Russell Hobbs 27170AU User manual

27170AU
I www.russellhobbs.com.au
I www.russellhobbs.co.nz

2
f
eg
j
i
h
Ah Bh C

3
IMPORTANT SAFEGUARDS
When using this appliance, basic safety precautions should always be followed, including the following:
Read all instructions before, and follow whilst using this appliance.
1. To protect against electrical hazards, do not immerse the air fryer body in water or any liquid.
2. Do not use it in a bathroom or near any source of water.
3. Do not use outdoors.
4. This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
5. This appliance is NOT a toy. Children should be supervised to ensure they do NOT play with this
appliance.
6. Always follow the instructions when using this appliance.
7. The temperature of accessible surfaces/parts may become very hot when the appliance is operating
and may remain hot for some time after the appliance has been switched off.
8. To avoid the possibility of scalding, keep clear of steam escaping around the door area.
9. CAUTION: Do not touch any internal surfaces until the air fryer has fully cooled.
10. CAUTION: Do not operate on an inclined plane. Place the air fryer on a stable, level, heat-resistant
surface and out of reach of children.
11. Route the power cord so it does not overhang, and cannot be caught accidentally.
12. Unplug the air fryer when not in use, before moving and before cleaning. Let it cool down fully before
cleaning and storing away.
13. There are no user serviceable parts. If the power cord is damaged, it must be replaced by the
manufacturer or similarly qualified person in order to avoid hazard.
14. Do not operate this appliance with a damaged cord/plug or after the appliance has malfunctioned, or
been dropped or damaged in any manner. Contact Customer Service for examination, adjustment,
repair or replacement.
15. To shut down, press C, turn off the wall power outlet then grasp the plug and remove from wall
power socket. Never pull by the cord.
16. Leave a clear space of at least 50mm around the air fryer when in use.
17. Do not cover the air fryer or put anything on top of it while in use.
18. Do not use the air fryer near or below curtains, overhead cupboards or or other combustible
materials.
19. Keep the power cord and the air fryer away from hotplates, cook-tops and burners.
20. Cook meat, poultry, and derivatives (mince, burgers, etc.) till the juices run clear. Cook fish till the flesh
is opaque throughout.
21. Do not pour oil or any other liquid into the basket.
22. Do not use accessories or attachments other than those supplied as specifically for use with the air
fryer.
23. Do not use the air fryer for any purpose other than that described in these instructions.
24. Do not connect this air fryer to an external timer or remote control system.
L

4
25. For added safety, electrical appliances should be connected to a power outlet that is protected by a
residual current device (RCD), also often referred to as a ‘Safety Switch’. Your switchboard may already
incorporate an RCD. If unsure, call an electrician for verification and fitting if necessary.
This appliance is intended to be used in household and similar applications such as:
• staff kitchen areas in shops, offices and other working environments;
• by clients in hotels, motels and other residential type environments;
• bed and breakfast type environments;
• farm houses.
CAUTION: Benchtops, such as, but not limited to, engineered stone, marble, granite and acrylic
may not be tolerant of localised temperature rises. Therefore, any appliance that radiates heat
should be placed on a heat resistant pad or chopping board to prevent the heat from affecting
the benchtop.
SAVE THESE INSTRUCTIONS
PARTS
1. Touch controls and display
2. Body
3. Crisping plate
4. Basket
5. Handle
BEFORE USING FOR THE FIRST TIME
• Handwash the removable parts, rinse, and dry.
• When using your air fryer for the first time, you may notice smoke or a slight odour for the first few
minutes of cooking. This is normal. Ensure the room is well ventilated.
PREPARATION
• Sit the appliance on a stable, level, heat-resistant surface.
• Leave a space of at least 50mm all-round the appliance.
• Have oven gloves (or a tea towel) on hand, use heat resistant plastic tongs and a heat-resistant mat or
dinner plate to rest the basket on.
• Note: Do not use metal tongs as it may scratch the coating. We recommend using only heat resistant
plastic or silicon coated tongs.
• Your air fryer may be shipped with the handle detached from the basket. If required, remove the
basket and attach the handle by sliding it downwards into the opening until it clicks into place. Make
sure that the handle is locked into place before use. Once fitted, the handle cannot be removed.
To remove the basket from the body
1. Hold the top of the body.
2. Grip the basket handle with the other hand.
3. Slide the basket out of the body.
4. Rest the basket on a heat-resistant mat.
To adjust the crisping plate:
The crisping plate can be adjusted to a high or low position to allow food to be positioned closer to or
further from the element during cooking.
1. There are supports inside the basket (Fig. A).
2. For the low position, place the crisping plate on the bottom of the basket (Fig. B).
3. For the high position, place the crisping plate on the supports inside the basket (Fig. C).

5
DIGITAL TOUCHSCREEN
ICON DESCRIPTION
C
On/Off
OPQRSUVNWX
Preset functions
Z
Used to adjust the cooking temperature in conjunction
with the ior jbuttons.
Y
Used to adjust the cooking time in conjunction with the
ior jbuttons.
ij
Increase/decrease
88:88 Time/Temperature Display
PRESET FUNCTIONS
Your air fryer has the following cooking functions. You can adjust the default cooking times and
temperatures as desired.
Function Default Cooking
Time (mins)
Default Temperature
(ºC)
Shake
Reminder
Fries O 18 205 Yes
Vegetables P 8195 Yes
Bake Q 30 160 No
Fish R 10 200 No
Eggs S 18 120 No
Chicken U 40 180 Yes
Grill V 12 205 Yes
Reheat N 12 115 Yes
Defrost
W
15 85 Yes
Dehydrate
X
120 50 No
ADJUSTING THE COOKING TIME OR THE TEMPERATURE
1. Once you have selected the desired cooking mode, tap the ( Z ) icon and then tap the ( i )and( j )icons
to increase or decrease the cooking temperature as desired.
2. To adjust the cooking time, tap the ( Y ) icon and then tap the ( i )and( j )icons to increase or decrease
the cooking time as desired.

6
USING
• Your air fryer uses hot air and radiant heat for cooking.
Preheating
1. Set the cooking time to 5 minutes.
2. Tap the on/off icon (C) to start the preheating cycle.
3. When the cooking time reaches zero, your air fryer will beep 5 times and switch off.
Cooking
1. Place the crisping plate inside the basket.
2. Place desired food into the cooking basket. Do not overfill the basket, to leave space for the hot air to
circulate between pieces of food.
3. Slide the basket back into the air fryer body, ensuring it clicks into place and sits flush within your air
fryer body. Your air fryer will not work unless the basket is properly inserted.
4. Once the basket has been correctly inserted, the control panel will be illuminated.
5. Tap the (C) power icon. Your air fryer will show a default cooking time of 15 minutes and a default
temperature of 190ºC.
6. Select the desired preset function.
7. Make any adjustments to the cooking time or temperature as required (see Adjusting the cooking
time or temperature).
8. Tap the (C) icon to start cooking.
• To stop cooking at any time tap the ( C ) icon.
9. Once the cooking time has elapsed, the timer will beep 5 times and the unit will switch off.
10. Slide the basket out of the body and check that the food is cooked.
11. Place the basket on an insulated mat.
Notes
• To remove food from the basket, we recommend using tongs. We do not recommend tipping the
basket upside down as oil residue will drip out.
• CAUTION: Hot oil from the ingredients may gather at the bottom of the basket. Be careful when
removing the crisping plate from the basket.
• Unplug the appliance, once all cooking is complete.
• Your air fryer will switch off when you remove the basket.
• Your air fryer will switch back on when you replace the basket in to the body and will automatically
resume the cooking cycle from where it stopped.
Shake Reminder
To ensure even cooking,some foods require shaking or turning during cooking. Some of the built in presets
include a reminder. Your air fryer will beep and the SHAKE icon will flash when the reminder is active.
Carefully remove the basket and gently shake it, or use tongs to turn the food.
Note
If you do not remove the basket and shake the food, the SHAKE icon will remain lit.
COOKING TIMES AND FOOD SAFETY
• To be used purely as a guide
• Check food is cooked through before serving. If in doubt, cook it a bit more.
• Cook meat, poultry, and any derivatives (mince, burgers, etc.) till the juices run clear.
• Cook fish till the flesh is opaque throughout.
• When cooking pre-packed foods, follow any guidelines on the package or label.

7
Food Temperature
ºC
Time
(min) Remarks
Chips 200 25 Rinse, dry, toss in salt, pepper, and oil
Potato wedges 200 15-20 Rinse, dry, toss in salt, pepper, and oil
Sweet potato wedges 200 15-20 Rinse, dry, toss in salt, pepper, and oil
Jacket potato 180 30-40 For a crispy jacket, brush with oil
Roast potatoes 180 25-35 Rinse, dry, toss in salt, pepper, crushed
rosemary (optional) and oil
Mixed Mediterranean
vegetables 180 6-10 All cut to similar sizes, approx. 1-2cm pieces, toss in oil and season
Chicken Breast 180 15-20
Chicken Thighs 180 25-30 Cooking time depends on size. Brush with oil,
season
Chicken wings 180 23-28 Cooking time depends on size. brush with oil,
season
Burgers 180 8-12 Cooking time depends on size. brush with oil,
season
Sausages 180 8-12
Pork chop 180 22 Brush with oil, season
Salmon fillet 180 8-12 Brush with oil, season
White fish fillet 180 8-12 Brush with oil, season
Sausage Roll 200 13-15 Brush with oil, season
Spring Roll 200 8-10
Muffins 180 15-18
Frozen Food Temperature
ºC
Time
(min) Remarks
Chips 200 25
Potato wedges 200 15-20
French fries 200 12-20
Chicken Nuggets 200 6-10
Fish fillets 200 10 -12
Fish Fingers 180 6-10
Onion Rings 180 10-15
Scampi 180 15
NOTE: High fat foods (e.g. pork) may create smoke. This is normal as oil residue is cooked at a high
temperature. Reducing temperature may decrease the effect of smoke.

8
CARE AND MAINTENANCE
• Unplug the appliance.
• Leave everything to cool down.
Basket and Crisping Plate
1. Once the air-fryer has cooled, remove the basket from the air-fryer body for cleaning.
2. Wipe the interior of the body to remove any crumb or residue, but DO NOT wipe the heating
elements located at the top.
3. Remove the crisping plate from the basket.
4. Dispose of food residue and oils, and wipe both the crisping plate and basket with a damp cloth
before hand washing them in warm to hot soapy water. Dry thoroughly before placing back in the air
fryer body.
• The basket and crisping tray can also be washed in a dishwasher.
Exterior Surfaces
• Clean the exterior with a damp cloth or sponge. Dry thoroughly.
RECYCLING
Legislation in some localities mandates that e-waste (anything with a plug, battery or cord) is disposed
of through controlled recycling facilities and must not be disposed of in general household waste. For
more information about recycling of electrical and battery operated appliances, please contact your
local council or your local household waste disposal service.

9
Spectrum brands Australia Pty Ltd
Locked Bag 3004 Braeside
Victoria 3195 Australia
Customer Service in Australia
TollFree: 1800 623 118
Email: [e-mail]
Website: www.spectrumbrands.co.au
Spectrum Brands New Zealand Ltd
PO Box 9817 Newmarket
Aukland 1149 New Zealand
Customer Service in New Zealand
TollFree: 0800 736 776
Email: [e-mail]
Website: www.spectrumbrands.co.nz
Spectrum Brands Australia Pty Ltd and Spectrum Brands New Zealand Ltd
Warranty Against Defects
In this warranty:
Australian Consumer Law means the Australian consumer law set out in Schedule 2 to the Competition
and Consumer Act 2010;
CGA means the New Zealand Consumer Guarantees Act 1993;
Goods means the product or equipment which was accompanied by this warranty and purchased in
Australia or New Zealand, as the case may be;
Manufacturer, We or us means:
1. for Goods purchased in Australia, Spectrum Brands Australia Pty Ltd ABN, 78 007 070 573;
or
2. for Goods purchased in New Zealand, Spectrum Brands New Zealand Ltd, as the case may be,
contact details as set out at the end of this warranty;
Supplier means the authorised distributor or retailer of the Goods that sold you the Goods in Australia or in
New Zealand; and
You means you, the original end-user purchaser of the Goods.
1. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law, or the
CGA. You are entitled to a replacement or refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if
the goods fail to be of acceptable quality and the failure does not amount to a major failure.
2. The benefits provided by this Warranty are in addition to all other rights and remedies in respect of
the Goods which the consumer has under either the Australian Consumer Law or the CGA. The
original purchaser of the Goods is provided with the following Warranty subject to the Warranty
Conditions:
3. We warrant the Goods for all parts defective in workmanship or materials for a (Warranty Period)
period of 2 years from the date of purchase.
If the Goods prove defective within the Warranty Period by reason of improper workmanship or material,
we may, at our own discretion, repair or replace the Goods without charge.

10
Warranty Conditions
4. The Goods must be used in accordance with the manufacturer’s instructions. This Warranty does not
apply should the defect in or failure of the Goods be attributable to misuse, abuse, accident or
non-observance of manufacturer’s instructions on the part of the user. As far as the law permits, the
manufacturer does not accept liability for any direct or consequential loss, damage or other expense
caused by or arising out of any failure to use the Goods in accordance with the manufacturer’s
instructions.
5. Exhaustible components (such as batteries, filters and brushes) of the Goods are included under this
Warranty only where there is a defect in workmanship or materials used.
6. The warranty granted under clause 3 is limited to repair or replacement only.
7. Any parts of the Goods replaced during repairs or any product replaced remain the property of the
manufacturer. In the event of the Goods being replaced during the Warranty Period, the warranty on
the replacement Goods will expire on the same date as for the Warranty Period on the original Goods
which are replaced.
8. In order to claim under the warranty granted under clause 3 you must:
(a) Retain this warranty with your receipt/proof of purchase; and
(b) Return the Goods to us at the relevant address or to the Supplier by prepaid freight within the
Warranty Period accompanied with (i) the legible and unmodified original proof of purchase,
which clearly indicates the name and address of the Supplier, the date and place of purchase,
the product name or other product serial number and (ii) this warranty.
9. This warranty is immediately void if:
(a) Any serial number or appliance plate is removed or defaced;
(b) The Goods have been serviced or otherwise repaired by a person not authorised to do so by
us or where non approved replaced parts are used.
10. The Goods are designed for domestic use only. The Goods must be connected to the electrical
voltage requirements as specified in the ratings label located on the Goods.
11. This warranty does not cover the cost of claiming under the warranty or transport of the Goods to and
from the Supplier or us.
12. This warranty is only valid and enforceable in Australia against Spectrum Brands Australia Pty Ltd and
in New Zealand against Spectrum Brands New Zealand Ltd.
Contact us or the Supplier for further details.
Register your product online
If you live in Australia please visit: www.spectrumbrands.com.au/warranty
If you live in New Zealand Please visit: www.spectrumbrands.co.nz/warranty
Registration of your warranty is not compulsory, it gives us a record of your purchase AND entitles you to
receive these benefits: Product information; Hints and tips; Recipes and news; Information on special price
offers and promotions.
Any questions? Please contact Customer Service for advice.

11

T22-9003227
