RUPTELA FM-Pro4 User manual

Table of contents
1 Preface......................................................................................................................................... 2
1.1 Use of this document .............................................................................................................. 2
1.2 Document change log ............................................................................................................. 2
2 Introduction.................................................................................................................................. 3
2.1 Purpose ................................................................................................................................. 3
2.2 Acronyms............................................................................................................................... 3
2.3 Legal information.................................................................................................................... 3
2.4 Safety.................................................................................................................................... 3
2.5 References............................................................................................................................. 4
3 Device description ......................................................................................................................... 6
3.1 About .................................................................................................................................... 6
3.2 Package contents ................................................................................................................... 6
3.3 Physical characteristics............................................................................................................ 7
3.4 Technical characteristics.......................................................................................................... 7
3.5 IO pin out .............................................................................................................................. 8
3.6 Interfaces and peripheral accessories ..................................................................................... 10
3.7 Certification.......................................................................................................................... 11
3.8 LED status ........................................................................................................................... 11
3.8.1 GNSS LED ..................................................................................................................... 11
3.8.2 GSM LED....................................................................................................................... 11
3.8.3 Peripheral LED ............................................................................................................... 12
3.8.4 LED status in sleep and deep sleep modes ....................................................................... 13
4 Device configuration.................................................................................................................... 14
4.1 Driver installation.................................................................................................................. 14
4.2 Sample configuration ............................................................................................................ 16
4.3 Advanced configuration......................................................................................................... 18
4.3.1 Global settings ............................................................................................................... 19
4.3.2 Profile settings............................................................................................................... 24
4.3.3 IO settings .................................................................................................................... 29
4.4 Integration protocol .............................................................................................................. 35
5 Installation recommendations....................................................................................................... 36
5.1 Device installation................................................................................................................. 36
5.2 FM-Pro4 BT device................................................................................................................ 36
5.3 Antenna installation .............................................................................................................. 36

1Preface
1.1 Use of this document
This document provides required information for proper device handling, preparation, configuration and
installation to a vehicle. This document has a linear structure –from the device package box reception to
the recommendations on how to install the device to the vehicle. However it is not overfilled with
unnecessary information. You will find only basic descriptions about various functions and actions needed
to start using the device. Additionally, there will be references to a more detailed descriptions.
The following markings are used to highlight important information:
Notes contain important information that you need to pay attention to.
Note
Notes like this contain important information!
Actions and various elements of the software required for configuration of the device are marked
in bold.
All actions are described in sequence in the following five sections: Introduction, Device
description, Device preparation, Device configuration and Installation recommendations.
1.2 Document change log
Date
Version
Change details
2016-06-16
1.0
Initial draft
2016-08-30
1.1
Added FW and FM4 configurator compatibility check description in
“Advanced configuration” chapter. Added “Shock detection” description in
“Global settings” chapter.
2016-10-14
1.2
Added “CAN HCV” and “DXP CAN” modes descriptions in the “IO settings”
chapter.
2016-11-29
1.3
Information about FM-Pro4 BT device in “Technical characteristics”, “Global
settings” and “Installation recommendations” chapters.
2016-12-13
1.4
“Constant TCP link” functionality description in “Profile settings” chapter.
2017-01-30
1.5
In the “IO settings” chapter: CANbus data filter by engine sate described.
“Keep TCO parameter values when engine is OFF” described.
2017-03-09
1.6
Changed DIFF file description in “Advanced Configuration” chapter.

2Introduction
2.1 Purpose
The purpose of this document is to provide physical and technical data of the device, to explain device’s
behavior and how various conditions are indicated. Device preparation for the operation and its
configuration instructions are included as well.
2.2 Acronyms
PC –Personal Computer;
GPRS –General Packet Radio Service;
GPS –Global Positioning System;
GSM –Global System for Mobile Communications;
GLONASS –Global Navigation Satellite System;
GNSS –Global Navigation Satellite System;
SMS –Short Message Service;
AC / DC –Alternating Current/Direct Current;
PCB –Printed Circuit Board;
LED –Light Emitting Diode;
I / O –Inputs / Outputs;
2G –second generation of mobile telecommunications technology;
3G –third generation of mobile telecommunications technology;
UMTS –Universal Mobile Telecommunications System;
BT - Bluetooth
2.3 Legal information
Copyright © 2016 Ruptela. All rights reserved. Reproduction, transfer, distribution or storage of parts or all
of the contents in this document in any form without the prior written permission of Ruptela is prohibited.
Other products and company names mentioned in this document are trademarks or trade names of their
respective owners.
2.4 Safety
All the associated (additional) equipment such as PC’s, batteries, sensors etc., shall meet the
requirements of standard EN60950-1.
Do not disassemble the terminal. If the enclosure of the terminal is damaged, or the insulation of
wires is damaged, first of all disconnect power supply cables from power supply source.
All of the wireless data transferring equipment produces interference that may affect other
devices, which are placed nearby.
The terminal can be installed or dismounted only by qualified personnel!
The terminal must be firmly fastened in the predefined location. Predefined location is described
in the mounting instructions.
The programming must be performed using a 2nd safety class PCs (with an autonomic power
supply).

Make sure that the terminal is installed in a place, where it will not be subjected to harsh
environmental conditions for extended time periods.
Caution! If an incorrect type of battery is used for replacement, there is a high explosion risk.
Dispose used batteries according to the environmental requirements.
Any installation and/or handling during a lightning storm is prohibited.
For configuration use cables that were purchased from Ruptela. Ruptela is not responsible for
any harm caused, while using wrong cables for the PC ↔ Terminal connection.
Attention! Do not connect the wires marked red (power supply) and black (chassis) to the wrong
battery poles. Device has a reverse polarity protection, however if connected incorrectly, the
device will not work
To disconnect the device from the power supply, you need to disconnect 12 PINs plug from the
device or disconnect the wires from the vehicle‘s power supply.
This crossed-out wheelie bin symbol means that waste equipment should not be disposed of with
your other household waste. The product must be taken to separate collection points at the
product`s end-of life.
This chapter contains procedures to help you safely operate the FM terminal. By following these
requirements and recommendations, you will avoid dangerous situations. You must read these instructions
carefully and follow them strictly before operating the device! The terminal is supplied from a car battery
with these ratings: 12/24 V DC. The allowed voltage range from the battery is from 10 volts to 32 volts DC.
Max. current for FM-Pro4 is 250 mA @ 12 V DC. Max. current for FM-Pro4 3G / Pro4 BT is 350 mA @ 12 V
DC.
To avoid mechanical damage, it is advised to transport the FM terminal in an impact-proof package.
Before connecting wires of the 12 PIN cable to the vehicle, it is recommended to ensure that the cross-
sectional area of wires mounting is at least 0.75 mm2.
To correctly dismount the terminal from the vehicle, first of all disconnect power supply wires (12 PIN
connector). Only then other plugs or interfaces can be disconnected.
The terminal is intended to be installed in a restricted access location, which is not accessible for the
operator.
2.5 References
This document is designed to work in a conjunction with other documents. Documentation is kept light,
unnecessary information is omitted. Additional and extensive explanations can be found in the
documentation referenced below:
FM-Pro4 / Pro4 3G / Pro4 BT Datasheets –Contains technical data of the FM-Pro4 / Pro4 3G / Pro4
BT device. Datasheets can be acquired from su[email protected]om
Quick start guide –A quick guide for a better understanding of the device configuration process and
functions.
Peripheral accessories –Instructions on how to use peripheral accessories together with the FM-
Pro4 / Pro4 3G / Pro4 BT device.
Website –Our documentation website that contains the most recent firmware, configurator and
sample configuration files.

Microsoft Framework –This additional software is required in order to run our configurator.
VCOM drivers –Drivers required for device connection to PC.
All links are also provided in corresponding sections, where additional information might be needed.
Note
Ruptela documentation website address: doc.ruptela.lt

3Device description
3.1 About
Ruptela‘s FM-Pro4 / Pro4 3G / Pro4 BT is 4th generation advanced, low power consumption but powerful
tracking device. It acquires it’s position by a GPS/GLONASS signal and transfers data to a server via cellular
3G or GSM/GPRS network.
3G network support was not previously available for FM4 devices. This new feature in FM-Pro4 3G is the
main advantage over the FM-Pro4 devices.
FM-Pro4 BT device contains Bluetooth module. This feature further extends its accessories list and adds
new configuration capabilities.
Some common FM-Pro4 / Pro4 3G / Pro4 BT advantages over previous generation FM-Pro3 devices:
Lower power consumption
More powerful 1-wire interface
USB power supply for configuration
2 x RS232 and 1 x RS485 ports work at the same time
2 SIM card slots (on demand, only for FM-Pro4 / Pro4 BT)
Gyroscope (on demand)
FM-Pro4 FM-Pro4 3G FM-Pro4 BT
3.2 Package contents
FM-Pro4 / Pro4 3G / Pro4 BT device is supplied in cardboard package. GPS/GLONASS antenna and IO
cables are disconnected from device. Package contents:
FM- Pro4 / Pro4 3G / Pro4 BT device
12 PINs and 14 PINs cables
GPS/GLONASS all-in-one antenna

Note
Providing a SIM card is optional, according to your payment plan. The SIM card is necessary for connection
to the GSM network. The SIM card can be obtained from your local GSM service provider. The SIM card can
work with the terminal only when all SIM card security codes are disabled.
3.3 Physical characteristics
Properties
Enclosure dimensions
111 x 75 x 25 mm
Indication
3 LEDs: Sat. status, GSM status, Periph. status
Housing
Plastic
External elements
GPS/GLONASS all-in-one antenna
Configuration interface
USB
Connectors
12 & 14 PINs
3.4 Technical characteristics
1Power consumption @ 12V
FM-Pro4
FM-Pro4 BT
FM-Pro4 3G
Idle mode, mA
50
60
70
Sending records, mA
180
210
150
Deep sleep mode, mA
22
22
22

Ambient temperature ratings, °C:
Temperature range for device (without battery)
Storage temperature, °C
-40 ~ +70
Operating temperature, °C
-35 ~ +70
2Temperature range for battery
Charge, °C
0 ~ +45
Discharge, °C
-20 ~ +60
Storage, °C
-20 ~ +70
Electrical and internal elements
Power supply range
10-32 V DC
Absolute maximum ratings
50 V @ 60 s
72 V @ 0.1 s
Internal power supply
Li-Po 3.7 V, 1050 mA
Digital input threshold
4 V
Analogue input resolution
12 bit
GPS/GLONASS module
Ublox EVA-M8M
Channels
72
Sensitivity
-163 dBm
GPS/GLONASS antenna
External
Frequency
1575.42 ± 3 MHz
GSM modem
Quectel M95
Bands
850/900/1800/1900 MHz @ GSM
GSM antenna
Internal, Quad band
3GSM/UMTS modem
Quectel UG96
Bands
800/850/900/1900/2100 MHz @ UMTS
850/900/1800/1900 MHz @ GSM
GSM/UMTS antenna
Internal, Quad band
4Bluetooth
Bluetooth LOW Energy 4.0
Protections
Short circuit protection
Reverse polarity protection
Electrostatic discharge protection on USB
Electrostatic discharge protection on 1-wire
Overcurrent protection on 1-wire power
3ESD protection on SIM card slot
5Charging protection
1 Firmware dependent; given values are valid when there are no peripheral devices attached. If battery is in charging mode, then power consumption in each mode will
be higher within 170 mA.
2 If temp is >45C, charging is disabled, if >60C battery is disconnected from the system at all.
3Only for the FM-Pro4 3G device.
4Only for the FM-Pro4 BT device. Feature is currently under development.
5 Not soldered in standard version. Can be ordered.

3.5 IO pin out
12 PIN connector
Pin nr
Pin
Wire color
Description
1
10-32 V
Red
Power supply 12/24 V (range: 10-32 V)
2
Chassis
Black
Ground connection
3
DIN1
Pink
Digital input, threshold 4 V
4
AIN1
Gray
Analogue input (range: 0-30 V)
5
DIN2
Blue
Digital input, threshold 4 V
6
AIN2
Green
Analogue input (range: 0-30 V)
7
DIN3
White
Digital input, threshold 4 V
8
DOUT1
Purple
Digital output open collector up to 32 V, 1 A
9
DIN4
Yellow
Digital input, threshold 4 V
10
DOUT2
Orange
Digital output open collector up to 32 V, 1 A
11
CAN2 L
Blue/red
J1939 CAN interface low connection
12
CAN2 H
White/red
J1939 CAN interface high connection
14 PIN connector
Pin nr
Pin
Wire color
Description
1
PortB-232 RX
Yellow
RS 232 port B receive signal
2
Chassis
Black
Ground connection
3
PortB-232 TX
Orange
RS 232 port B transit signal
4
1W. +5V
Red
1-wire power supply +5 V, 200 mA
5
PortA-232 RX
Purple
RS 232 port A receive signal
6
1W. Data
Green/yellow
1-wire data channel
7
PortA-232 TX
Pink
RS 232 port A transit signal
8
CAN1 H
White
J1939 CAN interface high connection
9
L-Line
Green
J1939 CAN interface L line channel, diagnostics
10
CAN1 L
Blue
J1939 CAN interface low connection
11
K-Line
Brown
J1939 CAN interface K line channel, diagnostics
12
Chassis
Black
Ground connection
13
PortC-485 A
White/red
RS 485 differential signaling line A
14
PortC-485 B
Yellow/brown
RS 485 differential signaling line B
Note
Only one CAN line work at the same time. Connect your hardware to one of the interfaces and configure it
accordingly.

3.6 Interfaces and peripheral accessories
There are several peripheral accessories that can be connected to the FM-Pro4 /
Pro4 3G / Pro4 BT device. With peripherals you can get even more features and
extended functionality. All available peripherals can be purchased from Ruptela.
Please contact your manager for more details.
Note
Maximum 1-Wire interface power output is 200 mA @ 5 V.
FM-Pro4 / Pro4 3G / Pro4 BT device support RS232, RS485, 1-wire and CAN
interfaces. List of available peripherals devices that can be to them:
Available on 1-Wire:
4 × Temperature sensors
DS18B20/DS18S20 (10 mA @ 5 V)
1 × iButton DS1990, DS1971
with passive socket.
Available on DOUTs:
1 × ECO Driving panel (Power
supply from 1-Wire. 40 mA @ 5 V)
1 × Buzzer/LED
1 × Ignition lock (including ignition
block upon GSM jamming detection)
Available on AINs:
2 × Analogue fuel sensors
Available on RS232 ports A and/or B:
2 x LLS digital fuel sensors
Transparent channel
2 x RFID readers
1 x Magnetic card reader
1 x TCO driver card reader
1 x Alcohol sensor
1 x Garmin (Send and receive SMS,
routes to/from navigation system.
(Only on port B)
1 x Spreader
Available on RS485 port C:
Up to 10 LLS fuel sensors
1 x J1708 interface
Transparent channel
Available on CAN interface:
Vehicle CANbus (FMS)
information reading
HCV CAN (heavy commercial
vehicles)
MobilEye
DXP CAN

Note
Few hardware features that are present in FM-Pro4 are currently not available in FM-Pro4 3G. These
features are 2nd SIM card slot and 3,5 mm TTRS audio interface.
Only FM-Pro4 BT devices have built in Bluetooth module.
You can find peripheral accessories installation instructions and documentation on our documentation
website.
3.7 Certification
FM-Pro4 / Pro4 3G / Pro4 BT devices have passed quality tests and comply with following certifications:
Certification
FM-Pro4
FM-Pro4 BT
FM-Pro4 3G
E-mark


CE 1304


RoHS



FCC Part 15

3.8 LED status
3.8.1 GNSS LED
When GPS/GLONASS signal is not received or GPS/GLONASS signal is not accurate, the GPS LED is blinking
as follows:
When accurate GPS/GLONASS signal is received, the GPS LED is blinking as follows:
3.8.2 GSM LED
When GSM signal is not received, GSM LED is blinking as follows:

When device has a good GSM signal, but no GPRS, LED is blinking as follows:
When device has good GSM signal and it is connected to GPRS, then LED is blinking as follows:
When the device terminal has GSM signal and it is sending data via GPRS, LED is blinking:
3.8.3 Peripheral LED
The device terminal can have up to 3 peripheral devices attached to it (e.g. CAN, LLS, 1-wire). So there are
4 different types of LED states possible. When there is no peripheral attached, LED will not blink at all:
When there is 1 peripheral interface connected, the peripheral LED is blinking:
When there are 2 peripheral interfaces connected, the peripheral LED is blinking:
When there are 3 peripheral interfaces connected, the peripheral LED is blinking:

3.8.4 LED status in sleep and deep sleep modes
When device is in sleep / deep sleep mode all three LEDs blink at the same time in the following pattern:

4Device configuration
4.1 Driver installation
Virtual COM port driver installation is mandatory, only then your PC will recognize the FM-Pro4 / Pro4 3G /
Pro4 BT device that was connected to the USB port. You can download newest drivers on our
documentation website (VCOM drivers).
Choose correct archive file with drivers for your OS version and download it to your PC.
Installation procedure:
Uninstall previous Virtual COM port driver versions (Start-> Settings-> Control Panel-> Add or
remove programs).
Extract archive file “Win7.zip” or “Win8.zip” to a desired location on your PC.
If you are running a 32-bits OS version, launch the “dpinst_x86.exe” [1.]
If you are running a 64-bits OS version, launch the “dpinst_amd64.exe” [2.]
Windows 7 Users might get a Security Warning message. Click “Yes” [3.].
In the next window select “Next” [4.].

Wait for the setup to complete the installation and click “Finish” [5.].
Driver is now installed and ready to use.

4.2 Sample configuration
Please go to our documentation website and download sample configuration and the latest configurator.Also
you will need the latest version of Microsoft Framework.
Operating system requirements:
MS Windows XP/Vista/7/8
Example for FM-Pro4 / Pro4 3G:
Start the VCP.exe from configurator folder.
Select Pro4.
Click File → Open CFG.
In dialog window, browse the sample configuration file you downloaded from the documentation
website.
Click Open.

FM-Pro4 BT
Procedure for Pro4 BT device is very similar. Download configurator and sample configuration file for the
FM-Pro4 BT device. In configurator select Pro4 BT and open “Standard config PRO BT (for clients).ff4c” file.
Sample parameters will be loaded. However you will need to enter other parameters on your own.
1. Enter IP (in the 255.255.255.255 format) or a Domain Name (not exceeding 40 characters) and
PORT to which the device should send data.
2. Enter APN settings: APN name, User login and Password (if login and password is needed). If you
choose to enable Lock FM device to the SIM card check-box you will be required to enter SIM
card’s PIN code every time you try to connect to the device via USB cable. As long as it is checked
you will not be able to use different SIM cards with this device.
3. Select a COM port you connected the device to and click “Connect”. At this point the configuration is
ready to be send to the device, so the device must be connected to the computer.
4. Click “Send CFG”button. The configuration will be uploaded to the device.
Note
APN name, login and password should be provided by your mobile network operator.
Now the device is configured to send data to the specific server. Sample IO parameters are enabled
(loaded with configuration file). You can log in to your tracking platform to see whether the device is
sending data.

4.3 Advanced configuration
The configuration tool is quite similar to the ones used for other 3rd generation devices. Overview of the
configuration is described in sections.
The “File”menu gives you access to control
configuration files. Choose New/Save/Open CFG to
perform the corresponding action. CFG means full
configuration file.
The “Tools”menu contains language selection
options: English or Russian are available.
Save/Open DIFF allows you to create a DIFF file.
DIFF files are used to change only one or few certain parameters without a need to upload the full
configuration to the device. It is useful, when updating over-the-air.
Attention
A DIFF file will save all made changes to a configuration. For example changing a number in the IP filed, or
marking a checkbox, but, if a change was made, and afterwards reverted to the previous state (checkbox
checked, and unchecked afterwards), this will not be marked as a "change made". DIFF will only record
changes made to the initial configuration (a loaded pre-set configuration is considered an initial
configuration). Particular attention must be taken, when creating a DIFF file, to avoid accidental changes to
the configuration.
The control panel on the left hand side allows you to choose and control the device.
Select the “COM” port that the device is connected to and hit “Connect”. At this point
FM4 configurator checks compatibility between itself and firmware (FW) in the device.
Every FW version is released together with a recommended FM4 configurator. More
information about different FW’s and recommended configurators for them can be found
in FW changelogs. After compatibility check, three outcomes are possible:
1. FW and FM4 configurator versions are compatible. Go ahead and continue FM
device configuration.
2. FW is incompatible with this FM4 configurator, because FW version is too old for
this configurator. This will be notified in a new alert pop up window. “Send CFG”
and “Get CFG” buttons will be disabled. Use “Send FW” button to update firmware
version in the device.
3. FW is incompatible with this FM4 configurator, because configurator is too old for
this FW version. This will be notified in a new alert pop up window. “Send CFG”
and “Get CFG” buttons will be disabled. Download new version of FM4 configurator, which is
recommended for this firmware version.
“Send CFG”and “Get CFG”buttons are used to send and receive the configuration file to/from the
hardware.
“Send FW”is used to send new firmware to your device.
In the drop box below you can select a type of the device. If you connected one to your PC, it will be
displayed. Now Pro4 or Pro4 BT name should be displayed.

4.3.1 Global settings
The first part of the configuration tool is “Global” settings. Global include connection settings and other
settings independent from the profile settings –global settings are the same for all profiles.
Connection settings here you should enter server IP and port that the device should connect to. The IP
can be entered in the numeric format: 255.255.255.255. You can also use a Domain name (not exceeding
40 characters). IP 2 is a backup IP address, which is used when the device is unable to connect to the first
server.
Note
Please have in mind that ports for TCP and UDP transfer protocols usually are different –please select the
correct transfer protocol and enter the correct port.
Two servers –checkbox changes the logic described above. It enables a two servers mode –the
same data is repeatedly transmitted to another server with IP2, unless we get a timeout. IP1 is
dedicated IP for server, from which we get the ACK’s for our record packets sent. After we get the
ACK from this IP, record data is considered as successfully transmitted to the server and it is
removed from the memory.
In this mode data is sent to IP2 only when connection to the IP1 is established. Packet, which is
sent to the IP1 server is also sent to the IP2 server.
Only records are going to be send to the IP2. Data packets such as Transparent Channel,
Tachograph, SD card, Garmin will not be send to the IP2.
Unable to send data:
When unable to establish connection to IP1, device does not connect to the IP2 as well. When
connected to IP1 and doing data transmission, but IP2 is unreachable –after receiving ACK from IP1
server, data is removed from memory, which can cause information loss in IP2 server.
