Runxin J50 Series User manual

The Whole House Water Filter
J50
J60
J120
J150
J180
User Manual
Please read this manual in details before using the device and keep it properly in order to
consult in the future.
Note: The design and specifications are subject to the changes without prior notice. We reserve
the right of interpretation to the user manual.
0WRX.466.571

Catalogue
Preface......................................................................................................................
1.Product Profile..........................................................................................................
2.Working Principle .....................................................................................................
3. Assembly & Parts....................................................................................................
4.Specification & Active Carbon Volume......................................................................
5. Application Range ...................................................................................................
6. Technical Parameters..............................................................................................
6.1 Parameter Table................................................................................................
6.2 Working Condition..............................................................................................
7. Function and Characteristics ...................................................................................
8.Installation................................................................................................................
8.1Installation Condition...........................................................................................
8.2Installation and Connection.................................................................................
8.3Control Valve Set and Usage..............................................................................
※The Function of Control Panel and Parameter Setting.....................................
※Parameter Set..................................................................................................
※Flow Chart .......................................................................................................
9.Usage Illustration......................................................................................................
10.Notice.....................................................................................................................
11.Troubles-Shooting..................................................................................................
12.Maintenance...........................................................................................................
13.Warranty Guidance.................................................................................................

1
Preface
Thanks for choosing our products. The whole house water filter series products are featured
by reduction of residual chlorine and other impurity things. It can meet the demand of daily laundry,
bath, cleaning and provide drinking water with high quality for organization, school, group, etc.
In order to correctly install, set, use and maintain products, please do read the manual in
details and strictly follow the steps to install and use the products. You can refer to this manual to
solve problems that you meet during the usage. This manual and product warranty card should be
kept properly.
1.Product Profile
The product is working automatically and intelligently. It adopts food-grade active carbon to
filter the raw water with the characteristics of high flow rate, good filtering effect, automatic rinsing
and long life time. It removes the harmful things efficiently such as residual chlorine, abnormal
smell, rust, mud, etc. After the active carbon disabled, the device could rinse automatically to
regenerate the carbon to make it recovering the function of filtering. The device has the functions
of service, backwash and fast rinse which are full automatically realized.
It adopts LCD display screen, menu control and hommization icons, featured by concision
and intuition. Users can set parameters and conduct operations according to the menu icons that
display on the screen.
2.Working Principle
The active carbon has the adsorption character and large surface which could absorb the
impurity things from water, such as abnormal smell, residual chlorine to make the drinking water
taste better. According to the pre-set program, it can automatically control the open and close of
each valve, so as to realize of filtering, backwash and fast rinse.

2
3. Assembly & Parts
No.
Description
No.
Description
1
Automatic Multi-port Valve
4
Active Carbon
2
FRP Tank
5
Strainer
3
Riser Pipe
6
Quartz Sand
4.Specification and & Active Carbon Volume
Model
FRP Tank Size
(Φ*h)mm
FRP Tank Model
Active Carbon
Volume L
Quartz Sand
Volume L
RL-J50
258*330
1013
5
4
RL-J60
258*434
1017
7
4
RL-J120
258*897
1035
22
4
RL-J150
258*1121
1044
31
4
RL-J180
258*1381
1054
38
4

3
5.Applicaton Range
Tap water or other water source which meet the requirement for whole house water filter.
6. Technical Parameters
6.1Parameter Table
Model
Rated Service Flow Rate
of Products Approval
Related to Drinking Water
L/h
Water Treatment Capacity
m3
Working Pressure
MPa
RL-J50
500
1.1
0.15-0.4
RL-J60
600
1.5
RL-J120
1200
3.5
RL-J150
1500
5
RL-J180
1800
6
6.2 Working Condition
Working Condition
Working Pressure
0.15MPa～0.4MPa
Water Temperature
5℃～38℃
Working Environment
Environment Temperature
4℃～40℃
Relative Humidity
≤95%（25℃）
Electrical Facility
AC100～240V/50～60Hz
Water Quality
Turbidity
＜20FTU
Inlet/Outlet
G1 or G3/4
Drain
G1 or G3/4
7. Function and Characteristics
1.Active carbon has a good performance on adsorption.
●Deodorization: Remove the abnormal smell which is caused by phenol or oil.
●Discoloration: Remove the color which is caused by the pollution of organic or resultant

4
generated by iron, manganese or plant.
●Dechloridation: Remove the stink which is caused by disinfector in drinking water (Residual
chlorine).
●Remove TOC: Remove 10-60% of organic pesticide, insecticide, chlorinated hydrocarbon,
etc.
●Remove heavy metal: Such as Hg, Cr, etc.
●Remove synthetic detergent and dyestuff.
●Remove virus.
●Remove radioactive substances.
●Remove mutagenic substances in water.
2. Regeneration starts automatically: According to the regeneration time and water treatment
capacity of one cycle, the system will start the regeneration program.
3. Automatic memory function: The parameters set by users, such as rinsing time, backwash
time, fast rinse time and so on, can be saved for good no matter how long the power is off.
4. Language can be chosen: Chinese or English can be chosen so as to meet the habit of
users.
5. Buttons lock function: No operations to buttons on the controller within 1 minute, buttons
are locked. Press and hold the “ ”and“ ” buttons for 5 seconds to unlock. This function can
avoid incorrect operation.
8.Installation
8.1 Installation Condition
※Place the product on the flat surface that can bear the weight more than 3 times of the
machine. Besides, there are water inlet and water outlet, drain pipeline and sewage in the
workplace. For the automatic product, it also needs the AC power receptacle.
※Generally, the products are installed in the equipment room, underground garage (These
places should have water inlet pipeline, water outlet pipeline, drain pipeline and sewage).Or they
can be connected with the main water inlet of the place, such as villas, apartments, schools or
business establishments, etc. If it is necessary, you can install the product outdoor. However, you
should take some protective measures to prevent the product from being frostbiting, basking and
water.
※Do not put the product near the place with alkaline and acid substance or gas, avoiding
being corroded.
※The suitable pressure for filter is between 0.15Mpa and 0.6Mpa. Booster pump or a relief
valve is necessary when the inlet pressure is lower or higher than standard.

5
※Make sure a check valve is equipped between the device and water heater when a heating
stove or water heater is connected behind the device, in case of hot water reflux and damage the
inner system of the product.
※Separate sewer line for the device is required. 5 to 10cm clearance must be maintained
between the drain pipe and floor drain, in case of siphon and cause valve damage by the waste
water.(Installation refer to below picture)
※Before installing the pipeline, please clean the residual impurity and dust in the pipeline.
After the main water inlet is closed, connect it with the device.
※All of pipeline that used should meet the relevant regulations, and the installation should
accord with the local installation rules.
※When install, please keep a certain operation space for adding salt, cleaning and
maintaining.
8.2Installation and Connection
※Pipeline installation and connection should conform to the local installation rules.
Inlet/outlet should be connected with the water pipe in the same axis (Refer to the below
installation picture). The position of inlet and outlet shouldn’t be reversed.
※It is suggested to install a manual bypass valve between the main water inlet and
inlet/outlet of the device, making it convenient for installation and maintenance. (Refer to the
below installation picture).

6
Illustration: Install two three-way ball valves to connect the control valve and inlet/outlet
pipeline. The valve B is connected with the inlet of the control valve; the valve Ais connected with
the outlet of the control valve. When repair the tank, adjust the valve A and B to make the inlet
connected with outlet directly, so the water do not pass through the valve; When normally use,
adjust the valeA and B connected with valve.
※Install the drain pipeline of water filter, use the PVC soft or hard tube.
1.Use PVC soft tube for installation
Take out the soft tube and metal clamp from the spare part kit, make the drain connector
insert into soft tube as much as possible, the insert part is no less than 20 mm (In winter, the
temperature is low, use the hot water to make the head of tube soft which is convenient for
installation.) After insert, put metal clamp on tube and tighten it by screwdriver. If it is not
convenient to assemble the tube on filter, it could remove the drain connector then assemble the
tube. Take out the clip before removing the drain connector (See following picture).
2.Use PVC hard tube for installation
When use PVC hard tube for installation, remove the connector and sealing ring as the
following picture. It needs professionals to install. The installation is like the following picture.

7
※Control valve should be higher than sewer. The length of drain line should be similar to the
height of tank. Insert the drain line to the floor drain, but not to the bottom. Leave about 5-10mm
distance between the end port of drain line and sewer.
※Each pipeline should be supported with fixed holder independently, avoiding the control valve
be damaged by bearing the gravity from the pipeline.
Notice: Please make sure the drain line and overflow line is connected and close to sewer,
making the waste water flow into the sewer rapidly.
8.3Control Valve Set and Usage
※The Function of Control Panel and Parameter Setting
For this series products, foreground mode and background mode can be selected. Foreground
mode is suitable for user and can set Time of Day, Rinsing Time, etc. Background mode can set
other parameters by manufacturer, such as Service, Backwash Time, Fast Rinse Time, etc.
Foreground parameter enquiry and setting

8
A. Button lock indicator
●Lights on, indicating the buttons are locked. At this moment, press any single button will not
work (No operation in one minute, will light on and lock the buttons.)
●Solution: Press and hold both and for 5 seconds until the lights off.
B. “ ” Menu/Confirm button
●Press under the service status, the system turns into setting interface. Select the item and
inquire the value.
●Under inquiry status, press and the digits flash. It turn into setting interface, and you can
adjust the parameters by press and .
●After the setting, press and turn into setting interface by saving the settings with a “Di”
sound.
C. “ ” Manual/Return button
●Press under the service status, the system will finish current status and turn into next status
immediately. (For example: If the quality of outlet water fails, after unlocking the buttons, press
in service status, it will start regeneration cycles instantly; During the cycle of regeneration, if you
want finish current steps in advance, press and it will turn into next step at once.)
●Press under the inquiry status, the system will turn back to service status interface; Press
under the setting status, the system will turn back to inquiry status.
●Under the setting status, press and the system will turn back to inquiry status without saving
the setting value.
D. Down and Up
●Under the inquiry status, press or to view all values.
●Under the setting status, press or to adjust values.
●Press and hold both and for 5 seconds to lift the button lock status.
※Parameter Setting (By users)
Item
Parameter Set Arrange
Factory Default
Time of Day
00:00～23:59
Current time
Rinsing Time
00:00～23:59
02:00
●Press and hold both and for 5 seconds under the service status, till the lights off.

9
Process Display
①User Mode
After power on, the following interface will show 3 seconds, and then enter into user mode.
②F67D process display
Service Status Backwash Status Fast Rinse Status Motor Operation
Illustration:
Working process of F67D/F71D: Service→Backwash→Fast Rinse→Service (So circulate).
F67D Residential Filter valve setting items and process
Items
Process steps
Symbol
Time
Of Day
When lights on, press and hold both and
for 5 second until lights off.
1．Press and enter into the interface of ”Set
Filter Para.” ,as the figure J1 shows. The item of
“Set Time of Day” will be selected by system
automatically.
2．Then press , and the setting interface will
display as the figure J2; The hour value ”12”
flashes, through or to adjust the hour value.
3．Then press again, the minute value “30”
flashes, through or to adjust the minute
J1
J2
Set Time of Day
12：30
Set Filter Para.
》Set Time of Day
》Set Rinsing Time
02:17:25
In Fast Rinse…
Remaining: 3 min.
02:08:00
In Backwashing…
Remaining: 3 min.
12:30:25
System in Service
****************
Residential Valve Type
****************
*
Motor Running…

10
value.
4．Lastly, press and hear a sound “Di”, then
finish adjustment.
Rinsing
Time
1．Press and enter into the interface of ”Filter
Filter Para.” ,as the figure J1 shows.
2．Press and select the item of “ Set Rinsing
Time”; Then press , the setting interface will show
as the figure J3; The hour value 02 flashes, through
or to adjust the hour value.
3．Then press , the minute value “00” flashes,
through or to adjust the minute value.
4．Lastly, press and hear a sound “Di”, then
finish adjustment.
J3
※Background parameter inquiry and setting (Operated by manufacturer or professional dealer)
A. Enter background mode
Within 6 seconds of the L1 displaying, press and hold and for more than 3 seconds to enter
the background setting menu. The interface as the H1 shows (Including H1-1 and H1-2)
H1-1
H1-2
Set Filter Para.
Set Time of Day
》Set Rinsing Time
Set Valve Model
○
+F67
○F71
Set Mode
○
+Filter
○Softener
Set Service Days
7 days
Set Backwash
3Min.
》Set Mode-Filter
Set Valve Model-F67
Set Service Days-7 days
Set Backwash-3Min.
Set Fast Rinse-3Min. ↑

11
A1
A2
A3
A4
A5
B. Parameter set in background
Parameters could be set in background: Set Mode, Set Valve Model, Set Service Days, Set
Backwash, Set Fast Rinse(For water filter setting)
a) In the H1 interface, select the “Mode” and press , as the figure A1 shows. Press or to
select the mode that you need. Select Filter for water filter. After that, Press to save the setting
and turn back to H1; or press to turn back to H1 without saving the setting.
b) In the H1 interface, select “Set Valve Model” and press , as the figure A2 shows. Press or
to select the matched valve type. Press to save the setting and turn back to H1; or press
to turn back to H1 without saving the setting.
c) In the H1 interface, select “Set Service Days” and press , as the figure A3 shows. Press or
to select the days that you need. Press to save the setting and turn back to H1; or press
to turn back to H1 without saving the setting.
d) In the H2 interface, select “Set Backwash” and press , as the figure A4 shows. Press or
to select the backwash time that you need. Press “ ”to save the setting and turn back to H1; or
press “ ” to turn back to H1 without saving the setting.
e) In the H2 interface, select “Set Fast Rinse” and press , as the figure A5 shows. Press or
to select the fast rinse time that you need. Press to save the setting and turn back to H1; or
press to turn back to H1 without saving the setting.
Illustration: For this series products, you don’t need set the background parameters. All of them
are already set by manufacturer according to the product type and specification. If you have to
reset, please makes sure the work is done by professional.
※Parameter Set (Only for factory or professional dealer)
Model
Backwash Time (Minute)
Fast Rinse Time (Minute)
Regeneration Days (Day)
RL-J50
2
2
5
Set Fast Rinse
3Min.

12
RL-J60
RL-J120
3
3
7
RL-J150
RL-J180
4
3
10
※Flow Chart
9. Usage Illustration
After installing the device and setting the relevant parameters, please conduct the trial
running as follows:
Switch on power. Press and go in the Backwash status; adjust the bypass valve (Three-way
valve A and B) to service position, slowly open the inlet valve. At this moment, the air is emptying
from the drain pipeline. Until the drain water is clean.
Press , and turn into Fast Rinse status. Until the drain water is clean.
It needs couple times of backwash and fast rinse for the first time usage.
Press to back to Service status, open the faucet to check if the water is clean. If the water is
still carbon color, it needs more backwash and fast rinse.
Illustration: The purpose of frequently backwash and fast rinse for the first time of using the
system is to clean the carbon powder and activate it which is food grade. So there may be some
black water flowing out.
Notice:
If the water is entering fast, the media in tank will be loss. When water is entering slowly,
you can hear the sound of air-out from the drain pipeline
During the trial running, check each port, there should be no media flowing out. Check
each connection part, be sure there is no leakage.
The time of backwash and fast rinse is set depending on the practical need.

13
10. Notice
Before reading and understanding the manual instruction, please do not operate the device.
10.1 Forbid installing the device near heat source or take anti-heat protective measures when
install near the heat source. It is also forbidden to connect the device with the hot-water pipeline or
the pipeline with the possibility of hot-water returning.
10.2 If the raw water fails to meet the standards of local tap water, such as big content of sand, the
pretreatment device should be installed before the device.
10.3 Without being used for a long time or the pressure of the inlet water is instable, please close
the inlet port and turn off the power. Before using again, please firstly conduct a regeneration cycle
through manual operation so as to ensure the quality of filtering water.
10.4 When use the filter for the first time or the device is idle for long period, it is normal that the
outlet water is black. It needs couples times of backwash and fast rinse.
10.5 If the water demand is increasing (Compared to usual demand) or the raw water quality is
reducing, please add the backwash and fast rinse times.
10.6 As the product is constantly updating, the possibility that the manual instruction can’t accord
with the product may happen. So, it is subjected to the actual product.
Special note: The tap pipeline pressure is unstable (General speaking, the pressure at
night is higher than the daytime), so at the beginning two days after the system installed,
pay close attention to each connection port if there is any leakage.
11. Troubles-Shooting
Trouble details
Cause
Solution
1.Filter doesn’t rinse.
A. Power outage.
B. Incorrect rinsing time set.
C. Controller broken.
A. Check the power (Check fuse,
plug, pull chain or switch).
B. Reset rinsing time.
C. Check or replace the controller.
2.Not good quality of
filtered water.
A. Bypass valve opened.
B. Leakage on riser pipe.
C. Vale body internal
leakage.
D. Active carbon invalid.
E. Short time of rinsing.
A. Close the bypass valve.
B. Ensure the riser pipe and o ring
are good.
C. Repair or replace the valve
body.
D. Replace the active carbon.

14
E. Adjust the rinsing time.
3. Regeneration too
often or less.
A. Regeneration cycle set
incorrect.
A. Set the correct the regeneration
cycle depending on the raw water
quality and usage of end-user.
4. Loss of media
through drain line.
A. Air in water system.
B. Big flow rate of
backwash.
C. Bottom strainer broken.
A. Assure that well system has
proper air eliminator control.
B. Reduce the backwash flow rate.
C. Replace new bottom strainer.
5. Control cycle
continuously.
A. Locating signal writing
breakdown.
B. Controller is faulty.
C. Foreign material stuck the
driving gear.
A. Check and connect locating
signal wiring.
B. Replace controller.
C. Take out foreign material.
6. Drain port
continually drain.
A. Valve body internal
leakage.
B. Power off when valve in
backwash or fast rinse.
A. Repair or replace the valve
body.
B. Close the bypass valve until the
power is on.
7. All indicators
display on display
board.
A. Wiring of display board
with control board fails to
work.
B. Main control board is
faulty.
C. Adapter is damaged.
D. Voltage is unsteady.
A. Check and replace it.
B. Replace main control board.
C. Check and replace adapter.
D. Check the voltage and adjust it.
8. No display on
display board.
A. Wiring of display board
with control board fails to
work.
B. Display board is
damaged.
C. Main control board is
damaged.
D. Electricity is interrupted.
A. Check and replace it.
B. Replace display board.
C. Replace main control board.
D. Check electricity.
9. E1 Flashes
A. Wiring of locating
board with control board is
damaged.
B. Locating board is
damaged.
C. Mechanical driven is
damaged.
D. Control board is
damaged.
E. Wiring of motor with
control board is damaged.
F. Motor is damaged.
A. Replace wiring.
B. Replace locating board.
C. Check and repair
mechanical part.
D. Replace control board.
E. Replace wiring.
F. Replace motor.

15
10. E2 Flashes
A. Hall component on
locating board is damaged.
B. Wiring of locating
board with control board is
damaged.
C. Control board is
damaged.
A. Replace locating board.
B. Replace wiring.
C. Replace control board.
11. E3 or E4 Flashes
A. Control board is
damaged.
A. Replace control board.
12. Maintenance
12.1 Before check-up please turn off the inlet of water filter.
12.2 Prohibit the use of harmful health detergents or chemicals to clean, wipe the device.
12.3 Wipe with a moistened soft fabrics to clean equipment surface dust and foreign matter, avoid
the water into the valve internal erosion electrical components causing damage.
Note：
1. Check or replace the active carbon, the length of riser tube should be neither higher nor 10mm
lower than the tank top opening height, and its top end should be rounded to avoid damage of
O-ring inside the valve.
2. Avoid floccules substance together with resin to fill in the mineral tank.
3. Avoid O-ring inside control valve falling out while rotating it on the tank.
13. Warranty Guidance
Dear Customers:
Thanks for use water filter. For the protection of your rights, please read the manual and
warranty guidance in details before using our products, so that we can service you better.
※“Three Guarantees” period is one year since the purchase date (Refer to the date of guarantee
card or other provable documents)
※During the guarantee period, maintenance is free if the damage is caused by the product quality
problems. However, if the damage is caused by user, we will charge you a certain fee.

16
※When guarantee period is expired, we will still provide after-sales service, such as maintenance,
changing media, supplying parts, etc. The fee of materials and service will be charged according
to our latest charging standards.
※It couldn’t be repaired free of charge under the below conditions:
①Media, seal, decoration shell, the coating of appearance, etc.
②The damage is caused by force majeure, such as fire, flood, electric shock, earthquake,
etc.
③The damage is result from the disassembly or refits by user or repair by non-scheduled
maintenance unit.
④The damage is caused by the improperly transportation, installation, usage and
maintenance.
⑤Content in guarantee proof is unconfirmed with the label on the real good or be altered.
⑥User can’t provide the guarantee card or other proofs.
The product dealers are responsible for the maintenance and other after-sales service. (The
guarantee card or other proof is effective with the dealers’ stamp or our company’s stamp)
Please keep the guarantee card properly and provide it when maintenance.
