Safety 1st Grow and Go Extend N Ride User manual

You can also:
Send Us a Text: 1-812-203-4747
(US and Canada Only. Carrier Fees May Apply)
Find Us Online: www.safety1st.com
Email Us: [email protected]
Give Us a Call: 1-800-544-1108
(Toll Free, US and Canada Only)
Grow and Go Extend N Ride, LX
All-in-One Convertible Car Seat
Your model may look dierent than one shown on cover.
Read all instructions BEFORE USING this car seat.
KEEP INSTRUCTIONS FOR FUTURE USE.
Failure to follow the warnings on the labels and in
the instruction manual can result in serious injury or
death to your child.
4358-8174 10.8.21
• Buckle Assembly
• Chest Clip
• Seat Pad Set
• Removable Cup Holder(s)
• Removable Snack Lid
• Removable Snack Tray
• Lower Anchor Belt
• Top Tether
• Locking Clip
• Instructions
For parts availability and
questions, call, text, or chat.
If requested color is not
available, similar color will
be substituted.
Applicable tax and shipping
& handling will also be
added.
Replacement Parts List
(on select models)

Your child’s safety is
worth the time it will
take to read and follow
these instructions.
Ready? Let’s go!
Pages 1-4 will introduce
you to the parts of the car
seat.
The Back Cover of this
Manual has our
contact information.
If at any point you would
like assistance, please feel
free to reach out to us.
Welcome to the
Safety 1st Family!
Thank you for
choosing this car
seat, also known as
a child restraint!
To help you get
started using your
child’s new car seat,
here are the 4 main
tasks you’ll need to
complete.
Measure
Your Child
Install Car Seat
into Your Vehicle
Adjust Car Seat to
Fit Your Child
Secure Your Child
in Car Seat

Contents
1 Getting Started
1 Parts of Car Seat
3 Accessory Use
5 Choosing Car Seat Mode
7Rear-Facing Section
9 Rear-Facing Child Fit
11 Rear-Facing Vehicle Install
18 Forward-Facing Section
20 Forward-Facing Child Fit
22 Forward-Facing Vehicle Install
50 Wash & Care
50 Removing Seat Pad Set
52 Cleaning Parts of Car Seat &
Installing Seat Pad Set
53 Vehicle Belt & LATCH Information
53 LATCH: Lower Anchor Belt
55 Vehicle Belts
59 Top Tether
29 Securing Child in Car Seat
32 Booster Seat Section
34 Storing Harness System
37 Booster Seat Use in Vehicle
40 Booster Seat Child Fit
41 Making Adjustments to Car Seat
41 Changing Headrest/Harness Height
42 Changing Buckle Position
44 Harness System Adjustments
for Smaller Infants
48 Reclining Car Seat
49 Using Footrest
60 Safety Information
60 Child Restraint Use
61 Vehicle Seating Position
62 Installation in Vehicle
63 Replacement & Expiration
64 Registration & Safety Notices
65 Aircraft Information
66 Warranty
©2021 Dorel Juvenile Group, Inc. Safety 1stTM and the Safety 1st logo and design are trademarks of Dorel Juvenile Group, Inc. [phone] www.safety1st.com.
Styles and colors may vary. Los estilos y los colores pueden variar. Made in USA from American and imported parts (including seat pad). Hecho en EE.UU. a partir de
piezas americanas e importadas (incluyendo la almohadilla del asiento). Distributed by (distribuido por) Dorel Juvenile Group, Inc., 2525 State St., Columbus, IN 47201-
7494. Dorel Juvenile Canada, 2233 Argentia Road, Suite 110, Mississauga, ON L5N 2X7. Importado y Distribuido en Chile por: Comercial e Industrial Silfa S.A. - San
Ignacio 0201 / Parque Industrial Portezuelo Quilicura, Santiago Chile. Fono (562) 2339 9000. En Perú por: Comexa S.A. - Los Libertadores 455 – San Isidro, Lima – Perú.
Fono (511) 4469014. En Centro América, Caribe y Ecuador por: Best Brands Group S.A. – Av. Balboa, Bay Mall Plaza, Planta Baja, local 9, Panamá. -
Fono: [phone]. En Colombia por: Baby Universe S.A.S. - Vía 40 No. 77-29, Barranquilla,Colombia - Fono: [phone] Importador: DJGM,
S.A. DE C.V. Gabriel Mancera No. 1041 Col. Del Valle, Benito Juárez C.P. 03100 México, Ciudad de México R.F.C. DJG140305GN9 Tel. [phone]

Adjustable Headrest
Easy Out Harness Covers*
Removable Cup Holders
& 1 Snack Lid*
Harness Release Lever
(through opening in pad)
Harness Adjustment Strap
LATCH: Lower
Anchor Belt
(bag may be in the
Forward-Facing
Belt Path)
Head Pillow*
Body Pillow*
Harness System
*See pages 3-4 for Accessory Use. *See pages 3-4 for Accessory Use.
Buckle Cover*
Lower Shoulder
Harness Slots for
Smaller Infants
Forward-
Facing
Belt Path
Rear-Facing
Level Line
Base
Rear-
Facing
Belt Path
LATCH: Lower Anchor
Belt Storage Attachments
Tether Strap
Tether Storage Attachment
Instruction Manual Storage
Harness Strap Splitter Plate
Tether Strap Adjuster
Recline Handle
Adjustable Footrest
Headrest/Harness
Adjustment Handle
1 2
Parts of Car Seat
Chest Clip
Buckle
Harness Straps
Upper Shoulder
Harness Slots
Your model may look dierent than one shown.

Head Pillow & Body Pillow
Only For Use in
Rear-Facing Mode
The head and body pillows
must be used together.
To remove head pillow, pull
it out from behind the body
pillow.
To remove body pillow, undo
the buckle and pull it through
the slot in the pillow. Slide the
pillow out from behind the
harness straps.
If using the lower shoulder
harness slots for smaller
infants, see page 45-47.
3 4
Accessory Use
Removable Cup Holder(s),
Snack Lid, & Snack Tray
(on select models)
For Use in All Modes
The cup holder(s), snack lid,
and snack tray are top-rack
dishwasher safe.
To remove cup holder, twist the
cup holder counterclockwise. Pull
it out of the slot in the car seat.
To remove snack lid, pull it off
the top of the cup holder.
To remove snack tray, locate
the 2 tabs underneath of the
snack tray. Squeeze them
together and lift the snack tray
out of the slot in the car seat.
Buckle Cover
For Use in Rear-Facing Mode or
Forward-Facing Mode
To remove, undo the buckle and pull
the buckle cover off the buckle.
Easy Out Harness Covers
(on select models)
For Use in Rear-Facing Mode or
Forward-Facing Mode
If the harness covers will not allow
proper positioning of the chest clip or
interfere with getting a tight enough
harness fit for a smaller baby, remove
them and DO NOT use.
Store them until your child is large
enough to use the harness covers while
maintaining a properly fitting harness.
Front
Back
Snack Tray
Cup Holder
To remove, undo the fasteners on
the headrest pad. Pull the fastening
strips on the covers apart. Slide
the covers out from behind the
headrest pad.
To install, undo the fasteners on
the headrest pad. With the back of
the harness covers facing you, slide
them behind the headrest pad. Fold
harness covers down towards you.
Place the harness straps into the
covers. Fasten the harness covers.

Your child’s height, weight, and age determine how the car
seat should be placed in the vehicle.
Children vary widely in body size, shape, and temperament—
please consult your doctor before switching between
any modes within the limits and fit requirements of the
car seat.
State Laws
Please be certain to follow your state’s laws regarding car
seat use.
American Academy of Pediatrics
Recommendations
Infants and Toddlers
Should ride in a rear-facing car seat as long as possible, until
they reach the highest weight or height allowed by their car seat.
Toddlers and Preschoolers
Once they are facing forward, children should use a forward-
facing car seat with a harness for as long as possible, until they
reach the height and weight limits for their car seats.
School-Aged Children
Once they have outgrown their forward facing car seat, children
should use a belt-positioning booster seat until the vehicle’s
lap and shoulder seat belt fits properly. This is often when they
have reached at least 4 feet 9 inches in height and are 8 to 12
years old.
Older Children
All children younger than 13 years should be restrained in the
rear seats of vehicles for optimal protection.
Measure your child’s weight and height
(DO NOT guess) before choosing this car
seat’s mode.
Booster Seat Mode
40-100 lb (18.1-45.4 kg) and
43-52 in. (110.1-132.1 cm)
Booster Seat Section
PAGE 32
Storing Harness System
PAGE 34
Booster Seat Use in Vehicle
PAGE 37
Booster Seat Child Fit
PAGE 40
Rear-Facing Mode
5-40 lb (2.3-18 kg) and
19-40 in. (48-101.6 cm)
Rear-Facing Section
PAGE 7
Rear-Facing Child Fit
PAGE 9
Rear-Facing Vehicle Install
PAGE 11
Forward-Facing Mode
22-65 lb (10.1-29 kg) and
29-49 in. (73.6-125 cm) and
at least 1 year old
Forward-Facing Section
PAGE 18
Forward-Facing Child Fit
PAGE 20
Forward-Facing Vehicle Install
PAGE 22
Choosing Car Seat Mode
5 6
WARNING:

In this car seat, your child can remain Rear-Facing
until they outgrow any one of the following:
• Weight Limit: 40 lb (18 kg); OR
• Height Limit: 40 in. (101.6 cm); OR
• Rear-Facing Child Fit requirements, see page 9.
Before installing the car seat in your vehicle, check your
child’s fit in the car seat.
This way you won’t have to redo the vehicle installation to
make adjustments to the car seat.
Rear-Facing Child Fit: Page 9
Rear-Facing Vehicle Install: Page 11
NEVER install a rear-
facing child restraint
in the front seat of a
vehicle equipped with
an active frontal airbag.
DO NOT use the tether for rear-
facing mode. Secure the tether strap
hook to its storage attachment.
DO NOT use the lower anchor belt
along with the vehicle lap or lap/
shoulder belt.
DO NOT fasten multiple lower
anchor hooks on the same lower
anchor bar in the vehicle.
Check the vehicle belt or the lower
anchor belt before each use. Use
ONLY if the belt can be tightened
properly and locked securely in
place.
Even when unoccupied, this child
restraint MUST be firmly secured
to the vehicle with the lower anchor
belt or with the vehicle seat belt.
This child restraint MUST ALWAYS
face the rear of the vehicle until
the child is at least 1 year old and
weighs 22 lb (10 kg).
Rear-Facing Section
7 8
5-40 lb (2.3-18 kg) and 19-40 in. (48-101.6 cm)
Children under 1 year of age MUST ride Rear-Facing.
WARNING:

1
2
Check Harness
Strap Position
The harness strap MUST
be at or slightly below the
shoulders; never above.
Check Buckle Position
• Use the slot closest to your child.
• The buckle should not be
underneath or behind your child.
Do not use 3rd slot in Rear-Facing
Mode.
Check Head Position
The top of your child’s
head must be at least
1 in. (2.5 cm) below
the top of the car
seat’s headrest.
Undo Chest Clip
& Buckle
Place Child in
Car Seat
Fully Loosen
Harness Straps
Push down on the harness
release lever (through the
opening in the pad) while
pulling out on the harness
straps as shown.
1 2 3 4 5 6
Rear-Facing Child Fit
9 10
To change the harness
strap height, see page 41.
To change the buckle
position, see page 42.
To learn how to check
harness tightness, see
pages 29-30.
If you cannot achieve a
snug harness fit for your
child, see pages 44-47.
Buckle
Strap
Buckle

Place Car Seat Rear-
Facing in Back Seat
The car seat base must be
flat on the vehicle seat.
Rotate Footrest
Out of Way For Now
You will make adjustments to the
footrest AFTER the car seat is
installed.
For more information about
using the footrest, see page 49.
Recline Car Seat &
Check Rear-Facing
Level Line
Before installing the car seat in your
vehicle, check to see if you need to
adjust the buckle position for your
child. See page 9 for child fit.
Once the car seat is installed, you
will not be able to adjust the buckle
position.
Review Vehicle Owner’s Manual
Determine what kind of vehicle
belts your car has and how to use
them to lock a car seat in place OR
where LATCH: lower anchor seating
positions are located in your vehicle.
There are 2 different methods for install.
Use only one:
Vehicle Belt
DO NOT use both the LATCH: lower anchor belt and vehicle belt
at the same time to install the car seat.
LATCH: Lower Anchor Belt
1 2 3
Rear-Facing Vehicle Install
11 12
continued on next page
For children who
cannot sit up
unassisted, the Rear-
Facing Level Line on
the car seat must be
parallel with the ground
using either Position
3 or 2.
For children who can
sit up unassisted,
you may make the car
seat more upright in
Position 2.
OR
Recline handle is at
front of car seat.
continued on next page
WARNING:

Locate Rear-Facing Belt Path and
Route Vehicle Belt or
Lower Anchor Belt Through It
For the LATCH belt: You may need to fully lengthen
the belt before routing it into the belt path. Squeeze the
adjuster button and pull the belt out as shown.
Vehicle Belt or Lower
Anchor Belt Goes:
• under the car seat pad; AND
• across the car seat; AND
• in front of the buckle; AND
• out the other Rear-Facing
Belt Path opening.
Do not twist belt.
Buckle Vehicle Belt
If your car has a switchable
retractor, use it to lock the
vehicle belt. Review page 57
of this manual or your vehicle
owner’s manual.
Attach Lower
Anchor Belt Hooks
to Vehicle’s Lower
Anchors
continued on next page
13 14
Finished Lower
Anchor Belt
Routing
The adjuster can be
on either side of the
car seat.
Tighten Belt
Place your hand in the car seat and firmly push the car seat down
and back towards the vehicle seat. Pull the belt towards you and
parallel (in line) with the belt path as shown.
For the LATCH belt or Lap Only Vehicle Belt: it may be easier to
tighten if you route the free end of the belt back into the Rear-
Facing Belt Path, reach into the Rear-Facing Belt Path, and pull
the free end of the belt towards you.
4
OR
5 6 7
OR
Adjuster

Recheck Rear-
Facing Level Line
Redo the installation
if the car seat is not
reclined correctly for
your child.
Check Belt Tightness
Hold the Rear-Facing Belt
Path with your non-dominant
hand. Push and pull the car
seat from side to side.
It should not move more than
1 in. (2.5 cm).
Secure Child in
Car Seat
See page 29-31.
15 16
Only if necessary, you
may place a tightly
rolled towel(s) or foam
pool noodle(s) under
the front of the car seat
base to help make the
Rear-Facing Level
Line parallel with the
ground.
Check often to make
sure padding is still in
place and the belt is
tight.
If the car seat
moves more than 1 in.
(2.5 cm), you can try:
• Pulling the belt
tighter; OR
• Reinstalling the car
seat; OR
• Changing to a
different seating
location; OR
• Switching to a
different install
method (LATCH or
vehicle belt).
continued on next page
Adjust Footrest
Use one of the 3 Rear-Facing footrest positions to put
the footrest as flush against the vehicle seat as possible.
The footrest does not need to touch the back of the
vehicle seat; there can be a small gap.
Rear-Facing Mode
Footrest Use
For more information
about using the
footrest, see page 49.
8 9 10 11
1A
1B
1C

FINISHED!
17 18
Lap Belt
Lap/Shoulder Belt
LATCH: Lower
Anchor Belt
Vehicle Belt Install: Is the vehicle belt locked? See step 6.
LATCH: Lower Anchor Belt Install: Are the hooks securely
attached to the vehicle’s lower anchors? See step 6.
Is the belt tightened enough so that the car seat does not
move more than 1 in (2.5 cm) from side to side? Check the
tightness of the install often to make sure it has not loosened.
See steps 7 and 8.
If your child cannot sit up unassisted, is the Rear-Facing
Level Line parallel with the ground? See steps 3 and 11.
Is the footrest in either position 1A, 1B, or 1C? See step 9.
Forward-Facing Section
continued on next page
In this car seat, your child can remain harnessed
Forward-Facing until they outgrow any one of the
following:
• Weight Limit: 65 lb (29 kg); OR
• Height Limit: 49 in. (125 cm); OR
• Forward-Facing Child Fit requirements, see page 20
Before installing the car seat in your vehicle, check your
child’s fit in the car seat.
This way you won’t have to redo the vehicle installation to
make adjustments to the car seat.
Forward-Facing Child Fit: Page 20
Forward-Facing Vehicle Install: Page 22
22-65 lb (10.1-29 kg) and 29-49 in. (73.6-125 cm) and at least 1 year old
Children MUST be at least 1 year of age to ride Forward-Facing.

19 20
DO NOT use the lower anchors of the child
restraint anchorage system (LATCH system) to
attach this child restraint when restraining a
child weighing more than 40 lbs (18 kg).
The vehicle belt MUST be used for installation
if your child weighs more than 40 lb (18 kg).
You MUST ALWAYS attach, adjust, and secure
the tether (top anchorage) strap when installing
the car seat in the Forward-Facing Mode with
internal harness.
DO NOT use the lower anchor belt along with
the vehicle lap or lap/shoulder belt.
Check the vehicle belt or the lower anchor belt
before each use.
Use ONLY if the belt can be tightened properly
and locked securely in place.
DO NOT fasten multiple lower anchor hooks on
the same lower anchor bar in the vehicle.
Even when unoccupied, this child restraint
MUST be firmly secured to the vehicle with the
lower anchor belt or with the vehicle seat belt.
In this child restraint your child MUST be at
least 1 year old and weigh 22 lb (10 kg) before
they sit forward-facing.
Forward-Facing Child Fit
Head Position
The tops of your child’s ears
MUST be below the top of
the car seat’s headrest.
Undo Chest Clip
& Buckle
Place Child in
Car Seat
Fully Loosen
Harness Straps
Push down on the harness
release lever (through the
opening in the pad) while
pulling out on the harness
straps as shown.
1 2 3 4
continued on next page
WARNING:

21 22
Harness Strap
Position
The harness strap MUST
be at or slightly above the
shoulders; never below.
Buckle Position
• Use the slot closest to your child.
• The buckle should not be
underneath or behind your child.
The buckle can be used in any
buckle slot.
To change the harness
strap height, see page 41.
To change the buckle
position, see page 42.
To learn how to check
harness tightness, see
pages 29-30.
If you cannot achieve a
snug harness fit for your
child, see pages 44-47.
Forward-Facing Vehicle Install
Before installing the car seat in your
vehicle, check to see if you need to
adjust the buckle position for your
child. See page 20 for child fit.
Once the car seat is installed, you
will not be able to adjust the buckle
position.
Review Vehicle Owner’s Manual
Determine what kind of vehicle
belts your car has and how to use
them to lock a car seat in place OR
where LATCH: lower anchor seating
positions are located in your vehicle.
There are 2 different methods for install.
Use only one:
Vehicle Belt
for children up to 65 lb (29 kg)
OR
DO NOT use both the LATCH: lower anchor belt and vehicle belt
at the same time to install the car seat.
You MUST ALWAYS attach, adjust, and secure the tether (top
anchorage) strap when installing the car seat in the Forward-
Facing Mode with internal harness.
LATCH: Lower Anchor Belt
for children up to 40 lb (18 kg)
5 6
1
2
3
continued on next page
Buckle
Strap
Buckle
WARNING:

continued on next page
23 24
Put Car Seat into
Position 1 & Place
Car Seat Forward-
Facing in Back Seat
The vehicle seat back must
be upright.
Locate Vehicle Top
Tether Anchors
Review your vehicle owner’s
manual for top tether
anchor locations and how
to route the tether strap
when there are vehicle
headrests.
1 2 3 4 5
Lift Tether Adjuster to
Loosen Tether Strap
Loosely Attach
Tether Hook to
Vehicle’s Top
Tether Anchor
Locate Forward-Facing Belt Path and
Route Vehicle Belt or Lower Anchor Belt Through It
For the LATCH belt: You may need to fully lengthen the belt
before routing it into the belt path. Squeeze the adjuster button
and pull the belt out as shown.
Only use semi-
reclined Position 2 if
necessary to install the
car seat flush against
the vehicle seat back.
If your vehicle has a
headrest that interferes
with a flush car seat
fit, check your vehicle
owner’s manual to see
if it can be removed,
adjusted, or if there are
other possible seating
locations for you to
install.
Recline handle is at
front of car seat.
OR

25 26
Vehicle Belt or Lower
Anchor Belt Goes:
• under the car seat pad; AND
• across the car seat; AND
• out the other Forward-Facing
Belt Path opening.
Do not twist belt.
Buckle Vehicle Belt
If your car has a switchable
retractor, use it to lock the
vehicle belt. Review page 57
of this manual or your vehicle
owner’s manual.
Attach Lower
Anchor Belt Hooks
to Vehicle’s Lower
Anchors
Tighten Belt
Place your hand in the car seat and firmly push the car seat down and back
towards the vehicle seat. Pull the belt towards you and parallel (in line) with the
belt path as shown.
For the LATCH belt or Lap Only Vehicle Belt: it may be easier to tighten if you
route the free end of the belt back into the Forward-Facing Belt Path, reach into
the Forward-Facing Belt Path, and pull the free end of the belt towards you.
Tighten Tether
Push firmly on the back of
the car seat and pull the free
end of the tether strap to
remove all of the slack.
6 7 8 9
Finished Lower
Anchor Belt
Routing
The adjuster can be
on either side of the
car seat.
Adjuster
OR
continued on next page

27 28
Check Belt Tightness
Hold the Forward-Facing
Belt Path with your non-
dominant hand. Push and pull
from side to side.
It should not move more than
1 in. (2.5 cm).
Adjust Footrest
Use the Forward-Facing footrest
arm and footrest positions that
best fits your child. You may also
place the footrest into the storage
position. Your child’s knees MUST
NOT pass the top of the cup
holders and/or snack tray.
If the car seat
moves more than 1 in.
(2.5 cm), you can try:
• Pulling the belt
tighter; OR
• Reinstalling the car
seat; OR
• Changing to a
different seating
location; OR
• Switching to a
different install
method (LATCH or
vehicle belt).
FINISHED!
Lap Belt + Tether
for children up to 65 lb (29 kg)
Lap/Shoulder Belt + Tether
for children up to 65 lb (29 kg)
LATCH: Lower Anchor Belt +
Tether
for children up to 40 lb (18 kg)
Vehicle Belt Install: Is the vehicle belt locked? See
step 7.
LATCH: Lower Anchor Belt Install: Are the hooks
securely attached to the vehicle’s lower anchors?
See step 7.
Is the belt tightened enough so the car seat does
not move more than 1 in (2.5 cm) from side to side?
Check the tightness of the install often to make sure it
has not loosened. See steps 8 and 10.
Has the tether been installed and tightened? See
steps 4 and 9.
Is the footrest in a position that best fits your child?
See step 11.
Forward-Facing
Mode Footrest Use
For more information
about using the
footrest, see page 49.
10 11
1D 1E
2 or 3
& any footrest position
that best fits your child.
Storage

29 30
Securing Child in Car Seat
Place Child in Car Seat
Your child’s bottom and back
should be flat against the car
seat.
Buckle Harness
Pull the harness straps
up to make sure buckle is
locked.
Fasten Chest Clip
Insert right half of the chest
clip into the left half and
snap together.
Tighten Harness
Pull the harness adjustment
strap straight out to snugly
tighten the harness.
Position Chest Clip
Slide chest clip up the
harness straps and position
it at mid-chest (even with
armpits) and away from
your child’s neck.
Unfasten harness covers.
Try to pinch the harness
at the shoulders vertically
between index finger and
thumb as shown.
If your fingers slip off, the
harness is tight enough.
If you can pinch the
harness strap, tighten more.
Fasten harness covers.
1 2 3 4 5 6
A snug strap should
not allow any slack.
It lies in a relatively
straight line without
sagging.
It does not press on
the child’s flesh or
push the child’s body
into an unnatural
position.
continued on next page
Check Harness Tightness

31 32
Booster Seat Section
Failure to fasten and tighten the harness
system correctly may allow the child to be
ejected from the child restraint in a crash
or sudden stop causing serious injury or
death.
DO NOT mistake comfort for safety. The
harness system must be snugly adjusted.
DO NOT put snowsuits or
bulky garments on your
child when placing them
in the child restraint.
Bulky clothing can
prevent the harness
straps from being
tightened properly.
FINISHED!
Your child is now secured in the car seat.
Check your child’s fit often and make any
needed adjustments to the car seat as
they grow.
continued on next page
To Remove Child from Car Seat:
1. Loosen Harness Strap
2. Unbuckle Harness
3. Release Chest Clip
4. Remove Child
Troubleshooting
1. If the buckle or harness
release lever sticks: DO NOT
lubricate. Check for dropped
food, sticky spilled drinks, dirt,
leaves, etc.
Clean with warm water and/or
remove the object with tweezers.
If you cannot get the harness to
adjust and remain tight with the
buckle securely locked, do not
use this car seat.
2. If your harness twists:
Straighten the harness each time
you put your child in the car seat.
Lock the buckle and tighten the
harness so it will be ready for next
use.
In this car seat, your child can remain in a Booster
Seat until they outgrow any one of the following:
• Weight Limit: 100 lb (45.4 kg); OR
• Height Limit: 52 in. (132.1 cm); OR
• Booster Seat Child Fit requirements, see page 40
You MUST store the harness system and remove the
accessories (except the cup holders and/or snack
tray) when using the Booster Seat Mode. To remove
accessories, see pages 3-4.
Storing Harness System: Page 34
Booster Seat Use in Vehicle: Page 37
Booster Seat Child Fit: Page 40
40-100 lb (18.1-45.4 kg) and 43-52 in. (110.1-132.1 cm)
WARNING:

Fully Loosen
Harness Straps
Undo Buckle Recline Car Seat
Reach under the car seat.
Rotate the buckle’s metal
retainer and push it up
through the car seat.
Pull Buckle & Buckle
Cover Out of Car Seat
Store the buckle and buckle
cover in a safe place for
future use.
1 2 3 4
Storing Harness System
33 34
DO NOT use the harness system when using
as a booster seat.
DO NOT use LATCH when using as a booster
seat. Secure the lower anchor belt and the
tether strap to their storage attachments.
Use ONLY the vehicle’s lap and shoulder
belt system when restraining the child in this
booster seat.
DO NOT use only the lap belt
when using this seat as a
booster seat. The shoulder
belt must always be adjusted
snugly across the child’s chest.
NEVER place shoulder belt under the child’s
arms or behind their back.
DO NOT use this booster seat if the tops of
your child’s ears are above the top of the
booster seat’s headrest.
continued on next page
WARNING:
