Rotronic HygroClip2 ADVANCED User manual

© 2017 ROTRONIC AG Bassersdorf Switzerland
RMS Digital Input Module

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 2 of 22
Table of Contents
1Overview.................................................................................................................................................3
1.1 RMS System Overview........................................................................................................................3
1.2 Device Overview..................................................................................................................................4
1.3 RMS Digital Input Module ....................................................................................................................5
1.4 Power Supply.......................................................................................................................................5
1.5 Inputs / Outputs....................................................................................................................................6
1.6 RTCC (Real Time Clock Calendar)......................................................................................................6
1.7 Data Logging........................................................................................................................................6
1.8 Operating and display elements...........................................................................................................7
1.9 Interface...............................................................................................................................................7
1.10 MODBUS communication protocol.......................................................................................................8
2Dimensions ............................................................................................................................................9
3Installation............................................................................................................................................10
4Electrical Connections........................................................................................................................11
4.1 Connection of external power supply.................................................................................................11
4.2 Connection of digital inputs................................................................................................................11
4.3 Switch between Input / Reed .............................................................................................................11
4.4 Behavior of the inputs ........................................................................................................................12
4.5Behavior in battery operation .............................................................................................................12
5Operation..............................................................................................................................................13
5.1 Default Configuration .........................................................................................................................13
5.2 Configuration of the LAN Devices with RMS-CONFIG.......................................................................13
5.3 Integration in the RMS-WEB Software...............................................................................................15
5.4 Function Overview .............................................................................................................................17
6Maintenance.........................................................................................................................................18
6.1 Battery Replacement..........................................................................................................................18
7Firmware Update..................................................................................................................................18
8Technical Specifications.....................................................................................................................19
9Additional Documents.........................................................................................................................21
10 Document Version...............................................................................................................................22

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 3 of 22
Scope:
This manual is valid for the RMS digital input module from firmware version V1.x. The low-order digit of the
manual is updated with each new release.
1 Overview
1.1 RMS System Overview
The Rotronic Monitoring System (RMS) is a network comprising various devices and the RMS server software.
The software is the heart of the system. It collects all measured data of the devices and saves it in the database.
The individual devices work as input modules (data loggers) and as output modules (displays, analog outputs,
switched outputs). The user can view the system data at any time on a PC, laptop or smart phone.
Figure 1: Schematic diagram of the RMS with the server software and database at the heart

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 4 of 22
1.2 Device Overview
All devices can be configured as wanted as modules of the system. The following table shows all basic types of
the RMS devices. Almost all modules
1
have the following options:
Interface: Ethernet / Wireless
Housing: Wall housing / DIN top hat rail housing
Display Module
The display module can show any values from the
RMS network. Humidity, temperature and switch
states can be configured per software.
Standard Logger
Records the measured data of the digital HygroClip
HCD or other RMS probes. Stored in the ring
memory, the data are then sent to the server
software.
Output Module
Provides two analog voltage or current outputs or is
also available as variant with two solid-state relays in
order, for example, to switch alarm lamps.
Input Module
Records voltage or current signals from analog
devices such as particle counters, flow transmitters
or CO2 probes. For example:
HF5 transmitter (humidity & temperature)
AF1 transmitter (air flow)
CO2 transmitter (CO2)
PF4 transmitter (differential pressure)
Temperature Logger
The loggers can be equipped with various
temperature sensors (NTC, Pt100, Pt1000 or K-
element). This offers highest flexibility in use.
Mini Logger
A temperature logger with integrated or remote NTC
sensor. Instead of a temperature sensor, it is also
available with a switch input in order, for example, to
monitor door contacts.
Gateway
The gateway is the connecting element between
Ethernet and wireless network and forwards the data
flow from the loggers to the data centre.
1
Except for the Mini Logger

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 5 of 22
1.3 RMS Digital Input Module
The digital input module saves all measured data based on event and sends it to the database via Ethernet.
The minimum signal pulse length is 100ms. Should the connection be lost, the module stores the data on the
internal memory to protect data integrity and fills up the data gaps when the connection has been restored. The
device has a battery so that logging of measured data is also ensured in the event of a failure in the external
power supply.
The device provides the following basic functions:
oTwo input channels (logic level 5 ... 24V or reed contacts)
oData logging of up to 75,000 measured values
oTransfer of the recorded data to the RMS software
oFirmware update
1.4 Power Supply
The digital input module has the following three power supply variants:
Two 3.6 V lithium thionyl chloride AA batteries
The power supply of the batteries suffices to carry out measurement and data storage and to operate
the wireless interface. Devices with an Ethernet interface must also have one of the following power
supplies.
24 VDC ±10 % / <100 mA
2
via terminals (V+ / V-)
Power over Ethernet (PoE), per standard IEEE 802.3af, Class 1
Note on the batteries:
The AA batteries are lithium thionyl chloride batteries available in the industrial trade. All RMS input modules
are designed for this type of battery. Only batteries of the same type or with identical characteristic values may
be used as replacement batteries.
1.4.1 Type of Battery
Battery Specifications
Article
RMS-BAT (please see for Details www.rotronic.com)
Type
Li-SOCl2
Capacitance
2100 mAh
Voltage
3.6 V
Dimensions
AA (50.3mm x Ø14.55mm)
2
Power supply requirements: 24 VDC ±10 % / >4 W nominal / <15W limited power source

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 6 of 22
1.5 Inputs / Outputs
Two channels are available for measuring a digital Boolean value each. The two inputs are switched either via
a logic level of 5 ... 24V or a reed contact. When the input status is changed, the device is activated, and
measured values are transferred to the database. This means the measurement of the digital inputs is event
triggered. The following table lists the main types of RMS devices:
Data Loggers for Interchangeable Probes
RMS-LOG-L
Data logger, external probe, LAN
RMS-LOG-868
Data logger, external probe, 868 MHz
Temperature Data Loggers
RMS-MLOG-T10-xxx
Data logger, external probe, 1 x NTC, 868 / 915 Mhz
RMS-LOG-T-xxx
Data logger, internal probe, 1 x NTC, 868 / 915 Mhz
Analog Input Modules
RMS-MADC-xxx-A
Data logger, 1 x analog input, 868 / 915 Mhz , 0(4)…20 mA
RMS-MADC-xxx-V
Data logger, 1 x analog input, 868 / 915 Mhz , 0…10 V
RMS-8ADC-L-R-A
8 x analog input, LAN, mounting on DIN top hat rail, 0(4)…20 mA
Digital Input Modules
RMS-DI-L-R
Data logger, 2 x digital input, LAN, mounting on DIN top hat rail
Digital Output Modules
RMS-DO-L-R
2 x digital output, LAN, mounting on DIN top hat rail
1.6 RTCC (Real Time Clock Calendar)
The device has a real time clock calendar. The time is synchronized continuously when connected to the server.
1.7 Data Logging
The values of every measurement are saved in the memory with the time stamp. At a measurement interval of
one minute, it is possible to save data of more than one month, which corresponds to 70,000 measured values.
When the ring memory is full, the oldest values are overwritten. In case of server or network failures, lost of
measured data can only happen after one month.
The recording of measured data is always active when the device is integrated in a RMS-WEB system and
thus continuous measurements are carried out.
Following measured values are saved:
- time stamp
- actual status of the digital inputs

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 7 of 22
1.8 Operating and display elements
The device has a button and a multi-color LED for operation and display of the operating state. The button is
used during commissioning or for switching the device off in battery operation. The device flashes only if the
operating state changes, or if the push button is pressed briefly. The displayed device state is updated for
each event. In order to prolong the operating time in the battery operation, the LED flashing can be
deactivated.
Trigger
Action
LED
Pairing
1s
Confirms pairing
N x orange, the indicator flashes while the
paring request is running
Device status check
1s
At "online" operation
1 x green, measurement & data transmission
succesful
1x orange, measurement succesful, data
transfer failed
1x red, low battery (only by battery powered)
Automatic
At status change from
the input
1.9 Interface
The device is operated completely via the LAN interface.

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 8 of 22
1.10 MODBUS communication protocol
For direct connection to other systems, the device provides a MODBUS TCP server. Following data is
available via MODBUS communication:
Description
Details
Protocol
MODBUS TCP
TCP Port
502
Connection timeout:
When TCP connection is open and for more than 30 seconds no communication is performed, the device
automatically closes the TCP connection. In case of a communication interruption, this prohibits the socket from
being blocked.
1.10.1 MODBUS register
Device data (FC4: Read Input Registers)
Address
Number
Parameter
Data type
Comment
10000
16
Digital inputs
Unsigned 16 Bit
Bit 0 = Input 1 / Bit 1 = Input 2
Measurement values (FC2: Read Discrete Inputs)
Adresse
Number
Parameter
Data type
Comment
30000
2
Serial number
Unsigned 32 Bit
SN in Hex: e.g. 01ACCBE1 = 28101601

If no communication is performed for more than 30 seconds, the device automatically closes the
TCP connection.

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 9 of 22
2 Dimensions
Figure 2: Side view from left of DIN rail housing Figure 3: Front view of DIN rail housing

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 10 of 22
3 Installation
The wall mounting is carried out using a standard DIN rail (EN 50022 / 35mm x 7.5mm). The rail is attached to
the wall or in the control cabinet. Then just plug in the device on the DIN rail.
Figure 4: Wall mounting Figure 5: Network cable connection
When plugging the network cable into the device, make sure it clicks in audibly.
Note!
Please remove this yellow stick to turn on the battery supply. If you don’t remove this stick, you will not be
able to record data if the power supply is interrupted.
Figure 6: Batterie Stick

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 11 of 22
4 Electrical Connections
4.1 Connection of external power supply
Marking
Function
V+
Power Supply +
V-
Power Supply -
4.2 Connection of digital inputs
Marking
Function
D-IN1+R
Input 1 Reed
D-IN1-
Input 1 GND
D-IN1+
Input 1 Input (+ 5-24VDC)
D-IN2+R
Input 2 Reed
D-IN2-
Input 2 GND
D-IN2+
Input 2 Input (+ 5-24VDC)
4.3 Switch between Input / Reed
There are 2 options for inputs:
1. Logical voltage level
User has the possibility to use the input with 5 ... 24VDC as the high level of the digital input.
2. Reed contact
The two input contacts are connected, e.g. with a relay.
Selection between these two options can be carried out via the software (RMSConfig or Webservice). The two
digital inputs can be configured independently.
D-IN1+
D-IN1-
D-IN1+R
D-IN2+
D-IN2-
D-IN2+R
IN1 Reed
contact-
contact +
IN1 Input
5…24V
GND
IN2 Reed
contact -
contact +
IN2 Input
5…24V
GND

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 12 of 22
4.4 Behavior of the inputs
The measurement of the digital inputs are event-based, which means that the device transmits data to the
server only when a voltage level change is detected or the web service requests it at the set interval.
If the inputs are frequently changing, the maximum allowed switching frequency is 0.833 Hz, or a change can
be detected every 1.2s.
The inputs are independent, always active and register changes via the trigger. The device is not suitable for
pulses shorter than 1.2 seconds.
For the detection of the single pulses, the pulse must be at least 100ms long. The transfer to the web service
takes place with 2 different time stamps (1s offset).
Since, especially when using low voltages such as Reed, the input cable length shall be taken into account
(refer to the technical data).
4.5 Behavior in battery operation
The batteries serve to supply the device with power in the event of a failure in the external power supply. The
functionality of the device is restricted in battery mode. The device continues to measure and records all data
in the internal memory. The device cannot communicate via the Ethernet interface.
Lithium batteries of the type AA with 3.6 V are used, per section 1.4.1. Make sure they are inserted correctly.
The poles are marked on the battery and in the battery compartment.

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 13 of 22
5 Operation
This section describes all manipulations necessary for operation.
5.1 Default Configuration
The devices are configured ex works. All devices with a LAN connection have a standard address for the server
with the RMS server software. The standard server corresponds to the Rotronic Cloud. Devices that need to
send the data to a different server need to be reconfigured.
LAN Devices
TCPIP configuration: The DHCP server must be on, the configuration is obtained automatically.
RMS-WEB Server URL: http://rms.rotronic.com/wService/wService3.DeviceService.svc
5.2 Configuration of the LAN Devices with RMS-CONFIG
If you do not want to connect the device to the Rotronic Cloud, the server must be configured in the device.
Connect the device to the local network as described in section 3 . Start the RMS configuration
software.
Search for the device under Device > Search > Network Device. The software finds all RMS devices
in the local network.
Enter the host (server address) and the URL of the software services under Settings.
Finish configuration with "Write".

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 14 of 22
Once they have been configured with the correct server address, the devices can then be integrated into the
server software. Details are described in the manual E-SM-RMS-WEB.

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 15 of 22
5.3 Integration in the RMS-WEB Software
To integrate the device, port 80 must be enabled in your network and a DHCP server must assign the IP
address to the device. The device must be able to reach the server with the RMS server software or the
Cloud.
The devices can also be given a static IP address if there is no DHCP server available in the network.
Integration of the device (Pairing) in 6 Steps
1
If you do not want to connect the device to the Rotronic Cloud, the server must be configured in
the device.
Connect the device to the local network and start the RMS configuration software.
Search for the device under Device > Search > Network Device. The software finds all
RMS devices in the local network.
Enter the host (server address) and the URL of the software services under Settings.
Finish configuration with “Write”.
2
Log into the RMS software / Cloud. Select Extras > Setup > Devices > New LAN Device
3
Enter the serial number of the device. The device flashes orange.
4
Press the button on the device briefly. The device stops flashing.

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 16 of 22
5
Configure the device.
6
Finish configuration.
You can find details in the instruction manual for the RMS server software: E-SM-RMS-WEB

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 17 of 22
5.4 Function Overview
Overview of the main software functions of the device
► Digital inputs
The device detects status changes at the input and sends these
to the RMS-WEB software.
The states can also be queried via Modbus TCP.
► Discovery
With Discovery it is possible to find devices in the subnet with
the RMS configuration software irrespective of their IP
configuration and to change their settings.
► IP configuration
The devices can have static or dynamic IP configurations. It is
recommended that you use a dynamic IP configuration
whenever possible.
If fixed IPs are used, the network topology must be considered
exactly.
► RMS Web Server settings
Every device has the server address and software path of the
RMS server software stored in it in order to build up
communication with the RMS server software.
The two parameters can be set with the RMS configuration
software:
Host: Address of the server with the RMS software
Server path: Server path where the server software is
installed.
► Audit Trail
The device stores events when changes are made to the
configuration.
► Save measured data
The measured values of every measurement are saved in the
internal ring memory (75,000 measured values). If the data
cannot be sent to the server software directly, they are kept in
the device and then sent later as soon as the connection to the
server software has been restored. Measurements are still
carried out in case of PoE power failure.
► Battery mode
If the external power supply (24 VDC / PoE) fails, the device
runs in battery mode. Measurements are still carried out at the
set interval and the data saved in the ring memory (75,000
measured values).
►Firmware update
The firmware of the device can be updated directly via the RMS
server software.

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 18 of 22
6 Maintenance
Even the best technology needs regular maintenance. This chapter describes the most important points.
6.1 Battery Replacement
The batteries last 1.6 years with 1 minute event interval, and 3 years with a 5 minute event interval. The device
shows automatically when the battery needs to be replaced.
LED flashes red
System message in the RMS server software
The following steps are necessary to replace the battery:
Press the front flap of the housing, which is labeled with Rotronic, with a very narrow object.
Remove the old battery and insert a new one
The time setting of the data logger is synchronized automatically after the battery replacement.
Important:
The battery life depends on the ambient temperature. Low or high temperatures can lead to a shorter
battery life.
7 Firmware Update
The firmware can be updated with the RMS server software. Firmware updates are available for downloading
on the Rotronic website.

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 19 of 22
8 Technical Specifications
Device specific data
Device type
RMS digital input module
Number of inputs
2 independent digital inputs
Input frequency
Max: 0.833Hz, btw. 1.2s
Pulse detection time
Min: 100ms
Input circuit
Logic levels: 0V / 5-24V
Triggering-threshold: ~3,77V
Current consumption: <1mA
Reed circuit
Max. load at input: 100kΩ
Max. input cable length
<3m
General data LAN devices
IP protection class
IP20
Fire protection klass
UL94-V0
Range of application
-40…70 °C / 0…100 %RH, Not condensing
Storage and transport conditions
-40…30 °C / 0…90 %RH
Max. altitude of operation
2000 m.a.s.l.
Data memory
75‘000 measured values
Interfaces
Ethernet
Cable length ethernet
<30m min. Cat. 5
Power Supply
Supply voltage
24 VDC ±10 % / <100 mA3
PoE: 802.3af-2003, Class 1
Battery
Polarity protection
Yes
Current consumption
<100 mA
Battery life
~2 years (at 23 °C)
3
Power supply requirements: 24 VDC ±10 % / >4 W / limited power source

RMS Digital Input Module
E-M-RMS-DI-V1_1.docx
Instruction Manual
© 2018 ROTRONIC AG Bassersdorf Switzerland Page 20 of 22
Start Time and Measurement Interval
Start time
10 s (typical)
Logging frequency
Event triggered & interval (10 s to 15 min)
Housing Specifications
Housing material
PC (Polycarbonate)
Dimensions
108 x 89,7 x 62,2 mm
Weight
200 g
Conformity
EMV-directives
2014/30/EU
LVD- directives:
2014/35/EU
EN 61326-1 IEC 61326-1
EN 61000-6-2 IEC 61000-6-2
EN 55011 IEC CISPR 11
EN 55032 IEC CISPR 32
EN 61010-1 IEC 61010-1
Performance criterion: www.rotronic.com
RoHS-directives:
2014/65/EU
EN 50581
Soldering material: Lead free
FDA / GAMP
directives
FDA CFR21 Part 11 / GAMP5
