RTI T2x User manual

T2x
Reference Guide
Wireless Remote Control
It’s Under Control®
Safety Suggestions
Read and Follow Instructions. Read all safety and operating instructions before
operating the unit.
Retain Instructions. Keep the safety and operating instructions for future
reference.
Heed Warnings. Adhere to all warnings on the unit and in the operating
instructions.
Heat. Keep the unit away from heat sources such as radiators, heat registers,
stoves, etc., including ampliers that produce heat.
Power Sources. Use only batteries of the type described in the operating
instructions, or as marked on the unit.
Water and Moisture. Do not use the unit near water—for example, near a sink,
in a wet basement, near a swimming pool, near an open window, etc.
Object and Liquid Entry. Do not allow objects to fall or liquids to be spilled into
the enclosure through openings.
Servicing. Do not attempt any service beyond that described in the operating
instructions. Refer all other service needs to qualied service personnel.
Damage Requiring Service. The unit should be serviced by qualied service
personnel when:
•Objects have fallen or liquid has been spilled into the unit.
•The unit has been exposed to rain.
•The unit does not appear to operate normally or exhibits a marked change in
performance.
•The unit has been dropped or the enclosure has been damaged.
Product Contents
Contents within the box include the following items:
•One (1) T2x Remote Control
• One (1) Docking Station
• One (1) International Power Supply Kit (5V, 2A)
• One (1) Replaceable Keycap Kit (8 button keycaps and keycap replacement tool)
• One (1) Reference Guide
• One (1) Firmware Update Notication
Limited Warranty
RTI warrants its products for a period of three (3) years (one year only for
included battery packs); or for a period of time compliant with local laws when
applicable from the date of purchase from RTI or an authorized RTI distributor.
This warranty may be enforced by the original purchaser and subsequent owners
during the warranty period, so long as the original dated sales receipt or other
proof of warranty coverage is presented when warranty service is required.
Except as specied below, this warranty covers all defects in material and
workmanship in this product. The following are not covered by the warranty:
Damage resulting from:
1. Accident, misuse, abuse, or neglect.
2. Failure to follow instructions contained in this Guide.
3. Repair or attempted repair by anyone other than Remote Technologies
Incorporated.
4. Failure to perform recommended periodic maintenance.
5. Causes other than product defects, including lack of skill, competence or
experience of user.
6. Shipment of this product (claims must be made to the carrier).
7. Being altered or which the serial number has been defaced, modied or
removed.
70-210130-14 V1.4
For news about the latest updates, new product information, and new
accessories, please visit our web site at: www.rticontrol.com
For general information, you can contact RTI at:
Remote Technologies Incorporated
5775 12th Avenue East, Suite 180
Shakopee, MN 55379
Tel. [phone]
Contacting RTI
If you are encountering any problems or have a question about your RTI
product, please contact RTI Technical Support for assistance (see the Contacting
RTI section of this guide for contact details).
RTI provides technical support by telephone or e-mail. For the highest quality
service, please have the following information ready, or provide it in your e-mail.
• Your Name
• Company Name
• Telephone Number
• E-mail Address
• Product model and serial number (if applicable)
If you are having a problem with hardware, please note the equipment in your
system, a description of the problem, and any troubleshooting you have already
tried.
If you are having a problem with software, please note what version you have
installed, the operating system on your PC, a description of the problem, and
any troubleshooting you have already tried. If you are calling about a software
or programming question or problem, please be at your computer when you
place your call. This will considerably speed up the troubleshooting process.
*Please do not return products to RTI without return authorization.*
Service & Support
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. Any changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the device.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference
that may cause undesired operation.
Industry Canada Compliance Statement
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference
that may cause undesired operation.
Cet appareil est conforme avec Industrie Canada exempts de licence standard
RSS (s). Son fonctionnement est soumis aux deux conditions suivantes:
1. Ce dispositif ne peut causer des interférences nuisibles.
2. Cet appareil doit accepter toute interférence reçue y compris des
interférences qui peuvent provoquer un fonctionnement indésirable.
DECLARATION OF CONFORMITY (DOC)
The Declaration of Conformity for this product can be found on the RTI website
at: www.rticontrol.com/declaration-of-conformity
Federal Communications Commission Notice
Copyright © 2022 • Remote Technologies Incorporated • All rights reserved.
T2x Wireless Remote Control
Cleaning
To clean your T2x, lightly dampen a lint-free cloth with plain water or a mild
detergent and wipe the touchscreen, keypad and outer surfaces.
NOTE: Do not use harsh chemicals as damage to the unit may occur.
The remarkable T2x is the fth generation of RTI’s renowned T2 remote
control platform. The 2.8” color display delivers vivid custom graphics,
including two-way feedback with album art, while the perfect selection of soft-
touch buttons provide quick access to common tasks.
• Dual RF capability uses 433MHz and 2.4GHz (utilizing Zigbee®technology).
• Integrated 802.11b/g wireless Ethernet.
• Two-way control using 2.4GHz (Zigbee), WiFi and RTI control components.
• Flush mount, edge-to-edge touchscreen.
• Integrated grip sensors keep the remote awake while in use.
• Accelerometer provides instant-on control.
Key Features

It’s Under Control®
T2x Wireless Remote Control
Programming the T2x
THE TOUCHSCREEN DISPLAY AND HARD BUTTONS
The T2x touchscreen display and buttons are programmed using the RTI
Integration Designer®programming software. (Integration Designer software
available to authorized RTI dealers only).
FIRMWARE AND SOFTWARE UPDATES
Please verify that you have the most recent rmware and software installed
for this and all RTI products. Authorized RTI dealers can download the latest
rmware and Integration Designer from the dealer section of www.rticontrol.
com.
INSTALLING FIRMWARE
1. Turn o the T2x - Press and hold the “Backlight” button and the “OK” buttons
simultaneously.
2. Connect the T2x dock to a PC using a USB cable (USB A to Micro B).
3. Press and hold the “5-way Joystick” button.
4a. Place the T2x into the docking station.
Or
4b. Connect the T2x to a PC directly using an RTI programming cable. (Contact
your local distributor to purchase this cable. The programming cable is also
included with the RTI IRPRO programming kit).
UPDATING INTEGRATION DESIGNER PROGRAMMING
RTI’s Integration Designer data les can be downloaded to the T2x using the
following methods:
• Connect the docking station to a PC using a USB cable (USB A to Micro B) and
place the T2x into the docking station.
Or
• Connect an RTI programming cable to the T2x and a PC. (Contact your local
distributor to purchase this cable. The programming cable is also included with
the RTI IRPRO programming kit).
Or
• Wirelessly via the local area Ethernet network (LAN). NOTE: Initial
programming including network settings will need to take place using the
docking station or the RTI programming cable.
Powering On/O the T2x
TO POWER THE T2xON:
•Press and hold the “Backlight” button and the “OK” buttons simultaneously
until the T2x powers on (Approximately 1-2 seconds).
OR
• Place the T2x in the docking station - this will automatically power the T2x on.
(Docking station does not need to be powered).
NOTE: If the unit does not power on, it may be necessary to charge the battery.
See charging information below.
TO POWER THE T2xOFF:
• Press and hold the “Backlight” button, then press the “OK” button for
approximately 5 seconds until the T2x powers o.
NOTE: During normal operation, powering the T2x o should not be necessary.
LIST BACK
CH
CH
Light Sensor
Front of T2x
Charging the T2x Battery
WHEN TO CHARGE THE T2x:
The T2x uses a Lithium-ion rechargeable battery which does not exhibit a
memory eect from being charged too often and may be placed into the dock
when not in use.
• A low battery icon will illuminate at the top right of the T2x (above the display)
when the battery capacity becomes low and a charge cycle is required.
CHARGING THE T2x:
1. Locate and install the appropriate wall outlet plug on to the power supply.
2. Insert the micro USB end of the power supply cable into the USB port located
on the backside of the docking station.
3. Plug the power supply cable into a wall outlet.
4. Gently slide the T2x into the docking station clear plastic alignment sleeve
until the remote is seated on to the dock connector.
NOTE: Plugging the T2x docking station into a PC
using a USB cable will also charge the T2x.
Backlight Button Color Guide:
Blue = Normal use
Red = T2x charging
Green = T2x fully charged
Multi-colored = T2x connected to a PC.
T2x Remote
(Backside)
Power Supply Cable
(With Micro USB Connector)
T2x Docking Station
(Backside)
To Wall Outlet
T2x Remote
USB A to Micro B Cable
T2x Docking Station
To PC USB port
PC
Downloading software/rmware updates
via the T2x docking station and USB cable
Replacing the T2x Battery
The following steps for removing the battery door should be performed by an
authorized service center or trained installer only.
REMOVE THE BATTERY DOOR:
1. Gently insert a small paper clip into the battery door latch hole until it stops
(see diagram).
2. Tilt the paper clip toward the top of the T2x to release the battery door latch.
REPLACE BATTERY:
1. Remove two (2) battery bracket screws
(Phillips head) and remove bracket.
2. Slide battery out of T2x - pull on
plastic tab connected to battery.
3. Slide new battery into T2x - metal
contacts inserted rst and label
facing up.
4. Replace battery bracket and install
two (2) screws - in order to align
battery bracket properly, get both
screws started before tightening fully.
5. Reinstall battery door - rst align the
wide end of the battery door against
the battery door opening, then
push the latch end of the door into
the T2x until it snaps in place.
NOTE: Always use ocial RTI batteries. Using batteries with improper power will
void warranty. Batteries available for purchase at www.rticontrol.com.
T2x (Backside)
Battery Door
Battery Bracket Screws (2)
Battery Door
Latch Hole
Paper Clip
The T2x Control Panel
The T2x has many settings that can be adjusted directly on the remote through
the control panel. Please note that changes made directly in the T2x control
panel will be overwritten by changes made in Integration Designer.
ACCESSING THE CONTROL PANEL
The Control Panel page can be displayed by holding down the “Backlight” button
until the page is displayed (approx. 5 seconds).
ADJUSTABLE SETTINGS
• Backlight Level • Time Out • Tilt Switch • Grip Sensor • Battery
• Sound • Calibrate Touchscreen • Network Information
Battery Low Indicator
IR Transmission Window
Wireless Ethernet
Connection Indicator
Touchscreen Display
Backlight Button
COLORS:
Blue = Normal use
Red = T2x charging
Green = T2x charged
Multi-colored = T2x
connected to a PC.
Dock Connector Alignment Sleeve
5-Way Joystick
Programmable
Keypad
Buttons
Dock Connector Port
NOTE: The T2x dock connector port is used for battery charging and downloading software/
rmware updates into the remote. To insure a reliable connection between the remote and
the dock, the T2x utilizes a 10-pin connector that is compatible with a T2x Docking Station
or an RTI programming cable.
THE T2xDOCKING STATION
Dock Connector: A 10-pin dock connector is used to insure a reliable connection between the
remote and the dock during battery charging and software/rmware downloads.
Micro USB Port: The T2x dock has a micro USB port (located on the backside) for connection
of the AC power supply cable or a standard USB A to Micro B cable for connection to a PC.
Hard Buttons with
Replaceable Keycaps:
NOTE: These four button
keycaps may be replaced
with the keycaps that ship
with the T2x or keycaps
may be ordered separately
using the RTI Laser Shark
custom engraving service.
Visit the rticontrol.com
dealer website for Laser
Shark and button keycap
replacement instructions.
