RSA Lighting Mini Die Cast MS5008 User manual

Type: Project:
RSA LIGHTING LLC 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: [phone] • www.rsalighting.com
©2002 RSA Lighting LLC All Rights Reserved • Specifications subject to change without notice. MD3
Recessed trim suitable
for downlighting
applications.
All die cast construc-
tion with durable pow-
der coat or plated fin-
ish.
Eyeball lamp holder
provides 45º adjustability
Includes recessed hous-
ing with porcelain bi-pin
lamp socket and 30” 18
AWG SF-1 wire leads.
U.L. Listed for undercabi-
net installations.
2.5"
3.125"
2"
1.813"
3"
Overall can height
(Actual space required 
above ceiling: 2.5")
0.125"
Lamp holder adjusts for
variable beam placement.
Item # Description Finish Trim Dia. Ceiling Cut-Out Lamp
MS5008
MS5009
Recessed Adjustable Eyeball Trim White
Black
3.13” 2.50” 12 volts Bi-Pin MR11
Halogen
20 watts max.
 MS5008
 MS5009
3.13” Die Cast Eyeball Trim
45º Adjustability
12V Bi-Pin Base MR11 Lamp 20 Watts Max.
