RT214 Integration Guide
3
RT214 Integration Guide

RT214 Integration Guide
1
Contents
Introduction............................................................................................................................................................................................................... 2
Illumination................................................................................................................................................................................................................3
Aimer.......................................................................................................................................................................................................................... 3
Introduction............................................................................................................................................................................................................... 4
General Requirements...............................................................................................................................................................................................4
ESD.....................................................................................................................................................................................................................4
Dust and Dirt.....................................................................................................................................................................................................4
Ambient Environment..................................................................................................................................................................................... 4
Thermal Considerations.................................................................................................................................................................................. 5
External Optical Elements............................................................................................................................................................................... 5
Mounting.................................................................................................................................................................................................................... 6
Housing Design.......................................................................................................................................................................................................... 7
Optics.......................................................................................................................................................................................................................... 7
Window Placement.......................................................................................................................................................................................... 7
Window Material and Color............................................................................................................................................................................ 8
Coatings and Scratch Resistance.....................................................................................................................................................................9
Window Size................................................................................................................................................................................................... 10
Roll, Skew and Pitch.......................................................................................................................................................................................11
Ambient Light................................................................................................................................................................................................. 12
Eye Safety........................................................................................................................................................................................................12
Power Supply........................................................................................................................................................................................................... 13
Ripple Noise............................................................................................................................................................................................................. 13
DC Characteristics................................................................................................................................................................................................... 13
Operating Voltage.......................................................................................................................................................................................... 13
I/O Voltage......................................................................................................................................................................................................17
Timing Sequence..................................................................................................................................................................................................... 18
Power Up Timing Sequence.......................................................................................................................................................................... 18
Interface Pinouts..................................................................................................................................................................................................... 21
Connector Specifications........................................................................................................................................................................................ 24
External Circuit Design........................................................................................................................................................................................... 24
Good Read LED Circuit...................................................................................................................................................................................24
Beeper Circuit.................................................................................................................................................................................................25
EVK........................................................................................................................................................................................................................... 27

RT214 Integration guide
2
Introduction
The RT214 is an area image engine for barcode reading. It includes an illumination LED and an aiming LED.
LED Compliance Statement
The RT214 complies with IEC 62471:2006 for LED safety.
The RT214 contains:
•a CMOS image sensor and its lens
•an LED based illumination system
•an LED aiming system
Figure 1-1 System Block Diagram

RT214 Integration guide
3
Illumination
The RT214 has a white LED for supplementary lighting, making it possible to scan barcodes even in complete darkness. The
illumination can be programmed On or Off.
Aimer
The RT214 contains a red LED aimer to help the user to easily position the target barcode within the engine’s field of view to
increase scan efficiency. The aiming pattern can be turned On or Off. It is advisable to turn it on when scanning barcodes in regular
circumstances. For applications in the background of different materials and colors or in the strong light or backlight environment,
it is advised to turn off the aimer.

RT214 Integration guide
4
Introduction
This chapter explains how to install the RT214, including general requirements, housing design, and physical and optical
information.
△
！
Cau ti on : Do no t to u c h t he imaging len s when in st alling th e engine . Be c are fu l no t to lea v e f ingerprin ts on t he len s.
△
！
Cau ti on : Do no t to u c h t he illumina ti on LED during handling . I mproper handling m a y damage t he L ED.
General Requirements
ESD
ESD protection has been taken into account when designing the RT214. However, due to limited board space, additional ESD
protection, such as TVS protection, is not provided on the engine’s I/O interface. It is advised to take corresponding protection
measures when integrating the engine.
The engine is shipped in ESD safe packaging. Always exercise care when handling the engine outside its package. Be sure
grounding wrist straps and properly grounded work areas are used.
Dust and Dirt
The RT214 must be sufficiently enclosed to prevent dust particles from gathering on the lens and circuit board. Dust and other
external contaminants will eventually degrade the engine’s performance.
Ambient Environment
The following environmental requirements should be met to ensure good performance of the RT214.
Table 2-1
Operating Temperature
-20°C to 55°C
Storage Temperature
-40°C to 70°C
Humidity
5% ~95% (non-condensing)

RT214 Integration guide
5
Thermal Considerations
Electronic components in the RT214 will generate heat during the course of their operation. Operating the RT214 in
continuous mode for an extended period may cause temperatures to rise on CPU, CIS, LEDs, DC/DC, etc. Overheating can
degrade image quality and affect scanning performance. Given that, the following precautions should be taken into
consideration when integrating the RT214.
Reserve sufficient space for good air circulation in the design.
Avoid wrapping the RT214 with thermal insulation materials such as rubber.
External Optical Elements
Do not subject external optical components on the engine to any external force. Do not hold the engine by an external optical
component, which may cause the mechanical joints that secure the components to crack or break due to excessive stress.

RT214 Integration guide
6
Mounting
The illustrations below show the mechanical mounting dimensions (unit: mm) for the RT214.
Figure 2-1
Note: Tolerance of dimension is ±0.15mm.

RT214 Integration guide
7
Housing Design
※Note: Conduct an optical analysis for the housing design to ensure optimal scanning and imaging performance.
Housing design should make sure that internal reflections from the aiming and illumination system are not directed back to
the engine. The reflections from the housing or window can cause problems. Avoid any highly reflective objects around the
engine that can cause bright spots to appear in the captured image. It is recommended to use baffles or matte-finished dark
internal housing colors.
Optics
The RT214 uses a sophisticated optical system. An improperly designed internal housing or improper selection of window
material can degrade the engine’s performance.
Window Placement
The window should be positioned properly to let the illumination and aiming beams pass through as much as possible and no
reflections back into the engine (reflections can degrade the reading performance of the engine).
There are two window placement options.
•Parallel window – Primary option for imager engines. The following window distance requirements should be satisfied:
The maximum distance is measured from the front of the engine housing to the furthest surface of the window. In order to
reach better reading performance, the distance from the front of the engine housing to the nearest surface of the window
should not exceed a(a=0.1mm) and the distance from the front of the engine housing to the furthest surface of the window
should not exceed a+d (a=0.1mm, d=2mm), as shown in Figure 2-2.
•Tilted window - This option is for laser/imager engines. For the tilted window distance requirements, please see Table 2-2.

RT214 Integration guide
8
Figure 2-2
Table 2-2
Minimum Angle (Tilted Window)
Distance from the front of the engine housing (b)
10mm
15mm
20mm
Uncoated, minimum window positive tilt (+w)
35°
30°
28°
Uncoated, minimum window negative tilt (-w)
Window Material and Color
Window material must be clear. Use only cell-cast plastics or optical glass. PMMA and chemically tempered glass are
recommended. Window material selected for the engine should meet or exceed the specifications specified in Table 2-3. When
using a clear plastic window, it is recommended to apply anti-reflection (AR) coating on it.
•PMMA (Cell-cast acrylic): When fabricated by cell-casting, has very good optical quality and low initial cost, but surface
must be protected from the environment due to its susceptibility to attack by chemcials, mechanical stresses, and UV light.
Reasonably good impact resistance.
•Chemically tempered glass: Glass is a hard material which provides excellent scratch and abrasion resistance. But
unannealed glass is brittle. Increased flexibility strength with minimal optical distortion requires chemical tempering. Glass
is hard to be cut into odd shapes and cannot be ultrasonically welded.

RT214 Integration guide
9
Table 2-3
Specification
Description
Spectral Transmittance
≥90% (PMMA)
≥91% (Chemically tempered glass)
Thickness
0.5-2.0mm
Light Wavelength
400-780nm
Clear Aperture
1.0mm to edges
Surface Quality
60-20 scratch/dig
Pay extra attention to the light wavelength when using plastic materials. Colored windows are not recommended if the engine
is used to scan barcodes on moving objects.
Coatings and Scratch Resistance
Scratch on the window can greatly reduce the performance of the RT214. It is suggested to use abrasion resistant window
material or coating.
The following introduces two commonly-used types of coatings:
•Anti-reflection coatings: Anti-reflection (AR) coatings can be applied to window surfaces to reduce reflected light from the
window back into the engine. Multi-layer AR coatings on windows help to achieve less than 0.5% reflectance and covered
wavelength is 400-780nm.
•Scratch resistance coatings: Scratch resistance coatings require a degree of greater than 5H in its hardness. Coatings can be
applied to plastic surfaces to increase the surfaces’abrasion and scratch resistance.
Both tempered glass and plastic windows can be AR coated. However, it is easier and more cost-effective to put an AR coating on
the glass than on the plastic.
The AR coating specifications below should be met when using an AR coated window.
Single side AR coating: 93% minimum transmittance within spectrum range from 400 nm to 780 nm.
Double side AR coating: 97% minimum transmittance within spectrum range from 400 nm to 780 nm.
