DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
SPECIFICATION FEATURES
www.cooperlighting.com
Thermal
Protector
9.45”
13.01”
17.14”
16.01”
13.01”
45º x 45º
Adjust
Double
Gimbal
6.69”
6.69”
Integral Electronic
Metal Halide Ballast
A ... Housing
Housing, junction box & trimless
meshplate assembly are all steel
construction. Perforated meshplate allows
for trimless installation in drywall/plaster
ceilings by allowing the ceiling’s mudding
compound to be applied right up to the
edge of the fixture opening. Includes
a beveled “knife-edge” lips to ensure a
clean edge. Can accommodate 0.50” to
1.25” ceiling thickness. Optional Chicago
Plenum configuration available.
B ... System Protection:
Thermal protection provided to guard
against overheating and misuse of
insulation over and around fixture. Vent
holes in housing provide cooler operation.
C... Junction Box
Junction Box is UL listed for through
branch wiring, 6 #12 90º C supply
conductors or 60º C for end of run. The
fixture is also UL listed as ‘access above
ceiling not required’.
D... Electrical
Electrical accessible through ceiling
opening. J-Box located on the side wall
of the housing behind removable access
doors. Integral electronic metal halide
ballasts on individually removable “trays”
for easy maintenance. May also be con-
figured for remote power.
E ... Lamps
One (1) T6 G12 Metal Halide lamp with
reflector mounted in adjustable double
gimbal. Lamp holder is individually remov-
able and may be regressed 1” for additional
cut-off. Lamp can accept up to three opti-
cal accessories (i.e. lens + hex louver +
snoot). 45º x 45º locking lamp adjustment.
Beveled-edge lamp ring is secured with
threadless, bayonet action. Optional
retractable arm is available for lamp
pulldown and extreme aiming. Includes
G12 socket.
F ... Mounting
Butterfly Brackets accept 1/2” EMT,
C Channel, Tbar fasteners, and bar
hangers. Four tabs on housing for
securing to structure. Perforated flaps
along housing sides for securing trimless
insert to fixture and drywall.
G... Labels
cULus listed for non-type IC
applications, suitable for use in damp
locations.
Ceiling Cut-Out: 7.49” x 7.49”
COMBOLIGHT®
Next Generation
Recessed
Single-Lamp Fixture
One (1) Light
T6 G12 Metal Halide
New Construction
Housing
Trimless
ORDERING INFORMATION
An adjustable Single-lamp Recessed fixture for trimless installation suitable for
downlighting and accent applications. Utilizes ONE (1) T6 G12 Metal Halide
lamp.
For new construction applications. Insulation must be kept 3” from all sides
and at least 1” above the housing.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
rev 050108
Configuration
C1 =COMBOLIGHT Recessed
One (1) Light
Housing
N =New Construction
C =Chicago Plenum
C1 E N
Lamp Type / Wattage Label / Reflector Type
070T6N =70 Watt T6 G12 Metal Halide / Narrow
070T6M =70 Watt T6 G12 Metal Halide / Medium
070T6W =70 Watt T6 G12 Metal Halide / Wide
Power Supply
E =Electronic Metal Halide
Ballast
Power Supply
Voltage
1 =120V
2 =277V
Lamp Mechanism
G =Double Gimbal
R =Retractable Double Gimbal
Trim Finish
W =White
B =Black
S =Industrial Silver
Trim Insert
N =Trimless
Housing Interior/Electrical Door
/Sleeve Finish
W =White
B =Black
S =Industrial Silver
T6 G12 Lamp with Reflectors
This fixture utilizes T6 Metal Halide lamp and includes high-
performance clear aluminum reflectors in narrow, medium,
or wide distributions. Non-standard color reflectors are
available upon request.
