,617 055 ERJ3EKF1002V RESISTOR CHIP 10K
R596,604 055 ERJ3EKF1003V RESISTOR CHIP 100K
R501 055 ERJ3EKF10R0V RESISTOR CHIP 10
R528,529,550,551,553-560,562,563 055 ERJ3EKF10R0V RESISTOR CHIP 10
R575,577,582,583 055 ERJ3EKF10R0V RESISTOR CHIP 10
R520,522 055 ERJ3EKF2001V RESISTOR CHIP 2K
R599,601 055 ERJ3EKF2202V RESISTOR CHIP 22K
R587,588 055 ERJ3EKF2701V RESISTOR CHIP 2.7K
R572,573,597 055 ERJ3EKF3000V RESISTOR CHIP 300
R571 055 ERJ3EKF3303V RESISTOR CHIP 330K
R606,607 055 ERJ3EKF33R0V RESISTOR CHIP 33
R530-543,552,589,592,600 055 ERJ3EKF4701V RESISTOR CHIP 4.7K
R564,565 055 ERJ3EKF5600V RESISTOR CHIP 560
R621-623 055 ERJ3EKF6040V RESISTOR CHIP 604
R567,569,584 055 ERJ3EKF6040V RESISTOR CHIP 604
R511-519 055 ERJ3EKF68R0V RESISTOR CHIP 68
R502-510 055 ERJ3EKF75R0V RESISTOR CHIP 75
R595 055 ERJ3EKF8202V RESISTOR CHIP 82K
R524,608-611,615 055 ERJ3GEY0R00V RESISTOR CHIP 0
R598,603 055 ERJ3RQF1R0V RESISTOR CHIP 1
R525-527 055 ERJ3RQF2R2V RESISTOR CHIP 2.2
JK501-503 066 C-4964A01 2P PIN JACK + DIN JACK
CP601 068 B12B-PH-KS CONNECTOR WAFER 12P
CP605 068 B4B-PH-KS CONNECTOR WAFER 4P
501 X-1494-B PCB ASSY (FRONT)
XT101 023 CSTLS16M0X51BO CERAMIC RESONATOR
IC101 031 CXP81120-127Q IC SMD (CPU) MASKING
RMC101 031 RPM7138H9 IC (REMOTE RECEIVER)
IC102-104 031 TD62C950RF IC SMD (FL DISPLAY) TD62C950RFG
Q101,102 032 KRC107S TRANSISTOR CHIP KRC107S
FL101 035 HNA22ML04 FL TUBE
D101,102 037 KDS184RTK DIODE CHIP
C103 041 TUTES1E470-7TF EECTROLYTIC CAPACITOR 25V47uF
C105,106 041 TUTES1H100-7TF EECTROLYTIC CAPACITOR 50V10uF
C101 041 TUTES1H3R3-7TF EECTROLYTIC CAPACITOR 50V3.3uF
C102,104 047 ECJ2VB1H223K CAPACITOR CAPACITOR CHIP 0.022uF
C130 047 ECJ2VF1H104Z CAPACITOR CAPACITOR CHIP 0.1uF
C107-109 047 ECJ2VF1H104Z CAPACITOR CAPACITOR CHIP 0.1uF
R111-113,116 055 ERJ6ENF1002V RESISTOR CHIP 10K
R115 055 ERJ6ENF10R0V RESISTOR CHIP 10
(R114) 055 ERJ6ENF1800V RESISTOR CHIP 180
(R114) 055 ERJ6ENF4700V RESISTOR CHIP 470
016 X-1494A01-02 PCB ASSY
8

Parts List 7/10 RSP-1069
SYMBOL PARTS NO. DESCRIPTION
R109 055 ERJ6ENF4701V RESISTOR CHIP 4.7K
R120 055 ERJ6ENF4702V RESISTOR CHIP 47K
R101-108 055 ERJ6ENF4702V RESISTOR CHIP 47K
R110,117 055 ERJ6GEY0R00V RESISTOR CHIP 0
SW101-116 061 C-4679A03 TACT SWITCH 5mm GRY HV061050GS
CP104 068 B2B-PH-KS CONNECTOR WAFER 2P
CP103 068 B3B-PH-KS CONNECTOR WAFER 3P
CP101 068 B8B-PH-KS CONNECTOR WAFER 8P
501 E-1495 PCB ASSY (DIGITAL)
L401-404 021 2888100012 PULSE TRANS.EP7-01-201M
IC418 023 CXOSMD-003 CRYSTAL SMD 24.576MHz
XT402 023 HC49USMD-015 CRYSTAL SMD 5.00MHz
L419,421 025 BK2125HS101 BEAD COIL CHIP BK2125HS101-T
L405,407,409,410,411,413,414,417 025 BK2125HS102 BEAD COIL CHIP BK2125HS102-T
L406,408,412,415,416,418,420 025 BK2125HS601 BEAD COIL CHIP BK2125HS601-T
IC406 031 74HC157 IC SMD (QUAD MPX) 74VHC157
IC417 031 74HC244 IC SMD (OCTAL BUFFER) 74VHC244
IC422 031 74HCT125 IC SMD (QUAD BUFFER) 74HCT125D
IC414 031 AK4114VQ IC SMD (D/A TRANSCEIVER) AK4114VQP
IC438 031 AME1117CCGT IC SMD (REGULATOR) ABF AME1117CCGTZ
IC434 031 AT24C16A10PU-2.7 IC DIP (EPROM)
IC411,415,423,426 031 DSD1791DB IC SMD (DAC)
IC433 031 ES29LV160E-X58 IC SMD (SOFT WRITING) DSP ROM
IC410 031 HEF4094BT IC SMD (SHIFT REGISTER)
IC405 031 HIN232CB IC SMD (TRANSMITTER RECEIVER) HIN232CBZ
IC432 031 K4S641632K-UC75 IC SMD (MEMORY)
IC401-404 031 LTV817 IC (PHOTO COUPLER)
IC407-409,412,419,424,427-430,435,436,439 031 NJM2068M IC SMD (OPE DUAL)
IC437 031 PCM1804DBG4 IC SMD (ADC)
IC413,425 031 SN74LVC1G125DBV IC SMD (BUFFER)
IC420 031 SN74LVC1G3157DB IC SMD ANALOG SWITCH)
IC416 031 TC9482BFG IC SMD (VOLUME)
IC431 031 TMS320DA610 IC SMD (DSP)
IC421 031 UPD70F3712-P69 IC SMD (SOFT WRITING) Main CPU and Flash
Q419 032 KRA107S TRANSISTOR CHIP KRA107S
Q413-418,420,421 032 KRC107S TRANSISTOR CHIP KRC107S
Q401-406 032 KRC231S TRANSISTOR CHIP KRC231S
Q407-412 032 TA1450-ST TRANSISTOR 2SA1450AA-ST
D401-403 037 KDS184RTK DIODE CHIP KDS184RTK
C507 041 TEEUFC1H4R7B ELECTROLYTIC CAPACITOR 50V4.7uF
C467,509,541,589,630,657,718,719 041 TUTES1A101-7TF ELECTROLYTIC CAPACITOR 10V100uF
C490 041 TUTES1A471-7TF ELECTROLYTIC CAPACITOR 10V470uF
C465,466,472,489,504-506,515,520,525 041 TUTES1E470-7TF ELECTROLYTIC CAPACITOR 25V47uF
C538-540,546,565,568,582,585,586,600-605 041 TUTES1E470-7TF ELECTROLYTIC CAPACITOR 25V47uF
C611,616,623,649,654,655,669,686,687 041 TUTES1E470-7TF ELECTROLYTIC CAPACITOR 25V47uF
C702,703,705,710,722 041 TUTES1E470-7TF ELECTROLYTIC CAPACITOR 25V47uF
C426,433,448,449,485,522,564,618 041 TUTES1H010-7TF ELECTROLYTIC CAPACITOR 50V1uF
C650,704 041 TUTES1H0R1-7TF ELECTROLYTIC CAPACITOR 50V0.1uF
C440-445,447,473-478,484,496,521,533 041 TUTES1H100-7TF ELECTROLYTIC CAPACITOR 50V10uF
C537,563,572-577,617,670-676,713 041 TUTES1H100-7TF ELECTROLYTIC CAPACITOR 50V10uF
C508 041 TUTES1H3R3-7TF ELECTROLYTIC CAPACITOR 50V3.3uF
C486 041 TUTES1HR22-7TF ELECTROLYTIC CAPACITOR 50V0.22uF
C494 041 TUTES1HR47-7TF ELECTROLYTIC CAPACITOR 50V0.47uF
C481,487,518,523,545,566,614,621 047 ECJ1VB1H182K CERAMIC CAPACITOR CHIP 1800pF
C668,678,717,723 047 ECJ1VB1H222K CERAMIC CAPACITOR CHIP 2200pF
016 E-1495C00 PCB ASSY
9

Parts List 8/10 RSP-1069
SYMBOL PARTS NO. DESCRIPTION
C666,712 047 ECJ1VB1H223K CERAMIC CAPACITOR CHIP 0.022uF
C415,417,418,681-684,706,707,715 047 ECJ1VC1H100D CERAMIC CAPACITOR CHIP 10pF
C419-422,424,425,427-432 047 ECJ1VC1H101J CERAMIC CAPACITOR CHIP 100pF
C640-645,664,677,714,720 047 ECJ1VC1H101J CERAMIC CAPACITOR CHIP 100pF
C470,471,479,480 047 ECJ1VC1H220J CERAMIC CAPACITOR CHIP 22pF
C457-462,633-638 047 ECJ1VC1H470J CERAMIC CAPACITOR CHIP 47pF
C468,482,488,497,512,519,524,531,542 047 ECJ1VC1H561J CERAMIC CAPACITOR CHIP 560pF
C549,567,570,598,615,622,631 047 ECJ1VC1H561J CERAMIC CAPACITOR CHIP 560pF
C401-414,416,423,434-439,446,450-456 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C463,464,469,483,491-493,495,498-503 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C510,511,513,514,516,517,526-530,532 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C534-536,543,544,547,548,550-562,569 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C571,578-581,583,584,587,588,590-597 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C599,606-610,612,613,619,620,624-629 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C632,639,646,647,648,651-653,656 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C658-663,665,667,679,680,685,688-701 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C708,709,711,716,721 047 ECJ1VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
RM401-409 055 CN43-220 NETWORK RESISTOR CHIP 22
R417-420,425,426,474-479,496,527,529,540 055 ERJ3EKF1000V RESISTOR CHIP 100
R542,546-548,560,565,568,571,574-576,579 055 ERJ3EKF1000V RESISTOR CHIP 100
R588,614,623,632,634-639,657,660,668,688 055 ERJ3EKF1000V RESISTOR CHIP 100
R707,711,716,717,729,730,732-735,739 055 ERJ3EKF1000V RESISTOR CHIP 100
R430-435,481,502,505,506,509,510,513 055 ERJ3EKF1001V RESISTOR CHIP 1K
R538,541,543,599,600,603,604,607,608 055 ERJ3EKF1001V RESISTOR CHIP 1K
R611,690,693,694,697,698,701 055 ERJ3EKF1001V RESISTOR CHIP 1K
R442-446,465-468,553,555,558,640,661 055 ERJ3EKF1002V RESISTOR CHIP 10K
R687,702 055 ERJ3EKF1002V RESISTOR CHIP 10K
R453-458,480,497,501,503,504,507,508,511 055 ERJ3EKF1003V RESISTOR CHIP 100K
R512,545,552,589,593,601,602,605,606,609 055 ERJ3EKF1003V RESISTOR CHIP 100K
R610,633,644,691,692,695,696,699,700 055 ERJ3EKF1003V RESISTOR CHIP 100K
R517,518 055 ERJ3EKF1004V RESISTOR CHIP 1M
R401-410,421,422,473 055 ERJ3EKF10R0V RESISTOR CHIP 10
R483,484,487,488,491,492 055 ERJ3EKF1202V RESISTOR CHIP 12K
R670,671,674,675,678,679,709,718,736,742 055 ERJ3EKF1501V RESISTOR CHIP 1.5K
R617,628 055 ERJ3EKF1502V RESISTOR CHIP 15K
R498,514,523,525,549,559,561,564,572 055 ERJ3EKF1801V RESISTOR CHIP 1.8K
R577,590,595,596,597,616,619,621,641 055 ERJ3EKF1801V RESISTOR CHIP 1.8K
R645,651,662,666,681,703,706,708,721 055 ERJ3EKF1801V RESISTOR CHIP 1.8K
R531 055 ERJ3EKF1802V RESISTOR CHIP 18K
R447-449 055 ERJ3EKF2002V RESISTOR CHIP 20K
R495,519,521,536,544,566,569,584,587 055 ERJ3EKF2202V RESISTOR CHIP 22K
R612,631,649,663,685 055 ERJ3EKF2202V RESISTOR CHIP 22K
R532-535,580-583,624-627,648,682-684 055 ERJ3EKF22R1V RESISTOR CHIP 22.1
R723-727 055 ERJ3EKF2700V RESISTOR CHIP 270
R499,520,522,537,550,567,570,585,591,613 055 ERJ3EKF3301V RESISTOR CHIP 3.3K
R618,629,642,650,652,686,710,714,731,737 055 ERJ3EKF3301V RESISTOR CHIP 3.3K
R615,665,689,712,722 055 ERJ3EKF3901V RESISTOR CHIP 3.9K
R436-441 055 ERJ3EKF3902V RESISTOR CHIP 39K
R427,469 055 ERJ3EKF4700V RESISTOR CHIP 470
R459-464,482,485,486,489,490,493,494 055 ERJ3EKF4701V RESISTOR CHIP 4.7K
R516,528,530,539,563,586,594,630,647 055 ERJ3EKF4701V RESISTOR CHIP 4.7K
R653-656,658,659,669,672,673,676,677 055 ERJ3EKF4701V RESISTOR CHIP 4.7K
R680,704,705,719,720 055 ERJ3EKF4701V RESISTOR CHIP 4.7K
R713,715,738,741 055 ERJ3EKF47R0V RESISTOR CHIP 47
R500,515,524,526,551,562,573,578,592 055 ERJ3EKF6800V RESISTOR CHIP 680
R598,620,622,643,646,664,667 055 ERJ3EKF6800V RESISTOR CHIP 680
R423,424,428,429,450-452,470-472 055 ERJ3EKF75R0V RESISTOR CHIP 75
10

Parts List 9/10 RSP-1069
SYMBOL PARTS NO. DESCRIPTION
R411-416,740 055 ERJ3RQF2R2V RESISTOR CHIP 2.2
R728 055 ERJ3RQF4R7V RESISTOR CHIP 4.7
SW401 061 C-4679A03 TACT SWITCH 5mm GRY HV061050GS
JAK401-406 065 HSJ1002-016020 3.5ΦMINI JACK
JAK417 066 C-4764A03 2P PIN JACK (Y.Y)
JAK415 066 C-4792A01 6P PIN JACK (W.R)
JAK416 066 C-4829A01 1P PIN JACK (YEL)
JAK409,410 066 C-4859A01 2P PIN JACK (BLK)
JAK407 066 SY010-8P/K RJ45 TERMINAL SY010-8P
JAK411-414 066 TORX142L OPTICAL MODULE TORX142L-F
JAK408 066 TOTX142L OPTICAL TERMINAL TOTX142L-F
CP501 068 B11B-PH-KS CONNECTOR WAFER 11P
CP606 068 B14B-PH-KS CONNECTOR WAFER 14P
CP304,305 068 B15B-PH-KS CONNECTOR WAFER 15P
CP201 068 B2B-PH-KS CONNECTOR WAFER 2P
CP406,502,607 068 B6B-PH-KS CONNECTOR WAFER 6P
CP603 068 B7B-PH-KS CONNECTOR WAFER 7P
501 X-1496 PCB ASSY (POWER)
LF101 021 TRL-356 LINE CHOKE COIL LF-2217 150uH
T101 022 T-1075N02 SUB TRANSFORMER
Q102,204 032 TC3708-ST TRANSISTOR 2SC3708AA-ST
D216,217 034 KBL406 POWER DIODE 400V6A
D214,215,218 034 KBP206 POWER DIODE 200V6A
ZD101,102 034 MTZJ3.9B ZENER DIODE 3.9V
D101-105,205,207,210,212,213,219-221 034 T1N4004-TB DIODE 1N4004-F
ZD104 034 TRD12JST1 ZENER DIODE 12V
ZD103 034 TRD24JST1 ZENER DIODE 24V
ZD105,106 034 TRD5.1JST1 ZENER DIODE 5.1V
F102* for 230V 036 5ST1.6-R FUSE 250V1.6A
F102* for 120V 036 5ST2-R FUSE 250V2A
F101 036 5ST315-R FUSE 250V314mA
F203-206 036 5ST4-R FUSE 250V4A
C212,221 041 TUTES1C102-7TS ELECTROLYTIC CAPACITOR 16V1000uF
C223 041 TUTES1E470-7TF ELECTROLYTIC CAPACITOR 25V47uF
C238-243,253,254,255 041 TUTES1H010-7TF ELECTROLYTIC CAPACITOR 50V1uF
C104,107 041 TUTES1H220-7TF ELECTROLYTIC CAPACITOR 50V22uF
C112 041 TUTES1J471-7TS ELECTROLYTIC CAPACITOR 63V470uF
C230-237 041 UTWE1E472-7 ELECTROLYTIC CAPACITOR 25V4700uF
C213,244-252 043 TC50V104 CERAMIC CAPACITOR 0.1uF
C101-103 044 3549472109 AC CAPACITOR 400V0.0047uF
C214-220,222,224,225,226,228,229 044 BQ014E0103J M.P. CAPACITOR 100V0.01uF
R208 053 CR14-101J-A CARBON RESISTOR 1/4W 100
R211,216 053 CR14-102J-A CARBON RESISTOR 1/4W 1K
R217-220 053 CR14-103J-A CARBON RESISTOR 1/4W 10K
R104,105 053 CR14-221J-A CARBON RESISTOR 1/4W 220
R109,212,215 053 CR14-222J-A CARBON RESISTOR 1/4W 2.2K
R102 053 CR14-470J-A CARBON RESISTOR 1/4W 47
R213 053 CR14-472J-A CARBON RESISTOR 1/4W 4.7K
R106-108 053 CR14-4R7J-A CARBON RESISTOR 1/4W 4.7
RLY101 063 DG1U-12 RELAY DG12D1-O(M)-2
CT101 068 4428503746 CONNECTOR WAFER 3P
CP404 068 B14B-PH-KS CONNECTOR WAFER 14P
CT103,104,CT100,CTA101,102,CTS101,102 068 B2P3-VH CONNECTOR WAFER 2P
CT203 068 B2P-VH CONNECTOR WAFER 2P
CP204 068 B4B-PH-KS CONNECTOR WAFER 4P
016 X-1496B01-03 PCB ASSY
11

Parts List 10/10 RSP-1069
SYMBOL PARTS NO. DESCRIPTION
CP302 068 B5B-PH-KS CONNECTOR WAFER 5P
CP106 068 B7B-PH-KS CONNECTOR WAFER 7P
CP211 068 B8B-EH CONNECTOR WAFER 8P
CP604 068 B8B-PH-KS CONNECTOR WAFER 8P
505 HSRSP-1069 HEAT SINKER ASSY (with 501 X-1496-01)
017 WQ3-05B00 HEAT SINKER BOARD
IC202,203.205 031 KIA278R05PI IC KIA278R05PI/P (REG.+5VDC)
IC204 031 NJM317F IC (REGULATOR)
IC201 031 NJM7805FA IC (REG. +5VDC) KIA7805AP
IC208,209 031 NJM7812FA IC (REG. +12VDC) KIA7812AP
IC207 031 NJM7815FA IC (REG. +15VDC) KIA7815AP
IC206 031 NJM7915FA IC (REG. -15VDC) KIA7915PI
011 FP-613A-B BLACK PANEL ASSY
011 FP-613A-S SILVER PANEL ASSY
011 TH3-01B00 H/S PANEL
012 C-4844B01 KNOB 10Φ(BLACK)
012 C-4844B02 KNOB 10Φ(SILVER)
012 C-4845B01 KNOB 33Φ(BLACK)
012 C-4845B02 KNOB 33Φ(SILVER)
012 RV4-09A00 PUSH BUTTON 14Φ(BLACK)
012 RV4-09A01 PUSH BUTTON 14Φ(SILVER)
012 TB3-18A00 TACT BUTTON 16 KEY (BLACK)
012 TB3-18A01 TACT BUTTON 16 KEY (SILVER)
014 C-4723B05 UPPER COVER
019 4TQF-17B KNOB RING (RED) 33Φ
019 4TQF-17B#2 KNOB RING (BLU) 33Φ
019 4TSH-19#2 PLASTIC FOOT 50ΦBLACK
019 C-4714A00 POWER KNOB RING 14Φ(BLACK)
019 C-4714A01 POWER KNOB RING 14Φ(SILVER)
022 T-1108N04 POWER TRANSFORMER
034 SEL1124R LED (RED) 1X5
034 SEL1E24W LED (BLU) 1X5
061 C-4838A00 ROCKER SWITCH SR1N6BB
069 C-4629A01 AC 2P INLET 6102.3100 (WIRING)
072 C-4621A03 AC CORD SET (SJT AWG16) for USA
072 C-4622A02 AC CORD SET for AUSTRALIA
072 C-4623A02 AC CORD SET for UK
072 C-4624A03 AC CORD SET for EUROPE
072 C-4738A01 PIN PLUG CORD AU
072 C-4786A00 COMPUTER I/O CABLE (4-P)
081 WK3-05A00 INSIDE CARTON
081 WK3-06A00 SHIPPING CARTON
081 ZE-204 ETHAFOAM MOULDING
082 OMRSP-1069 OWNER'S MANUAL
092 RR-1060 REMOTE UNIT
O T H E R S
HEAT SINK ASSEMBLY
12

RSP-1069
SYMBOL PART
S
DESCRIPTION
Addendum List for Black and Silve
r
Panel Assy is included:
Panel Window
Side Cap
Knob Ring
Tact buttons
LED
011 FP-613A-B BLACK PANELASS
Y
011 FP-613A-S SILVER PANELASS
Y
011 TH3-01B00 H/S PANEL H109
012 C-4844B01 KNOB 10F (BLK)
012 C-4844B02 KNOB 10F (SLV)
012 C-4845B01 KNOB 33F NO LINE (BLK)
012 C-4845B02 KNOB 33F NO LINE (SLV)
012 RV4-09A00 PUSH BUTTON 14F (BLK)
012 RV4-09A01 PUSH BUTTON 14F (SLV)
012 TB3-18A00 TACT BUTTON 16 KEY (BLK)
012 TB3-18A01 TACT BUTTON 16 KEY (SLV)
034 SEL1124
R
LED (RED) 1X5
034 SEL1E24W LED (BLU) 1X5
13

RSP-1069 Main U
pg
rade Software Procedure
1. Execute nec flash upgrade.exe then will be created new folder as "C:\Program Files\nec upgrade".
2. Connect upgrade cable between RSP-1069 and PC
3. Set upgrade enviornment on OSD Menu
"OSD Main Menu-> Other -> Main U
pg
rade ->
y
es "
p
ress Enter
.
4. Copy Object file(.HEX) and INI file (main_rsp1069.ini) file, and save it in temporary same folder.
5. Execute nec_flash_upgrade.exe from Program list.
6. Load INI file by pushing "Load INI" button.
load main_rsp1069.ini for RSP1069 main micom.
7. Load HEX file by pushing "Load HEX" button.
load rsp1069vxxx_xxxxxx.hex for RSP1069 main micom.
14

8. After pushing "COM" button placed at "HEX" button upper, and choosing COM1~COM4.
(connecting PC's COM1 ~COM4 and cable).
>>>>>
9. Push "Connect" button placed at program's below left side,and BaudRate placed next to "COM"
button will be displayed if the above process is OK.
10. Click "Write" button placed next to "Connect" button .
11.
12. AC Power "OFF" and "ON" again to save.
After finshing "Write", then the total writing time
will be displayed.
15

RSP-1069 Scalar (VIDEO) Upgrade Software Procedure
1. Execute nec flash upgrade.exe then will be created new folder as "C:\Program Files\nec upgrade".
2. Connect upgrade cable between RSP-1069 and PC.
3. Set upgrade enviornment on OSD Menu
"OSD Main Menu-> VIDEO/HDMI -> Video Upgrade -> yes " press Enter.
4. Copy Object file(.HEX) and INI file (video_scaler.ini) file, and save it in temporary same folder.
5. Execute nec_flash_upgrade.exe from Program list.
6. Load INI file b
y
p
ushin
g
"Load INI" button.
load video_scaler.ini for video scaler CPU of the RSP-1069.
7. Load HEX file by pushing "Load HEX" button.
load scaler1058vxxx.hex for video scaler CPU of the RSP-1069.
16

8. After pushing "COM" button placed at "HEX" button upper, and choosing COM1~COM4.
(connecting PC's COM1 ~COM4 and cable).
>>>>>
9. Push "Connect" button placed at program's below left side,and BaudRate placed next to "COM"
button will be displayed if the above process is OK.
10. Click "Write" button placed next to "Connect" button .
11
12 AC Power "OFF" and "ON" again to save.
After finshing "Write", then the total writing time
will be displayed.
17

RSP-1069 DSP Upgrade Manager V1.0.0 Procedure
Install the “DSP Upgrade Manager_V100” program which is provided by ROTEL in the
computer. And connect RS232 Cable with DB-9 to RJ45 terminations.
1. Click “Open File” -> select Upgrade file 2. Confirm Port and Baud Rate setting. Then, click “Next”
button. (ref: RSP-1069 Baud Rate is 38400)
3. Communication port initializing ……
Wait. Then click “Next” button.
5. Click “Next” button.
11. Finish.
6. The device’scurrentversion is displayed. Click
“Next” button.
8. The sector is erased. The flash is writing
automatically. Wait a while.
4. Press the “Next” button for starting the procedure.
7.The sectoris erasing. Wait a moment.
10. Completed all procedure. Power off and
on again on main switch of rear. Click “Exit”
button to finish the “Upgrade Manager”
program.
9. If the writingandchecksum is OK, wait a
nextprocedure.
18

<MEMO 1>
RSP-1069 will get FL full illumination from "Direct" and "Always ON" setting
Press "2CH" and "MUTE" of front panel while turn on the rear panel master
power switch. When release the lighting, press STANDBY switch or master
power switch.
Light-up ALL FL segments to check:
on Power Option menu.
19

<MEMO 2>
20
