RTI U1 User manual

IR-PRO Professional Infrared Code Capture System
U1 Waterproof Wireless Controller
U1
Operation Guide
v1.0

i
FEDERAL COMMUNICATIONS COMMISSION NOTICE
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
FCC ID: MMURTI0400
CAN: 3166-RTI0400

U1 Waterproof Wireless Controller
ii
ATTERY DISPOSAL
This product is shipped with non-rechargeable alkaline batteries.
These batteries are generally considered not to be
environmentally hazardous. In most cases they can be disposed of
in normal household trash, but you should always verify and
follow your local regulations.
Do not burn or incinerate used batteries, as it may cause internal
materials to explode.
It is important not to dispose of large amounts of alkaline batteries
in a group. Used batteries are often not completely "dead."
Grouping used batteries together can bring these "live" batteries
into contact with one another, creating safety risks.
SAFETY SUGGESTIONS
Read Instructions. Read all safety and operating instructions
before operating the unit.
Heat. Keep the unit away from heat sources such as radiators,
heat registers, stoves, etc., including amplifiers that produce heat.
Batteries. When replacing batteries, use only new ones. Do not
mix new and used batteries together. Rechargeable batteries are
not recommended for this product.
Cleaning. The unit should be cleaned only as recommended in the
operating guide.
Servicing. Do not attempt any service beyond that described in
the operating guide. Refer all other service needs to qualified
service personnel.
Damage Requiring Service. The unit should be serviced by
qualified service personnel when the unit does not appear to
operate normally or exhibits a marked change in performance.

iii
LIMITED WARRANTY
Remote Technologies Incorporated warrants its products for a
period of one (1) year from the date of purchase from Remote
Technologies Incorporated or an authorized Remote Technologies
Incorporated distributor.
This warranty may be enforced by the original purchaser and
subsequent owners during the warranty period, so long as the
original dated sales receipt or other proof of warranty coverage is
presented when warranty service is required.
Except as specified below, this warranty covers all defects in
material and workmanship in this product. The following are not
covered by the warranty:
Damage resulting from:
1. Accident, misuse, abuse, or neglect.
2. Failure to follow instructions contained in this Guide.
3. Repair or attempted repair by anyone other than Remote
Technologies Incorporated.
4. Causes other than product defects, including lack of skill,
competence or experience of user.
5. Shipment of this product (claims must be made to carrier).
6. Being altered or which the serial number has been defaced,
modified or removed.
Remote Technologies Incorporated is not liable for any damages
caused by its products or for its failure of its products to perform,
including any lost profits, lost savings, incidental damages, or
consequential damages.
Remote Technologies Incorporated is not liable for damages based
upon inconvenience, loss of use of the product, loss of time,
interrupted operation, commercial loss, any claim made by a third
party or made by you for a third party.
Remote Technologies Incorporated’s liability for any defective
product is limited to repair or replacement of the product, at our
option.

U1 Waterproof Wireless Controller
iv
If your U1 needs service, please contact Remote Technologies
Incorporated by telephone, fax or e-mail for return information.
Please do not return products to RTI without return
authorization.
DISCLAIMER
All rights are reserved. No part of this document may be
photocopied, reproduced, or translated without the prior written
notice of Remote Technologies Incorporated.
The information contained in this document is subject to change
without notice. Remote Technologies Incorporated shall not be
liable for errors or omissions contained herein or for consequential
damages in connection with the furnishing, performance, or use of
this guide.
Microsoft and Windows are registered trademarks of Microsoft
Corporation. Other brands and their products are trademarks or
registered trademarks of their respective holders.
U1, It’s Under Control, TheaterTouch,TheaterTouch Designer, and the
RTI logo are trademarks of Remote Technologies Incorporated.

v
Contents
Federal Communications Commission Notice ---------------------- i
Battery Disposal ----------------------------------------------------------- ii
Safety Suggestions -------------------------------------------------------- ii
Limited Warranty -------------------------------------------------------- iii
Disclaimer-------------------------------------------------------------------iv
Contents------------------------------------------------------------------------ v
Chapter 1. Welcome----------------------------------------------------------1
Waterproof Note------------------------------------------------------------1
Unpacking and Inspection -----------------------------------------------2
Product Contents-----------------------------------------------------------2
Software Requirements ---------------------------------------------------2
Chapter 2. Introduction -----------------------------------------------------3
Features-----------------------------------------------------------------------3
Important Notes ------------------------------------------------------------4
Cleaning----------------------------------------------------------------------4
Remote Reference ----------------------------------------------------------5
Chapter 3. Operation---------------------------------------------------------7
Getting Started--------------------------------------------------------------7
Programming----------------------------------------------------------------8
Assembly---------------------------------------------------------------------8
Operating---------------------------------------------------------------------8
Chapter 4. Troubleshooting------------------------------------------------9
USB Communication Problems -----------------------------------------9

U1 Waterproof Wireless Controller
vi
Chapter 5. Service and Support----------------------------------------- 11
Updates and New Products-------------------------------------------- 11
Contacting Remote Technologies Incorporated------------------- 11
RTI Technical Support -------------------------------------------------- 11
Specifications---------------------------------------------------------------- 13

1
Chapter 1. Welcome
Thank you for purchasing the U1 waterproof wireless controller.
The U1 Remote Control provides a rugged interface option for
communicating with RTI remote control processors.
The U1 was designed for reliable wireless control of audio/video
systems from environments which are too harsh for normal
remote controls. It is completely sealed, making it both waterproof
and floating. Whether indoors or out, the U1 is a perfect
companion for hot tubs, pools, bathrooms, and decks.
Programming is easy and convenient thanks to the Windows®
based TheaterTouch Designer™software. Because RTI’s remote
control products are sold only through professional
installers/programmers, and never directly to consumers, it is our
philosophy to not incorporate programming capability directly
into our products. Instead, we are committed to providing our
dealers with the hardware and software tools that allow them to
create re-usable programming databases and templates in the
most efficient and reliable way possible.
The U1 is capable of radio frequency output only. The RM-433
receivers (purchased separately) allow transmission through walls
and cabinets. The RF receivers connect to an RTI control system
for the ultimate in control reliability and flexibility. RTI control
systems provide many advanced features such as IR routing, local
macro execution, power sensing, and RS-232 control.
WATERPROOF NOTE
The U1 is designed to withstand temporary exposure to water
only. Prolonged exposure of more than 30 minutes may result in
the U1 malfunctioning. Although it is safe to use in showers, hot
tubs, and pools, DO NOT ALLOW THE U1 TO REMAINING
FLOATING IN WATER FOR AN EXTENDED PERIOD OF TIME.
A convenient mounting holster is provided for storage when the
U1 is not in use.

U1 Waterproof Wireless Controller
2
UNPACKING AND INSPECTION
After unpacking your new U1 universal system controller, save all
of the packing materials in case you ever have to ship the unit.
Thoroughly inspect the U1 and packing materials for signs of
damage. Report any damage to the carrier immediately. Report
any equipment malfunctions to Remote Technologies
Incorporated or an authorized Remote Technologies Incorporated
distributor.
PRODUCT CONTENTS
Contents within the box include the following items:
! One (1) U1 universal system controller.
! One (1) mounting holster.
! Ten (10) machine screws with o-rings.
! Two (2) wood screws.
! Four (4) AAA alkaline batteries.
! One (1) Operation guide.
SOFTWARE REQUIREMENTS
The recommended minimum system requirements needed to run
the TheaterTouch Designer software are as follows:
! Windows 98SE®, Windows ME®, Windows 2000®, Windows
XP®or later version.
! A free USB port.
! At least 64 Megabytes of RAM.
! At least 100 Megabytes of free disk storage.
! A mouse is required.
! Optional printer for printing reports.

3
Chapter 2. Introduction
FEATURES
The U1 provides superior quality and reliability as well as these
specific features:
! Durable design is waterproof and it floats.
! Comfortable ergonomic design permits effortless, one-
handed operation.
! The perfect selection of buttons for basic audio/video
control.
! Four source and eight general purpose buttons are fully
assignable/programmable.
! Easy-to-use Windows® based software for programming
and customization.
! Transmits commands using RF for operation through walls,
cabinets, etc.
! Completely customizable, programmable and upgradeable.
! Tactile feedback on all buttons.
! Includes mounting holster for attaching to walls or other
surfaces.
! Optional 'Voltage' and 'Video' sensing modules to monitor
power status of equipment.
! Optional interface for RS-232-controlled equipment.
! Non-volatile Flash memory stores your system configuration
even when power is not present.
