RST Instruments MEMS IPI 4 User manual

All efforts have been made to ensure the accuracy and
completeness of the information contained in this document. RST
Instruments Ltd reserves the right to change the information at any
time and assumes no liability for its accuracy.
Copyright © 2020. RST Instruments Ltd. All rights reserved.
Document Number: ICM0095B
Release Date: January 5, 2021
MEMS Digital In-Place Inclinometer System
Quick Start Guide

MEMS Digital in-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
Page i
REVISION HISTORY
Rev.
Revision History
Date
Prepared By
Approved By
A
Initial release
2020-Nov-13
MP
BN
B
Added instructions for Campbell CR6 and
CR310 loggers; DT Logger Host instructions
updated for v. 1.18.5.
2020-Dec-24
MP
AB

MEMS Digital in-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
Page ii
TABLE OF CONTENTS
1 INTRODUCTION............................................................................................................1
2 HARDWARE SET UP....................................................................................................1
2.1 Initial Set Up and Configuration.........................................................................1
2.2 Installation in the Field ......................................................................................3
2.2.1 Cleaning Connectors ..............................................................................3
3 MINIMUM SYSTEM REQUIREMENTS...............................................................................4
3.1 Hardware..........................................................................................................4
3.2 PC Hardware ....................................................................................................4
3.3 Windows Host Operating System......................................................................4
4 DT2485 QUICK START UP INSTRUCTIONS USING DT LOGGER HOST..............................5
4.1 Digital Output for MEMS IPI Systems................................................................5
4.2 Software Installation..........................................................................................5
4.3 Data Logger Configuration................................................................................5
4.4 Downloading Data.............................................................................................9
4.5 Help System .....................................................................................................9
5 CAMPBELL LOGGER QUICK START UP INSTRUCTIONS...................................................9
5.1 Hardware Requirements...................................................................................9
5.2 CR6 Wiring .....................................................................................................10
5.2.1 Updating the Modbus Addresses With a CR6.......................................10
5.2.2 Code for CR6........................................................................................12
5.3 CR310 Wiring..................................................................................................14
5.3.1 Updating the Modbus Addresses With a CR310...................................14
5.3.2 Code for CR310....................................................................................17
6 INSTALLATION...........................................................................................................19
7 SERVICE AND REPAIR................................................................................................19
LIST OF FIGURES
Figure 2-1 Mating the connectors...............................................................................................1
Figure 2-2 Cable tie –do not remove.........................................................................................2
Figure 2-3 Place protective caps on connectors when not in use...............................................4
Figure 4-1 DTBUS tab ...............................................................................................................7
Figure 5-1 CR6 wiring schematic .............................................................................................10
Figure 5-2 Select CRBasic Editor under the Program menu.....................................................10
Figure 5-3 CR6 Series Program icon .......................................................................................11
Figure 5-4 Compiling and saving the code in the CRBasic editor.............................................11
Figure 5-5 Successful compilation message ............................................................................12
Figure 5-6 Select Connect from Main menu.............................................................................12
Figure 5-7 CR6 code .............................................................................................................13

MEMS Digital in-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
Page iii
Figure 5-8 Wiring schematic for an IPI system to the CR310 using RS232 DB9
connector...........................................................................................................14
Figure 5-9 Wiring schematic for an IPI system to the CR310 logger using C1 and C2 .............14
Figure 5-10 Select CRBasic editor under the Program menu...................................................15
Figure 5-11 CR300 Series Program icon...................................................................................15
Figure 5-12 Compiling and saving the code in the CRBasic editor...........................................16
Figure 5-13 Successful compilation message ..........................................................................16
Figure 5-14 Select Connect from Main menu...........................................................................16
Figure 5-15 CR310 code..........................................................................................................18
LIST OF TABLES
Table 2-1 Digital output for MEMS IPI 4 system and RST DT2485.............................................3
Table 4-1 Digital output for MEMS IPI 4 system and RST DT2485.............................................5

MEMS Digital in-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
1
1 INTRODUCTION
The following guide provides a high-level overview for setting up a MEMS Digital In-
Place Inclinometer System (IPI) system. Please consult the MEMS Digital In-Place
Inclinometer System Installation Manual (ICM0062) and the DT Logger Host
Instruction Manual (ELM0080) for detailed instructions not covered in this guide.
2 HARDWARE SET UP
To ensure that all components are working together correctly and able to
communicate, RST recommends that initial set up and configuration take place in the
office or warehouse, prior to final installation in the field.
2.1 INITIAL SET UP AND CONFIGURATION
1. Connect all IPI sensors in a string by mating the connectors (Figure 2-1).
FIGURE 2-1 MATING THE CONNECTORS
NOTE: IT IS NOT NECESSARY TO CONNECT THE BAY RODS AT THIS POINT,BUT CAN BE
DONE TO ENSURE FAMILIARITY WITH THE CONNECTION PROCEDURE.
NOTE: DO NOT CUT THE CABLE TIE THAT LOCKS THE CABLE TO THE WHEEL
ASSEMBLY (FIGURE 2-2). CABLE TIES HAVE BEEN PLACED TO RELIEVE
TENSION ON THE CABLES.

MEMS Digital in-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
2
FIGURE 2-2 CABLE TIE –DO NOT REMOVE
2. Record the serial number of each sensor and its order in the string, from the top
to the bottom of the string.
Connect the IPI string to the desired data logger, following the wiring scheme outlined in
Table 2-1.
CAUTION: IT IS CRITICAL THAT THE SENSORS ARE INSTALLED IN THE SAME ORDER ON
THE STRING AS IN THE INITIAL SET UP AND CONFIGURATION.READ ERRORS
AND STRING FAILURE MAY OCCUR.

MEMS Digital in-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
3
TABLE 2-1 DIGITAL OUTPUT FOR MEMS IPI 4SYSTEM AND RST DT2485
Wire Color
MEMS IPI 4
Red
V+
Green
A
White
B
Black
GND
Bare
SH
3. Follow the instructions outline in Section 4 to configure the string. Ensure that
serial numbers are entered in the same order as they appear on the string.
4. Disconnect all sensors and place the shipping caps on all connectors to prevent
contamination.
2.2 INSTALLATION IN THE FIELD
Once the system and communication have been configured in the office or
warehouse, installation in the field will be straightforward. See ICM0062 for detailed
instructions.
2.2.1 Cleaning Connectors
Keep caps on connectors (Figure 2-3) until mated to the next sensor to prevent
contamination. Store the caps in a clean, dry location for future use.
Any dirt within the connectors may cause water ingress and cause an entire
string of IPIs to fail.
CAUTION: CONTAMINATION,SUCH AS DIRT OR DUST,IN THE CONNECTORS CAN CAUSE
READ FAILURES IN AN ENTIRE STRING OF IPIS.
In the event of contamination within the connectors, the connector ends may be
flushed with isopropyl alcohol and set aside to dry.
CAUTION: IT IS CRITICAL THAT THE SENSORS ARE INSTALLED IN THE SAME ORDER ON
THE STRING AS IN THE INITIAL SET UP AND CONFIGURATION.READ ERRORS
AND SYSTEM FAILURE MAY OCCUR.

MEMS Digital in-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
4
FIGURE 2-3 PLACE PROTECTIVE CAPS ON CONNECTORS WHEN NOT IN USE
3 MINIMUM SYSTEM REQUIREMENTS
3.1 HARDWARE
•DT2485 logger, or
•Campbell Logger
oPC with LoggerNet, and
oRST ELGL4000 Interface (if using CR310)
3.2 PC HARDWARE
•Desktop or laptop with Intel or AMD processor
•USB port
3.3 WINDOWS HOST OPERATING SYSTEM
The following Microsoft™ Windows operating systems are supported:
•Windows 7 (x86 and x64)
•Windows Server 2008 R2 (x64)
•Windows 8 (x64)
•Windows Server 2012 R2 (x64)
•Windows 8.1 (x64)
•Windows 10 (x86 and x64)

MEMS Digital in-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
5
4 DT2485 QUICK START UP INSTRUCTIONS USING
DT LOGGER HOST
The following is a brief outline to get you up and running quickly with the RST
DT2485 data logger and DT Logger Host.
4.1 DIGITAL OUTPUT FOR MEMS IPI SYSTEMS
To connect the IPI system to the DT2485, wire the cable to the screw terminal
according to Table 4-1.
.TABLE 4-1 DIGITAL OUTPUT FOR MEMS IPI 4SYSTEM AND RST DT2485
Wire Color
MEMS IPI 4
Red
V+
Green
A
White
B
Black
GND
Bare
SH
4.2 SOFTWARE INSTALLATION
1. Run the software installation file RST_DTLogger_Setup_X.XX.X.exe,
where X.XX.X indicates current software version. The current version can be
downloaded from:
https://rstinstruments.com/resources/software. Navigate to the site and
select the appropriate data logger.
2. Follow the on-screen instructions to install the software. The default directory
is: C:\Program Files (x86)\RST Instruments\DT Logger Host\
Contact RST Instruments with any questions or concerns.
4.3 DATA LOGGER CONFIGURATION
1. Connect the IPI string to the logger by following the wiring scheme outlined in
Table 4-1. Connect the logger to a PC via the USB port or via the wireless
module, if applicable.
NOTE: THE DT LOGGER HOST SOFTWARE REQUIRES A SET OF DRIVERS INSTALLED ON
THE HOST COMPUTER IN ORDER TO COMMUNICATE OVER USB COMMUNICATION
PORT.
IF AUTOMATIC DRIVER UPDATE IS ENABLED AND AN INTERNET CONNECTION IS
AVAILABLE,RST USB DRIVERS WILL BE DOWNLOADED FROM MICROSOFT™
WINDOWS UPDATE SERVER AND INSTALLED AUTOMATICALLY.

MEMS Digital in-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
6
2. Launch the software. Once the software connects to the logger, the port and
status indicators will turn green and the Status screen should display logger
information.
3. Navigate to the DTBus tab to configure the IPI sensors (Figure 4-1). All
currently configured sensors are listed along with sensor index, sensor serial
number and sensor type.

MEMS Digital In-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
7
FIGURE 4-1 DTBUS TAB
Add another sensor
to the string
Insert a sensor to
the current
position in the
string
Change communication
between ASCII and
Modbus
Remove the currently
displayed sensor
from the string or
remove all sensors
Add specified number
of subsequent sensors
with identical
parameters.
Save the changes
and start logging
Verify Sensors can
communicate with
logger

MEMS Digital In-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
8
a. Confirm that the communication mode has been set to Modbus.
b. Clear existing entries on the table by clicking Del Sel.
c. Click on Add Node to add a new sensor to the string. Ensure the right
sensor type and version have been selected.
d. Click on the Serial column and enter the last 5 digits of the serial
number of the first sensor in the string.
e. Repeat Steps c and d until all sensors in the string have been
entered.
f. Confirm that the serial numbers of the sensors are entered in the
same order they will be installed.
g. Click on Verify Nodes to ensure that each sensor in the string is able
to communicate with the logger.
4. Enable Eng Units to record the data in specific Engineering Units. Enter the
appropriate parameters.
5. Once the desired parameters are set, click the Upload to Logger button to
apply the changes. Click “Yes” when asked to update Modbus Addresses.
6. Wait for update process to finish. The logger is now logging data.
7. If desired, real time sensor readings can be monitored by selecting the
Monitor tab.
NOTE: EXISTING ENTRIES MUST BE CLEARED (NOT RENAMED)BEFORE NEW SENSORS
ARE ADDED TO THE TABLE.
NOTE: IF ENTERED CORRECTLY,THE ORDER THAT THE SENSORS APPEAR IN DT
LOGGER HOST WILL BE A VISUAL REPRESENTATION OF THE LAYOUT OF THE
STRING IN THE BOREHOLE,WITH THE BOTTOM-MOST SENSOR ON THE DT
LOGGER HOST LIST CORRESPONDING TO THE BOTTOM-MOST SENSOR IN THE
BOREHOLE,AND THE SENSOR IN POSITION 1ON THE SOFTWARE
CORRESPONDING TO THE TOP-MOST SENSOR IN THE STRING.
DT LOGGER HOST
BOREHOLE
Sensor 1
Sensor 1
Sensor 2
Sensor 2
Sensor 3
Sensor 3
Sensor 4
Sensor 4
Sensor 5
Sensor 5
TAKING TIME TO SET UP AND CONFIGURE THE SENSORS CORRECTLY AT THE
OUTSET WILL RESULT IN A MORE PLEASANT DATA COLLECTION AND
INTERPRETATION EXPERIENCE.
CAUTION: ENSURE THAT THE COMMUNICATION MODE HAS BEEN SET TO MODBUS TO
AVOID COMMUNICATION ERRORS.

MEMS Digital In-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
9
8. Under the Status tab, check to make sure the parameters are correct and
that the logger is either logging or there is a log pending under the Sampling
section.
9. Click Disconnect button to terminate logger connection.
10. Exit the software and disconnect the communication cable.
11. The data logger should now be taking readings. Return to the logger to
download the data. Check the remaining battery life every time you connect.
The battery state is an approximate value based on recent battery use.
4.4 DOWNLOADING DATA
1. Connect the communication cable to your computer and the DT2485 and
launch the software. If the connection is successful, the port and status
indicators turn green and the Status screen should display logger
information.
2. Press the Collect Data button on the Status tab to download the data. A data
file (*.csv) will automatically be created in the data directory. The default data
directory is:
My Documents\Multichannel\
3. Before downloading, the program will ask whether you would like to erase
the existing data on the logger or keep appending to existing records. To
erase the old data and continue logging with the same parameters, select
the Logging tab and press Apply Settings.
4. To keep the old data on the logger and continue logging, exit the program,
and disconnect the communication cable.
5. To change any logging parameters, do so under the Logging tab and press
Apply Settings to save the changes.
6. Disconnect the communication cable when finished.
4.5 HELP SYSTEM
An extensive help system in DT Logger Host can be activated anytime by pressing
F1 or the RST icon. Answers to common problems and troubleshooting tips can be
found by browsing help topics or searching using keywords.
5 CAMPBELL LOGGER QUICK START UP
INSTRUCTIONS
The following is a brief outline to update the Modbus addresses of IPI sensors in a
string with a CR6 or CR310 Campbell logger. Before
5.1 HARDWARE REQUIREMENTS
•Campbell Logger
oCR6

MEMS Digital In-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
10
oCR310
▪RST ELGL4000 Interface
•PC with the latest version of LoggerNet
5.2 CR6 WIRING
To connect the IPI system to a CR6 Campbell logger, follow the wiring schematic
outlined in Figure 5-1.
FIGURE 5-1 CR6 WIRING SCHEMATIC
5.2.1 Updating the Modbus Addresses With a CR6
Before updating the Modbus addresses on the IPI string, ensure that all settings
have been saved on the logger unit.
Modbus addresses for sensors connected to a Campbell CR6 logger can be
updated via a CRBasic code. Once the user has defined the number of sensors
and their respective serial numbers, the code will automatically assign a Modbus
address to each sensor in the string once the code is run.
1. Open LoggerNet.
2. Navigate to the “CRBasic Editor” option under the Program menu (Figure 5-2).
FIGURE 5-2 SELECT CRBASIC EDITOR UNDER THE PROGRAM MENU
3. Select the appropriate logger from the menu, depending on the type of logger
used.

MEMS Digital In-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
11
FIGURE 5-3 CR6 SERIES PROGRAM ICON
4. Ensure that any existing settings have been saved
5. Remove the template code and paste the code (see Section 5.2.2) into the
editor. The appropriate code will depend on the type of logger that will be used.
6. Update the number of IPIs and the serial number of each IPI in the code, in
order of installation or planned installation.
7. Compile the code, and then name and save it.
FIGURE 5-4 COMPILING AND SAVING THE CODE IN THE CRBASIC EDITOR
8. If the compilation was successful, the following message will appear at the
bottom of the window:
NOTE: IF THE CR6 SERIES PROGRAM ICON DOES NOT APPEAR,IT WILL NEED TO BE
ADDED VIA THE SET UP MENU FIRST.

MEMS Digital In-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
12
FIGURE 5-5 SUCCESSFUL COMPILATION MESSAGE
9. Close the CRBasic Editor.
10. On the Main LoggerNet menu, select “Connect”.
FIGURE 5-6 SELECT CONNECT FROM MAIN MENU
11. Follow general LoggerNet instructions for ensuring current settings have been
saved.
12. Select “Send New” on the right-hand side of the screen and open the saved
CRBasic code from Step 7.
13. Click on “Start Running”.
14. The Modbus addresses for the sensors on the IPI string will now be updated.
5.2.2 Code for CR6
Copy and paste the following code into the CRBasic Editor. The items in red
indicate user input:
CAUTION: COLLECT EXISTING DATA FROM THE LOGGER BEFORE SENDING THE NEW
PROGRAM.

MEMS Digital In-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
13
FIGURE 5-7 CR6 CODE
‘Constants and variables definitions
Const n_ipi = n'Number of IPI sensors per chain, replace ‘n’ with
number of IPIs in string
Dim modbus_serial_number(n_ipi) As Long 'IPI Sensor SN for Modbus protocol
Public ipi_sn(n_ipi) = {xxxxx,yyyyy,…,nnnnn} 'IPI Sensor SN, replace “xxxxx” with correct SN for
each IPI, separated by comma
Public modbus_result(n_ipi) 'Modbus 1 bit result code for acknowledge
Public ipi_data(n_ipi,3) 'A Axis, B Axis and Temp data array
Dim i
Public interface_banner As String * 64
‘Define data tables
DataTable (IPI_GEN4_table,1,-1)
Sample(n_ipi*3,ipi_data(),IEEE4) 'Presents the sensor data for all sensors per string
EndTable
‘Main Program
BeginProg
'Open serial port
SerialOpen(ComC1,9600,0,0,128,4)
SerialFlush(ComC1)
'Guard against serial number error causing incorrect data
SerialOut(ComC1,"@@65534 MBA 247 247"+CHR(13),"",1,0)
Delay(0,1,Sec)
SerialFlush(ComC1)
'Set devices endianness to standard CDAB
SerialOut(ComC1,"@@65534 TXO 0"+CHR(13),"",1,0)
Delay(0,1,Sec)
SerialFlush(ComC1)
'Set & Verify Modbus Addresses
For i = 1 To n_ipi 'up to the number of IPI sensors
'Set device Modbus address command to default 1 to "n_ipi"
SerialOut(ComC1,"@@"+ipi_sn(i)+" MBA "+i+" "+i+CHR(13),"",1,0)
Delay(0,1,Sec)
SerialFlush(ComC1)
Next i
Scan (1,Min,0,0) ‘Reading interval per IPI string
'Power Up Bus & query Sensors for current reading
For i = 1 To n_ipi
'Read A Axis, B Axis and Temp starting from 0x30 register
ModbusMaster(modbus_result(i),ComC1, 9600,i,3,ipi_data(i,1),49,3,3,300)
Delay(0,50,mSec)
Next i
CallTable IPI_GEN4_table ‘Call table to store the data
NextScan
EndProg

MEMS Digital In-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
14
5.3 CR310 WIRING
To connect an IPI system to a CR310 Campbell logger, an RS485 to RS232
interface, such as RST’s ELGL4000 series, will need to be used. The interface/IPI
assembly can be wired as follows (Figure 5-8):
FIGURE 5-8 WIRING SCHEMATIC FOR AN IPI SYSTEM TO THE CR310 USING RS232
DB9 CONNECTOR
In the event that the C1 and C2 ports are vacant, the C1 and C2 ports can be used
in place of the DB9 port. See the wiring diagram outlined in Figure 5-9.
FIGURE 5-9 WIRING SCHEMATIC FOR AN IPI SYSTEM TO THE CR310 LOGGER USING C1 AND
C2
5.3.1 Updating the Modbus Addresses With a CR310
Before updating the Modbus addresses on the IPI string, ensure that all settings
have been saved on the logger unit.
Modbus addresses for sensors connected to a Campbell CR310 logger can be
updated via a CRBasic code. Once the user has defined the number of sensors
and their respective serial numbers, the code will automatically assign a Modbus
address to each sensor in the string once the code is run.
1. Open LoggerNet.
2. Navigate to the “CRBasic Editor” option under the Program menu (Figure 5-2).
NOTE: AN RS485 TO RS232 INTERFACE MUST BE USED WHEN UPDATING THE
MODBUS ADDRESSES WITH A CR310 LOGGER.

MEMS Digital In-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
15
FIGURE 5-10 SELECT CRBASIC EDITOR UNDER THE PROGRAM MENU
3. Select the appropriate logger from the menu, depending on the type of logger
used.
FIGURE 5-11 CR300 SERIES PROGRAM ICON
4. Ensure that any existing settings have been saved
5. Remove the template code and paste the code (see Section 5.3.2) into the
editor. The appropriate code will depend on the type of logger that will be used.
6. Update the number of IPIs and the serial number of each IPI in the code, in
order of installation or planned installation.
7. Compile the code, and then name and save it.
NOTE: IF THE CR6 SERIES PROGRAM ICON DOES NOT APPEAR,IT WILL NEED TO BE
ADDED VIA THE SET UP MENU FIRST.

MEMS Digital In-Place Inclinometer System
Quick Start Up Guide
ICM0095B
RST Instruments Ltd.
16
FIGURE 5-12 COMPILING AND SAVING THE CODE IN THE CRBASIC EDITOR
8. If the compilation was successful, the following message will appear at the
bottom of the window:
FIGURE 5-13 SUCCESSFUL COMPILATION MESSAGE
9. Close the CRBasic Editor.
10. On the Main LoggerNet menu, select “Connect”.
FIGURE 5-14 SELECT CONNECT FROM MAIN MENU
