RTS DBP 4M User manual

DBP Digital Beltpack
DBP 4M | DBP 4F | DBP 5F
en Technical Manual

DBP Digital Beltpack Table of contents | en 3
Bosch Security Systems, LLC Technical Manual 2021-06 | 01 | F.01U.380.825
Table of contents
1Safety 6
1.1 Copyright and Disclaimer 6
1.2 Notices 6
1.3 Important safety instructions 7
2Introduction 8
2.1 Features 8
3Reference view 9
3.1 Belt clip removal and replacement 10
4Cabling 11
4.1 To OMS 11
4.2 To OMI 12
4.3 To ODIN 12
4.4 PoE 13
5Install the Bluetooth dongle 15
6Create an Intercom connection 16
6.1 Connect to OMS using Connect Devices 16
6.2 Configure intercom OMNEO ports to make connection offers 16
6.2.1 Configure OMS to make a connection offer 16
6.2.2 Configure ODIN to make a connection offer 17
6.3 Accept a connection offer on DBP 18
6.4 Create connections using IPedit 18
6.4.1 Add DBP to IPedit 18
6.4.2 Configure an OMNEO channel for DBP using IPedit 19
6.4.3 Configure the DBP to accept an OMNEO offer using IPedit 21
6.5 Create connections using AZedit 22
6.5.1 Configure OMS/ODIN to make a connection offer 22
6.5.2 Configure an OMI card to make a connection offer 23
7Modes of operation 25
7.1 PL Mode 25
7.2 Keypanel Mode 25
8Basic Operation 26
8.1 Main screen icons 26
8.2 Navigation basics 27
8.3 Hot keys 28
8.4 UI controls 31
8.5 Volume adjustment 32
8.6 Call Signaling (PL Mode only) 34
8.7 Talk and Listen 34
8.8 Call waiting window 35
8.9 Bluetooth 37
8.9.1 Answer a phone call via Bluetooth 37
8.9.2 Phone call management window 39
8.9.3 Patch a phone call to the Intercom 39
8.10 Upgrade firmware 40
8.11 Download screen saver images or splash screen images 44
9Menu Structure 46
9.1 Setup | Network 46
9.1.1 Device Name 47

4en | Table of contents DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825 Technical Manual Bosch Security Systems, LLC
9.1.2 DHCP 48
9.1.3 IP Address 48
9.1.4 Netmask 49
9.1.5 Gateway 50
9.1.6 DNS Server 51
9.1.7 Domain 52
9.1.8 MAC Address 53
9.2 Setup | Offers 53
9.2.1 DBP Offers 53
9.2.2 Aux Offers 54
9.3 Setup | Key Assignments 54
9.4 Setup | Service 56
9.4.1 Tone 56
9.4.2 Test Mode 57
9.4.3 User Reset 58
9.4.4 Factory Reset 59
9.5 Setup | Authentication 61
9.5.1 Require PIN 61
9.5.2 Set PIN 62
9.6 Setup | Key Modes 63
9.7 Audio | Headset 63
9.7.1 Sidetone 63
9.7.2 Echo Canceller 64
9.8 Audio | Microphone 65
9.8.1 Mic Select 65
9.8.2 Mic Gain 65
9.8.3 Hot Mic 66
9.8.4 Noise Gate 67
9.8.5 XLR Mic Type 68
9.8.6 Allow Mic Kill 68
9.8.7 Send Mic Kill 69
9.9 Audio | 3.5mm Aux 70
9.9.1 Aux Mode 70
9.9.2 Input Gain 71
9.9.3 Output Gain 71
9.10 Audio | BT Aux Levels 72
9.10.1 Input Gain 72
9.10.2 Output Gain 72
9.11 Audio | OMNEO CH 2 Levels 73
9.11.1 Input Gain 73
9.11.2 Output Gain 74
9.12 Audio | Mixer 74
9.12.1 Headset L+R 74
9.12.2 Headset Left 75
9.12.3 Headset Right 76
9.12.4 To Intercom 76
9.12.5 3.5mm Aux Out 77
9.12.6 OMNEO Ch2 Out 77
9.12.7 Bluetooth Out 78

DBP Digital Beltpack Table of contents | en 5
Bosch Security Systems, LLC Technical Manual 2021-06 | 01 | F.01U.380.825
9.13 Call Alerts 79
9.13.1 Call Beep 79
9.13.2 Call Vibration 80
9.14 Information 80
9.15 Bluetooth 81
9.15.1 Ready to Pair 81
9.15.2 Paired Headsets 83
9.15.3 Paired Aux Devs 84
9.16 Display 86
9.16.1 Display Mode 86
9.16.2 Brightness 87
9.16.3 Screen Saver 88
9.16.4 Screen Flip 88
10 Icons 90
11 Technical data 93

6en | Safety DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825 Technical Manual Bosch Security Systems, LLC
1 Safety
1.1 Copyright and Disclaimer
All rights reserved. The product information and design disclosed herein were originated by
and are the property of Bosch Security Systems, LLC. Bosch reserves all patent, proprietary
design, manufacturing, reproduction, use and sales rights thereto, and to any article disclosed
therein, except to the extent rights are expressly granted to others.
No part of this document may be reproduced or transmitted in any form by any means,
electronic, mechanical, photocopying, recording, or otherwise, without the prior written
permission of the publisher. For information on getting permission for reprints and excerpts,
contact Bosch Security Systems, LLC.
All other trademarks are property of their respective owners.
The content and illustrations are subject to change without prior notice.
1.2 Notices
CE Compliant and UL Certified
The lightning flash and
arrowhead within the triangle
is a warning sign alerting you
of dangerous voltage inside
the product.
Caution: To reduce the risk of
electric shock, do not remove
cover. No user-serviceable
parts inside. Refer servicing
to qualified service personnel
The exclamation point within
the triangle is a warning sign
alerting you of important
instructions accompanying
the product.
See marking on bottom/back of product.
!
Warning!
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
!
Warning!
This is a CLASS A product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.

DBP Digital Beltpack Safety | en 7
Bosch Security Systems, LLC Technical Manual 2021-06 | 01 | F.01U.380.825
!
Warning!
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
1.3 Important safety instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
8. Only use attachments/accessories specified by the manufacturer.
9. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
10. Unplug the apparatus during lightning storms or when unused for long periods of time.
11. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.

8en | Introduction DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825 Technical Manual Bosch Security Systems, LLC
2 Introduction
The DBP (Digital Belt Pack) is one of RTS' initial offerings in the wired digital party line
solution space. The DBP provides two modes in which the DBP can operate for up to four
configurable audio conferences. There are two modes DBP can operate, KP (Keypanel) mode
and PL (Party Line) mode. When connected to an intercom in KP mode, any key assignment
that is made to a keypanel can be made on the DBP. When connected to an OMS, the
assignment types are limited to PL, RY (relays), and UR (UPL resources).
When connected to the OMS (OMNEO Main Station), the DBP operates as a digital party line
device. The DBP also connects to any of the RTS matrix products directly via OMNEO. This
includes OMI cards in ADAM (or ADAM -M) frames or OMNEO ports on ODIN frames. When
connected to an RTS OMNEO matrix, the DBP acts as a wired, 4-button keypanel. The DBP
automatically determines the correct mode of operation (digital party line connection to OMS
or keypanel connection to the matrix) at power on.
The DBP recovers power over an 802.3af or 802.3at compliant Ethernet interface. The PoE
(power over Ethernet) In port connects to a PoE compliant power sourcing equipment. The
PoE Out port is available for daisy chain connections to other DBPs.
The DBP comes in a rugged, over-molded enclosure that is IP-53 compliant. It has a full-color
TFT display and an icon-based menu interface, which allows for local configuration of essential
customer preferences.
2.1 Features
– Incorporates both XLR and 3.5 mm TRRS connectors for headsets, and the XLR headsets
are available in 3 different headset XLR options: 4-pin female, 4-pin male, and 5-pin
female. The 5-pin female headset supports stereo audio.
– PoE powered via an 802.3af or 802.3at managed switch or PoE injector. Contains a PoE
In and PoE Out port, which allows up to six DBPs to be daisy-chain connected to the
same PoE (+) switch port.
– DBP connects to an OMNEO main station (Digital Party Line) or an OMNEO capable
matrix (OMI card or ODIN). DBP can support up to four active Party Lines. 40 DBPs can
be connected to OMS (based on model), 64 DBPs can be connected to one OMI card
(based on model, 128 DBPs can be connected to one ODIN, based on model).
– Supports Bluetooth audio connectivity using either an IO Gear GBU522 dongle or an LM
Technologies LM506 dongle.
– Incoming CALL notifications via audible alerts or haptic vibration.

DBP Digital Beltpack Reference view | en 9
Bosch Security Systems, LLC Technical Manual 2021-06 | 01 | F.01U.380.825
3 Reference view
1 2 34 5 67
7
8
910 11 12
13 14
1 Master Volume Control knob / Key A and C Volume knob
2 CLR/BACK button
3 CALL button
4 SEL/MENU button
5 Master Volume Control knob / Key B and D Volume knob
6 Lanyard loop
7 Belt Clip
8 USB Bluetooth dongle connector
9 PoE Out connector
10 PoE In connector
11 XLR Headset connector
12 3.5mm AUX connector
13 Talk keys (A, B, C, and D)
14 Display screen

10 en | Reference view DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825 Technical Manual Bosch Security Systems, LLC
3.1 Belt clip removal and replacement
1
2
To remove the belt clip, do the following:
1. Lift the tension clip (1) up.
2. With the tension clip up, slide the belt clip out of the belt clip track (2).
To replace the belt clip, do the following:
4Align and slide the belt clip into the belt clip track (2).
A click is felt/heard when the belt clip is securely in place.

DBP Digital Beltpack Cabling | en 11
Bosch Security Systems, LLC Technical Manual 2021-06 | 01 | F.01U.380.825
4 Cabling
4.1 To OMS
i
Notice!
PoE is not necessary as long as it is on a network that can reach the DBP.
To cable the DBP to an OMS main station, do the following:
1. Using a CAT-5e cable, attach one end to the PoE IN connector on the DBP.
2. Connect the other end of the cable to an approved PoE switch.
3. Using a second CAT-5e cable, connect one end to the approved PoE switch.
4. Connect the other end to the OMNEO connector on the OMS device.
PoE Switch
i
Notice!
If using IPedit to configure the connection between the DBP and the OMS, a third cable is
needed to connect the OMNEO port to the PoE switch.

12 en | Cabling DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825 Technical Manual Bosch Security Systems, LLC
For information on connecting the DBP to the OMS, see Configure OMS to make a connection
offer, page 16 .
4.2 To OMI
To cable a DBP to an OMI card, do the following:
1. Using a CAT-5e cable, attach one end to the PoE IN connector on the DBP.
2. Connect the other end of the cable to an approved PoE switch.
3. Using a second CAT-5e cable, connect one end to the approved PoE switch.
4. Connect the other end to an Ethernet connector on the OMI card.
SERIAL
J5
J2J1
ETHERNET
OMI-2 BC
J3 J4
PoE Switch
For information on connecting the DBP to the OMI card, see Configure an OMI card to make a
connection offer, page 23 .
4.3 To ODIN
To connect the DBP to an ODIN matrix, do the following:
1. Using a CAT-5e cable, attach one end to the PoE IN connector on the DBP.
2. Connect the other end of the cable to an approved PoE switch.

DBP Digital Beltpack Cabling | en 13
Bosch Security Systems, LLC Technical Manual 2021-06 | 01 | F.01U.380.825
3. Using a second CAT-5e cable, connect one end to the approved PoE switch.
4. Connect the other end to the OMNEO port on ODIN.
J6 J7
PoE Switch
i
Notice!
If using IPedit to configure the connection between the DBP and ODIN, use a third cable to
connect the OMNEO port to the PoE switch.
For information on how to connect the DBP to an ODIN, refer to Configure ODIN to make a
connection offer, page 17 .
4.4 PoE
The Digital Belt Pack includes a PoE In and PoE Out connector that allows multiple DBPs to be
daisy chained from the same switch port. RTS recommends use of an 802.3at compliant PoE
switch for daisy chaining. RTS guidance on the number of DBPs that can be daisy chained
from an 802.3at port are as follows:
– Using CAT-5e cable or better, up to six DBPs can be daisy chained where each daisy chain
span has a length of 100 foot (30 m) or less (total of 600 feet / 180 meters of cable).
– Using CAT-5e cable or better, up to three DBPs can be daisy chained where each daisy
chain span has a length of 328 foot (100 m) or less (total of 984 feet / 300 meters of
cable).

14 en | Cabling DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825 Technical Manual Bosch Security Systems, LLC
i
Notice!
It is possible to use PoE injectors on the end of a daisy chain to extend the number of DBPs
and cable lengths supported
Using more than 6 DBPs on the same 802.3at switch port may result in unreliable beltpack
operation.
To daisy chain belt backs together, do the following:
1. Connect one end of a CAT-5e cable from the PoE Out connector on one DBP belt pack.
2. Connect the other end of the CAT-5e cable to the PoE In connector on a second DBP
belt pack.
3. Connect one end of a second CAT-5e cable to the PoE Out connector on the second DBP
belt pack.
4. Connect the other end of the second CAT-5e cable to the PoE In connector on a third
DBP belt pack.
5. Repeat these steps to add additional belt packs to the daisy chain.
J2
J3
Figure4.1: Daisy Chain Example

DBP Digital Beltpack Install the Bluetooth dongle | en 15
Bosch Security Systems, LLC Technical Manual 2021-06 | 01 | F.01U.380.825
5 Install the Bluetooth dongle
It is best to install the dongle when there is no power to the device. If you install the dongle
while the DBP is on, the belt pack recognizes the dongle and reboots to initialize the hardware
properly. If you remove the dongle while the DBP has power, it does not reboot.
i
Notice!
Optimal Bluetooth audio quality is achieved when the DBP is paired with a headset that
incorporates a boom microphone construction versus Bluetooth headsets with embedded
microphones (i.e., ear buds).
To install the Bluetooth dongle, do the following:
1. Open the USB connector door (1).
Take care not to over-extend the door.
2. Insert the dongle (2) in the connector.
Figure5.1: DBP USB dongle installation
3. Close the USB connector door (1).
4. Push the door surface to ensure the door is within the DBP enclosure.

16 en | Create an Intercom connection DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825 Technical Manual Bosch Security Systems, LLC
6 Create an Intercom connection
6.1 Connect to OMS using Connect Devices
To connect OMNEO devices via the OMS front panel UI, do the following:
1. Navigate to Connect Devices menu itemmenu item (Configuration | Ports | Connect
Devices).
2. Click the ENC2 encoder knob.
OMS scans for available OMNEO devices, and then shows devices that support Easy
Connect (KP-Series, DBP, OKI, etc.). Discoverable devices need to be powered on,
connected to the network, and be on the same subnet.
3. Navigate to the Connect All button.
OR
Navigate to the OMNEO device.
4. Select the Connect button.
6.2 Configure intercom OMNEO ports to make connection offers
6.2.1 Configure OMS to make a connection offer
i
Notice!
For more information, see the OMS manual found at www.rtsintercoms.com.
To connect a DBP to OMS, do the following:
1. Navigate to the OMNEO icon (Configuration | Ports | OMNEO).
2. Click the ENC2 encoder knob.
The OMNEO Channels screen displays.
3. Select the port to configure.

DBP Digital Beltpack Create an Intercom connection | en 17
Bosch Security Systems, LLC Technical Manual 2021-06 | 01 | F.01U.380.825
i
Notice!
If you are connecting a DBP or Keypanel in order to power it up on this port, choose Channel
1. Any other port is an Aux port and the DBP has only two channels.
1. Enter the device name of the partner device to connect to this port.
2. Select the type of partner device.
3. Select the channel number on the partner device to connect to.
4. (Optional) Change the Rx Latency for the connection.
The default is recommended.
5. When finished, press ENC1 to exit.
6. Choose Save to save the changes.
6.2.2 Configure ODIN to make a connection offer
i
Notice!
For more information, see the ODIN manual found at www.rtsintercoms.com
To connect a DBP to an ODIN, do the following:
1. Navigate to the OMNEO icon.
2. Click the right encoder knob.
The OMNEO Channels screen displays.
i
Notice!
If the intercom system contains only one ODIN frame, the Frame field is not displayed. If the
intercom system contains multiple ODIN frames, the Frame field activates and allows ports in
other frames to be selected and configured. While the Frame field is highlighted, press the
right encoder knob to activate the field. Once activated, turn the right encoder knob to select
another frame in the system.
3. Navigate to the Port field.
4. Click the right encoder knob.
The Port field becomes active.
5. Scroll to the desired port.
6. Navigate to the Device Name field.
7. Enter the device name of the partner device to connect to this port.
8. Navigate to the Device Type field.
9. Scroll to the OMNEO device type of the partner device.
10. Navigate to the channel field.
11. Scroll to the desired channel on the partner device.
12. (Optional) Enter a description for this connection.

18 en | Create an Intercom connection DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825 Technical Manual Bosch Security Systems, LLC
13. (Optional) Select the latency to use for this connection. (1 ms is recommended for best
quality).
14. Click the left encoder knob to exit the screen.
A Changes Made confirmation message displays.
15. Navigate to the desired action.
16. Click the right encoder knob to confirm.
i
Notice!
Alternately, the left shaft encoder can be clicked or the CLR button can be pressed to cancel
this prompt and go back to editing the underlying screen.
17. Click the right encoder knob to confirm the selection.
6.3 Accept a connection offer on DBP
To accept a DBP Offer, do the following:
1. Navigate to the DBP Offers menu item (Setup | Offers | DBP Offers).
2. Press the SEL/MENU button.
The field highlights.
3. Rotate either shaft encoder to scroll through the available offers.
4. Press the SEL/MENU button to confirm the change, or press the CLR/BACK button to
abort changes.
6.4 Create connections using IPedit
6.4.1 Add DBP to IPedit
To add a DBP to IPedit, do the following:
1. Open IPedit.
2. Select Add from the Device menu.
The Add Devices screen displays.

DBP Digital Beltpack Create an Intercom connection | en 19
Bosch Security Systems, LLC Technical Manual 2021-06 | 01 | F.01U.380.825
3. Select one or more available devices.
The Add button becomes active.
4. Click the Add button.
The device catalog displays the selected devices.
5. Click the Done button.
The screen closes.
6.4.2 Configure an OMNEO channel for DBP using IPedit
To configure an OMNEO channel for DBP using IPedit, do the following:
i
Notice!
The Destination Type does not need to be selected if using the Browse window to select the
device. It fills the type and IP Address automatically.
Using the Channel Configuration Pane

20 en | Create an Intercom connection DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825 Technical Manual Bosch Security Systems, LLC
1. In the Destination Device Name field, click the … button.
The Discovered Devices screen displays.
2. Expand the tree to view the destination devices available.
3. Select the desired device for the destination.
4. Click OK.
The screen closes.
5. Select the channel to which the device connects.
6. (Optional) Enter the channel description.
