Rush TX500 User manual

Operator's Manual
Original Operating Instructions
TX500 Aluminum
Packable Ramp
10320
Revised 03/02/12
© 2012 Ardisam, Inc.
All Rights Reserved.
Visit us online at
www.rushramps.com
GAS/OIL
RATIO
50:1

Owner’s Manual
TX500 Aluminum Packable Ramp
Page 2 Visit www.rushramps.com or call 800-345-6007 M-F 8-5 CST
WARNING
READ, UNDERSTAND AND FOLLOW ALL ASSEMBLY,
INSPECTION, AND USE INSTRUCTIONS PROVIDED
BEFOREEACHUSE.FAILURETOFOLLOWALLINSTRUCTIONS,
WARNINGS & LOAD CAPACITY RATING COULD RESULT IN
SERIOUS INJURY OR DEATH.
IF ANY INSTRUCTIONS ARE NOT UNDERSTOOD OR IF YOU
HAVE A PARTS ISSUE CALL 8003456007 BEFORE USING.
DO NOT USE AN ATV ON THIS RAMP IF THE ATV HAS SNOW
CHAINS ON TIRES. CHAINS WILL CAUSE DAMAGE TO YOUR
RAMP AND ARE HAZARDOUS!
THIS RAMP IS FOR USE WITH 4WHEELED ATVS, UTVS,
AND LAWN TRACTORS ONLY. DO NOT USE WITH 2 OR
3WHEELED VEHICLES OR VEHICLES EXCEEDING 2,000 LB.
SAFETY STRAPS MUST BE SECURELY HOOKED UP TO
VEHICLETO PREVENT RAMPS FROM SLIDING OFFTAILGATE.
TESTBEFOREUSINGORYOU COULDBESERIOUSLYINJURED.
BE SURE YOUR TRUCK IS IN PARK AND EMERGENCY BRAKE
ENGAGED.
BE SURE 4WHEELED ATV, UTV, OR LAWN TRACTOR IS
CENTERED ON RAMPS. DO NOT USE WITH ANY VEHICLE
THAT HAS WIDER TIRES THAN THE RAMP WIDTH.
MAXIMUM USABLE HEIGHT, GROUNDTO LOADING POSITION,
IS NO MORE THAN ONE HALF THE LENGTH OF THE RAMP.
BE SURE RAMPS ARE PROPERLY PLACED AND SECURED AS
DESCRIBED IN LOADING INSTRUCTIONS.
DO NOT USE ON SOFT SURFACES OR UNLEVEL TERRAIN.
REAR ENGINE EQUIPMENT SHOULD BE LOADED IN REVERSE
TO AVOID FRONT END REARUP.
DO NOT EXCEED THE CAPACITY OF YOUR LOADING
SURFACE I.E. TAILGATE, BUMPER. IF UNKNOWN, CONSULT
THE MANUFACTURER TO FIND LOAD CAPACITIES.
IF LOADING OR UNLOADING FROM A TRAILER, MAKE SURE
THE TRAILER IS PROPERLY COUPLED TO THE TOW VEHICLE.
NEVER STAND INTHE PATH OF EQUIPMENTWHEN LOADING/
UNLOADING WITH THE RAMP, AND KEEP BYSTANDERS
AWAY FROM THE RAMPS.
DO NOT STEP BETWEEN RUNGS.THIS MAY CAUSE A PERSON
TO FALL THROUGH AND POSSIBLY RESULT IN SERIOUS
BODILY INJURY.
RAMPS ARE INTENDED FOR LOADING/UNLOADING
EQUIPMENT ONTO A TRAILER OR PICKUP TRUCK. DO NOT
USE RAMP SECTIONS AS A LADDER, SCAFFOLDING, OR FOR
ANY OTHER PURPOSE.
RUSH™ Packable Ramps offers a line of ATV and UTV ramps.
We appreciate your purchase of one of our world class ramps.
Follow these few simple instructions and your product will be
sure to give you many years of trouble free pleasure. Instructions
should be kept in a safe place and reviewed at least annually.
If for any reason you have a problem with your product, DO
NOT return to the retailer; contact the RUSH™ customer
service department at 800-345-6007 Monday through Friday
from 8 a.m. to 5 p.m. CST for assistance.
ASSEMBLY INSTRUCTIONS:
1. If your RUSH™ ramp is in its compressed position, pivot your
ramp to separate rungs. Then unfold the ramp to lock rungs
in proper position. SEE FIGURE 1.
2. Insert detent pin in hole at center rung on each section to
lock ramp in place. SEE FIGURE 1.
Figure 1
1) Pivot ramp to separate rungs 2) Unfold top and bottom section
3) Ramp rungs will automatically lock in position when unfolded.
Lock top and bottom sections together using detent pin.
detent pin
WARNING
BE CAREFUL OF PINCH POINTS AT RAMP HINGE LOCATIONS.
BE CAREFUL OF PINCH POINTS AT RAMP TAB LOCATIONS
WHILE SECURING RAMP TO TAILGATE.
BE CAREFUL OF PINCH POINTS BETWEEN RUNGS WHILE
COLLAPSING RAMP.

Owner’s Manual
TX500 Aluminum Packable Ramp
Page 3Visit www.rushramps.com or call 800-345-6007 M-F 8-5 CST
Figure 3
ALWAYS…
• Useonlevelgroundandsecurelyattachramptotruck.
• Becarefulofpinchpointsatramphingelocations.
• Becarefulofpinchpointsatramptablocationswhilesecuring
ramp to tailgate, and of pinch points between rungs.
• Useas4-wheeledATV,UTV,orlawntractorramponly.
• Inspect before each and every use to be sure there is no
product damage or loose/missing bolts and hardware.
Lubricate hinges as necessary.
NEVER…
• Neverexceedloadcapacityof1,000lb.perramp(2,000lb.as
a pair), evenly distributed over four wheels.
• Useadamagedramp;replacewithnew
• Usewhileundertheinfluenceofalcoholordrugs.
• LoadATVonrampwithanygearonracksofATV.
• Usewith2-or3-wheeledvehicles.
• Usecarelessly--ThinkSafety!
• Useinslipperyconditions.
REPLACEMENT COMPONENTS
A306 Rubber tab cover
48663 Ramp strap, complete
WARRANTY
RUSH™ Ramps, a division of Ardisam Inc., offers a one year limited
warranty to be free from defects in materials and workmanship for
theservicelifeoftheproduct,nottoexceedtwelveconsecutive
months from the date of purchase. This warranty applies to the
original owner with a proof of purchase and is not transferable.
This warranty applies only to products which have not been
subjected to negligent use, misuse, alteration, accident or if
repairs have been made by anyone outside our factory. This
warranty supersedes all other warranties either expressed or
implied and all other obligations or liabilities on our part.
Ardisam, Inc., does not assume, and does not authorize any other
person to assume for us, any liability in connection with the sale of
our products. Warranty work must be sent directly to Ardisam, Inc.
or one of our authorized service centers and performed by them.
To obtain warranty service and/or replacement instructions,
you must have prior approval from Ardisam, Inc. before
shipping your package to us by calling our customer service
department at 800-345-6007 M-F 8-5 CST or by writing to:
Ardisam, Inc., 1160 Eighth Avenue, Cumberland, WI 54829
for a return material authorization number (RMA#). All
items must be shipped prepaid. Ardisam, Inc. will at no charge,
repair or replace, at their discretion, any defective part which
falls under the conditions stated above. Ardisam retains the
right to change models, specifications and price without notice.
For replacement parts, phone [phone] or go online to
www.rushramps.com.
S
Figure 2
bumper s-hook
loop
tailgate
straps tight
(assemblyinstructionscontinued...)
3. Attach the two provided securing straps to the fifth rung
awayfromthetailgateend(oneoneachramp).Wraptheloop
end of each strap around the center brace and thread the
buckle and “S” hook end through the loop. This permanently
attaches straps to the ramp. SEE FIGURE 2.
USE INSTRUCTIONS:
TO LOAD YOUR 4-WHEELED ATV, UTV OR LAWN TRACTOR:
1. On level ground, rest both ramps on the tailgate. SEE FIGURE
3.Besurerampsarecentered on tailgate and aligned correctly
to your four-wheeled ATV, UTV, or lawn tractor’s wheel width.
2. Hook the “S” hooks of both straps to bumper and pull on loose
endofstrapsuntilstrapsaretightlyholdingramptotailgate.Be
sure ramps have not moved location when tightening straps.
Double check to make sure ramps are still aligned correctly. To
remove, simply push the thumb release on strap buckle.
3. Draw the ATV, UTV or lawn tractor up the ramps. We
recommend using an electric or manual winch.
4. Once vehicle is in truck bed, be sure to set brake and securely
tie down vehicle. Ramp can now be removed, folded up, and
stored.
TO UNLOAD YOUR 4-WHEELED ATV, UTV OR LAWN TRACTOR:
1. Reverse loading procedures to unload your ATV, UTV, or lawn
tractor.

Visit www.rushramps.com or call 800-345-6007 M-F 8-5 CST
RUSH™ Packable Ramps
Division of Ardisam, Inc.
11608thAvenue,POBox666
Cumberland, WI 54829
800-345-6007|Fax715-822-2223
Email: [email protected]om
