Saeco Intelia Deluxe HD8906/06 User manual

Register your product and get support at
www.saeco.com/welcome
HD8906
Type HD8906
ENGLISH
한국의
Register your product and get support at
www.saeco.com/welcome
4219.460.3412.1 HD8906 FRONT-BACK COVER_EN-KO.indd 1 07/03/16 11:52

ESP RES SO C APP UCCI NO
ESP RES SO LU NGO MIL K FR OTH
CA RAF E QUI CK CL EAN MEN U
A
R
O
M
A
S
T
R
E
N
G
T
H
S
P
E
C
I
A
L
D
R
I
N
K
S
1
2
29
30
4
13
14
15
16
28 27
17 18
21
22
20
19
23 24
26
25
3
8
9
6
5
10
11
7
12

English 5
한국의 30

English
Contents
Introduction 5
Important 6
Warning 6
Caution 6
Electromagnetic fields (EMF) 7
Machine overview (Fig. 1) 7
The display 8
First installation 8
Manual rinsing cycle 10
AquaClean filter 11
AquaClean filter installation 11
Replacing the AquaClean filter 12
Using the machine 12
Brewing coffee with beans 12
Adjusting the coffee quantity 12
Adjusting the grind setting 13
Cappuccino, baby cappuccino and milk froth 13
Brewing special drinks 14
Cleaning and maintenance 14
Weekly cleaning of the brew group 14
Lubrication 16
Milk carafe quick clean 17
Daily cleaning of the milk carafe 17
Weekly cleaning of the milk carafe 18
Monthly full milk carafe cleaning with milk circuit cleaner 19
Descaling 20
Descaling procedure 21
Interruption of the descaling cycle 22
Warning icons and error codes 22
Meaning of error codes 23
Ordering accessories Saeco 24
Guarantee and support 24
Recycling 25
Troubleshooting 25
Introduction
Congratulations on buying this Intelia/Intelia Deluxe full automatic espresso
machine! The machine is suitable for preparing espresso coffee using whole
coffee beans. You can use the milk carafe to prepare perfect cappuccino in
a quick and easy way.To fully benefit from the support that Saeco offers,
please register your product at www.saeco.com/welcome. This user manual
applies to all Intelia/Intelia Deluxe models with milk carafe.
5
English

Important
Warning
-Connect the machine to a wall socket with a voltage matching the
technical specifications of the machine.
-Connect the machine to an earthed wall socket.
-Do not let the power cord hang over the edge of a table or counter, or
touch hot surfaces.
-Never immerse the machine, mains plug or power cord in water (danger
of electrical shock).
-Do not pour liquids on the power cord connector.
-Never direct the hot water jet towards body parts: danger of burns.
-Do not touch hot surfaces. Use handles and knobs.
-Switch off the machine with the main switch located on the back and
remove the mains plug from the socket:
-If a malfunction occurs.
-If the machine will not be used for a long time.
-Before cleaning the machine.
-Pull on the plug, not on the power cord.
-Do not touch the mains plug with wet hands.
-Do not use the machine if the mains plug, the power cord or the machine
itself is damaged.
-Do not make any modifications to the machine or its power cord.
-Only have repairs carried out by a service center authorized by Philips to
avoid a hazard.
-The machine should not be used by children younger than 8 years old.
-This machine can be used by children aged from 8 years and above and
by persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the machine in a safe way and if they
understand the hazards involved.
-Cleaning and user maintenance shall not be made by children unless
they are older than 8 and supervised.
-Keep the machine and its cord out of the reach of children aged less than
8 years.
-Children should be supervised to ensure that they do not play with the
machine.
-Never insert fingers or other objects in the coffee grinder.
Caution
-This machine is intended for normal household use only. It is not
intended for use in environments such as staff kitchens of shops, offices,
farms or other work environments.
-Always put the machine on a flat and stable surface. Keep it in upright
position, also during transport.
-Do not place the machine on a hotplate or directly next to a hot oven,
heater or similar source of heat.
6English

-Only put roasted coffee beans in the bean hopper. If ground coffee,
instant coffee, raw coffee beans or any other substance is put in the
coffee bean hopper, it may cause damage to the machine.
-Let the machine cool down before inserting or removing any parts. The
heating surfaces may retain residual heat after use.
-Never fill the water tank with warm, hot or sparkling water, as this may
cause damage to the water tank and the machine.
-Never use souring pads, abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the machine. Simply use a soft cloth
dampened with water.
-Descale your machine regularly. The machine indicates when descaling is
needed. Not doing this will make your appliance stop working properly.
In this case repair is not covered under your guarantee.
-Do not keep the machine at temperatures below 0°C.Water left in the
heating system may freeze and cause damage.
-Do not leave water in the water tank when the machine is not used over
a long period of time. The water can be contaminated. Use fresh water
every time you use the machine.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
Machine overview (Fig. 1)
1 Lid of the bean hopper
2 Coffee bean hopper
3 Socket for cord
4 Water tank
5 Pre-ground coffee compartment
6 Grinder adjustment knob
7 Control panel
8 Coffee grounds container
9 Coffee dispensing spout
10 Drip tray
11 Drip tray cover
12 Drip tray full indicator
13 ESPRESSO button
14 ESPRESSO LUNGO button
15 AROMA STRENGTH button
16 CARAFE QUICK CLEAN button
17 Standby button
18 MENU button
19 SPECIAL DRINKS button
20 MILK FROTH button
21 CAPPUCCINO button
22 Cord
23 Cleaning brush (for specific types only)
24 Grease (for specific types only)
25 Pre-ground coffee measuring spoon
26 Water hardness tester
27 Coffee residues drawer
7
English

28 Brew group
29 Milk carafe
30 Hot water dispensing spout
The display
Use these buttons to navigate through the menus:
ESPRESSO
-ESPRESSO button = ESC button: press this button to return to the main
menu. The ESC button takes you back one level. You may have to press
the ESC button several times to get back to the main menu.
A
R
O
M
A
S
T
R
E
N
G
T
H
-AROMA STRENGTH button = OK button: press this button to select,
confirm or stop a function.
CAPPUCCINO
-CAPPUCCINO button = UP button: press this button to scroll up through
the display menu.
S
P
E
C
I
A
L
D
R
I
N
K
S
-SPECIAL DRINKS button = DOWN button: press this button to scroll down
through the display menu.
First installation
This machine has been tested with coffee. Although it has been carefully
cleaned, there may be some coffee residues left. We guarantee, however,
that the machine is absolutely new.
Like with most full-automatic machines, you first need to brew some coffees
to enable the machine to complete its self-adjustment and get the best
tasting coffee.
1Remove all packaging material from the machine.
2Place the machine on a table or worktop away from the tap, the sink and
heat sources.
Note: Leave at least 15 cm of free space above, behind and on both sides
of the machine.
3Slide the drip tray with drip tray cover into the machine.
4Remove the water tank.
5Fill the water tank with fresh water to the MAX level indication.
8English

6Open the lid of the bean hopper. Fill the bean hopper with coffee beans
and close the lid.
7Insert mains plug into a wall socket (1) and insert the small plug into the
socket located on the back of the machine (2).
8Place a container under the hot water and coffee dispensing spouts.
Check if the hot water dispensing spout is installed correctly.
9Press the standby button to switch on the machine.
10 Press the OK button to start the automatic circuit priming cycle.
11 The machine heats up and the display shows the temperature icon.
-The machine starts rinsing water through the coffee dispensing spout.
The display shows the rinsing icon and a progress bar.
AQUA
CL EAN
AQUACLEAN
FILTER?
12 The display shows the following icon to indicate you have to install the
AquaClean filter.
If you want to install the AquaClean filter afterwards, press the ESC
button and continue with the manual rinsing cycle. For installation, see
chapter ‘AquaClean filter’.
AQU A
CL EAN INSTALL
FI LTER
13 Press the OK button. The display shows the following icon.
14 Remove the AquaClean filter from its packaging. Shake the filter for about
5 seconds.
15 Immerse the AquaClean filter upside down in a jug with cold water and
wait until no more air bubbles come out.
9
English

16 Remove the water tank from the machine, empty it and insert the filter
vertically onto the filter connection.
17 Fill the water tank with fresh water to the MAX level indication.
18 Press the OK button.
AQUA
CL EAN
0/8
ON
OFF
19 Select ON on the display and confirm the activation by pressing the OK
button
When activation is finished, the display shows a tick to confirm activation.
AQUA
CLEAN
100%
20 The display shows the filter ready icon to indicate the AquaClean filter
has been installed correctly.
21 To rinse the filter, press the SPECIAL DRINKS button and select the HOT
WATER option and press the OK button twice. Water flows out from the
hot water dispensing spout. Discard this water.
It can take a while until water comes out of the hot water dispensing
spout. The filter needs to be fully filled and rinsed with water.
The machine is ready for use.
After installing the AquaClean filter, you do not have to perform the manual
rinsing cycle.
Manual rinsing cycle
1Place a container under the coffee dispensing spout.
2Press the AROMA STRENGTH button and select the pre-ground coffee
brewing function.
Do not add pre-ground coffee in the pre-ground coffee compartment.
3Press the ESPRESSO or ESPRESSO LUNGO button.
-The machine starts dispensing hot water.
4Wait until the machine stops dispensing water and empty the container.
5Repeat steps 1-3 twice.
6Press the SPECIAL DRINKS button. Place a container under the hot water
dispensing spout.
7Press the UP/DOWN buttons to scroll through the options of the display.
Press the OK button to select ‘hot water’.
8Press the OK button to start hot water dispensing.
10 English

-Dispense water until the display shows the no water icon.
9Fill the water tank with fresh water up to the MAX level and remove the
container.
The machine is ready for use.
AquaClean filter
The AquaClean filter is designed to reduce limescale deposits in your coffee
machine and provide filtered water to preserve the aroma and flavor of each
cup of coffee. If you use a series of 8 Aquaclean filters as indicated in this
user manual, you don't have to descale your machine for 5000 cups (with a
capacity of 100 ml).
AquaClean filter installation
Your machine has to be completely limescale-free before you start to use
the AquaClean filter. If you did not activate the filter upon first use and
brewed more than 50 cups (with 100 ml capacity), you need to descale the
machine before you activate the filter.
1Remove the AquaClean filter from its packaging. Shake the filter for about
5 seconds.
2Immerse the AquaClean filter upside down in a jug with cold water and
wait until no more air bubbles come out.
3Remove the water tank from the machine.
4Insert the AquaClean filter vertically onto the filter connection. Push the
AquaClean filter to the lowest possible point. Make sure that the filter fits
tightly and the seal is in the right position, to guarantee the best
performance.
5Fill the water tank with fresh water and slide it back into the machine.
6Press the MENU button and scroll to the AquaClean filter option. Then
press the OK button to select the AquaClean filter option.
If you are installing the filter at first time use, follow the steps in chapter
‘First installation’.
AQUA
CL EAN
0/8
ON
OFF
7Select ON on the display and confirm the activation by pressing the OK
button.
11
English

Note: The display shows a tick icon to confirm the activation.
8To rinse the filter, press the SPECIAL DRINKS button, select the HOT
WATER option and press the OK button twice. Water flows out from the
hot water dispensing spout. Discard this water.
Note: It can take a while until water comes out of the hot water
dispensing spout. The filter needs to be fully filled and rinsed with water.
9Use the sticker attached to the plastic packaging of the AquaClean filter
to write down the date of the next filter replacement (after 3 months).
Place the sticker on the water tank.
The filter and machine are now ready for use.
Replacing the AquaClean filter
Replace the filter every 3 months or at machine request.
Display icon AquaClean filter What to do
10% + icon flashes The performance of this filter is decreasing. It is
recommended to remove the old filter and place the
new filter as described in section 'AquaClean filter
installation’ to retain proper filter performance.
0% + icon flashes Remove the old filter immediately and place the new
filter as described in section ‘AquaClean filter
installation’. When you activate a new filter, the display
shows the word NEW. Press the OK button to confirm
the activation.
0% and icon disappears from display You first need to descale the machine before you can
place and activate a new filter.
After 8 filter replacements you need to descale the machine chapter
‘Descaling’, section ‘Descaling procedure’.
Using the machine
Brewing coffee with beans
1Adjust the coffee dispensing spout to suit the size of your cup.
2Press the AROMA STRENGTH button to select the desired coffee
strength from 1-5 beans.
3Press the ESPRESSO button to brew an espresso or press the ESPRESSO
LUNGO button to brew a coffee.
Adjusting the coffee quantity
1Press and hold the ESPRESSO button or ESPRESSO LUNGO button until
the display shows the word MEMO.
2When the cup contains the desired amount of coffee, press the OK
button to save the selected quantity.
12 English

Adjusting the grind setting
Note: You can only adjust the grinder settings when the machine is grinding
coffee beans.
1Open the lid of the bean hopper.
2Place a cup under the coffee dispensing spout.
3Press the ESPRESSO button.
4While the machine grinds the coffee, place the end of the measuring
spoon handle on the grinder adjustment knob in the coffee bean hopper.
Use the spoon to press and turn the knob to the left or to the right one
notch a time.
5There are 10 different grinding degree settings you can choose from. The
smaller the dot, the stronger the coffee.
-Coarse grind: lighter taste, for dark roasted coffee blends.
-Fine grind: bolder taste, for light roasted coffee blends.
6Brew 2-3 coffees to taste the difference.
Cappuccino, baby cappuccino and milk froth
Note: You can adjust the cappuccino and milk froth quantity.
1Remove the hot water dispensing spout.
2Remove the milk carafe lid.
3Fill the milk carafe with milk between the MIN and MAX level indications.
4Place back the milk carafe lid.
5Turn the dispensing spout on the milk carafe to ‘I’.
13
English

6Insert the milk carafe into the machine. Make sure the carafe is inserted
properly.
7Place a cup under the coffee and milk dispensing spouts.
8Choose your milk-based beverage.
-Press the CAPPUCCINO button to brew a cappuccino.
-Press the LATTE MACCHIATO button to brew a latte macchiato.
-Press the SPECIAL DRINKS button and select baby cappuccino to brew a
baby cappuccino.
The machine first dispenses a preset quantity of frothed milk into the cup or
glass and then dispenses a preset quantity of coffee.
Brewing special drinks
In the special drinks menu you can select hot water and baby cappuccino.
1Press the SPECIAL DRINKS button to enter the menu. The display shows
the options for special drinks.
2Press the UP/DOWN buttons to scroll through the options on the menu.
3Press the OK button to confirm the desired beverage.
4When you select HOT WATER, insert the hot water dispensing spout into
the machine and lock it into place. When you select cappuccino, milk
froth or baby cappuccino, insert the milk carafe into the machine.
Cleaning and maintenance
Weekly cleaning of the brew group
Clean the brew group once per week.
1Remove the coffee grounds container and open the service door.
2Remove the coffee residues drawer.
1
2
3To remove the brew group, press the lever and pull the brew group out of
the machine.
4Rinse the brew group with fresh water and let it air dry.
14 English

5To place the brew group back, make sure that the lever is in contact with
the base of the brewing unit.
Note: If it is not in contact with the base, push it down.
6Make sure the locking hook of the brew group is in the correct position.
To position the hook correctly, push it upwards until it is in uppermost
position.
15
English

7The hook is not correctly positioned if it is still in bottommost position.
8Slide the brew group back into the machine along the guiding rails on the
sides until it clicks into position. Then place the coffee residues drawer
back in the machine.
Monthly cleaning of the brew group with the degreasing tablet
-Perform this cleaning cycle after the machine has brewed 500 cups of
coffee or once a month.
-Use a degreasing tablet for this cleaning cycle.
Caution: Only use degreasing tablets for cleaning. They do not have a
descaling function.
1Place a container under the coffee dispensing spout.
2Press the AROMA STRENGTH button and select GROUND COFFEE.
3Put a degreasing tablet in the pre-ground coffee compartment.
4Press the OK button. The machine dispenses water from the coffee
dispensing spout.
5When the progress bar has reached the middle, set the power button to
OFF.
6Let the degreasing solution work for approximately 15 minutes.
7Set the power button to ON.
8Press the standby button.
9Wait until the machine performs an automatic rinsing cycle.
10 Perform the 'Weekly cleaning of the brew group' procedure.
11 Remove the drip tray with the coffee grounds container. Empty the drip
tray and the coffee grounds container and place them back in the
machine.
12 Press the AROMA STRENGTH button and select GROUND COFFEE.
13 Press the OK button. The machine dispenses water from the coffee
dispensing spout.
14 Repeat steps 12 and 13 twice. Discard the dispensed water.
15 To clean the drip tray, put a degreasing tablet in the drip tray and fill the
drip tray up to two-thirds of its capacity with hot water. Let the
degreasing tablet take effect for about 30 minutes. Then empty the drip
tray and rinse it thoroughly.
Lubrication
Lubricate the brew group after approximately 500 cups of coffee or once a
month.
1Apply some lubricant around the shaft in the bottom of the brewing unit.
16 English

2Apply lubricant to the rails on both sides, as shown in the illustration.
3Slide the brew group back into the machine along the guiding rails on the
sides until it clicks into position. Then place the coffee residues drawer
back in the machine.
Milk carafe quick clean
Between brewing milk varieties you can rinse the spout with hot water to
make sure every milk recipe is optimal.
1Place a cup or container under the spout to collect the water.
2Turn the milk dispensing spout to the ‘I’ position.
3Press the CARAFE QUICK CLEAN button.
-The display reminds you have to insert the milk carafe, press the OK
button to confirm.
Note: Press the ESC button if you want to interrupt the milk carafe clean.
1The machine starts rinsing water through the coffee dispensing spout.
The display shows the rinsing icon and a progress bar.
Daily cleaning of the milk carafe
It is important to clean the milk carafe every day or after you have used it, as
this preserves hygiene and ensures perfect milk froth consistency.
11
2
1Press the release buttons to remove the lid.
2Turn the milk dispensing spout up to the reference mark (indicated by a
dot).
17
English

3Lift the milk carafe dispenser to remove it from the lid and wash it with
lukewarm water. Remove all milk residues.
4Put the milk dispensing spout back onto the milk carafe lid. To insert it,
align the dot on the spout with the indication on the lid.
Weekly cleaning of the milk carafe
1Press the release buttons to remove the lid.
2Rinse the lid and the milk carafe with fresh water. Remove all milk
residues.
3Place the lid back onto the milk carafe and make sure it locks into place.
4Remove the top of the lid and fill the milk carafe with fresh water up to
the MAX level.
5Place the top of the lid back onto the milk carafe.
6Insert the milk carafe into the machine. Place a container under the milk
dispensing spout.
7Press the MILK FROTH button to select hot milk.
8The display shows the icon to indicate that the machine is dispensing
water.
9When the machine stops dispensing, remove and empty the milk carafe.
The display will ask you to perform a quick clean cycle, you do not need
to perform this cycle during the weekly cleaning of the milk carafe.
10 Press the release buttons to remove the lid of the milk carafe.
11 Turn the milk dispensing spout to the dot indicated on the lid.
12 Lift the milk dispensing spout off the lid.
13 Remove the ring from the milk carafe dispensing spout.
14 Press the button indicated with the arrow to unlock the cover of the milk
dispensing spout.
18 English

15 To remove the cover, press the sides of the dispensing spout lightly and
pull the cover downwards off the dispensing spout.
16 Pull the milk frothing unit upwards.
17 Pull the fitting outwards from the milk frothing device.
18 Remove the suction tube.
19 Pull the fitting outwards and separate it from the remaining part.
20 Clean all parts with lukewarm water.
21 Reassemble all parts following in reverse order.
Monthly full milk carafe cleaning with milk circuit cleaner
Only use SAECO milk circuit cleaner CA6705 for this cleaning cycle.
19
English
