Russell Hobbs RHPYRO6503B SS User manual

Model number(s):
RHPYRO6503B SS
Pyrolytic Oven
Instruction Manual
IMPORTANT:
RETAIN FOR FUTURE REFERENCE
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
Contents
Safety Instructions ………………………………………. 3-5
Product Overview ………………………………………. 6
Positioning ………………………………………. 7
Installation ………………………………………. 8-9
Usage ………………………………………. 10-25
Oven functions ………………………………………. 11-12
Dials & Button functions ………………………………………. 13
Oven cavity & before first use ………………………………………. 14
Setting the clock ………………………………………. 15
Function & temperature setting ………………………………………. 16
Minute minder ………………………………………. 17
Duration timer ………………………………………. 18
Reservation function ………………………………………. 19-20
Cancel function, checking time,
safety lock
………………………………………. 20-21
Cooking guidelines & warnings ………………………………………. 22-23
Accessories ………………………………………. 24-25
Cleaning & Maintenance ………………………………………. 26-30
Trouble shooting ………………………………………. 31
Guarantee ………………………………………. 32
Technical specification ………………………………………. 33
Notes ………………………………………. 34-35

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
3
Safety Instructions
Important note:
Please read this booklet before installing and switching on this appliance.
The manufacturer assumes no responsibility for incorrect installation and
usage as described in this booklet.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance.
Electric ovens and hobs must be hard-wired to a suitably rated electrical
cooker power point –it is recommended that you consult a qualified
electrician. Failure to do so will invalidate your guarantee, liability claims
and could lead to criminal prosecution
•Children should be supervised to ensure that they do not play with the
appliance.
•If the supply lead is damaged it must be replaced by a qualified person
using the correct lead, available from 0345 208 8750.
•Packaging material is dangerous to children. Never allow children to play
with packaging material.
•Check the appliance for damage after unpacking it. Do not connect the
appliance if it has been damaged in transport.
•The appliance can only be used safely if it is correctly installed according
to the safety instructions. The installer is responsible for ensuring that
the appliance works correctly after installation.
•All operations relating to installation and regulation must be carried out
by an authorised installation engineer, respecting applicable regulations,
standards and the specifications of the local electricity providers.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
4
Safety Instructions
•This appliance can only be installed in a well-ventilated place in accordance with
existing regulations and ventilation specifications.
•This appliance is intended for domestic use and the household environment
only. The appliance is not intended for use outside.
•Do not tamper with the appliance's interior. If necessary, call our customer
helpline
•Do not switch on the appliance if it is damaged in any way. Contact our
customer helpline
•This appliance is only intended for cooking purposes, not as a heating system.
•Do not leave the appliance unattended during operation. The manufacturer is
not liable for damage which is caused by improper use or incorrect operation.
•Combustible items stored in the cooking compartment may catch fire. Never
store combustible items in the cooking compartment. Never open the appliance
door if there is smoke inside. Switch off the appliance and switch off the circuit
breaker in the fuse box.
•A draught is created when the appliance door is opened. Greaseproof paper
may come into contact with the heating element and catch fire. Do not place
greaseproof paper loosely over accessories during preheating. Always weight
down the greaseproof paper with a dish or a baking tin. Only cover the surface
required with greaseproof paper. Greaseproof paper must not protrude over
the accessories.
•Always slide accessories into the cooking compartment
•The appliance becomes very hot. Never touch the interior surfaces of the
cooking compartment or the heating elements. Always allow the appliance to
cool down. Keep children at a safe distance.
•Accessories and ovenware become very hot. Always use oven gloves to remove
accessories or ovenware from the cooking compartment.
•Shelves and the universal tray only must be placed and used between the 5 side
supports.
•The universal tray or any other kind of baking tray should not be placed on the
bottom of the oven cavity.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
5
Safety Instructions
•Alcoholic vapours may catch fire in the hot cooking compartment. Never
prepare food containing large quantities of drinks with a high alcohol content.
Only use small quantities of drinks with a high alcohol content. Open the
appliance door with care.
•The accessible parts become very hot when in operation. Never touch hot parts.
Keep children at a safe distance.
•When you open the appliance door, hot steam may escape. Open the appliance
door with care. Keep children at a safe distance.
•Water in a hot cooking compartment may create hot steam. Never pour water
into the hot cooking compartment.
•Scratched glass in the appliance door may develop into a crack. Do not use a
glass scraper, sharp or abrasive cleaning aids or detergents.
•The appliance gets hot. Do not keep combustible objects or aerosol cans in
drawers directly underneath the appliance.
•A defective appliance may cause electric shock. Never switch on a defective
appliance. Switch off the appliance and switch off the circuit breaker in the fuse
box. Contact the customer services.
•The cable insulation on electrical appliances may melt when touching hot parts
of the appliance. Never bring electrical appliance cables into contact with hot
parts of the appliance.
•Penetrating moisture may cause an electric shock. Do not use any high pressure
cleaners or steam cleaners.
•When replacing the cooking compartment bulb, the bulb socket contacts are
live. Before replacing the bulb, switch off the appliance and switch off the
circuit breaker in the fuse box.
•Incorrect repairs are dangerous. Repairs may only be carried out by a qualified
electrician.
•Never use strong and abrasive cleaning agents as they will cause surface
damage.
•In the event of a malfunction, turn off the appliance’s electricity supply. For
repairs, call customer services.
•Carrying the appliance: do not carry or hold the appliance by the door handle.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
6
Product overview
1
78
1. Oven function dial
2. Function touch buttons
3. Handle
4. Glass window
5. LED Display
6. Temperature/adjustment
dial
7. 2 x Wire shelf
8. 1 x Universal tray & handle
9. 1 x Wire rack
10.2 x Distance holding screws
Unit & Spare Parts
If any of the above parts are missing please contact the customer service team on
0345 208 8750 or visit www.productcare.co.uk
2
4
3
5
6
910

Positioning
•This appliance is to be installed under a counter top or in cabinets.
•Avoid damaging the product during installation.
•The appliance can only be used safely if it is correctly installed according to the
safety instructions. The installer is responsible for ensuring that the appliance
works correct when installed.
•Electric ovens and hobs must be hard-wired to a suitably rated electrical
cooker power point –it is recommended that you consult a qualified
electrician. Failure to do so will invalidate your guarantee, liability claims and
could lead to criminal prosecution.
•The aperture size has to be (H)600 x (W)560 x (D)570mm (please note that the
depth size is a minimum measure, the oven can be installed in an aperture that
has a bigger depth).
Note:
•Select heat-resistant work surface material to avoid larger deformation
caused by the heat radiation from the appliance.
•This oven has forced air ventilation.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
7

Installation
Preparation & installation
Ensure that there are no electric wires, gas or water pipes in the area where holes
are to be made.
Components of the appliance may have sharp edges. Wear protective gloves.
1. Ensure that there is an electrical power point within adequate distance of the
oven after it has been installed.
2. Ensure the aperture measures (H)600 x (W)560 x (D)570mm, in accordance
with the positioning instructions detailed on the previous page.
3. Carefully and gently put the oven into the aperture recess, making sure that
power cable can still be accessed.
4. Connect the oven to the electrical power point before pushing the oven into
the aperture fully.
5. Once this is done open the oven door and secure the oven to the kitchen
cabinet with two distance holding screws which fit the holes in the oven frame.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
8

Installation
Electrical connection
•WARNING- THIS APPLIANCE MUST BE EARTHED
•This appliance is designed to be connected to a 220-240V~50Hz AC electricity
supply.
•Before proceeding with the electrical connection, verify that the current
carrying capacity of the system and the isolator / main switch is adequate for
the maximum power rating of the oven.
•Electrical installation of the residence and of the appliance’s isolator must be
earthed and conform with the required safety regulations.
•If there is no suitable circuit and a fused switch, they must be installed
by a qualified electrician before the hob is connected.
•An isolator switch must be easily accessible once the oven has been installed.
•Do not use adaptors, multiple sockets and/or extension leads.
•A circuit breaker with a contact opening of at least 3 mm, rated 32A and
delayed functioning type must be installed inside the supply circuit.
•During installation, please ensure that insulated cables are used. An incorrect
connection might damage your appliance and will void the manufacturer’s
guarantee.
•All repairs must be carried out by an authorised service personal or a
qualified electrician.
•Switch off/isolate your appliance before each maintenance.
•The GREEN/YELLOW wire is the EARTH and must be connected to the
terminal which is marked with the letter E or by the earth symbol or
coloured GREEN or GREEN/YELLOW.
•The BLUE wire is the NEUTRAL and must be connected to the terminal
marked with the letter N or coloured BLACK.
•The BROWN wire is the LIVE wire and must be connected to the
terminal marked with the letter L or coloured RED.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
9

Usage
Control panel
The appliance has an oven function dial, temperature dial, a display and function
buttons, these are explained below:
LED display
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
10
1 2 5 7
346
1. Oven function dial
2. Minute minder touch button
3. Clock touch button
4. LED display
5. Start cooking touch button
6. Pause/stop cooking touch button
7. Temperature/adjustment dial
1. Oven function symbols
2. Time/minute minder
3. Oven temperature
4. Safety lock symbol
5. Alarm/Timer symbol
6. Oven light indicator
7. Reservation function
1 2
3
5
7
6
4

Symbol Function
Oven Lamp: Turns on the oven lamp.
Defrost: Circulates air in the oven at room temperature (without the use of
any heat) enabling quicker thawing of frozen food.
Use to defrost food only.
Bottom heating: The temperature is emitted from below which provides
heat to the base of food.
Use bottom heating for baking and browning dishes from below, ideal for
slow cooking dishes such as casseroles, stews, pastries and pizzas where a
crispy base is desired.
Top & bottom heating: Heat is emitted evenly from the top and bottom,
which provides convectional cooking. The top and bottom elements work
together to provide convectional cooking.
Best suited for single items that are centred in the oven: cakes and pizzas on
baking trays, and for lean joints of beef, etc.
Usage
Note: Always pre-heat the oven to the required temperature before cooking.
Oven function dial
The oven function dial allows you to set the oven function mode for the oven. The
dial has to be pressed in for it to pop out, before it can then be rotated clockwise
or anti-clockwise to set the required oven function.
When the required type of function is set, the oven light that is inside the oven
lights up. The temperature dial will also need to be adjusted when using any of the
oven functions except the oven lamp and defrost functions.
The appliance will utilise different elements within the oven cavity, depending on
the oven function that you select.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
11

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
12
Symbol Function
Convection heating with fan: The fan distributes the heated air around the
food that is emitted by the top and bottom heating elements.
Best suited for baking, roasting all meat, vegetables and pre-cooked meals.
Single grill: Part of the area below the grill heating element becomes hot.
The inner grill element is on.
Can be used to grill a small number of burgers, sausages fish or bread.
Double grill: The whole area below the grill heating element becomes hot.
The inner and outer grill elements are on.
Can be used to grill a large number of burgers, sausages fish or bread.
Double grill with fan: The fan distributes the heated air around the food.
The grill element and fan switch on and off alternately.
Hot air grilling is particularly suitable for grilling fish, poultry and larger
pieces of meat.
Convection heating: A fan with a ring heating element on the back of the
oven ensures that the heated air is distributed evenly.
You can bake cakes, pizza, biscuits, small cakes and puff pastry on two
levels at the same time.
Pyrolytic cleaning: This function cleans the oven cavity by raising the inner
oven temperature to approximately 450°C (the oven will lock the oven door
during this function). The resultant ash deposits can be wiped away with a
soft damp cloth once the oven has cooled down
PYA
Usage

Usage
Temperature/adjustment dial
Use the Temperature/adjustment dial to set the required temperature for the
oven. The dial has to be pressed in for it to pop out, before it can then be rotated
clockwise to set the required temperature.
The temperature can be set between 50°C and 250°C (this is dependent on the
function that is selected) and the grill temperature can be set between 180°C and
240°C.
NOTE: The unit of adjustment for temperature will change 5°C at a time.
The oven function dial must be adjusted to select the required oven function;
turning the temperature dial alone will not make the oven heat up.
Minute minder touch button
Press the minute minder touch button to set the countdown timer. The timer is
independent from the oven functions, when the countdown time has finished, an
audible signal will sound. The minute minder must be set prior to selecting an
oven function.
Clock touch button
Press the clock touch button to set the clock.
Start cooking touch button
Press the start cooking touch button to start the cooking function after the oven
function and temperature have been selected. Also press this button to
continue/resume cooking after pausing the cooking function.
Pause/stop cooking touch button
Press the pause/stop cooking touch button to pause the cooking function (the
oven will stop heating). If you wish to cancel the cooking function, you should
press the pause/stop cooking touch button twice. The oven will stop heating and
return to stand-by mode.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
13

Usage
The oven cavity
•The oven light is located in the cooking compartment. During oven operation,
the oven light is on.
•A cooling fan protects the oven from overheating.
•The cooling fan switches on and off as required. The hot air escapes above the
door.
•So that the cooking compartment cools down more quickly after operation, the
cooling fan continues to run for a certain period afterwards.
•There are supports either side of the compartment that accessories such as the
wire shelf baking tray, etc. can be inserted in to.
•The coating of the oven cavity is enamel.
•Before you use the accessories for the first time, clean them with hot soapy
water and a soft dish cloth.
•Clean all accessories by hand, do not clean in the dishwasher.
Before first use
Warnings:
•When it is first used, it is normal for the oven to give off odours; this does not
pose any risk and does not indicate a malfunction; they will disappear in
time.
•To remove any residue from the oven that may have been left from the
manufacturing process, you should select the convection & fan oven function
and set the thermostat to its maximum temperature setting.
•It is perfectly normal for a smell to be produced during this process.
•You should make sure that any windows in the room are left open during this
process.
•It is advisable for you not to remain in the room whilst the burning off
process is taking place.
•You should leave the oven on maximum setting for 30 –40 minutes.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
14

Usage
•After the oven cavity has cooled, it should then be cleaned with warm soapy
water, using either a sponge or soft cloth. No abrasive cleaners should be
used.
•Outer parts of the oven should be cleaned with warm soapy water, using
either a sponge or soft cloth. No abrasive cleaners should be used.
•We would recommend that an appropriate stainless steel cleaner and polish
is regularly used on the stainless steel surfaces of this appliance.
Setting the clock
When the oven is first connected to the electrical supply and powered on (or after
a power cut), the clock will need to be set. The display will automatically show the
time as “0:00“, there will be a single beep and the “:" will flash.
Note: ensure the correct time is set before using the oven.
Note: the clock is a 24 hour clock, for example 2PM will be shown as 14:00.
To set the correct time of day
1. Press the clock touch button and the hour digits will flash on the LED display.
2. Turn the temperature/adjustment dial to adjust the hour time. Your oven has
a 24 hour clock, so it is possible to adjust the hour digit between 0 and 23.
3. When the correct hour time appears on the LED display, press the clock button
again. The minute digits will flash on the LED display.
4. Turn the temperature/adjustment dial to adjust the minute time; it is possible
to adjust the minute digit between 0 and 59.
5. When the correct minute time appears on the LED display, press the clock
button for a third time to confirm the time of day.
6. The “:” symbol between the digits will flash and the time of day will light on
the LED display.
Note: You can adjust the time of day at any time by following the instructions
above, as long as the oven is not currently in use.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
15

Usage
Note: Always pre-heat the oven to the required temperature before cooking.
Selecting an oven function and temperature
The oven function dial should be used to select the particular mode of cooking
that you require. The appliance will utilise different elements within the oven
cavity, depending on the oven function that you select.
To start cooking:
1. Turn the oven function dial to select the oven function that you require. The
oven function symbols will light on the display to show you which oven
function is currently being selected. (see page 11-13 for a list of oven
functions/symbols).
2. Turn the Temperature/adjustment dial to set the temperature; the
temperature can be set between 50°C and 250°C (this is dependent on the
function that is selected) and the grill temperature can be set between 180°C
and 240°C.
3. Press the start cooking touch button to confirm the oven function and
temperature that you have chosen and the oven will start cooking.
4. The oven will operate until it has been turned off.
During cooking, you can adjust the cooking temperature by turning the
temperature/adjustment dial. The oven temperature will appear on the LED
display as you turn the temperature/adjustment dial. When the correct
temperature appears on the LED display, press the start cooking touch button.
If the start button is not pressed within 3 seconds of an oven temperature being
selected then the oven will revert back to the previously set temperature
NOTE: The unit of adjustment for temperature will change 5°C at a time. The Grill
function will adjust in 5°C or 30°C units dependent on the grill function.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
16

Usage
The minute minder
The minute minder is a countdown timer that is independent from the oven
functions. When the countdown time has finished, an audible signal will sound.
The minute minder must be set prior to selecting an oven function.
NOTE: The minute minder can be used without an oven cooking function
selected, and it will work as a separate kitchen timer.
To set the minute minder:
1. Press the minute minder touch button and the hour digits will flash on the LED
display.
2. Turn the temperature/adjustment dial to adjust the hour time; it is possible to
adjust the hour digit between 0 and 9.
3. When the correct hour time appears on the LED display, press the minute
minder touch button again. The minute digits will then flash.
4. Turn the temperature/adjustment dial to adjust the minute time; it is possible
to adjust the minute digits between 0 and 59.
5. When the correct minute time appears on the LED display, press the start
button to confirm the countdown time. The timer will be active immediately.
6. If required, you can now set an oven function, however the minute minder will
have no affect on the function when the time has elapsed.
7. The alarm will sound 10 times when the countdown has finished.
Note: You cannot amend the minute minder after a cooking function has been
started. To do this, you must cancel the current cooking operation and re-
program the minute minder and cooking function.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
17

Usage
The duration timer
The duration timer is a countdown timer that is linked to your oven. When the
countdown has finished, an audible signal will sound and the oven will turn off.
To set the duration timer:
1. After you have selected an oven function and pressed start, the oven will start
to heat and will run until it is turned off unless the duration timer is set.
2. During cooking, adjust the cooking time (cooking duration) by turning the oven
function dial.
3. Press the start cooking touch button to confirm the oven cooking duration that
you have chosen and the oven timer will start.
4. At the end of the cooking time, an audible signal will sound and the oven will
turn off.
NOTE: When adjusting the timer, please be aware that the timer will scroll
through one minute at a time between 0:00 –0:30 minutes. When scrolling
between 0:30 minutes to 9:00 hours, the timer will scroll in 5 minute units.
Pausing a cooking function
During cooking, if you wish to pause the cooking function, you should press the
pause/stop cooking touch button once. The oven will stop heating and the cooking
time will pause.
To continue cooking after pausing the cooking function, you should press the start
cooking touch button. The oven will resume cooking, using the same oven function
and temperature as previously set.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
18

Usage
Reservation function
The reservation function allows you to set the time you want your oven to come
at, with the function you require and for the duration you require.
Note: The clock must be set for this function to work
To set the reservation function:
1. To set the time that you require the oven to start cooking at, press the clock
touch button and the hour digits will flash on the LED display.
2. Turn the temperature/adjustment dial to adjust the hour time. Your oven has
a 24 hour clock, so it is possible to adjust the hour digit between 0 and 23.
3. When the correct hour time appears on the LED display, press the clock button
again. The minute digits will flash on the LED display.
4. Turn the temperature/adjustment dial to adjust the minute time; it is possible
to adjust the minute digit between 0 and 59.
5. When the correct minute time appears on the LED display, turn the oven
function dial (do not press the clock button) to select the oven function that
you require. The oven function symbols will light on the display to show you
which oven function is currently being selected. (see page 11-13 for a list of
oven functions/symbols).
6. Turn the temperature/adjustment dial to set the temperature; the
temperature can be set between 50°C and 250°C (this is dependent on the
function that is selected) and the grill temperature can be set between 180°C
and 240°C.
7. Press the start cooking touch button to confirm the oven function and
temperature that you have chosen and the oven will start cooking.
8. Turn the oven function dial to set the cooking time you require, press the start
cooking touch button to confirm the cooking time.
9. The display will return to the clock but now the reservation icon will be lit on
the display
10. At the time of reservation, cooking will start automatically after a buzzing
sound and the reservation icon will stop being lit on the display.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
19

Usage
Notes:
•The reservation time can be checked by pressing clock button, the reservation
time will be display for 3 seconds later before the display reverts back to the
current time again.
•When the reservation function has been set, press the cancel button once and
the oven function, temperature and cooking duration of the reservation
function will be shown on the display. Press the cancel button again to cancel
the reservation function completely, or press the start button to return to
reservation function.
•The minute minder function cannot be used when the reservation function has
been set
Cancelling a cooking function
During cooking, if you wish to cancel the cooking function, you should press the
pause/stop cooking touch button twice. The oven will stop heating and return to
stand-by mode.
Checking the time function
Whilst the appliance is cooking, to check the time of day, press the clock touch
button once. When a countdown time is set, to check the remaining cooking time,
press the clock touch button once.
Safety lock
Note: When the safety lock is switched on, it disables the control panel so that it
is not possible to alter any settings.
Press the pause/stop cooking touch button and start cooking touch buttons
simultaneously for 3 seconds. There will be a long audible signal and lock a symbol
will appear on the LED display, these confirm that the safety lock has been
activated.
For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcare.co.uk
20
