RugDoctor 93306 User manual

Portable
Spot Cleaner
USER MANUAL
Model Number: 93306
Motorised brush for use on:
STAIRS VEHICLE UPHOLSTERY SPOTS/STAINS
Y
E
A
R
G
U
A
R
A
N
T
E
E

2 UK 01903 23 55 58 EIRE 1800 93 20 96 UK 01903 23 55 58 EIRE 1800 93 20 96 3
Founded by a professional carpet cleaner in 1972, the
rst Rug Doctor machines were designed and built for
professional use. A brand was born and soon after,
Rug Doctor launched the rst rental programme that made
professional-grade carpet cleaning machines available to
the public. More than 40 years later, Rug Doctor are seen
as the Carpet Care Experts and have become a household
name around the world. The brand continues as the leader
in carpet care rental systems with powerful carpet and
upholstery cleaning machines and innovative products.
Rug Doctor Ltd., Unit 29, Decoy Road
Timberlaine Trading Estate, Worthing
West Sussex BN14 8ND
[e-mail]
www.rugdoctor.co.uk
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Please read all instructions before using.
When using an electrical appliance,
basic precautions should always be
followed, including the following:
If faulty, do not attempt any maintenance or repair: contact Rug Doctor
∆This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning the use of the appliance by a
person responsible for their safety.
∆Children should be supervised to ensure that they do not play with the appliance
∆The plug must be removed from the mains socket before filling, emptying or cleaning the
machine.
∆During operation, the cleaning solution sprayed out could be hazardous due to its
temperature, pressure or chemical content. Refer to warnings printed on the Rug Doctor
Portable Spot Cleaner bottle.
∆Do not use shampoo or any foaming detergent in this machine. If foam appears in the
recovery tank during operation switch o immediately and empty tank.
∆Care must be taken to ensure that the power cable remains undamaged. If damaged, do
not change, return machine to Rug Doctor.
∆To avoid scalding or burns, use caution when handling hot tap water to fill tanks. Do not
boil or microwave water to be used in machine. Use only luke warm water when cleaning
wool or wool blend carpets.
∆Do not leave appliance unattended when plugged in or while it is on. Unplug from mains
socket when not in use and before servicing.
∆To reduce the risk of fire and electric shock due to internal component damage, use
only Rug Doctor® cleaning products intended for use with this appliance.
∆Do not allow to be used as a toy. Not intended for use by children. Close attention and
adult supervision is necessary when used near children. Do not allow children to place
their body parts in or near openings and moving parts.
∆Use only as described in this manual. Use only Rug Doctor’s recommended products.
∆Do not use with damaged power cable or plug. If appliance is not working as it should,
has been dropped, damaged, left outdoors or dropped into water, stop using and return
it to Rug Doctor.
∆Do not pull or carry by power cable, use power cable as a handle, close a door on power
cable, or pull power cable around sharp edges or corners. Do not run appliance over
power cable. Keep power cable away from heated surfaces.
∆Do not unplug by pulling on power cable. To unplug, grasp the plug, not the power cable.
∆Do not handle plug or appliance with wet hands.
∆Do not put any object into openings. Do not use if any opening is blocked; keep free of
dust, lint, hair, and anything that may reduce air flow.
∆Keep hair, loose clothing, fingers and all parts of body away from openings and moving
parts.
∆Turn o all controls before unplugging.
∆Use extra care when cleaning on stairs.
∆Do not use to pick up flammable or combustible liquids or materials such as petrol, paints
or use in areas where they may be present.
∆Do not use to pick up anything that is burning or smoking, such as cigarettes, matches, or
hot ashes.
∆Do not place in or pick up caustic or toxic materials (Such as, bleach, ammonia, toilet
bowl cleaner and drain cleaners) with machine.
∆Use only on surfaces moistened by cleaning process or small spills. Do not place or
submerge machine in standing water or try to clear flooded areas.
∆Do not clean over floor mounted electrical mains sockets.
∆The use of an extension power cable is not recommended.
∆Failure to follow the foregoing instructions may expose the user to the possibility of
electric shock, personal injury and/or death.
∆When clean water tank runs out, stop using the machine and follow instructions to refill.
∆Do not operate without tanks or in any manner inconsistent with above warnings or
the operating instructions set forth in this manual.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, INJURY OR PROPERTY DAMAGE:
3 Safety Instructions
4 Cleaning Tips
5 Parts, Components
6 How To Clean / Features
8 Troubleshooting &
Replacement Parts
9 Other Cleaning Solutions
10 Warranty Information

4 UK 01903 23 55 58 EIRE 1800 93 20 96 UK 01903 23 55 58 EIRE 1800 93 20 96 5
CLEANING TIPS
1. Pick-up and discard any solid debris in the area before using your
RUG DOCTOR PORTABLE SPOT CLEANER.
2. Always test colour fastness before using on carpets and upholstery:
A. Wet an inconspicuous area with a small amount of cleaner
B. After 1-2 minutes, blot with a white paper towel and check for colour
transfer
3. When cleaning, make sure the suction nozzle is in direct contact with
the surface you are cleaning. You will be able to see the dirty solution being sucked into
the nozzle. If you don’t see it, tilt the nozzle forward to ensure good vacuum suction and
pass over the area again.
4. When using RUG DOCTOR PORTABLE SPOT CLEANER on stairs, keep the machine
on the step or two below where you are cleaning for easy manoeuvrability. Use the
convenient “Easy Carry” handle to move from step to step.
Use only RUG DOCTOR PORTABLE MACHINE SPOT CLEANER whenever you use
your RUG DOCTOR PORTABLE SPOT CLEANER as it has been specially formulated to
give best cleaning results. Using Non-RUG DOCTOR cleaning solutions may harm the
machine and will void the warranty.
PRE-ASSEMBLED
READY TO GO
OUT OF
THE BOX!
PRODUCT PARTS, COMPONENTS
Retractable
handle
“Easy Carry”
handle
No tangle
power cable wrap
Carpet–friendly
wheels for extra
manoeuvrability
Slim design to
t on stairs
Flexible hose
with compact
storage
Removable
clean
water tank
Rug Doctor’s exclusive
MOTORISED
handheld brush
CLEANING SOLUTION
RUG DOCTOR PORTABLE MACHINE SPOT CLEANER is
specially formulated for the RUG DOCTOR PORTABLE SPOT
CLEANER. Deep clean spots and stains all around your home;
carpets, stairs, upholstery, mattresses, vehicles and more! Keep
RUG DOCTOR PORTABLE MACHINE SPOT CLEANER always at
the ready.
Use only Rug Doctor Portable Machine Spot Cleaner on wool or
wool blend carpets. No other cleaner is recommended.
Removable
waste water tank
SPRAY
trigger

6 UK 01903 23 55 58 EIRE 1800 93 20 96 UK 01903 23 55 58 EIRE 1800 93 20 96 7
WHEELS & RETRACTABLE “LUGGAGE STYLE” HANDLE
1. To lift the RETRACTABLE HANDLE press down on the HANDLE
RELEASE button while lifting the handle upward.
2. Tip the unit back and pull to manoeuver easily around your home.
3. To retract the handle, press down on the HANDLE RELEASE
button pushing the handle downward until completely recessed
into the unit.
EMPTYING THE WASTE WATER TANK
1. Empty the WASTE WATER TANK when the dirty water reaches the “Full Line”
2. Remove the WASTE WATER TANK from the unit by pulling the tank forward and
lifting it straight up. The inlet on the side of the tank is now open so it is important
to KEEP IT UPRIGHT while you go to the sink or toilet to dispose of the dirty
water.
3. Over a sink or toilet, turn the tank on its side and allow the dirty water to pour out
of the inlet.
4. In order to clean the WASTE WATER TANK, unscrew the WIDE OPENING LID.
Remove the WIDE OPENING LID and oat column from inside the tank and set
aside.
5. Remove any debris in the tank and around the lter and rinse the inside of the
tank.
6. Replace the oat column and the WIDE OPENING LID, rmly tighten the cap.
7. Replace the WASTE WATER TANK by setting it straight down into the unit,
pressing down rmly until it feels secure.
REFILL THE CLEAN WATER/SOLUTION TANK
1. Simply lift the CLEAN WATER TANK straight up from the unit.
2. Unscrew the cap and pull the nozzle to remove the tube from the tank.
3. Add RUG DOCTOR PORTABLE MACHINE SPOT CLEANER formula to the
“SPOT CLEANER” ll line shown at the bottom of the tank. Each 120ml ll is the
equivalent of just over a third of a coffee mug full. Add hot tap water, lling to the
“Clean Water” line marked on the tank. Only use luke warm water on wool/wool
mix carpets. DO NOT BOIL OR MICROWAVE WATER.
4. Insert the tube into the tank, replace the cap and tighten.
5. Replace the tank by setting it straight down into the unit, pressing down rmly
until it feels secure.
After you’ve used your RUG DOCTOR PORTABLE SPOT CLEANER follow these easy
steps for quick clean-up and storage of your unit.
1. Unplug the power cable from the mains socket and wrap it around the power
cable retainers.
2. Wrap the ex hose around the hose retainers and replace the MOTORISED BRUSH
on the unit.
3. Empty the CLEAN WATER TANK (if necessary), rinse and replace on the unit.
4. Empty the WASTE WATER TANK then rinse, clean and dry before placing back on
the unit. The WIDE OPENING LID tank opening is designed to allow your hand to
t inside to thoroughly clean, rinse and dry, for a fresh clean tank.
5. Store the handle in the recessed position for compact storage.
6. Keep in a protected, dry area at room temperature. IMPORTANT: DO NOT
EXPOSE THE UNIT TO TEMPERATURES BELOW 4o C (40o F) AND ABOVE 43o C
(110o F).
POWERFUL,
MOTORISED
BRUSH
FOR A DEEP
DOWN CLEAN
You’re now ready to deep clean spots and stains on carpet, upholstery
and hard to clean places such as stairs and vehicles. Your RUG
DOCTOR PORTABLE SPOT CLEANER has innovative features; A
powerful MOTORISED BRUSH to clean deep down and WHEELS and a
RETRACTABLE “LUGGAGE STYLE” HANDLE to make getting to the stain
easier than ever before.
MOTORISED BRUSH
1. With the unit powered on, position the MOTORISED BRUSH well in front of the stain or
area you want to deep clean.
2. Turn ON the MOTORISED BRUSH by pressing power switch to the “ON” position.
3. Squeeze and hold the SPR AY trigger to begin cleaning. Slowly move the tool over the
stain, releasing the SPRAY trigger at the end of the cleaning process. For dried-in or
deep down stains, make multiple passes, but do not overwet the carpet or upholstery
you are cleaning.
4. Excess water can be removed by making additional passes with the tool without
squeezing the SPRAY trigger. This will allow faster drying time and avoid overwetting.
5. Leave machine on for 15 seconds after cleaning to allow all of the dirty solution to be
collected into the WASTE WATER TANK.
SETTING UP/ GET READY TO CLEAN
Your RUG DOCTOR PORTABLE SPOT CLEANER is ready to start cleaning right out of
the box. No assembly required! Follow these simple instructions to start cleaning.
Fill the CLEAN WATER TANK:
a. Simply lift the CLEAN WATER TANK straight up from the unit.
b. Unscrew the cap and pull the nozzle to remove the tube from the tank.
c. Add hot tap water, lling to the CLEAN WATER line marked on the top of the
tank. Only use luke warm water on wool/wool mix carpets. DO NOT BOIL OR
MICROWAVE THE WATER.
d. Pour RUG DOCTOR PORTABLE MACHINE SPOT CLEANER solution into the
tank, lling to the “Spot Cleaner” line marked on the tank. Each 120ml ll is the
equivalent of just over a third of a coffee mug full.
e. Insert the tube back into the tank, replace the outer cap and tighten.
f. Replace the tank by setting it straight down into the unit, pressing down rmly
until it feels secure.
1. Lift the MOTORISED BRUSH from the unit and completely unwrap the ex hose
from around the hose retainers.
2. Rotate the power cable retainers on the back of the unit to release the power
cable and unwrap completely. Plug into a mains socket.
HOW TO CLEAN / FEATURES
HOW TO CLEAN / FEATURES (CONT)
CLEANING UP & STORAGE AFTER USE
CARPET
FRIENDLY
WHEELS,
EASY TO
MANOEUVER
DO NOT USE BOILED OR MICROWAVED WATER IN TANK. Doing so could
result in scalding or burns. ALWAYS CHECK FOR COLOURFASTNESS.
Do not overwet the carpet. Use luke warm water on wool and wool blend
carpets. DO NOT USE on natural bre, silk or pure wool oriental rugs, hand
loomed wool rugs, braided rugs, sisal, sea grass matting or jute carpets, silk,
haitian cotton, brushed corduroy, leather, non colourfast fabrics, berber,
Flotex, Ryalux carpets, wood effect laminate ooring. Doing so could
damage material and void warranty on machine. Do not walk on wet carpet.

8 UK 01903 23 55 58 EIRE 1800 93 20 96 UK 01903 23 55 58 EIRE 1800 93 20 96 9
Problem Possible Reason How to Fix
No Power Power cable not plugged in
Power button not pressed
Plug power cable into wall
mains socket
Press unit power
button on
No / Low Spray Not pressing spray trigger
Clean Water / solution tank
is empty or low
Clean Water tank is
not seated or installed
correctly
Spray is clogged
Press spray trigger
Fill Clean Water tank with
water and solutions
Lift Up Clean Water tank,
secure outer cap and
reposition
Clean the spray spout
No / Low Suction Waste Water / collection
tank Is full
Waste Water / collection
tank is not seated /
installed correctly
Filter screen inside Waste
Water / collection tank
clogged
Empty Waste Water /
collection tank
Lift Up Waste Water /
collection tank and place
back into position
Clean off debris on lter
screen inside Waste Water
/ collection tank
MOTORISED Brush Doesn’t
Oscillate Brush mode is not switched on Turn MOTORISED BRUSH button to the on position.
Ensure that you have
vacuumed over the area
rst so debris or hair does
not get caught or tangled
in the brush
Replacement Parts Image Part #
Clean Water Tank (with Tube, Nozzle &
Cap) 93074
Waste Water Tank (with Float
Column & Wide Opening Lid) 93076
Retractable Handle Replacement 93077
TROUBLE SHOOTING
REPLACEMENT PARTS
Accessories and replacement parts are available for your RUG DOCTOR PORTABLE SPOT
CLEANER by calling Rug Doctor Customer Service UK 01903 23 55 58 or EIRE 1800 93 20 96
or visiting www.rugdoctor.co.uk.
CALL UK 01903 23 55 58 or EIRE 1800 93 20 96 if problem is not resolved
Rug Doctor Trafc Lane Cleaner
A pre-treatment for cleaning heavy
trac areas on carpets. It helps to lift
and loosen ground in dirt and soiling
and is especially eective on greasy
and oil based stains.
Rug Doctor Urine Eliminator
Eliminates foul odours in carpets and
furnishings caused by pets, children
or the incontinent. It’s enzyme
technology removes the hard urine
crystals from dried in stains. Eective
against urine, blood, faeces and vomit
stains. It can also be used as a pre-
treatment to machine cleaning.
Rug Doctor Odour Remover
An alkaline based treatment. It uses an
enzymatic process to eliminate most
foul odours including food, smoke
and animal waste, leaving the aected
area deodorised. Eective on some
dried in stains.
These cleaning solutions are available in over 3,500 stores across the UK.
See our store finder on www.rugdoctor.co.uk for your nearest outlet.
OTHER RUG DOCTOR CLEANING SOLUTIONS

10 UK 01903 23 55 58 EIRE 1800 93 20 96 UK 01903 23 55 58 EIRE 1800 93 20 96 11
2.4. Rug Doctor does not exclude or limit in any way its liability for:
(a) death or personal injury caused by its negligence or the negligence of
its employees, agents or subcontractors;
(b) fraud or fraudulent misrepresentation;
(c) breach of the terms implied by section 12 of the Sale of Goods Act
1979 (title and quiet possession);
(d) breach of the terms implied by sections 13, 14 and 15 of the Sale of
Goods Act 1979 (description, satisfactory quality, fitness for purpose
and samples); and
(e) defective products under the Consumer Protection Act 1987.
Expenses
If a Machine is returned to Rug Doctor for repair under the guarantee at Clause 1.1
within thirty (30) days of delivery, Rug Doctor will pay the delivery charges both
from and back to you. However, you will be responsible for paying any delivery
charges for Rug Doctor sending the Machine back to you if the Machine is not
considered by Rug Doctor to have a material defect.
Thereafter, you may be required to send the machine to Rug Doctor should repairs
be required during the Guarantee Period. You will be responsible for paying any
delivery charges for sending the Machine to and from Rug Doctor for repairs
occurring under the guarantee and within the Guarantee Period and after the initial
thirty (30) days.
How Do I Get Service Under This Guarantee?
TO OBTAIN GUARANTEE ASSISTANCE, please call the Rug Doctor Consumer
Support Team on: 01903 235558 (9.00 am to 5.00 pm Mon - Fri) or e-mail
[e-mail]. Rug Doctor will need the following information
in order to assist you: your name, address and telephone number, product model
and serial number, proof of purchase showing date and place of purchase. Please
explain the nature of the problem.
Rug Doctor will review all the facts involved and advise you as to recommended
procedure. We recommend you keep the original carton and packing materials.
Rug Doctor Ltd, Unit 29, Timberlaine Trading Estate Decoy Road, Worthing,
West Sussex BN14 8ND
E-mail: [e-mail] Web Site: www.rugdoctor.co.uk
Unauthorised Use
For the avoidance of doubt, use of the Machine for rental purposes is strictly
forbidden and would result in you being unable to rely on this Guarantee. This
Guarantee gives you specific legal rights. We hope you enjoy your Portable Spot
Cleaner cleaning experience.
You can register your Rug Doctor® Portable Spot Cleaner
machine at www.rugdoctor.co.uk
What Does This Guarantee Cover / How Long Does The Guarantee
Last
1.1. Rug Doctor guarantees to the original purchaser for a period of 2 years from
the date of purchase (“Guarantee Period”), the machine supplied by Rug Doctor
and every component part thereof (collectively, “Machine”) shall be free from
material defects. However, this guarantee is subject to Clauses 1.2, 1.4 and 2.4
and does not apply in the circumstances described in Clause 2.1.
1.2. Subject to Clause 2.1, if:
(a) you give notice (in accordance with the “How Do I Get Service Under
This Guarantee” section below) to Rug Doctor during the Guarantee
Period within a reasonable time of discovery that the Machine has a
material defect; and
(b) Rug Doctor is given a reasonable opportunity of examining the Machine;
and
(c) you (if asked to do so by Rug Doctor) return the Machine to Rug
Doctor’s place of business, payment for which will be in accordance with
the “Expenses” section below;
Rug Doctor will repair or replace the Machine without further charge.
1.3. The guarantee at Clause 1.1 shall apply to any replacement Machine (for a period
of 12 months from the date of delivery of that replacement) and any repaired
Machine (for the original Guarantee Period) supplied by Rug Doctor.
1.4. This Guarantee is given in addition to, and does not aect, your legal rights in
relation to the Machine that is faulty or not as described. Advice about your legal
rights is available from your local Citizens’ Advice Bureau or Trading Standards
oce.
What The Guarantee Does Not Cover
2.1. The guarantee at Clause 1.1 does not apply to any defect in the Machine arising
from:
(a) any further use of the Machine made by you or any third party after
giving notice in accordance with Clause 1.2;
(b) your failure, or that of any third party, to follow Rug Doctor’s oral or
written instructions (including but not limited to the User Guide supplied
with the Machine) as to the storage, use and maintenance of the Machine
(as to the latter, for best operating eciency and cleaning, use of only
Rug Doctor cleaning products is recommended);
(c) any alteration or repair, or attempted alteration or repair, by you or any
third party of the Machine without the written consent of Rug Doctor;
(d) fair wear and tear, wilful damage, negligence by you or any third party,
accident, improper use and abuse, or abnormal storage or working
conditions; or
(e) use by you or any third party of the Machine in any way or at any time
for rental purposes.
2.2. If Rug Doctor fails to comply with these terms, then it shall be responsible for
loss or damage that you suer that is a reasonably foreseeable result of its
breach of the terms or its negligence, but Rug Doctor shall not be responsible
for any loss or damage that is not reasonably foreseeable.
2.3. Rug Doctor is only supplying the Machine for domestic and private use. You
agree not to use the Machine for any commercial, business or re-sale purpose,
and Rug Doctor has no liability to you for any loss of profit, loss of business,
business interruption, or loss of business opportunity.
GUARANTEE AND PRODUCT REGISTRATION

12
Portable
Spot Cleaner
71493 © 2014 Rug Doctor LLP - All rights reserved
