Ryobi CSB143LZK Quick setup guide

RYOBI 7-1/4 in.
CIRCULAR SAW
MODEL NO. CSB143LZK
REPAIR SHEET

2
RYOBI 7-1/4 in. CIRCULAR SAW – MODEL NUMBER CSB143LZK
WARNING: Improper repair of a double insulated tool can result in damages to the double insulation system possibly causing electrical shock
or electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized
Service Center. For the service center nearest you call 1-800-525-2579.
60
1
234
6
11
57
12
13
14
15
40
36
39
38
37
41
62
58 16 17
54
55
18
21 23 24
25 26
28
42 43
44
20
50
51
61
35
1
29
29
46
31
30
32
53
45
52
47
48
49
56
59
8
9
9
7
19
33
34
10
5
22 27

3
RYOBI 7-1/4 in. CIRCULAR SAW – MODEL NUMBER CSB143LZK
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
CIRCULAR SAW or when ordering parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 660208052 Screw (M4 x 16 mm, Pan Hd.)...................... 7
2 524937002 End Cover ..................................................... 1
3 562998001 Rubber Bumper ............................................ 2
4 290075001 Brush Assembly............................................ 2
5 660259008 Screw (M4.5 x 35 mm).................................. 3
6 524935002 Motor Housing .............................................. 1
7 681304001 Ball Bearing (608-2RS) ................................. 1
8 230452001 Motor Assembly (Inc. Key No. 7) .................. 1
9 660101002 Screw (4.2 x 2.54 x 50, Type B Pan Hd.) ...... 2
10 941120012 Warning Label............................................... 1
11 525084001 Volute ............................................................ 1
12 634292001 Spindle Lock ................................................. 1
13 693411002 Compression Spring ..................................... 1
14 670974003 Lock Nut (M5) ............................................... 1
15 202001006 Upper Blade Guard Assembly
(Inc. Key No. 10, 18, 56-57 and 59).............. 1
16 561984001 Bumper ......................................................... 1
17 660193005 Shoulder Screw (M5 x 20 mm) ..................... 1
18 680413005 Bushing......................................................... 1
19 305403001 Output Shaft and Gear Assembly................. 1
20 680980003 Roll Pin.......................................................... 1
21 305401001 Lower Blade Guard Support Assembly
(Inc. Key No. 19) ........................................... 1
22 661349001 Screw (M4 x 16 mm, Pan Hd.)...................... 4
23 680672006 Torsion Spring............................................... 1
24 524934002 Lower Blade Guard....................................... 1
25 693438001 Retaining Ring .............................................. 1
26 611791001 Inner Flange Bushing .................................... 1
27 680775001 Outer Blade Washer...................................... 1
28 660988001 Blade Screw (5/16-18 x 9/16 in.) .................. 1
29 202145001 Handle Assembly.......................................... 1
30 280226001 Circuit Board w/Micro Switch Assembly ...... 1
31 760476004 Switch ........................................................... 1
32 790021001 Closed End Wire Connector ......................... 1
33 551060003 Bend Relief ................................................... 1
34 730372030 Power Cord................................................... 1
35 690119009 Rip Guide ...................................................... 1
36 660206042 Screw (M3.5 x 16 mm, Pan Hd.)................... 3
37 351101001 Laser Cover .................................................. 1
38 693240001 Compression Spring ..................................... 1
39 291129001 Laser Assembly ............................................ 1
40 513075002 Hex Nut (M3)................................................. 1
41 512963002 Nylon Screw (M3 x 6 mm, Special)............... 1
42 612031001 Depth Lock Nut (1/4-20) ............................... 1
43 634295001 E-Ring ........................................................... 1
44 634293001 Depth Lock Lever ......................................... 1
45 693616001 Carriage Bolt (1/4-20 x 5/8 in., Special)........ 1
46 305407002 Base Assembly (Inc. Key Nos. 47-53) .......... 1
47 301124018 Edge Guide Knob Assembly......................... 1
48 660106007 Hex Nut (8-32)............................................... 1
49 660112006 Screw (8-32 x 11/32 in., Pan Hd.)................. 1
50 301124020 Bevel Lock Knob........................................... 1
51 680771002 Washer (OD5/8 x ID7/16 x 1/16t).................. 1
52 660104010 Carriage Bolt (1/4-20 x 5/8 in.) ..................... 1
53 634389001 Blade Wrench ............................................... 1
54 941121021 Data Label..................................................... 1
55 941120008 Warning Label............................................... 1
56 941006007 Laser Label (ENG/FR) ................................... 1
57 941006008 Laser Label (SP)............................................ 1
58 941002019 Logo Label .................................................... 1
59 681717001 Ball Bearing (6000-2RS) ............................... 1
60 680776001 Spring Washer .............................................. 1
61 680783014 Blade (7-1/4 in.) ............................................ 1
62 941001058 Laser Label ................................................... 1
Not Shown:
200673002 Dust Nozzle Kit (Optional)............................. 1
990000076 Operator’s Manual
5-2-13
(Rev:05)

4
RYOBI 7-1/4 in. CIRCULAR SAW – MODEL NUMBER CSB143LZK
WIRING DIAGRAM
RED
RED
MOTOR
MICRO
SWITCH
WHITE
WHITE WHITE
WIRE NUT
BLACK
BLACK
BRUSH
ASSEMBLY
CIRCUIT BOARD
ASSEMBLY
LASER
ASSEMBLY
SWITCH
BLACK
POWER CORD
BLACK
