ROYAL
ENFIELD
OWNER’S
MANUAL
BS VI-2022

Royal Eneld Support
1800 - 210 - 0007
1. Roadside Assistance
2. Product Update
3. Feedback
4. Dealer Locator
RoyaleneldSupport support@royaleneld.com www.royaleneld.com
Download the ROYAL ENFIELD APP and explore more
To access dealer details scan the QR code

READY. SET. SCRAM.
Conceived on our LS410 platform, SCRAM is a scrambler with an o-road pedigree. Bold & Playful - Lively & Engaging, it is nimble to
ride, from trails to alleyways. Always ready for what comes next; without a second thought. Living life on an instinct, spontaneous &
restless SCRAM 411 is all-ready to take it on.
While the Scram is all-ready, this Owner’s Manual prepares you to be ready before you set out to Scram. It thoroughly covers
features, capability, operation of the controls and quick xes. For the best health and performance of your motorcycle, we highly
recommend that you maintain it as per the schedule and procedures described in this manual. It should be considered a permanent
part of your motorcycle and should always be stored in it, even if it is subsequently sold.
For support and information, please call 1800 210 0007 anytime between 9 AM - 9 PM, any day of the week.
—Team Royal Eneld
FOREWORD

Royal Eneld Scram 411
2
All information in this manual is based on the latest product
information available at the time of publication. Due to
continuous improvements there may be discrepancies
between the information in this manual and your motorcycle.
Royal Enfield reserves the right to make production changes
at any time without prior notice and without incurring any
obligation to make the same or similar changes to motorcycles
previously built or sold. All images shown are for reference to
explain and need not to be exactly the same on the model you
own. Technical specifications are subject to change without
prior notice. "© Copyright 2021 Royal Eneld (A unit of Eicher
Motors Ltd.). All Rights Reserved. No part of this manual shall
be copied,distributed or otherwise dealt without the express
permission in writing of Royal Eneld"
Part No. RAM00385/A / Qty. 1000 / Oct. 2021 /
NOTE
Disclaimer
This motorcycle meets the BS VI emission norms.
NOTICE
1. Do not polish matt nished paint surface in your motorcycle as
it will increase the gloss level.
2. Wash the painted parts only with plain water and do not use any
strong solvents cleaning agents or detergents.
3. Scratches, if happens on the matt finish parts cannot be
touched up and corrected / removed.
4. Warranty is not applicable for any matt nished painted parts of
the motorcycle.
5. The heat resistance coated components such as silencer pipe,
exhaust etc.., shall not be wiped clean with oiled cloth as it can
generate smokewhen the vehicle is driven and also leave patch
marks.

Royal Eneld Scram 411 3
Personal and motorcycle information ........................................... 4
Technical specications.................................................................. 5
Recommended lubricants ............................................................. 11
Safety denitions........................................................................... 12
Motorcycle identication numbers .............................................. 13
Location of key parts .................................................................... 15
Operation of controls ....................................................................18
Pre-Operational checks ............................................................... 40
Safe & Happy riding ..................................................................... 41
Cargo & Accessories .................................................................... 44
Rules of the road ......................................................................... 46
Running in period......................................................................... 48
Warning indications & Safety systems......................................... 49
Starting......................................................................................... 53
Gear shifting, Riding & Stopping .................................................. 54
Parking ......................................................................................... 55
Environment care ............................................................................... 56
Periodical maintenance chart ............................................................. 59
Tools kit .............................................................................................. 66
First aid kit .......................................................................................... 67
Minor maintenance tips ..................................................................... 68
Long trip precautions ......................................................................... 87
Shock absorber ...................................................................................88
O roading ......................................................................................... 89
Washing procedure ............................................................................ 90
Storage precautions ........................................................................... 92
Trouble shooting ................................................................................ 93
Warranty terms & Conditions ............................................................ 97
Emission warranty ............................................................................ 100
Service / Maintenance record ........................................................... 105
Note .................................................................................................. 106
CONTENTS

Royal Eneld Scram 411
4
Name
Door No. / Street
Locality / Town
City Country
Contact Res : O :
Mobile : Email :
Licence No. Valid till :
Model Color :
Engine No.
VIN. No.
Tyre Make Front : Rear:
Tyre Nos. Front : Rear:
Battery make Battery No :
Sold by
Date of Sale
PERSONAL & MOTOR CYCLE INFORMATION

Royal Eneld Scram 411 5
Ignition system .......... Digital electronic ignition
Spark plug .................. Bosch - UR5CC
Start spark plug gap ... 0.7 to 0.8 mm
Engine type ............. Single cylinder, 4 Stroke, SOHC,
Air cooled, Fuel injection
Bore ......................... 78 mm
Stroke ...................... 86 mm
Displacement........... 411 cc
Compression ratio.... 9.5:1
Max power ............... 24.3bhp (17.88 kW) @ 6500 rpm
Max torque .............. 32 Nm @ 4250 ±250 rpm
ECU / Variable
Idle rpm.................... 1300 ±100 rpm
Starting system ....... Electric Start
Air lter element ........ Paper element
Lubrication ................. Wetsump
Engine oil capacity...... 2.3 l ( Initial ll only),
1.61.8 l (Subsequent rells)
TECHNICAL SPECIFICATIONS
IGNITION SYSTEM
ENGINE

Royal Eneld Scram 411
6
Clutch....................... Wet multi plates
Primary drive............ Gear
Primary ratio ............ 2.312:1
Gear box................... 5 Speed. Constant mesh
Gear Ratio
1st Gear ............... 1st 2.916:1
2nd Gear............... 2nd 1.833:1
3rd Gear............... 3rd 1.428:1
4th Gear............... 4th 1.173:1
5th Gear............... 5th 1.000:1
Secondary drive ....... 5/8” Chain & sprocket
Secondary ratio....... 2.533:1
Drive chain links....... 110 links
TECHNICAL SPECIFICATIONS
TRANSMISSION

Royal Eneld Scram 411 7
Frame ........................ Half duplex split cradle frame
Steering lock ............ In built
Suspension
Front................. Telescopic, 41 mm forks 190 mm travel
Rear................... Mono shock with linkage, 180 mm Rear
wheel travel
Brakes
Brake system..... Dual channel ABS
Front disc.......... 300 mm Dia disc.
Rear disc ........... 240 mm Dia disc.
Tyre size
Front ................. 100/90 - 19"
Rear ................... 120/90 - 17"
Tyre pressures
Solo
Front .................. 25 psi / 1.75 kg/cm2
Rear .................... 32 psi/ 2.25 kg/cm2
With pillion
Front .................. 27 psi/ 1.89 kg/cm2
Rear .................... 34 psi/ 2.39 kg/cm2
TECHNICAL SPECIFICATIONS
CHASSIS

Royal Eneld Scram 411
8
Fuel type.................. Unleaded gasoline
Ethanol content....... E10 or less
Minimum octane..... 91 RON (Research octane rating number)
or Higher
Fuel tank capacity*... 15 ± 0.5 l (approx*)
Low fuel warning* .... Fuel segment 1ST bar blinking.
4 ±0.5 l (approx*)
Dead stock ............... 0.5 l (approx*) (unusable fuel)
TECHNICAL SPECIFICATIONS
1. The use of petrol containing more than the specied ethanol
will cause the fuel tank corrosion & paint damage and will also
damage the rubber tubes in the fuel line as well.
2. It is recommended to use only unleaded petrol, as leaded petrol
will cause damage to the catalytic converter.
Fly wheel magneto ....... 221 W @ 1500 rpm
Generation ................... Alternator, lll Phase
System ......................... 12 V - DC
Battery ......................... 12 volt, 8 Ah VRLA
Head lamp ................... 12 V, H460/55 W - BULB
Tail lamp/ Brake lamp.. 12 V - 4/1 W LED
CAUTION
ELECTRICALS
* The above values are approximate and the actual capacity
will vary with each fuel tank.

Royal Eneld Scram 411 9
Licence plate illuminator............12 VLED
Front position lamp....................12 V -LED
Speedometer lamp.....................12 V -LED
Hi beam indicator ......................12 V - LED
Neutral lamp telltale ..................12 V - LED
Turn signal telltale .....................12 V - LED
Turn signal..................................12 V, 10 W * 4 Nos.
Horn ..........................................12 V, 2.5 A
Starter motor ............................12 V, 0.7 kW
Instrument cluster ....................Digital cluster with LCD
Malfunction indicator................12 V - LED
ABS indicator.............................12 V - LED
TECHNICAL SPECIFICATIONS
Using bulbs/electrical gadgets other than specied rating will lead to
overloading/erratic behaviour/premature failure of electrical system.
Modications or tments which are not approved by Royal Eneld,
will seriously aect the performance of the vehicle and will render
the warranty void.
WARNING

Royal Eneld Scram 411
10
Length............................. 2160 mm
Width ............................... 840 mm
Height .............................. 1165 mm
Wheel base ...................... 1455 mm
Ground clearance. ............ 200 mm
Saddle height .................... 795 mm
Kerb weight (90% fuel & oil) ...... 194 kg
Gross vehicle weight .................... 375 kg
DIMENSIONS WEIGHTS
1. Values/Dimensions mentioned above are for reference only.
2. In view of continuous improvements being done on our motorcycles, the specications are subject to change without prior notice.
3. Do not use the vehicle beyond the allowed gross weight. The suspension and tyres are designed to perform only to the maximum
gross vehicle weight.
TECHNICAL SPECIFICATIONS
NOTE

Royal Eneld Scram 411 11
Grade Grade Grade
SAE 15 W SO API SL Grade JASO MA 2
Semi synthetic
10 W/Fork oil
(Viscosity range 35) DOT 4
Rell: 2.3 l (approx).
Dry ll: 1.6 -1.8 l (approx).
(During oil & lter element replacement
in periodical maintenance).
Capacity Capacity Capacity
Oil level should be up to “MAX” level. Do not overll as it will aect the clutch functioning.
ENGINE OIL FRONT FORK OIL BRAKE FLUID
455 ml/leg Front/Rear:100 ml
RECOMMENDED LUBRICANTS
Recommendation subject to change without notice.
Using non recommended/In-correct oils, can cause serious damage to the moving parts, aect performance of the motorcycle and
void the warranty.
NOTE
NOTE
CAUTION

Royal Eneld Scram 411
12
SAFETY DEFINITIONS
Indicates important and useful messages for clearer understanding.
All images shown in subsequent pages are for reference to explain and need not to be exactly the same on the model you own.
NOTE
This message if disregarded will result in damage to the motorcycle.
CAUTION
Indicates a potentially hazardous situation. Disregarding this message will result in injury to rider or other persons.
WARNING
The information given under the titles: Warning, Caution and Note are for your safety and for the care and safety to your motorcycle and
others. Please read these carefully and if disregarded will result in injury to yourself or others and damages to the motorcycle.

Royal Eneld Scram 411 13
MOTORCYCLE IDENTIFICATION NUMBERS -DETAILS
The VIN is a 17 digit number punched on the right side steering head tube and in the information plate rivetted to the frame down tube.
Sample VIN :
Manufacturer's code
Engine Family Name
Engine Capacity
Model (Scram 411)
Transmission type
Type of Fuel System
Place of Manufacturing
(1Oragadam, 2Vallam Vadagal)
Year of Manufacturing
(L:2020 , M:2021 , N:2022)
Month Of Manufacturing
(AJan., HAug., KSep., NDec.)
Production serial no.
ME3 D 4 B X5 X X FXXXXXX
#ME3D4B5FXXXXXXXXX#
FRAME NUMBER

Royal Eneld Scram 411
14
ENGINE NUMBER
The engine number is punched on the left hand side crankcase. It is the means of identication of the engine and its production details.
Please do not tamper with the engine number as it is prohibited by law.
MOTORCYCLE IDENTIFICATION NUMBERDETAILS
D4A5X
FX
XXXXXXX
Engine family
Engine capacity
Type of cooling
Type of transmission
Fuel feed
Manufacturing plant
(0TVT. 10RG)
Year of manufacture
(2021 , M, 2022 , N, 2023 , P)
Month of manufacture
(AJan., HAug., KSep., NDec.)
Production serial number

Royal Eneld Scram 411 15
LOCATION OF KEY PARTS
11
13
3 5 7
6
1
2
89
4
12
10 1. Turn signal switch
2. Horn button
3. Rear view mirror left side
4. Head lamp high beam/low beam switch
5. Instrument cluster
6. Ignition key
7. Tripper
8. Engine kill switch
9. Info button
(Which is available in the RH switch module)
10. Rear view mirror right side
11. Electric start switch
12. Hazard switch
13. Fuel tank cap

Royal Eneld Scram 411
16
1. Front tracator right side
2. Horn
3. Oil level window
4. Rear brake pedal
5. Rider foot rest right side
6. ABS module
7. Pillion foot rest right side
8. Rear tracator right side
LOCATION OF KEY PARTS
1
3
2
567 4
4
8
6

Royal Eneld Scram 411 17
1. Head lamp
2. Front tracator left side
3. Canister
4. Pillion foot rest left side
5. Tail lamp
6. Rear tracator left side
7. Licence plate illuminator
8. Center stand
9. Gear change lever
10. Rider foot rest left side
11. Side stand
LOCATION OF KEY PARTS
1
2
6
4
3
7
5
810
911

Royal Eneld Scram 411
18
OPERATION OF CONTROLS
1. Turn handle bar to extreme left
or right position.
2. Switch “OFF” ignition
gently depress key and turn
anticlockwise further till
steering is locked and remove
key.
1. Insert key, turn clockwise to ignition “OFF” position. If
required, gently shake handle bar to help unlock steering
easily.
STEERING LOCK
LOCKING:
UNLOCKING:
Do not force or attempt to lock/unlock steering if the handle bar is
not in extreme left or right side. Failure to adhere to this caution will
damage the lock and also cause the key to bend or break.
After unlocking steering and before starting engine check the handle
bar free movement by turning to both left and right sides several
times.
Failure to do so will cause unstable riding, leading to a potential
accident, resulting in serious injury to both rider and other road
users, besides causing severe damage to the motorcycle.
WARNING
CAUTION
