Ryobi P745 Quick setup guide

RYOBI
JOB-SITE RADIO
MODEL NO. P745
REPAIR SHEET

RYOBI JOB-SITE RADIO – MODEL NUMBER P745
2
11
220
21
17
18
16
22
23
26
24
27
15
9
4
13
5
55
5
3
19
77
12
25
26
25
8
11
10
14
6

RYOBI JOB-SITE RADIO – MODEL NUMBER P745
3
PARTS LIST
1 51-120-109R000 Screw (M6 x 20 mm) .....................................4
2 67-745-001H000 Handle ...........................................................1
3 15-745-002R000 Antenna .........................................................1
4 67-745-003H000 Left Frame .....................................................1
5 51-120-108R000 Screw (M6 x 30 mm) .....................................8
6 83-745-005R000 Logo Label.....................................................1
7 51-210-205R000 Square Nut (M6) ............................................4
8 52-974-509R000 Door Latch.....................................................1
9 67-745-002H000 Right Frame...................................................1
10 67-745-027H000P Door Latch Bracket .......................................1
11 51-110-135R000 Screw (M3 x 18 mm) .....................................2
12 67-745-023H000P Volume Knob .................................................1
13 83-745-001R000 AUX Label......................................................1
14 51-120-107R000 Screw (M3 x 15 mm) .....................................1
15 83-745-009R000 Data Label .....................................................1
16 83-745-003R000 LED Label ......................................................1
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding
your RADIO or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
17 67-745-035H000P Back Door .....................................................1
18 52-974-508R000 Hinge Pin .......................................................1
19 67-745-033H000P AAA Battery Door ..........................................1
20 83-745-004R000 Charger Label................................................1
21 83-745-002R000-WDP Warning Label ...............................................1
22 83-745-006R000 Display Label.................................................1
23 83-745-007R000 Logo Label.....................................................1
24 67-745-034H000P Compartment Door .......................................1
25 52-915-608RA00 E-Ring............................................................2
26 52-974-506R000 Door Pin.........................................................2
27 83-745-000R000 USB Label .....................................................1
Not Shown:
24-000-002 AAA Batteries ................................................2
987000675 Operator’s Manual.........................................1
8-9-11
(Rev:01)
