Power On and Test
1. Turn on accessory power to the vehicle.
2. Put the vehicle in reverse gear.
During normal operation, the monitor only turns on
when the vehicle is shifted into reverse.
If the monitor fails to turn on when power is applied,
confirm power connections. Disconnect and firmly
reconnect the LCD Monitor cables.
3. For installations with video recorder integration,
configure the recorder as shown in the RVS Recorder
Configuration Guide (700-1103).
4. Adjust the camera view so that the bumper of the vehicle
is just visible across the bottom edge of the monitor, as
shown.
5. Refer to the camera installation guide for details on
closing and fastening the camera once it has been aimed.
6. Turn off accessory power to the vehicle.
LCD Monitor Configuration
For information on custom monitor settings, see the Rear
Vision Monitor Quick Install Guide (700-1107)
Related Documents
For full product details, and access to our Document Library,
please visit the Seon Community Web site:
https://community.safefleet.net
If you do not have access credentials, please contact
Customer Service.
Customer Service
•Service: 1.844.899.7366
•General Enquiries: 1.877.630.7366
•Email: [e-mail]
If your RVS device is to be returned, please contact
Customer Service, and provide the model and/or serial
number of your unit. Ask for a Return Merchandise
Authorization (RMA) number. An RMA number allows the
Service Technicians to better track your product when it
comes in for service. Please show the RMA number on the
outside of the package. ANY RETURNED PRODUCT
WITHOUT AN RMA NUMBER MAY BE REFUSED.
Warranty
For full warranty information, please visit:
http://www.seon.com/documents/Seon-Warranty.pdf
Rear Vision System Installation Guide
for Standalone and Video Recorder Integration
Introduction
The Rear Vision System (RVS) for vehicles enables the driver to see the camera output on a dash-mount monitor
whenever the reverse signal is triggered. The video feed can be mirrored with monitor settings.
This document covers physical installation of RVS hardware components. The RVS can be installed in two ways:
•Standalone: the RVS is powered from the vehicle, and displays on the dashboard monitor without passing
through the recorder; RVS video is NOT recorded.
•Recorder Integration: Using a recorder camera socket, RVS camera video runs through the video recorder
before appearing on the monitor. RVS video, events, and alarms are recorded. For details on setting up a
recorder for RVS integration, see the RVS Recorder Configuration Guide (700-1103).
Note: High definition camera views cannot be displayed on the monitor.
When installed, RVS typically operates as follows:
•The monitor is usually OFF (dark)
The monitor only turns ON when the vehicle is put into reverse gear (REVERSE signal is applied)
Important: When the vehicle ignition is turned on, the recorder may require approximately one minute to boot
up before video from the rear view camera appears on the dashboard monitor.
System Installation Components
Rear view camera with corresponding mounting hardware. Option A: HExHD or HEHDxx camera harness
Option B: 75’ Camera extension cable (060-1094)
Camera cable adaptor for retrofit (060-1095)
7” Monitor (080-1059), including sunshade (665-1020),
bracket (660-1073), and hardware kit (020-1042)
Rear Vision Monitor Quick Install Guide (700-1107)
20’ Video extension cable (HEHD20)*
Monitor power and connector harness (060-1096)
RCA cable adaptor (060-1102)
Expansion harness for TH4/DH4/TH6/TH8/NH16 HX/NX
(060-1059) *
Expansion harness for TL-HD (060-1014) *
Monitor diode kit (020-1045)
*Components not required for standalone installations

Monitor and Camera Connections (Standalone)
Use the following image and steps to connect the monitor and camera:
Once the camera is installed according to its installation documentation:
1. Connect the 2x3 Microfit connector on cable Ato the BACK AV3 Microfit socket on cable B.
2. Install the monitor bracket and mount the monitor on the dashboard.
For details, see the Rear Vision Monitor Quick Install Guide (700-1107).
3. Connect the monitor output from cable Bto the monitor input cable.
Verify that the arrows on the connector ends are aligned.
4. Connect the BACK TRIGGER AV3 (blue) fly wire from cable Bto the striped end of the supplied diode.
5. Connect the unmarked end of the supplied diode to the reverse signal input (active high trigger).
6. Connect the GND (black) fly wire from cable Bto battery negative.
7. Connect the POWER (red) fused fly wire from cable Bto 12V ignition (switched source) power.
8. (Optional) Attach the M12 socket on cable adaptor Cto the LEFT AV1 input on cable B.
The RCA jacks on cable Caccept composite video input from an accessory device.
To use the standard definition video output (CVBS) from an inView 360 HD system, connect the adapter cable
060-1199 to an RCA input on cable C. For more information, visit the Seon Community
(https://community.safefleet.net).
9. See “Power On and Test”.
Monitor and Camera Connections (Recorder Integration)
Use the following image and steps to connect the monitor, camera, and recorder:
1. Once the camera is installed according to its installation documentation, connect cable Ato a camera port on the
back panel of the recorder.
Take note of the camera port number*- you’ll need it for the Recorder Configuration procedure (see the
RVS Recorder Configuration Guide (700-1103).
*for TL-HD recorders, note the channel number
2. Connect the 2x4 Microfit*connector on cable Bto the EXPANSION** socket on the recorder’s rear panel.
* for TL-HD recorders, use the 1x8 Sherlock connector
** for all other supported recorders, connect to the EXPANSION 1socket
3. Connect the 2x3 Microfit connector on cable Bto the Microfit socket on cable C.
4. Connect the 2x3 Microfit connector on cable Cto the BACK AV3 Microfit socket on cable D.
5. Install the monitor bracket and mount the monitor on the dashboard.
For details, see the Rear Vision Monitor Quick Install Guide (700-1107).
6. Connect the monitor output from cable Dto the monitor input cable.
Verify that the arrows on the connector ends are aligned.
7. Connect the BACK TRIGGER AV3 (blue) fly wire from cable Dto the striped end of the supplied diode.
8. Connect the unmarked end of the supplied diode to the reverse signal input (active high trigger).
9. Connect the GND (black) fly wire from cable Dto battery negative.
10. Connect the POWER (red) fused fly wire from cable Dto12V ignition (switched source) power.
11. (Optional) Attach the M12 socket on cable adaptor Eto the LEFT AV1 input on cable D.
The RCA jacks on cable Eaccept composite video input from an accessory device.
To use the standard definition video output (CVBS) from an inView 360 HD system, connect the adapter cable
060-1199 to an RCA input on cable E. For more information, visit the Seon Community
(https://community.safefleet.net).
12. See “Power On and Test”.
Monitor trigger inputs
expect an Active H/L signal.
Voltage references:
Active H: DC 3.3V - 36V
Active L: < DC 3.3V
Monitor trigger inputs
expect an Active H/L
signal. Voltage
references:
Active H: DC 3.3V - 36V
Active L: < DC 3.3V
