DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
A...Trimless Fixture
Round trimless adjustable AR70 fixture.
Includes bullet plunger retainers for
smooth snap-in action during installation
and removal of trim for relamping. Helps
guard against plaster cracking.
B ...Lamp
For use with 12V AR70 lamp 50W max.
Lamp not included. Fixture can accept up
to two (2) optical accessories.
C ...Socket
Double contact bayonet base socket for
12V AR70. (Included with Quiet Ceiling
Housing sold separately)
D...Finish
Trim face is powder coated in white,
black, industrial silver, stainless
steel or primer finish for painting in
existing ceiling color. All other internal
components are flat black.
E ...Safety
Steel safety cable provided. Attaches
to tab inside housing to prevent falling
during maintenance or as a result of
accidental dislodging of the trim.
QUIET CEILING
TRIMLESS
QCT2375
4” Round Trimless
Recessed Adjustable
AR70 Fixture
FOR 12V AR70 50W max.
Compatible Housings:
QCT960
QCT962IC
QCT964RM
QCT966SP
ORDERING INFORMATION
Fixture
QCT2375 =
4” Round Trimless
Adjustable Fixture
for 12V AR70.
4” round recessed trimless adjustable AR70 fixture. For use with 12V
AR70 lamp 50W max.
For use in downlight and accent applications.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
Finish
WH =White
BK =Black
S =Industrial Silver
SS =Stainless Steel (painted)
PM =Primer
QCT2375
Ceiling mudding compound is applied
right to the edge of the fixture.
rev 111006
0º - 35º
C
A
E
B
5.00"
DIA.
2.18"
DIA.
