Safran RX-1 User manual

© Safran Data Systems –IMP000074 e14r1
RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev
08
Date: 21/06/2021
Customer Ref.: -
Written by :
Tangi Le Bournault
Checked by :
Grégory Blanc
Approved by :
Christophe Delacoudre
Customer Service
Product Manager
Quality Insurance
Date & Signature: 09/07/2021
Date & Signature: 12/07/2021
Date & Signature: 13/07/2021
Total number of page(s): 139
REVISIONS
Is.Rev
Date
Description
Page(s) or chapter(s)
changed
Writer
1.0
Creation of the document
All
1.1
05/2017
Update with prototype / serial version
JGP
1.2
11/2017
Update pictures, options, tracking menu,…
JGP,TLT
1.3
07/2018
Update Test Generator, BER Tester, STC Demod
JGP
1.4
12/2018
Description of the independent channel mode,
allowed starting at software version E3R0
GBC
05
06/2019
Update to be aligned with major release E5R0 and
internal PLM tool
TLT
06
06/2020
Chapter ordering and reference to a separate
document for graphical user interface.
All
TLT
07
03/2021
RX-1 Upgrade, Display Configuration Sub-Menu
§4.6.3, §5.3.5
Christophe Foret
08
21/06/21
Safety information upgrade, Alarms & Minor changes
Page 8,§10
TLT
Safran Data Systems Inc.
3005 Business Park Drive, Norcross, GA 30071 - USA . Tel: [phone] - Fax: [phone]

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 2
CAUTION
LEGEND
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
The lightning flash with an arrowhead symbol within an equilateral triangle is intended
to alert the user to the presence of uninsulated ‘dangerous voltage’ within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 3
IMPORTANT SAFETY INSTRUCTION
This product is designed and manufactured to meet strict quality and safety standards (conformity to
EN 60950:2002 standard: Safety of information technology equipment.
However, you should be aware of the following installation and operation precautions:
Take heed of warning and instructions.
You should read all the safety and operating instructions before operating this
apparatus. Retain this handbook for future reference and adhere to all warnings in the
handbook or on the apparatus.
Children safety.
This equipment is not suitable for use in places where children are likely to be present.
Water and moisture.
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture.
The presence of electricity near water can be dangerous. Do not use the apparatus
near water.
Object or liquid entry.
Take care that objects do not fall and liquids are not spilled into the product chassis
through any openings.
Installation.
Ensure that the product chassis ventilation is not impeded.
Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Only use attachments and accessories specified by the manufacturer.
This unit should be used in a 19” rack mount cabinet only.

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 4
Cleaning.
Unplug the unit before cleaning.
Clean only with dry cloth.
THIS PRODUCT SHOULD NORMALLY ONLY REQUIRE A WIPE WITH A SOFT, DAMP, LINT-FREE CLOTH.
DO NOT USE PAINT THINNER OR OTHER CHEMICAL SOLVENTS FOR CLEANING.
Opening of the product chassis.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE; THE PRODUCT CHASSIS SHOULD ONLY BE OPENED BY
QUALIFIED PERSONNEL FOR MAINTENANCE PURPOSE (EXCEPT FOR OPPOSITE INSTRUCTIONS IN THE
USER’S MANUAL).
Technical Maintenance.
Refer all servicing to qualified maintenance personnel. Servicing is required when
apparatus has been damaged in any way, such as power supply cord is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or has been dropped.
THE QUALIFIED MAINTENANCE PERSONNEL MUST TAKE REASONABLE PRECAUTIONS TO FACE THE
OBVIOUS DANGERS.
Powers sources.
Only connect the apparatus to a power supply as described in the operating
instructions or as marked on the apparatus.
Turning off the power switch does not completely isolate this product from the power
line so remove the plug from the socket if not using it for extended period of time.
Unplug this apparatus during lightning storms.
Power cord protection.
Power supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords and
plugs, and the point where they exit from the appliance.

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 5
Grounding.
WARNING: THIS APPARATUS SHALL BE CONNECTED TO A MAINS SOCKET OUTLET WITH A
PROTECTIVE EARTHING CONNECTION.
THE APPLIANCE MUST BE CONNECTED TO AN ELECTRICAL GROUND AND THE POWER CORD IS
DESIGNED FOR THAT.
Linked first of all the mechanical mass (present gudgeon M4 at the rear of the
equipment). The product must be connected with an earth of protection by a green /
yellow cable with a section at least equal to 0.75 mm² with a round pod diameter 4 mm
containing a double setting and preservation on the ground wire.
Power supply cable and socket.
THIS APPARATUS MUST BE USED WITH A POWER SUPPLY CABLE OF 1 MM2 SECTION MINIMUM.
THE POWER SUPPLY SOCKET MUST BE LOCATED AT A DISTANCE OF LESS THAN 1.5 M FROM THE
EQUIPMENT AND EASILY ACCESSIBLE.
Battery replacement and disposal.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 6
Note: FCC Rules
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by Safran Data Systems Inc
may cause, harmful interference and void the FCC authorization to operate this equipment.

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 7
CE MARKING
Markings are placed at the rear of the unit, regarding the power ratings and compliance.
The symbol on the chassis indicates that it is in compliance with the Electromagnetic
Compatibility directive (2014/30/UE), the low Voltage directive (2014/35/UE) and RoHS directive
(2011/65/UE). A declaration of Conformity UE is available by contacting technical support. This
equipment is a:
✔Group 1 Class A product
Recommendation concerning the cabling:
CE certification has been carried out with 3-meter interconnecting cables with remote equipment.
SAFRAN DATA SYSTEMS recommends the use of high quality interconnecting cables type. The high
quality recommended user interconnecting cables are “shield twisted pair” or “coaxial cable” industrial
type with cable shield. The cable shield will provide the necessary mechanical protection.
Not using this high quality designed cable could result in unexpected intersystem / extra system
electromagnetic emission and susceptibility.

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 8
WEEE DIRECTIVE
(Directive applicable only in the European Community)
Markings are placed at the rear of the unit and on all electronic subassemblies, regarding the WEEE
directive:
DO NOT place the used equipment in regular waste bins.
All equipment marked with this logo must be recycled by an approved Waste Electrical and Electronic
Equipment processing facility. If desired, the equipment can be returned at the customers expenses to
Safran Data Systems for proper recycling, after asking for a RMA by sending a request to:
[e-mail]
Please consider the environmental cost of transportation of the used equipment and preferably use a
local WEEE processing facility.

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 9
INTERNATIONAL SECURITY STATEMENT
France, Canada: L'appareil doit être connecté à une prise de terre.
Suomi: Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan.
Norge: Apparatet må tilkoples jordet stikkontakt.
Sverige: Apparaten skall anslutas till jordat uttag.

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 10
CUSTOMER SUPPORT
In case of uncertainty regarding operation of this equipment, contact either your
reseller or the SAFRAN DATA SYSTEMS company at the following address :
Web Portal Access :
https://support.safran-data-systems.com/sd/
Email :
mail to: [e-mail]
SAFRAN DATA SYSTEMS
5, esplanade Anton Philips
14460 Colombelles
France
Tel. : [phone]
Fax : [phone]
Email :
mail to: [e-mail] or
[e-mail]
SAFRAN DATA SYSTEMS, INC
3005 Business Park Drive, Norcross, GA 30071
Tel : [phone]
Fax : [phone]

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 11
TABLE OF CONTENTS
1 AIM ................................................................................................................................................................................14
2 REFERENCES ...................................................................................................................................................................15
2.1 APPLICABLE DOCUMENTS.......................................................................................................................................................15
2.2 REFERENCE DOCUMENTS .......................................................................................................................................................15
2.3 ACRONYMS &ABBREVIATIONS................................................................................................................................................16
3 DESCRIPTION..................................................................................................................................................................20
3.1 GENERAL DESCRIPTION ..........................................................................................................................................................20
3.2 BASELINE............................................................................................................................................................................21
3.3 OPTIONS.............................................................................................................................................................................25
4 INSTALLATION ................................................................................................................................................................27
4.1 MECHANICAL.......................................................................................................................................................................27
4.2 STANDARD 19” RACK INTEGRATION .........................................................................................................................................28
4.3 THERMAL............................................................................................................................................................................28
4.4 ELECTRICAL .........................................................................................................................................................................29
4.4.1 Connector description ..............................................................................................................................................31
4.4.1 High-Density Sub-D 44 points connector “Data” .....................................................................................................33
4.4.2 Digital Out LEMO “Status” .......................................................................................................................................33
4.4.3 Specific Cables..........................................................................................................................................................34
4.4.4 Electrical Signals ......................................................................................................................................................35
4.5 ACCOUNTS CREDENTIALS........................................................................................................................................................36
4.6 SOFTWARE UPDATE ..............................................................................................................................................................37
4.6.1 OS installation ..........................................................................................................................................................37
4.6.2 SD Card Preparation.................................................................................................................................................39
4.6.3 RX-1 Upgrade ...........................................................................................................................................................39
4.7 OS HARDENING AND SECURITY UPDATES..................................................................................................................................41
5 LOCAL OPERATION .........................................................................................................................................................42
5.1 FRONT PANEL CONTROL ........................................................................................................................................................42
5.1.1 Display configuration ...............................................................................................................................................43
5.1.2 Graphic displays .......................................................................................................................................................45
5.1.3 Signal strength and data quality..............................................................................................................................47
5.1.4 Lock status ...............................................................................................................................................................48
5.1.5 Demodulator status .................................................................................................................................................48
5.1.6 Keyboard ..................................................................................................................................................................49
5.2 MAIN MENU SETTINGS .........................................................................................................................................................52
5.2.1 Frequency.................................................................................................................................................................53
5.2.2 Combiner mode........................................................................................................................................................54
5.2.3 IF Filter .....................................................................................................................................................................55
5.2.4 Modulation Scheme .................................................................................................................................................56
5.2.5 Bit Rate ....................................................................................................................................................................57
5.3 CONFIGURATION MENU ........................................................................................................................................................58
5.3.1 Data Configuration Sub-Menu .................................................................................................................................59

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 12
5.3.2 Tracking Configuration Sub-Menu ...........................................................................................................................62
5.3.3 Preset Configuration Sub-Menu...............................................................................................................................67
5.3.4 System Configuration Sub-Menu .............................................................................................................................68
5.3.5 Display Configuration Sub-Menu .............................................................................................................................72
5.3.6 Options Configuration Sub-Menu ............................................................................................................................74
5.3.7 Advanced Configuration Sub-Menu .........................................................................................................................86
6 REMOTE CONTROL INTERFACE .......................................................................................................................................95
7 SPECIFIC FUNCTIONS ......................................................................................................................................................96
7.1 INDEPENDENT CHANNELS CAPABILITIES .....................................................................................................................................96
7.1.1 Version E3Rx ............................................................................................................................................................96
7.1.2 Version E5Rx ............................................................................................................................................................97
7.2 PRE DCOMBINER .................................................................................................................................................................98
7.3 ZEROING FUNCTION. .............................................................................................................................................................99
7.4 AFC FEATURE....................................................................................................................................................................101
7.5 NOISE FIGURE MEASUREMENT .............................................................................................................................................102
7.6 POST-D COMBINER.............................................................................................................................................................103
7.6.1 Post-D –best channel. ...........................................................................................................................................103
7.6.2 Post-D in optimum mode. ......................................................................................................................................103
7.6.3 Internal Post-D combiner. ......................................................................................................................................104
7.6.4 External Post-D Combiner. .....................................................................................................................................105
7.7 ENHANCED ADAPTATIVE EQUALIZER.......................................................................................................................................107
7.8 DEMODULATORS................................................................................................................................................................108
7.8.1 Supported demodulation .......................................................................................................................................108
7.8.2 FM discrimator gain adjustment............................................................................................................................108
7.8.3 PCM-FM Trellis : modulation index mitigation ......................................................................................................110
7.9 QUALITY FACTOR................................................................................................................................................................112
7.10 FEC...............................................................................................................................................................................113
7.10.1 Convolutional decoding .......................................................................................................................................113
7.10.2 Reed Solomon decoding.......................................................................................................................................113
7.10.3 Turbo decoding ....................................................................................................................................................114
7.10.4 Low Density Parity Check .....................................................................................................................................114
7.10.5 Bitrate and Overhead...........................................................................................................................................114
7.11 DATA QUALITY ENCAPSULATION (DQE) AND DATA QUALITY METRIC (DQM).............................................................................115
7.11.1 DQE ......................................................................................................................................................................115
7.11.2 DQM.....................................................................................................................................................................116
7.12 FRAME SYNCHRONIZER CONFIGURATION DETAILS....................................................................................................................117
7.12.1 Sync Word Length ≤32 bits..................................................................................................................................119
7.12.2 Sync Word Length > 32 bits..................................................................................................................................121
7.13 TELEMETRY DATA STORAGE OPTION.....................................................................................................................................123
7.14 COFDM :SYNCHRONIZATION STATE MACHINE......................................................................................................................125
8 CHAPTER 10 CONFIGURATION FILE DESCRIPTION.........................................................................................................127
8.1 LOCATION.........................................................................................................................................................................127
8.2 DESCRIPTION.....................................................................................................................................................................127
8.2.1 <xml> tag ...............................................................................................................................................................127
8.2.2 <configuration> tag ...............................................................................................................................................127
9 REGISTRY PARAMETERS (FOR EXPERT USERS). .............................................................................................................130
9.1 TIME CODE .......................................................................................................................................................................130

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 13
9.2 TM SERVER UDP CONFIGURATION ........................................................................................................................................130
9.3 35MHZ SPURIOUS REJECTION ..............................................................................................................................................130
9.4 EXTRA COMMANDS.............................................................................................................................................................131
9.5 TCP/IP OR UDP/IP FRAME SETUP WITH REED SOLOMON FEC...................................................................................................131
9.6 TCP/IP OR UDP/IP FRAME SETUP WITH REED SOLOMON FEC (SOYUZ).......................................................................................132
9.7 TCP/IP OR UDP/IP FRAME SETUP WITH TPC FEC...................................................................................................................132
9.8 IRIG-B SETUP ...................................................................................................................................................................132
9.9 VIEWER SERVER..................................................................................................................................................................133
9.10 STORAGE CONFIGURATION.................................................................................................................................................133
9.11 MCS TCP INTERFACE CONFIGURATION.................................................................................................................................134
10 ALARMS DESCRIPTION................................................................................................................................................135
11 STANDARD TELEMETRY RECEIVER CONTROL INTERFACE ............................................................................................137
12 DD-1494 FORM EXAMPLE...........................................................................................................................................138

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 14
1 AIM
This user’s manual describes the relevant information for operating the Safran Data System (ZDS) RX-1
Compact Operational Receiver.
The RX-1 is a 1U dual-channel multiband telemetry receiver, including multi-mode TIER demodulators, bit-
synchronizers, and state-of-the-art signal processing functions enabling to get the most data from flight test
missions. Its compact size and all its interfaces allow its use for any kind of mobile or fixed tracking and
telemetry stations, up to a final delivery of data over Ethernet.

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 15
2 REFERENCES
2.1 Applicable Documents
[AD1]
IRIG106-17
(Range Commanders Council) Telemetry Standards
[AD2]
STI100013
General Cortex Ethernet Interface
[AD3]
STI100013_RTR
RTR Specific Ethernet interface
[AD4]
D109537
RX-1 Technical Specification
[AD5]
D130486
RTR-NeXt/RX1 Graphical User Interface Manual
[AD6]
CCSDS 131.0-B-2
TM Synchronization and Channel Coding
2.2 Reference Documents
[RD1]
MAQ10000
ZDS Quality Assurance

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 16
2.3 Acronyms & Abbreviations
SYMBOLS:
% Percent
Plus or minus
Greater than or equal
Less than or equal
And
Approximately
PREFIXES:
n Nano-
Micro-
m Milli-
k Kilo-
M Mega-
G Giga-
UNITS:
A Ampere
B Byte
bps Bit per second
C Celsius
dB Decibel
dBc dB with respect to the unmodulated carrier
F Farad
Hz Hertz
mm Millimeter
rpm revolutions per minute
Ohms
s Second
s/s Sample per second (ks/s, Ms/s,...)
V Volt

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 17
ABBREVIATIONS:
AC Alternative Current
AD Applicable Document
AFC Automatic Frequency Control
AGC Automatic Gain Control
AM Amplitude Modulation
APC Automatic Phase Control
AQSK Asynchronous Quadrature Phase Shift Keying
BER Bit Error Rate
BNC Bayonet Neill-Concelman
BP-L/M/S BiPhase-Level/Mark/Space
BPSK Binary Phase Shift Keying
BS Bit Synchronizer
BTs Bandwidth Filter per Symbol Period
BW Bandwidth
CCSDS Consultative Committee for Space Data System
CH10 Chapter 10
CLK Clock
CNR Carrier to Noise Ratio
CPFSK Continuous Phase Frequency Shift Keying
CPU Central Processing Unit
DC Direct Current
dBc dB with respect to the un-modulated carrier
DBP-L/M/S Differential Bi-Phase-Level/Mark/Space
DC Direct Current
DM-M/S Delay Modulation –Mark / Space (Miller code)
DQE Data Quality Encapsulation
DQM Data Quality Metric
DQPSK Differential Quadrature Phase Shift Keying
FCC Frame Code Complement
FEC Forward Error Correction
FFT Fast Fourier Transform

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 18
FM Frequency Modulation
FPGA Field-programmable Gate Array
FS Frame Synchronizer
FSK Frequency Shift Keying
GMSK Gaussian Minimum Shift Keying
GUI Graphical User Interface
H/W Hardware
IF Intermediate Frequency
IP Internet Protocol
I/O Input/Output
LAN Local Area Network
LCD Liquid Crystal display
LED Light Emitting Diode
LFO Low Frequency Output
LO Local Oscillator
LSB Least Significant Bit
MCS Monitoring & Control Software
MMI Man Machine Interface
MSB Most Significant Bit
MS-FM Multi Symbol Frequency Modulation
MSP Main Signal Processing
M&C Monitoring & Control
NA Not Applicable
NCO Numerically Controlled Oscillator
NRZ-L Non Return to Zero Level
NRZ-M Non Return to Zero Mark
NTSC National Television System Committee
OQPSK Offset Quadrature Phase Shift Keying (also called SQPSK)
PAL Phase Alternated Line
PCI Peripheral Component Interconnect
PCM Pulse Code Modulation
PLL Phase Locked Loop
PM Phase Modulation

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 19
pp Peak to peak
PRBS Pseudo Random Binary Sequence
PROM Programmable Read-Only-Memory
PS Power Supply
QPSK Quadrature Phase Shift Keying
RAM Random Access Memory
RF Radio Frequency
RMS Root Mean Square
R-S Reed Solomon
QPSK Quadrature Phase Shift Keying
RNRZ-L/M/S Randomized Non Return to Zero-Level/Mark/Space
RSR Radio Signal Recorder
RTR Radio Telemetry Receiver
RX-1 Compact Operational REceiver
SNR Signal to Noise Ratio
SOQPSK Shaped Offset Quadrature Phase Shift Keying
SPS Signal Processing Software
S/W Software
TBD To Be Defined
TCP/IP Transmission Control Protocol/Internet Protocol
TFT Thin-Film Transistor
TM Telemetry
UDP User Datagram Protocol
Vpp Volt Peak to Peak
SDSy Safran Data Systems

RX-1 Compact Operational Receiver
User's Manual
Ref. D104047
Is.Rev 08
Previous Ref.: -
Date: 21/06/2021
© Safran Data Systems –IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 20
3 DESCRIPTION
3.1 General description
The RX-1 is dedicated to IRIG106 telemetry reception, supporting any type of IRIG 106 telemetry signal in
P-, C-IF, L-, S- and C-band (optional) with 2 channels. It is used for both high dynamics tracking and
telemetry. The implementation of 8 pre-selection SAW filters allows the RX-1 to have excellent adjacent
channel rejection, better AGC regulation and high dynamics (>90dB). One direct consequence is its
capacity to maintain auto-track of the tracking antenna much farther as the AGC and AM signals can be
retrieved at a lower SNR.
Not only the RX-1 features a choice of 30 IF filters (from 3kHz to 40MHz) but customized filters can also be
implemented by firmware upgrade to better fit the customer specific application. In addition to a high-
performance pre-D combiner (available in Frequency and Polarization diversity) and an outstanding
Enhanced Adaptive Equalizer for multipath mitigation (optional), the RX-1 features a TIER multi-mode
demodulator with trellis for each channel (PCM/FM, SOQPSK-TG, ARTM-CPM) with excellent
performances, in terms of locking threshold, BER, as well as very short (re)acquisition time following a
signal loss.
It also features real time spectrum and eye pattern display for all channels (while demodulating), and a
thorough set of inputs and outputs. Furthermore, The RX-1 incorporates the latest features from IRIG-106
as LDPC decoders (optional).
A special option on the RX-1 allows the pre-d combining of two IF 70MHz signals played back from the
Cortex RSR into the RX-1 along with their digital AGC signals. Finally, the RX-1 has the capacity to
distribute the TM data over Ethernet (TMoIP) with embedded time stamp. TM data is raw (ie non-
synchronized). The format is either a proprietary native ZDS format or as per IRIG 106 chapter 10
standards. Both are compatible with a large number of software-based telemetry processing software used
to process, extract and display the parameters.
