12 in. MITER SAW
MODEL NO. TS1552LA
REPAIR SHEET

Figure A
43 15 42 41
39
58
57
36
38
61
60 30
33
32
31
66
28
63
62 68
27
29
37
59
65
13
40
14
15
16
21 19 20
35 34
26
11
12
987
18 17
2
10
35646
67 52
56
54
55
53 51
55
54
24
25
1
46 47
50
44
45
48 64
23
22
49 44
45
69
70
RYOBI MITER SAW – MODEL NUMBER TS1552LA
2

RYOBI MITER SAW – MODEL NUMBER TS1552LA
3
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE A)
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
KEY PART
NO. NUMBER DESCRIPTION QTY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
1 089100300701 BASE/MITER TABLE ASSEMBLY...................1
2 270577000 PIVOT SHOE ..................................................1
3 089100300002 BEVEL PIVOT ASSEMBLY .............................1
4 303510000 BEVEL INDICATOR ........................................1
5 089100300004 BEVEL SCALE INDICATOR (LEFT).................1
6 020716007 * SCREW w/WASHER
(M5 X 0.8 X 10 mm PAN HD.).........................2
7 021117003 WASHER ........................................................1
8 021611000 WAVY WASHER .............................................1
9 022300001 NYLON LOCK NUT ........................................1
10 028969001 LOCK PIN.......................................................1
11 021109019 FLAT WASHER ...............................................1
12 303451002 BEVEL LOCK KNOB ......................................1
13 020113008 * SCREW-SHOULDER (M6 X 10 mm) ..............1
14 021403007 * WAVY WASHER (7.5 X 12.7 X 0.4t)................1
15 021103010 * WASHER (7.5 X 16 X 0.8t)..............................2
16 021101033 WASHER ........................................................1
17 130064000 LOCK PIN.......................................................1
18 089100300017 LOCK PIN COVER..........................................1
19 303226000 SPRING SPACER ........................................... 1
20 029233001 TORSION SPRING .........................................1
21 132068000 ARM PIVOT SHAFT........................................1
22 020314015 HEX SCREW ..................................................2
23 022116001 HEX NUT ........................................................2
24 020804011 SCREW ..........................................................6
25 089100300024 THROAT PLATE (TABLE INSERT)...................1
26 020504009 * LOCKING SCREW (M6 X 1P X 10 mm)..........1
27 022111007 NUT (M6) ........................................................1
28 089100300702 MOTOR ASSEMBLY ......................................1
29 089100300027 * HEX SOCKET BOLT (M6 X 1P X 24 mm) ....... 1
30 089100300703 CARRY HANDLE ASSEMBLY ........................1
31 303711000 CARRY HANDLE (LOWER) ............................1
32 303710000 CARRY HANDLE (UPPER) .............................1
33 020132005 * SCREW (M4 X 45 mm PAN HD.) ....................2
34 089100300031 RUBBER SLEEVE...........................................1
35 028921003 * SCREW (10-32 X 20 mm)...............................1
36 089100300704 BLADE............................................................1
37 089100300033 INNER BLADE WASHER................................1
38 089100300705 LOWER BLADE GUARD ASSEMBLY.............1
39 089100100133 * SCREW (10-32 X 5/16 in. PAN HD.)...............1
40 089100300035 * SHOULDER BOLT (10-32 X 6.5 mm) ............. 1
41 021119002 * WASHER (5.5 X 16 X 0.8t)..............................1
42 270579000 LEVER ............................................................1
43 028931002 * SHOULDER SCREW (M5 X 0.8P) ..................1
44 020606009 * SCREW (5/16-18 X 1-1/2 in.) .........................4
45 021120003 * WASHER (8 X 16 X 1.2t).................................4
46 089100300041 * KNOB (M6 X 1P X 40 mm) .............................1
47 089100300042 SPECIAL BOLT...............................................1
48 089100300043 FENCE............................................................1
49 089100300044 SLIDING MITER FENCE.................................1
50 089100300045 * SPRING (51.5 X 7 X 0.4t)................................1
51 900786003 MITER LOCK HANDLE...................................1
52 040027001 BLADE WRENCH ...........................................1
53 089100300706 WORK CLAMP ASSEMBLY ...........................1
54 089100300048 TABLE EXTENSION........................................2
55 089100300707 TABLE EXTENSION
CLAMP BRACKET ASSEMBLY......................2
56 900757000 STOP BLOCK.................................................1
57 089100300049 DUST GUIDE..................................................1
58 089100300050 DUST BAG (24 X 26 X 10) ..............................1
59 089100300725 ADJUSTABLE LASER.....................................1
60 290257000 OUTER BLADE WASHER...............................1
61 089100300053 * BLADE BOLT (M10 X 18 mm).........................1
62 089100300901 HANDLE WARNING LABEL ...........................1
63 089100300902 HANG TAG WARNING LABEL .......................1
64 870033002 FENCE SCALE ...............................................1
65 020325001 HEX BOLT (LASER) ........................................1
66 089100304900 DATA LABEL...................................................1
67 089100300913 ANTI TIP ASSEMBLY (BRKT & NUTS) ...........1
68 089100300914 ANTI TIP LABEL - (HANG TAG)......................1
69 089100304902 SLIDING FENCE LABEL.................................1
70 089100300726 HEX KEY (1/16 in.)..........................................1
71 089100300721 ADJUSTABLE LASER KIT
(INC. KEY NOS. 59, 65 & 70) .........................1
987000163 OPERATOR’S MANUAL
9-20-07
(REV:01)

1
Figure B 2
3
4
5
6
7
8
9
10
11
13
12
14
15
16
17
9
5
RYOBI MITER SAW – MODEL NUMBER TS1552LA
4

RYOBI MITER SAW – MODEL NUMBER TS1552LA
5
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE B)
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
089100300701 BASE/MITER TABLE ASSEMBLY (INC. KEY NOS.1-17).............................................. 1
1 020606013 * HEX SOCKET BOLT (5/16 X 18 X 14.8 mm) ................................................................ 2
2 021120003 * WASHER (8 X 16 X 1.2t)............................................................................................... 2
3 270575000 SPRING INDEX ............................................................................................................ 1
4 022308001 NYLON NUT................................................................................................................. 1
5 021109011 * FLAT WASHER (10 X 21 X 1.2t).................................................................................... 2
6 021403001 WAVY WASHER ........................................................................................................... 1
7 225234000 BASE ............................................................................................................................ 1
8 330030000 GROMMET................................................................................................................... 1
9 867227001 WARNING LABEL (NO HANDS)................................................................................... 2
10 870033000 MITER SCALE .............................................................................................................. 1
11 024400000 SCREW ........................................................................................................................ 3
12 089100300709 MITER TABLE ASSEMBLY ........................................................................................... 1
13 303515000 MITER POINTER .......................................................................................................... 1
14 020716007 * SCREW w/WASHER (M5 X 0.8 X 10 mm PAN HD.)..................................................... 1
15 303514000 SHOE ........................................................................................................................... 2
16 020726003 * SCREW w/WASHER (M4 X 0.7 X 8 mm)...................................................................... 4
17 303254000 MITER LOCK PLATE .................................................................................................... 1

Figure C
RYOBI MITER SAW – MODEL NUMBER TS1552LA
6
10
9
3
5
8
7
6
4
21

RYOBI MITER SAW – MODEL NUMBER TS1552LA
7
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE C)
089100300705 LOWER BLADE GUARD ASSEMBLY (INC. KEY NOS. 1-10) .................................... 1
1 022307001 * NUT (10-32) ...............................................................................................................1
2 021108006 * WASHER (13/64 X 15/32 X 0.5t)................................................................................1
3 089100300121 BLADE BOLT COVER ................................................................................................1
4 089100300122 SPRING ..................................................................................................................... 1
5 089100300123 LOWER BLADE GUARD............................................................................................1
6 270376005 LOWER GUARD PLATE............................................................................................. 1
7 028939010 * SCREW (10-32) ......................................................................................................... 1
8 303993000 RUBBER WHEEL....................................................................................................... 1
9 022711000 PLATE NUT................................................................................................................1
10 089100300912 WARNING LABEL......................................................................................................1

Figure D
RYOBI MITER SAW – MODEL NUMBER TS1552LA
8
3
1
5
8
7
6
4
2

RYOBI MITER SAW – MODEL NUMBER TS1552LA
9
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE D)
089100300709 MITER TABLE ASSEMBLY (INC. KEY NOS. 1-8) ...........................................................1
1 020704002 SCREW w/WASHER (M5 X 0.8 X 10 mm)......................................................................2
2 270576000 TABLE GUARD...............................................................................................................1
3 028961001 SHOULDER BOLT..........................................................................................................1
4 020505009 SET SCREW...................................................................................................................1
5 089100300116 MITER TABLE.................................................................................................................1
6 028307007 PIVOT SHAFT.................................................................................................................1
7 089100300911 BEVEL SCALE................................................................................................................1
8 024400000 RIVETS ...........................................................................................................................3

Figure E
32
29
28
31
30
20
25
19
26 24
23
1
22
35
34
36
33
21
5
6
324
37
27
7
9
8
10
11
12
13
15
14
15
14
16 17 18
RYOBI MITER SAW – MODEL NUMBER TS1552LA
10

RYOBI MITER SAW – MODEL NUMBER TS1552LA
11
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGUR E)
KEY PART
NO. NUMBER DESCRIPTION QTY
089100300702 MOTOR ASSEMBLY.......................................1
1 089100300078 UPPER BLADE GUARD..................................1
2 029151001 * SPRING (7.7 X 1 X 30 mm)............................. 1
3 023206001 RETAINING RING (E-6) ...................................1
4 290206001 ARBOR LOCK.................................................1
5 089100300082 DUST CHUTE .................................................1
6 089100100070 * SCREW w/WASHER (M5 X 0.8 X 8 mm) ........1
7 050001100 BALL BEARING ..............................................1
8 270026000 BEARING PLATE ............................................1
9 089100300086 * SCREW w/WASHER (M4 X 0.7 X 23 mm) ......2
10 089100300711 ARMATURE ASSEMBLY
(INC. KEY NOS. 7, 8 &11) ..............................1
11 050007000 BALL BEARING ..............................................1
12 021400001 WAVE WASHER..............................................1
13 089100300089 MOTOR HOUSING w/FIELD ..........................1
14 089100300090 BRUSH ASSEMBLY........................................2
15 089100300091 BRUSH COVER (M22 X 1P)............................2
16 089100300092 * SCREW w/WASHER (M5 X 35 mm) ...............4
17 089100300093 END CAP ........................................................1
18 089100300094 SCREW (M4 X 2P X 16 mm SPECIAL) ...........2
19 029166001 * SPRING (6.2 X 0.8 X 37 mm).......................... 1
20 089100300713 MAIN HANDLE ASSEMBLY............................1
21 089100300909 UPPER GUARD WARNING LABEL ................1
22 089100300910 LOGO LABEL (UPPER GUARD) .....................1
23 020132003 SCREW (M4 X 14 mm PAN HD. SPECIAL).....4
24 303288000 MICRO SWITCH (125/250 VAC).....................1
25 089100300099 SWITCH ACTUATOR ......................................1
26 089100300100 WIRE NUT (P3) ...............................................1
27 020103033 * SCREW (M4 X 10 mm) ...................................1
28 303006000 CORD CLAMP ................................................1
29 020132000 * SCREW (M4 X 0.7 X 14 mm) ..........................2
30 330021000 BEND RELIEF .................................................1
31 089100300105 POWER CORD ...............................................1
32 089100300106 * SCREW (M4 X 0.7P X 28 mm)........................ 4
33 052002000 NEEDLE BEARING .........................................1
34 089100300109 * SCREW w/WASHER (M5 X 0.8 X 12 mm) ......2
35 020704004 SCREW...........................................................1
36 089100300712 OUTPUT SHAFT ASSEMBLY .........................1
37 089100300111 * SCREW w/WASHER (M4 X 10) ......................1

RYOBI MITER SAW – MODEL NUMBER TS1552LA
12
Figure F
3
1
5
8
7
6
4
2
1
2
3
9
10
11

RYOBI MITER SAW – MODEL NUMBER TS1552LA
13
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical
shock or electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi
Authorized Service Center. For the service center nearest you call 1-800-525-2579.
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE F)
089100300710 MOTOR HOUSING W/FIELD ASSEMBLY (INC. KEY NOS. 1-11).............................1
1 303302000 BRUSH HOLDER .....................................................................................................2
2 303002001 NUT HOLDER............................................................................................................2
3 022301001 * NYLON NUT (M5 X 0.8P) ..........................................................................................2
4 089100300072 MOTOR HOUSING ...................................................................................................1
5 089100300073 FIELD ASSEMBLY W/LEADS....................................................................................1
6 028600001 * SCREW w/WASHER (M5 X 0.8 X 65 mm PAN HD.)..................................................2
7 089100300075 BAFFLE ....................................................................................................................1
8 089100300907 LOGO ........................................................................................................................1
9 089100300908 WARNING LABEL .....................................................................................................1
10 089100300076 ARMATURE OUTPUT LEAD......................................................................................1
11 330052000 BEARING COVER .....................................................................................................1

WIRING DIAGRAM
RED LEAD
BLACK LEAD
MOTOR
SWITCH
RED LEAD
BROWN LEAD
POWER CORD
WHITE
LEAD
WHITE LEAD
BRUSHES
TERMINAL
RYOBI MITER SAW – MODEL NUMBER TS1552LA
14
