RSA Lighting Microgem MLV3801 User manual

DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
A Trim
358˚ x 70˚ Adjustable wall accent trim
for downlight, wall washing, and accent
applications. 4.3” o.d. trim face. Can hold
one optical lens. Lamp can rotate 358˚
x 70˚.
B Lamp
For use with 12V MR16 lamp 71W max.
Lamp not included.
C Socket
GU5.3 bi-pin socket for 12V MR16.
(Included with Microgem housing sold
separately)
D Lens
Includes clear protective glass lens.
Can hold up to 1 optical accessory total.
E Finish
MLV3801 Powder coated white trim.
MLV3802 Powder coated black trim.
MLV3803 Industrial silver trim.
MICROGEM
RECESSED
MLV3801 - 3803
4.3” O.D.
Round Die Cast
Wall Accent Trim
358˚ x 70˚
Adjustability
FOR 12V MR16 71W max.
Compatible Housings:
C500 / C500-SH
C600 / C600-EL
C700
C800
C900
SH2A
ORDERING INFORMATION
Fixture
MLV3801 White Trim
MLV3802 Black Trim
MLV3803 Industrial Silver Trim
4.3” round recessed adjustable trim for downlight, wall washing, and
accent applications. For use with 12V MR16 lamp 71W max.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
rev. 102406
3.125”
70º
2.125”
1.75” dia.
4.31” dia.
E
A
D
B
C
