Rowlett Premier User manual

Model:
Premier/Regent/Esprit Toasters
Toaster
Instruction manual
Rowlett Toaster IM_UK_A5_v1_20190904.indb 1 2019/9/4 17:41

2
UK
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• Caution: Hot surfaces!
• DO NOT touch the top and sides of the appliance when in use.
Danger of burns!
• DO NOT immerse the appliance in water.
• DO NOT obstruct or cover the appliance in any way when in
use.
• DO NOT insert any metallic objects in to the appliance when
connected to a power supply.
• DO NOT leave the appliance unattended during operation.
• Always switch off the appliance, disconnect the power supply
and allow to cool before cleaning or carrying out maintenance.
• Always switch off and disconnect the power supply to the
appliance when not in use.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a
Rowlett agent or a recommended qualified technician in order
to avoid a hazard.
• DO NOT use if damaged.
Rowlett Toaster IM_UK_A5_v1_20190904.indb 2 2019/9/4 17:41

3
UK
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children
unless they are older than 8 and supervised.
• Keep the appliance and its cord out of reach of child less than
8 years.
• This appliance is not intended to be operated by means of an
external timer or separate remote-control system.
• Fire hazard! Bread can burn! The appliance should
not come into contact or be covered with easily flammable
materials, like curtains, textiles, walls and the like. Always
ensure sufficient safety distance to flammable materials.
• This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
• Rowlett recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
Rowlett Toaster IM_UK_A5_v1_20190904.indb 3 2019/9/4 17:41

4
UK
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your Rowlett product.
Engineered for reliability, Rowlett toaster range enjoys huge success in pubs, restaurants, leisure outlets,
hotels, institutions and caring establishments. Select from a wide choice of Bread toasters available with
variable settings for toasting perfection.
Pack Contents
The following is included:
• Toaster
• Instruction manual
Rowlett prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your Rowlett dealer immediately.
Operation
Ejector lever
Slot selector knob
Power indicator light
Timer knob with
On/Off function
Crumb tray
Model: DA206
Toasting
1. Remove the appliance from the packaging. Make sure that all protective plastic film and plastic
coatings are thoroughly removed from all surfaces.
2. Ensure the Timer knob is set to ‘OFF’.
Note: There is no separate on/off switch on the toaster as it forms part of the
timer mechanism. Your toaster is “off” when the timer knob is set to “OFF”.
Ensure your toaster is plugged in before turning it on.
Rowlett Toaster IM_UK_A5_v1_20190904.indb 4 2019/9/4 17:41

5
UK
3. The slot selector knob is used to determine which slots are energised.
Note: All Rowlett toasters (excluding 2-slot toasters) have a slot selector knob
that enables you to control which slots are in use, saving on element wear and
electricity.
Choose how many slots you need and adjust the selector knob accordingly.
Slots are energised from the left.
4. Load bread into toaster with ejector lever up. Lower to toast. Do not use bread that is too thick.
5. Set the timer knob to desired time setting according to your taste. It is better to use 1 day old bread.
6. The power indicator light will illuminate and the timer will start.
7. Power will be automatically turned off shortly before the timer completes its task.
8. The toast can be removed immediately by using the ejector lever, or left in the machine to keep warm
for several minutes.
Cleaning, Care & Maintenance
Always switch off the appliance, disconnect the power supply and allow to cool
before cleaning or performing maintenance.
• If necessary wipe the exterior with a soft cloth and warm soapy water.
• Never use a scouring agent as this will scratch the finish.
• Dry thoroughly after cleaning.
Crumb Tray
• Periodically empty the crumb tray (located at the bottom of the appliance).
• Slide the tray out to empty.
• Slot back in securely when replacing the tray.
Notes on maintenance
• Bread containing fruit or nuts can be toasted but natural sugars present may cause them to stick to
the guard rails on your toaster. Such debris should not be left on the guard rails as it will char and
possibly smoke and can swell so as to damage the element.
• Elements wear out with use and it is impossible to predict their life as this is affected by the amount
and type of use and the quality of electrical supply. They can easily be damaged by careless handling.
Your toaster has been designed that should anything go wrong all major components such as
elements and switches can easily be replaced.
• Repairs or replacement of components should be undertaken only by a competent electrician.
• All components and fitting instructions can be obtained from your supplier.
Rowlett Toaster IM_UK_A5_v1_20190904.indb 5 2019/9/4 17:41

6
UK
Troubleshooting
If your Rowlett appliance develops a fault, please check the following table before making a call to the
Helpline.
Fault Probable Cause Solution
The unit is not working The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call Rowlett agent or qualified technician
Fuse in the plug has blown Replace the plug fuse
Power supply Check power supply
Internal wiring fault Call Rowlett agent or qualified technician
Heating element has expired Call Rowlett agent or qualified technician
Technical Specifications
Model Voltage Power Number of
Bread slot
Dimensions
H x W x D mm Weight
DA205 220-240V~, 50/60Hz 1800W 4 210 x 410 x 210 6.0kg
DA206 220-240V~, 50/60Hz 2600W 6 210 x 500 x 210 8.0kg
DR061 220-240V~, 50/60Hz 1000W 2 200 x 310 x 210 4.3kg
DR063 220-240V~, 50/60Hz 1000W 2 200 x 310 x 210 4.3kg
DR065 220-240V~, 50/60Hz 1000W 2 200 x 310 x 210 4.3kg
CY995 220-240V~, 50/60Hz 1000W 2 200 x 310 x 210 4.3kg
DR066 220-240V~, 50/60Hz 1800W 4 200 x 400 x 210 5.75kg
DR068 220-240V~, 50/60Hz 1800W 4 200 x 400 x 210 5.75kg
DR070 220-240V~, 50/60Hz 1800W 4 200 x 400 x 210 5.75kg
CY994 220-240V~, 50/60Hz 1800W 4 200 x 400 x 210 5.75kg
DR071 220-240V~, 50/60Hz 2600W 6 200 x 530 x 210 7.2kg
DR073 220-240V~, 50/60Hz 2600W 6 200 x 530 x 210 7.2kg
DR075 220-240V~, 50/60Hz 2600W 6 200 x 530 x 210 7.2kg
CY996 220-240V~, 50/60Hz 2600W 6 200 x 530 x 210 7.2kg
DL277 220-240V~, 50/60Hz 1800W 4 210 x 400 x 210 6.5kg
DA221 220-240V~, 50/60Hz 1800W 4 210 x 400 x 210 6.5kg
DA222 220-240V~, 50/60Hz 1800W 4 210 x 400 x 210 6.5kg
DA223 220-240V~, 50/60Hz 1800W 4 210 x 400 x 210 6.5kg
DL278 220-240V~, 50/60Hz 2600W 6 210 x 500 x 210 8.1kg
Rowlett Toaster IM_UK_A5_v1_20190904.indb 6 2019/9/4 17:41

7
UK
Electrical Wiring
This appliance is supplied with a 3 pin, moulded, BS1363 plug and lead, with a 13 amp fuse as standard.
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible for
waste disposal in your area.
Rowlett parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
Rowlett products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of Rowlett.
Every effort is made to ensure all details are correct at the time of going to press, however, Rowlett reserves the right to
change specifications without notice.
Rowlett Toaster IM_UK_A5_v1_20190904.indb 7 2019/9/4 17:41

DECLARATION OF CONFORMITY
•Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement •
Gerätetyp •
Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
2 Slot 4 Slot 6 Slot
Premier Stainless Steel
Regent
Quartz
Grey
Jet Black
Traffic Red
White
Esprit
Chrome
White
Jet Black
Traffic Red
Model • Modèle • Modell • Modello • Modelo • Malli 2 Slot 4 Slot 6 Slot
Premier DA205 DA206
Regent
DA222
DA221
DA223
DL277 DL278
Esprit
CY995 CY994 DR071
DR061 DR066 DR073
DR063 DR068 DR075
DR065 DR070 CY996
Application of Council Directives(s)
Toepassing van Europese Richtlijn(en) • Application de la/des
directive(s) du Conseil • Anwendbare EU-Richtlinie(n) •
Applicazione delle Direttive • Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do Conselho
Low Voltage Directive (LVD) 2014/35/EC
EN 60335-1:2012 +A11:2014 +A13:2017
EN 60335-2-9:2003 +A1:2004 +A2:2006
+A12:2007 +A13:2010 +AC:2012
EN 62233:2008
Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to Directive
2011/65/EU
Producer Name • Naam fabrikant • Nom du producteur • Name
des Herstellers • Nome del produttore • Nombre del fabricante •
Nome do fabricante
Buffalo
Producer Address • Adres fabrikant • Adresse du producteur •
Anschrift des Herstellers • Indirizzo del produttore • Dirección del
fabricante • Morada do fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
42 North Point
Business Park
New Mallow Road
Cork
Ireland
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and
Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus Ich,
der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und
Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati. El
abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y
estándar(es) arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)
Directiva(s) e Norma(s)
4th September 2019
Ashley Hooper
Date • Data • Date • Datum • Data • Fecha • Data
Signature • Handtekening • Signature • Unterschrift
Firma • Firma • Assinatura
Full Name • Volledige naam • Nom et prénom • Vollständiger Name •
Nome completo • Nombre completo • Nome por extenso
Position • Functie • Fonction • Position • Qualifica • Posición • Função Technical & Quality Manager
Rowlett Toaster IM_UK_A5_v1_20190904.indb 8 2019/9/4 17:41

UK 0845 146 2887
NL 0800 – 29 1 29
040 – 2628080
FR 0800 - 29 2 29
01 60 34 28 80
DE 0800 – 1860806
IT N/A
ES 901-100 133
PT [email protected]
Rowlett Toaster IM_UK_A5_v1_20190904.indb 9 2019/9/4 17:41

Rowlett Toaster IM_UK_A5_v1_20190904.indb 10 2019/9/4 17:41

Rowlett Toaster IM_UK_A5_v1_20190904.indb 11 2019/9/4 17:41

Rowlett Toaster IM_UK_A5_v1_20190904
Rowlett Toaster IM_UK_A5_v1_20190904.indb 12 2019/9/4 17:41
