RTS DSPK4 User manual

DSPK4 User Station
DSPK4‑D, DSPK4‑F 4F, DSPK4‑F 4M, DSPK4‑F 5F, DSPK4‑W
en Technical Manual

DSPK4 User Station Table of contents | en 3
Bosch Security Systems, LLC Technical Manual 2023-03 | V01 | F.01U.409.148
Table of contents
1Important notices 6
1.1 Copyright and disclaimer 6
1.2 Safety notices 6
1.3 Important safety instructions 7
1.4 FCC information 8
2Introduction 9
3Reference view 10
4Connections 12
5Mounting instructions 14
5.1 Mount the DSPK4-W wall mount 14
5.2 Mount the DSPK4-F flush mount 16
5.2.1 Console mounting 16
5.2.2 Standard 4-gang electrical box mounting 18
6Cabling 21
6.1 Power 21
6.1.1 PoE+ / PoE++ 21
6.1.2 External DC power 23
6.1.3 DC terminal block 23
6.2 GPIO connector 25
6.3 Footswitch 27
7Install the Bluetooth dongle 28
8Create an intercom connection 29
8.1 Connect to OMS using the Connect Devices Menu 29
8.2 Configure intercom OMNEO ports to make connection offers 29
8.2.1 Configure OMS to make a connection offer 29
8.2.2 Configure ODIN to make a connection offer 30
8.3 Accept a connection offer 31
8.4 Create connections using IPedit 31
8.4.1 Add DSPK4 to IPedit 31
8.4.2 Configure an OMNEO channel for DSPK4 using IPedit 32
8.4.3 Configure the DSPK4 to accept an OMNEO offer using IPedit 34
8.5 Create connections using AZedit 36
8.5.1 Configure OMS/ODIN to make a connection offer 36
8.5.2 Configure OMI card to make a connection offer 37
9Modes of operation 38
9.1 PL Mode 38
9.2 Keypanel Mode 38
10 Basic operation 39
10.1 Main screen icons 39
10.2 Navigation basics 40
10.3 Hot keys 43
10.4 UI controls 44
10.5 Volume adjustment 45
10.5.1 Master volume adjustment 45
10.5.2 Individual key volume adjustment 46
10.5.3 Adjust volume for OMNEO 2 and Bluetooth input volumes 46
10.5.4 Mute a PL key assignment 47
10.5.5 Adjust Matrix In level in AZedit 47

4en | Table of contents DSPK4 User Station
2023-03 | V01 | F.01U.409.148 Technical Manual Bosch Security Systems, LLC
10.5.6 Verify speaker dim setting 48
10.6 Call signaling 48
10.7 Talk and listen 49
10.8 Footswitch 49
10.9 Call waiting window 51
10.10 Bluetooth operation basics 51
10.10.1 Answer a phone call via Bluetooth 52
10.10.2 Phone call management window 52
10.10.3 Patch a phone call to the Intercom 52
11 Menu Structure 54
11.1 Icons 54
11.2 Setup | Network 57
11.2.1 Device Name 57
11.2.2 DHCP 58
11.2.3 IP Address 59
11.2.4 Netmask 59
11.2.5 Gateway 60
11.2.6 DNS Server 61
11.2.7 Domain 62
11.2.8 MAC Address 63
11.3 Setup | Offers 63
11.3.1 DSPK4 Offers 63
11.3.2 Aux Offers 64
11.4 Setup | Miscellaneous 64
11.4.1 Call beeps 64
11.4.2 Footswitch Mode 64
11.5 Setup | Service 65
11.5.1 Tone 65
11.5.2 Test mode 65
11.5.3 User reset 66
11.5.4 Factory reset 68
11.6 Setup | Authentication 69
11.6.1 Require PIN 69
11.6.2 Set PIN 70
11.7 Setup | Key Modes 71
11.8 Audio | Speaker / Headphones 71
11.8.1 Sidetone 71
11.8.2 Echo Canceller 72
11.9 Audio | Microphone 73
11.9.1 Mic Select 73
11.9.2 Mic Gain 74
11.9.3 Hot Mic 74
11.9.4 Noise Gate 75
11.9.5 XLR Mic Type 76
11.9.6 Allow Mic Kill 76
11.9.7 Send Mic Kill 77
11.9.8 Mic Mute Latches 78
11.10 Audio | Advanced / DSP 79
11.10.1 Mic AGC Level 79

DSPK4 User Station Table of contents | en 5
Bosch Security Systems, LLC Technical Manual 2023-03 | V01 | F.01U.409.148
11.10.2 Mic Noise Reduction 79
11.11 Audio | BT Aux Levels 80
11.11.1 Input Gain 80
11.11.2 Output Gain 80
11.12 Audio | OMNEO CH 2 Levels 81
11.12.1 Input Gain 81
11.12.2 Output Gain 82
11.13 Audio | Mixer 82
11.13.1 Active Mic 82
11.13.2 From Intercom 83
11.13.3 OMNEO Ch2 In 84
11.13.4 Bluetooth In 84
11.14 Key assignments 85
11.14.1 Change Setup Page 87
11.15 Information 88
11.16 Bluetooth 88
11.16.1 Ready to pair 89
11.16.2 Paired headsets 90
11.16.3 Paired aux devs 91
11.17 Display 93
11.17.1 Display mode 93
11.17.2 Brightness 94
11.17.3 Screen saver 95
12 Maintenance 96
12.1 Upgrade firmware 96
12.2 Download screen saver images or splash screen images 99
12.3 Troubleshooting 101
13 Technical data 102

6en | Important notices DSPK4 User Station
2023-03 | V01 | F.01U.409.148 Technical Manual Bosch Security Systems, LLC
1 Important notices
1.1 Copyright and disclaimer
All rights reserved. The product information and design disclosed herein were originated by
and are the property of Bosch Security Systems, LLC. Bosch reserves all patent, proprietary
design, manufacturing, reproduction, use and sales rights thereto, and to any article disclosed
therein, except to the extent rights are expressly granted to others.
No part of this document may be reproduced or transmitted in any form by any means,
electronic, mechanical, photocopying, recording, or otherwise, without the prior written
permission of the publisher. For information on getting permission for reprints and excerpts,
contact Bosch Security Systems, LLC.
All other trademarks are property of their respective owners.
The content and illustrations are subject to change without prior notice.
1.2 Safety notices
The lightning flash and
arrowhead within the triangle
is a warning sign alerting you
of dangerous voltage inside
the product.
Caution: To reduce the risk of
electric shock, do not remove
cover. No user-serviceable
parts inside. Refer servicing
to qualified service personnel
The exclamation point within
the triangle is a warning sign
alerting you of important
instructions accompanying
the product.
See marking on bottom/back of product.
!
Warning!
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
!
Warning!
The main power plug must remain readily operable.
!
Caution!
To reduce the risk of electric shock, grounding of the center pin of this plug must be
maintained.
!
Warning!
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

DSPK4 User Station Important notices | en 7
Bosch Security Systems, LLC Technical Manual 2023-03 | V01 | F.01U.409.148
CE Compliant and UL Certified
!
Warning!
This is a CLASS A product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
1.3 Important safety instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong is provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of
the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug the apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.

8en | Important notices DSPK4 User Station
2023-03 | V01 | F.01U.409.148 Technical Manual Bosch Security Systems, LLC
1.4 FCC information
FCC suppliers Declaration of Conformity
F.01U.405.616 DSPK4-D IP 4 ch desktop user station
F.01U.405.617 DSPK4-W IP 4 ch wall mount user station
F.01U.405.618 DSPK4-F 4M IP 4 ch flush mount user station 4M
F.01U.405.619 DSPK4-F 4F IP 4 ch flush mount user station 4F
F.01U.405.620 DSPK4-F 5F IP 4 ch flush mount user station 5F
Compliance statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Responsible Party
Bosch Security Systems, LLC
130 Perinton Parkway
14450 Fairport, NY, USA

DSPK4 User Station Introduction | en 9
Bosch Security Systems, LLC Technical Manual 2023-03 | V01 | F.01U.409.148
2 Introduction
The DSPK4 (Digital Speaker Station) is an IP-based version of its wired analog speaker station
predecessor, with several key enhancements, such as high quality digital audio and the use of
standard Ethernet, making it compatible and versatile to fit into any environment.
Building on the versatility, DSPK4 comes in three different variants: a desktop version, a wall
mount version, and a flush mount version. There is a model for every situation. The flush
mount version comes with 4-pin female, 4-pin male, or 5-pin female front panel headset XLR
connector. RTS offers a purchasable 4-gang electrical box for the flush mount model
installation. The wall mount and desktop versions have all three XLR connectors.
Power the DSPK4 via an external AC/DC power adapter, a DC +24 V terminal block, or by
PoE+ / PoE++ (Power over Ethernet). In addition, you can have peace of mind when powering
the DSPK4 with Local DC power because PoE+ / PoE++ is ready to take over as a redundant
power supply with no interruptions if the unexpected happens.
The DSPK4 has a full-color TFT display and an icon-based menu interface, which allows for
local configuration of essential customer preferences.
Features
– Supports power redundancy from an external DC power supply or the Local +24V
terminal block to PoE+ / PoE++
– Supports connections to an OMNEO Main Station (Digital Party Line) or an OMNEO
capable matrix (ADAM or ADAM M with OMI installed or ODIN).
– Features a high-resolution TFT display, allowing user setup and configuration using an
icon-based GUI.
– Multiple DSPK4 variants: Desktop and Wall Mount devices with 4-pin and 5-pin headset
connectors and a Flush Mount device with 4-pin male, 4-pin female or 5-pin female
connector options.
– Supports Bluetooth audio connectivity via Bluetooth enabled USB dongles and phone
connectivity.

10 en | Reference view DSPK4 User Station
2023-03 | V01 | F.01U.409.148 Technical Manual Bosch Security Systems, LLC
3 Reference view
NOTE: The callouts below are for all models, unless otherwise noted.
Figure3.1: DSPK4 front panel call outs
Call out Description
1 Front panel headset connector1
2 Front panel microphone connector
3 Mounting hole covers
4 Talk/Listen keys (A, B, C, D)
5 Master Volume Control knob / Key A and C Volume knob
6 BACK/CLR button
7 SHIFT button
8 SEL/MENU button
9 Master Volume Control knob / Key B and D Volume knob
10 Speaker
11 Display screen
12 Mic Select button
13 CALL button
14 Mic Mute button
1 - The DSPK4-F has either a 4-pin, or 5-pin option.

DSPK4 User Station Reference view | en 11
Bosch Security Systems, LLC Technical Manual 2023-03 | V01 | F.01U.409.148
1 2 3 4 5 6 7 8
Figure3.2: DSPK4 rear and side panel call outs
Callouts Description
1 USB Bluetooth dongle connector
2 GPIO terminal block
3 DC power supply connector pin out diagram
4 External DC power supply connector
5 DC power terminal block
6 PoE+/++ and OMNEO Ethernet connector
7 OMNEO Ethernet connector
8 XLR headset connector (DSPK4-D and DSPK4-W only)Right and left panel
connectors.
1
Figure3.3: DSPK4 bottom-side call outs
Callouts Description
1 Keyhole slots for wall mounting (DSPK4-W only)

12 en | Connections DSPK4 User Station
2023-03 | V01 | F.01U.409.148 Technical Manual Bosch Security Systems, LLC
4 Connections
Pin Assignment
Tip Rear Panel Mic In+
Ring Rear Panel Mic In -
Sleeve Chassis Ground
Table4.1: Front Panel 1/4-inch Jack
5-pin Dynamic 5-pin Electret 4-pin Dynamic 4-pin Electret
Pin 1 Mic - Ground Mic - Ground
Pin 2 Mic + Mic Mic+ Mic
Pin 3 Speaker - Speaker - Speaker - Speaker -
Pin 4 Left Speaker + Left Speaker + Speaker + Speaker +
Pin 5 Right Speaker + Right Speaker + N/A N/A
Pin 6 Push-to-talk
input
Push-to-talk
input
Table4.2: Headset Connectors
Pin Data
Pin 1 +5V
Pin 2 Data -
Pin 3 Data +
Pin 4 Ground
Table4.3: USB Connector
Pin Assignment Silk Screen
1 Relay Common C
2 Relay normally closed NC
3 Relay normally open NO
4 Opto-Input Anode A+
5 Opto-Input Cathode K-
6 Chassis Ground
Table4.4: GPIO Connector J2
Pin Assignment
1 +24V DC
2 Ground

DSPK4 User Station Connections | en 13
Bosch Security Systems, LLC Technical Manual 2023-03 | V01 | F.01U.409.148
Pin Assignment
3 Chassis Ground
Table4.5: External DC Power Connector J3
Pin Assignment
1 Chassis Ground
2 Ground
3 +24V DC
Table4.6: Terminal Block Power Connector J4
i
Notice!
+24V power terminal block shall be connected to PS2 or LPS source.
Pin Data Power
1 Data A+ DC+
2 Data A- DC+
3 Data B+ DC-
4 Data C+ DC+
5 Data C- DC+
6 Data B- DC-
7 Data D+ DC-
8 Data D- DC-
Table4.7: PoE In J5
Pin Data
1 Data A+
2 Data A-
3 Data B+
4 Data C+
5 Data C-
6 Data B-
7 Data D+
8 Data D-
Table4.8: Ethernet Connector J6

14 en | Mounting instructions DSPK4 User Station
2023-03 | V01 | F.01U.409.148 Technical Manual Bosch Security Systems, LLC
5 Mounting instructions
5.1 Mount the DSPK4-W wall mount
i
Notice!
We recommend that this device not be mounted in a high traffic area where it could be
accidently dismantled. Always observe local codes and requirements.
Before mounting the unit:
– It may be necessary to predrill the holes or use screw anchors, depending on the type of
mounting surface.
– The unit comes with three wood screws. If you need to use different screws due to a
different mounting surface, be sure to adhere to the following guidelines:
– Screw diameter: M5
– Screw head diameter: no more than 10mm across
– Screw head height: no more than 3.5mm tall
– The screw spacing is not consistent with standard residential stud spacing. You may need
to use appropriate wall anchors if mounting the DSPK4 on a gypsum wall.
!
Caution!
Proper wall mounting
To reduce the risk of injury to yourself or damage to the device:
- Follow all instructions provided.
- Ensure the wall structure/materials will support the weight of the device.
- Use the recommended hardware for your device based on the wall structure/materials.
- Additional reinforcement may be required depending on the wall structure/materials the
device will be installed and local codes and standards.
To mount the unit on the wall, do the following:
1. Using the screw-hole template provided in the box and a pencil, mark the three screw
hole locations on the wall.
2. Using a screwdriver, drive screws into the predefined holes.

DSPK4 User Station Mounting instructions | en 15
Bosch Security Systems, LLC Technical Manual 2023-03 | V01 | F.01U.409.148
4-6 mm
[0.15-
0.23 in]
M5
10 mm
[0.3 in]
3.5 mm
[0.1 in]
3. Align the bottom of the unit over the screws, allowing the screw heads to slide into the
largest part of the keyhole opening.

16 en | Mounting instructions DSPK4 User Station
2023-03 | V01 | F.01U.409.148 Technical Manual Bosch Security Systems, LLC
1
2
4. Using suitable force, slide the unit downward, ensuring it locks into place.
If the unit does not lock in place, remove it completely from the wall and retry
IMPORTANT:
It is necessary for all screws to protrude from the wall at approximately the same height. The
height should be 4-6mm from the underside of the screw head to the wall.
– If the screw is inserted too far, the unit cannot latch in place.
– If the screw is not inserted far enough, the unit is not locked in place properly and can
potentially fall off the wall.
5.2 Mount the DSPK4-F flush mount
5.2.1 Console mounting
If you choose to console mount your unit, you can power the unit using PoE, External DC
Power Supply, or DC Terminal Block. For more information, see Power, page 21 .
i
Notice!
If using External DC Power Supply or DC Terminal Block, PoE can act as a failover option. This
means if DC Power fails, the unit automatically switches to PoE.
To console mount the unit, do the following:
1. Use the console mounting cutout guide found in the box to cut a hole in the surface to
which you are installing the unit and drill the clearance holes.
2. Place the unit in the console cutout.
3. On the rear panel of the unit, thread the screws through the clearance holes from the
back of the console into the rear panel of the unit.

DSPK4 User Station Mounting instructions | en 17
Bosch Security Systems, LLC Technical Manual 2023-03 | V01 | F.01U.409.148
i
Notice!
Front Panel Damage/Dimpling
The screws needs to protrude past the console-mounting surface at a minimum of 10 mm, but
no more than 14 mm. Any more than 14mm can cause dimpling/damage to the front cover of
the unit.
10-14 mm
[0.39 -
0.55 in]
4. Tighten the screws into the threaded holes of the unit.

18 en | Mounting instructions DSPK4 User Station
2023-03 | V01 | F.01U.409.148 Technical Manual Bosch Security Systems, LLC
5.2.2 Standard 4-gang electrical box mounting
i
Notice!
We recommend using a metal 4-gang electrical box, not a plastic or other material electrical
box.
RTS offers a purchasable 4-gang electrical box for flush-mount model installation.
To mount in a standard 4-gang electrical box, do the following:
1. Using a flat head screwdriver, gently pry the four rubber plugs from the front panel.
2. Remove the knockouts from the bottom of the electrical box to allow for wire routing.
You may not use every knock out. It depends on the connections to the device.
i
Notice!
You cannot power the flush mount unit with the External DC power supply when using it in
combination with an electrical box. The connector protrudes too far.
We recommend using PoE+/++ to power the unit.
3. Thread the cables through the knockouts on the electrical box.

DSPK4 User Station Mounting instructions | en 19
Bosch Security Systems, LLC Technical Manual 2023-03 | V01 | F.01U.409.148
4. Connect the cables to the unit.
5. Tip the unit forward slightly so the cables clear the metal lip of the electrical box while
inserting it into the electrical box.

20 en | Mounting instructions DSPK4 User Station
2023-03 | V01 | F.01U.409.148 Technical Manual Bosch Security Systems, LLC
>/=12.7mm
[0.5 in]
x4
6-32
6. Secure the unit to the electrical box with 6-32 machine screws (x4).
The minimum screw length is12.7mm (0.5 inch).
7. Replace the rubber plugs on the screw heads.
