RVS Air Vue RVS-AVL User manual

2.4GHz Digital Wireless
Transmitter with PLC
Instruction Manual
©Rear View Safety 2023
RVS-AVL

2©Rear View Safety
Introduction ...................................................................................................3
In The Box ......................................................................................................3
SafetyInformation......................................................................................4-6
Precautions ....................................................................................................7
Product Features ..........................................................................................9
Technical Specifications ...........................................................................10
Connection Diagram ..................................................................................11
Connection and Operation Instructions .................................................11
Troubleshooting............................................................................................12
Warranty ......................................................................................................14
Disclaimer ....................................................................................................15
TABLE OF CONTENTS

Rear View Safety, 1797 Atlantic Ave., Brooklyn NY 11233
800.764.1028 [email protected]
www.rearviewsafety.com
3
IN THE BOX
Congratulations on purchasing a Air VueTM Digital Wireless Transmitter!
With this manual you will be able to properly install and operate the unit.
The accompanying monitor for this wireless transmitter is intended to be installed
as a supplement aid to your standard rear view mirror that already exists in your
vehicle. The Monitor should not be used as a substitute for the standard rear
view mirror or for any other mirror that exists in your vehicle.
In some jurisdictions, it is unlawful for a person to drive a motor vehicle equipped
with a TV viewer or screen located forward of the back of the driver’s seat or in
any location that is visible, directly or indirectly, to the driver while operating the
vehicle.
Please read all of the installation instructions
carefully before installing the product. Improper
installation will void manufacturer’s warranty.
1 x Transmitter Box
1 x Antenna
Cables
Manual
INTRODUCTION

4©Rear View Safety
SAFETY INFORMATION
USAGE : The Rear View Camera System is designed to help the driver safely
detect people and/or objects helping to avoid damage or injury. However, you
the driver, must use it properly. Use of this system is not a substitute for safe,
proper or legal driving.
• Never back up while looking at the monitor alone. You should always check
behind and around the vehicle when backing up, in the same way as you would
if the vehicle did not have the Rear View Camera System. If you back up while
looking only at the monitor, you may cause damage or injury. Always back up
slowly.
• The Rear View Camera System is not intended for use during extensive back-
up maneuvers or backing into cross trac or pedestrian walkways.
• Please, always remember, the area displayed by the Rear View Camera System
is limited. It does not display the entire panorama that is behind you.
PLEASE READ THE ENTIRE MANUAL AND FOLLOW THE INSTRUCTIONS
AND WARNINGS CAREFULLY. FAILURE TO DO SO CAN CAUSE SERIOUS
DAMAGE AND/OR INJURY, INCLUDING LOSS OF LIFE. BE SURE TO OBEY ALL
APPLICABLE LOCAL TRAFFIC AND MOTOR VEHICLE REGULATIONS AS IT
PERTAINS TO THIS PRODUCT. IMPROPER INSTALLATION WILL VOID
MANUFACTURER’S WARRANTY.

Rear View Safety, 1797 Atlantic Ave., Brooklyn NY 11233
800.764.1028 [email protected]
www.rearviewsafety.com
5
SAFETY INFORMATION
INSTALLATION
Electric shock or product malfunction may occur if this product
is installed incorrectly.
• Use this product within the voltage range specified. Failure to do so can
cause electronic shock or product malfunction.
• Take special care when cleaning the monitor.
• Make sure to firmly ax the product before use.
• If smoke or a burning smell is detected, disconnect the system immediately.
• Where the power cable may touch a metal case, cover the cable with a
friction tape. A short circuit or disconnected wire may cause a fire.
• While installing the RVS System be careful with the wire positioning in
order to avoid wire damage.
• The RVS System should only be used when the vehicle is in reverse.
• Do not watch movies or operate the monitor while driving; as it may cause
an accident.
• Do not install the monitor where it may obstruct drivers view or obstruct an
air bag device.
• Dropping the unit may cause possible mechanical failure.
• When in reverse, monitor buttons are not functional

6©Rear View Safety
IN NO EVENT SHALL SELLER OR MANUFACTURER BE
LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF
ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM
ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
If you have questions about this product,
please contact us at:
800.764.1028 [e-mail]
www.rearviewsafety.com
New York
1797 Atlantic Ave
Brooklyn, NY 11233
Indiana
319 Roske Dr.
Elkhart, Indiana 46516
Canada
68 Trafalgar Square
Thornhill, ON, L4J 7M5, Canada

Rear View Safety, 1797 Atlantic Ave., Brooklyn NY 11233
800.764.1028 [email protected]
www.rearviewsafety.com
7
PRECAUTIONS
Storage and Keeping
Operating Precautions
1. Do not expose the device to excessive heat or cold. The storage temperature
of this device is -30~+80°C. The operating temperature of this device is
-20~+70°C with a maximum relative humidity of 90%.
2. Avoid dropping or striking this device.
3. Avoid using this device in enclosed spaces, areas with excessive vibration or
subjecting this device to severe impacts.
4. Do not place cables where they may be pinched or stepped on.
5. The device is designed to be water-resistant, but not completely waterproof
for underwater application.
1. The device may be powered by a 12 or 24 volt automotive battery or vehicle
electrical system.
2. Make sure all cables are connected properly. Observe polarity. Improper
cable connections may damage the device. Remove the power cable
connections when you do not intend to use the unit.
High voltage is present within the device.
The case should only be opened by professionals.
Never try to repair this device by yourself. In case of
any problems, please turn o the device at once and
notify our company or authorized dealer.

8©Rear View Safety
Remove all cable connections from the device before cleaning the unit.
This symbol is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
that may be of sucient magnitude to constitute risk of electric
shock to persons.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
This symbol is intended to alert the user not to dispose
of electrical and electronic equipment.
CAUTION
Any changes or modifications not expressly approved in this manual could void
your warranty and necessitate expensive repairs.
MAINTENANCE

Rear View Safety, 1797 Atlantic Ave., Brooklyn NY 11233
800.764.1028 [email protected]
www.rearviewsafety.com
9
2. PRODUCT FEATURES
(1) Power supply: DC10-32V
(2) Supply 12V voltage for camera
(3) Supports AHD 720P or AHD 1080P camera
(4) Metal housing, solid, suitable for outdoor use
(5) Waterproof protection level: IP69K
(6) Power & Pair LED Indicators
Power: the “POWER” indicator turns red when
power is on.
Pairing: “PAIRING” indicator turns solid blue
when paired.
Antenna
Power
4 Pin Camera Connector

10 ©Rear View Safety
3. TECHNICAL SPECIFICATIONS
Power supply DC 10-32V
Video input AHD720P / AHD1080P
Video Codec H.264
Operation frequency 2400 - 2483.5 MHz (ISM band)
Modulation QPSK
RF Bit Rate 6Mbps
Spread spectrum FHSS
Transmitter Power FCC < 26 dBm, CE < 20 dBm, MIC < 10 dBm
Receiving Sensitivity -78dBm
Transmission Range FCC < 300 m, CE < 200 m, MIC < 60 m
Active area 154.08(H) × 85.92(V) mm
Signal delay < 200ms
Operating Temperature -20 ~ +70°C RH90%
Storing Temperature -30 ~ +80°C RH90%
