RWM Casters RWM CONVERTIBLE HAND TRUCK User manual
RWM CONVERTIBLE HAND TRUCK ASSEMBLY INSTRUCTIONS
PART LIST
REFERENCE PART QTY
A
HC1 Large Convertible Frame
1
B
Frame Reinforcements
2
C
CA2 Nose Plate
1
D
BRK Wheel Brackets
1 Pair
E
A1 Axle
1
F
10” Wheels
2
G
5/8” Flat Washers
2
H
3/16” x 1-7/8” Roll Pin
2
I
1/8” x 1” Cotter Pin
2
J
5/16” x 2-1/4” Hex Bolts
4
K
5/16” Lock Nuts
4
STEP 1
•
Remove supplied Hex Bolts (J) and Lock Nuts (K) from
Frame Assembly
•
Remove and discard white nylon ties from Wheel Brackets (D)
•
Working from outside in, reinstall Hex Bolts (J) through
Wheel Brackets (D), Frame (A), Frame Reinforcements (B)
and Nose Plate (C).
•
Align Wheel Brackets (D) so that the integrated bosses fit into the
recesses on the outside of the Frame (A).
•
The curvatures of the brackets point toward the top of the Frame
(A) and the protrusion is on the same side of the frame as the blue
handle.
•
The Nose Plate (C) protrudes from the opposite side of the blue
handle
•
Reinstall the Locking Nuts (K).
DO NOT TIGHTEN.
Hex Bolts
(J)
Wheel Bracket
(D)
Frame
(A)
Frame
Reinforcement
(B)
Lock Nuts
(K)
(K)
Nose Plate
(C)
RWM Casters
1225 Isley Road • P.O. Box 668 • Gastonia, NC 28053
Phone 800-634-7704 • Fax 800-253-6634 • www.rwmcasters.com
Quality products on time. RWM Casters. The value added supplier.
STEP 2
•
Install the Axle (E) through the outermost holes of the Wheel
Brackets (D).
•
Install Flat Washers (G) on each end of the axle.
STEP 3
•
Align one Axle (E) hole with the corresponding notch in the Wheel
Bracket (D).
•
Using a hammer, lightly drive the Roll Pin (H) into the hole until
the end of the Roll Pin is nearly flush with the face of the Wheel
Bracket.
•
Repeat for other side.
STEP 5
•
Install a 10” Wheel (F) on each side of the Axle (E).
STEP 6
•
Additional washers are supplied with the installation kit to compen-
sate for the difference spacing required when alternate wheels are
installed with varying hub lengths. If necessary, remove wheel and
add/remove washers to adjust free play.
•
Install 1 Cotter Pin (I) into each end of Axle (E) and wrap the split
ends.
STEP 7
•
Discard all unused hardware.
•
Remove and discard the supplied white nylon ties form the Frame Reinforcements (B).
Flat Washer (G)
Wheel Brackets (D)
Axle (E)
Wheel Brackets (D)
Roll Pin (H)
Axle (E)
10” Wheel (F)
Axle (E)
Cotter Pin(I)
Axle (E)
STEP 4
•
Securely tighten each of the Lock Nuts (K) installed in Step 1.
Locking Nuts (K)
