SAGE SCIENCE INC
BluePippin Installation Guidelines
460009 Rev. A
Originated March 9, 2015
Revised:
Page 1of 7
Prepared by: Alex Vira
SUMMARY
This guideline documents requirements and procedures for users or Sage Science
Staff for installing the BluePippin instrument.
Notice of proprietary property
This document and the information contained in it are the proprietary property
of Sage Science Inc. It may not be copied or used in any manner nor may
any of the information in or upon it be used for any purpose without express
written consent from an authorized agent of Sage Science Inc.

SAGE SCIENCE INC.
BLUEPIPPIN INSTALLATION GUIDELINES
460011 Rev. A PAGE 2 OF 7 3/5/2015
Table of Contents
1.0 INTRODUCTION .......................................................................................................................... 3
1.1 Purpose.............................................................................................................................................. 3
1.2 Scope................................................................................................................................................. 3
1.3 Reference Documents....................................................................................................................... 3
1.4 Responsibilities................................................................................................................................. 3
2.0 BLUE-PIPPIN INSTALLATION REQUIREMENTS.................................................................... 4
2.1 Operating Conditions........................................................................................................................ 4
2.2 Safety ................................................................................................................................................ 4
2.3 Power Consumption and Heat .......................................................................................................... 4
2.4 Operating Power and Outlet Requirement........................................................................................ 4
2.5 Bench Space...................................................................................................................................... 4
3.0 BLUE-PIPPIN INSTALLATION PROCEDURE........................................................................... 5
3.1 Packaging and Components.............................................................................................................. 5
3.2 Installation......................................................................................................................................... 6
Figures
2.1 Instrument and Monitor Dimensions……………………………………………………………...…5
3.1 Rear Panel of the BluePippin………………….………….………………………..……...…………7
3.2 Front Panel of the BluePippin and Cassette Nest……….…………………………...………………7

SAGE SCIENCE INC.
BLUEPIPPIN INSTALLATION GUIDELINES
460011 Rev. A PAGE 3 OF 7 3/5/2015
1.0 INTRODUCTION
1.1 Purpose
This guideline documents requirements and procedures for users or Sage Science Staff for
installing the BluePippin system.
1.2 Scope
This document encompasses the requirements, conditions, and steps for the installation of the
BluePippin instrument. This document will be used by Sage Science personnel and Sage
Science customers or collaborators.
1.3 Reference Documents
460013, BluePippin Operations Manual
All at the latest revision.
1.4 Responsibilities
The Sage Science Applications Lab Director or designee will be responsible to ensure that this
procedure is implemented.

SAGE SCIENCE INC.
BLUEPIPPIN INSTALLATION GUIDELINES
460011 Rev. A PAGE 4 OF 7 3/5/2015
2.0 BLUE-PIPPIN INSTALLATION REQUIREMENTS
2.1 Operating Conditions
The BluePippin system is designed to operate under the following environmental conditions:
Pollution Degree 2
Installation category 2
Max. Altitude 2000m
Indoor use
Ambient temperature 17-25oC
Humidity 10-80%, non-condensing
2.2 Safety
Standard laboratory precautions should be taken when handling BluePippin Gel cassettes and
operating the BluePippin:
Wear a lab coat, safety glasses, and gloves.
Use in proximity of an eye wash station and/or running water
2.3 Power Consumption and Heat
At maximum power consumption, the BluePippin generates approximately 100Watts
(340 BTU/hr)
2.4 Operating Power and Outlet Requirement
Two 110V (or 220V) outlets are required:
BluePippin instrument
LCD monitor
2.5 Bench Space
A 30” X 30” area is recommended for operation of the BluePippin and preparation of Gel
cassettes, based on a 30” deep bench. Minimally, a depth of 18” will suffice.
BluePippin instrument dimensions:
11”W x 7”H x 21”D (28 x 18 x 53 cm)

SAGE SCIENCE INC.
BLUEPIPPIN INSTALLATION GUIDELINES
460011 Rev. A PAGE 5 OF 7 3/5/2015
2.5 Bench Space (cont’d)
LCD monitor dimensions (including stand):
17.5”W x 13”H x 7” D (44 x 33 x 18 cm)
Figure 2.1. Instrument and Monitor Dimensions
3.0 BLUE-PIPPIN INSTALLATION PROCEDURE
3.1 Packaging and Components
The system is shipped in two boxes: one will contain the BluePippin instrument and accessories,
and the second box will contain the computer monitor in the manufacturer’s original packaging.
With the boxes in the upright position, open and confirm that the following items are enclosed:
Monitor
LCD computer monitor
VGA video cable
Power supply
Power cord
BluePippin
BluePippin Instrument
Accessory box
oComputer keyboard, USB
oComputer mouse, USB
oPower supply
oPower cord
oRinse Cassette
oOptical Calibration fixture
oOperation Manual
Optical calibration
fixture with protective
cover
Rinse cassette

SAGE SCIENCE INC.
BLUEPIPPIN INSTALLATION GUIDELINES
460011 Rev. A PAGE 6 OF 7 3/5/2015
3.2 Installation
1. Open the LCD monitor box, and assemble it according to the manufacturer instructions
2. Cut the top seal on the BluePippin box, and open. Remove the upper foam rubber insert.
3. Remove the accessory box and place it on a benchtop. It is a white box (on its side) in the front of the
foam rubber inserts. Remove the keyboard, mouse, and instrument power supply and cords from
BluePippin their packaging.
4. Grip the front bottom and back top of the instrument and lift it from the box. The BluePippin weighs
approximately 15 lbs.Place the unit onto the bench top.
5. Connect the LCD monitor (VGA port, under the screen) to the BluePippin (VGA port, back panel, see
Figure 3.1) using supplied video cable.
6. Using the power cord and power supply provided by the manufacturer, plug the monitor into an electrical
outlet.
7. Turn on the monitor.
8. Insert the USB connector from the computer keyboard into any USB port located on the back panel of
the BleuPippin (Figure 3.1).
9. Insert the USB connector from the computer mouse into any USB port located on the back panel of the
BluePippin (Figure 3.1).
10. Connect BluePippin instrument to the power outlet using the BluePippin power supply and power cable.
The power input connector is in the lower right hand corner on the back panel of the BluePippin (Figure
3.1).
11. When connected to power, the blue leds on the instrument nest will be lit at all times.
12. Press the power button. It is located on the left side of the back panel (Figure 3.1).
13. When powered on, the blue light on the front panel of the Instrument will turn on (Figure 3.2).
14. When powered on, the software will launch (this will take approximately 30 –60 seconds).

SAGE SCIENCE INC.
BLUEPIPPIN INSTALLATION GUIDELINES
460011 Rev. A PAGE 7 OF 7 3/5/2015
Figure 3.1 Rear Panel of the BluePippin
Power Button
Power Entry Port
VGA Video Port
USB Ports (4)
Nest LED lights are on
at all times when
connected to power.
After the power button
is pressed, the front
panel Blue LED will
light, and the software
will launch.
Figure 3.2 Front Panel of the BluePippin and cassette nest
When running
a protocol, a
green light is
also indicated on
the front panel.
