RSA Lighting MINIACCURUS TZ5102 User manual

DESCRIPTION
www.cooperlighting.com
SPECIFICATION / FEATURES
Catalog # Type
Project
Comments
Prepared by
Date
Integral
Kicker
Reflector
Flexible Conduit
Integral Electronic
Low Voltage Transformer
with Thermal Protection
and Wiring Compartment
in Cylindrical Enclosure
Acoustical Tee
Mounting Brackets
5.25”
3.90”
3.90”
1.70”
1.70”
18.00”
6.00”
2.00”
A...Housing
All aluminum construction with 18” of
flexible conduit attached to a cylindrical
transformer/wiring enclosure. Mounting
hardware suited for TechZone™ ceilings
exclusively.
B ...Trim:
3.9” o.d. square wallwash trim with
internal kicker reflector. Finished in
Armstrong® white.
C ...System Protection:
Thermal protection inside housing.
Vent holes in housing provide cooler
operation. All aluminum construction
provides overall reduced temperatures.
D...Electrical
Electronic transformer housed in a
separate metal enclosure. Enclosure
includes a separated wiring compartment
and entry for primary leads.
E ...Lamp
12V MR16 50 watts max. (not included)
“POSI-GRIP” bi-pin lamp socket for firm,
mechanical lamp connection. Can accept
up to two (2) optical accessories.
MINI
ACCURUS
Armstrong® TechZone™
Compatible
TZ5102
3.9” Square
Wallwash
FOR 12V MR16 50 watts max.
ORDERING INFORMATION
TZ5102
3.9” Square Wallwash Trim with 1.7” Square Opening
Includes Housing with Integral Electronic Transformer and
J-box -Trim face has Armstrong White finish with flat black
internal finish. Internal aluminum kicker reflector.
12V MR16 50W max.
3.9” Square Wallwash MR16 trim with internal kicker reflector. For use
with Armstrong® TechZone™ Ceiling products.
Trim face has Armstrong White finish with flat black internal finish
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
TZ5102
rev. 072007
