Ryobi P505 Quick setup guide

RYOBI
18 VOLT CIRCULAR SAW
MODEL NUMBER P505
REPAIR SHEET

2
RYOBI 5-1/2 in. (140 mm) CIRCULAR SAW – ITEM NUMBER P505
SEE FIGURE B
3
4
3
5
6
7
8
11
9
12 14
16
17 18
19
20 21 22
23
24 25
10
33
29
30
31
32 26
27
28
1
2
15
13
FIGURE A

3
RYOBI 5-1/2 in. (140 mm) CIRCULAR SAW – ITEM NUMBER P505
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
CIRCULAR SAW or when ordering repair parts.
PARTS LIST – FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY
1 660193006 Screw (M5 x 18 mm).......................................1
2 560990003 Rubber Stopper..............................................1
3 670974003 Lock Nut (M5) .................................................2
4 660145003 Screw (M5 x 40 mm, Pan Hd.)........................1
5 523287001 Shaft Lock Holder...........................................1
6 900303008 Sealing Pad ....................................................1
7 630191001 Shaft Lock Plate .............................................1
8 523274001 Shaft Lock Button...........................................1
9 940114191 Logo Label (End Cap).....................................1
10 940533055 Ryobi One+ Label...........................................1
11 941121478 Data Label ......................................................1
12 941120109 Warning Label.................................................1
13 670056001 Compression Spring (Shaft Lock)...................1
14 680002001 Hex Key (#5, 6 mm x 80 mm) .........................1
15 941002221 Logo Label......................................................1
16 525914002 Upper Blade Guard.........................................1
17 660024044 Screw (M4 x 16 mm, T20 Torx Pan Hd.) ........3
18 680672001 Torsion Spring.................................................1
19 523124001 Lower Blade Guard.........................................1
20 680503003 Retainer Plate .................................................1
21 660201004 Screw (M2.6 x 10 mm, Pan Hd.).....................4
22 610276003 Inner Blade Clamp..........................................1
23 670973029 Blade (5-1/2 in., 24T) ......................................1
24 610121001 Outer Blade Clamp.........................................1
25 660144005 Blade Screw
(M6 x 16 mm, Left Hand Threads)..................1
26 301124004 Depth Lock Knob............................................1
27 691992001 Washer (OD12 x ID6.4 x 1t) ............................1
28 661067002 Screw (M6 x 22 mm, Pan Hd.)........................1
29 304721009 Base Assembly (Incl. Key Nos. 30-33) ...........1
30 660142008 Screw (M6 x 12 mm, Pan Hd.)........................1
31 660212053 Screw (M4 x 16 mm, Pan Hd.)........................1
32 680022003 Hex Nut (M4)...................................................1
33 301124011 Bevel Lock Knob ............................................1
Not Shown
990000625 Operator's Manual
7-13-15
(Rev:01)
KEY PART
NO. NUMBER DESCRIPTION QTY

4
RYOBI 5-1/2 in. (140 mm) CIRCULAR SAW – ITEM NUMBER P505
1
2
3
3
12
11 10
4
9
5
6
8
13
7
FIGURE B

5
RYOBI 5-1/2 in. (140 mm) CIRCULAR SAW – ITEM NUMBER P505
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
CIRCULAR SAW or when ordering repair parts.
PARTS LIST – FIGURE B
KEY PART
NO. NUMBER DESCRIPTION QTY
1 523123001 End Cap......................................................................................................................1
2 660024044 Screw (M4 x 16 mm, T20 Torx Pan Hd.) ..................................................................12
3 203523001 Housing Assembly......................................................................................................1
4 523141001 Lock-Off Button..........................................................................................................1
5 672552001 Spring .........................................................................................................................1
6 270016162 Switch w/Wiring Assembly .........................................................................................1
7 560219006 Hex Key Plug ..............................................................................................................1
8 220180001 Gear Box Assembly....................................................................................................1
9 660208049 Screw (M4 x 22 mm, Pan Hd.)....................................................................................4
10 660212004 Screw (M4 x 16 mm, T25 Torx Pan Hd.).....................................................................2
11 670030004 Washer (OD7.2 x ID4.1 x 1.1t) ....................................................................................2
12 230387001 Motor w/Pinion Assembly...........................................................................................1
13 306640001 Output Shaft w/Gear Assembly..................................................................................1

6
RYOBI 5-1/2 in. (140 mm) CIRCULAR SAW – ITEM NUMBER P505
WIRING DIAGRAM
BLACK
MOTOR
SWITCH
RED
RED
CONTACT
PLATE
HOLDER
